RYOBI
18 VOLT IMPACT DRIVER
MODEL NO. P230
REPAIR SHEET

RYOBI HP 18 VOLT IMPACT DRIVER – MODEL NUMBER P230
2
1
4
2
35
8
9
6
7
10
11
12
23
13
17
16
15
19
21
18
20
22
24
14
1
27
25
2
26
28

RYOBI HP 18 VOLT IMPACT DRIVER – MODEL NUMBER P230
3
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
1 200202246 HOUSING SET ASSEMBLY W/LABEL ............. 1
2 6320601 BIT CLIP 0.4THK ............................................ 2
3 690258001 RETAINING RING .......................................... 1
4 690266001 WASHER OD 15.4XID 12.4X 1.0 ................... 1
5 690261001 SPRING .......................................................... 1
6 690260003 SLEEVE .......................................................... 1
7 660176003 ST SCREW (M4 X 25 mm) ............................. 4
8 940230097 WARNING LABEL .......................................... 1
9 300639008
GEAR CASE ASSEMBLY ................................. 1
10 940114106 LOGO LABEL ................................................. 1
11 690249001 WASHER ......................................................... 1
12 690268001 STEEL BALL ................................................. 2
13 690257005 BIT HOLDER ................................................... 1
14 300640005 CAM SHAFT & HAMMER ASSEMBLY .......... 1
15 690256001 RETAINING RING .......................................... 1
16 610275001 INTERNAL GEAR ........................................... 1
17 660212032 SCREW (M4 X 7mm) ..................................... 2
18 6703001 SPRING WASHER ......................................... 2
19 901043001 OIL SEAL ........................................................ 1
20 640766001 INNER CASE .................................................. 1
21 6620805 SCREW (M4 X 16 mm) .................................. 8
22 230081003 MOTOR & PINION ASSEMBLY ...................... 1
23 512572001 F/R PUSH BATTON ......................................... 1
24 270018079 SWITCH ASSEMBLY ..................................... 1
25 670802046 SINGLE BIT, PH2 ........................................... 1
26 690884005 3/8 in. SOCKET ADAPTOR ............................ 1
27 200292003 PLUG-IN LANYARD ....................................... 1
28 940077061 DATA LABEL ................................................... 1
983000557 OPERATOR’S MANUAL (960223390)
983000557R REPAIR SHEET (REV:00)
01-21-05
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
IMPACT-DRIVER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY.

RYOBI HP 18 VOLT IMPACT DRIVER – MODEL NUMBER P230
4
WIRING DIAGRAM
MOTOR
BLACK LEAD
SWITCH
RED LEAD
WHITE LEAD
LED
RED LEAD
