Ryobi D47CK Quick setup guide

RYOBI 3/8 in. DRILL
DOUBLE INSULATED
MODEL NO. D46C
REPAIR SHEET

RYOBI 3/8 in. DRILL – MODEL NUMBER D46C
2
21
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
22
21
20 27
23
24
25
26 28
29
30
31
32
33
16
34
35
19

* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
RYOBI 3/8 in. DRILL – MODEL NUMBER D46C
3
1 660211008 * SCREW (M3 X18 mm) .........................................4
2 6702801 SPRING WASHER (OD5.7 X ID3.1 X 0.8 mm)..... 4
3 6359801 MOUNTING PLATE ............................................. 1
4 631892001 SPRING PLATE (0.4 mm).....................................2
5 5434601 SPRING HOLDER................................................1
6 641112001 CLUTCH CAP (OUTER) .......................................1
7 551009001 CLUTCH CAP (INTER).........................................1
8 660226010 * SCREW (M2 X 14 mm) ........................................4
9 5437201 SLEEVE ...............................................................1
10 680434002 SPRING (OD35.4 X ID29.6 X 23 t) .......................1
11 6897003 WASHER (OD43 X ID30 X 0.15 t) ........................2
12 6897002 WASHER (OD43 X ID30 X 0.2 t) ..........................1
13 6897005 WASHER (OD43 X ID30 X 0.1 t) ..........................1
14 670105005 CLUTCH WASHER (OD39.3 X ID30.5 X 1.5 mm)..1
15 5660201 BIT HOLDER........................................................1
16 300141056 HOUSING ASSEMBLY ........................................1
17 940051043 LOGO LABEL.......................................................1
18 290069114 BRUSH ASSEMBLY.............................................1
19 6612003 SCREW (M5 X 0.8 X 18.5 mm LEFT HAND)........1
20 6782045 DOUBLE BIT (PH2 S6 L50 mm) ..........................1
21 740824001 FIELD ................................................................... 1
22 760197007 SWITCH...............................................................1
23 7334501 POWER CORD ....................................................1
24 6935501 CORD CLAMP .....................................................1
25 6620801 * SCREW (M4 X 12 mm) ........................................2
26 5927402 BEND RELIEF ......................................................1
27 6782044 DOUBLE BIT (PH3 S7 L50 mm) ..........................1
28 6620805 * SCREW (M4 X16 mm) .......................................10
29 940055112 DATA LABEL ........................................................1
30 380005003 FORWARD/REVERSE SELECTOR ......................1
31 681056001 * BALL BEARING (608ZZ)......................................1
32 681057001 * BALL BEARING (608RS)......................................1
33 200443001 ARMATURE ASSEMBLY (INC. KEY NOS. 31-32) .1
34 220017147 GEAR BOX SUB ASSEMBLY ..............................1
35 690032011 CHUCK (3/8 in.) ...................................................1
36300281116 CARRYING CASE (NOT SHOWN) .......................1
983000808 OPERATOR’S MANUAL (960223654)
7-17-08
(REV:01)
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
DRILL or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY

RYOBI 3/8 in. DRILL – MODEL NUMBER D46C
4
WIRING DIAGRAM
RED LEAD
BLACK LEAD
MOTOR
SWITCH
BRUSH ASSEMBLY
BRUSH
ASSEMBLY
YELLOW LEAD WHITE LEAD
WHITE LEAD
BLACK LEAD
POWER CORD
