SAMES KREMLIN 01D140 User manual

DIAPHRAGM PUMPS
01D140 / 01D140E
II 2 G Ex h IIB T6-T4 Gb X
II 2 D Ex h IIIC 85-150°C Db X
Equipment references
01D140: 144907010
01D140E: 144907015
User Manual 582115110
2020-05-26
Index C
SAMES KREMLIN SAS
13 Chemin de Malacher
38240 Meylan
www.sames-kremlin.com
33 (0)4 76 41 60 60

Any communication or reproduction of this document , in any fo rm whatsoever, and any exploit ation or
communications of its contents are prohibited, except with the express written consent of t he m anufacturer.
The descriptions and features contained in this document are subject to change without notice.
co pyright by m anufacturer

Table of contents
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 3
Table of contents
TABLE OF CONTENTS......................................................................................................................................................3
Evolution table of the document........................................................................................................................... 5
Warranty..............................................................................................................................................................6
1SAFETY INSTRUCTIONS .........................................................................................................................................7
1.1 PERSONAL SAFETY..............................................................................................................................................7
Overview..............................................................................................................................................................7
Personnel qualifications........................................................................................................................................7
Meaning of the pictograms...................................................................................................................................8
Security devices....................................................................................................................................................9
Danger of pressure ...............................................................................................................................................9
Injection hazards ................................................................................................................................................10
Fire hazards, explosion, electric arc, static electricity..........................................................................................10
Hazards of toxic products.................................................................................................................................... 11
1.2 INTEGRITY OF THE MATERIALS ........................................................................................................................... 12
Material recommendations................................................................................................................................. 12
Products implemented........................................................................................................................................16
2ENVIRONMENT................................................................................................................................................... 18
Material marking................................................................................................................................................19
3PRESENTATION OF THE EQUIPMENT............................................................................................................... 20
Context of use ....................................................................................................................................................20
Non-intended use...............................................................................................................................................20
Foreseeable misuse ............................................................................................................................................21
4IDENTIFICATION ................................................................................................................................................. 22
4.1 DESCRIPTION OF THE MARKING OF THE PLATE...................................................................................................... 22
Additional ATEX information...............................................................................................................................26
5GENERAL SPECIFICATIONS.................................................................................................................................28
5.1 TECHNICAL C HARACTERISTICS............................................................................................................................ 28
01D140 / 01D140E Pumps...................................................................................................................................28
Wetted parts in contact with the conveyed product............................................................................................28
D i me ns i o ns.........................................................................................................................................................29
5.2 PRINCIPLE OF OPERATION................................................................................................................................. 30
Diaphragm pump................................................................................................................................................30
Functional description........................................................................................................................................ 30
Advantages.........................................................................................................................................................30
6INSTALLATION .................................................................................................................................................... 31
Transport........................................................................................................................................................... 31
Check the scope ofdelivery................................................................................................................................. 32
Environment.......................................................................................................................................................32
Preparation........................................................................................................................................................ 32
Connections .......................................................................................................................................................33
Storage...............................................................................................................................................................35

Table of contents
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
4
7COMMISSIONING............................................................................................................................................... 36
Commissioning instructions ................................................................................................................................38
8OPERATION......................................................................................................................................................... 39
8.1 REGULATING THE DELIVERY RATE ....................................................................................................................... 39
8.2 TROUBLESHOOTING......................................................................................................................................... 40
Rectification of malfunctions...............................................................................................................................40
9MAINTENANCE................................................................................................................................................... 42
Maintenance schedule .......................................................................................................................................44
10 DECOMMISSIONING AND CLEANING............................................................................................................... 45
Damage to the pump due to hardening, crystallising media................................................................................. 46
Cleaning prior to decommissioning ....................................................................................................................47
11 REPLACING PUMP COMPONENTS.................................................................................................................... 48
11.1 REPLACING THE DIAPHRAGM ............................................................................................................................. 48
11.2 REPLACEMENT OF THE PNEUMATIC VALVE........................................................................................................... 49
11.2.1 DI SMANTLING OF THE PNEUMATIC VALVE....................................................................................................... 50
11.2.2 MOUNTI NG THE PNE UM ATIC VALVE.............................................................................................................. 51
11.3 REPLACING THE BALL VALVES AND SUCTION PIPES ................................................................................................ 53
12 SPARE PARTS....................................................................................................................................................... 55
12.1 EXPLODED VIEW.............................................................................................................................................. 55
12.2 PARTS LIST..................................................................................................................................................... 56
12.3 SPARE PARTS KITS ........................................................................................................................................... 58
Diaphragm Kit - 01D140 Pump............................................................................................................................58
Diaphragm Kit - 01D140E Pump ..........................................................................................................................58
Ball valve Kit - 01D140 / 01D140E Pumps ............................................................................................................58
Ball valve sealingjoints +springs Kit - 01D140 / 01D140E Pumps .........................................................................59
Pneumatic valve Kit - 01D140 / 01D140E Pumps..................................................................................................59
Pneumatic valve sealing joints Ki t - 01D140 / 01D140E Pumps.............................................................................60
13 DECLARATION OF CONFORMITY ...................................................................................................................... 61

582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 5
Evolution table of the
document
Revision history
Writer
Object
Revision
Date
Reviewer
E DUMONT
/F SEGUIN
01D140 /
01D140E Pumps
A07/2019 -
E DUMONT
/F SEGUIN
01D140 /
01D140E Pumps
B26/05/2020 -
E DUMONT
/F SEGUIN
Pumps 01D140 /
01D140E
C 13/08/ 2019 -
Dear customer, you have just purchased your new equipment and
we thank you for it.
We have taken the utmost care, from design to manufacture, so that
this equipment gives you complete satisfaction.
For a good use and an optimal availability, we invite you to read this
manual carefully before using your equipment.

26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
6
Warranty
We reserve the right to make any changes or improvements even
after receipt of an order without being able to attribute a non-
compliance to the descriptions contained in the instruction manuals
and selection guides.
Our equipment is checked and tested in our w orkshops before
shipment.
To be valid, any complaint concerning a material will have to be
formulated to us in writing within 10 days of the delivery.
SAMES KREMLIN equipment, equipped with its original identification
plates, has a one-year warranty or 1800H of operation (first term
reached) from the date of ex-factory against any defect of material
or defect of it is up to us to see and appreciate.
The warranty excludes wear parts, deterioration or wear resulting from
abnormal or unscheduled use by SAMES KREMLIN, failure to observe
instructions for proper operation or lack of maintenance.
The warranty is limited to the repair or exchange of parts returned to
our factory and recognized as defective by us and does not cover
the listed wear parts or not.
Any costs resulting from an operating outage can not be charged to
us. The costs of return to our workshops are the responsibility of the
customer.
An intervention can be carried out on site at the customer's request.
In this case, the transportation and accommodation costs of the
technician (s) will remain the responsibility of the applicant.
Any changes made to our equipment without our consent will void
the warranty.
Our guarantee is limited to that of the suppliers of materials which
enter in the composition of our sets.

Safety instructions
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 7
1Safety instructions
1.1 Personal safety
Overview
Read all operating instructions and device labels carefully
before putting the equipment into service.
Personnel using this equipment must have been trained in its use.
The w orkshop manager must ensure that the operators have fully
understood all the instructions and safety rules of this equipment and
other elements and accessories of the installation.
Misuse or operation can cause serious injury. This material is for
professional use only. It must be used only for the purpose for w hich it
w as intended.
Do not modify or transform the material. Parts and accessories must
only be supplied or approved by the manufacturer.
Never operate the pump w hile damaged.
The equipment must be checked periodically. Defective or worn parts
must be replaced.
Nev er exceed the m axim um w orking pressures of the equipment
components.
Always respect the laws in force regarding security, fire, electricity
and explosion protection of the destination country of the equipment.
Only use productsor solvents that are compatible with the parts in
contact with the equipment (see product manufacturer's technical
data sheet).
Personnel qualifications
Tasks on the pump must only be performed in accordance w ith
existing rules and statutory regulations, by personnel w ho have been
instructed and are qualified in this regard, in compliance with due
diligence obligations.
The following requirements must be fulfilled:

Safety instructions
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
8
Personnel must have special skills and experience in the
respective technical area. This particularly applies for
maintenance and repair tasks on mechanical and
pneumatic fixtures of the pump.
Personnel must have know ledge of applicable standards,
directives, accident prevention regulations and operating
conditions.
Personnel must have been authorised by the person
responsible for safety to perform the respectively required
tasks.
Personnel must be capable of recognising and avoiding
possible dangers.
The required personnel qualifications are subject to different statutory
regulations depending on the implementation site. The ow ner must
ensure compliance with the applicable laws.
Meaning of the pictograms
Danger mov ing parts
Danger : high pressure
Risks of product
emanation
Danger : hot parts or
surfaces
Danger : flammability
risks
Danger : electricity
Risk of explosion
Danger (user)
Glasses required
Glov es required
Grounding
Danger pinching,
crushing

Safety instructions
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 9
Security devices
WARNING
Guards (motor cover, coupling guard, housings, ...) are set
up for safe use of the equipment.
The manufacturer can not be held responsible for any bodily
injury as w ell as failures and / or damage to the equipment
resulting from the destruction, the occultation or the total or
partial removal of the protectors.
Nev er exceed the m aximum w orking pressures of the
equipment components.
Stay away from moving parts.
Danger of pressure
Safety requires that a decompressed air shutoff valve be mounted on
the pump motor supply circuit to allow trapped air to escape w hen
the supply is shut off.
Without this precaution, the residual air from the engine may cause
the motor pump to operate and cause a serious accident.
Similarly, a product purge valve must be installed on the equipment
circuit so that it can be purged (after shutting off engine air and
decompressing it) before any intervention on the equipment. These
valves should remain closed for air and open for the product during
the procedure.

Safety instructions
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
10
Injection hazards
"HIGH PRESSURE" technology requires the utmost care.
Operation can cause dangerous leaks. There is a risk of product
injection into exposed parts of the body, which can lead to serious
injury and the risk of amputation :
An injection of product into the skin or other parts of the
body (eyes, fingers ...) must be treated urgently by
appropriate medical care.
Do not look at the gun nozzle when it is under pressure.
Never direct the jet to another person.
Never attempt to stop the jet with the body (hands, fingers
...) or with rags or similar.
Fire hazards, explosion, electric arc,
static electricity
Improper grounding, insufficient ventilation, open flames or sparks can
cause an explosion or fire which could result in serious injury.
To avoid these risks, especially when using pumps, it is imperative:
To connect the equipment, the parts to be treated, the
cans of products and cleaners to the ground,
To ensure good ventilation,
Keep the w ork area clean and free of rags, papers, solvents,
Do not operate electrical switches in the presence of vapors
or during removal,
Immediately stop the application in the presence of arcs,
Store all liquids outside the work areas.
Use products whose flash point is as high as possible to avoid
any risk of formation of flammable gases and vapors
(consult the product safety data sheets).
To equip the drums with a lid to reduce the diffusion of gases
and vapors in the cabin.
It is forbidden to pump explosive materials.
During the assembly and disassembly, during the transport
to/from the place of use and during the repair, there is the
risk involved of generating sparks, e.g. through friction,
impact or grinding processes or through electrostatic
charge. Ensure that during this work intervals these hazards

Safety instructions
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 11
w ill be reliably prevented or that no explosive atmosphere
will exist.
Hazards of toxic products
Toxic products or vapors can cause serious injury through contact with
the body, in the eyes, under the skin, but also by ingestion or
inhalation. It is imperative :
To know the type of product used and the dangers it
represents,
Store the products to be used in appropriate areas,
Contain the product used in the application in a container
designed for that purpose,
Evacuate the products in accordance with the legislation of
the country w here the equipment is used,
To wear protective clothing designed for that purpose,
Wearing goggles, hearing protectors, gloves, shoes,
coveralls and masks for the respiratory tract.
WARNING
The use of halogenated hydrocarbon solvents and
products containing these solvents in the presence of
aluminum or zinc is prohibited.
Failure to follow these instructions exposes the user to the
risk of explosion resulting in serious injury or death.

Safety instructions
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
12
1.2 Integrity of the m aterials
Material recommendations
Protectors are put in place for safe use of the equipment.
Examples :
Engine hood.
Coupling protector.
Carters.
The manufacturer can not be held responsible in case of:
Bodily injury.
As w ell as breakdowns and / or damage to the equipment
resulting from the destruction, modification, the occultation
or the total or partial withdrawal of the protectors.

Safety instructions
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 13
Pump
Recommendations for pumps :
Nev er exceed the m aximum w orking pressures of the
equipment components.
Do not operate the pump with a product that does not
meet the manufacturer's requirements in terms of viscosity,
abrasiveness, etc.
The presence of solid residues in the product used can
seriously damage the pump and especially the diaphragms.
Keep hands clear of moving parts.
The parts constituting this movement must be kept clean.
Before starting up or using the motor pump, carefully read
the DECOMPRESSION PROCEDURE.
Check that the decompression and purge air valves are
working properly.
It is forbidden to operate the pump without its protective
motor cover - risk of crushing
Only use genuine SAMES KREMLIN accessories and spare
parts designed to withstand the pump's operating pressures.
Feeding phase of the pump
Mandatory wearing of PPE (glasses + gloves + safety shoes).
Feeding cycle
The feeding cycle must be carried out at a maximum of :
1 bar / 14.5 psi at the gauge of the air equipment, keeping
the gun open. Manually and progressively increase pressure
with the air regulator.

Safety instructions
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
14
Paint phase pump and pressure gun
Mandatory wearing of PPE during this phase of painting
w here the pump and the gun are under pressure.
Do not look at the gun nozzle when it is under pressure.
Rinse at a maximum of 1 bar / 14.5 psi at the pressure gauge
of the air equipment (variable pressure depending on the
length of the pipes).
Rinsing the pump
Wearing PPE (glasses + gloves + safety shoes).
Do not look at the gun nozzle when it is under pressure.
Rinse at a maximum of 1 bar / 14.5 psi at the pressure gauge
of the air equipment (variable pressure depending on the
length of the pipes).
Defusing the pump
PPE port mandatory.
Risk of hydraulic heating during defusing
Risk of overheating of the hydraulics in case of defusing.
Ma ss ca ble
It is mandatory to connect the pump to earth. The canes
are conductive.

Safety instructions
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 15
Tubing
Recommendations for pipes.
Keep hoses away from traffic areas, moving parts and hot
areas.
Never subject product hoses to temperatures above 60 °C /
140°F or below 0 °C / 32°F.
Do not use hoses to pull or move equipment.
Tighten all connections, hoses and connectors before
commissioning the equipment.
Check hoses regularly, replace them if damaged.
Never exceed the maximum working pressure stated on the
hose (MWP).
For fitting the hoses and gun: PPE is mandatory.
Tighten to block stop (hoses + gun).
Normal stop
To make a normal stop:
Use the air regulator to gradually decompress the pump.

Safety instructions
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
16
Products implemented
Given the diversity of the products implemented by the users and the
impossibility of listing all the characteristics of the chemical
substances, their interactions and their evolution over time SAMES
KREMLIN and the manufacturer can not be held responsible:
The poor compatibility of materials in contact.
Inherent risks to staff and the environment.
Wear and tear, maladjustment, malfunction of equipment or
machines and the quality of the finished product.
In the event of a diaphragm rupture, a large area of the
environment may be contaminated with the pumped
medium.
The pump should only be used in environments that do not alter the
properties of the products used in a negative w ay.
Checking the compatibility of materials is the responsibility of the user.
The user w ill have to identify and prevent the potential dangers
inherent to the implemented products such as :
Toxic vapors.
Fire.
Explosions.
It w ill determine the risks of immediate reactions or due to repeated
exposures to the staff.
SAMES KREMLIN and the manufacturer decline any responsibility, in
case of:
Bodily or psychic injuries.
Direct or indirect material damage due to the use of
chemical substances.
The following points must be observed if the hazard analysis
conducted by the operator reveals that a possible leakage of the
medium poses an increased risk :
The installation of media shut-off valves at the medium inlets
and outlets to shut off the medium flow in case of a leakage
on the pump.
The installation of the pump with shut-o ff v al ve, 3-way valve
and check valve in the compressed air supply line. These 3
components prevent the pumped medium from entering
the compressed air system in the case of a diaphragm
rupture.

Safety instructions
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 17
If the diaphragms are completely defective, the fluid can
enter the compressed air circuit, damage it and exit via the
sound absorber. Depending on the pumped medium, the
sound absorber must be replaced by a suitable pipe or hose
connection to avoid danger. The outlet is to be removed to
a safe place.
If diaphragms are completely defective, the medium to be
pumped can react w ith materials in the compressed air
circuit. The operator must evaluate the risk before taking it
into operation and take appropriate measures.

Env ironment
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
18
2Environment
The equipment must be installed on a horizontal, stable and flat
ground (e.g. concrete slab).
Non-moving equipment must be fixed to the ground by suitable
fasteners (spit, screws, bolts, ...) to ensure their stability during use.
To avoid risks due to static electricity, the equipment and its
components must be grounded.
For pumping equipment (pumps, elevators, chassis, etc.), a
2.5 mm section wire is attached to the equipment. Use this
wire to connect the equipment to the general "earth". In
severe environments (mechanical protection of the ground
wire, vibrations, moving equipment, etc.) where damage to
the grounding function is likely, the user will have to replace
the w ire of 2, 5 mm supplied, by a device more adapted to
its environment (wire of greater section, braid of mass, fixing
by lug with eyelet ...).
Have the earth continuity checked by a qualified
electrician. If earth continuity is not assured, check terminal,
wire and grounding point. Never operate the equipment
without solving this problem.
The gun must be "grounded" through the air hose or fluid
hose. In the case of spraying with a pistol equipped with a
bucket, the air hose must be conductive.
The materials to be painted must also be "grounded" by
means of clamps with cables or, if they are suspended, by
means of hooks which must remain permanently clean.
Note: all objects in the work area must also be
grounded.

Env ironment
582115110-EN-indC-Pump-01D140-01D140E.docx 26/05/2020 19
Do not store more flammable products than necessary
inside the w ork area.
These products must be stored in approved containers and
grounded.
Use only grounded metal buckets for the use of rinse
solvents.
Cartons and papers are to be banned. Indeed they are very
bad conductors, even insulators.
Material marking
Each dev ice is equipped w ith a sign plate with the name of the
manufacturer, the reference of the device, important information
for the use of the device (pressure, pow er, ...) and sometimes
against the pictogram shown below.
The equipment is designed and manufactured with high quality
materials and components that can be recycled and reused.
European Directive 2012/19 / EU applies to all devices marked with
this logo (crossed out bin). Find out about the collection systems
available for electrical and electronic devices.
Comply with the rules in your area and do not dispose of old
appliances with household waste. Proper disposal of this old device
w ill help prevent adverse effects on t he env ironment and hum an
health.

Presentation of the equipment
26/05/2020 582115110-EN-indC-Pump-01D140-01D140E.docx
20
3Presentation of the equipment
Context of use
The pumps and operating instructions are intended for
industrial use only.
The pumps are designed to be installed in a paint booth.
The pump may only be used for the transport of liquid media
(see 6.1 "Technical characteristics").
The pump may only be used within the specified limits (see
6.1 "Technical characteristics").
The fluid to be transported must be compatible with the
materials used in the construction of the pump (see 6.1
"Technical characteristics").
The choice of the fluid to be transported depends on the
co m pany using the pump.
Non-intended use
A use other than the use described in the paragraph, "Intended use"
and in this operating manual, and any use that extends beyond the
specified intended use, shall apply as non-intended use. The
manufacturer shall not be liable damage resulting from non-intended
use. This risk is borne solely by the user / ow ner.
The conveyance of media does not meet the product
specification
Modification of the pump in any form is prohibited
The pump is operated w hile damaged
Operation, maintenance and repair of the system by
unauthorised and/or untrained personne
Pump operation without earthing
Pump operation with parameters and/or operating data
exceeding the specification
Operating the pump at a location with ignition risk due to
source of ignition in the vicinity of the pump
Use or operation of the pump by private users
Pump modification or conversion
Installation on unsuitable grounds or flooring
