RYOBI
18 VOLT IMPACT DRIVER
MODEL NUMBER P236
REPAIR SHEET

2
5
1
1
11
3
7
12 13 14
15
16
24
28
29
27
23
25
17 19 20 18 21
22
8910
31
4
6
26
30
RYOBI 18 VOLT IMPACT DRIVER − MODEL NUMBER P236
2

RYOBI 18 VOLT IMPACT DRIVER − MODEL NUMBER P236
1 201986002 Housing Assembly (Inc. Key Nos. 2-3 and 30)...1
2 940488328 Data Label ..........................................................1
3 940114178 Logo Label..........................................................1
4 291056001 LED Assembly ....................................................1
5 660031011 Screw (M3.5 x 16 mm) ......................................8
6 660436006 Screw (M4 x 25 mm) .........................................4
7 690258001 Retaining Ring ....................................................1
8 690266001 Washer (OD15.4 mm x ID12.4 mm x 1t).............1
9 690261001 Spring .................................................................1
10 690260026 Sleeve.................................................................1
11 300639028 Gear Case and Sleeve Bearing Assembly..........1
12 517868001 Washer ...............................................................1
13 692268001 Steel Ball ............................................................2
14 692822003 Bit Holder ...........................................................1
15 300640017 Cam Shaft and Hammer Assembly....................1
16 690256001 Retaining Ring ....................................................1
17 610449011 Internal Gear.......................................................1
18 902578001 Plate ...................................................................1
19 660212045 Screw (M4 x 7 mm) ............................................4
20 670030004 Spring Washer ....................................................4
21 641775001 Inner Case ..........................................................1
22 230377001 Motor and Pinion Assembly ...............................1
23 523179001 Forward/Reverse Selector..................................1
24 270016166 Switch Assembly................................................1
25 303001015 Magnet Assembly (Inc. Key No. 26) ...................1
26 560444002 Foam Rubber......................................................2
27 6320601 Bit Clip................................................................1
28 670802045 Bit (#2 Phillips)....................................................1
29 690884002 3/8 in. Socket Adaptor .......................................1
30 940230097 Warning Label ....................................................1
31 562753001 Foam Rubber Pad ..............................................1
NOT SHOWN:
988000661 Operator's Manual..............................................1
8-25-11
(REV:01)
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
IMPACT DRIVER or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY

RYOBI 18 VOLT IMPACT DRIVER − MODEL NUMBER P236
RED
RED
BLACK
BLACK RED
SWITCH
CONTACT
PLATE
MOTOR
WHITE
LED ASSEMBLY
4
WIRING DIAGRAM
