Ryobi P260 Quick setup guide

RYOBI
18 VOLT IMPACT WRENCH
MODEL NUMBER P260
REPAIR SHEET

2
RYOBI 18 VOLT IMPACT WRENCH – MODEL NUMBER P260
1
2
2
3
4
5
678
9
11
14
13
12
15
10

3
RYOBI 18 VOLT IMPACT WRENCH – MODEL NUMBER P260
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
18 VOLT IMPACT WRENCH or when ordering parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 940304497 Logo Label.................................................... 1
2 201666001 ** Housing Assembly
(Use with Best Vincent Switch)..................... 1
303587001 ** Housing Assembly
(Use with Marquardt Switch) ........................ 1
3 230247001 Motor Assembly............................................ 1
4 220036005 Gear Train & Hammer Assembly................... 1
5 940221063 Warning Label ............................................... 1
6 301216014 Gear Box w/Anvil Assembly ......................... 1
7 670030004 Washer Ring (OD 7.2 x ID 4.1 x 1.0 mm) ...... 4
8 660133015 Screw (M4 x 20 mm)..................................... 4
9 562393001 Rubber Cap .................................................. 1
10 670772002 ¼ in. Quick Connect Coupler ....................... 1
11 940976506 Data Label..................................................... 1
12 660024049 Screw (M4 x 16 mm)..................................... 6
13 519289005 Forward/Reverse Button............................... 1
14 660031011 Screw (M3.5 x 16 mm).................................. 2
15 270013008 ** Switch Assembly (Best Vincent Switch) ....... 1
270061002 ** Switch Assembly (Marquardt Switch)........... 1
Not Shown:
987000672 Operator’s Manual (961067120)
3-6-12
(Rev:05)
** Housing Assembly 20166001 Must Be Used With Best Vincent Switch 270013008 Or Housing Assembly 303587001 Must Be Used With Marquardt Switch
Assembly 270061002. They Will Not Interchange With Each Other.

4
RYOBI 18 VOLT IMPACT WRENCH – MODEL NUMBER P260
WIRING DIAGRAM
MOTOR
SWITCH
RED LEAD
RED LEAD
BLACK
LEAD
BLACK LEAD
CONTACT PLATE
HOLDER
