SAGEMCOM MF 5591DN User manual

USER MANUAL
MF 5591DN

2Sagemcom · MF 5591dn
EN
INTRODUCTION
DEAR CUSTOMER
Introduction Brand Variable
With the purchase of this device, you have chosen a
quality Sagemcom product brand. Their device fulfils
the most varied requirements for private use or in
your office and business everyday.
Energy Saving Mode
You use the power and toner saving functions to save
electricity and toner, by switching the device to
power saving mode or printing in toner saving mode.
Use the ECO- button to make toner saving copies
quickly and simply.
Starter Cartridge
For printing purposes, your device utilises the most
up-to-date laser printing technology. A starter car-
tridge is provided with the device. This starter car-
tridge is already installed; however you must remove
the packaging used for transportation before you can
use the device.
Paper Tray
You can insert a supply of paper into the paper tray
of up to 250 sheets. You can insert special paper for-
mats, envelopes, slides, sheets of labels or printed
documents into the manual paper feed.
Document Feed Slot
The device is equipped with an automatic document
feeder. Up to 50 Documents can be feed automati-
cally into the machine to be scanned, faxed or copied.
You can scan single documents or smaller templates
using the flatbed scanner.
Crystal
Your device has the image and text enhancement
function Crystal with which you achieve optimal
printing and copying quality for your documents.
Introduction
Using the business card copy, you can copy both
sides of a small document (for example of a business
card) onto one page
Print Calendar
Your device prints a weekly overview as a calendar
page for you – for the current week, the coming week
or a freely selectable week.
If you want, your device can print Sudoku puzzles in
four different difficulty levels with solution.
Introduction
With the Lightweight Directory Access Protocol
(LDAP), you can call up the address data for a direc-
tory service on a LDAP server and send faxes or
scanned documents to recipients via email. The
address information of the LDAP server is displayed
along with the saved entries of your device (entries
on the LDAP server are identified with a +).
You have many functions available to you for fax
transmission, for example, different resolutions or
the timer function. You can secure your fax reception
with a code. In that case, incoming faxes are not
printed out, but rather are stored in the fax memory.
With the fax polling function, you can retrieve faxes
that lie ready in the dialled device.
Time Stamp
The device prints the date and the exact arrival time
on every incoming fax received. This allows you to
document the exact time at which you have received
a fax transmission. A memory buffer in the device
ensures that the correct date and time of reception
will be maintained even after a power loss.
Introduction
With fax reception onto a USB storage medium, the
device saves incoming faxes onto a connected USB
storage medium. Fax messages are saved as TIFF
files with receipt date and time.
Introduction
The selection menu for USB storage media appears
on the display as soon as you connect a USB storage
medium (USB stick, external hard drive etc.) to the
USB host port on the front of the device. You can
print a list of all saved documents or individual doc-
uments as well as delete files. Save scanned docu-
ments or incoming faxes on to the USB storage
medium.
Companion Center SFX
You can connect the device to a computer and use it
as a printer or scanner. You'll find the software on
the supplied installation CD Companion Center SFX.
In this way, you can scan and edit photos and texts,
send and receive faxes and access the device's web
interfaces, with which you can change many set-
tings.
Networks
A network cable or WLAN adapter enables you to
connect the device to an existing network as a net-
work printer. All computers in the network can then
access the device and scan or print.
optional and original
Scanner
The device supports the scanning of colour docu-
ments as well as faxing, printing and copying and
black and white. If you have connected the device to
a network, you have several options available for
reading documents: You can scan the document and
save in on a computer on the network, send it as an
email attachment, store in on an FTP server or save
it on a computer on the network with SMB.
We hope you enjoy your device and its many func-
tions!
Notice
WLAN IS OPTIONAL
WLAN is optional and functions only with
an original adapter, which you can purchase
through our order service. More informa-
tion: www.sagemcom.com
