Specifi cations
SMC-30 & SMC-35*SMC-40 & SMC-45*SMC-50 & SMC-55*
Processor 2.13 GHz Intel® Core 2 Duo 2.4 GHz Intel® Core 2 Duo 2.67 GHz Intel® Core 2 Duo
Storage 500 GB 1 TB RAID5 2 TB RAID5
Memory 2 GB 2 GB 4 GB
Graphics Card NVIDIA® 8500 GT NVIDIA® 8500 GT NVIDIA® 8800 GT
* SMC with CableCARD™ slot
Operating System: Microsoft Windows Vista™ Ultimate
Rear Audio Inputs:
SMC-30, 40, 50 (1) FM Antenna , (2) S-Video/Audio
Rear Video Inputs:
SMC-30, 40, 50 (2) NTSC, (2)ATSC, (2) S-Video/Audio
SMC-35, 45, 55 (2) CableCARD™ slots
Front A/V Source Inputs: Composite video, S-Video/Audio
Media Card Reader: 28-in-1
DVD/CD Player/Recorder: DVD/RW, CD/RW
Audio Outputs: (4) 7.1 Channel 1/8” stereo jacks,
(1) Optical S/PDIF jack
Microphone Jack: (1)
Video Outputs:
SMC-30, 35, 40, 45 DVI-I, HDMI (video only), Component,
Composite, and S-Video,
VGA (w/supplied adapters)
SMC-50, 55 (2) DVI-I, (1) S-Video, VGA and HDMI
(w/supplied adapters)
IR Ports: (1) Input, (2) Outputs
Serial Ports: (2) RS-232 (9-pin)
230 Kpbs baud rate
USB 2.0/1.1 ports: (6) rear, (2) front
FireWire Jacks: (1) rear, (1) front
PS2 Ports: PS2 Mouse, PS2 Keyboard
Network Port: (1) Ethernet (RJ-45)
Wiring Requirements: CAT-5e or CAT-6 Cable
Trigger Ports: (2) 12V trigger outputs,
(2) Phoenix plugs
Peripheral Ports: (1) Parallel, (1) Monitor
Wireless Keyboard: RF Keyboard, (4) AA Alkaline Batteries
USB RF Dongle
Remote Control: RF Remote, (3) AAA Alkaline Batteries
Operating Temperature: 45°F (7°C) to 75°F (24°C)
Humidity: 10% to 90% non-condensing
Rack Spaces: 3U
Dimensions: 16.75” x 5.5” x 16”
(425 x 140 x 406 mm)
Weight: 35 lbs. (15.9 kg)
Power: 120/240 ISO 3-conductor cord
Back Panel (all models)
1. RS232 Serial Device Control
2. 12-Volt Trigger outputs to Relays/Shades
3. IR Input and Outputs
4. FireWire / IEEE 1394 port for Digital Video Cameras
5. Ethernet
6. AC Input Power 120/240 VAC
7. VGA Video and DVI Output (inactive)
8. USB 2.0/1.1 ports
9. Digital/Analog Audio Output to Receiver/Amplifi er
10. Microphone input
12
3
45
6
7
8
9
10
Video Outputs
(30, 35, 40, 45 models)
1. Component Video outputs
2. S-Video output
3. Composite Video output
4. DVI-1 output
5. HDMI output
Video Outputs
(50 and 55 models)
6. DVI-1 1 output
7. DVI-1 2 output
8. S-Video/ Component
Video output
1
2
3
4
5
6
7
8
A/V Inputs
(30, 40, 50 models)
1. FM radio coaxial input
2. NTSC coaxial input
(Cable or Satellite TV)
3. ATSC coaxial input
(HD TV antenna)
4. S-Video input
(Cable or Satellite set-top box)
5. Audio inputs
A/V Inputs
(35, 45, 55 models)
6. Digital Cable TV coaxial inputs
7. CableCARD slots
6
7
1
2
3
4
5
