Samsung AC NX S C Series User manual

Air conditioner
Installation manual
AC∗∗∗NX∗S∗C
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this manual carefully and retain it for future reference.
DB68-07420A-01

AA
2
English
Safety precautions
Contents
General information

Carefully read the content of this manual before installing the air conditioner and store the manual
in a safe place in order to be able to use it as reference afterinstallation.
Formaximum safety, installers should always carefully read the following warnings.
Store the operation and installation manual in a safe location and remember to hand it over to the
new owner if the air conditioner is sold or transferred.
This manual explains how to install an indoorunit with a split system with two SAMSUNG units.
The use of other types of units with different control systems may damage the units and invalidate
the warranty. The manufacturershall not be responsible for damages arising from the use of non
compliant units.
The manufacturer shall not be responsible for damage originating from unauthorized changes
or the improper connection of electric and requirements set forth in the “Operating limits” table,
included in the manual, shall immediately invalidate the warranty.
The air conditionershould be used only for the applications forwhich it has been designed: the
indoor unit is not suitable to be installed in areas used for laundry.
Do not use the units if damaged. If problems occur, switch the unit off and disconnect it from the
power supply.
 
switch and contact SAMSUNG’s technical support if the unit produces smoke, if the power cable is
hot or damaged or if the unit is very noisy.
Always remember to inspect the unit, electric connections, refrigerant tubes and protections

The unit contains moving parts, which should always be kept out of the reach of children.
Carefully follow the precautions listed below because they are essential to guarantee the safety
of the equipment.

servicing it or accessing its internal components.

personnel.

WARNING
Safety precautions ................................................................................................................................................................... 2
Preparation for outdoor unit installation ........................................................................................................................... 4
Deciding on where to install the outdoor unit ................................................................................................................ 6
Outdoor unit installation .................................................................................................................................................... 10
Connecting the cable ........................................................................................................................................................... 12
Extending the power cable ................................................................................................................................................. 18
Connecting the refrigerant pipe ....................................................................................................................................... 20
Connecting up and removing air in the circuit .............................................................................................................. 21
Cutting/Flaring the pipes .................................................................................................................................................... 22
Performing leak tests ......................................................................................................................................................... 23
Insulation ............................................................................................................................................................................... 24
Using stop valve ................................................................................................................................................................... 25
Adding refrigerant ............................................................................................................................................................... 26
Pump down Procedure ........................................................................................................................................................ 27
Checking correct grounding ............................................................................................................................................. 28
Testing Operations................................................................................................................................................................ 29
Troubleshooting ................................................................................................................................................................... 31

3
English
ENGLISH
Do not attempt to repair, move, alter or reinstall the unit. If performed by unauthorized personnel,

 
Do not disassemble and alter the heaterat yourown discretion.
All the materials used for the manufacture and packaging of the air conditioner are recyclable.
The packing material and exhaust batteries of the remote controller(optional) must be disposed of
in accordance with current laws.
The air conditionercontains a refrigerant that has to be disposed of as special waste. At the end of
its life cycle, the air conditionermust be disposed of in authorized centers orreturned to the retailer
so that it can be disposed of correctly and safely.
This appliance is not intended for use by persons(including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
upervision or instruction concerning use of the appliance by a person responsible for their safety ;
Young children should be supervised to ensure that they do not play with the appliance.
Installing the unit

the electrical lines.
Always disassemble the electric lines before the refrigerant tubes.

Upon receipt, inspect the product to verify that it has not been damaged during transport. If the
product appears damaged, DO NOT INSTALL it and immediately report the damage to the carrier
or retailer (if the installeror the authorized technician has collected the material from the retailer.)

After completing the installation, always carry out a functional test and provide the instructions
on how to operate the air conditioner to the user.

Do not use the air conditionerin environments with hazardous substances orclose to equipment


Our units should be installed in compliance with the spaces shown in the installation manual, to
ensure accessibility from both sides and allow repairs or maintenance operations to be carried
out. The unit’s components should be accessible and easy to disassemble without endangering

For this reason, when provisions of the installation manual are not complied with, the cost
required to access and repair the units (in SAFETY CONDITIONS, as set out in prevailing
regulations) with harnesses, ladders, scaffolding or any other elevation system will NOT be
considered part of the warranty and will be charged to the end customer.
Power supply line, fuse or circuit breaker

Always make sure that the power supply is compliant with current safety standards. Always install
the air conditioner in compliance with current local safety standards.

Always verify that a suitable grounding connection is available.
 

connected to the same electric lines.
Always verify that the cut-off and protection switches are suitably dimensioned.
 
provided in the wiring diagram included in the manual.
Always verify that electric connections (cable entry, section of leads, protections…) are compliant

that all connections comply with the standards applicable to the installation of air conditioners.
Devices disconnected from the power supply should be completely disconnected in the condition
of overvoltage category.


- When extension wiring is required due to power line damage, refer to "Extending the power
cable" in the installation manual.

AA
4
English
Preparation for outdoor unit installation
The air conditioner uses R-410A refrigerant.
(Unit : mm)
B Type: AC071NX∗SEC
310
793
364
660
12
18
880 53
310
793
364
660
12
18
880 53
A Type: AC052NX∗SEC
364
310
638
880 54
660
12
23
320
967
364
645
12
26
880 60
C Type: AC090NX∗SEC

5
English
ENGLISH
Plate protection
cloth
Wire rope
Moving the Outdoor Unit byWire Rope
Fasten the outdoor unit by two 8m or longerwire ropes as shown at

between the outdoor unit and rope, then move the unit.
 The appearance of the unit may be
different from the picture depending
on the model.
D Type: AC100NX∗SGC / AC120NX∗SGC / AC140NX∗SGC / AC160NXMSGC
375
1162
932 78
427
690
12
26

AA
6
English
Deciding on where to install the outdoorunit
Outdoor Unit
Fuse
Outdoor
Unit
Stereo
1.5m or more
Indoor Unit Control
Air Guide Duct
(This product is not
provided by
Samsung)
1m or more
1m or more
1.5m or more
1.5m or more
1.5m or more
Fuse
200mm
300mm
The outdoor unit must not be placed on its side or upside down, as the compressor lubrication oil will run into
the cooling circuit and seriously damage the unit.
Choose a location that is dry and sunny, but not exposed to direct sunlight or strong winds.
Do not block any passageways or thoroughfares.
Choose a location where the noise of the air conditionerwhen running and the discharged air do not disturb
any neighbours.
Choose a position that enables the pipes and cables to be easily connected to the indoor unit.

unnecessary noise and vibration.



Make sure that the water dripping from the drain hose runs away correctly and safely.
When you install the outdoorunit at wayside, you should install it above 2m height or make sure that the heat
from the outdoor unit shouldn't be in direct contact with passersby. (The ground for application :The revision of
regulation for facility in building by the law of the Ministry of Construction and Transportation.
CAUTION

specialist.




corrosion may occur in outdoor unit and cause product malfunction.

7
English
ENGLISH
When installing the outdoor unit near seashore, make sure it is not directly exposed to sea breeze. If you can not
nd a adequate place without direct see breeze, protection wall should be constructed.
Install the outdoor unit in a place (such as near buildings etc.) where it can be prevented from sea breeze
which can damage the outdoor unit.
If you cannot avoid installing the outdoor unit by the seashore, construct a protection wall around to block
the sea breeze.
• Protection wall should be constructed with a solid mate-
rial such as concrete to block the sea breeze and the height
and the width of the wall should be 1.5 times larger than the
size of the outdoor unit. Also, secure over 700mm between
the protection wall and the outdoor unit for exhausted air to
ventilate.
Install the outdoor unit in a place where water can drain smoothly.
 If you cannot nd a place satisfying above conditions, please contact manufacturer. Make sure to clean the
sea water and the dust on the outdoor unit heat exchanger and spread corrosion inhibitor on heat exchanger. (At
least one time per one year.)
Check the condition of the product periodically.
˗ Check the installation site every 3 months and perform anti-corrosion treatment such as R-Pro supplied by
SAMSUNG (Code : MOK-220SA) or commercial water repellent grease and wax, etc., based on the product
condition.
˗ When the product is to be shut down for a long period of time, such as off-peak hours, take appropriate mea-
sures like covering the product.
 If the product installed within 500m of seashore, special anti-corrosion treatment is required.
 Please contact your local SAMSUNG representative for further details.
Outdoor unit
Sea breeze
Sea
Outdoor unit
Sea breeze
Sea
Outdoor unit
Sea breeze
Sea
Protection wall
WARNING
• Should adopt bar type louver. Don’t use a type of rain resistance louver.
• Louver specifications.
– Angle criteria : less than 20˚
– Opening ratio criteria : greater than 80%
[Bar type louver] [Rain resistance louver]

AA
8
English
Space Requirements for Outdoor Unit
When installing 1 outdoorunit
(Unit : mm)
300 or more
1500 or more
 When the air outlet is opposite the wall  When the air outlet is towards the wall
300 or more
300 or more 600 or more
1500 or more
2000 or more
 When 3 sides of the outdoor unit are blocked
by the wall
 The upper part of the outdoor unit and the air
outlet is towards the wall
600 or more
300 or more
300 or more1500 or more
 The upper part of the outdoor unit and the air
outlet is opposite the wall
 When front and rear side of the outdoor unit is
towards the wall
Deciding on where to install the outdoorunit

9
English
ENGLISH
When installing more than1 outdoor unit
(Unit : mm)
1500 or more
 When the air outlet is towards the wall
300 or more
300 or more 600 or more 600 or more 600 or more
 When 3 sides of the outdoor unit are blocked by the wall
300 or more1500 or more
600 or more 600 or more
500 or more
500 or more
300 or more
300 or more
 When front and rear side of the outdoor unit is towards the wall  The upper part of the outdoor unit
and the air outlet is towards the
wall
1500 or more 600 or more 3000 or more 300 or more3000 or more
 When 3 sides of the outdoor unit are blocked by the wall
CAUTION
The units must be installed according to distances declared, in order to permit accessibility from
each side, either to guarantee correct operation of maintenance or repairing products. The unit’s
parts must be reachable and removable completely under safety condition (forpeople or things).

AA
10
English
Outdoor unit installation
The outdoorunit must be installed on a rigid and stable base to avoid any increase in the noise level and
vibration, particularly if the outdoor unit is to be installed in a location exposed to strong winds orat a height, the
unit must be xed to an appropriate support(wall or ground).
Fix the outdoor unit with anchor bolts.
(Unit : mm)
Anchor bolt hole
B Type
660
880
310 340
364
690
932
375 403
427
Anchor bolt hole
D Type
Anchor bolt hole
A Type
660
880
310 340
364
645
880
320 340
364
Anchor bolt hole
C Type
CAUTION


the unit.
NOTE
 

11
English
ENGLISH
Outdoor Unit Support
20mm
Anchor bolt
Outdoor
Unit
Base Surface
Outdoor Unit
Support
OUTDOOR UNIT INSTALLED ON THE WALL BY RACK
- Ensure the wall will be able to suspend the weight of rack and outdoor unit ;
- Install the rack close to the column as much as possible ;
- Install proper grommet in orderto reduce noise and residual vibration
transferred by outdoor unit towards wall.
Designed to cut off
residual vibration
from outdoorunit
to rack. (not sup-
plied with product)
Soft rubber designed to
cut off vibration from rack
to wall. (not supplied with
product)
CAUTION
When installing air guide duct



AA
12
English
Connecting the cable
Two electronic cables must be connected to the outdoor unit.
The connection cord between indoor unit and outdoor unit.
The power cable between outdoor unit and auxiliary circuit breaker.
Specially for Russian and European market, before installation, the supply authority should be consulted to
determine the supply system impendance to ensure compliance.
Example of Air Conditioner System
If an outdoor unit is installed in a place in danger of an electric leak or submergence, you must install
the ELCB or MCCB+ELB
Indoor Unit
Power cable
Outdoor Unit Communication cable
Grounding
OR
Power cable
Communication cable
When using ELCB for1 phase
Grounding
Indoor Unit
Power cable
Outdoor Unit Communication cable
Grounding
Power cable
Communication cable
When using ELCB for3 phase 4 wires
OR
Grounding
CAUTION





13
English
ENGLISH
Specication for circuit breaker and power supply cord
Model OutdoorUnits Maximum Input Current [A] PowerSupply
Outdoor Unit Indoor Unit Rated Voltage Range Outdoor Indoor Total MCA MFA
Hz Phase Volts Min. Max. Cooling Heating
AC052NX4SEC AC052NN4SEC 50  220-240 198 264 14.2 -1.0 15.2 15.2 17.8
AC071NX4SEC AC071NN4SEC 50  220-240 198 264 1 7. 3 -1.0 18.3 18.3 21.6
AC090NX4SEC AC090NN4SEC 50  220-240 198 264 20.1 -1.0 21.1 21.1 25.1
AC100NX4SGC AC100NN4SEC 50  380-415 342 457 9.8 -1.0 10.8 10.8 12.3
AC120NX4SGC AC120NN4SEC 50  380-415 342 457 10.7 -1.0 11.7 11.7 13.4
AC140NX4SGC AC140NN4SEC 50  380-415 342 457 13.6 -1.0 14.6 14.6 1 7.0
AC052NXMSEC AC052NNMSEC 50  220-240 198 264 14.0 -3.0 1 7.0 1 7.0 18.7
AC071NXMSEC AC071NNMSEC 50  220-240 198 264 1 7. 6 -3.0 20.6 20.6 22.7
AC090NXMSEC AC090NNMSEC 50  220-240 198 264 21.6 -3.0 24.6 24.6 27.1
AC100NXMSGC AC100NNMSEC 50  380-415 342 457 10.0 -3.0 13.0 13.0 14.3
AC120NXMSGC AC120NNMSEC 50  380-415 342 457 11.4 -3.5 14.9 14.9 16.4
AC140NXMSGC AC140NNMSEC 50  380-415 342 457 14.0 -3.5 1 7. 5 1 7. 5 19.3
AC160NXMSGC AC160NNMSEC 50  380-415 342 457 16.4 -3.5 19.9 19.9 21.9
Powersupply cord is not supplied with airconditioner.
- Select the powersupply cord in accordance with relevant local and national regulations.
- Wire size must comply with the applicable local and national code.
 
NOTE
 
- Units are suitable for use on electrical systems where voltage supplied to unit terminal is not below orabove listed
range limits
2. Maximum allowable voltage variation between phases is 2%.
3. Wire size & type must complywith the applicable local and national code.
- Wire size : Based on the value of MCA.
- Wire type : 60245 IEC57(IEC) orH05RN-F(CENELEC) grade or more.
4. MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker).
5. MCA represents maximum input current.
MFA represents capacitywhich may accept MCA
Abbreviations
- MCA : Min. Circuit Amps. (A)
- MFA : Max. Fuse Amps. (A)

AA
14
English
1-phase terminal block spec
AC power : M4 screw Communication : M4 screw
1(L) 2(N) N
L
11.4
11.4
10.1 10.1
When installing the indoor unit in a computer room or net work room, use the double shielded (Tape aluminum / polyes-
ter braid + copper ) cable of FROHH2R type.
Indoor Power supply Communication Cable Home Server
Power Supply  Indoor Power cable
 ±10% 1.5mm²↑,3wires 0.75-1.5mm²,2wires 0.75mm²,2wires
Between Indoor and Outdoor Connection cable Specications(Common in use)
 Power supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed flexible
cord. (Code designation IEC:60245 IEC 57 / CENELEC: H05RN-F or IEC:60245 IEC 66 / CENELEC: H07RN-F)
11.4
10.1
3-phase terminal block spec
AC power : M4 screw
N
L3(T)
1(L) 2(N)
L2(S)
L1(R)
9.95 11.55
Communication : M4 screw
Connecting the cable

15
English
ENGLISH
The appearance of the unit may be different from the picture depending on the model.
Wiring Diagram of PowerCable
When using ELCB for1 phase
ELB
ELCB
MCCB
Or
F1 F2 L N1(L) 2(N)
Power Supply Electrical component box
Indoor Unit
Communication cable Main power cable
Cable clamp
Cable tie
Indoor Power
When using ELCB for3 phase
ELB
ELCB
MCCB
Or
1(L) 2(N)
F1 F2
L1(R) L2(S) L3(T) N
Indoor Unit
Power Supply Electrical component box
Main power cable
Cable clamp
Cable tie
Indoor Power
Communication cable
CAUTION
 
 
- If the poweris unbalanced greatly, it may shorten the life of the condenser. If the unbalanced poweris
exceeded over4% of supply rating, the indoorunit is protected, stopped and the error mode indicates.
 
the indoor and outdoor units within ducts. (with appropriate IP rating and material selection for your application)
 
a least 3 mm.
 
overvoltage category.
 

AA
16
English
The appearance of the unit may be different from the picture depending on the model.
Wiring Diagram of Connection Cord
1 phase 3 phase
1(L) 2(N) 1
V1 V2 F3 F4
F2F1 2
F1 F2
1(L) 2(N) L N
Main power cable
Cable tie
Outdoor Unit
Indoor Unit
Cable clamp
Indoor Power
Communication cable
1(L) 2(N) 1
V1 V2 F3 F4
F2F1 2
1(L) 2(N)
F1 F2
L1(R) L2(S) L3(T) N
Main power cable
Cable tie
Outdoor Unit
Indoor Unit
Cable clamp
Indoor Power
Communication cable
Connecting the cable
NOTE

coversecurely.

eyelet terminal with M4 screw hole(NOTSUPPLIED WITH UNIT ACCESSORIES).

17
English
ENGLISH
Connect the rated cables only.
Connect using a driverwhich is able to apply the rated torque to the screws.

damaged.
Tightening Torque (kgf • cm)
M3 
M4 
M5 
Connecting the PowerTerminal
Connect the cables to the terminal board using the compressed ring terminal.
Cover a solderless ring terminal and a connector part of the power cable and then connect it.
Silver solder
Nominal
dimensions
for cable
[mm2(inch2)]
Nominal
dimensions
for screw
[mm(inch)]
B D d1 E F L d2 t
Standard
dimension
[mm(inch)]
Allowance
[mm(inch)]
Standard
dimension
[mm(inch)]
Allowance
[mm(inch)]
Standard
dimension
[mm(inch)]
Allowance
[mm(inch)]
Min.
[mm
(inch)]
Min.
[mm
(inch)]
Max.
[mm
(inch)]
Standard
dimension
[mm(inch)]
Allowance
[mm(inch)]
Min.
[mm
(inch)]
4/6
(0.006/
0.009)
4(3/8) 9.5(3/8) ±0.2
(±0.007)
5.6(1/4) +0.3(+0.011)
-0.2(-0.007)
3.4(1/8) ±0.2
(±0.007)
6
(1/4)
5
(3/16)
20
(3/4)
4.3
(3/16)
+ 0.2(+0.007)
0(0)
0.9
(0.03)
8(3/16) 15(9/16) 9
(3/8)
28.5
(1-1/8)
8.4
(1-3/16)
+ 0.4(+0.015)
0(0)
10(0.01) 8(3/16) 15(9/16) ±0.2
(±0.007)
7.1(1/4) +0.3(+0.011)
-0.2(-0.007)
4.5(3/16) ±0.2
(±0.007)
7.9
(5/16)
9
(3/8)
30
(1-3/16)
8.4
(1-3/16)
+ 0.4(+0.015)
0(0)
1.15
(0.04)
16(0.02) 8(3/16) 16(10/16) ±0.2
(±0.007)
9(3/8) +0.3(+0.011)
-0.2(-0.007)
5.8(1/4) ±0.2
(±0.007)
9.5
(5/16)
13
(1/2)
33
(1-5/16)
8.4
(1-3/16)
+ 0.4(+0.015)
0(0)
1.45
(0.05)
25(0.03)
8(3/16) 12(1/2) ±0.3
(±0.011)
11.5(7/16) +0.5(+0.019)
-0.2(-0.007)
7.7(5/16) ±0.2
(±0.007)
11
(3/8)
15
(5/8) 34
(1-3/8)
8.4
(1-3/16)
+ 0.4(+0.015)
0(0)
1.7
(0.06)
8(3/16) 16.5(10/16) 13
(1/2)
8.4
(1-3/16)
35(0.05)
8(3/16) 16(10/16) ±0.3
(±0.011)
13.3(1/2) +0.5(+0.019)
-0.2(-0.007)
9.4(3/8) ±0.2
(±0.007)
12.5
(1/2)
13
(1/2)
38
(1-1/2)
8.4
(1-3/16)
+ 0.4(+0.015)
0(0)
1.8
(0.07)
8(3/16) 22(7/8) 13
(1/2)
43
(1- 11/16)
8.4
(1-3/16)
50(0.07) 8(3/16) 22(7/8) ±0.3
(±0.011)
13.5(1/2) +0.5(+0.019)
-0.2(-0.007)
11.4(7/16) ±0.3
(±0.011)
1 7. 5
(11/16)
14
(9/16)
50
(2)
8.4
(1-3/16)
+ 0.4(+0.015)
0(0)
1.8
(0.07)
70(0.10) 8(3/16) 24(1) ±0.4
(±0.015)
17.5(11/16) +0.5(+0.019)
-0.4(-0.015)
13.3(1/2) ±0.4
(±0.015)
18.5
(3/4)
20
(3/4)
51
(2)
8.4
(1-3/16)
+ 0.4(+0.015)
0(0)
2.0
(0.078)
CAUTION
 
holes below depending on the spot.
• Run transmission wiring between the indoor and outdoor units through a conduit to protect against
external forces, and feed the conduit through the wall together with rergerant piping.
 
lining and bushing with an electrical insulation such as rubber and so on.
 
 
 

AA
18
English
1. Prepare the following tools.
Tools Crimping pliers Connection sleeve
(mm) Insulation tape Contraction tube (mm)
Spec MH-14 20xØ6.5(HxOD) Width 19mm 70xØ8.0(LxOD)
Shape
2. 
the power cable.
- Peel off 20 mm of cable shields from the pre-installed tube.
CAUTION

and outdoor units, refer to the installation manual.
After peeling off cable wires from the pre-installed tube, insert
a contraction tube.
(Unit: mm)
120
60
202020
180
Power cable
20
Pre-installed tube for the power cable
3. Insert both sides of core wire of the power cable into the connection
sleeve.
f Method1
Push the core wire into the sleeve from both sides.
Connection sleeve
f Method 2
Twist the wire cores togetherand push it into the sleeve.
Connection sleeve
4. 
location.
- The compression dimension should be 8.0.
- 
Compression
dimension
f Method1
Compress it 4 times.
5 mm
f Method 2
Compress it 4 times.
5 mm
Extending the power cable

19
English
ENGLISH
5. Wrap it with the insulation tape twice or more and position your contraction tube in the middle of the
insulation tape.
Three or more layers of insulation are required.
f Method1
40 mm
Insulation tape
f Method 2
Insulation tape
35 mm
6. Apply heat to the contraction tube to contract it.
Contraction tube
7. 
CAUTION
Make sure that the connection parts are not exposed to outside.
Be sure to use insulation tape and a contraction tube made of approved reinforced insulating
materials that have the same level of withstand voltage with the power cable. (Comply with the
local regulations on extensions.)
Insulation tape
WARNING
In case of extending the electric wire, please DO NOT use a round-shaped Pressing socket.
- 

AA
20
English
Connecting the refrigerant pipe
Refrigerant piping system
 The appearance of the unit may be different
from the diagram depending on the model.
Make at least one round:
It will reduce noise and vibration
Outer diameter [mm] Minimum thickness [mm] Temper grade
ø6.35 0.7
C1220T-O
ø9.52 0.7
ø12.70 0.8
ø15.88 1.0
ø15.88 0.8 C1220T-1/2H
OR
C1220T-H
ø19.05 0.9
ø22.23 0.9
Temper grade and minimum thickness of the refrigerant pipe
L1
L0
H
Refrigerant piping system table
Pipe length or height
AC052NX∗SEC
AC071NX∗SEC
AC090NX∗SEC
AC100NX∗SGC
AC120NX∗SGC
AC140NX∗SGC
AC160NXMSGC
Max. allowable length Actual pipe length L0 + H + L1 30 m or less 50 m or less
Allowable height length Actual pipe length H 15 m or less 30 m or less
CAUTION


CAUTION

treatment, plug the space.

to proceed precisely to prevent interference
with the internal parts.
