safety precaution HTP-T32G User manual

H.264 HD VIDEO SERVER
UserManualver.1.0
HTP‐T32G
H.264IPBoxCamera

H.264 IP Camera Manual
2
/
4
Safety Precaution
Make sure to turn off the power before installing HTP-T32G.
Do not install under the direct sunlight or in dusty areas.
Make sure to use the product within the temperature and humidity specified in the specification.
Do not operate the product in presence of vibrations or strong magnetic fields.
Do not put electrically conducting materials in the ventilation hole.
Do not open the top cover of the product. It may cause a failure or electric shock on the
components.
To prevent from overheating, make sure to keep the distance at least 10cm from the ventilation
hole.
Make sure proper voltage (220V/100V) before connecting the power.
We appreciate your purchasing HTP-T32G.
Before installing the product, please read the following with care.
SAFETY PRECAUTION

H.264 IP Camera Manual
3
/
4
Table of Content
Table of Content....................................................................................................................................3
1. Introduction.......................................................................................................................................5
1. About User Manual ....................................................................................................................5
2. Feature ......................................................................................................................................5
3. Product and Accessories ...........................................................................................................6
4. Part Names and Functions ........................................................................................................7
5. System Modes and Connections ...............................................................................................8
2. Installation.......................................................................................................................................11
1. Connecting Network (LAN) ......................................................................................................11
2. Connecting Audio.....................................................................................................................11
3. Connecting Serial Ports ...........................................................................................................11
4. Connecting Sensor and Alarm .................................................................................................11
5. Connecting Power ...................................................................................................................11
6. Check if It Works......................................................................................................................12
3. System Operation ...........................................................................................................................13
1. Remote Video Monitoring ........................................................................................................13
2. Initialization of IP Address........................................................................................................16
4. Remote Configuration .....................................................................................................................17
Using Internet Browser ................................................................................................................17
1. System Configuration ..............................................................................................................18
2. Video Configuration .................................................................................................................21
3 .Audio Configuration .................................................................................................................25
4. Network Configuration .............................................................................................................26
5. Serial Port Configuration..........................................................................................................30
6. Event Configuration .................................................................................................................32
7. Preset Configuration ................................................................................................................36
8. User Configuration...................................................................................................................37
9. Camera Configuration..............................................................................................................40
5. True Manager .................................................................................................................................45
1. True Manager Software ...........................................................................................................45
2. Server Registration and Removal ............................................................................................45
3. Server Connection Management .............................................................................................48
4. Server Status Monitoring..........................................................................................................49
TABLE OF CONTENT

H.264 IP Camera Manual
4
/
4
5. Network and System Diagnostics ............................................................................................50
6. F/W Upgrade ...........................................................................................................................53
7. Remove Configuration and Video Monitoring...........................................................................53
6. Trouble Shooting.............................................................................................................................54
7. Appendix.........................................................................................................................................55
TABLE OF CONTENT

H.264 IP Camera Manual
5
/
4
1. About This Manual
This User Manual provides information on operating and managing the premium network camera, HTP-
T32G. The Manual includes instructions of installation, operation and configuration of HTP-T32G as well as
how to make troubleshooting.
2. Features
HTP-T32G is a network camera with remote live monitoring, audio monitoring and control via an IP
network such as LAN, ADSL/VDSL, and Wireless LAN.
Video
zHighly efficient compression algorithm, H.264 & MJPEG support (Dual Streaming)
zCompression in various resolution: QCIF, CIF, Half-D1, D1
zWide range of transmission rates: 32kbps ~ 8Mbps
zVarious transmission modes: CBR, VBR
zMotion detection
Audio
zMulti-transmission mode: Uni-direction (HTP-T13MG → Client PC or Decoder, Client PC or
Decoder →HTP-T13MG), Bi-direction
Network
zFixed IP & Dynamic IP (DHCP) support
z1:1, 1:N support
zMulticasting
zAutomatic transmit rate control according to network conditions
Serial Data
zRS-485 support
zData pass-through mode : Serial data communication between HTP-T32G and Decoder
Sensor and Alarm
zSupport direct connections of external sensor and alarm devices
zEvent Alarm
INTRODUCTION 1

H.264 IP Camera Manual
6
/
4
User Interface
zDiagnose and upgrade through dedicated program called True Manager
zSystem configuration using Internet Explorer
High Reliability
zReliable embedded system
zSystem recovery by dual watch-dog functions
3. Product and Accessories
HTP-T32G
(Lens is not included)
Quick Manual SW and User Manual CD
INTRODUCTION 1

H.264 IP Camera Manual
7
/
4
4. Part Names and Functions
Rear View
Connector Function
1. Ethernet/802.3af Ethernet port/802.3af LED :
Booting and system check
2. RESET Button Initialization of network setting
3. AUDIO IN Audio input
4. AUDIO OUT Audio output
5. POWER IN DC 12V
6. SENSOR/ALARM Sensor input/ Alarm output
7. RS-485 RS-485 port
8. Composite Composite output
9. SD CARD SD memory card slot
INTRODUCTION 1
⑥⑦
⑧
①
②
③
⑤
④

H.264 IP Camera Manual
8
/
4
5. System Connections
HTP-T32G IP Cameras can be connected in either 1 to 1 connection where one HTP-T32G is connected
one PC client or a decoder system or 1 to many connections where one HTP-T32G can be connected
several PCs and decoder systems.
Topology
Generally, HTP-T32G and PC or a decoder is connected in 1-to-1 mode or 1-to many configuration.
z1:1 Connection .
One HTP-T32G is installed at a site where video images are transmitted. A PC or a decoder is
installed at a central location to receive and view the video images on an analog monitor. Audio
and serial data are transferred
in either direction.
1
INTRODUCTION
HTP-T32G Decoder
Site Remote Center
Monitor
Remote Center
HTP-T32G PC
Site Remote Center

H.264 IP Camera Manual
9
/
4
z1:N Connection .
In this configuration, a site can be monitored from many remote central locations. Although up to
64 PCs or decoders can be connected to on HTP-T32G, in the real network environment, network
bandwidth can limit the maximum connections.
. Functionally, the central monitoring system (CMS) software provided can replace the decoder
Multicast Mode
If the network supports multicasting, a large number of decoders can be used to receive video effectively
from a HTP-T32G using a single streaming of video and audio.
Relay
Video and audio can be retransmitted from a center to another center. The arrangement is useful when
the network bandwidth to the site is limited while there are more than one center want to monitor the site.
INTRODUCTION 1
1
HTP-T32G Decoder
Site Center 1
Decoder
Center 2
HTP-T32G PC or Decoder
PC or Decoder
PC or Decoder
Remote Center
Site
1

H.264 IP Camera Manual
10
/
4
CMS (Central Monitoring System)
CMS is a Window-based remote monitoring program in order to monitor or control video, audio, and
events in real time from several IP cameras or video servers. Please refer to the CMS User Manual for
more in detail.
INTRODUCTION 1
HTP-T32G CMS
Site Remote Center
HTP-T32G Decoder
Site Remote Center
CMS

H.264 IP Camera Manual
11
/
4
1. Connecting Network (LAN)
zConnect a LAN Cable to LAN port of HTP-T13MG.
2. Connecting Audio
Audio is full-duplex. It is possible to set the mode as Tx-only, Rx-only or Tx-Rx.
zConnect audio input and output ports to audio devices accordingly.
zThe Audio signal required is line level, so audio equipment with an amp, mixer or other amplifier
should be used.
3. Connecting Serial Ports
RS-485 of HTP-T32G can be connected to external equipment such as PT receiver etc. PC client can
send PT commands to the external equipment via the serial port.
When a decoder system instead of PC client is connected to HTP-T32G, the serial port and that of the
decoder system works in pass-through mode. That is, data from at one port is delivered to the other port,
vice versa
4. Connecting Sensor and Alarm
Connect sensor and alarm devices to corresponding terminals accordingly.
5. Connecting Power
After confirming the power source, connect power adaptor and connect the 12VDC connector to the
system.
INSTALLATION 2

H.264 IP Camera Manual
12
/
4
6. Check if it Works
Once the power is supplied to the camera, it will start booting. The system will boot up to an operating
mode after approximately 40-60 seconds. The green LED on the Ethernet port will flash indicating the
system is ready.
Software provided on the disc called True Manager allows you to check the IP address and other
network details of the camera. Please refer to the True Manager manual for instructions on how to find
the IP address of the camera and if required changing it.
INSTALLATION 2

H.264 IP Camera Manual
13
/
4
1. Remote Video Monitoring
There are two ways to monitor video when the decoder site and HTP-T32G are connected. In order for a
proper operation, an IP address must be set accordingly. Please refer to True Manager in Chapter 3 or
Remote Setting in Chapter 4 for further details.
Default ID : admin Default Password : 1234
Video Monitoring with Decoder System
Once HTP-T32G’s IP address is set in the remote IP address section of the decoder, the decoder system
will connect to HTP-T32G and start receiving the video images. Normally, a monitor connected to the
decoder will display video images.
Video Monitoring using Internet Explorer
Open Internet Explorer and enter HTP-T32G’s IP address. The system will ask for confirmation to install
Active-X control. Once authorized, the Internet Explorer will start to display video images from HTP-
T32G as shown below.
Default IP Address : http://192.168.10.100
SYSTEM OPERATION 3

H.264 IP Camera Manual
14
/
4
zVideo Selection
HTP-T32G is capable of dual streaming. Video Selection allows you to choose Primary Video
image or Secondary Video image. Video Image is displayed according to the resolution set on
video configuration. When dual streaming is not activated and secondary mode is selected,
video cannot be displayed
zScreen Size
Screen size is initially adjusted according to the compression resolution. If you click x1/2 icon,
the whole screen size will be reduced in half.
SYSTEM OPERATION 3

H.264 IP Camera Manual
15
/
4
zDigital Zoom
You can control the view using Zoom In and Zoom out. The more the camera zooms in, the
smaller the square of control panel is. Position of the image can be changed by moving position
of the square. Max x5 Digital Zoom is available. If you press x1, the screen will return to the
normal size.
zPTZ Control Panel
PTZ Control Panel is used for controlling external PTZ devices when the external PTZ devices
are connected through serial port.
zFocus Near, Focus Far, Auto Focus
Adjust the focus
zSensor Input
HTP-T32G supports one sensor input. Status of the sensor is displayed in real time. When the
sensor connected to HTP-T32G is working, the light turns red.
zAlarm Output
HTP-T32G supports one Alarm output. A number icon indicates status of the alarm device. To
operate the alarm device, press the number icon.
zScreen Capture
Capture pictures and store them as BMP or JPEG files.
zAudio Transfer
Transfer audio from a PC that displays video image currently to HTP-T32G.
3
SYSTEM OPERATION

H.264 IP Camera Manual
16
/
4
2. Initialization of IP Address
If a system IP address is lost, the system can be reset to the system default IP address using the reset
button in the back side of the system.
①While system is in operation, press the reset button for more than 5 seconds.
②The system will reboot automatically
③Once the system reboots, IP address will be set to the system default as below.
•IP mode Fixed IP •IP address 192.168.10.100
•Subnet mask 255.255.255.0 •Gateway 192.168.10.1
•Base port 2222 •HTTP port 80
SYSTEM OPERATION 3

H.264 IP Camera Manual
17
/
4
Using web browser
Remote setting is available by using web browser. Enter IP address of HTP-T32G and then a live view
screen appears as below. Press Setup button located in the upper right area of the monitoring screen to
go to the server setup.
For Remote Setting, user should be authorized higher than manager level.
The configurations are grouped into 8 categories: System, Video, Audio, Network, Serial, Event,
Preset and User. Any configuration changes are not applied until Apply button is pressed. Leaving the
page without pressing Apply button, any changes in the page will be discarded.
REMOTE CONFIGURATION 4
cEnter IP Address
dPress Setup button

H.264 IP Camera Manual
18
/
4
1. System Configuration
REMOTE CONFIGURATION
1. System configuration
4

H.264 IP Camera Manual
19
/
4
General
zSystem ID
Set the System ID. The set System ID is displayed with video image on Web browser. The
System ID is also transferred to remote software, such as CMS, and displayed on it.
zLanguage
Select the language to be used for web-based configuration
Firmware
zFirmware version
Current firmware version
zBoard ID
Network board ID of HTP-T32G recognized by system
Time
zStart Time
Latest system boot date and time
zCurrent Time
Current date & time: Enter a new date and time and press Set Current Time button to update
date & time
zTime Zone
Select time zone of where the system is installed. Depending on the time zone, Daylight Saving
Time will work automatically
According to the selected time zone (not set time at your computer), current time will be
displayed on remote software and recording files.
.
A time zone is a region of the earth that has uniform standard time, usually referred to as
the local time. By convention, time zones compute their local time as an offset from UTC
(Coordinated Universal Time). In casual use, GMT (Greenwich Mean Time) can be
considered equivalent to UTC. Local time is UTC plus the current time zone offset for the
considered location
REMOTE CONFIGURATION
1. System configuration
4

H.264 IP Camera Manual
20
/
4
zAutomatically synchronize with NTP server
Synchronize system time with an NTP server using NTP (network time protocol). Name of the
NTP server should be registered on NTP server Name.
Reboot
zReboot Server
Pressing Reboot Server button will cause the system to reboot. Do not press the Reboot
button unless the server needs a reboot.
Factory Reset
zFactory Reset
Current IP Address of HTP-T32G is changed to default IP Address, 192.168.10.100. System
log and user registrations are also cleared. The other setting value will be remained.
The Network Time Protocol (NTP) is a protocol for synchronizing the clocks of computer
systems over packet-switched, variable-latency data networks. It is designed particularly to
resist the effects of variable latency by using a jitter buffer.
REMOTE CONFIGURATION
1. System configuration
4
