Nortel Secure Router 4134 User manual

Nortel Secure Router 4134
Installation — Chassis
Release: 10.2
Document Revision: 03.01
www.nortel.com
NN47263-300
.

Nortel Secure Router 4134
Release: 10.2
Publication: NN47263-300
Document release date: 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
While the information in this document is believed to be accurate and reliable, except as otherwise expressly
agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF
ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are
subject to change without notice.
Nortel, Nortel Networks, the Nortel logo, and the Globemark are trademarks of Nortel Networks.
ATTENTION:
Before unpacking, installing, or using the Secure Router 4134, ensure you read the section about
regulatory information and general safety precautions in the first chapter of this guide.
All other trademarks are the property of their respective owners.
.

3
.
Contents
Secure Router 4134 regulatory information and safety
precautions 5
International Regulatory Statements of Conformity 5
National Electromagnetic Compliance (EMC) Statements of Compliance 5
FCC statement (USA only) 5
TIA-968-A 6
ICES statement (Canada only) 6
CE marking statement (Europe only) 6
European Union and European Free Trade Association (EFTA) notice 7
VCCI statement (Japan/Nippon only) 7
BSMI statement (Taiwan only) 8
MIC notice (Republic of Korea only) 8
National Safety Statements of Compliance 8
EN 60950 statement 8
NOM statement (Mexico only) 9
Información NOM (unicamente para México) 9
Denan statement (Japan/Nippon only) 10
National Environmental Statements of Compliance 10
RoHS Directive Compliance Statement 10
WEEE Directive Compliance Statement 11
Safety messages 11
Notices 11
Cautions and warnings for the Secure Router 4134 12
Personal safety and equipment protection 13
Module protection 13
Cables and connectors protection 14
Electrostatic discharge 14
Antistatic material 15
New in this release 17
Introduction 19
Navigation 19
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.

4
Nortel Secure Router 4134 chassis fundamentals 21
Secure Router 4134 chassis 21
Important information about the Secure Router 4134 27
Compatible external interface modules for the Secure Router 4134 28
Slot numbering 29
Secure Router 4134 replaceable parts 30
Secure Router 4134 service access panel 32
Secure Router 4134 chassis installation 35
Prerequisites to Secure Router 4134 chassis installation 35
Secure Router 4134 chassis installation procedures 35
Secure Router 4134 chassis installation navigation 36
Prepare and install the Secure Router 4134 chassis 39
Unpacking and inspecting the chassis and shipping accessories 39
Installing the mounting brackets on the Secure Router 4134 40
Prerequisites 42
Installing the Secure Router 4134 chassis in an equipment rack 43
Prerequisites 44
Installing the terminal lug on the Secure Router 4134 44
Prerequisites 45
Opening the rear access panel 47
Prerequisites 47
Hardware specifications 49
Chassis dimensions 49
Weights 49
Clearance requirements 50
Environmental requirements 50
Mounting rack requirements 51
Power and grounding 52
Power supply specifications 52
Power budget 52
Grounding 53
Translations of safety messages 55
Class A device caution statement 55
Qualified service personnel warning statement 56
Overcurrent warning statement 56
Cover plate warning statement 57
Laser fiber optic warning statement 58
Electric shock danger statement 59
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.

5
.
Secure Router 4134 regulatory
information and safety precautions
International Regulatory Statements of Conformity
This is to certify that the Nortel Secure Router 4134 equipment was
evaluated to the international regulatory standards for electromagnetic
compliance (EMC) and safety and were found to have met the
requirements for the following international standards:
•EMC – Electromagnetic Emissions – CISPR 22, Class A
•EMC – Electromagnetic Immunity – CISPR 24
•Electrical Safety – IEC 60950, with CB member national deviations
Further, the equipment has been certified as compliant with the national
standards as detailed below.
National Electromagnetic Compliance (EMC) Statements of
Compliance
FCC statement (USA only)
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the Federal Communications
Commission (FCC) rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy. If it is not installed and used in accordance
with the instruction manual, it may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case users will be required to take
whatever measures may be necessary to correct the interference at their
own expense. Changes or modifications not expressly approved by Nortel
could void the user’s authority to operate the equipment.
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.

6Secure Router 4134 regulatory information and safety precautions
TIA-968-A
This equipment complies with Part 68 of the FCC rules. The FCC Part
68 label is located on the bottom chassis panel. This label contains the
FCC Registration Number and Ringer Equivalence Number (REN) for
this equipment. If requested, this information must be provided to your
telephone company.
Connection to the telephone network should be made by using standard
modular telephone jacks, type RJ-48C. The RJ-48C plug and/or jacks used
must comply with the FCC Part 68 rules.
MFRs Port
Identifier Facilities Interface
Code
Service Order
Code Network
Connectors
T1: lines 1–16 04DU9-1SN
04DU9-1ZN 6.0N RJ-48C
ICES statement (Canada only)
Canadian Department of Communications Radio Interference
Regulations
This digital apparatus (Nortel Secure Router 4134) does not exceed the
Class A limits for radio-noise emissions from digital apparatus as set out
in the Radio Interference Regulations of the Canadian Department of
Communications.
Règlement sur le brouillage radioélectrique du ministère des
Communications
Cet appareil numérique (le commutateur Nortel Secure Router 4134)
respecte les limites de bruits radioélectriques visant les appareils
numériques de classe A prescrites dans le Règlement sur le brouillage
radioélectrique du ministère des Communications du Canada.
CE marking statement (Europe only)
EN 55022 statements
This is to certify that the Nortel Secure Router 4134 equipment is shielded
against the generation of radio interference in accordance with the
application of Council Directive 2004/108/EC. Conformity is declared by
the application of EN 55022 Class A (CISPR 22).
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.

National Electromagnetic Compliance (EMC) Statements of Compliance 7
CAUTION
This device is a Class A product. In a domestic environment,
this device can cause radio interference, in which case the user
may be required to take appropriate measures. For translations
of this message, see “Translations of safety messages” (page
55).
EN 55024 statement
This is to certify that the Nortel Secure Router 4134 is shielded against the
susceptibility to radio interference in accordance with the application of
Council Directive 2004/108/EC. Conformity is declared by the application
of EN 55024 (CISPR 24).
EN 300386 statement
The Nortel Secure Router 4134 complies with the requirements of EN
300386 V1.3.3 for emissions and for immunity for a Class A device
intended for use in either Telecommunications centre or locations other
than telecommunications centres given the performance criteria as
specified by the manufacturer.
European Union and European Free Trade Association (EFTA) notice
All products labeled with the CE marking comply with R & TTE Directive (1999/5/EEC)
which includes the Electromagnetic Compliance (EMC) Directive (2004/108/EC) and
the Low Voltage Directive (2006/95/EC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the following
European Norms (ENs). The equivalent international standards are listed
in parenthesis.
•EN 55022 (CISPR 22)–Electromagnetic Interference
•EN 55024 (IEC 61000-4-2, -3, -4, -5, -6, -8, -11)–Electromagnetic
Immunity
•EN 61000-3-2 (IEC 610000-3-2)–Power Line Harmonics
•EN 61000-3-3 (IEC 610000-3-3)–Power Line Flicker
VCCI statement (Japan/Nippon only)
This is a Class A product based on the standard of the Voluntary Control
Council for Interference (VCCI) for information technology equipment.
If this equipment is used in a domestic environment, radio disturbance
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.

8Secure Router 4134 regulatory information and safety precautions
may arise. When such trouble occurs, the user may be required to take
corrective actions.
BSMI statement (Taiwan only)
This is a Class A product based on the standard of the Bureau of
Standards, Metrology and Inspection (BSMI) CNS 13438 and CNS14336,
Class A.
MIC notice (Republic of Korea only)
This device has been approved for use in Business applications only per
the Class A requirements of the Republic of Korea Ministry of Information
and Communications (MIC). This device may not be sold for use in a
non-business application.
Observe the Regulatory Marking label on the back or bottom of each
switch for specific certification information pertaining to this model. Each
Nortel Secure Router 4134 model is approved for shipment to/usage in
Korea and is labeled as such, with all appropriate text and the appropriate
MIC reference number.
National Safety Statements of Compliance
EN 60950 statement
This is to certify that the Nortel Secure Router 4134 equipment is in
compliance with the requirements of EN 60950 in accordance with the Low
Voltage Directive. Additional national differences for all European Union
countries have been evaluated for compliance.
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.

National Safety Statements of Compliance 9
NOM statement (Mexico only)
The following information is provided on the devices described in this
document in compliance with the safety requirements of the Norma Oficial
Méxicana (NOM):
Exporter: Nortel Networks,
5400 Hellyer Ave,
San Jose, CA 95138 USA.
Importer: Nortel Networks de México, S.A. de C.V.
Avenida Insurgentes Sur #1605
Piso 30, Oficina
Col. San Jose Insurgentes
Deleg-Benito Juarez México D.F. 03900
Tel:
Fax: [phone]
52 5 480 2199
Input: Nortel Secure Router 4134:
•PS-SR4K-660W-AC-POE
100-240V ~ 10A/5A 50/60 Hz
•PS-SR4K-250W-AC
100-240V ~ 5A/3A 50/60 Hz
•PS-SR4K-250W-DC
43-72V 9.5A MAX
Información NOM (unicamente para México)
La información siguiente se proporciona en el dispositivo o en los
dispositivos descritos en este documento, en cumplimiento con los
requisitos de la Norma Oficial Méxicana (NOM):
Exportador: Nortel Networks,
5400 Hellyer Ave,
San Jose, CA 95138 USA.
Importador: Nortel Networks de México, S.A. de C.V.
Avenida Insurgentes Sur #1605
Piso 30, Oficina
Col. San Jose Insurgentes
Deleg-Benito Juarez México D.F. 03900
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.

10 Secure Router 4134 regulatory information and safety precautions
Tel:
Fax: [phone]
52 5 480 2199
Embarcar a: Nortel Secure Router 4134:
•PS-SR4K-660W-AC-POE
100-240V ~ 10A/5A 50/60 Hz
•PS-SR4K-250W-AC
100-240V ~ 5A/3A 50/60 Hz
•PS-SR4K-250W-DC
43-72V 9.5A MAX
Denan statement (Japan/Nippon only)
National Environmental Statements of Compliance
The WEEE Directive 2002/96/EC and RoHS (Restriction of Hazardous
Substances) Directive 2002/95/EC sets collection, recycling and recovery
targets for various categories of electrical products and their waste.
RoHS Directive Compliance Statement
The Restriction on Hazardous Substances Directive (RoHS) (2002/95/EC),
which accompanies the WEEE Directive, bans the use of heavy metals
and brominated flame-retardants in the manufacture of electrical and
electronic equipment. Specifically, restricted materials under the RoHS
Directive are Lead (including solder used in PCB’s), Cadmium, Mercury,
Hexavalent Chromium, and Bromine.
Nortel declares compliance with the European Union (EU) RoHS Directive
(2002/95/EC).
Nortel Secure Router 4134
Installation — Chassis
NN47263-300 03.01 7 September 2009
Copyright © 2007-2009 Nortel Networks. All Rights Reserved.
.
