RED3 INTEGRATED SERVER - SETUP GUIDE
USB PORTS
Used for keyboard,
mouse, other input
devices, flash
storage, etc.
SYSTEM STATUS
A - Power Indicator
B - Hard Drive Acvity
PORT ACTIVITY INDICATOR
16 or 24 Channels
A B
Front
POWER SUPPLY
120-240VAC
50-60 Hz
LAN PORTS
PoE Power Available = max 30W Each
(Complies with Class 3 PoE)
Global Power Available = max 288W (16
Ch.) 487W (24 Ch.)
WAN PORT/SFP PORT
Used for Dual Networks /
Advanced Network Sengs
VGA
Monitor
Display
HDMI
Monitor
Display
COMBO UPLINK
PORT
Twisted Pair (CAT6
Recommended)
or via SFP Port
eSATA
Connecon for
external drive
USB 3.0 SFP
Port
Rear

RED3 INTEGRATED SERVER - SETUP GUIDE
2 - Prior to Connecng to a Network1- Packing Contents
Power Cord
3 - StartUp Wizard 4 - System Management
RED3 IS
Keyboard and Mouse
Rack Ears
Soware Manual
Power Cord
1. Connect a keyboard, monitor, and
mouse.
2. Connect the power supply to the
RED3 IS.
3. Log in to Windows (case sensive)
Username: Administrator
Password: Completeview!
4. Configure the Salient network,
computer name, and other relave
parameters for network
connecvely.
The default IP address for the RED3
switch is 192.168.1.50, but can be set
through the web interface.
To configure the RED3 integrated
switch, browse to hp://192.168.1.50.
Username: Admin
Password: Completeview!
(case sensive)
Cameras will connect to ports 1 to 16
or 1 to 24 depending on the unit.
Connect U2 to the client/corporate
network. The network address is
configured through the Windows
Control Panel. U1 is used as an
expansion port to the switch to
connect addional devices or switches.
Aer successfully logging into Windows, the CompleteView™ StartUp Wizard will automa-
cally launch. The Wizard will step through the inial configuraon of CompleteView™ server.
Contact Salient support at hp://www.salientsys.com/support/contact-support/, or
1-844-SALIENT (1-844-725-4368) for assistance, if required. The system does come fully
licensed with 16 or 24 channels depending on the unit.
