S-Lighting S-AURA User manual

USER MANUAL
S-AURA

TABLE OF CONTENTS
1. IntroductIon 3
2. Safety InformatIon 3
3. Product InformatIon 4
3.1 SPecIfIcatIon 4
3.2 cleanIng and maIntenance 5
3.3 dMX-512 7
4. dISPlay menu 9
5. dMX functIonS and valueS 10

3 www.slservice.pl S-LIGHTING S-Aura
1. IntroductIon
2. Safety InformatIon
Thank you for choosing our product! Please consult
this manual for any safety reasons, to ensure a painless
and trouble-free operation, as well as for any reference
needed.
We encourage you to check out our other products at our
website: http://slservice.pl/ !
To maintain this device’s condition and to ensure a safe
operation, it is absolutely necessary for the user to follow
these safety instructions and warning notes written in this
user manual.
- This device falls under protection-class I. Therefore it is essential
that the device should be earthed.
- The electric connection and installation should be done
by qualied personnel in order to minimize the risk
of accidental electric shock and damaging the device.
- Always disconnect from the mains, when the device is not
in use or before cleaning it. Only handle the power cord by the plug.
Never pull out the plug by tugging the power cord.
- Make sure the power cord is never crimped or damaged
by sharp edges - if this would be the case, immediately
replace the cable for the exact same type.
- Before connecting the unit to the mains, make sure it is not
damaged mechanically. If you notice any signs of damage,
you should contact your dealer immediately. In this case
do not connect the device to the mains.
- Make sure that the available voltage is not higher than 240V.
- Never look directly into the light source (especially if you have
any epileptic past)!
- The device must be installed on a stable structure. Always use steel
security cable to attach the device to a stable structure.
- Do not use this device in high humidity conditions and at tempera-
tures above 40°C.
- Do not cover the ventilation slots when operating to avoid internal
overheating.

S-LIGHTING S-Aura www.slservice.pl 4
Power supply voltage: 100-240V
Power consumption: 250W
Voltage frequency: 50/60Hz
Diode type and power: 12W RGBW OSRAM 4in1 LED
Number of diodes: 19pcs
Beam angle: 8°-58°
Pan: 540°
Tilt: 240°
Scan rate: 7000 Hz
Dimming: 16-bit dimmer
DMX standard: DMX 512
DMX channels: 14/25
AC IN: powerCON
AC OUT: powerCON
DMX IN: XLR - 3 pin
DMX OUT: XLR - 3 pin
IP Rating: IP20
Cooling: Active
Height [cm]: 38
Width [cm]: 32
Depth [cm]: 21
Weight [kg]: 8
3. Product InformatIon
3.1 SPecIfIcatIon
- CAUTION: This product’s housing may be hot when lights
are operating.
- DO NOT connect this product to a dimmer or rheostat.
In case of a serious operating problem stop using this product
immediately!
Important:
Damages caused by a disregard of this user manual are not subject
to warranty or any liability.

5 www.slservice.pl S-LIGHTING S-Aura
3.2 cleanIng and maIntenance
There are no servicable parts inside the device. Maintenance and
service operations are only to be carried out by authorized dealers.
If you need any spare parts, please use only genuine parts.
If the power supply cable of this device becomes damaged,
it has to be replaced by authorized dealers only, in order
to avoid hazards.
Never remove the ground pins from power cord nor spin
any cooling fan with compressed air, as this can damage the compo-
nents in your xture.
If you have further questions, please contact your dealer.
We recommend a frequent cleaning of the device, as dust,
smoke and other debris will build up on the optics and ho-
using. After disconnecting the power wipe the devi-
ce with a soft, lint-free and damp cloth. Never use alcohol
or solvents, as these may damage the nish. A dry paint brush is an
excellent tool to remove surface dust.
Be sure to periodically check for loose parts that could damage the
device or potentially allow the device to cause injury. Make sure all
overhead and wall installations have a secondary safety accessory
installed, such as safety cable rated for your device type and size.
Check the power cord as well, make sure there is no damage that
could cause electrical shock, never remove the ground pin. There are
no user-servicable parts in this device. Do not attempt to open and
repair the xture.
CAUTION! Always disconnect from mains before
starting any maintenance operation!
Before replacing a fuse, disconnect the power
cord! Always replace with the same type
and rating of fuse!

S-LIGHTING S-Aura www.slservice.pl 6
Mounting & rigging
This device can be mounted in any orientation (vertical, horizontal).
Always make sure there is adequate ventilation and no ammable
surfaces within 2 feet (0.6 meters) of the device. You can mount
the device using clamps or with threaded bolt type hardware.
Always install the included safety eyebolt and cable when mounting
in overhead or wall locations.
Expected LED lifespan
LEDs gradually decline in brightness over time, mostly because
of heat. Packaged in clusters, LEDs exhibit higher operating
temperatures than in ideal, single LED conditions. For this
reason, using clustered LEDs at their fullest intensity signicantly
reduces the LEDs’ lifespan. Under normal conditions, this lifespan
can be 40’000 to 50’000 hours.
If extending this lifespan is vital, lower the operating temperatu-
re by improving the ventilation around the product and reducing
the ambient temperature to an optimal operating range. In addition,
limiting the overall projection intensity may also help to extend
the LEDs’ lifespan.
Warning: Do not mount the xture in the
ventilation path of a nearby heating supply
duct. The heated airow will cause device
failure due to overheating.

7 www.slservice.pl S-LIGHTING S-Aura
3.3 dMX-512
- 2-conductor twisted pair plus a shield,
- maximum capacitance between conductors - 30pF/ft,
- maximum capacitance between conductor & shield - 55 pF/ft,
- maximum resistance of 20 ohms / 1000 ft (304.8m in normal),
- nominal impedance 100 - 140 ohms.
Cable connectors:
Cables must have a male XLR connector on one end and a female
XLR connector on the other end (duh!).
A word on termination: DMX is a resilient communication protocol,
however errors still occasionally occur. Termination reduces signal
errors, and therefore best practises include the use of terminator
in all circumstances. If you are experiencing problems with erratic
device behavior, especially over long cable runs, a terminator may
help improve performance.
CAUTION: Do not allow contact between the common and the
device’s chassis ground. Grounding the common may cause
a ground loop, and your device may perform erratically. Test cables
with an ohm meter to verify correct polarity and to make sure
the pins are not grounded or shorted to the shield or each other.
To build your own DMX Terminator:
Obtain a 120-ohm, 1/4-watt resistor and
wire it between pins 2 & 3 of the last
xture. They are also readily available from
specialty retailers. A DMX terminator
To link devices together you’ll
need data cables. You should use
data grade cables that can carry
a high quality signal and are
less prone to electromagnetic
interference. For instance,
Belden© 9841 meets the
specications for EIA RS-485 applications. Standard microphone
cables will probably be OK, but note that they cannot transmit
DMX data as reliably over long distances. In any event, the cable
should have the following characteristics:

S-LIGHTING S-Aura www.slservice.pl 8
First device
in chain
Signal IN
To the
next
device
Next device
in chain
Step 1: Connect the male
connector of the DMX cable
to the female connector (output)
on the controller.
Step 2: Connect the female
connector of the DMX cable
to the rst device’s male
connector (input).
Note: It doesn’t matter which device address
is the rst one connected. We recommend
connectingthe devicein termsof theirproximi-
ty to the controller, rather than connecting
the lowest device number rst, and so on.
Setting up DMX control
Step 3: Connect other devices in the chain from output to input
as above. Place a DMX terminator on the output of the nal device
to ensure the best communication.
Fixture linking (Master/Slave Mode)
1. Connect the (male) 3-pin connector side of the DMX cable to the
output (female) 3-pin connector of the rst device.
2. Connect the end of the cable coming from the rst device, which
will have a (female) 3-pin connector to the input connector of the
next device consisting of a (male) 3-pin connector. Then, proceed
to connect from the output as stated above, to the input
of the following device (and so on).
3-Pin / 5-Pin
If you use a controller with a 5 pin DMX output connector, you will
need to use a 5 pin to 3 pin adapter. They are widely available over
the Internet and from specialty retailers, but if you’d like to build
your own, the table below details a proper cable conversion:
Conductor 3-Pin female (Output) 5-Pin male (Input)
Ground/Shield Pin 1 Pin 1
DMX Data (-) Pin 2 Pin 2
DMX Data (+) Pin 3 Pin 3
Not used. no connector Pin 4
Not used. no connector Pin 5

9 www.slservice.pl S-LIGHTING S-Aura
Address
Reset
Set DMX Address
All Reset
Set Shuto Time
Power ON
02-60m
Normal / Reverse
Key Lock
Last Run Hrs
ON / OFF
Normal / Reverse
Flip Display
Ttl Life Hrs
ON / OFF
English / Chinese
Disp Flash ON / OFF
Disp. Setting
Pan
Tilt
Language
DMX Mode
Info
Test
Test
EXT
Time Info
All
Pan 0-255
Blue 0-255
Functions 0-255
Zoom 0-255
STD
Software Version
Motor
Tilt 0-255
White 0-255
Red 0-255
Strobe 0-255
LED
Speed 0-255
Colour 0-255
Green 0-255
Dimmer 0-255
4. dISPlay menu

S-LIGHTING S-Aura www.slservice.pl 10
STD EXT Value Function Description
1
0-019
Shutter
Shutter closed
20-024 Shutter open
25-064 Strobe 1 (fast <--> slow)
65-069 Shutter open
70-084 Strobe 2: opening pulse (fast <--> slow)
85-089 Shutter open
90-104 Strobe 3: closing pulse (fast <--> slow)
105-109 Shutter open
110-124 Strobe 4: random strobe (fast <--> slow)
125-129 Shutter open
130-144 Strobe 5: random opening pulse (fast <--> slow)
145-149 Shutter open
150-164 Strobe 6: random closing pulse (fast <--> slow)
165-169 Shutter open
170-184 Strobe 7: burst pulse (fast <--> slow)
185-189 Shutter open
190-204 Strobe 8: random burst pulse (fast <--> slow)
205-209 Shutter open
210-224 Strone 9: sine wave (fast <--> slow)
225-229 Shutter open
230-244 Strobe 10: burst (fast <--> slow)
245-255 Shutter open
2 0-255 Dimmer Intensity (0 <--> 100%)
3 0-255 Zoom Zoom adjustment (wide <--> narrow)
4 0-255 Pan Pan adjustment (0° <--> 540°)
5 0-255 Pan ne Pan ne adjustment
6 0-255 Tilt Tilt adjustment (0° <--> 240°)
7 0-255 Tilt ne Tilt ne adjustment
8
0-009
Function
No function
10-014 Reset entire xture
15-039 No function
40-044 PTSP = NORM2
45-049 PTSP = FAST2
50-054 PTSP = SLOW2
5. dMX functIonS and valueS

11 www.slservice.pl S-LIGHTING S-Aura
STD EXT Value Function Description
8
55-059
Function
No function
60-064 Fan mode FULL2
65-069 No function
70-074 Fan mode REGULATED2
75-089 No function
90-094 Calibrated color output mode COLOR CALIB = ON3
95-099 No function
100-104 RAW color output mode COLOR CALIB = OFF3
105-109 No function
110-114 Fast dimming, speed of changes unrestricted2
115-119 No function
120-124 Smooth dimming, speed of changes restricted slightly2
125-249 No function
250-255 Illuminate display
9
0-009
Macros
Open. RGBW color mixing enabled
10-014 LEE 790 - Moroccan Pink
15-019 LEE 157 - Pink
20-024 LEE 332 - Special Rose Pink
25-029 LEE 328 - Follies Pink
30-034 LEE 345 - Fuchsia Pink
35-039 LEE 194 - Surprise Pink
40-044 LEE 181 - Congo Blue
45-049 LEE 071 - Tokio Blue
50-054 LEE 120 - Deep Blue
55-059 LEE 079 - Just Blue
60-064 LEE 132 - Medium Blue
65-069 LEE 200 - Double CT Blue
70-074 LEE 161 - Slate Blue
75-079 LEE 201 - Full CT Blue
80-084 LEE 202 - Half CT Blue
85-089 LEE 117 - Steel Blue
90-094 LEE 353 - Lighter Blue
95-099 LEE 118 - Light Blue
100-104 LEE 116 - Medium Blue Green
105-109 LEE 124 - Dark Green
110-114 LEE 139 - Primary Green

S-LIGHTING S-Aura www.slservice.pl 12
STD EXT Value Function Description
9
115-119
Macros
LEE 089 - Moss Green
120-124 LEE 122 - Fern Green
125-129 LEE 738 - JAS Green
130-134 LEE 088 - Lime Green
135-139 LEE 100 - Spring Yellow
140-144 LEE 104 - Deep Amber
145-149 LEE 179 - Crome Orange
150-154 LEE 105 - Orange
155-159 LEE 021 - Gold Amber
160-164 LEE 778 - Millennium Gold
165-169 LEE 135 - Deep Golden Amber
170-174 LEE 164 - Flame Red
175-179 Open
Color wheel rotation eect
180-201 Clockwise (fast <--> slow)
202-207
208-229 Counter-clockwise (fast <--> slow)
230-234 Open
235-239 Fast
240-244 Medium
245-249 Slow
250-255 Open
10 0-255 Red Red (0 <--> 100%)
11 0-255 Green Green (0 <--> 100%)
12 0-255 Blue Blue (0 <--> 100%)
13 0-255 White White (0 <--> 100%)
14 0-019 CTC CTC disabled
20-255 CTC (10'000K <--> 2'500K)
* 15 0-255 Pre-program 1 Eect selection (FX1)
* 16 0-255 Speed of FX1 Pre-program 1 (CH15) speed (0 <--> max)
* 17 181-244 Pre-program 2 Eect selection (FX2)
* 18 245-255 Speed of FX2 Pre-program 2 (CH17) speed (0 <--> max)
* 19 0-049 Settings of FX
No sync
• FX1 and FX2 run through cycles independently
• Cycle duration is regular
• CH16 and CH18 adjust FX1 and FX2 independently

13 www.slservice.pl S-LIGHTING S-Aura
STD EXT Value Function Description
* 19
050
Settings of FX
Sync
• FX1 and FX2 run through cycles in sync
• Cycle duration is regular
• CH16 adjusts overall speed, CH18 has no eect
51-169
Sync shift
• FX1 and FX2 run through cycles in sync
• FX2 is oset (delayed) relative to FX1
• Oset is adjustable (0 <--> max)
• CH16 adjusts overall speed, CH18 has no eect
170-209
Sync random
• FX1 and FX2 run through cycles in sync
• Cycle duration for synchronized FX1 and FX2 is
made shorter and longer at random
• CH16 adjusts overall speed, CH18 has no eect
210-255
No sync, random
• FX1 and FX2 run through cycles independently
• Cycle duration for FX1 and FX2 is made shorter
and longer at random
• CH16 and CH18 adjust FX1 and FX2 independently
* 20
0-019
Aura shutter
and strobe
eect
Shutter closed
20-024 Shutter open
25-064 Strobe 1 (fast <--> slow)
65-069 Shutter open
70-084 Strobe 2: opening pulse (fast <--> slow)
85-089 Shutter open
90-104 Strobe 3: closing pulse (fast <--> slow)
105-109 Shutter open
110-124 Strobe 4: random strobe (fast <--> slow)
125-129 Shutter open
130-144 Strobe 5: random opening pulse (fast <--> slow)
145-149 Shutter open
150-164 Strobe 6: random closing pulse (fast <--> slow)
165-169 Shutter open
170-184 Strobe 7: burst pulse (fast <--> slow)
185-189 Shutter open
190-204 Strobe 8: random burst pulse (fast <--> slow)
205-209 Shutter open
210-224 Strobe 9: sine wave (fast <--> slow)
225-229 Shutter open
230-244 Strobe 10: burst (fast <--> slow)
245-255 Shutter open
* 21 0-255 Aura dimmer Aura intensity (0 <--> 100%)

S-LIGHTING S-Aura www.slservice.pl 14
STD EXT Value Function Description
* 22
0-009
Aura macro
Open. RGB color mixing enabled
10-014 LEE 790 - Moroccan Pink
15-019 LEE 157 - Pink
20-024 LEE 332 - Special Rose Pink
25-029 LEE 328 - Follies Pink
30-034 LEE 345 - Fuchsia Pink
35-039 LEE 194 - Surprise Pink
40-044 LEE 181 - Congo Blue
45-049 LEE 071 - Tokyo Blue
50-054 LEE 120 - Deep Blue
55-059 LEE 079 - Just Blue
60-064 LEE 132 - Medium Blue
65-069 LEE 200 - Double CT Blue
70-074 LEE 161 - Slate Blue
75-079 LEE 201 - Full CT Blue
80-084 LEE 202 - Half CT Blue
85-089 LEE 117 - Steel Blue
90-094 LEE 353 - Lighter Blue
95-099 LEE 118 - Light Blue
100-104 LEE 116 - Medium Blue Green
105-109 LEE 124 - Dark Green
110-114 LEE 139 - Primary Green
115-119 LEE 089 - Moss Green
120-124 LEE 122 - Fern Green
125-129 LEE 738 - JAS Green
130-134 LEE 088 - Lime Green
135-139 LEE 100 - Spring Yellow
140-144 LEE 104 - Deep Amber
145-149 LEE 179 - Chrome Orange
150-154 LEE 105 - Orange
155-159 LEE 021 - Gold Amber
160-164 LEE 778 - Millenium Gold
165-169 LEE 135 - Deep Golden Amber
170-174 LEE 164 - Flame Red
175-179 Open
Color wheel rotation eect
180-201 Clockwise (fast <--> slow)

15 www.slservice.pl S-LIGHTING S-Aura
STD EXT Value Function Description
* 22
202-207
Aura macro
Stop (this will stop whatever color is at the time)
208-229 Counter-clockwise (slow <--> fast)
230-234 Open
Random color
235-239 Fast
240-244 Medium
245-249 Slow
250-255 Open
* 23 0-255 Aura red Red aura color intensity (0 <--> 100%)
* 24 0-255 Aura green Green aura color intensity (0 <--> 100%)
* 25 0-255 Aura blue Blue aura color intensity (0 <--> 100%)

S-LIGHTING S-Aura www.slservice.pl 16
Type Value FX Name FX Adjust
Aura Sync
Dimmer sync
0-009 Idle n/a
10-012 Dimmer sync n/a
13-015 Strobe sync n/a
16-018 Dimmer + strobe sync n/a
19-021 Aura color sync n/a
22-024 Aura all sync n/a
25-039 Reserved n/a
Intensity FX
Aura strobe delay
40-042 Aura strobe delay Trigger Delay
43-045 Strobe alternate single Speed
46-048 Strobe alternate dual Speed
49-051 Strobe alternate triple Speed
52-054 3-step strobe Speed
55-060 Reserved n/a
61-063 Intensity random alternate Speed
64-066 Aura ramp, Beam ash Speed
67-069 Beam ramp, Aura ash Speed
70-072 Intensity Aura, Beam ramp Speed
73-075 Intensity Beam, Aura ramp Speed
76-099 Reserved n/a
Color FX
Aura color oset
100-102 Aura color oset Color oset
103-108 Reserved n/a
109-111 Hue shimmer Amount
112-114 Saturation shimmer Amount
115-126 Reserved n/a
127-129 Color strobe n/a
130-132 Color oset strobe Color oset on strobe
133-135 Aura color strobe n/a
136-138 Aura color oset strobe Aura color oset on strobe
139-141 Color spikes Strenght
142-159 Reserved n/a
Zoom FX
Zoom / color oset
160-162 Color zoom ramp in Speed
163-165 Color zoom ramp out Speed
165-168 Color zoom fade in Speed
169-171 Color zoom fade out Speed
172-174 Reserved n/a
175-177 Zoom ramp up Speed
178-180 Zoom ramp down Speed
181-219 Reserved n/a
Reserved 220-255 Reserved n/a
FX: pre-programmed eects
