Russell Hobbs RHM2023 User manual

MICROWAVE OVEN
User Instructions - Please keep for future reference
Model: P80D20EL-TL3/H
Read these instructions carefully before using your microwave oven. By following these instructions
carefully your oven will provide you with many years of excellent service.
Specifications
Model:
Power Source:
Microwave Power Consumption:
Microwave Maximum Output:
Oven Capacity:
Turntable Diameter:
External Dimensions (L x W x H):
Net Weight:
P80D20EL-TL3/H
230V~240V/50Hz
1200 Watt
800 Watt
20 litres
Ø 245 mm
262×452×370mm
Approx. 12Kg
IMPORTANT
•WARNING: if the door or door seals are damaged, the oven must not be operated until it has
been repaired by a competent person
•WARNING: it is hazardous for anyone other than a competent person to carry out any service
or repair operation that involves the removal of a cover which gives protection against
exposure to microwave energy;
•WARNING: liquids and other food must not be heated in a sealed container since they are
liable to explode;
•WARNING: only allow children to use the oven without supervision when adequate instruction
have been given so that the child is able to use the oven in a safe way and understands the
hazards of improper use.
•WARNING: accessible parts may become hot during use. Young children should be kept
away. CAREFULLY RETAIN THESE INSTRUCTIONS

SAFETY INSTRUCTIONS
1. The oven must be placed on a level surface.
2. The turntable and turntable ring assembly must always be used in the oven during cooking. Place the cookware gently on the turntable and handle it
carefully to avoid possible breakage.
3. Incorrect use of dish for browning food may cause turntable to break.
4. Use onlythe specified bag size when using pre-prepared popcorn.
5. The oven has several built-in safety switches to ensure that the power remains off when the door is open. Do not tamper with these switches.
6. Do not operate the microwave oven when empty. Operating the oven with no food or food that is extremely low in moisture can cause fire, charring or
sparking.
7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable may cause the turntable to break.
8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating may occur which could cause scalding when feeding the baby.
9. Do not heat narrow-necked containers, such as syrup or sauce bottles.
10. Do not attempt to deep-fry in your microwave oven.
11. Do not attempt home canning in this microwave oven as it is impossible to be sure all contents of the jar have reached boiling temperature.
12. Do not use this microwave oven for commercial purpose. This microwave oven is made for household use only.
13. To prevent delayed eruptive boiling of hot liquids and beverages or scalding yourself, stir liquid before placing the container in the oven and during
heating.
14. Check the food in the microwave oven frequently to avoid burning due to overheating.
15. Failures to maintain the oven in a clean condition could lead to deterioration of the surface which could adversely affect the life of appliance and possibly
result in a hazardous situations.
16. Stand at arm's length when opening the door to avoid scalding when steam or hot air is released.
17. ALWAYS allow an appropriate standing time after the oven has switched off according to the food being cooked to allow heat to distribute evenly
throughout the food.
18. Use oven gloves when removing any cookware from oven to reduce chance of being burned or scalded.
19. Read and follow the specific: "recautions for avoiding possible exposure to excessive microwave energy".
20. As with most cooking appliances, close supervision is necessary to reduce the risk of a fire in the oven cavity. If a fire should start or smoke is observed:
a. Keep the oven door closed.
b. Turn the oven off and unplug the appliance.
21. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode.
22. Do not overcook food. Regularly observe the oven if paper, plastic, or other combustible materials are used in the oven.
23. Do not use the oven cavity for storage purposes. Do not store items such as bread, cookies, paper products, etc. inside the oven.
24. Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven.
25. This oven must be earthed. Connect only to properly earthed outlet. See "earthing installation".
26. Install or locate this oven in accordance with the installation instructions provided.
27. Use this appliance only for its intended uses as described in the manual. Do not use corrosive chemicals or vapours in this appliance. This Oven is
specifically designedto heat or cookfood. It is not designed for industrial or laboratory use.
28. Never allow children to use the oven without supervision unless adequate instructions have been given so that the children are able to use the oven in a
safe way and understand the hazards of improper use.
29. If the supply cord or plug is damaged, or if the oven is not working properly or has been dropped it must be replaced or repaired by the manufacturer or its

service agent or a similarly qualified person in order to avoid a hazard.
30. This appliance should be serviced only by qualified service technicians. Contact the nearest authorised service facility for examination, repair or
adjustment.
31. Do not cover or block any vents on the oven.
32. Do not store or use this appliance outdoors.
33. Do not use this oven near water, near a kitchen sink, in a wet basement or near a swimming pool.
34. Do not immerse cord or plug in water.
35. Keep cord away from heated surfaces.
36. Do not let cord hang over edge of table or counter.
37. When cleaning door and oven surfaces use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth.
38. There must be more than 30cm free or open space above the top surface of the oven.
39. Do not attempt to repair the oven yourself, please consult an authorised service agent.
40. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature should be carefully checked before consumption, in
order to avoid burns.
41. Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not
to try and override or tamper with the safety interlocks.
42. Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the, (1) door (i.e.
door is not bent or dented), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.
43. Utensils should be checked to ensure that they are suitable for use in microwave ovens.
44. The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to
the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the
shop where you purchased the product.
45. The lampholder is installed in the oven that is non-user serviceable area.
46. The oven should be cleaned regularly and any food deposits removed.
47. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in
shattering of the glass.
48. Do not use steam cleaners inside the cavity.
49. During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.
50. This appliance is not intended for use by persons (including children) with reduced physical, sensory or metal capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsiblefor their safety.
51. Microwave heating of beverages can results in delayed eruptive boiling, therefore care must be taken when handling the container.

5
CONTENTS
PAGE
2snoitacificepS
3snoitcurtsnIytefaS
5stnetnoC
6nevOevaworciMnIesUnaCuoYslairetaM
6nevOevaworciMnIgnisUdiovAoTslairetaM
7slisnetU
7seirosseccAdnAstnenopmoCnevO
8noitallatsnIelbatnruT
8nevOruoYgnillatsnI
9selpicnirPgnikooCevaworciM
9slobmySgnigakcaPdooFevaworciM
01nevOevaworciMruoYgnitarepO
01lenaPlortnoC
Clock Setting 11
11tratSkciuQ
11gnikooCevaworciM
21tsorfeDotuA
31tsorfeDdeepS
31gnikooCegatsitluM
Auto Cook 14
Child Lock 15
51gnitaeHdnapUgnimraW
61nevOevaworciMruoYgninaelC
61ecnanetniaMdnagnitoohselbuorT
81srewsnAdnasnoitseuQ
81setoNtnatropmI
02noitallatsnIgnihtraE
eetnarauG

MATERIAL YOU CAN USE IN MICROWAVE OVEN
skrameRslisnetU
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking
Arcing can occur if foil is
too close to oven walls. The foil should be a least 1 inch (2.5cm) away from oven walls.
Browning dish Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage cause the turntable to break
Dinnerware Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow steamto escape.
Paper plates and cupsUse for short-term cooking/warming only. Do not leave oven unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for short-term cooking only.
Parchment paper Use as a cover to prevent splattering and retain moisture
Plastic
Microwave-safe only. Follow the manufacturer's instructions. Should be labelled "Microwave Safe".
Some plastic containers soften as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit,
pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and sugar thermometers)
Wax paper Use as a cover to prevent splattering or as a wrap during steaming.
MATERIALS TO AVOID USING IN THE MICROWAVE OVEN
skrameRslisnetU
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal
handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed
utensils Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven
Plastic foam Expanded polystyrene may melt or contaminate the liquid inside when exposed to high temperature.
.kcarcrotilpsyamdnanevoevaworcimehtnidesunehwtuoyrdlliwdooWdooW

UTENSILS
CAUTION
Personal Injury Hazard
Tightly-closed containers could explode. Closed containers should be opened and plastic pouches pierced before cooking. See above for further instructions
"Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the utensil in question by following the procedure below.
Utensil test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the utensil is warm, do not use if for microwave cooking.
4. Do not exceed 1 minute cooking time.
SETTING UP YOUR OVEN
OVEN COMPONENTS AND ACCESSORIES
Remove the oven and all the material from the carton. Your oven comes with the following accessories:
Glass plate - 1
Instruction manual – 1
Turntable ring assembly - 1
1. Door Safety Lock System
2. Oven Window
3. Wave Guide
4. TurntableRing Assembly
5. Glass Turntable
6. Control Panel
Warning : Do not remove the wave guide. It is to protect the magnetron.

TURNTABLE INSTALLATION
Glass turntable(5), to be placed on the turntable support ring
a. Never place the glass turntable (5) upside down. The turntable
should never be restricted in movement.
b. Both glass turntable (5) and turntable support ring (4) must always
be used during cooking.
c. All food and containers of food should always be placed on the
glass turntable for cooking.
d. The glass turntable rotates clockwise or anti-clockwise randomly,
this is normal.
e. If glass turntable or turntable support ring cracks or breaks, contact
your nearest authorized service centre.
INSTALLING YOUR OVEN
Carefully remove all packaging materials and accessories.
.roodnekorbrostnedsahcusegamadynarofnevoehtenimaxE
Do not install if oven is damaged in any way.
Cabinet : Remove any protective film found on the outer surface.
Do not remove the light brown mica cover that is screwed onto the inner side of the microwave to
protect the magnetron.
INSTALLATION
1. Select a level surface that provides enough clear space for the intake and / or outlet vents (see
fig.3).
A minimum clearance if 3.0 inch (7.5cm) is required between the oven and any adjacent wall. One
side must be clear.
1. Leave a minimum clearance of 12 inch (330) above the oven.
2. Do not remove the feet from the bottom of the oven.
3. Blocking the inside and/or outlet openings can damage the oven.
4. Place the oven as far away from radios and televisions as possible. Operation of microwave oven may cause interference to your radios and televisions
as possible. Operation of microwave oven may cause interference to your radio or televisions reception.
5. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating
label.
Warning : Do not install microwave oven over a range cooktop or other heat-producing appliance. If installed above a heat producing appliance the
microwave oven could be damaged and the warranty would be void.
Warning : Do not install microwave oven in a cupboard.
(4)
(5)

MICROWAVE COOKING PRINCLIPES
1. The microwaves generated by the magnetron are evenly distributed through the food as the glass turntable revolves. This ensures that the food is
cooked uniformity.
2. The microwaves are absorbed by the food up to a depth of approximately 1 inch (2.5cm). Cooking continues as the heat is dissipated through the food.
3. Cooking times will vary according to the recipe and the density, weight and water content of the food. The cooking time will also vary according to the
temperature at the start of cooking, i.e. depending on whether the food is frozen or not.
MICROWAVE FOOD PACKAGING SYMBOLS
Microwave Symbols
On the front of your oven there is a microwave symbol, show as below. This symbol has been introduce
for your benefit when cooking or reheating packing food.
Package food is also increasingly using a microwave symbol similar to the one below.
When you see this symbol on food packaging the cooking instructions are based on the either IEC
power Output Rating. On the reheating Categories A, B, C, D or E
A, B, C, D or E
MORE HEATING TIME LESS HEATING TIME
800W
E

10
OPERATING YOUR MICROWAVE OVEN
CONTROL PANEL
DISPLAY
For display the Cooking time, power, indicators, and clock time.
POWER
For select microwave function and setting the microwave cooking
power level.
CLOCK
For setting the clock.
MULTI STAGE COOKING
For multi stage cooking.
SPEED DEFROST
For defrost food by time.
AUTO DEFROST
For defrost food by weight.
WEI. ADJ.
For select specify food weight or number ofservings.
TIME/MENU
Turn the dial to select cooking time / the cooking menu.
START
Press to confirm or start acooking program.
STOP/CANCEL
Press to cancel setting / reset setting / pause cooking / cancel cooking.
It is also used for setting child lock.

11
Your microwave Oven is equipped with a clock, you must set the clock when you first install your oven or after a power failure.
1. Press button once and it will display "12H" and " " is flashing.
2. Continue to press button to select the clock in 12 or 24 hour cycle.
3. Turn to select the hour.
4. Press button once.
5. Turn to select the minute
6. Finally, press and the time will be set.
For example: Set the current time to 8:30 in 24H format.
1. Press once and it will display “12H” and is flashing
2. Press again and it will display “24H” and is flashing.
3. Select the clock in 12 Hr or 24 Hr and adjust the hour until it displays “8: ”. is flashing.
4. Press again, it displays “8:00”, is flashing.
5. Turn to adjust the minute until it displays 8:30 and will flash.
6. Press once to confirm the setting and “:” is flashing.
Note: You can press the button once to check clock time during cooking.
QUICK START
In the standby mode, press the button once, the oven will start to cook with 100% power for 30 sec. Each additional press on
the will increase the cooking time for another 30 sec, and the longest time for this setting can be added up to 12 minutes.
Example: To cook for 2 minutes with 100% power
Press button 4 times the LED displays 、&and the cooking time will increase to 2 minutes. The oven starts cooking
immediately at full microwave power. Then will disappear.
MICROWAVE COOKING
To cook with microwave, time and power level should be set. The longest cooking time to be set is 60 min.
1. Press to select the microwave cooking and the display shows ”100”、、 、& .
2. Continue to press to select the required microwave power level until the required power setting is reached.
3. Turn to adjust the cooking time until the required time is reached and is flashing.
4. Press to start the cooking.
Time/ Menu
Time/ Menu
CLOCK SETTING
Time/ Menu
Time/ Menu

13
400 00:09:00 40% 20% 20%
500 00:10:48 40% 20% 20%
600 00:12:36 40% 20% 20%
700 00:14:24 40% 20% 20%
800 00:16:12 40% 20% 20%
900 00:18:00 40% 20% 20%
1000 00:19:48 40% 20% 20%
1100 00:21:36 40% 20% 20%
1200 00:23:24 40% 20% 20%
1300 00:25:12 40% 20% 20%
1400 00:27:00 40% 20% 20%
1500 00:28:48 40% 20% 20%
1600 00:30:36 40% 20% 20%
1700 00:32:24 40% 20% 20%
1800 00:34:12 40% 20% 20%
Note: 1. The cooking time for each stage is 1/3 of total cooking time.
2. When the cooking time is halfway through, the oven will pause and produce beep sound to let you know. This is normal. You can
open the door and turn the food over. If you do not need to turn the food over, you can press to continue the cooking.
SPEED DEFROST
The oven can quickly defrost food to the set time you entered.
EXAMPLE: defrost shrimp for 5 mins.
1. Place the shrimp to be defrosted into the oven.
2. Press button once.
3. Turn dial clockwise until it displays 5:00.
4. Press button.
5. When the cooking is finished, it will display END and beep four times.
MULTI- STAGE COOKING
This microwave can be set up to 2 stage cooking or speed defrost + 2 stage cooking.
Example : Speed defrost for 5mins + Microwave 100% for 5mins + Microwave 80% for 10mins.
1. Press button once and Turn dial clockwise until it displays 5:00.
2.Press button once.
3.Press button once and turn clockwise to adjust the cooking time to 5:00.
4.Press button again
5. Press button twice and turn clockwise to adjust the cooking time to 10:00.
6.Prress button.
Time/ Menu
Time/ Menu
Time/ Menu
Time/ Menu

14
Note:
1. The respective lights will come on to indicate which stage the oven is operating in.
2. It will beep after each stage.
3. Speed frost will not be count into the stage cooking but it will put into the 1st program.
4. Auto defrost & Auto cook cannot be used in multi-stage cooking.
AUTO COOK
This auto function has eight pre-set cooking program. You do not need to set either cooking times or power level. The table below shown
the details of the programs.
1. In standby state, turn clockwise to choose desired auto cooking program, i.e. 1 to 8.
2. Press toselect the weight of food.
3. Press to start the cooking.
Example: To cook 400g of fish.
1. Turn clockwise until the LED displays “ ” & “6“.
2. Continue to press until the LED display “400”, “ ”, “ ” & “ “ are flashing.
3. Press to start cooking.
AUTO FUNCTION COOKING CHART
Auto Cooking Auto Manual Weight Display Power
1 MILK/COFFEE
1 portion / 200 ml
2 portions / 400 ml
3 portions / 600 ml
1
2
3P-100
ECIR2 150 g
300 g
450 g
600 g
150 g
300 g
450 g
600 g
30% P-100
30% P- 80
40% P-40
3 SPAGHETTI 100 g
200 g
300 g
100 g
200 g
300 g P- 80
4POTATO 1 portion / 230 g
2 portions / 460 g
3 portions / 690 g
1
2
3P-100
5AUTO REHEAT
200 g
300 g
400 g
500 g
600 g
700 g
800 g
200 g
300 g
400 g
500 g
600 g
700 g
800 g
P-100
6FISH
200 g
300 g
400 g
500 g
600 g
200 g
300 g
400 g
500 g
600 g
P-80
AZZIP7 150g 300g
450g
150g
300g
450g P- 100
8POPCORN 99g 99g P- 100
Note:
For Spaghetti add boiling water before cooking.
The result of auto cooking depends on factors such as fluctuation of voltage, the shape and size of food, your personal preference as to the
doneness of certain foods and even how well you happen to place food in the oven. If you find the result at any rate not quite satisfactory,
please adjust the cooking time a little bit accordingly.
Time/ Menu
Time/ Menu

15
CHILD LOCK
Lock: In standby state, press over 3 seconds, a long “beep” will be heard denoting entering the children—lock state, and the lock
indicator will be illuminated.
Unlock: In locked state, press over 3 seconds, a long “beep” will be heard denoting entering the lock is released, and the
locked indicator will disappear.
WARNIG UP AND HEATING
Times stated are approximate and can vary depending on the quality, size of the chopped pieces, storage temperature and moisture content of the foodstuff. It is advisable
to set a shorter cooking time at first, and then if necessary continue the cooking process, until the food is cooked to your satisfaction。
skrameR)sniM(emiTleveLtuptuOytitnauQffutsdooF
Liquids puc1,kliM 150g P100 (=100%) 0.5 – 1 Caution: Stir the liquid prior to and during heating/reheating, let liquid
stand for at least 10 seconds after cooking and always take care when
adding ingredients to hot liquids.
Water/Coffee
/Milk1 cup 150g P100 (=100%) 1 - 2 Caution: Stir the liquid prior to and during heating/reheating, let liquid stand for at least 10 seconds after cooking and always take care when
adding ingredients to hot liquids. diuqiltel,gnitaeher/gnitaehgniruddnaotroirpdiuqilehtritS:noituaC5-3)%001=(001Pg005retaW stand for at least 10 seconds after cooking and always take care when
adding ingredients to hot liquids.
One-course meals/
Ready-to-serve meals 450g P100 (=100%) 4 - 6 Cover.
.ritS2-1)%001=(001Pg052spuoS .semitneewtebritS5-3)%001=(001Pg005swetS yrtluoP/taeM 3-2)%001=(001Pg052tsaoR
Rissoles/Meatballs 500g P100 (=100%) 3 -4 .liohtiwhsurbylthgiL4-3)%001=(001Pg054nekcihC2/1 selbategeV .rits,revoC2-1)%001=(001Pg0511xnoitroP .rits,revoC4-2)%001=(001Pg0032xsnoitroP
Side Dishes .rits,revoc,dnaherofebylthgilsnepmaD2-1)%001=(001Pg051seldooN .rits,revoc,dnaherofebylthgilsnepmaD2-1)%001=(001Pg051eciR .revoC4-3)%001=(001Pg005seotatoP .erutarepmetehtkcehc,llewritS2-1)%001=(001Pg002,xorppadooFybaB
Meat
Beef, Pork in one piece 500g P 80 (= 80%) 11 - 14 Cover, turn halfway through cooking, leave to stand for 3-5 minutes.
Lightly smoked pork loin 500g P 80 (= 80%) 12 - 15
51-21)%001=(001PfaoltaeM .krofhtiwniksecreiP3-2)%08=(08Pg002segasuaS
Poultry .setunim5rofdnatsotevael,ecnonrut,revoC52-02)%001=(001Pg0001nekcihC 5-4)%08=(08Pg052nekcihCfoseceiP
Fish .setunim3rofdnatsotevael,ecnonrut,revoC7-5)%08=(08Pg003hsifhserF .setunim3rofdnatsotevael,ecnonrut,revoC5-4)%08=(08Pg003hsiffotelliF .setunim3rofdnatsotevael,revoC01-8)%001=(001Pg004hsifnezorF hserf,selbategeV
Cauliflower, broccoli, fennel 150g P100 (=100%) 8 - 10 Chop vegetables into small pieces, cook with liquid,
(3-5 tablespoons), stir in between times leave to stand for 3-5 minutes,
add spices, (salt before serving).
21-01)%001=(001Pg005snaebhcnerF
Potatoes, boiled potatoes 500g P100 (=100%) 8 - 10 .seotatopgniliobroftekcajehtkcirP21-01)%001=(001Pg005seotatoptekcaJ 01-8)%001=(00
1Pg005storraC
Vegetables, deep frozen Take note of details on the packaging. 5-3rofdnatsotevael,semitneewtebnirits,diuqilemosdda,revoC21-01)%001=(001Pg003hcanipsfaeL minutes.
9-7)%001=(001Pg003saeP 21-01)%001=(001Pg002skeeL 8-6)%001=(001Pg002storraC 8-6)%001=(001Pg052stuorpslessurB 4-3+)%001=(001Pg051hcanipS 22-02)%03=(03PstreseD
Pudding/Flummery 500g P100 (=100%) 6 - 8

CLEANING YOUR MICROWAVE OVEN
1. Turn off the oven and remove the power plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe with a damp
cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of spray and other harsh cleaners as
they may stain, streak or dull the door surface.
3. The outside surfaces should be cleaned with a damp cloth. To prevent damage to the operating parts inside the
oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth to
remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the control panel,
leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may occur when
the microwave oven is operated under high humidity condition. And it is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a
dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the bottom
surface of the oven with mild detergent. The roller ring may be washed in mild sudsy water or dishwasher. When
removing the roller ring from cavity floor for cleaning, be sure to replace in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a deep
microwaveable bowl, microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.
11. The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean
condition could lead to deterioration of the surface that could adversely affect the life of the appliance and
possibly result in a hazardous situation.
12. Please do not dispose this appliance into the domestic rubbish bin, it should be disposed to the particular
disposal center provided by the municipalities.
Removable Parts
1. The turntable may be cleaned at the sink. Be careful not to chip or scratch the edges as this may cause the
turntable to break during use.
2. The turntable roller rest should be cleaned regularly.
3. Do not immerse the turntable glass in cold water.
Special Care
For best performance and safety, the inner door panel and the oven front frame should be free of food residue. To
prevent damage to the operating parts inside the oven, water should not be allowed to seep into the ventilation
openings.
TROUBLESHOOTING AND MAINTENANCE
NORMAL CONDITION
Microwave oven interfering with TV reception.
Radio and TV reception may be interfered with when microwave oven is in operation. It is similar to the interference of
small electrical appliances such as food mixers, vacuum cleaners and electric fans. This is normal.
Oven light dim.
In low power microwave cooking, oven light may become dim. This is normal.
Steam accumulating on door, hot air out of vents.
In cooking, steam may come out of food. Most will come out from vents but some may condense on cool places such

as the oven door. This is normal.
Oven started accidentally with no food in.
Although starting the oven with no food in it should be avoided, it does no damage to the oven provided it is only
operated empty for a very short time. It is advised that a glass or microwave safe container of water is always left in
the oven to absorb any heat should the oven be turned on accidentally
MAINTENANCE
Troubleshooting
Check for problems by using the chart below. If the microwave oven still does not work properly, contact the nearest
authorized service centre.
PROBLEM POSSIBLE CAUSE
a. Plug not secure in power socket, or not switched on.
Oven will not start b. Door is open.
.tessinoitarepognorW.c
a. Materials which should be avoided in microwave oven are used.
Arcing or sparking b. The oven is operated when empty.
c. Spilled food remains in the cavity.
a. Materials which should be avoided in microwave oven are used.
b. Food is not defrosted completely.
Unevenly cooked food
c. Power setting for cooking time is incorrect.
d. Food is not turned or stirred.
Overcooked food Power setting for cooking time is incorrect.
a. Materials to be avoided in microwave oven are used.
b. Food is not defrosted completely.
c. Oven ventilation ports are restricted.
Undercooked food
d. Power setting for cooking time is incorrect.
Incompletea. Materials to be avoided in microwave oven are used.
defrosting b. Power setting for cooking time is incorrect.
c. Food is not turned or stirred.
Noise comes from
turntable when Food residue exists between the turntable roller rest and cavity bottom.
oven is turned on
Oven light does not a. The light bulb has burned out
glow b. START has not been pressed.

QUESTIONS AND ANSWERS
Q: When the oven is plugged into a wall outlet for the first time, it does not work properly. What's wrong?
A: The microcomputer used in the oven control may temporarily become scrambled and fail to function as
programmed. Unplug the oven from the wall outlet and then plug it back in. The microcomputer will then reset for
proper functioning.
Q: Why is there noise coming from the oven when using a lower power level?
A: When cooking with power other than 100%, the oven automatically switches on and off to obtain the correct power
output. The clicking noise can be heard when the oven switches on and off. This is normal
Q: Why is there steam coming out of the air exhaust vent?
A: Steam is produced during cooking. The microwave oven has been made to vent this steam.
Q: What is wrong when the oven light will not glow?
A: There may be several reasons why the oven light will not glow. The light bulb has burned out or START has not
been pressed.
Q: Why do eggs sometimes burst?
A: The egg yolk may burst because of steam build-up inside the membrane. Pierce the membrane with a toothpick
before cooking it. Never microwave eggs in the shell as they may explode.
Q: How is boiling over avoided?
A: Use a larger utensil than usual for cooking. If you open the oven door or touch STOP/CLEAR, the food will stop
boiling.
IMPORTANT NOTES
1. Before first using this oven please read this instruction manual and keep it for future reference.
2. Do not attempt to repair the oven yourself, please consult an authorised service agent.
3. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature should be
carefully checked before consumption, in order to avoid burns.
4. Check the oven and the cable regularly for damage. If there is any kind of damage, the oven should not be used.
Warning:
a. It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the
removal of any cover which gives protection against exposure to microwave energy.
b. Never allow children to use the oven without supervision unless adequate instructions have been given so that the
children are able to use the oven in a safe way and understand the hazards of improper use.
c. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
NOTE
• Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to
microwave energy. It is important not to try and override or tamper with the safety interlocks.
•Carefully clean door seals and sealing surfaces.
• Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there
is no damage to the, (1) door (i.e. door is not bent or dented), (2) hinges and latches (broken or loosened), (3) door
seals and sealing surfaces.
•Utensils should be checked to ensure that they are suitable for use in microwave ovens.
•When heating food in plastic or paper containers, check the oven frequently to avoid any possibility of ignition.
•Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling

the container.
•If smoke is observed, switch off or unplug the appliance immediately and keep the door closed in order to stifle any
flames.
•Eggs in their shells and whole hard-boiled eggs should not be heated in microwave ovens since they may explode.
• If the door or door seals are damaged the oven must not be operated until it has been repaired by a trained person.
• Liquids or other foods must not be heated in sealed containers since they are liable to explode.
Bulb replacement
If the interior light bulb fails, it can be easily replaced by a qualified service engineer. Do not attempt to remove the
outer casing as this will expose live components. Please consult a qualified service engineer.
