Runco CRYSTAL CX-70DHD User manual

CX-70DHD
1080p, High-Definition Flat Panel LCD
and Digital High Definition (DHD) Controller/Scaler/Processor
with
INSTALLATION/OPERATION MANUAL

CX-70DHD Installation/Operation Manual iii
PRELIMINARY
RuncoCare™ Standard Two Year Limited
Warranty
Congratulations on your purchase of a Runco® product! With proper installation, setup and care, you should enjoy many years
of unparalleled video performance.
This RuncoCare Standard Limited Warranty is provided free of charge by Runco International with the purchase of a covered
Runco product. The following sets forth Runco’s Standard Limited Warranty applicable to all Runco projectors, processors,
LCD and plasma display products, with the exception of the following models: XP-103DHD, SC-1, SC-1a and VW-100HD1.
The following terms and conditions of the RuncoCare Standard Limited Warranty represent a contract between us, Runco
International and you, the customer who has purchased a Runco product. This contract applies to purchases of covered
Runco products occurring on or after September 1, 2008. Runco reserves the right to change the terms of this contract, and
such changes shall apply to purchases of covered Runco products that occur on or after any future effective date.
• Two-year protection from defects in material and workmanship
• Access to 24x7 phone support
• Complimentary, second-day one-way shipping
Runco warrants its products to be free from defects in material and workmanship during the warranty period provided below.
If, in Runco’s determination, a product proves to be defective in material or workmanship during the warranty period, Runco
will repair the product, replace the product with a similar new or like new product, or refund a prorata share of the purchase
price (calculated based on the remainder of the warranty period and the thencurrent MSRP2of a similar product), if repair or
replacement of the product is determined by Runco to not be feasible.
Runco products are warranted for two (2) years from the date of shipment from Runco. Lamps are warranted six (6) months
from the date of shipment or 1000 hours, whichever comes first. All other accessories, which includes, but is not limited to,
cables, remotes, carrying cases, lens cap and other peripherals sold with the Runco product, are warranted for ninety (90)
days from the date of shipment. Repaired product or replacement lamp is subsequently warranted for the remaining portion (if
any) of the original warranty term or 90 days from the date the product was shipped to you, whichever is longer.
This RuncoCare Standard Limited Warranty is valid only for the first customer who purchases the covered product from an
authorized Runco dealer or distributor. This warranty is not transferable. You may be required to provide proof of purchase in
order to receive warranty services.
1. Runco may update this list of products excluded from this warranty from time to time at Runco’s sole discretion, but updates to
the list of covered products will not apply on a retroactive basis.
RuncoCare Standard Features
Warranty Coverage
2. MSRP is defined as the most recent product price listed on Runco’s price list.
Length of Warranty
Eligibility

iv CX-70DHD Installation/Operation Manual
PRELIMINARY
In the event of a product defect, please follow the warranty claim procedure provided below:
1. The Customer is required to contact a Runco dealer or Runco Technical Support via email at [e-mail] or via
phone at (toll free) 800-23RUNCO (800-237-8626). If the customer is located outside North America, call [phone]
in Europe for product service.
2. Be prepared to provide the date of purchase, the place of purchase, serial number, product model number, description of
the problem and troubleshooting steps already attempted.
3. Runco Technical Support staff will attempt to correct any minor issues that may be causing the problem. If Runco is
unable to fix the problem to the customer’s satisfaction, Runco will issue a Return Material Authorization (RMA) if it is
determined that the claim was made within the coverage period of the Standard Limited Warranty.
4. The customer will need to return the defective product to the Runco repair depot location specified by the Runco technical
support representative. The customer will need to properly package the defective product, consisting of the product only,
and not include any accessories (e.g., cables, remotes, carrying cases, lens, lens cap and other peripherals) and return it
to the Runco repair depot specified by the technical support representative. It is the customer’s responsibility to properly
package the hardware, include all appropriate materials, and return it to the location specified by the Runco technical
support department. The customer will need to address and resolve any shipping damage claims directly with the shipping
company.
5. The customer is responsible for providing a suitable box to ship the defective product to an authorized Runco repair depot.
Boxes may be purchased from a Runco technical support representative.
6. The customer is responsible for paying freight charges to ship the defective product to an authorized Runco repair depot.
7. Runco will pay freight charges to return the repaired/replacement product to the customer from the Runco repair depot.
8. Once an RMA has been created, the customer may contact serviceorder[email protected] for followup questions or
confirmation status of the claim process.
This RuncoCare Standard Limited Warranty does not include or is limited by the following:
1. Products not purchased from an authorized Runco dealer
2. Rental costs incurred by the customer in the event of product defect or failure
3. Any product with a defaced, modified, or removed serial number
4. Damage, deterioration, or malfunction resulting from:
a Accident, abuse, misuse, neglect, improper ventilation, fire, water, disaster, lightning, or other acts of nature, smoke
exposure (cigarette or otherwise), unauthorized product modification (including use of an unauthorized mount), or failure
to follow instructions supplied with the product
b Repair or attempted repair by anyone not authorized by Runco
c Any damage to the product due to shipment
d Removal or installation of the product
e Causes external to the product, such as electric power fluctuations or failure
f Use of supplies or parts not meeting Runco’s specifications
g Normal wear and tear
h Expected lamp degradation and normal decrease in lamp output over a period of time or as the lamp is consumed
i Customer caused defects, including but not limited to, scratched/defaced/altered plastics
RuncoCare Claim Procedure
Warranty Exclusions

CX-70DHD Installation/Operation Manual v
PRELIMINARY
j Failure to follow maintenance procedures as outlined in the product’s user guide where a schedule is specified for
regular cleaning of the product
k Opening the product and/or tampering with internal circuitry
l Products lost, stolen or discarded
m Any damage or dissatisfaction associated with latent images, “burnin,” or any other damage determined by Runco to be
the result of customer use patterns
n Any other cause, which does not relate to a product defect in material or workmanship
5. Removal, installation, and setup service charges are excluded from this Standard Limited warranty
6. Runco’s warranty does not cover black uniformity issues or other LCD issues associated with usage outside the Runco
recommended guidelines and specifications for the product
7. Second day shipment delivery time and availability may vary based on origin and destination and Runco is unable to deliver
to PO Box and FPO Box addresses
Runco offers extended and expanded service plans. For information on additional product protection, please email
[e-mail] or call (toll free) 800-23RUNCO (800-237-8626).
Please visit http://www.runco.com/info.html to register product.
RUNCO PROVIDES NO WARRANTIES, EXPRESS OR IMPLIED, EXCEPT THOSE EXPRESSLY PROVIDED HEREIN. RUNCO
EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
Extended Service Options
Online Product Registration
Limitation of Implied Warranties

vi CX-70DHD Installation/Operation Manual
PRELIMINARY
RUNCO’S MAXIMUM AGGREGATE LIABILITY HEREUNDER IS LIMITED TO THE COST OF REPAIR OR REPLACEMENT OF
THE PRODUCT.
1. RUNCO SHALL NOT BE LIABLE FOR DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECT IN THE PRODUCT,
DAMAGES BASED UPON INCONVENIENCE, LOSS OF USE OF THE PRODUCT, LOSS OF TIME, LOSS OF PROFITS,
LOSS OF BUSINESS OPPORTUNITY, LOSS OF GOODWILL, INTERFERENCE WITH BUSINESS RELATIONSHIPS, OR
OTHER COMMERCIAL LOSS, EVEN IF THE CUSTOMER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
2. RUNCO SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, INDIRECT, SPECIAL, OR PUNITIVE
DAMAGES ANY OTHER DAMAGES, WHETHER INCIDENTAL, INDIRECT, CONSEQUENTIAL OR OTHERWISE.
3. RUNCO SHALL NOT BE LIABLE FOR ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.
This warranty gives you specific legal rights, and you may have other rights, which vary from locality to locality. Some localities
do not allow limitations on implied warranties and/or do not allow the exclusion of incidental or consequential damages, so the
above limitations and exclusions may not apply to you.
© Copyright 2009 Runco International, LLC (“Runco”). This document contains proprietary information protected by copyright,
trademark and other intellectual property laws. All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic or other means, in any form, without prior written permission of Runco.
The trademarks reporduced in this Runco Owner’s Manual and used on the Runco Products are either owned by Runco or are
licensed by Runco. You may not reproduce or use the trademarks without the prior written consent of Runco.
Runco Products are manufactured under one or more of the following patents: US. Patent 6755540 and Other Patents
Pending.
Exclusion of Damages
Effect of Local Law
COPYRIGHT AND TRADEMARKS:

CX-70DHD Installation/Operation Manual vii
PRELIMINARY
Thank you for your purchase of this quality Runco video product! It has been designed to provide you with the quality of video
that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the
menus and operation.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for the replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point
where they exit from the apparatus.
11. Only use the attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Keep the packing material in case the equipment should ever need to be shipped.
Important Safety Instructions
WARNING
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

viii CX-70DHD Installation/Operation Manual
PRELIMINARY
Manufacturer’s Name: Runco International, LLC
Manufacturer’s Address: 1195 NW Compton Drive, Beaverton, OR 97006-1992
hereby declares that the Products’ Model Numbers:
CX-70DHD
conform with the provisions of:
Council Directive 2004/108/EC on Electromagnetic Compatibility;
EN 55022 “Limits and methods of measurements of radio interference characteristics of information technology equipment”
1998;
EN 55024 “Limits and methods of measurements of immunity characteristics of information technology equipment” 1998;
Including:
• EN 61000-4-2 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 2:
Electrostatic discharge immunity test”
• EN 61000-4-3 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 3: Radiated,
Radio-Frequency, Electromagnetic Field Immunity Test”
• EN 61000-4-4 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 4: Electrical
fast transient/burst immunity test”
• EN 61000-4-5 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 5: Surge
immunity test"
• EN 61000-4-6 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 6: Conducted
disturbances induced by radio-frequency fields immunity test"
• EN 61000-4-8 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 8: Conducted
disturbances induced by power frequency magnetic fields immunity test"
• EN 61000-4-11 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 11: Voltage
dips, short interruptions and voltage variations immunity tests"
And:
• EN 61000-3-2 "Electromagnetic compatibility (EMC) Part 3, Section 2: Limits for harmonic current emissions (equipment
input current up to and including 16 A per phase)" 2000;
• EN 61000-3-3 "Electromagnetic compatibility (EMC) Part 3, Section 3: Limitations of voltage changes, voltage
fluctuations and flicker in public low-voltage supply systems, for equipment with rated current up to and including 16 A
and not subject to conditional connection" 1995;
Council Directive 2006/95/EC and amended by M1 and C1 on Low Voltage Equipment Safety;
EN 60950 “Safety of information technology equipment, including electrical business equipment”
The Technical Construction file required by this Directive is maintained at the corporate headquarters of Runco International,
LLC, located at 1195 NW Compton Drive, Beaverton, OR 97006-1992.
Date of Declaration: February 2009
Compliance Information
DECLARATION OF CONFORMITY:

CX-70DHD Installation/Operation Manual ix
PRELIMINARY
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
The Product contains small amounts of tin, lead and/or mercury. Disposal of these materials may be regulated due to
environmental considerations.
This product may contain mercury or other electronic waste that can be hazardous if not disposed of properly.
Recycle or dispose in accordance with local, state, or federal Laws.
For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG.
For lamp specific disposal information check WWW.LAMPRECYCLE.ORG.
This symbol found on your product or on its packaging, indicates that this product should not be treated as
household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection
point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences to the environment and human health, which could
otherwise be caused by inappropriate disposal of this product. The recycling of materials will help to conserve
natural resources. This symbol is only valid in the European Union. If you wish to discard this product, please
contact your local authorities or dealer and ask for the correct method of disposal.
FCC PART 15:
INDUSTRY CANADA (ICES-003):
PRODUCT DISPOSAL:
IMPORTANT RECYCLE INSTRUCTIONS
DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT (Applicable throughout the European
Union and other European countries with separate collection programs)

x CX-70DHD Installation/Operation Manual
PRELIMINARY
Notes:

CX-70DHD Installation/Operation Manual xi
1Table of Contents
PRELIMINARY
RuncoCare™ Standard Two Year Limited Warranty ................................................... iii
Important Safety Instructions....................................................................................... vii
Compliance Information .............................................................................................. viii
1. Introduction ...............................................................................................................1
About This Manual .......................................................................................................1
Target Audience .....................................................................................................1
If You Have Comments About This Manual... ..........................................................1
Textual and Graphic Conventions ...........................................................................1
Using This Manual ........................................................................................................2
Description, Features and Benefits ...............................................................................3
Key Features and Benefits ......................................................................................3
Parts List ...............................................................................................................4
2. Controlsand Functions............................................................................................5
CX-70DHD at a Glance ................................................................................................5
Controls and Indicators...........................................................................................5
Connectors.............................................................................................................6
DHD Controller Front Panel ..........................................................................................7
DHD Controller Rear Panel ...........................................................................................9
Outputs ..................................................................................................................9
Inputs .....................................................................................................................9
CX-70DHD Remote Control Unit ................................................................................11
3. Installation ...............................................................................................................15
Remote Control ..........................................................................................................15
Notes on Batteries................................................................................................15
Notes on Remote Control Operation.....................................................................15
Quick Setup ...............................................................................................................16
Installation Considerations ..........................................................................................17
Ambient Light .......................................................................................................17
Ventilation.............................................................................................................17
Audio/Video Synchronization Issues......................................................................17
Other Considerations............................................................................................18
Mounting the CX-70DHD on a Wall or Table Stand...............................................19
Connections to the CX-70DHD and DHD Controller ...................................................21

Table of Contents
xii CX-70DHD Installation/Operation Manual
PRELIMINARY
Connecting the CX-70DHD to the DHD Controller ................................................21
Connecting Source Components to the DHD Controller .......................................23
RS-232 Controller Connection..............................................................................29
Connecting 12-volt Trigger Outputs to External Equipment...................................30
Connecting an External IR Receiver to the DHD Controller....................................31
Connecting AC Power ..........................................................................................32
4. Operation .................................................................................................................33
Turning on the Power .................................................................................................33
Setting the Computer Display Properties ....................................................................33
Using the On-Screen Menus ......................................................................................35
Main Menu............................................................................................................36
Input Source.........................................................................................................37
Aspect Ratio.........................................................................................................37
Picture..................................................................................................................40
Input Position........................................................................................................45
Memory Presets ..................................................................................................47
Information ...........................................................................................................48
Calibration ............................................................................................................48
Service .................................................................................................................52
5. Maintenance and Troubleshooting ........................................................................57
Cleaning .....................................................................................................................57
Cleaning the Display Panel Body and Remote Control ..........................................57
Cleaning the Screen..............................................................................................57
Cleaning the Vents................................................................................................57
Troubleshooting Tips ..................................................................................................57
6. External Control ......................................................................................................59
Serial Communications ...............................................................................................59
RS-232 Connection and Port Configuration ..........................................................59
Serial Command Syntax .......................................................................................59
Using Discrete IR Codes ............................................................................................64
IR Command Protocol ..........................................................................................64
IR Command List..................................................................................................65
7. Specifications..........................................................................................................67
CX-70DHD Specifications ..........................................................................................67
DHD Controller Specifications ....................................................................................68
CX-70DHD Dimensions ..............................................................................................69
Supported Timings .....................................................................................................70

CX-70DHD Installation/Operation Manual xiii
1List of Figures
PRELIMINARY
2-1. CX-70DHD Controls and Indicators ..............................................................................5
2-2. CX-70DHD Connector Locations..................................................................................6
2-3. DHD Controller Front Panel ..........................................................................................7
2-4. DHD Controller Rear Panel ...........................................................................................9
2-5. DHD Controller/CX-70DHD Remote Control...............................................................11
3-1. Available Range of the Remote Control ......................................................................15
3-2. Ventilation Requirements for Enclosure Mounting .......................................................17
3-3. Assembling and Installing the Table Stand..................................................................20
3-4. Connecting the CX-70DHD to the DHD Controller......................................................22
3-5. RS-232 Connection from the DHD Controller to the CX-70DHD.................................23
3-6. HDMI Source Connections .........................................................................................24
3-7. Component Video Source Connections......................................................................25
3-8. RGBHV Source Connections......................................................................................26
3-9. SCART RGBS Source Connections............................................................................27
3-10. S-Video and Composite Video Source Connections.................................................28
3-11. RS-232 Control System Connection.........................................................................29
3-12. Connecting 12-volt Trigger Outputs..........................................................................30
3-13. External IR Receiver Connection...............................................................................31
4-1. CX-70DHD OSD Menu Structure................................................................................35
4-2. Typical PLUGE Pattern for Adjusting Brightness .........................................................40
4-3. Typical Gray Bar Pattern for Adjusting Contrast ..........................................................41
4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint................................42
4-5. Typical Test Pattern for Adjusting Sharpness..............................................................44
4-6. Overscan Modes ........................................................................................................46
4-7. CIE 1931 Chromaticity Diagram .................................................................................49
6-1. RC5 Message Format ................................................................................................65
7-1. CX-70DHD Dimensions (with Table Stand) .................................................................69

List of Figures
xiv CX-70DHD Installation/Operation Manual
PRELIMINARY
Notes:

CX-70DHD Installation/Operation Manual 1
PRELIMINARY
1.1
About This Manual
This Owner’s Manual describes how to install, set up and operate a Runco CX-70DHD
Flat-Panel LCD and DHD Controller.
Throughout this manual, the Runco CX-70DHD Flat-Panel LCD and DHD Controller are
referred to collectively as the “CX-70DHD.”
Target AudienceRunco has prepared this manual to help installers and end users get the most out of the
CX-70DHD.
Runco has made every effort to ensure that this manual is accurate as of the date it was
printed. However, because of ongoing product improvements and customer feedback, it
may require updating from time to time. You can always find the latest version of this and
other Runco product manuals on-line, at www.runco.com.
If You Have Comments
About This Manual...
Runco welcomes your comments about this manual. Send them to tech[email protected]om.
Textual and Graphic
Conventions
Text Conventions: The following conventions are used in this manual, in order to clarify
the information and instructions provided:
• Remote control button identifiers are set in upper-case bold type; for example, “Press
EXIT to return to the previous menu.”
• Computer input (commands you type) and output (responses that appear on-screen) is
shown in monospace (fixed-width) type; for example: “To change the aspect ratio to
Letterbox, type LETTERBOX <Enter>.”
• All keys with functional names are initial-capped, set in bold type and enclosed in angle
brackets. These keys are the following: <Enter>, <Spacebar>, <Control>, <Esc>
and <Tab>.
•<Enter> indicates that you may press either the RETURN or ENTER key on your
computer keyboard if it has both keys.
In addition to these conventions, underlining, boldface and/or italics are occasionally used
to highlight important information, as in this example:
1. Introduction
A carriage return must be used after each command or string.
Note

Introduction
2 CX-70DHD Installation/Operation Manual
PRELIMINARY
Graphic Conventions: These symbols appear in numerous places throughout the
manual, to emphasize points that you must keep in mind to avoid problems with your
equipment or injury:
1.2
Using This Manual
Use the following table to locate the specific information you need in this manual.
TIPS highlight time-saving short cuts and helpful guidelines for using
certain features.
NOTES emphasize text with unusual importance or special
significance. They also provide supplemental information.
CAUTIONS alert users that a given action or omitted action can
degrade performance or cause a malfunction.
WARNINGS appear when a given action or omitted action can result
in damage to the equipment, or possible non-fatal injury to the user.
DANGER appears when a given action can cause severe injury or
death.
Tip
Note
Caution
WARNING
DANGER!
If you need... ... Turn to page:
Information about obtaining service iv
General information about the CX-70DHD
Flat-Panel LCD and DHD Controller
3
Installation instructions 15
First-time configuration instructions 33
Advanced configuration instructions 48
Troubleshooting tips 57
Specifications for the CX-70DHD Flat-Panel LCD
and DHD Controller
67

Introduction
CX-70DHD Installation/Operation Manual 3
PRELIMINARY
1.3
Description, Features
and Benefits
Following the longstanding tradition of providing the finest custom theater products,
Runco proudly unveils its 70-inch Crystal Series™ LCD, the CX-70DHD. Runco’s largest
LCD flat panel joins the esteemed Crystal Series, which represents the finest Runco has to
offer and is a testament to Runco’s commitment to deliver the most exquisite flat-panel
displays for an unsurpassed large-screen experience. Combining image prowess,
impeccable design, flawless function and incredible craftsmanship, the Crystal Series
products bespeak unparalleled luxury for the elite few who covet them.
The Runco CX-70DHD is a native “Full-HD” (1920 x 1080) LCD that is ideal for rooms of
distinction where a large screen size is desired, but where ambient light makes front
projection difficult and the glare of a plasma screen simply unacceptable. In addition to its
exceptional contrast ratio and superb gray scaling for true-to-life image quality, the
CX-70DHD features the ISF™ (Imaging Science Foundation) calibration suite, including
day and night modes for an optimal picture in the most challenging lighting conditions.
Designed exclusively for discriminating tastes, the CX-70DHD is the first LCD flat panel to
feature Runco’s proprietary external DHD™ video controller/scaler/processor. The DHD
not only incorporates Runco’s exclusive advanced Vivix III™ digital video processing
technology to achieve the highest level of image fidelity, but it also enhances
standard-definition digital and NTSC content to near high-definition quality.
Regardless of video source, Runco’s CX-70DHD provides rich, detailed HD imagery.
While lesser displays may show signs of image distortion, especially at larger screen sizes,
the CX-70DHD incorporates Runco’s WideVision™ technology with exclusive
VirtualWide™ content conversion, which masterfully converts all 4:3 content to
widescreen 16:9 aspect ratio and optimizes Anamorphic and Letterbox content with no
loss of image integrity.
The CX-70DHD offers exceptional installation flexibility. It measures less than six inches
thin for unobtrusive installation on a wall, and the external DHD processor allows for a
pristine installation, with just a single HDMI with HDCP output to the display required. All
source and component inputs (Composite, S-Video, HDMI with HDCP, and RGB) are
handled by Runco’s DHD, which, like all of the components, can be hidden from view.
The CX-70DHD includes a discrete remote, RS-232 interface and three, +12 VDC triggers
for greater integration capabilities that can help create the ideal entertainment
environment with touch-of-a-button convenience. The display’s elegant black bezel
matches any room décor.
Key Features and BenefitsThe CX-70DHD offers these key features and benefits:
• 16:9 Native Resolution: 1920 x 1080
• Multiple Aspect Ratios with VirtualWide™ Mode
• Includes DHD with HDMI video controller/processor
• Less than 6 inches thin
• Exceptional detail and artifact-free video enhancement
• ViVix™ video processing with 3:2 film detection circuitry

Introduction
4 CX-70DHD Installation/Operation Manual
PRELIMINARY
Parts List Your CX-70DHD is shipped with the following items. If any items are missing or damaged,
please contact your Runco dealer or Runco Customer Service at (800) 23-RUNCO.
• CX-70DHD Flat-Panel LCD and DHD Controller
• Table Stand
• AC Power Cords (2)
• Remote Control Unit and two (2), AAA-size batteries
• Communication Cable, RJ-11 Male to RJ-45 Male, 20 feet (part number 175-0686-00)
• Rack-mount hardware for the DHD Controller
• CX-70DHD Installation/Operation Manual (this document)
• CX-70DHD Quick Setup Guide
Optional Accessories:
• Wall Mount Kit (part number 956-0285-00)
➤

CX-70DHD Installation/Operation Manual 5
PRELIMINARY
2.1
CX-70DHD at a Glance
Controls and IndicatorsFigure 2-1 shows the CX-70DHD controls and indicators.
Figure 2-1. CX-70DHD Controlsand Indicators
2. Controlsand Functions
IN OUT
RS-232
IN
ANALOG
IN OUT
DVI
1
23
4

Controls and Functions
6 CX-70DHD Installation/Operation Manual
PRELIMINARY
1. DISPLAY STAND
Included with the CX-70DHD for table-top installations.
2. POWER SWITCH
Connects or disconnects the display panel from the AC power source.
3. STANDBY/ON INDICATOR
- Lights blue to indicate normal operation;
- Lights red to indicate that the CX-70DHD is in standby mode.
4. REMOTE CONTROL SENSOR
Receives the signals from the remote control.
Connectors Figure 2-2 shows the connector locations on the CX-70DHD, and the paragraphs that
follow describe them.
Figure 2-2. CX-70DHD Connector Locations
➤
IN OUT
RS-232
IN
ANALOG
IN OUT
DVI
IN OUT
RS-232
IN
ANALOG
IN OUT
DVI
1
2
3
5
4
6
