Ryobi P235A Quick setup guide

RYOBI
18 Volt Impact Driver
Model Number P235A
Repair Sheet
ONE WORLD TECHNOLOGIES, INC.
P.O. Box 1288, Anderson, SC 29622 • Phone [phone]
www.ryobitools.com

RYOBI 18 VOLT IMPACT DRIVER − MODEL NUMBER P235A
2
14
10
18
13
15
19
16
12
12
17
11
98
7
1
6
5
4
3
2

RYOBI 18 VOLT IMPACT DRIVER − MODEL NUMBER P235A
3
1 660436005 Screw (M4 x 25.4 mm, T-20 Torx, Pan Hd.) .............. 4
2 203032005 Gear Case and Sleeve Bearing
Assembly (Inc. Key No. 18) ........................................ 1
3 903748001 Gasket........................................................................ 1
4 203032003 Cam Shaft and Hammer Assembly............................ 1
5 610449039 Ring Gear ................................................................... 1
6 662895001 Screw (M4 x 7 mm, T20 Torx Pan Hd.)
w/Spring Washer........................................................ 2
7 306997002 Inner Case Assembly ................................................. 1
8 680334036 Pin .............................................................................. 2
9 206032002 Motor w/Pinion Assembly .......................................... 1
10 203032004 Contact Plate and Switch Assembly.......................... 1
11 538409001 Forward/Reverse Selector ......................................... 1
12 203032002 Housing Assembly (Inc. Key Nos. 16-17)................... 1
13 303001052 Magnet and Foam Rubber Assembly ........................ 1
14 660031017 Screw (M3.5 x 16 mm, T10 Torx Pan Hd.) ................. 8
15 630206007 Bit Clip........................................................................ 1
16 941655039 Logo Label ................................................................. 1
17 941122259 Data Label .................................................................. 1
18 941120374 Hot Surface Warning Label ........................................ 1
19 670802034 Bit .............................................................................. 1
NOT SHOWN
995000841 Operator's Manual (961153041)
12-13-19
(Rev:01)
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
IMPACT DRIVER or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY

RYOBI 18 VOLT IMPACT DRIVER − MODEL NUMBER P235A
4
WIRING DIAGRAM
BLACK
BLACK
SWITCH
LED
CONTACT PLATE
RED
MOTOR
RED
