SAMES KREMLIN 20F50 User manual

PUMP 20F50 pH
Equipment reference
151772200
User Manual 582156110
2020-11-20
Index C
Translation from the original instructions
SAMES KREMLIN SAS
13 Chemin de Malacher
38240 Meylan
www.sames-kremlin.com
33 (0)4 76 41 60 60

Any communication or reproduction of this document, in any form whatsoever, and any exploitation or
communication of its contents is prohibited, except with the express written consent of SAMES KREMLIN.
The descriptions and features contained in this document are subject to change without notice.
© SAMES KREMLIN 2019

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 3
Contents
Evolution table of the document ................................................................................................................................. 5
Guarantee.................................................................................................................................................................... 6
1DECLARATION OF CONFORMITY ............................................................................................................ 7
2DECLARATION OF INCORPORATION....................................................................................................... 8
3SAFETY INSTRUCTIONS ..........................................................................................................................9
3.1 PERSONAL SAFETY....................................................................................................................................... 9
Overview...................................................................................................................................................................... 9
Meaning of the pictograms........................................................................................................................................ 10
Security devices ......................................................................................................................................................... 11
Pressure hazards........................................................................................................................................................ 11
Injection hazards........................................................................................................................................................ 12
Fire hazards, explosion, electric arc, static electricity................................................................................................ 12
Toxic chemicals hazards............................................................................................................................................. 13
3.2 INTEGRITY OF THE MATERIAL ....................................................................................................................... 14
Material recommendations ....................................................................................................................................... 14
4ENVIRONMENT ................................................................................................................................... 19
5PRESENTATION OF THE MATERIAL....................................................................................................... 21
5.1 COMPLETE SYSTEM ................................................................................................................................... 21
5.1.1 VISUAL GENERIC PRESENTATION................................................................................................................... 21
Context of use............................................................................................................................................................ 22
5.2 DESCRIPTION OF THE MAIN ELEMENTS OF THE SYSTEM ..................................................................................... 23
Pump, model 20F50 pH ............................................................................................................................................. 23
Motor, model 500-4 Stroke 100 ................................................................................................................................ 24
Fluid section, model F50 pH....................................................................................................................................... 26
Air supply assembly ................................................................................................................................................... 27
Fluid filter 3/8", model 250 bar / 3625.75 psi............................................................................................................ 28
6IDENTIFICATION .................................................................................................................................. 29
6.1 DESCRIPTION OF THE LABEL MARKING ........................................................................................................... 29
7EQUIPMENT PLANS ............................................................................................................................. 31
Pump, model 20F50 pH (bare pump and wall mounted pump) ................................................................................ 31
8TECHNICAL FEATURES AND OPERATING PRINCIPLES ............................................................................ 33
8.1 TECHNICAL FEATURES ................................................................................................................................ 33
8.2 OPERATING PRINCIPLE ............................................................................................................................... 37
9INSTALLATION..................................................................................................................................... 40
Connections subsets .................................................................................................................................................. 40
Connection to compressed air supply........................................................................................................................ 41
9.1 STORAGE ................................................................................................................................................ 42
9.2 HANDLING .............................................................................................................................................. 42
10 START UP ............................................................................................................................................ 43
11 USE OF THE EQUIPMENT ..................................................................................................................... 44
11.1 USER SETTINGS......................................................................................................................................... 44

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
4
11.2 SAFETY IN PRODUCTION ............................................................................................................................. 44
11.3 DIAGNOSTIC HELP /TROUBLESHOOTING GUIDE .............................................................................................. 45
11.4 POSSIBLE SYMPTOMS OF FAULTS /CAUSES OF FAULTS /REMEDY TO BE APPLIED -FAST OPERATION .......................... 47
12 MAINTENANCE.................................................................................................................................... 50
12.1 PREVENTIVE MAINTENANCE PLAN ............................................................................................................... 50
Pump.......................................................................................................................................................................... 50
Motor......................................................................................................................................................................... 51
Fluid section............................................................................................................................................................... 52
Spray gun ................................................................................................................................................................... 52
Filter........................................................................................................................................................................... 52
12.2 PREVENTIVE MAINTENANCE ........................................................................................................................ 53
13 DISASSEMBLY / RE-ASSEMBLY ............................................................................................................. 54
13.1 DISASSEMBLY OF THE GROUNDING CABLE ...................................................................................................... 54
Preliminary operations .............................................................................................................................................. 55
13.2 DECOUPLING /COUPLING OF MOTOR AND FLUID SECTION ................................................................................ 56
13.3 CHANGING THE BELLOWS ........................................................................................................................... 74
13.4 DISMANTLING /REASSEMBLING THE SUCTION VALVE ....................................................................................... 95
13.5 DISASSEMBLY /REASSEMBLY OF THE EXHAUST VALVE .................................................................................... 103
13.6 DISASSEMBLY /REASSEMBLY OF THE EXHAUST FLANGE................................................................................... 113
13.7 DISASSEMBLY /REASSEMBLY OF THE MOTOR ............................................................................................... 127
13.8 DISASSEMBLY /REASSEMBLY OF AIR SUPPLY ASSEMBLY .................................................................................. 149
14 SPARE PARTS..................................................................................................................................... 152
14.1 WALL MOUNTED PUMP,MODEL 20F50 PH................................................................................................. 152
14.2 MOTOR,MODEL 500-4 STROKE 100 ......................................................................................................... 156
14.3 REVERSING-BLOCK .................................................................................................................................. 159
14.4 FLUID SECTION,MODEL F50 PH ................................................................................................................ 162
Servicing kit # 144 951 095 ...................................................................................................................................... 167
Package of seals # 144 951 090 ............................................................................................................................... 168
14.5 AIR SUPPLY ASSEMBLY ............................................................................................................................. 170
14.6 AIR REGULATOR 1/4".............................................................................................................................. 172
14.7 FLUID FILTER 3/8 ", MODEL 250 BAR /3625.75 PSI .................................................................................... 176

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 5
Evolution table of the
document
Recording revisions
Editor
Object
Revision
Date
Modified by
C. HUSSON Pump,
model 20F50 pH
A - Week 32/2020 B. KHALDI
C. HUSSON –
F. SEGUIN
Disassembly /
reassembly added
B - Week 42/2020 -
C. HUSSON Update C - Week 47/2020 C. HUSSON
Dear customer, you have just purchased your new equipment and
we thank you for it.
We have taken the utmost care, from design to manufacture, so that
this equipment gives you complete satisfaction.
For good use and optimal availability, we invite you to read this
manual carefully before using your equipment.

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
6
Guarantee
We reserve the right to make any changes or improvements even
after receipt of an order without being able to attribute a non-
compliance to the descriptions contained in the instruction manuals
and selection guides.
Our equipment is checked and tested in our workshops before
shipment.
To be valid, any complaint concerning a material will have to be
formulated to us in writing within 10 days of the delivery.
SAMES KREMLIN equipment, equipped with its original identification
plates, has a one-year warranty or 1800 hours of operation (first term
reached) from the date of ex-factory against any defect in material
or workmanship which we reserve the right to acknowledge.
The warranty excludes wear parts, deterioration or wear resulting from
abnormal or unscheduled use by SAMES KREMLIN, failure to observe
instructions for proper operation or lack of maintenance.
The warranty is limited to the repair or exchange of parts returned to
our factory and recognized as defective by us and does not cover
the listed wear parts.
Any costs resulting from an operating outage can not be charged to
us. The costs of return to our workshops are the responsibility of the
customer.
An intervention can be carried out on site at the customer’s request.
In this case, the transportation and accommodation costs of the
technician (s) will remain the responsibility of the applicant.
Any changes made to our equipment without our consent will void
the warranty.
Our guarantee is non-transferable, and is limited to the original
purchaser.

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 7
1Declaration of Conformity
Refer to the existing declaration delivered with the product.

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
8
2Declaration of incorporation
The manufacturer : SAMES KREMLIN with assets of 12 720 000 Euros
Head office : 13, chemin de Malacher
- 38 240 - MEYLAN - FRANCE
Tel. [phone]
Herewith declares that the pump, model 20F50 pH, part number :
-151 772 200,
was carried out by complying with the essential rules of safety and
health.
This declaration is present in the pump, model 20F50 pH package.

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 9
3Safety instructions
3.1 Personal safety
Overview
Read all operating instructions and device labels carefully
before putting the equipment into service.
Personnel using this equipment must have been trained in its use.
The workshop manager must ensure that the operators have fully
understood all the instructions and safety rules of this equipment and
other elements and accessories of the installation.
Misuse or operation can cause serious injury. This equipment is for
professional use only. It must be used only for the purpose for which it
was intended.
Do not modify or transform the equipment. Parts and accessories must
only be supplied or approved by SAMES KREMLIN.
The equipment must be checked periodically. Defective or worn parts
must be replaced.
Never exceed the maximum working pressures of the equipment
components.
Always respect the laws in force regarding security, fire, electricity of
the destination country of the equipment.
Only use fluids or solvents that are compatible with the parts in
contact with the material (see material manufacturer’s technical
data sheet).

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
10
Meaning of the pictograms
Danger, general signal
(user)
Danger: high pressure
Explosive materials Danger: Electricity
Toxic substances Corrosive materials
Harmful or irritating
materials
Danger of pinching,
crushing
Risk of product
emanation
Danger: hot parts or
surfaces
Danger of automatic
start, moving parts
Danger: flammability
hazard
General obligation
Grounding
Refer to the
manual/instruction
leaflet
Gloves must be worn
Protective helmet Hearing protection
Mandatory respiratory
protection
Safety footwear
Protective clothing
Protective visor
Wearing of glasses is
mandatory
Material recycling

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 11
Security devices
Attention
Guards (motor cover, coupling guard, housings, …)
are set up for safe use of the equipment.
The manufacturer cannot be held responsible for any
bodily injury as well as failures and / or damage to the
equipment resulting from the destruction, hiding or
total or partial removal of the guards.
Never exceed the maximum working pressures of the
equipment components.
Pressure hazards
Safety requires that a pressure relief air shut-off valve must be installed
in the pump motor supply system to allow trapped air to escape
when the supply is shut off.
Without this precaution, residual air from the motor may cause the
motor pump to operate and cause a serious accident.
Also, a fluid drain valve must be installed in the fluid system so that the
fluid can be drained (after shutting off motor air and decompressing
it) before any intervention on the equipment. These valves must
remain closed for air and open for the product during the
intervention.

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
12
Injection hazards
‘HIGH PRESSURE’ technology requires the utmost care.
Its operation can lead to dangerous leaks. In this case, there is a risk of
injecting material into exposed body parts, which can lead to serious
injury and amputation:
An injection of fluid into the skin or other parts of the
body (eyes, fingers …) must be treated urgently by
appropriate medical care.
Do not look at the gun nozzle when it is under pressure.
Never direct the jet to another person.
Never try to stop the jet with the body (hands, fingers,
…) or with rags or similar.
Fire hazards, explosion,
electric arc, static
electricity
Incorrect grounding, insufficient ventilation, flames or sparks can
cause an explosion or fire that could result in serious injury.
In order to avoid these risks, especially when using pumps, it is
imperative:
to ground the equipment, the parts to be treated, the
cans of products and cleaners,
to ensure good ventilation,
to keep the working area clean and free of rags,
apers, solvents,
do not operate electrical switches in the presence of
vapors or during removal,
to immediately stop the application in the presence of
arcs,
to store all liquids outside of the working areas.
to use material with the highest possible flash point to
avoid any risk of formation of flammable gases and
vapors (refer to product safety data sheets).
to equip the drums with a lid to reduce the diffusion of
gases and vapors in the cabin.
it is forbidden to pump explosive materials.

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 13
Toxic chemicals hazards
Toxic materials or vapors can cause serious injury through contact
with the body, in the eyes, under the skin, but also by ingestion or
inhalation. It is imperative :
to know the type of material used and the dangers it
represents,
to store the materials to be used in appropriate areas,
to contain the material used during the application in
a container designed for this purpose,
to dispose the materials in accordance with the
legislation of the country where the equipment is used,
to wear clothing and protection designed for this
purpose,
to wear goggles, hearing, gloves, shoes, coveralls and
respiratory masks.
Attention
The use of halogenated hydrocarbon solvents and
products containing these solvents in the presence of
aluminum or zinc is prohibited.
Failure to follow these instructions could result in an
explosion hazard causing serious injury or death.

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
14
3.2 Integrity of the material
Material recommendations
Guards are fitted for safe use of the equipment.
Examples :
Motor hood,
Housings.
The manufacturer cannot be held responsible in case of:
bodily injury,
as well as breakdowns and / or damage to equipment
resulting from the destruction, hiding or total or partial
removal of guards.

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 15
Pump
Recommendations for pumps.
It is imperative to read the compatibilities of motors
and pumps before coupling them together as well as
the special safety instructions.
These instructions are on the pump instruction
manuals.
The pneumatic motor is intended to be coupled to a
fluid section. Never modify the coupling system.
Keep hands away from moving parts.
The parts constituting that movement must be kept
clean.
Before starting up or using the pump unit, read the
PRESSURE RELIEF PROCEDURE carefully.
Check that the pressure relief and drain air valves are
working properly.
It is forbidden to operate the pump without its
protective motor cover - risk of crushing.
It is forbidden to remove the safety valve when the
pump is in operation - check the correct functioning of
the air regulator and the pressure gauge once a
month.
Use only genuine SAMES KREMLIN accessories and
spare parts designed to withstand the operating
pressure of the pump.
Pump feeding phase
It is compulsory to wear PPE (goggles + gloves + safety
shoes).
Force-feeding cycle
The force-feeding cycle must be carried out at a
maximum of 1 bar / 14.5 psi on the pressure gauge of
the air equipment, keeping the gun open. Progressive
manual ascent to the air regulator.

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
16
Pump paint phase and pressure gun
PPE must be worn during this phase of painting when
the pump and the gun are under pressure.
Do not look at the gun nozzle when the gun is under
pressure.
The maximum pressures engraved on the equipments
must be strictly adhered to.
Flushing the pump
Wearing PPE (goggles + gloves + safety shoes).
Do not look at the gun nozzle when the gun is under
pressure.
Flush at a maximum of 1 bar / 14.5 psi on the air
equipment manometer (pressure varies according to
the length of the hoses).
Pump defusing
Wearing of PPE is mandatory.
Risk of fluid section heating during defusing
Risk of overheating of the fluid section in case of
defusing.
Ground cable
It is mandatory to ground the pump. The rods are
conductive.

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 17
Hoses
Recommendations for hoses.
Keep hoses away from traffic areas, moving parts and
hot areas.
Never subject hoses to temperatures above 60 ° C /
140° F or below 0 ° C / 32° F.
Do not use hoses to pull or move equipment.
Tighten all connections as well as the hoses and
junction fittings before commissioning the equipment.
Check hoses regularly and replace them if damaged.
Never exceed the maximum working pressure stated on
the hose (MWP).
For the assembly of the hoses and the gun: the wearing
of PPE is mandatory.
Tighten to the stop (Hoses + Gun).
Normal stop
To make a normal stop:
Use the air regulator to gradually depressurize the
pump.
Emergency shut-off valve
The stop valve is an emergency stop valve.
This valve must be within easy reach of the operator.

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
18
Materials used
Given the diversity of the materials implemented by the users and the
impossibility of listing all the characteristics of the chemical
substances, their interactions and their evolution over time SAMES
KREMLIN cannot be held responsible:
poor compatibility of materials in contact,
Inherent risks to personnel and the environment,
Wear and tear, malfunctions, material or equipment
malfunctions, as well as the quality of the finished.
The user shall identify and prevent from potential dangers inherent to
the materials used, such as:
Toxic vapors.
Fire.
Explosions.
It will determine the risks of immediate reactions or reactions due to
repeated exposures to personnel.
SAMES KREMLIN declines any responsibility, in case of:
Physical or mental injury,
Direct or indirect material damage due to the use of
chemical substances.

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020 19
4Environment
The equipment is installed on a horizontal, stable and flat floor (e.g.
concrete slab).
Non-movable equipment must be fixed to the ground by suitable
mounting devices (spit, screws, bolts, etc.) to ensure its stability during
use.
To avoid risks due to static electricity, the equipment and its
components must be grounded.
For pumping equipment (pumps, lifts, chassis, etc.), a 2.5
mm section wire is attached to the equipment. Use this
wire to connect the equipment to the general
“ground”. In the case of severe environments
(insufficient mechanical protection of the earthing wire,
vibrations, moving equipment, etc.) where damage to
the earthing function is likely, the user must replace the
2, 5 mm wire supplied, by a device more suited to its
environment (larger wire section, earth braid, fixing by
eye lug,…).
Have the ground continuity checked by a qualified
electrician. If ground continuity is not assured, check
terminal, wire and grounding point. Never operate the
equipment without first resolving this problem.
The gun must be "grounded" through the air hose or
fluid hose. When spraying from a gun, the fluid hose
must be conductive.
The equipments to be painted must also be “grounded”
by means of clamps fitted with cables or, if suspended,
by means of hooks which must be kept clean
permanently.
Note: all objects in the work area must also be
grounded.
Do not store more flammable materials than necessary
inside the work area.
These materials must be stored in approved, grounded
containers.
Use only grounded metal pails for flushing solvents.
Cardboard and papers are to be banned. They are very
bad conductors, even insulators.

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
20
Material markings
Each appliance is fitted with a nameplate bearing the name of
the manufacturer, the appliance reference number, important
information for the use of the appliance (pressure, power, etc.)
and sometimes the pictogram shown opposite.
The equipment is designed and manufactured with high quality
materials and components that can be recycled and reused.
The 2012/19/EU European Directive applies to all devices marked
with this logo (crossed-out waste bin). Find out more about the
collection systems available for electrical and electronic
appliances.
Follow the rules in your locality and do not dispose of your old
appliances with your household waste. Proper disposal of this old
appliance will help prevent negative effects on the environment
and human health.
