Rugged Ridge NITRO BEE User manual

NITRO BEE
USER MANUAL VERSION 1.3.0

2
CONTENTS
Quick Start Guide
Controls
Connections
Rechargeable Battery
Getting Acquainted
Changing Frequencies
Modes of Operation
Mode Selection
Channel Group Selection
Saving Channel Presets
PC Programing
Squelch
Tone Codes
Dimmer
Scan
03
05
06
09
09
09
10
11
11
12
12
13
13
14
14
Key Beeps
Backlight
Autolock
Timer
Charging
Audio Priority
Specifications
FCC Statement
Warranty
Notes
14
14
14
15
15
15
16
17
18
19

3
QUICK START GUIDE
NITRO BEE
• POWER ON NITROBEE BY HOLDING DOWN [ ] BUTTON UNTIL
DEVICE POWERS ON
• USE THE UP AND DOWN KEYS TO SELECT THE FREQUENCY DESIRED
DEFAULT FREQUENCY IS 454.0000
• LONG PRESS UP AND DOWN KEYS TO MOVE FASTER THROUGH THE
FREQUENCY LIST
• P1 AND P2 ARE PREPROGRAMMED
P1: 454.0000
P2: 464.5500
• TO SAVE YOUR FREQUENCY IN THE PRESETS, PRESS AND HOLD
P1 OR P2 UNTIL P1 OR P2 APPEAR ON THE DISPLAY UNDER YOUR
FREQUENCY, INDICATING YOUR FREQUENCY HAS BEEN SAVED
• ADJUST VOLUME LEVELS BY PRESSING THE + FOR VOLUME UP AND
THE - FOR VOLUME DOWN
• ONCE YOUR FREQUENCY AND VOLUME LEVEL ARE SET YOU
CAN LOCK THE DEVICE BY PRESSING THE [LOCK] BUTTON UNTIL
“LOCKED!” APPEARS ON THE DISPLAY
• TO POWER OFF THE NITROBEE, PRESS AND HOLD THE [ ] BUTTON
UNTIL “PRESS [LOCK] BUTTON TO POWER OFF!!” APPEARS ON THE
DISPLAY. PRESS [LOCK] TO CONFIRM POWER OFF

4
CONTROLS
VOLUME ADJUST BUTTONS
PRESET CHANNEL 1
PRESET CHANNEL 2
POWER/MENU LOCKSCROLL

5
CONTROLS
PRESET CHANNELS
Quick-press [P1/P2] to shortcut to the preset channel.
Long press [P1/P2] to save current channel or frequency
as a preset channel.
VOLUME ADJUST BUTTONS
Quick-press [+ −] to adjust volume up or down.
LOCK
Quick-press [ ] when in menu to go back.
Long-press [ ] to lock or unlock display
SCROLL
Quick-press [ ] to scroll up or down.
Long-press [ ] to fast scroll up or down.
POWER/MENU
To power on, long press [ ].
When on, quick press [ ] to open menu.
When in menu, quick press [ ] to accept.
To power off, long press [ ] then quick
press [ ] when prompted.

6
CONNECTIONS
AUDIO INPUT [2.5MM STEREO]
CHARGE PORT [USB-C]
AUDIO OUTPUT [3.5MM STEREO]

7
NITRO ADAPTER
• The Nitro Bee can be integrated with a single-seat
car harness and 2-way radio using accessory
cable CS-NITRO-ADPT-2.
• In this configuration, the driver can transmit and
receive on a 2-way radio normally.
• When a Race Control call is received, the Nitro
Bee mutes 2-way radio audio, giving Race Control
audio priority so the driver does not miss critical
race communications.
(See diagram on next page)

8

9
RECHARGEABLE BATTERY
The Nitro Bee uses an internal, Fast-Charge, lithium-ion
(Li-ion) rechargeable battery. It should be charged prior
to use with the included USB-C charge cable. The battery
indicator LED will illuminate red while charging and green
when fully charged. When fully depleted, the Nitro Bee
requires approximately 2.5 hour charge time to reach full
charge.

10
GETTING ACQUAINTED
To change the frequency use the scroll buttons. Once
the desired frequency is found, lock the keypad to prevent
accidental changes. To lock the keypad, press and hold the
Lock Button until you see “Locked!” appear on the display. To
unlock the keypad, press and hold the Lock Button until you
see “Unlocked!” appear on the display.
CHANGING FREQUENCIES
Saved Channels: In this mode, the Nitro Bee operates on
channels that have been saved to memory. Software is
available to add and remove channels.
Manual Input: In this mode, users can manually tune to any
frequency between 400 and 480mHz.
MODES OF OPERATION

11
In the Ch. Group menu, use the scroll buttons to select the
desired zone and press [ ] to confirm selection.
CHANNEL GROUP SELECTION
GETTING ACQUAINTED
Press [ ] > Select Ch. Mode > Select “Saved Channels” or
“Manual Input”, press OK
To select from the preprogrammed (Saved Channels)
Switch to “Saved Channels” mode: [ ] > [Ch. Mode] > [Saved
Channels]
Select desired Channel Group: [ ] > Ch. Group > scroll to
desired group and press OK.
Scroll up / down to select the desired channel, lock the
keypad to prevent accidental changes.
MODE SELECTION

12
P1: To save channels to the P1 preset button, select the
desired channel or frequency, then long-press P1 to save.
Once saved, Pressing P1 shortcuts the Nitro Bee to the
preset channel.
P2: To save channels to the P2 preset button, select the
desired channel or frequency, then long-press P2 to save.
Once saved, Pressing P2 shortcuts the Nitro Bee to the
preset channel.
SAVING CHANNEL PRESETS
Channels can also be saved (with alpha-tags) via PC
programming software, available from RT Systems Inc
software.
PC PROGRAMMING
GETTING ACQUAINTED

13
To add Tone Codes
Press [ ] > [ToneCodes] > [Type] > scroll up/down to the
desired tone code type, press OK
Press [ ] > [ToneCodes] > [Code] > scroll up/down to the
desired tone code, press OK.
Adjusting the Squelch setting increases or decreases the
sensitivity of the Nitro Bee receiver.
To adjust Squelch setting: Press [ ] > [Squelch Adj] > scroll
up/down to the desired squelch level, press OK
A Squelch setting of 1 means the Nitro Bee is at its most
sensitive setting (good for receiving weak radio signals).
A Squelch setting of 9 means the Nitro Bee is at its least
sensitive setting (good for blocking unwanted signals).
TONE CODES
SQUELCH
GETTING ACQUAINTED

14
Enabling this function automatically locks the keypad after
the selected time.
[ ] > [Settings] > [Auto Lock] > 5s / 10s / 15s
AUTOLOCK
[] > [Settings] > [Back Light] > [Dimmer] > up / down to
select desired brightness, press OK
DIMMER
The Nitro Bee has an adjustable backlight. Both brightness
and the duration of illumination can be adjusted.
BACKLIGHT
Turns audible button press beeps on / off
[ ] > Settings > Key Beeps > On / Off
KEY BEEPS
This function scans Saved Channels or all frequencies
between 400-480mHz (depending on active mode)
[ ] > Settings > Scan > On / Off
SCAN
GETTING ACQUAINTED

15
The Nitro Bee can be used on its own with earbuds or
speakers connected directly to the 3.5mm jack for listening
to Race Control or other radio calls.
Alternatively, the Nitro Bee can be used in conjunction with
a 2-way radio system (using cable PN: CS-NITRO-ADPT-2) to
allow two-way radio use, while giving Nitro Bee audio priority
over 2-way radio calls. This audio priority function is required
by many racing sanctioning bodies that allow 2-way radio
use.
AUDIO PRIORITY
The Nitro Bee uses a USB-C programming port and can be
charged using most USB-C charge cables. The charge time
for a fully depleted battery is approximately 2.5 hours (varies
depending on the power output of the USB port.
CHARGING
GETTING ACQUAINTED
[] > [Settings] > [Backlight] > [Timer] > up / down to select
5s, 10s, 15s, 20s, 25s, 30s, Press OK
TIMER

16
SPECIFICATIONS
Battery Capacity: 1000mAh
Charge time: 2.5 hours (approximate)
Runtime: 4-5 hours (varies with volume setting)
Frequency Range: 400-480 mHz
Channel Capacity: 10,000
(10 separate groups, up to 1,000 channels each group)
Analog Sensitivity: 0.2μV @ 12dB SINAD
Digital Sensitivity: 0.25uV(BER:5%)
Adjacent channels selectivity: ≤[email protected]
Inter-modulation: ≥65dB
Spurious response: ≥70dB
Audio response: +1~-3dB
Audio distortion: <5%
Audio power: 1W
FM Noise ≥45dB@25KHz /≥40dB @12.5KHz

17
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to
the condition that this device does not cause harmful interference. NOTE: THE
GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE.
SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE
THE EQUIPMENT. This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates and can radiate radio
frequency energy. If not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. Verification
of harmful interference by this equipment to radio or television reception can
be determined by turning it off and then on. The user is encouraged to try to
correct the interference by one or more of the following measures: •Reorient
or relocate the receiving antenna. •Increase the separation between the
equipment and receiver. •Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected. •Consult the dealer or an
experienced radio/TV technician for help.
MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR RADIOTELEPHONE
SERVICE SIGNALS IS PROHIBITED UNDER IC RULES AND FEDERAL LAW.

18
WARRANTY
We guarantee our Radios, Intercoms & Headsets to be free from manufacturing
defects in material and workmanship under normal use for a period of three (3)
years from the date of purchase. Aviation headsets are warrantied 7 years. All
other Rugged Radios branded products carry a one year warranty.
In the event that a defect covered by the warranty occurs during the applicable
period stated above, Rugged Radios, at its discretion, will either repair or replace
the product; such action on the part of Rugged Radios shall be the full extent of
Rugged Radios’ liability and the Customer’s sole and exclusive reparation.
Rugged Radios shall not be responsible for any defects or damage that in
Rugged Radios’ view are a result from the mishandling, abuse, misuse, improper
storage or improper operation of the device, including use in conjunction with
equipment that is electronically or mechanically incompatible with, or of inferior
quality to, the product, as well as failure to maintain the environmental conditions
specified by the manufacturer.
Note: Features & Specifications are subject to change without notice. Rugged
Radios is not responsible for unintentional errors or omissions on its packaging.

19
NOTES

WWW.RUGGEDRADIOS.COM
