Salamander Designs DYNO 102 MED User manual
Must be used in conjunction with Dyno 102 Medium.
Uso conjuntamente con Dyno 102 Medium.
Utilisation en même temps que Dyno 102 Medium.
FRA
ENG
ESP
FRA
Align Bracket by extending and spreading arms to
accommodate mounting pattern on the back of the TV.
Alinee el Soporte por medio de extender y desplegar los brazos para
acomodar el patrón de montaje en la parte trasera del televisor.
Aligner le support en étendant et en ouvrant les bras pour permettre le
modèle de montage sur l’arrière du téléviseur.
1
Note: Remove plastic slide covers from
screw mounting locations.
Nota: Quite las cubiertas deslizantes de plástico
de las ubicaciones para montar los tornillos.
Note: Retirer les protections glissantes en plastique
des emplacements servant au montage des vis.
ENG
ESP
FRA
Attach to TV using mouting screws. Refer to TV manufacturer installation
manual to determine the correct mount screw size.
Fijación a la TV con tornillos de montaje. Para determinar el tamaño correctos
tornillos de montaje, consulte el manual de instalación del fabricante del televisor.
Attache à la TV avec bonne vis de support. Pour déterminer la bonne vis de support,
se reporter au manuel d’installation du fabricant du téléviseur.
2
Note: Adapter Spacers can be utilized in applications where
interferences at back of TV prevent proper fit of Adapter Bracket.
Nota: Se pueden utilizar Espaciadores de Adaptador en aplicaciones en que
interferencias en la parte trasera del televisor impiden el ajuste correcto del
Soporte Adaptador Universal.
Note: Il est possible d’utiliser des entretoises d’adaptateur dans les situations
où quelque chose à l’arrière du téléviseur gêne une bonne adaptation du
support d’adaptateur universel.
Hook and secure onto Dyno 102 Medium mount assembly.
Enganche y asegure sobre Dyno 102 Medium ensamblaje de montaje.
Accrochez et fixez et sur Dyno 102 Medium support.
3
IMPORTANT SAFETY INSTRUCTIONS
Carefully inspect the mount for shipping damage or missing parts. If any damage is
apparent or you are missing parts contact Salamander Designs at 800-535-5659.
Read ALL assembly instructions before assembly. If you have any questions, please
contact your installation contractor or Salamander Designs.
Mounts must be attached as specified in assembly instructions. Improper installation
can result in serious personal injury.
This TV mount is intended for use with Flat-Panel TVs up to 42” with a maximum
weight capacity of 100 lbs.
Use of this mount with products heavier than the maximum weight or larger than
the size indicated may result in collapse of the mount causing possible injury.
The mount is designed to be installed using wall studs or supporting frame. Not for
use on steel stud walls or old cinder block walls. Installation to these type of walls
will require other fasteners than provided.
Use the mounting screws provided and DO NOT OVER TIGHTEN mounting screws.
