Samsung AM022FNNDEH Series User manual

SYSTEM AIRCONDITIONER CONTENTS
SYSTEM AIRCONDITIONER
INDOOR UNIT
AM017/022HN1DEH/EU
AM022/028/036FN1DEH/EU
AM056/071FN1DEH/TL, AM056/071JN1DEH/EU, AM056/071FN2DEH/EU
AM045/056/071/090/112/128/140/FN4DEH/EU
AM022/028/036/045/056/060FNNDEH/EU
AM015HNNDEH/EU
AM112/128/140/220/280FNHDEH/EU
AM036/056/071FNFDEH/EU
AM050/100FNKDEH/EU
AM017/022/028/036/045/056/071/090/112/128/140FNLDEH/EU
AM022/028/036/045/056/071/090/112//128/140FNMDEH/EU
AM056/071FNCDEH/EU
AM028/036/056FNJDEH/EU
AM022/028/036/056/071FNTDEH/EU
AM015HNTDEH/EU
AM022/028/036/045/056/071FNQDEH/EU
AM015HNQDEH/EU
AM160FNBFEB/EU,250FNBFEB/EU
AM160FNBFGB/EU,250FNBFGB/EU
AM160FNBDEH/EU,320FNBDEH/EU,500FNBDEH/EU
AM036/045/056/071/090/112/128/140HNMPKH/EU
AM112/128/140 HNHPKH/EU
AM180/224JNHFKH/EU
AM112/140JNCDKH/EU
AM015/022/028/036/045/056/071/082JNVDKH/EU
AM015/022/028/036/045/056/071/082JNADKH/EU
AM015/022/028/036/045/056/071/082JNVDEH/TK
AM022/028/036/045/056/060FNNDEH/TL
AM022/028/036/045/056/071FNLDEH/TL
AM056/071/090/112/128/140FNMDEH/TL
AM022/028/036/045/056/071/082JNVDKH/TL
AM140/220/280JNEPEH/EU
AM012/018/024/030/036/048/054/060/072JNZDCH/AA
AM160KNMDEH/EU, AM022/045KNJDEH/EU
1. Precautions
2. Product Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. PCB Diagram and Parts List
6. Wiring Diagram
7. Reference Sheet

Section 0
Samsung Electronics 1
Contents
1. Precautions ......................................................................................................................................................1
1-1 Precautions for the Service..................................................................................................................................................................................1
1-2 Precautions for the Static Electricity and PL..............................................................................................................................................1
1-3 Precautions for the Safety....................................................................................................................................................................................1
1-4 Precautions for Handling Refrigerant for Air Conditioner.................................................................................................................2
1-5 Precautions for Welding the Air Conditioner Pipe.................................................................................................................................2
1-6 Precautions for Additional Supplement of Air Conditioner Refrigerant..................................................................................2
1-7 Other Precautions.....................................................................................................................................................................................................2
2. Product Specifications.................................................................................................................. 3
2-1 The Feature of Product...........................................................................................................................................................................................3
2-2 Accessory and Option Specifications.........................................................................................................................................................44
3. Disassembly and Reassembly...................................................................................................47
3-1 Indoor Unit.................................................................................................................................................................................................................48
ŶAM017/022HN1DEH/EU............................................................................................................................................................................48
 Ŷ Slim 1 way cassette type............................................................................................................................................................................55
ŶAM052/060/072FN1DBH, AM052/060/072HN1DBH1...........................................................................................................64
 Ŷ BIG DUCT............................................................................................................................................................................................................71
 Ŷ GD-S(Big Duct) ...............................................................................................................................................................................................74
 Ŷ Global 4way Cassette type.......................................................................................................................................................................85
 Ŷ Duct type(Slim1,2).........................................................................................................................................................................................91
 Ŷ Duct type(Slim3).............................................................................................................................................................................................96
 Ŷ Duct type(Mid pressure1)......................................................................................................................................................................103
 Ŷ Duct typeDuct type (Mid Pressure2, High Pressure).............................................................................................................108
 Ŷ AM036/045/056/071/090/112/128/140HNMPKH, AM112/128/140HNHPKH/EU..............................................113
 Ŷ CEILING..............................................................................................................................................................................................................118
 Ŷ AM112/140JNCDKH/EU..........................................................................................................................................................................127
 Ŷ CONSOLE.........................................................................................................................................................................................................132
 Ŷ ERV PLUS..........................................................................................................................................................................................................137
 Ŷ Floor Standin Type......................................................................................................................................................................................146
 Ŷ Wall mount type..........................................................................................................................................................................................150
 Ŷ Global Mini 4way ........................................................................................................................................................................................153
ŶAM160FNBDEH/320FNBDEH/500FNBDEH ...............................................................................................................................159
ŶAM160/250FNBFEB, AM160/250FNBFGB....................................................................................................................................163
ŶWall Mounted type(A3050)...................................................................................................................................................................169
ŶOAP DUCT.......................................................................................................................................................................................................178
ŶV-AHU.................................................................................................................................................................................................................183
4. Troubleshooting.........................................................................................................................188
4-1 Check-up Window Description.....................................................................................................................................................................188
4-2 Service Operation..................................................................................................................................................................................................189
4-3 Troubleshooting.....................................................................................................................................................................................................194
4-4 Appropriate Measures for Different Symptom....................................................................................................................................227
5. PCB Diagram and Parts List.....................................................................................................325
5-1Indoor Unit..............................................................................................................................................................................................................325
5-1-1 Slim 1 way cassette type (medium).........................................................................................................................................325
5-1-2 2 way cassette type...........................................................................................................................................................................327
5-1-3 4way cassette , mini 4way casette type................................................................................................................................329
5-1-4 Duct type (Slim Duct 2)...................................................................................................................................................................331
5-1-5 Duct type (Slim Duct 3)...................................................................................................................................................................334
5-1-6 Duct type(MSP, HSP, Big Duct)....................................................................................................................................................337
5-1-7 Duct type(HSP).....................................................................................................................................................................................339
5-1-8 Duct type (Super) ...............................................................................................................................................................................341
5-1-9 Duct type (Global Duct)..................................................................................................................................................................343

Section 0
2Samsung Electronics
Contents
5-1-10 Duct type (Global Duct_HSP)...................................................................................................................................................346
5-1-11 Big Duct.................................................................................................................................................................................................349
5-1-12 Celing type...........................................................................................................................................................................................352
5-1-13 Big Ceiling ...........................................................................................................................................................................................354
5-1-14 Console..................................................................................................................................................................................................356
5-1-15 Wall-Mounted type (Neo Forte)..............................................................................................................................................360
5-1-16 ERV Plus .................................................................................................................................................................................................362
5-1-17 Hydro unit/Hydro unit HT...........................................................................................................................................................364
5-1-18 Hydro unit HT.....................................................................................................................................................................................366
5-1-19 Wall Mounted type(A3050 ) ......................................................................................................................................................373
5-1-20 OAP DUCT(AM140JNEPEH/EU)...............................................................................................................................................376
5-1-21 OAP DUCT(AM220/280JNEPEH/EU)....................................................................................................................................378
5-1-22 V-AHU......................................................................................................................................................................................................383
6. Wiring Diagram ..........................................................................................................................385
6-1 Indoor .......................................................................................................................................................................................................................385
6-1-1 Global 4way(Global Mini-4way) cassteet type..................................................................................................................385
6-1-2 Slim 1way cassette type .................................................................................................................................................................386
6-1-3 BIG Duct ...................................................................................................................................................................................................387
6-1-4 GD-S(Big Duct) .....................................................................................................................................................................................388
6-1-5 Ceiling........................................................................................................................................................................................................389
6-1-6 Big Ceiling...............................................................................................................................................................................................390
6-1-7 Console.....................................................................................................................................................................................................391
6-1-8 RAC(Neo Forte) ....................................................................................................................................................................................392
6-1-9 2way cassette type............................................................................................................................................................................393
6-1-10 DUCT type (Slim III).........................................................................................................................................................................394
6-1-11 DUCT type (Slim I, II, MSP)...........................................................................................................................................................395
6-1-12 Duct type (HSP).................................................................................................................................................................................396
6-1-13 Duct type (Global Duct, MSP)...................................................................................................................................................397
6-1-14 Duct type (Global Duct, HSP)....................................................................................................................................................398
6-1-15 Floor Stand Type...............................................................................................................................................................................399
6-1-16 ERV Plus .................................................................................................................................................................................................400
6-1-17 Hydro unit............................................................................................................................................................................................401
6-1-18 Hydro unit HT 3 phase..................................................................................................................................................................402
6-1-19 Hydro unit HT Single phase.......................................................................................................................................................403
6-1-20 Wall mounted type(A3050) .......................................................................................................................................................404
6-1-21 OAP DUCT............................................................................................................................................................................................405
6-1-22 V-AHU......................................................................................................................................................................................................407
7. Reference Sheet .........................................................................................................................408
7-1 Index for Model Name....................................................................................................................................................................................408
7-2 Pump-down Method......................................................................................................................................................................................410
7-3 How to Put Refrigerant in Refrigerant Container ...........................................................................................................................411

Samsung Electronics 1
1. Precautions
1-1 Precautions for the Service
OUse the correct parts when changing the electric parts.
– Please check the labels and notices for the model name, proper voltage, and proper current for the electric parts.
OFully repair the connection for the types of harness when repairing the product after breakdown.
– A faulty connection can cause irregular noise and problems.
OWhen disassembling or assembling, make sure that the product is laid down on a work cloth.
– Doing so will prevent scratching to the exterior of the rear side of the product.
OCompletely remove dust or foreign substances on the housing, connection, and inspection parts when performing repairs.
– This can prevent fire hazards for tracking, short, etc.
OPlease tighten the service valve of the outdoor unit and the valve cap of the charging valve as securely as possible by using
a monkey spanner.
OCheck whether the parts are properly and securely assembled after performing repairs.
– These parts should be in the same condition as before the repair.
1-2 Precautions for the Static Electricity and PL
OPlease carefully handle the PCB power terminal during repair and measurement when it is turned on since it is vulnerable
to static electricity.
– Please wear insulation gloves before performing PCB repair and measurement.
OCheck if the place of installation is at least 2m away from electronic appliances such as TV, video players, and stereos.
– This can cause irregular noise or degrade the picture quality.
OPlease make sure the customer does not directly repair the product.
– Arbitrary dismantling may result in electric shock or fire.
1-3 Precautions for the Safety
ODo not pull or touch the power plug or the subsidiary power switch with wet hands.
– This may result in electric shock or fire.
OIf the power line or the power plug is damaged, then it must be changed since this is a hazard.
ODo not bend the wire too much or position it so that it can be damaged by a heavy object on top.
– This may result in electric shock or fire.
OThe use of multiple electric outlets should be prohibited.
– This may result in electric shock or fire.
OGround the connection if it is necessary.
– The connection must be grounded if there is any risk of electrical short due to water or moisture.
OUnplug the power or turn off the subsidiary power switch when changing or repairing electrical parts.
– Doing so will prevent electric shock.
OExplain to workers that the battery for the remote control needs to be separated for storage purposes when the product
will not be used for a long time.
– This can cause a problem for the remote control since battery fluid may trickle out.

2Samsung Electronics
1-4 Precautions for Handling Refrigerant for Air Conditioner
Environmental Cautions: Air pollution due to gas release
OSafety Cautions
If liquid gas is released, then body parts that come into contact with it may experience frostbite/blister/numbness.
If a large amount of gas is released, then suffocation may occur due to lack of oxygen. If the released gas is heated, then noxious
gas may be produced by combustion.
OContainer Handling Cautions
Do not subject container to physical shock or overheating. (Flowage is possible while moving within the regulated pressure.)
1-5 Precautions for Welding the Air Conditioner Pipe
ODangerous or flammable objects around the pipe must be removed before the welding.
OIf the refrigerant is kept inside the product or the pipe, then remove the refrigerant prior to welding.
If the welding is carried out while the refrigerant is kept inside, the welding cannot be properly performed. This will also produce
noxious gas that is a health hazard. This leakage will also explode with the refrigerant and oil due to an increase in the refrigerant
pressure, posing a danger to workers.
OPlease remove the oxide produced inside the pipe during the welding with nitrogen gas.
Using another gas may cause harm to the product or others.
1-6 Precautions for Additional Supplement of Air Conditioner Refrigerant
OPrecisely calculate the refrigerant by using a scale and S-net, and proceed with the test operation.
Excessive supplement can cause harm to the product since it can cause an inflow of the liquid refrigerant into the compressor.
ODo not heat the refrigerant container for a forced injection.
This may cause harm to the product or others since the refrigerant container may burst.
ODo not operate the product after removing the product safety pressure switch and sensor.
If the product is blocked inside, then this may cause harm to the product or others due to the excess pressure increase of the
refrigerant gas.
1-7 Other Precautions
OThere should be no leakage of the pipes after installation. When withdrawing the refrigerant, the compressor should be
stopped before removing the connecting pipe.
If the compressor is operating while the refrigerant pipe is not correctly connected and the service valve is opened, then
air and other substances can enter the pipe. The interior of the refrigerant cycle may then build up excessive high pressure
resulting in explosion and damage.

Samsung Electronics 3
2. Product Specifications
2-1 Product Specifacations
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM017HN1DEH/EU AM022HN1DEH/EU AM022FN1DEH/EU1 AM028FN1DEH/EU1 AM036FN1DEH/EU
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP/HR HP/HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 1.7 2.2 2.2 2.8 3.6
Btu/h 5800 7500 7,500 9,500 12,200
Heating*
3)
kW 1.9 2.5 2.6 3.2 4.0
Btu/h 6400 8500 8,500 10,900 13,600
Condensate
(with High fan speed) Liters/h 1.6 1.6 1.12 1.44 1.6
Power Input W 24 25 50*
5)
45*
5)
50*
5)
Running Current A 0.14 0.15 0.20*
5)
0.23*
5)
0.25*
5)
Sound Level Sound Pressure*
4)
dB(A) 33 34 34 37 40
Fan
Type - Crossflow fan Crossflow fan Crossflow fan Crossflow fan Crossflow fan
Motor
Model - SIC-41CVJ-F127-2 SIC-41CVJ-F127-2 Y4S476B041L Y4S476B041L Y4S476B041L
Type - BLDC BLDC Feedback SSR Feedback SSR Feedback SSR
Output W 27W 27W - - -
Air Flow Rate m
3
/min 4.8/4.3/4.1 5.1/4.6/4.3 6/5/4 7/6/5 8/7/6
Refrigerant Type - R410A R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7 12.7
Drain (Quick Lock) ø, mm VP20 VP20 VP20 (OD 25, ID 20) VP20 (OD 25, ID 20) VP20 (OD 25, ID 20)
Weight Net Weight kg 8 8 10.5 10.5 10.5
Shipping Weight kg 10.8 10.8 13.0 13.0 13.0
Dimensions Net Dimensions (W x H x D) mm 740x135x360 740x135x360 970x135x410 970x135x410 970x135x410
Shipping Dimensions (W x H x D) mm 895x223x435 895x223x435 1,164x212x478 1,164x212x478 1,164x212x478
Panel Size
Model - PC1MWSKAN PC1MWSKAN PC1NUSMAN PC1NUSMAN PC1NUSMAN
Net Weight kg 2.6 2.6 3.0 3.0 3.0
Shipping Weight kg 4.2 4.2 5.0 5.0 5.0
Net Dimensions (W x H x D) mm 900x25x420 900x25x420 1,180x25x460 1,180x25x460 1,180x25x460
Shipping Dimensions (W x H x D) mm 958x112x482 958x112x482 1,259x144x539 1,259x144x539 1,259x144x539
Functions
Auto Restart - O O O O O
Auto Swing - O O O O O
Group/Individual Control - OOOOO
External Contact Control - OOOOO
Trouble Shooting by LED - OOOOO
Standard
Accessories
Installation Manual - OOOOO
Operation Manual - XXXXX
Pattern Sheet for Installation - OOOOO
Flexible Drain Hose - OOOOO
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump
(Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
Wired Remote
Controller - MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact
Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
2-1-1 Indoor Unit
QSlim 1way cassette type

Product Specifications
4Samsung Electronics
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM056FN1DEH/TL AM071FN1DEH/TL AM056JN1DEH/EU AM071JN1DEH/EU
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP/HR HP/HR HP/HR HP/HR
Performance Capacity
Cooling*2) kW 5.6 7.1 5.6 7.1
Btu/h 19,100 24,200 19,100 24,200
Heating*3) kW 6.3 8.0 6.3 8.0
Btu/h 21,500 27,300 21,500 27,300
Condensate (with High fan speed) Liters/h - - - -
Power Input W 55.0 80.0 55.0 80.0
Running Current A 0.28 0.40 0.28 0.40
Sound Level Sound Pressure *4) dB(A) 36 39 36 39
Fan
Type - Crossflow Fan Crossflow Fan Crossflow Fan Crossflow Fan
Motor
Model - SIC-55CVL-F158-3
FDA6531SSH
SIC-55CVL-F158-3
FDA6531SSH
SIC-55CVL-F158-3
FDA6531SSH
SIC-55CVL-F158-3
FDA6531SSH
Type - BLDC BLDC BLDC BLDC
Output W 54W 54W 54W 54W
Airflow Rate Cooling (High) m3/min 16.00/14.00/12.50 17.00/15.50/14.00 16.00/14.00/12.50 17.00/15.50/14.00
Heating (High) m3/min R410A R410A R410A R410A
Refrigerant Type - EEV EEV EEV EEV
Control Method - Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Temperature Control - Fuse Fuse Fuse Fuse
Safety Devices - 6.35 9.52 6.35 9.52
Piping
Connections
Liquid (Flare) ø, mm 12.7 15.88 12.7 15.88
Gas (Flare) ø, mm VP20 (OD 26,ID 20) VP20 (OD 26,ID 20) VP20 (OD 26,ID 20) VP20 (OD 26,ID 20)
Drain (Quick Lock) ø, mm 14 14 14 14
Weight Net Weight kg 18 18 18 18
Shipping Weight kg 1200 x 138 x 450 1200 x 138 x 450 1200 x 138 x 450 1200 x 138 x 450
Dimensions Net Dimensions (W x H x D) mm 1435 x 224 x 525 1435 x 224 x 525 1435 x 224 x 525 1435 x 224 x 525
Shipping Dimensions (W x H x D) mm 1,077x299x642 1,077x299x642 1,077x299x642 1,077x299x642
Panel Size
Model - PC1BWSEAN
PC1BWPEAN
PC1BWSEAN
PC1BWPEAN PC1BWSMAN PC1BWSMAN
Net Weight kg 4.5
6.1
4.5
6.1 6.3 6.3
Shipping Weight kg 7.8
9.1
7.8
9.1 8.3 8.3
Net Dimensions (W x H x D) mm 1410 x 23 x 500 1410 x 23 x 500 1410 x 23 x 500 1410 x 23 x 500
Shipping Dimensions (W x H x D) mm 1474 x 122 x 566 1474 x 122 x 566 1474 x 122 x 566 1474 x 122 x 566
Functions
Auto Restart - O O O O
Auto Swing - O O O O
Group/Individual Control - O O O O
External Contact Control - O O O O
Trouble Shooting by LED - O O O O
Standard
Accessories
Installation Manual - O O O O
Operation Manual - X X X X
Pattern Sheet for Installation - O O O O
Flexible Drain Hose - O O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00
Wired Remote Controller - MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14
Indoor Unit(cont.)
Q2 way cassette type

Product Specifications
Samsung Electronics 5
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM056FN2DEH/EU AM071FN2DEH/EU
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR
Performance Capacity
Cooling*2) kW 5.6 7.1
Btu/h 19,100 24,200
Heating*3) kW 6.3 8.0
Btu/h 21,400 27,200
Condensate (with High fan speed) Liters/h 2.87 3.19
Power Input W 70 75
Running Current A 0.38 0.40
Sound Level Sound Pressure *4) dB(A) 45 46
Fan
Type - Crossflow fan Crossflow fan
Motor
Model - PFS027WTVB PFS027WTVB
Type - Feedback SSR Feedback SSR
Output W 14.0 x 2 14.0 x 2
Airflow Rate Cooling (High) m3/min 14 14
Heating (High) m3/min 16 16
Refrigerant Type - R410A R410A
Control Method - EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 9.52
Gas (Flare) ø, mm 12.70 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32, ID 25) VP25 (OD 32, ID 25)
Weight Net Weight kg 21.0 22.0
Shipping Weight kg 25.0 26.0
Dimensions Net Dimensions (W x H x D) mm 890x230x575 890x230x575
Shipping Dimensions (W x H x D) mm 1,077x299x642 1,077x299x642
Panel Size
Model - PC2NUSMEN PC2NUSMEN
Net Weight kg 4.0 4.0
Shipping Weight kg 8.0 8.0
Net Dimensions (W x H x D) mm 1,030x25x650 1,030x25x650
Shipping Dimensions (W x H x D) mm 1,103x151x727 1,103x151x727
Functions
Auto Restart - OO
Auto Swing - OO
Group/Individual Control - OO
External Contact Control - OO
Trouble Shooting by LED - OO
Standard
Accessories
Installation Manual - OO
Operation Manual - XX
Pattern Sheet for Installation - OO
Flexible Drain Hose - OO
Filter / Safety Grille - Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00
Wired Remote
Controller
-MWR-WE10N MWR-WE10N
-MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14
Indoor Unit(cont.)
Q2 way cassette type

Product Specifications
6Samsung Electronics
Model AM045FN4DEH/EU AM056FN4DEH/EU AM071FN4DEH/EU AM090FN4DEH/EU
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW 4.5 5.6 7.1 9.0
Btu/h 15,300 19,100 24,200 30,700
Heating*3) kW 5.0 6.3 8.0 10.0
Btu/h 17,000 21,400 27,200 34,100
Condensate (with High fan speed) Liters/h 2.23 2.71 3.51 4.46
Power Input W 32 32 45 62
Running Current A 0.22 0.22 0.31 0.43
Sound Level
Sound Pressure (Cooling/Heating)*4) dB(A) 42 / 44 42 /44 44 / 44 47 / 47
Fan
Type - Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor
Model - FMC6531SSH FMC6531SSH FMC6531SSH FMC6531SSH
Type - BLDC BLDC BLDC BLDC
Output W *5) *5) *5) *5)
Airflow Rate Cooling (High) m3/min 14.5 14.5 17 19.5
Heating (High) m3/min 16.5 16.5 18.5 21.5
Refrigerant Type - R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 9.52 9.52
Gas (Flare) ø, mm 12.7 12.7 15.88 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg 25.0 25.0 25.0 25.0
Shipping Weight kg 31.0 31.0 31.0 31.0
Dimensions Net Dimensions (W x H x D) mm 840x204x840 840x204x840 840x204x840 840x204x840
Shipping Dimensions (W x H x D) mm 898x275x898 898x275x898 898x275x898 898x275x898
Panel Size
Model - PC4NUSKAN PC4NUSKAN PC4NUSKAN PC4NUSKAN
Net Weight kg 6.7 6.7 6.7 6.7
Shipping Weight kg 8.9 8.9 8.9 8.9
Net Dimensions (W x H x D) mm 950x30x950 950x30x950 950x30x950 950x30x950
Shipping Dimensions (W x H x D) mm 1,042x93x1,042 1,042x93x1,042 1,042x93x1,042 1,042x93x1,042
Functions
Auto Restart - O O O O
Auto Swing - O O O O
Group/Individual Control - O O O O
External Contact Control - O O O O
Trouble Shooting by LED - O O O O
Standard
Accessories
Installation Manual - O O O O
Operation Manual - X X X X
Pattern Sheet for Installation - O O O O
Flexible Drain Hose - O O O O
Filter / Safety Grille - Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00
Wired Remote
Controller - MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14
Indoor Unit(cont.)
Q4 way cassette
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
Samsung Electronics 7
Model AM112FN4DEH/EU AM128FN4DEH/EU AM140FN4DEH/EU
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW 11.2 12.8 14.0
Btu/h 38,200 43,600 47,700
Heating*3) kW 12.5 13.8 16.0
Btu/h 42,600 47,000 54,500
Condensate (with High fan speed) Liters/h 5.58 6.22 7.18
Power Input W 78 73 89
Running Current A 0.55 0.51 0.62
Sound Level
Sound Pressure (Cooling / Heating)*4) dB(A) 49 / 49 50 / 50 53 / 53
Fan
Type - Turbo Fan Turbo Fan Turbo Fan
Motor
Model - DAI33585ZLB DAI33585ZLB DAI33585ZLB
Type - BLDC BLDC BLDC
Output W *5) *5) *5)
Airflow Rate Cooling (High) m3/min 23.0 25.0 26.5
Heating (High) m3/min 26.5 29.5 32.0
Refrigerant Type - R410A R410A R410A
Control Method - EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 9.52 9.52 9.52
Gas (Flare) ø, mm 15.88 15.88 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg 17.0 19.0 19.0
Shipping Weight kg 20.0 22.5 22.5
Dimensions Net Dimensions (W x H x D) mm 840x246x840 840x288x840 840x288x840
Shipping Dimensions (W x H x D) mm 898x316x898 898x357x898 898x357x898
Panel Size
Model - PC4NUSKAN PC4NUSKAN PC4NUSKAN
Net Weight kg 6.7 6.7 6.7
Shipping Weight kg 8.9 8.9 8.9
Net Dimensions (W x H x D) mm 950x30x950 950x30x950 950x30x950
Shipping Dimensions (W x H x D) mm 1,042x83x1,042 1,042x83x1,042 1,042x83x1,042
Functions
Auto Restart - O O O
Auto Swing - O O O
Group/Individual Control - O O O
External Contact Control - O O O
Trouble Shooting by LED - O O O
Standard
Accessories
Installation Manual - O O O
Operation Manual - X X X
Pattern Sheet for Installation - O O O
Flexible Drain Hose - O O O
Filter / Safety Grille - Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - AR-DH00 AR-DH00 AR-DH00
Wired Remote
Controller
- MWR-WE10N MWR-WE10N MWR-WE10N
- MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14
Indoor Unit(cont.)
Q4 way cassette(cont.)
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
8Samsung Electronics
Model AM015HNNDEH/EU AM022FNNDEH6AM028FNNDEH6AM036FNNDEH6
Power Supply ø/V/Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode*1) HP/HR HP/HR HP/HR HP/HR
Performance Capacity
(Nominal)
Cooling*2) kW 1.5 2.2 2.8 3.6
Btu/h 5,100 7,500 9,600 12,300
Heating*3) kW 2.2 2.5 3.2 4
Btu/h 7,500 8,500 10,900 13,600
Power
Power Input
(Nominal)
Cooling*2)
W18 18 18 20
Heating*3) 18 18 18 20
Current Input
(Nominal)
Cooling*2)
A0.17 0.17 0.17 0.19
Heating*3) 0.17 0.17 0.17 0.19
Fan
Motor Type - Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Output W 65 x 1 65 x 1 65 x 1 65 x 1
Air Flow Rate H/M/L (UL) CMM 8.50/7.20/6.50 9.80/8.60/7.40 10.60/9.40/8.20 11.40/10.20/9.00
CFM 300/260/230 350/300/260 370/330/290 400/360/320
External
Pressure Min / Std / Max mmAq - - - -
Pa----
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35
ø, inch 1/4 1/4 1/4 1/4
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7
ø, inch 1/2 1/2 1/2 1/2
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Field
Wiring
Power
Source Wire
Below 20m /
over 20m mm² 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
Transmission Cable mm² 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Refrigerant Type - R410A R410A R410A R410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED EEV INCLUDED
Sound Sound
Pressure
COOLING /
HEATING (HIGH) dBA 38/40 38/40 40/40 42/40
Dimensions
Net Weight kg 12.0 12.0 12.0 12.0
Shipping Weight kg 14.0 14.0 14.0 14.0
Net Dimensions (W x H x D) mm 575 x 250 x 575 575 x 250 x 575 75 x 250 x 575 575 x 250 x 575
Shipping Dimensions
(W x H x D) mm 623 x 298 x 653 623 x 298 x 653 623 x 298 x 623 623 x 298 x 653
Panel Size
Panel model - PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN
Panel Net Weight - 2.7 2.7 2.7 2.7
Shipping Weight - 4.2 4.2 4.2 4.2
Net Dimensions (W×H×D) - 670 x 45 x 670 670 x 45 x 670 670 x 45 x 670 670 x 45 x 670
Shipping Dimensions
(W×H×D) - 714 x 106 x 724 714 x 106 x 724 714 x 106 x 724 714 x 106 x 724
Additional
Accessories
Drain pump
Drain pump - / Model Built-in Built-in Built-in Built-in
Max. lifting
Height /
Displacement
mm/liter/
h750/24 750/24 750/24 750/24
Air Filter - Long life filter Long life filter Long life filter Long life filter
Indoor Unit(cont.)
QMini 4 Way Cassette
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
Samsung Electronics 9
Indoor Unit(cont.)
QMini 4 Way Cassette (cont.)
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM045FNNDEH✳AM056FNNDEH✳AM060FNNDEH✳
Power Supply ø/V/Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode*1) -HP/HR HP/HR HP/HR
Performance Capacity
(Nominal)
Cooling*2) kW 4.50 5.60 6.00
Btu/h 15,400 19,100 20,500
Heating*3) kW 5.00 6.30 6.80
Btu/h 17,100 21,500 23,200
Power
Power Input
(Nominal)
Cooling*2)
W23.00 28.00 31.00
Heating*3) 23.00 28.00 31.00
Current Input
(Nominal)
Cooling*2)
A0.22 0.27 0.30
Heating*3) 0.22 0.27 0.30
Fan
Motor Type - Turbo Fan Turbo Fan Turbo Fan
Output W 65 x 1 65 x 1 65 x 1
Air Flow Rate H/M/L (UL) CMM 12.20/11.00/9.80 13.40/11.80/10.20 14.20/12.60/11.00
CFM 430/390/350 470/420/360 500/440/390
External
Pressure Min / Std / Max mmAq - - -
Pa---
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35
ø, inch 1/4 1/4 1/4
Gas (Flare) ø, mm 12.7 12.7 12.7
ø, inch 1/2 1/2 1/2
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Field
Wiring
Power Source Wire mm² 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
Transmission Cable mm² 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Refrigerant Type - R410A R410A R410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED
Sound Sound
Pressure
COOLING /
HEATING (HIGH) dBA 43/43 46/47 47/47
Dimensions
Net Weight kg 12 12 12
Shipping Weight kg 14 14 14
Net Dimensions (W x H x D) mm 575 x 250 x 575 575 x 250 x 575 575 x 250 x 575
Shipping Dimensions (W x H x D) mm 623 x 298 x 653 623 x 298 x 653 623 x 298 x 653
Panel Size
Panel model - PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN
Panel Net Weight kg 2.7 2.7 2.7
Shipping Weight kg 4.2 4.2 4.2
Net Dimensions (W×H×D) mm 670 x 45 x 670 670 x 45 x 670 670 x 45 x 670
Shipping Dimensions
(W×H×D) mm 714 x 106 x 724 714 x 106 x 724 714 x 106 x 724
Additional
Accessories
Drain pump
Drain pump - / Model Built-in Built-in Built-in
Max. lifting
Height /
Displacement
mm/liter/h 750/24 750/24 750/24
Air Filter - Long life filter Long life filter Long life filter

Product Specifications
10 Samsung Electronics
Product Specifications
Samsung Electronics 11
Indoor Unit(cont.)
QSlim duct
Model AM017FNLDEH/EU AM022FNLDEH6AM028FNLDEH6AM036FNLDEH6AM045FNLDEH6AM056FNLDEH6 AM071FNLDEH6AM090FNLDEH/EU AM112FNLDEH/EU AM128FNLDEH/EU AM140FNLDEH/EU
Power Supply ø/V/Hz
1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1)
HP / HR HP / HR HP / HR HP / HR HP / HR HP / HR
HP / HR HP / HR HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW
1.7 2.2 2.8 3.6 4.5 5.6
7.1 9.0 11.2 12.8 14.0
Btu/h
4,600 7,500 9,500 12,200 15,300 19,100
24,200 30,700 38,200 43,600 47,700
Heating*3) kW
1.9 2.5 3.2 4.0 5.0 6.3
8.0 10.0 12.5 13.8 16.0
Btu/h 5,200 8,500 10,900 13,600 17,000 21,400
27,200 34,100 42,600 47,000 54,500
Condensate (with High fan speed) Liters/h
0.80 1.12 1.28 2.07 2.39
2.87 3.83 4.63 4.95 5.26
Power Input W
55 55 60 65 90 95
120 170 170 200 220
Running Current A
0.3 0.3 0.32 0.33 0.52 0.53
0.6 0.96 0.96 1.28 1.43
Sound Level Sound Pressure *4) dB(A)
37 37 37 37 40 43
47 / 47 43 / 44 43 / 44 45 / 46 45 / 46
Fan
Type -
Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model -
YSK95-28-4-B YSK95-28-4-B YSK95-28-4-B YSK95-28-4-B YSK110-50-4SM YSK110-50-4SM
YSK140-60-4B DL-12840SSBC DL-12840SSBC DL-12840SSBC DL-12840SSBC
Type -
Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Non Feedback SSR BLDC BLDC BLDC BLDC
Output W *5) *5) *5) *5) *5) *5)
*5) *5) *5) *5) *5)
Airflow Rate
Cooling (High) m3/min
5.0 4 7.5 7.5 11.0 12.0
16.5 29.0 31.2 34.0 36.0
Heating (High) m3/min
5.5 8.2 9.0 9.0 14.0 15.0
20.0 34.0 34.0 36.0 38.0
External Static Pressure
Standard
(Min.~Max)
mmH2O 1(0~3) 1 (0~3) 1 (0~3) 1 (0~3) 2 (0~4) 2 (0~4)
2 (0~4) 3 (0~6) 3 (0~6) 3 (0~6) 3 (0~6)
Refrigerant Type -
R410A R410A R410A R410A R410A R410A
R410A R410A R410A R410A R410A
Control Method -
EEV EEV EEV EEV EEV EEV
EEV EEV EEV EEV EEV
Temperature Control -
Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse Fuse Fuse Fuse
Fuse Fuse Fuse Fuse Fuse
Piping Connections
Liquid (Flare) ø, mm
6.35 6.35 6.35 6.35 6.35 6.35
9.52 9.52 9.52 9.52 9.52
Gas (Flare) ø, mm
12.70 12.7 12.7 12.7 12.7 12.7
15.88 15.88 15.88 15.88 15.88
Drain ø, mm VP25 (OD 32,ID 25) VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg
19.0 19.0 19.0 19.5 23.5 23.5
30.0 44.0 44.0 46.0 46.0
Shipping Weight kg
23.0 23.0 23.0 23.5 28.0 28.0
35.0 52.0 52.0 54.0 54.0
Dimensions Net Dimensions (W x H x D) mm
700×199×600 700×199×600 700×199×600 700×199×600 900×199×600 900×199×600
1,100x199x600 1,300x295x690 1,300x295x690 1,300x295x690 1,300x295x690
Shipping Dimensions (W x H x D) mm
950x270x710 950x270x710 950x270x710 950x270x710 1150×280×710 1150×280×710
1350x280x710 1575x370x835 1575x370x835 1575x370x835 1575x370x835
Functions
Auto Restart - OOOOOO
OOOOO
Auto Swing -
XXXXXX
XXXXX
Group/Individual Control -
OOOOOO
OOOOO
External Contact Control -
OOOOOO
OOOOO
Trouble Shooting by LED - XXXXXX
XXXXX
Standard Accessories
Installation Manual -
OOOOOO
OOOOO
Operation Manual -
OOOOOO
OOOOO
Pattern Sheet for Installation -
XXXXXX
XXXXX
Flexible Drain Hose -
OOOOOO
OOOOO
Filter / Safety Grille -
Filter(Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) -
MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
Optional Accessories
Wireless Remote Controller -
MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
Duct Receiver Kits
Receiver
- MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10
MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10
ReceiverWire
- MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
Wired Remote
Controller Simplified -
MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
Drain Pump
MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D
MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
12 Samsung Electronics
Indoor Unit(cont.)
QDuct Type (Uplevel Static Pressure)
Model AM022FNMDEH/EU AM028FNMDEH/EU AM036FNMDEH/EU AM045FNMDEH/EU
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW 2.2 2.8 3.6 4.5
Btu/h 7,500 9,500 12,200 15,300
Heating*3) kW 2.5 3.2 4.0 5.0
Btu/h 8,500 10,900 13,600 17,000
Power Input W 80 80 85 125
Running Current A 0.4 0.4 0.55 1.15
Sound Level Sound Pressure (Cooling/Heating) *4) dB(A) 37 / 38 38/39 39/40 44 / 46
Fan
Type - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model - YSK110-25-4SM YSK110-25-4SM YSK110-50-4SM YSK140-200-4E1
Type - Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Output W *5) *5) *5) *5)
Airflow Rate
Cooling (High) m3/min 7.7 8.8 11.0 13.0
Heating (High) m3/min 8.9 10.3 12.7 14.5
External Static Pressure Standard(Min.~Max) mmH2O 2 (0~4) 2 (0~4) 2 (0~4) 4 (0~8)
Refrigerant Type - R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV
Temperature Control -
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7
Drain ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg 23.5 23.5 23.5 29.0
Shipping Weight kg 28.0 28.0 28.0 33.0
Dimensions Net Dimensions (W x H x D) mm 900×199×600 900×199×600 900×199×600 900×260×480
Shipping Dimensions (W x H x D) mm 1150×280×710 1150×280×710 1150×280×710 1170×595×340
Functions
Auto Restart - O O O O
Auto Swing - X X X X
Group/Individual Control - O O O O
External Contact Control - O O O O
Trouble Shooting by LED - X X X X
Standard
Accessories
Installation Manual - O O O O
Operation Manual - O O O O
Pattern Sheet for Installation - X X X X
Flexible Drain Hose - O O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) - MR-BH01 MR-BH01 MR-BH01 MR-BH01
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00
Duct Receiver Kits
Receiver
- MRK-A10 MRK-A10 MRK-A10 MRK-A10
ReceiverWire
- MRW-10A MRW-10A MRW-10A MRW-10A
Wired Remote
Controller Simplified - MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module MIM-B14 MIM-B14 MIM-B14 MIM-B14
Drain Pump
MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
13 Samsung Electronics
Product Specifications
Samsung Electronics 14
Indoor Unit(cont.)
 MSP duct
Model AM056FNMDEHSAM071FNMDEHSAM090FNMDEHSAM112FNMDEHSAM128FNMDEHSAM140FNMDEHSAM160KNMDEHS
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR HP / HR HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW
5.6 7.1 9 11.2 12.8 14 16.0
Btu/h 19,100 24,200 30,700 38,200 43,600 47,700 54,000
Heating*3) kW
6.3 8.0 10.0 12.5 13.8 16.0 18.0
Btu/h 21,400 27,200 34,100 42,600 47,000 54,500 60,000
Condensate (with High fan speed) Liters/h 4.63 4.95 5.1 -
Power Input W
130*5) 190*5) 240*5) 260 370 410 485
Running Current A 1.10*5) 1.25*5) 1.30*5) 1.17 1.67 1.86 2.24
Sound Level Sound Pressure *4) dB(A) 47 47 50 48 50 50 53
Fan
Type - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model - YSK140-200-4E1 YSK140-200-4E1 YSK140-200-4 YSK140-200-4 Y7S423C015 Y7S423C015 Y7S423C015
Type - Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Output W -------
Airflow Rate
Cooling (High) m3/min 14.5 18.5 19.5 27.0 32.0 37.0 39.5
Heating (High) m3/min 15.5 20.0 21.5 27.0 31.0 36.0 42.0
External StaticPressure Standard(Min.~Max) mmH2O 4(0~8) 4(0~8) 6(4~8) 8(4~12) 8(4~12) 8(4~12) 8(4~14)
Refrigerant Type -
R410A R410A R410A R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV EEV EEV EEV
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse Fuse Fuse Fuse Fuse
Piping Connections
Liquid (Flare) ø, mm 6.35 9.52 9.52 9.52 9.52 9.52 9.52
Gas (Flare) ø, mm 12.7 15.88 15.88 15.88 15.88 15.88 15.88
Drain ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP20 (OD 25, ID 20)
Weight Net Weight kg
29.0 29.0 34.0 36.0 52.0 52.0 50
Shipping Weight kg 33.0 33.0 39.0 42.0 59.0 59.0 57
Dimensions Net Dimensions (W x H x D) mm
900x260x480 900x260x480 1,150x260x480 1,150x320x480 1,200x360x650 1,200x360x650 1,200x360x650
Shipping Dimensions (W x H x D) mm 1170×595×340 1170×595×340 1420×595×340 1150×320×480 1480×790×420 1480×790×420 1480×790×420
Functions
Auto Restart - OOOOOOO
Auto Swing - X X X X X X X
Group/Individual Control - OOOOOOO
External Contact Control - OOOOOOO
Trouble Shooting by LED - X X X X X X X
Standard Accessories
Installation Manual - OOOOOOO
Operation Manual - OOOOOOO
Pattern Sheet for Installation - X X X X X X X
Flexible Drain Hose - OOOOOOO
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Optional Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
Duct Receiver Kits
Receiver
- MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10
ReceiverWire
- MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
Wired Remote
Controller Simplified -
MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
Drain Pump MDP-M075SGU3D MDP-M075SGU1D MDP-M075SGU1D MDP-M075SGU1D MDP-M075SGU2D MDP-M075SGU2D MDP-M075SGU2D

Product Specifications
15 Samsung Electronics
Indoor Unit(cont.)
QBig Duct
Model AM220FNHDEH/EU AM280FNHDEH/EU
Power Supply ø/V/Hz 1/220-240/50 1/220-240/50
Mode*1) HP / HR HP / HR
Performance Capacity
Cooling*2) kW 22.4 28.0
Btu/h 76,400 95,500
Heating*3) kW 25.0 31.5
Btu/h 85,300 107,500
Condensate (with High fan speed) Liters/h
Power Input W 530 790
Running Current A 3.8 5.9
Sound Level Sound Pressure (High/Low)*4) dB(A) 47 / 44 48 / 45
Fan
Type - Sirocco Fan Sirocco Fan
Motor
Model - DL-13875SSOB DL-13875SSOB
Type - BLDC BLDC
Output W
Airflow Rate
Cooling (High) m3/min 58 72
Heating (High) m3/min 58 72
External Static Pressure Standard(Min.~Max) mmH2O 15(5-25) 15(5-28)
Refrigerant Type - R410A R410A
Control Method - EEV EEV
Temperature Control - Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 9.52 9.52
Gas (Flare) ø, mm 19.05 22.2
Drain ø, mm VP25(OD32, ID25) VP25(OD32, ID25)
Weight Net Weight kg 89 89
Shipping Weight kg 99 99
Dimensions Net Dimensions (W x H x D) mm 1,240x470x1,040 1,240x470x1,040
Shipping Dimensions (W x H x D) mm 1,507x558x1,155 1,507x558x1,155
Functions
Auto Restart - O O
Auto Swing - X X
Group/Individual Control - O O
External Contact Control - O O
Trouble Shooting by LED - X X
Standard
Accessories
Installation Manual - O O
Operation Manual - O O
Pattern Sheet for Installation - O O
Flexible Drain Hose - O O
Filter / Safety Grille - X X
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00
Duct Receiver
Kits
Receiver
- MRK-A10 MRK-A10
ReceiverWire
- MRW-10A MRW-10A
Wired Remote
Controller Simplified - MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14
Drain Pump MDP-N047SNC1D MDP-N047SNC1D
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
16 Samsung Electronics
Indoor Unit(cont.)
QGD-S(Big Duct)
Model AM180JNHFKH/EU AM224JNHFKH/EU
Power Supply ø/V/Hz 1/220-240/50 1/220-240/50
Mode*1) HP / HR HP / HR
Performance Capacity
Cooling*2) kW 18.0 22.4
Btu/h - -
Heating*3) kW 20.0 25.0
Btu/h - -
Condensate (with High fan speed) Liters/h - -
Power Input W 340 530
Running Current A 1.9 2.9
Sound Level Sound Pressure (High/Low)*4) dB(A) 43 44
Fan
Type - Sirocco Fan Sirocco Fan
Motor
Model - DL-17860SSBA DL-17860SSBA
Type - BLDC BLDC
Output W
Airflow Rate High/Mid/Low m3/min 58/50/43 72/61/51
External Static Pressure Standard(Min.~Max) mmH2O 7.34(5-20) 7.34(5-20)
Refrigerant Type - R410A R410A
Control Method - EEV EEV
Temperature Control - Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 9.52 9.52
Gas (Flare) ø, mm 19.05 22.2
Drain ø, mm VP25(OD25, ID20) VP25(OD25, ID20)
Weight Net Weight kg 82 82
Shipping Weight kg 91.5 91.5
Dimensions Net Dimensions (W x H x D) mm 1,350 x 450 x 910 1,350 x 450 x 910
Shipping Dimensions (W x H x D) mm 1,629 x 548 x 989 1629 x 548 x 989
Functions
Auto Restart - O O
Auto Swing - X X
Group/Individual Control - O O
External Contact Control - O O
Trouble Shooting by LED - X X
Standard
Accessories
Installation Manual - O O
Operation Manual - O O
Pattern Sheet for Installation - O O
Flexible Drain Hose - O O
Filter / Safety Grille - X X
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00
Duct Receiver
Kits
Receiver
- MRK-A10 MRK-A10
ReceiverWire
- MRW-10A MRW-10A
Wired Remote
Controller Simplified - MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14
Drain Pump
MDP-G075SQ
(Internal installation)
MDP-G075SQ
(Internal installation)
MDP-G075SP
(External installation)
MDP-G075SP
(External installation)
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
Samsung Electronics 17
Indoor Unit(cont.)
QHSP Duct
Model AM112FNHDEH/EU AM128FNHDEH/EU AM140FNHDEH/EU
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW 11.2 12.8 14.0
Btu/h 38,200 43,600 47,700
Heating*3) kW 12.5 13.8 16.0
Btu/h 42,600 47,000 54,500
Condensate (with High fan speed) Liters/h
Power Input W 305 333 385
Running Current A 2.35 2.58 3.0
Sound Level Sound Pressure (High/Low)*4) dB(A) 43/40 45/40 46/44
Fan
Type - Sirocco Fan
AL, Φ226,L200, 2EA, KJBLWR
Sirocco Fan
AL, Φ226,L200, 2EA, KJBLWR
Sirocco Fan
AL, Φ226,L200, 2EA, KJBLWR
Motor
Model - BLDC Motor
(DL-12840SSB, 8Pole, Φ124)X2
BLDC Motor
(DL-12840SSB, 8Pole, Φ124)X2
BLDC Motor
(DL-12840SSB, 8Pole, Φ124)X2
Type - BLDC BLDC BLDC
Output W
Airflow Rate
Cooling (High) m3/min 33 35 39
Heating (High) m3/min 35 37 41
External Static Pressure Standard(Min.~Max) mmH2O 10 (5~20) 10 (5~20) 10 (5~20)
Refrigerant Type - R410A R410A R410A
Control Method - EEV EEV EEV
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 9.52 9.52 9.52
Gas (Flare) ø, mm 15.88 15.88 15.88
Drain ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg 62.0 62.0 62.0
Shipping Weight kg 70.0 70.0 70.0
Dimensions Net Dimensions (W x H x D) mm 1200×360×650 1200×360×650 1200×360×650
Shipping Dimensions (W x H x D) mm 1447x425x769 1447x425x769 1447x425x769
Functions
Auto Restart - O O O
Auto Swing - X X X
Group/Individual Control - O O O
External Contact Control - O O O
Trouble Shooting by LED - X X X
Standard
Accessories
Installation Manual - O O O
Operation Manual - O O O
Pattern Sheet for Installation - O O O
Flexible Drain Hose - O O O
Filter / Safety Grille - X X X
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00
Duct Receiver
Kits
Receiver
- MRK-A10 MRK-A10 MRK-A10
ReceiverWire
- MRW-10A MRW-10A MRW-10A
Wired Remote
Controller Simplified - MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14
Drain Pump MDP-M075SGU2D MDP-M075SGU2D MDP-M075SGU2D
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Norminal cooling capacities are based on;
- Indoor temperature : 27ఁDB, 19ఁWB - Outdoor temperature : 35ఁDB, 24ఁWB
*3) Norminal heating capacities are based on;
- Indoor temperature : 20ఁDB, 15ఁWB - Outdoor temperature : 7ఁDB, 6ఁWB
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
18 Samsung Electronics
Indoor Unit(cont.)
QGlobal Duct
Div. GD-1
Model Europe AM036HNMPKH/EU
Basic Model Europe AC036HBMDKH/EU(CAC)
Power Supply φ,V,Hz 1,220~240,50
Mode 1) - HP / HR
Performance Capacity Cooling 2) kW 92%װ3.6
Heating 3) kW 92%װ4.0
Power Input Consumption (Cooling/Heating) W 110% ײ50/50
Running Current (Cooling/Heating) A 110% ײ0.50/0.50
Indoorunit refrigerant adding amount Kg/EA 0.22
Noise Level 开发spec dB(A)ײ 40/40
Catalouel 标示值 dB(A)ײ 29/26/23
Fan
Type - Sirrocco Fan (Φ180*2ea)
Motor
Model - SIC-70CW-F1153-2 (DB31-00639A)
Type - BLDC feedback
Output W 153
Fan Speed
Fan(H/M/L) Standard rpm±20 700/660/620
Cooling (H/M/L)参考 Standard 700/660/620
Heating (H/M/L)参考 Standard 700/660/620
Airflow Rate
Fan(H/M/L) ᎑/min 12.00/9.50/8.00
Cooling (High)参考 -
Heating (High)⎩俪 -
Refrigerant Type - R410a
Control Method - EDM EEV3.2c Sanhua
Temperature Control - Micom&Thermistors
Safety Devices - Fuse:5A
External Static Pressure Standard(Min.~Max) mmH2O 0-2.5-15
OPTION CODE
Standard Static
Pressure 0≤ SP ≤2.5
Product 010054-1C5084-202424-331205
Install 020010-120000-200000-300000
Cycle 030000-100000-200000-300000
Install 2 050000-100000-200000-300000
All Static Pressure
0≤ SP ≤2.5 Product 010054-1C5084-202424-331205
2.5< SP ≤5 Product 010054-1C50EB-202424-331205
5< SP ≤7.5 Product 010054-1C5552-202424-331205
7.5< SP ≤10 Product 010054-1C55CA-202424-331205
10< SP ≤12.5 Product 010054-1C5A30-202424-331205
12.5< SP ≤15 Product 010054-1C5A85-202424-331205
Piping
Connections
Liquid (Flare) Φ,mm 6.35
Φinch 1/4כ
Gas (Flare) Φ,mm 12.7
Φinch 1/2כ
Drain Φ,mm VP25 (OD 32, ID 25)
Φinch -
Weight Net Weight kg 25.5
Shipping Weight kg 30
Dimensions
Net Dimensions (W×H×D) mm 850*250*700
inch -
Shipping Dimensions (W×H×D) mm 1064*320*784
inch -
HEX
Dimension - 2R*39S*TP8.4*675mm
Tube hair fin - H2.1(9hole)FMC 9.5mm,
Fin - Louver, FP1.3
Pass - 4*4 Pass
Micom - DB91-01629A
Version:140708 Checksum:E754
LOADING
QUANTITY
20ft EA 98
40ft EA 210
40ft JUMBO EA 240
Panel Size
Model Europe -
Net Weight kg -
Shipping Weight kg -
Net Dimensions (W×H×D) mm -
Shipping Dimensions (W×H×D) mm -
Optional Accessories
Model Europe MDP-G075SQ (Internal installation), MDP-G075SP (External installation)
Drain pump In/Option Option
Max. lifting Height / Displacement mm / liter/h 750mm, 24l/h
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Norminal cooling capacities are based on;
- Indoor temperature : 27ఁDB, 19ఁWB - Outdoor temperature : 35ఁDB, 24ఁWB
*3) Norminal heating capacities are based on;
- Indoor temperature : 20ఁDB, 15ఁWB - Outdoor temperature : 7ఁDB, 6ఁWB
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Product Specifications
Samsung Electronics 19
QGlobal Duct (cont.)
Div. GD-1 GD-1 GD-1
Model Europe AM045HNMPKH/EU AM056HNMPKH/EU AM071HNMPKH/EU
Basic Model Europe AC052HBMDKH/EU(CAC) AC060HBMDKH/EU(CAC) AC071HBMDKH/EU(CAC)
Power Supply φ,V,Hz 1,220~240,50 1,220~240,50 1,220~240,50
Mode 1) - HP / HR HP / HR HP / HR
Performance Capacity Cooling 2) kW 92%װ4.5 5.6 7.1
Heating 3) kW 92%װ5.0 6.3 8.0
Power
Input Consumption
(Cooling/Heating) W 110% ײ60/60 110/110 120/120
Running Current
(Cooling/Heating) A 110% ײ0.60/0.60 0.9/0.9 1.0/1.0
Indoorunit refrigerant adding amount Kg/EA 0.22 0.22 0.22
Noise Level 开发spec dB(A)ײ 44/44 45/45 47/47
Catalouel 标示值 dB(A)ײ 31/28/24 32/29/25 37/33/29
Fan
Type - Sirrocco Fan (Φ180*2ea) Sirrocco Fan (Φ180*2ea) Sirrocco Fan (Φ180*2ea)
Motor
Model - SIC-70CW-F1153-2 (DB31-
00639A)
SIC-70CW-F1153-2 (DB31-
00639A)
SIC-70CW-F1153-2 (DB31-
00639A)
Type - BLDC feedback BLDC feedback BLDC feedback
Output W 153 153 153
Fan Speed
Fan(H/M/L) Standard rpm±20 800/720/640 1000/920/840 1020/940/860
Cooling (H/M/L)参考 Standard 800/720/640 1000/920/840 1020/940/860
Heating (H/M/L)参考 Standard 800/720/640 1000/920/840 1020/940/860
Airflow Rate
Fan(H/M/L) ᎑/min 14.00/11.00/8.00 21.00/18.00/15.00 22.00/19.00/16.00
Cooling (High)参考 ---
Heating (High)⎩俪 ---
Refrigerant Type - R410a R410a R410a
Control Method - EDM EEV3.2c Sanhua EDM EEV3.2c Sanhua EDM EEV3.2c Sanhua
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse:5A Fuse:5A Fuse:5A
External Static Pressure Standard(Min.~Max) mmH2O 0-3-15 0-3-15 0-3-15
OPTION CODE
Standard Static
Pressure 0≤ SP ≤2.5
Product 010054-1C50D5-202D2D-331204 010054-1C547F-203838-331202 010054-1C5580-204747-331201
Install 020010-120000-200000-300000 020010-120000-200000-300000 020010-120000-200000-300000
Cycle 030000-100000-200000-300000 030000-100000-200000-300000 030000-100000-200000-300000
Install 2 050000-100000-200000-300000 050000-100000-200000-300000 050000-100000-200000-300000
All Static Pressure
0≤ SP ≤3 Product 010054-1C50D5-202D2D-331204 010054-1C547F-203838-331202 010054-1C5580-204747-331201
3< SP ≤6 Product 010054-1C545D-202D2D-331204 010054-1C55D5-203838-331202 010054-1C55E6-204747-331201
6< SP ≤9 Product 010054-1C55C4-202D2D-331204 010054-1C592B-203838-331202 010054-1C593C-204747-331201
9< SP ≤12 Product 010054-1C593B-202D2D-331204 010054-1C5A71-203838-331202 010054-1C5A82-204747-331201
12< SP ≤15 Product 010054-1C5AA2-202D2D-331204 010054-1C5AC8-203838-331202 010054-1C5AD9-204747-331201
Piping
Connections
Liquid (Flare) Φ,mm 6.35 6.35 9.52
Φinch כ כ 
Gas (Flare) Φ,mm 12.7 12.7 15.88
Φinch כ כ 
Drain Φ,mm
VP25 (OD 32, ID 25) VP25 (OD 32, ID 25) VP25 (OD 32, ID 25)
Φinch - - -
Weight Net Weight kg 25.5 25.5 25.5
Shipping Weight kg 30 30 30
Dimensions
Net Dimensions (W×H×D) mm 850*250*700 850*250*700 850*250*700
inch - - -
Shipping Dimensions (W×H×D) mm 1064*320*784 1064*320*784 1064*320*784
inch - - -
HEX
Dimension - 2R*39S*TP8.4*675mm 2R*39S*TP8.4*675mm 2R*39S*TP8.4*675mm
Tube hair fin - H2.1(9hole)FMC 9.5mm, H2.1(9hole)FMC 9.5mm, H2.1(9hole)FMC 9.5mm,
Fin - Louver, FP1.3 Louver, FP1.3 Louver, FP1.3
Pass 4*4 Pass 4*4 Pass 4*4 Pass
Micom - DB91-01629A
Version:140708 Checksum:E754
DB91-01629A
Version:140708 Checksum:E754
DB91-01629A
Version:140708 Checksum:E754
LOADING
QUANTITY
20ft EA 98 98 98
40ft EA 210 210 210
40ft JUMBO EA 240 240 240
Panel Size
Model Europe - - -
Net Weight kg - - -
Shipping Weight kg - - -
Net Dimensions (W×H×D) mm - - -
Shipping Dimensions (W×H×D) mm - - -
Optional Accessories
Model Europe
MDP-G075SQ (Internal installation)
MDP-G075SP (External installation)
MDP-G075SQ (Internal installation)
MDP-G075SP (External installation)
MDP-G075SQ (Internal installation)
MDP-G075SP (External installation)
Drain pump In/Option Option Option Option
Max. lifting Height / Displacement mm / liter/h 750mm, 24l/h 750mm, 24l/h 750mm, 24l/h
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Norminal cooling capacities are based on;
- Indoor temperature : 27ఁDB, 19ఁWB - Outdoor temperature : 35ఁDB, 24ఁWB
*3) Norminal heating capacities are based on;
- Indoor temperature : 20ఁDB, 15ఁWB - Outdoor temperature : 7ఁDB, 6ఁWB
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
