S-Access SA-REP-ETHERLINK_II-1DA-PL User manual

ETHERLINK II - Repeater Manual
Page 1 of 106
S-Access ETHERLINK_II Repeater
REPEATER DEVICES
TECHNICAL DESCRIPTION AND OPERATIONS MANUAL
Version 1.1
Document name _SAUM_SA_ETHERLINK_II_XX_Reg_V1-1_080123
Revision 23. January 2008

ETHERLINK II - Repeater Manual
Page 2 of 106
© Copyright ©2008 by S-Access GmbH. The content of this publication may not be reproduced
in any part or as a whole, transcribed, stored in a retrieval system, translated into any
language, or transmitted in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, photocopying, manual, or otherwise, without the prior written permission of
S-Access GmbH. Published S-Access GmbH. All rights reserved.

ETHERLINK II - Repeater Manual
Page 3 of 106
VERSION CONTROL.................................................................................................................7
SAFETY REGULATIONS ..........................................................................................................7
EU DIRECTIVE 2002/96/EC AND EN50419..............................................................................7
1SELECTION GUIDE ...........................................................................................................9
2INTRODUCTION...............................................................................................................10
3TECHNICAL DESCRIPTION ............................................................................................11
3.1 Application and general information about S-Access Etherlink_II devices..................11
3.2 Main features of S-Access Etherlink_II devices..........................................................13
3.3 PL and RL devices.....................................................................................................13
3.4 IP-67 devices .............................................................................................................17
3.5 Remote power supply, wetting current- supply and consumption modes....................19
3.5.1 Electrical safety regulations when using the remote power supply ......................19
3.5.2 Compatibility of wetting current supply and remote power supply modes............19
3.5.3 Remote power feeding........................................................................................19
3.5.4 Remote power Pass-through mode.....................................................................20
3.5.4.1 Jumper Settings V56 unit.............................................................................20
3.5.4.2 Jumper Settings V58 unit.............................................................................21
3.6 Description of S-Access Etherlink_II interfaces ..........................................................22
3.6.1 xDSL interface.....................................................................................................22
3.6.1.1 Master/Slave/Auto........................................................................................22
3.6.1.2 Multipair modes............................................................................................23
3.6.1.3 Reservation..................................................................................................25
3.6.1.4 Automatic configuration of a link...................................................................29
3.6.2 Ethernet interface................................................................................................31
3.6.3 An integrated switch of 64-kbit/s time slots..........................................................34
3.6.3.1 E1 mode (transmission of only time slots of E1 streams) .............................34
3.6.3.2 Mode of simultaneous transmission of time slots of E1 and Ethernet data ...35
3.6.4 Test loops ...........................................................................................................37
3.6.4.1 Analog Loopback .........................................................................................37
3.6.4.2 Performance monitoring...............................................................................38
3.6.4.3 G.826 performance monitoring.....................................................................38
3.6.5 BERT test............................................................................................................39
3.7 Alarm indication..........................................................................................................39
3.7.1 LEDs...................................................................................................................39
3.7.2 Alarm LEDs.........................................................................................................41
3.8 Management of S-Access Etherlink_II devices...........................................................43
3.8.1 Management of S-Access Etherlink_II with RS232 interface...............................43
3.8.2 Management of S-Access Etherlink_II with Ethernet interfaces...........................43
3.8.2.1 Telnet...........................................................................................................43
3.8.2.2 WEB.............................................................................................................43
3.8.2.3 SNMP ..........................................................................................................47

ETHERLINK II - Repeater Manual
Page 4 of 106
4PROGRAMMING GUIDE..................................................................................................48
4.1 Command structure....................................................................................................48
4.2 Etherlink_II software...................................................................................................50
4.3 Configuration storage and application........................................................................50
4.4 Groups of commands requiring confirmation..............................................................53
4.5 Command syntax.......................................................................................................54
4.6 Commands.................................................................................................................54
4.6.1 Main Menu..........................................................................................................54
4.6.1.1 System invitation..........................................................................................54
4.6.2 General Commands............................................................................................55
4.6.2.1 <H> command .............................................................................................55
4.6.2.2 <LINKCLEAR> command ............................................................................55
4.6.3 Performance management menu........................................................................55
4.6.3.1 <H> command .............................................................................................55
4.6.3.2 <TCPIP> command......................................................................................56
4.6.3.3 <MAC> command........................................................................................57
4.6.3.4 <G826> command .......................................................................................58
4.6.3.5 <RESETG826> command............................................................................58
4.6.3.6 <NETSTAT> command................................................................................59
4.6.3.7 <RESETNETSTAT> command....................................................................59
4.6.3.8 <M> command.............................................................................................59
4.6.3.9 <H> command .............................................................................................59
4.6.4 Fault and maintenance management menu ........................................................60
4.6.4.1 <H> command .............................................................................................60
4.6.4.2 <NM> command...........................................................................................61
4.6.4.3 <STATUS> command..................................................................................61
4.6.4.4 <STATUS ETH> command..........................................................................62
4.6.4.5 <MACTABLE> command.............................................................................62
4.6.4.6 <ALARM> command....................................................................................63
4.6.4.7 <AСO [GROUP ON/OFF])> command .........................................................64
4.6.4.8 <STARTAL ON/OFF N> command..............................................................64
4.6.4.9 <RESTART [N=1..4]> command..................................................................66
4.6.4.10 <RESET> command....................................................................................66
4.6.4.11 <SOFTUPDATE> command ........................................................................66
4.6.4.12 <SOFTCONFIRM> command......................................................................66
4.6.4.13 <SOFTINFO> command..............................................................................67
4.6.4.14 <APPLY /ALL/NET/VLAN/LINE/SNMP> command......................................67
4.6.4.15 <CONFIRM> command................................................................................67
4.6.4.16 <BACKUP> command..................................................................................68
4.6.4.17 <RESTORE> command...............................................................................68
4.6.4.18 <DIFF N/R/S/B N/R/S/B > command............................................................68
4.6.4.19 <DUMP N/R/S/B > command.......................................................................69
4.6.4.20 <LOAD> command ......................................................................................70
4.6.4.21 <POWERMODE [0..5]> command ...............................................................70

ETHERLINK II - Repeater Manual
Page 5 of 106
4.6.4.22 <SENSOR > command................................................................................70
4.6.4.23 <SENSOR [N=1-3] [O/C]> command...........................................................70
4.6.5 Configuration Management menu .......................................................................71
4.6.5.1 <H> command .............................................................................................71
4.6.5.2 <CONFIG> command ..................................................................................72
4.6.5.3 <CONFIG R/N/S/B> command.....................................................................72
4.6.5.4 <MASTER ON/OFF/AUTO N> command.....................................................73
4.6.5.5 <BASERATE K/AUTO [N=1..4]> command..................................................73
4.6.5.6 <PAM 16/32 [N]> command.........................................................................74
4.6.5.7 <ANNEX A/B/AB [N=1..4]> command..........................................................74
4.6.5.8 <PASSWORD USER/ADMIN> command ....................................................74
4.6.5.9 <ID N> command.........................................................................................74
4.6.5.10 <DEFAULT> command................................................................................74
4.6.5.11 <DEFAULT EVERYTHING> command........................................................75
4.6.5.12 <PAYLOAD list/NONE [N=1..4]> command .................................................75
4.6.5.13 <SERNUM> command.................................................................................75
4.6.5.14 <WAN> command........................................................................................75
4.6.5.15 <GSCOMPAT> command............................................................................76
4.6.5.16 <NET> command.........................................................................................76
4.6.5.17 <H> command .............................................................................................76
4.6.5.18 <NETCONFIG [R/N/S/B]> command............................................................77
4.6.5.19 <INTERFACE NAME COMMAND PARAM > command...............................78
4.6.5.20 <ETHSD 10/100/AUTO H/F [N=1..4]> command .........................................79
4.6.5.21 <SLICING SIZE> command.........................................................................79
4.6.5.22 <SETIP X.X.X.X> command.........................................................................80
4.6.5.23 <GATEWAY X.X.X.X> command.................................................................80
4.6.5.24 <NETMASK X.X.X.X> command..................................................................80
4.6.5.25 <VID> command..........................................................................................80
4.6.5.26 <TRAPIP ADD/DEL X.X.X.X> command......................................................80
4.6.5.27 <COMMUNITY> command ..........................................................................80
4.6.5.28 <SNMPSET ON/OFF> command.................................................................80
4.6.5.29 <NETDEFAULT> command.........................................................................81
4.6.5.30 <M> command.............................................................................................81
5SOFTWARE DOWNLOADING.........................................................................................82
5.1 Software loading via the RS232 port with the help of the Flash Loader program........82
5.2 Software loading via the COM port (the 1K Xmodem protocol)...................................86
5.3 Software loading via Ethernet (1K-Xmodem and Telnet)............................................91
6SERVICE INSTRUCTIONS...............................................................................................92
6.1 General requirements.................................................................................................92
6.2 Evaluation of the quality of the digital channel and operation parameters...................93
7APPENDICES...................................................................................................................94
7.1 Example 1 of configuration of Etherlink_II devices .....................................................94

ETHERLINK II - Repeater Manual
Page 6 of 106
7.1.1 Configuration of the S-Access Etherlink_II device at the Central Office premises.
94
7.1.2 Configuration of the S-Access Etherlink_II device at the Customer Premises......95
7.1.3 Configuration of the S-Access Etherlink_II regenerator at the Regenerator Point.95
7.2 Example 2 of configuration of Etherlink_II devices .....................................................95
7.2.1 Configuration of the S-Access Etherlink_II device at the Central Office premises.
96
7.2.2 Configuration of the S-Access Etherlink_II device at the Customer Premises......97
7.2.3 Configuration of the S-Access Etherlink_II regenerator at the Regenerator Point.97
7.3 Connectors’ description..............................................................................................99
7.3.1 “Ethernet” connector ...........................................................................................99
7.3.2 “G703” connector ..............................................................................................100
7.3.3 “xDSL” connector RJ45.....................................................................................100
7.3.4 “xDSL” connector XF19.....................................................................................101
7.3.5 “Monitor” connector ...........................................................................................102
7.3.6 “Monitor/TLM” connector XF4............................................................................102
7.3.7 “-48VDС” connector ..........................................................................................103
7.3.8 “-48VDС” connector XF6...................................................................................103
8TECHNICAL SPECIFICATION.......................................................................................104
8.1 Interfaces.................................................................................................................104
8.1.1 xDSL Line Interface...........................................................................................104
8.1.2 E1 Line Interface...............................................................................................104
8.1.3 Monitor Interface...............................................................................................104
8.1.4 Ethernet ............................................................................................................104
8.2 Power Supply...........................................................................................................105
8.3 Environmental..........................................................................................................105
8.3.1 Climatic Conditions ...........................................................................................105
8.3.2 Safety / EMC.....................................................................................................105
8.4 Physical Dimensions and Weight .............................................................................106

ETHERLINK II - Repeater Manual
Page 7 of 106
VERSION CONTROL
User Manual
Versi
on
Date
Software
Version
Major changes to previous version
1.0
January2007
1.2.7
Initial version
1.1
May 2007
1.3.4
Modified 7.3.4 for 2wire repeaters
Actualized multipair topic
Included pass-through jumper setting for V58
SAFETY REGULATIONS
IF THE UNIT IS NOT USED IN ACCORDANCE TO REGULATIONS DESCRIBED AND DEFINED IN
THE CHAPTERS ”TECHNICAL DESCRIPTION” AND “TECHNICAL SPECIFICATIONS”, S-ACCESS
GMBH REFUSES TO TAKE ANY RESPONSIBILITY. FURTHERMORE, NO WARRANTY IS GRANTED
IN SUCH CASE!
ITS ONLY ALLOWED TO USE EXTERNAL POWER SUPPLIES THAT ARE APPROVED ACOORDING
TO THE SAFETY STANDARD IEC/EN 60950-1.
ITS ONLY ALLOWED TO USE A REMOTE DSL POWER SOURCE THAT HAS AN APPROVED TVN3
INTERFACE.
THE EARTH SCREW OF THE NTU UNIT HAS TO BE CONNECTED PERMANENTLY TO A RELIABLE
PROTECTIVE EARTH CONDUCTOR.
ALL IP UNITS HAVE TO BE CONNECTED PERMANENTLY TO A RELIABLE PROTECTIVE EARTH
CONDUCTOR.
INCORRECT USE OF THIS DEVICE, USE IN ANY OTHER ENVIRONMENT AND/OR HOUSING THAN
PROVIDED BY S-ACCESS MIGHT LEAD TO HARMFUL CONDITIONS. FAILURE TO FOLLOW THESE
PRECAUTIONS MAY RESULT IN DEATH, SEVERE INJURY OR PROPERTY DAMAGE.
Please read this manual carefully before operating the system.
Installation of this equipment has to be done by qualified personnel only.
EU DIRECTIVE 2002/96/EC AND EN50419

ETHERLINK II - Repeater Manual
Page 8 of 106
This equipment is marked with the above recycling symbol. It means that at the end of the life of
the equipment you must dispose of it separately at an appropriate collection point and not place
it in the normal domestic unsorted waste stream. (European Union only)

ETHERLINK II - Repeater Manual
Page 9 of 106
1 SELECTION GUIDE
REPEATER (ETHERLINK II), Ethernet Bridge
Standalone
DIN RAILMounting
2 wire (5,7Mb)
4 wire (11,4Mb)
Protected Housing
Nx64/RS232
Ethernet Bridge
Ethernet Add/Drop
Point to Point
48V-DC
Remotely powerable
Telnet Management
Web Management
Telnet Management
SNMP Management
SA-REP-ETHERLINK_II-1DA-PL
SA-REP-ETHERLINK_II-1DA-RL
SA-REP-ETHERLINK_II-1DA-IP67
SA-REP-ETHERLINK_II-2DA-PL
SA-REP-ETHERLINK_II-2DA-IP67

ETHERLINK II - Repeater Manual
Page 10 of 106
2 INTRODUCTION
The present document describes devices of the S-Access Etherlink_II Repeater family. The
document contains the technical description of the devices, installation, configuration, and
operation instructions. Appendices containing additional information about the system are also
an integral part of the present document.
Warning!! Before starting operating the equipment, read carefully PART 5 of the present
document. The guarantee will not be granted to the device malfunctioning or damaged due to
failure to comply with the requirements stated in the Section related to “Service Instructions” of
the present document.
Warning!! An example of fast configuration of the equipment is described in Appendix 6.1 of the
present document.

ETHERLINK II - Repeater Manual
Page 11 of 106
3 TECHNICAL DESCRIPTION
3.1 Application and general information about S-Access Etherlink_II devices
S-Access Etherlink_II devices represent xDSL modems (ITU-T G.991.2–G.shdsl and ITU-T
G.991.2 –G.shdsl.bis standards, TC-PAM line encoding). They are designed to organize high-
speed data communication channels over symmetric digital subscriber lines (DSLs) with the
transmission rates from 200 to 5704 kbit/s (with the step of 64 kbit/s). The TC-PAM (Trellis
Coded Pulse Amplitude Modulation) encoding used in these devices well combines such
characteristics as the transmission range, noise immunity and electromagnetic operability. The
number of levels (code states) in TC-PAM is increased up to 32 and a special error correction
mechanism is used. To increase the distance range by 2 or more times, regenerators can be
used.
The family of S-Access ETHERLINK_II includes devices with G.703 and Ethernet network
interfaces. Thus, the S-Access ETHERLINK_II equipment provides complex services which
allow one to transmit simultaneously voice and data as well as to construct TDM networks of
different topologies without using expensive interface converter, multiplexers and cross-connect
systems.
The devices of this family include network termination units (NTUs) and line termination units
(LTUs), which are installed at the customer (user) premises and the operator (provider)
premises, respectively. In addition, the devices of this family include regenerators. To organize
the “point-to-point” topology, the following schemes can be used: NTU – NTU, LTU –LTU or
NTU –LTU.
The devices can be powered from local DC sources. Regenerators and NTUs can be fed both
locally or remotely from LTUs. Figure 1.1 presents an example of organization of data
transmission systems with the help of modems of the S-Access Etherlink_II family. Other
variants of the usage of this equipment are also possible.
О_ОП

ETHERLINK II - Repeater Manual
Page 12 of 106
LTU
RGNo2
( remote
power)
RGNo2
( remote
power)
RGNo2
( local power) NTU
SHDSL SHDSL SHDSL SHDSL
VLAN
Switch
Ethernet
Network
N2
Ethernet
Network
N1
Eth
ATS
G. 703(E1) G. 703(E1)
ATS
Management PCVoIP
VLAN
Switch
Ethernet
Network
N2
Ethernet
Network
N1 Management PCVoIP
INTERNET
Repeater Point Repeater Point Repeater Point
ETHERLINK_II ETHERLINK_II
SA_RC_ETHERLINK_II_4DSL-4E1-4ETH
SA_RC_ETHERLINK_II_4DSL-4E1-4ETH
Figure 3.1 An example of organization of a data communication channel using S-Access
Etherlink_II modems
Notations in the figure:
ATS: a private automatic branch exchange;
E1: a 2048-kbit/s digital flow structured according to ITU-T Rec. G.704;
Management PC: a personal computer used to configure the system;
VLAN Switch: a switch of Ethernet packets supporting the VLAN function (IEEE 802.1q);
VoIP: devices of IP telephony (VOICE over IP);
Ethernet Network: local Ethernet network;
ETHERLINK_II LTU: S-Access ETHERLINK_II line termination unit;
ETHERLINK_II NTU: S-Access ETHERLINK_II network termination unit;
RGNo2: S-Access ETHERLINK_II regenerator.
The devices of this family have different mechanic designs: SubRack –a unit to be inserted into
a 19’’ AccessGain shelf; MiniRack –a 1U (44.5 mm) unit to be inserted into a 19’’ cabinet;
Stand Alone –a desktop unit; IP-67 –a unit in a water-proof plastic or silumin housing (class IP-
67); XCVR –a unit to be inserted into a hermetic steel housing.
The devices have the following possibilities for monitoring and management:
Local management and control of remote devices and regenerators –VT 100;
Local management and control of remote devices and regenerators –Telnet session;
Operation in complex networks under the unified management system –support of SNMP.

ETHERLINK II - Repeater Manual
Page 13 of 106
The use of the Flash memory as the ROM provides an easy upgrade of the software.
xDSL modems are powered from a grounded primary DC source (38 … 78 V) or remotely.
Modems are designed to be used in-doors under the following environmental conditions:
- temperature of ambient air –from -5 … +45°C;
- relative air humidity –from 5% … 85% at +25°C.
3.2 Main features of S-Access Etherlink_II devices
S-Access Etherlink_II modems represent the next generation of modems of the S-Access
Etherlink family and have the following features:
1. A new type of line encoding –TC-PAM32 (TC-PAM16 is also supported).
2. Duplex data transmission over one symmetrical pair at 5.7 Mbit/s.
3. Simultaneous transmission of the TDM traffic and Ethernet data.
4. The 802.1q protocol.
5. Different ways of system configuration (for example, remote configuration of devices via
Telnet).
6. Embedded WEB interface.
7. The SNMP protocol.
8. Possibility of storing several configurations in the device’s EEPROM in order to download
the previous settings of the system.
9. Two levels of system users: administrator and user, protected with passwords.
10. The use of the modern circuit printed boards, chips and components.
11. Extended reliability of the equipment.
3.3 PL and RL devices
From the mechanic point of view, the device represents a case made of shockproof polystyrene
to withstand harsh environmental conditions, the case containing the basic elements of the
device. The power supply unit represents an external power supply in the form of a plug.
The front panel contains the following connectors and LEDs:

ETHERLINK II - Repeater Manual
Page 14 of 106
Table 3.1 Connectors and LEDs of the Stand Alone devices.
Element
Description
DSL 1
A LED showing the status of the first line interface of the device
DSL 2
A LED showing the status of the second line interface of the device
Eth
A LED showing the status of the Ethernet port
G.703 1
A LED showing the status of the first E1 port
G.703 2
A LED showing the status of the second E1 port
Ethernet
An RJ45 connector for the connection of Ethernet + two LEDs
G.703
An RJ45 connector for the connection to the Е1 equipment + two LEDs
Monitor
A DB9 connector (female) for the connection to the control terminal
-48VDC
A connector for the connection to a primary DC source
LP/DP
A toggle of the power supply (local/remote)
xDSL
An RJ45 connector for the connection to the xDSL line + two LEDs
A grounding bolt

ETHERLINK II - Repeater Manual
Page 15 of 106
Figure 3.2: Top- and front view SA_REG_ETHERLINK_II-1DA,V51 devices
Figure 3.3. Rear view SA_REG_ETHERLINK_II-1DA,V51 devices

ETHERLINK II - Repeater Manual
Page 16 of 106
Figure 3.4. Top view SA_REG_ETHERLINK_II-1DA-RL,V51 devices
Figure 3.5. Front view SA_REG_ETHERLINK_II-1DA-RL,V51 devices

ETHERLINK II - Repeater Manual
Page 17 of 106
3.4 IP-67 devices
The device represent a silumin or plastic housing containing the basic elements of the device.
The housing design corresponds to the IP-67 class (in accordance with IEC-60529). The
housing has two or three (for the plastic housing) cable inputs with stub cables for the
connection to xDSL lines, as well as two hermetic RJ-45 connectors, an M4 grounding bolt and
a LED for the silumin housing.
The regenerators in the silumin housing contain the following connectors and LEDs:
Table 3.2 Connectors and LEDs of simulin-housing regenerators.
Element
Description
“STATUS”
A LED
Ethernet
A hermetic RJ45 connector for the connection of Ethernet
Monitor/TLM
A hermetic RJ45 connector for the connection to the control terminal or
to the dry loop
M4 bolt
A grounding bolt
xDSL 1
1 and/or 3
A cable of the first and/or third xDSL line
xDSL 2
2 and/or 4
A cable of the second and/or fourth xDSL line
The regenerators in the plastic housing contain the following connectors and LEDs:
Table 3.3 Connectors and LEDs of plastic-housing regenerators.
Element
Description
DSL1
A LED showing the status of the first line
DSL2
A LED showing the status of the second line (for two-channel
regenerators)
Eth
A LED showing the status of the Ethernet port
G703 (above)
A LED showing the status of the first E1 port
G703 (below)
A LED showing the status of the second E1 port
A
A hermetic RJ45 connector for the connection to the control terminal or
to the dry loop
B
A hermetic RJ45 connector for the connection of Ethernet
Powering
Grounding
Output of the power cable (for locally powered devices) and
Grounding cable
xDSL 1
1 and/or 3
A cable of the first and/or third xDSL line
xDSL 2
2 and/or 4
A cable of the second and/or fourth xDSL line

ETHERLINK II - Repeater Manual
Page 18 of 106
Figure 3.4 View of SA_REG_ETHERLINK_II-XDA-IP67 devices

ETHERLINK II - Repeater Manual
Page 19 of 106
3.5 Remote power supply, wetting current- supply and consumption modes
The wetting current supply and remote power supply modes can be changed by using jumpers
and the management PC.
3.5.1 Electrical safety regulations when using the remote power supply
Despite the safe voltage on each wire with respect to the ground (<120 Volts), the use the
remote power supply requires one to observe strictly the following rules:
When working with lines and the a junction box, the xDSL cable should be disconnected
from the device supplying the remote power;
The insulation of cable pairs, junctions (junction boxes, plinths, etc.) should correspond to
norms and standards of the network;
3.5.2 Compatibility of wetting current supply and remote power supply modes
The table of compatibility of the wetting current supply and remote power supply modes is
presented below.
The devices operating in pairs should be configured for mutual operation (“” –
compatible). The use of the mode «-» is not recommended because it may cause: high power
consumption, degradation of communication (communication stability), the use of additional
safety measures. The mode “incompatible” (inc) will not allow the devices to establish
communication (because in this case one or both devices will be de-energized).
Wetting current supply
and remote power supply
modes
Regenerator
LTU
Remote
power
consumption
Local
Power
Remote
power
supply
Wetting
current
supply
Wetting
current
consumption
No
Regene-
rator
Remote
power
consumption
inc
inc

inc
inc
inc
No
inc

-
-


Warning! To prevent the FAILURE OF THE EQUIPMENT, the use of “X” modes IS STRICTLY
PROHIBITED!
Table 3.4 Compatible operation of remote power supply and wetting current supply modes.
3.5.3 Remote power feeding
Repeater devices can be configured to the local power supply and remote power supply modes
(LP/DP). The LP/DP modes are switched from one to another with the help of a toggle on the
rear panel of the device (see Figure 3.5).

ETHERLINK II - Repeater Manual
Page 20 of 106
Figure 3.5. Position of the switch of LP/DP modes on the repeater board.
3.5.4 Remote power Pass-through mode
It’s possible to feed more than one repeater in series from a LTU with a remote power source.
To provide the Pass-trough option, you have to put Jumpers to XM2, XM3, XM4 and XM5.
3.5.4.1 Jumper Settings V56 unit
