Ruby Devices Ruby Calculator Ultimate Edition User manual

User Manual
Ruby Calculator Ultimate Edition

2
User Manual
Hhhhhhh__hRuby Calculator Ultimate Editionhhhhhhhh_
Contents
1. Operating Modes ....................................................................................................................... 3
2. Chat Mode Guide ...................................................................................................................... 4
3. Smash Mode Guide .................................................................................................................. 8
4. How to Connect Two Ruby Calculators ......................................................................... 9
5. How to Connect to an iOS Smart Phone .................................................................... 10
6. How to Transfer Text Files to the Calculator for Storage ................................... 11
7. How to Connect to an Android Smart Phone ........................................................... 12
8. How to Connect to a Smart Phone through the Internet .................................... 13
9. How to Connect to a PC or Mac………………………………………………………….. 14
10. Scientific Calculator Functionality………………………………………………………..15
11. Support ........................................................................................................................................ 16
Document V: 17.0a

3
Hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh_
1. Operating Modes
The Ruby Calculator will operate in one of three modes at any given time. The
default mode upon power up of the calculator is “Calculator Mode”. In this mode
the calculator will work as a normal scientific calculator with the limitations as
outlined in Section 10.
To form a chat session with another device the calculator will need to enter “Chat
Mode”. Prior to being able to enter chat mode, however, the calculator will need to
receive a password from the user. The default password is “123456”. Simply enter
this value into the calculator and hit the “Equals” button. (Note that this default
password may be changed; see Section 2)
Once this has been done the calculator may now enter “Chat Mode” by hitting the
“MODE/CLR” button. See Section 2 for a description of the functionality of buttons
in “Chat Mode”.
Once in Chat Mode the user may press the “SHIFT” button followed by the
“MODE/CLR” button to enter “Smash Mode”.
“Smash Mode” is a special mode for extra fast typing; see Section 3 for further
details.

4
2. Chat Mode Guide
Once in “Chat Mode” buttons take on different functionality. Descriptions of the
functionality for the above highlighted buttons are given below.
1. The “SHIFT” button provides secondary functionality.
2. The “ALPHA” button will cause the Ruby Calculator to attempt to connect to
another Ruby Calculator within range. If the Ruby Calculator is already
connected to a device this button will alert the user that the calculator is already
connected.

5
3. The “x
-1
” button is used to change the Chat Mode password. Press the “Equals”
button after typing in the nominated password.
4. The brackets buttons are used for scrolling through received messages. The
brackets buttons are also used for fast file navigation. Pressing the “)” button on
an opened file will skip 10 pages through the file. Pressing the “SHIFT” button
followed by the “)” button will skip to the end of the file. The other bracket button
does the same but skips towards the start of the file.
5. The “RCL” button is used for reading stored text files and adding new text files
from the RXO Chat App. After pressing the “RCL” button use the “Left” and
“Right” arrow keys to select a file. To write a new file to a slot hit the “Transfer
File” button on the RXO Chat App after selecting the desired file slot. To delete a
file from a slot press the “DEL” button after selecting the desired file. To read the
contents of a file hit the “Equals” button after selecting the desired file. You may
then use the left and right arrow keys to browse through the contents of the file.
6. The “Number Pad” becomes a pad for typing alphanumeric sentences in “Chat
Mode”. Refer to the diagram below for a visual aid of the functionality of the pad.
Type like the pad is from an old school mobile phone. Hitting a button once more
than the number of letters contained will print the number corresponding to that
button, eg hitting “abc” four times in succession will print the number “8”. If the
user wishes to type faster messages than this mode can offer they may enter
“Smash Mode” and turn the entire calculator into a keyboard. See Section 3.
7. The “MODE/CLR” button switches the calculator between “Calculator Mode”
and “Chat Mode”. Note that after establishing a connection the user may
alternate between the modes and will still receive messages when in “Calculator
Mode”.
If the user presses the “SHIFT” button followed by the “MODE/CLR” button while
in “Chat Mode” the calculator will enter “Smash Mode”. See section 3 for a
description of Smash Mode.

6
8. The “Pol(“ button will cause the Ruby Calculator to disconnect from any
connected devices. This button is necessary when the user wishes to switch the
calculator from one device to another.
This button contains secondary functionality. Press “SHIFT” followed by “Pol(“ to
toggle the state of the Bluetooth on the calculator between on and off. This may
be useful if the user only wishes to use the note storage feature and would like to
turn their Bluetooth off.
9.
The “^” button will open the “Special Symbol” palette. Although users are able to
type all standard alphanumeric characters and numbers using the Number Pad
they may like to type special symbols like letters from the Greek Alphabet or
Mathematical Symbols. This palette will allow the user to do so. See below for a
visual description of characters included in the Special Symbol palette.
10. The “sin(” button is the Auto-Scroll button for file reading. If the user wishes for a
file to automatically scroll page by page through a file without having to touch
the calculator they may push this button to enable or disable auto-scrolling. To
enable or disable Auto-Scrolling the user should push this button while reading a
file to toggle the state of the feature. The default auto-scroll time if 5 seconds per
page; this time interval may be modified by pressing the same “sin(“ button while
in standard Chat Mode – that is, not while the file reader is open.

7
11. The “tan(“ button is used for searching the internet. Type in a query while in Chat
Mode and then press this button to retrieve search engine results to the
calculator. Use the “M+” button to read the received search results.
The “tan(“ button is also used for the File Search feature. While reading a stored
file press the “tan(“ button. Next, type in your search query using the number
pad. Finally, press the “Equals” button to execute the search and you will
automatically skip through the file until the next occurrence of the query is found.
After executing a File Search you may want to then skip again to the next
occurrence of the query without re-typing the query again. To do so, simply press
the “SHIFT” button followed by the “tan(“ button to skip immediately to the next
occurrence from the previously entered search query.
12. The “M+” button allows the user to cycle through large received messages that
are larger than the size of the screen. See below for a visual description of what
pushing this button does to the screen.
13. The “,” button is the Emergency/Panic button. Pressing this button will force the
calculator out of “Chat Mode” and relock the device. The password will need to
be re-entered for all “Chat Mode” functionality to resume.
14. The “Equals” button in “Chat Mode” will send the typed message to the
connected device. If no device is connected this button will alert the user that no
devices are connected.
The “Equals” button also offers a feature in “Calculator Mode”. While in
Calculator Mode the “Equals” button will naturally evaluate the given expression.
What the user may then do, however, is press the “SHIFT” button followed by the
“Equals” button which will send the last evaluated expression and result to any
connected devices.

8
3. Smash Mode Guide
To enter “Smash Mode” first enter “Chat Mode” and then press the “SHIFT” button
followed by the “MODE/CLR” button.
Once in “Smash Mode” buttons take on a different functionality. The entire button
pad is transformed into a keyboard for fast typing. A visual description of “Smash
Mode” is given below.

9
4. How to Connect Two Ruby Calculators
To connect two Ruby Calculators to each other perform the following steps.

Power on both calculators.

Type the “Chat Mode” password on both calculators and hit the “Equals/=”
buttons. The default password is “123456” to unlock “Chat Mode”.

Enter “Chat Mode” on both calculators by hitting the “MODE/CLR” buttons.

On one of the calculators press the “ALPHA” button. This button will cause
the calculator to search for another Ruby Calculator and automatically
connect if it finds one.

After observing the “Connection Established” message the users may begin
sending messages. The “Equals” button will send a typed message.

10
5. How to Connect to an iOS Smart Phone
To connect a Ruby Calculator to an iOS Smart Phone perform the following steps.

Download the app by Ruby Devices entitled “RXO Chat” from the Apple App
Store.

Switch on the Ruby Calculator and enter “Chat Mode”.

Switch on Bluetooth on the Apple device.

Start up the app and click on “Connect Now” as shown in the screenshot
below

Begin to chat.

11
6. How to Transfer Text Files to the Calculator for Storage
To transfer a text file to the Ruby Calculator perform the following steps.

Enter “Chat Mode”

Hit the “RCL” button to open the file storage

Select the slot you would like to transfer the text file to by using the “Left” and
“Right” arrow keys for navigation.

Connect to the Ruby Calculator using the RXO Chat app on an iOS or
Android device.

On your iOS device select the “File Transfer” button.

On your iOS device enter a “File Name” and paste in the “Notes” you would
like to store.

Select the “Transfer File” button to load the file onto the calculator. See
below for a visual aid of how the setup should look. In the example we are
transferred the file to slot number ten. Open a file using the “Equals” button.
Delete a file using the “DEL” button.

12
7. How to Connect to an Android Smart Phone
To connect the Ruby Calculator to an Android Smart Phone perform the following
steps.

Download the App entitled “RXO Chat” from the Google Play Store.

Follow the steps outlined for the iOS App. The Apps operate identically.

13
8. How to Connect to a Smart Phone through the Internet
Connecting a Ruby Calculator to a Smart Device through the Internet requires two
Smart Devices. This is because the Calculators do not have a Wi-Fi module so they
will need to utilize a phone to forward the messages.
The First Smart Phone will enter Tunnel Mode. In Tunnel Mode the Smart Phone
will connect to the Calculator using Bluetooth. The Tunnel Device must stay within
50 meters of the Calculator. The Tunnel Device must have an Internet
Connection. The Tunnel Device may be hidden somewhere on the user.
The Second Smart Phone will enter Internet Mode. The Internet Mode Device may
be anywhere in the world as long as this device has an Internet Connection.
Now when the user sends a message from the calculator the message will go
through the Tunnel Device and on to the Internet Mode Device and vice-versa.
To use this feature perform the following steps:

Open up the settings page on both the Tunnel and Internet device and
enter in your unique Internet and Tunnel ID given to you upon purchase.

Select the appropriate mode for both the Tunnel and Internet device.

Select “Done”. The “Chat” button will now establish the Internet Connection.

14
9. How to Connect to a PC or Mac
To connect your Ruby Calculator to a PC or Mac you will need to use the “RXO Chat
Web App”. To access the web app perform the following steps:

Open up a browser session on your PC or Mac and navigate to the following
URL:
www.rubydevices.com.au/rxo-chat.php

Log in to the Web App using your Tunnel and Internet Mode credentials.

Next, start RXO Chat on a smart phone and connect to your Ruby Calculator
in Tunnel Mode as described in Section 8.
Messages sent will now traverse between the computer and calculator.

15
10. Scientific Calculator Functionality
There are several buttons which exist for display purposes only on the calculator
and do not have any functionality in “Calculator Mode”. These buttons are
highlighted in blue below.
Furthermore, please note that this calculator uses 32-bit floating point arithmetic
and will consequently begin to lose accuracy in results after approximately 6
significant figures.

16
11. Support
For Customer Support or General Enquires please contact Ruby Devices at
the following email: [e-mail]
