Samsung AC TXQR H Series User manual

Airconditioner
Installationmanual
AC***TXQR*H
• Thank you forpurchasing this Samsung airconditioner.
• Before operating this unit, please read this manual carefullyand retain it forfuture reference.
DB68-09339A-02
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGX YWYWTXYTW`GGG㝘㤸GXXa[`aZ^

2English
Contents
SafetyInformation 3
General information 3
Installing the unit 4
Powersupplyline, fuse orcircuit breaker 4
InstallationProcedure 5
Step1 Choosing the installation location 5
Step 2 Fixing the outdoorunit in place 8
Step 3 Connecting the powercables, communication cable, and controllers 9
Step 4 Optional: Extendingthe powercable 18
Step 5 Connecting the refrigerant pipe 20
Step 6 Optional: Cutting and flaringthe pipes 21
Step 7 Connecting up and removing airin the circuit 21
Step 8 Adding refrigerant (R-410A) 23
Step 9 Performing the gas leaktest 24
Step10 Connectingthe drain hose to the outdoorunit 25
Step11 Insulating the refrigerant pipes 25
Step12 Checking the earthing 26
Step13 Performingfinal check and trial operation 27
Extraprocedures 30
Pumping down refrigerant 30
Relocatingthe indoorand outdoorunits 30
Using the stop valve 31
Appendix 32
Troubleshooting 32
Correct Disposalof This Product
(WasteElectrical& ElectronicEquipment)
(Applicableincountrieswithseparatecollectionsystems)
Thismarkingontheproduct,accessoriesorliteratureindicatesthattheproductanditselectronicaccessories(e.g.charger,
headset,USBcable)shouldnot bedisposed ofwithotherhouseholdwasteat theend oftheirworking life. Topreventpossible
harmtothe environment orhumanhealthfromuncontrolledwastedisposal,pleaseseparatethese items from othertypesof
wasteandrecyclethemresponsiblytopromotethesustainablereuseof material resources.
Householdusersshouldcontacteitherthe retailerwheretheypurchasedthisproduct,ortheirlocalgovernmentoffice,for
detailsofwhereandhowtheycantakethese itemsforenvironmentallysaferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthepurchasecontract.Thisproductand
itselectronicaccessoriesshouldnotbe mixedwith othercommercialwastesfordisposal.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGY YWYWTXYTW`GGG㝘㤸GXXa[`aZ^

3
English
SafetyInformation
SafetyInformation
WARNING
• Hazards orunsafe practices that mayresult in severe
personal injuryordeath.
CAUTION
• Hazards orunsafe practices that mayresult in minor
personal injuryorproperty damage.
• Carefully followthe precautions listed belowbecause
theyare essential to guarantee the safety of the
equipment.
WARNING
• Always disconnect the airconditionerfromthe power
supplybefore servicing it oraccessing its internal
components.
• Verifythat installation and testing operations are
performed byqualified personnel.
• Verifythat the airconditioneris not installed in an
easilyaccessible area.
Generalinformation
WARNING
• Carefully read the content of this manual before
installing the airconditionerand store the manual in
a safe place in orderto be able to use it as reference
afterinstallation.
• Formaximum safety, installers should always carefully
read the following warnings.
• Store the operation and installation manual in a safe
location and rememberto hand it overto the new
ownerif the airconditioneris sold ortransferred.
• This manual explains howto install an indoorunit with
a split systemwith two SAMSUNG units. The use of
othertypes of unitswith different control systems may
damage the units and invalidate thewarranty. The
manufacturershall not be responsible fordamages
arising from the use of non compliant units.
• The manufacturershall not be responsible fordamage
originating from unauthorized changes orthe
improperconnection of electric and requirements set
forth in the“Operating limits” table, included in the
manual, shall immediatelyinvalidate thewarranty.
• The airconditionershould be used only forthe
applications forwhich it has been designed: the indoor
unit is not suitable to be installed in areas used for
laundry.
• Do not use the units if damaged. If problems occur,
switchthe unit off and disconnect it from the power
supply.
• In orderto prevent electric shocks, fires orinjuries,
always stopthe unit, disable the protection switch
and contact SAMSUNG’s technical support if the unit
produces smoke, if the powercable is hot ordamaged
orif the unit is very noisy.
• Always rememberto inspectthe unit, electric
connections, refrigerant tubes and protections
regularly. These operations should be performed by
qualified personnel only.
• The unit contains moving parts,which should always
be kept out of the reach of children.
• Do not attempt to repair, move, alterorreinstall the
unit. If performed byunauthorized personnel, these
operations maycause electric shocks orfires.
• Do not place containerswith liquids orotherobjects
on the unit.
• All the materials usedforthe manufacture and
packaging of the airconditionerare recyclable.
• The packing material and exhaust batteries of the
remote controller(optional) must be disposed of in
accordance with current laws.
• The airconditionercontains a refrigerant that has
to be disposed of as specialwaste.At the end of its
life cycle,the airconditionermust be disposed of in
authorized centres orreturnedto the retailerso that it
can be disposed of correctlyand safely.
• Wearprotective equipment (such as safetygloves,
goggles, and headgear) during installation and
maintenanceworks.
Installation/repairtechnicians maybe injured if
protective equipment is not properlyequipped.
• This appliance is not intended foruse bypersons
(including children) with reduced physical, sensory
ormental capabilities, orlack of experience and
knowledge, unless theyhave been given supervision
orinstruction concerning use of the appliance bya
person responsible fortheirsafety. Children should be
supervised to ensure that they do not playwith the
appliance.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGZ YWYWTXYTW`GGG㝘㤸GXXa[`aZ^

4
SafetyInformation
English
SafetyInformation
Installingtheunit
WARNING
IMPORTANT:When installing theunit, alwaysremember
toconnectfirsttherefrigeranttubes,thentheelectrical
lines.
• Upon receipt, inspectthe producttoverifythat
it has not been damaged during transport. If the
product appears damaged, DO NOTINSTALLit and
immediatelyreport the damageto the carrieror
retailer(if the installerorthe authorizedtechnician has
collected the material from the retailer.)
• Aftercompleting the installation, always carryout a
functional test and provide the instructions on howto
operatethe airconditionerto the user.
• Do not use the airconditionerin environmentswith
hazardous substances orclose to equipment that
release free flames to avoid the occurrence of fires,
explosions orinjuries.
• Do not install the product in a place where
thermohygrostat is needed (such as serverroom,
machineryroom, computerroom, etc.). Those places
do not provide guaranteed operation condition of the
producttherefore performance can be poorin these
places.
• Do not install the product in a ship oravehicle (such
as a campervan). Salt,vibration orotherenvironmental
factormay cause the product malfunction, electric
shock orfire.
• Ourunits should be installed in compliancewith the
spaces shown in the installation manual,to ensure
accessibilityfrom both sides and allowrepairs or
maintenance operations to be carried out. The
unit’s components should be accessible and easy to
disassemblewithout endangering people and objects.
• Forthis reason,when provisions ofthe installation
manual are not compliedwith, the cost required to
access and repairthe units (in SAFETY CONDITIONS,
as set out in prevailing regulations)with harnesses,
ladders, scaffolding oranyotherelevation system will
NOTbe considered part of thewarrantyandwill be
chargedto the end customer.
Powersupplyline,fuseorcircuit
breaker
WARNING
• Always make sure that the powersupplyis compliant
with current safetystandards. Always install the air
conditionerin compliance with current local safety
standards.
• Alwaysverifythat a suitable earthing connection is
available.
• Verifythat thevoltage and frequencyof the power
supplycomplywith the specifications and that the
installed poweris sufficient to ensurethe operation of
anyotherdomestic appliance connected to the same
electric lines.
• Alwaysverifythat the cut-off and protection switches
are suitably dimensioned.
• Verifythat the airconditioneris connected to the
powersupplyin accordancewith the instructions
provided in thewiring diagram included inthe manual.
• Alwaysverifythat electric connections (cable entry,
section of leads, protections…) are compliant with
the electric specifications andwith the instructions
provided in thewiring scheme.Always verify that all
connections complywith the standards applicableto
the installation of airconditioners.
• Devices disconnected from the powersupplyshould
be completelydisconnected in the condition of
overvoltage category.
• Be sure notto perform powercable modification,
extensionwiring, and multiple wire connection.
– It maycause electric shock orfire due to
poorconnection, poorinsulation, orcurrent limit
override.
– When extensionwiring is required dueto power
line damage, referto "Step 4 Optional: Extending
thepowercable" inthe installation manual.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGG[ YWYWTXYTW`GGG㝘㤸GXXa[`aZ^

5
English
InstallationProcedure
InstallationProcedure
Step1 Choosingtheinstallationlocation
Installationlocationrequirements
• Donot place theoutdooruniton itssideorupside down.Failing
todo somaycausethe compressorlubricationoilto runintothe
cooling circuitand leadtoaserious damagetotheunit.
• Installthe unitinawell-ventilatedlocationawayfrom direct
sunlight orstrongwinds.
• Installthe unit ina locationthatwouldnot obstruct any
passagewaysorthoroughfares.
• Installthe unit ina locationthatwouldnot inconvenienceor
disturbyourneighbors, as theycouldbe affectedbythe noiseor
theairflowcomingfromtheunit.
• Installthe unitina locationwherethepipesand thecablescan
beeasilyconnectedtotheindoorunit.
• Installthe unitonaflat, stablesurfacethatcanwithstandthe
weightofthe unit.Otherwise,theunit cangeneratenoise and
vibrationduringoperation.
• Install the unit so that the airflowis directed towards the open
area.
• Maintainsufficient clearancearoundtheoutdoorunit,especially
fromaradio,computer,stereosystem,etc.
Remote control sensor
1 m ormore
Fuse
1 m ormore
1.5 m ormore
1.5 m ormore 300 mm
200 mm
OutdoorUnit
AirGuide Duct (This product is not provided bySamsung)
Stereo Computer etc
Control
1 m ormore 1 m ormore
1.5 m ormore
1.5 m ormore
300 mm
Fuse
200 mm
OutdoorUnit
IndoorUnit
AirGuide Duct (This product is not provided bySamsung)
Stereo Computer etc
• Install the unit at a heightwhere its base can be firmly
fixed in place.
• Make sure that thewaterdripping from the drain hose
runs awaycorrectly and safely.
CAUTION
• You have just purchased a system airconditioner
and it has been installed byyourinstallation
specialist.
• This device must be installed according tothe
national electrical rules.
• Ifyouroutdoorunit exceeds a netweight of 60 kg,
do not install it on a suspendedwall, but stand it
on a floor.
• When installing the outdoorunit at the seaside, make
surethat it is not directlyexposed to sea breeze. If
you cannotfind an adequate place free from direct
sea breeze, construct a protection wall ora protective
fence.
– Install the outdoorunit in a place (such as near
buildings etc.)where it can be prevented from sea
breeze. Failure to do so may cause a damageto the
outdoorunit.
Sea Sea
Sea breeze
OutdoorUnit OutdoorUnit
Sea breeze
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGG\ YWYWTXYTW`GGG㝘㤸GXXa[`aZ^

6
InstallationProcedure
English
InstallationProcedure
• Ifyou cannot avoid installing the outdoorunit at the
seaside, construct a protection wall aroundto block
the sea breeze.
• Construct a protection wall with a solid material such
as concrete to block the sea breeze. Make sure that the
height and thewidth of thewall are1.5 times larger
than the size ofthe outdoorunit. Also, secure a space
largerthan 700 mm between the protectionwall and
the outdoorunit forexhausted airto ventilate.
Sea
Sea breeze
OutdoorUnit
Protectionwall
CAUTION
• Depending on the condition of powersupply, unstable
powerorvoltage maycause malfunction of the parts
orcontrol system. (At the ship orplaces using power
supplyfrom electric generator...etc)
• Install the unit in a placewhere watercan drain
smoothly.
• If you have anydifficultyfinding installation location as
prescribed above, contact yourmanufacturerfordetails.
• Be sure to clean the sea waterand the dust on the heat
exchangerof the outdoorunit and applya corrosion
inhibitoron it. (At least once in ayear.)
• Check the condition of the product periodically.
– Check the installation site every3 months and
perform anti-corrosion treatment such as R-Pro
supplied by SAMSUNG (Code: MOK-220SA) or
commercialwaterrepellent grease and wax, etc.,
based on the product condition.
– When the product is to be shut down fora long
period of time, such as off-peak hours, take
appropriate measures like covering the product.
• If the product installedwithin 500m of seashore, special
anti-corrosiontreatment is required.
࢘ťʪɇϑʪʀͱϩɇʀϩцͱЇθͱʀɇƊđƊƸĘθʪΧθʪϑʪϩɇϩЭʪ
forfurtherdetails.
Outdoorunitdimensions
(Unit: mm)
AType
AC018TXQREH
880
638
338
15
310
661
4949
BType
AC024TXQREH
880
310 661
798
338
15
49
CType
AC036TXQREH
940
977
998
528
537
675
330
620
360
384
DType
AC048TXQREH
940
1185
1210
558
330
360
384
620
567
675
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGG] YWYWTXYTW`GGG㝘㤸GXXa[`aZ_

7
English
InstallationProcedure
EType
AC060TXQRGH
940
1395
1420
558
330
620
360
384
5671095
Minimumclearancesforthe outdoorunit
Wheninstalling1outdoorunit
(Unit: mm)
300 ormore
1500 ormore
300 ormore 600 ormore
300 ormore
2000 ormore
1500 ormore
600 ormore
300 ormore
1500 or more 300 or
more
Wheninstalling morethan1outdoorunit
(Unit: mm)
1500
ormore 600 ormore 3000 ormore 3000 ormore 300 ormore
600
ormore 600 ormore
1500
ormore 300
ormore
600
ormore 600 ormore
1500 ormore
300
ormore
300 ormore
600
ormore 600 ormore 600 ormore
300 ormore
500 ormore500 ormore
300 ormore
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGG^ YWYWTXYTW`GGG㝘㤸GXXa[`aZ_

8
InstallationProcedure
English
InstallationProcedure
CAUTION
• The outdoorunit must be installed according to the
specified distances in orderto permit accessibility
from each side, to guarantee correct operation,
maintenance, and repairof the unit. The components
of the outdoorunit must be reachable and removable
undersafe conditions forpeople and the unit.
WARNING
• Should adopt bartype louver. Don’t use a type of rain
resistance louver.
[Bartype louver] [Rain resistance louver]
• Louverspecifications.
– Angle criteria : less than 20°
– Opening ratio criteria : greaterthan 80%
Movingtheoutdoorunitwithwirerope
1 Before carrying the outdoorunit, fasten two wire ropes
of 8 m orlonger, as shown in the figure.
2 To prevent damages orscratches effectively, insert a
piece of cloth betweenthe outdoorunit and the ropes.
3 Move the outdoorunit.
Wire rope
Plate protection cloth
Wire rope
Plate protection cloth
• The appearance ofthe unit maybe different from
the picture depending onthe model.
Step2 Fixingtheoutdoorunitin
place
Install the outdoorunit on a rigid and stable base to
prevent disturbance from anynoise caused byvibration.
When installing the unit at a height orin a location
exposed to strong winds,fix the unit securelyto a support
(i.e., awall ora ground).
Fix the outdoorunitwith anchorbolts. Make sure thatthe
ɇʀ˵ͱθɵͱϩϑɇθʪߣߡͱθ˵˝˵ʪθ˙θͱϩ˵ʪɵɇϑʪϑЇθ˙ɇʀʪࢋ
(Unit : mm)
Anchorbolt hole
AC018/024TXQREH
357
661
880
338
359
(Unit : mm)
Anchorbolt hole
AC036/048/060TXQR*H
330
620
940
360
384
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGG_ YWYWTXYTW`GGG㝘㤸GXXa[`aZ_

9
English
InstallationProcedure
CAUTION
• Install a drain outlet atthe lowest end around the base
foroutdoorunit drainage
• When installing the outdoorunit on the roof,
waterproof the unit and check the ceiling strength.
• Make sure that thewall can support theweights ofthe
rack and the outdoorunit.
• Install the rack close to the column as much as
possible.
Optional:Fixingtheoutdoorunittoawallwith
arack
Anchorbolt
Designed to cut off residual vibration from
outdoorunit to rack. (not supplied with product)
Soft rubberdesigned to cut offvibrationfrom rack towall.
(not supplied with product)
Base surface
20 mm
• Install a propergrommet in orderto reduce noise
and residualvibration transferred bythe outdoorunit
towards thewall.
CAUTION
• When installing an airguide duct, be sureto check the
following:
– The screws do not damage the copperpipe.
– The airguide duct is fixed firmly on the guard fan.
Step3 Connectingthepowercables,
communicationcable,andcontrollers
You must connect the following three electrical cables to
the outdoorunit:
• The main powercable between the auxiliary circuit
breaker and the outdoorunit.
• The outdoor-to-indoorpowercable betweenthe
outdoorunit and the indoorunit.
• The communication cable between the outdoorunit
and the indoorunit.
CAUTION
• During installation, makefirst the refrigerant
connections and then the electrical connections. If the
unit is uninstalled, first disconnectthe electrical cables
and then the refrigerant connections.
• Connectthe airconditionerto the earthing system
before making the electrical connections.
NOTE
• Especially, ifyouroutdoorunit is the one designed for
Russian and European markets, consult the supply
authority, if necessary,to estimate and reduce the
supplysystem impedance before installation.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGG` YWYWTXYTW`GGG㝘㤸GXXa[`aZ_

10
InstallationProcedure
English
InstallationProcedure
Airconditioningsystemexamples
When using earth leakage circuit breaker(ELCB) fora
single phase
OutdoorUnit IndoorUnit
Earthing
Communication cable
Main power
cable
Outdoor-to-indoorpowercable
MCCB
1ø
ELCB
1ø
ELB
OR
When using earth leakage circuit breaker(ELCB) fora
3-phase, 4-wire system (3P4W)
OutdoorUnit IndoorUnit
Earthing
Communication cable
Main power
cable
Outdoor-to-indoorpowercable
MCCB
3ø
ELCB
3ø
ELB
OR
CAUTION
• If the outdoorunit is installed in a locationvulnerable
to an electric leak orsubmergence, make sure to
install an ELCB.
Connectingthemain powercable
WhenusingELBforAC018/024TXQREH(1-phase)
1(L) 2(N) F1 F2LN
Powersupply
Electrical
componentbox
IndoorUnit
MCCB
ELB
The appearance of the unit may be different
from the picture depending on the model.
Cable clamp Cabletie
Communication
cable
Outdoorto indoor
powercable Main power cable
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGXW YWYWTXYTW`GGG㝘㤸GXXa[`aZ`

11
English
InstallationProcedure
WhenusingELBforAC036/048/060TXQR*H
1(L) 2(N) L1(R) L2(S) L3(T) N F1 F2
1(L) 2(N) L N F1 F2
Powersupply
Electrical
componentbox
IndoorUnit
MCCB
ELB
The appearance of the unit may be different
from the picture depending on the model.
AC036/048TXQREH(1-phase)
AC060TXQRGH(3-phase)
Outdoor-to-indoor
powercable
Outdoor-to-indoor
powercable 3-phase 4-wire main powercable (AC 380V) Communication cable
Cabletie
Main powercable Communication cable
Cabletie
CAUTION
• You should connect the powercable into the powercable terminal andfasten itwith a clamp.
• The unbalanced powermust be maintainedwithin 2% of supplyrating.
If the poweris unbalanced greatly, it may shortenthe life of the condenser. If the unbalanced poweris exceeded over
4% of supplyrating, the indoorunit is protected, stopped and the errormode indicates.
• To protect the product fromwaterand possible shock,you should keep the powercable andthe connection cord of
the indoorand outdoorunitswithin ducts. (with appropriate IP rating and material selection foryourapplication)
• Ensurethat main supplyconnection is made through a switch that disconnects all poles, with contact gap of a least
ߤࢋ
• Devices disconnected from the powersupplyshould be completely disconnected in the condition of overvoltage
category.
• çʪʪΧʒϑϩɇʀʪϑͱ˙ߦߡͱθͱθʪɵʪϩиʪʪΧͱиʪθʀɇɵʪɇʒʀͱЇʀɇϩͱʀɇɵʪࢋ
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGXX YWYWTXYTW`GGG㝘㤸GXXa[`aZ`

12
InstallationProcedure
English
InstallationProcedure
Mainpowerterminalblockspecifications
• AC018/024TXQREH (1-phase) • AC036/048TXQREH (1-phase)
1(L) 2(N) N
LF1 F2
Communication: M4 screwAC power: M4 screw
16.3 12 11.410.1
(Unit : mm)
1(L) 2(N) F1 F2 LN
AC power: M4 screw Communication: M4 screw
15 12 11.4
10.1
(Unit : mm)
• AC060TXQRGH (3-phase)
1(L) 2(N) L1(R) L2(S) L3(T) N F1 F2
AC power: M4 screw Communication:
M4 screw
9.95 11.55 10.1
11.4
(Unit : mm)
Mainpowercablespecifications
The powercable is not suppliedwith airconditioner.
• Select the powersupplycable in accordance with relevant local and national regulations.
• Wire size must complywith the applicable local and national code.
• Specifications forlocalwiring powercord and branchwiring are in compliance with local cord.
1-phase
Model Outdoorunit Inputcurrent(Amperes) Powersupply
Indoorunit outdoor rated Voltagerange Outdoorunit Indoor
unit Total MCA MFA
Hz Volts Min. Max. Cooling Heating
AC018TN4PEH AC018TXQREH
50 220to240 198 264
17.5 17.5 1.5 19.0 19.0 20.0
AC018TNMPEH 2.5 20.0 20.0 20.0
AC024TN4PEH AC024TXQREH 20.0 20.0 1.5 21.5 21.5 25.0
AC024TNMPEH 2.5 22.5 22.5 25.0
AC036TN4PEH
AC036TXQREH 24.0 24.0
1.5 25.5 25.5 30.0
AC036TNMPEH 2.5 26.5 26.5 30.0
AC036TNPPEH 1.8 25.8 25.8 30.0
AC048TN4PEH
AC048TXQREH 32.0 32.0
1.5 33.5 33.5 40.0
AC048TNMPEH 2.5 34.5 34.5 40.0
AC048TNPPEH 1.8 33.8 33.8 40.0
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGXY YWYWTXYTW`GGG㝘㤸GXXa[`aZ`

13
English
InstallationProcedure
3-phase
Model Outdoorunit Inputcurrent(Amperes) Powersupply
Indoorunit outdoor rated Voltagerange Outdoorunit Indoor
unit Total MCA MFA
Hz Volts Min. Max. Cooling Heating
AC060TNMPEH AC060TXQRGH 50 380to 415 342 456.5 16.1 16.1 3.8 19.9 19.9 20.0
AC060TNPPEH 1.8 17.9 17.9 20.0
NOTE
1 Voltage range
• Units are suitable foruse on electrical systems
wherevoltage supplied to unit terminal is not
below orabove listed range limits
2 Maximumallowablevoltagevariationbetween phases is 2%.
3 Wire size & type must complywith the applicable local
and national code.
• Wire size: Based on thevalue of MCA.
• Wiretype:
1-phase: 60245 IEC57(IEC) orH05RN-F(CENELEC)
grade ormore
3-phase: 60245 IEC66(IEC) orH07RN-F(CENELEC)
grade ormore
4 MFA is used to select the circuit breakerand the ground
fault circuit interrupter(earth leakage circuit breaker).
5 MCA represents maximum input current.
• MFA represents capacitywhich may accept MCA
• Abbreviations
MCA: Min. CircuitAmps. (A)
MFA: Max. Fuse Amps. (A)
6 This equipment complies with IEC 61000-3-12
provided that the short-circuit powerSsc is greater
than orequal to Ssc (*2) at the interface point between
the user’s supply andthe public system. It is the
responsibility of the installeroruserof the equipment
to ensure, byconsultation withthe distribution
network operatorif necessary, that the equipment is
connected only to a supplywith a short-circuit power
Ssc greaterthan orequal to Ssc (*2).
Model Ssc[MVA]
AC036TXQREH 0.42
AC048TXQREH 0.43
AC060TXQRGH 3.20
Silencemodecontrollerwiringdiagram
• AC018/024TXQREH
CN001
Outdoorunit
CN001 Non-voltage contact
• AC036/048/060TXQR*H
Outdoorunit
ASSY Control out
Non-voltage contact
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGXZ YWYWTXYTW`GGG㝘㤸GXXa[`aZ`

14
InstallationProcedure
English
InstallationProcedure
Connectingtheoutdoor-to-indoorpowercable andthecommunicationcable
Indoorunit:4wayCST(AC***TN4PEH)
• AC018/024TXQREH (1-phase) • AC036/048TXQREH (1-phase)
1(L) 2(N) L N F2F1
LN
F1 F2
IndoorUnit
OutdoorUnit
Cable clamp
Outdoorto indoor
powercable Cabletie
Main power
cable Communication cable
1(L) 2(N) L N F2F1
LN
F1 F2
IndoorUnit
OutdoorUnit
Outdoorto indoor
powercable
Cabletie
Main power
cable Communication cable
NOTE
• Laythe electricalwiring so that the front coverdoes not rise up when doingwiring work and attachthe front cover
securely.
• Groundwire forthe indoorunit and outdoorunit connection cable must be clamped to a soft coppertin-plated eyelet
terminalwith M4 screw hole (NOTSUPPLIED WITH UNITACCESSORIES).
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGX[ YWYWTXYTW`GGG㝘㤸GXXa[`a[W

15
English
InstallationProcedure
Indoorunit:DUCT(AC***TNMPEH)
• AC018/024TXQREH (1-phase) • AC036/048TXQREH (1-phase)
1(L) 2(N) L N F1 F2
LNF1 F2
IndoorUnit
OutdoorUnit
Cable clamp
Outdoorto indoor
powercable Main power
cable
Communication
cable
Cable
tie
Cable clamp
LNF1 F2
1(L) 2(N) L N F1 F2
IndoorUnit
OutdoorUnit
Cable clamp
Outdoorto indoor
powercable Main powercable Communication cable
Cabletie
• AC060TXQRGH (3-phase)
1(L) 2(N) L1(R) L2(S) L3(T) N F1 F2
1(L) 2(N) 1 2
V1 V2 F3 F4F2F1
OutdoorUnit
IndoorUnit
Outdoorto indoor
powercable Main power cable Communication cable
Cabletie
Cable clamp
NOTE
• Laytheelectricalwiringsothatthefrontcoverdoesnot rise upwhendoingwiringworkandattachthefrontcoversecurely.
• Groundwireforthe indoorunitand outdoorunitconnectioncablemustbeclampedtoasoftcoppertin-plated eyeletterminal
withM4screwhole(NOTSUPPLIEDWITH UNITACCESSORIES).
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGX\ YWYWTXYTW`GGG㝘㤸GXXa[`a[W

16
InstallationProcedure
English
InstallationProcedure
Indoorunit:PAC(AC***TNPPEH)
• AC036/048TXQREH (1-phase) • AC060TXQRGH (3-phase)
IndoorUnit
OutdoorUnit
1(L)
1(L) 2(N)
F1 F2
LN
F1 F2
2(N)
Cable clamp
Indoorpowercable
Main power
cable Communication cable
Cabletie
IndoorUnit
OutdoorUnit
1(L)
1(L)
F1 F2
2(N) L1(R)L2(S) L3(T) N
F1 F1
2(N)
Indoorpowercable
Main power
cable
Cabletie
Communication cable
Cable clamp
NOTE
• Laythe electricalwiring so that the front coverdoes not rise up when doingwiring work and attachthe front cover
securely.
• Groundwire forthe indoorunit and outdoorunit connection cable must be clamped to a soft coppertin-plated eyelet
terminalwith M4 screw hole (NOTSUPPLIED WITH UNITACCESSORIES).
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGX] YWYWTXYTW`GGG㝘㤸GXXa[`a[W

17
English
InstallationProcedure
Outdoor-to-indoorpowerterminalspecifications
• Connectthe cables to the terminal board usingthe compressed ring terminal.
• Covera solderless ring terminal and a connectorpart of the powercable andthen connect it.
d2
F
LE
B
d1
D
t
Silversolder
Norminal
dimensions
forcable
(mm²)
Norminal
dimensions
forscrew
(mm)
BDd1EFLd2t
Standard
dimension
(mm) Allowance
(mm) Standard
dimension
(mm) Allowance
(mm) Standard
dimension
(mm) Allowance
(mm) Min. (mm) Min. (mm) Max. (mm) Standard
dimension
(mm) Allowance
(mm) Min. (mm)
4/6 49.5 ±0.2 5.6 +0.3
-0.2 3.4 ±0.2 6.0 520.0 4.3 +0.2
00.9
815.0 928.58.4
+0.4
0
10 8 15.0 ±0.2 7.1 +0.3
-0.2 4.5 ±0.2 7.9 9 30.0 8.4 +0.4 01.15
16 8 16.0 ±0.2 9.0 +0.3
-0.2 5.8 ±0.2 9.5 13 33 .0 8.4 +0.4 01.45
25 812.0 ±0.3 11.5 +0.5
-0.2 7.7 ±0.2 11.0 15 34.0 8.4 +0.4 01.7
816.5 13 8.4
35 816.0 ±0.3 13.3 +0.5
-0.2 9.4 ±0.2 12.5 13 38.0 8.4 +0.4 01.8
822.0 1343.08.4
50 8 22.0 ±0.3 13.5 +0.5
-0.2 11.4 ±0.3 17.5 14 50.0 8.4 +0.4 01.8
70 8 24.0 ±0.4 17.5 +0.5
-0.4 13.3 ±0.4 18.5 20 51.0 8.4 +0.4 02.0
• Connectthe rated cables only.
• Connect using a driverwhich is able to applythe ratedtorque tothe screws.
• If the terminal is loose, fire may occurcaused by arc. Ifthe terminal is connected too firmly, the terminal maybe damaged.
Ɵ˝˵ϩʪ˝ϩͱθαЇʪ࣍˝˙ଗʀ࣎
M4 12.0to18.0
M5 20.0 to 30.0
• ߢĘଗߢߡ˝˙ଗʀ
CAUTION
• When connecting cables, you can connect the cables tothe electrical part orconnect them through the holes below
depending on the spot.
• Connectthe communication cable between the indoorand outdoorunits through a conduit to protect against
external forces, and feed the conduit through thewall togetherwith refrigerant piping.
• Remove all burrs atthe edge of the knock-out hole and securethe cable to the outdoorknock-out using lining and
bushingwith an electrical insulation such as rubberand so on.
• Must keep the cable in a protection tube.
• Keep distances of 50mm ormore between powercable and communication cable.
• When the cables are connected through the hole, remove the Plate bottom.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGX^ YWYWTXYTW`GGG㝘㤸GXXa[`a[W

18
InstallationProcedure
English
InstallationProcedure
Outdoor-to-indoorpowerandcommunication
cablesspecifications
• Indoorunit: 4wayCST(AC***TN4PEH)
PAC (AC***TNPPEH)
Indoorpowersupply
Powersupply Max/Min(V) Indoorpowercable
ߢעࡡߣߣߡϩͱߣߥߡǤࡡߦߡ²і ±10% ߡࢋߨߦࠟࡡߤиθʪϑ
Communicationcable
ߡࢋߨߦࠟࡡߣиθʪϑ
• Indoorunit: Duct (AC***TNMPEH)
Indoorpowersupply
Powersupply Max/Min(V) Indoorpowercable
ߢעࡡߣߣߡϩͱߣߥߡǤࡡߦߡ²і ±10% ߢࢋߦࠟࡡߤиθʪϑ
Communicationcable
ߡࢋߨߦࠟࡡߣиθʪϑ
• Powersupplycords of parts of appliances foroutdoor
use shall not be lighterthan polychloroprene sheathed
flexible cord.
– Code designation
[1-phase] IEC: 60245 IEC 57 / CENELEC: H05RN-F
grade ormore
[3-phase] IEC: 60245 IEC 66 / CENELEC: H07RN-F
grade ormore
• When installing the indoorunit in a computerroom
ornet work room, use the double shielded (tape
aluminium / polyesterbraid + copper) cable of
FROHH2R type.
Step4 Optional:Extendingthe
powercable
1 Prepare the following tools.
Tools Spec Shape
Crimping pliers MH-14
Connection sleeve
(mm) 20xØ6.5 (HxOD)
Insulationtape Width19
mm
Contraction tube
(mm) 70xØ8.0 (LxOD)
2 As shown in thefigure, peel offthe shields from the
rubberand wire of the powercable.
• Peel off 20 mm of cable shields fromthe pre-
installed tube.
Powercable (Unit: mm)
20 20 20
60
120
180
180
120
60
20 20 20
Pre-installed
tube forthe
powercable
CAUTION
• Forinformation aboutthe powercable specifications
forindoorand outdoorunits, refertothe installation
manual.
• Afterpeeling off cablewires from the pre-installed
tube, insert a contractiontube.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGX_ YWYWTXYTW`GGG㝘㤸GXXa[`a[W

19
English
InstallationProcedure
3 Insert both sides of corewire of the powercable into
the connection sleeve.
• Method1: Push the corewire into the sleeve from
both sides.
• Method2: Twistthewire cores togetherand push it
into the sleeve.
Method1
Connection sleeve Connection sleeve
Method2
CAUTION
• If cablewires are connected without using connecting
sleeves, theircontact area becomes reduced, or
corrosion develops on the outersurfaces ofthewires
(copperwires) overa long time. This may cause an
increase of resistance (reduction of passing current)
and consequentlymayresult in a fire.
4 Using a crimping tool, compress the two points and
flip it overand compress anothertwo points in the
same location.
• The compression dimension should be 8.0.
Compression
dimension
• Aftercompressing it, pull both sides of thewire to
make sure it is firmlypressed.
Method1
Compress it 4 times.
5 mm 5 mm
Compress it 4 times.
Method2
5 Wrap itwith the insulation tape twice ormore and
position your contraction tube in the middle of the
insulation tape.
Method1 Method 2
40 mm
Insulationtape Insulation tape
35 mm
6 Apply heat to the contraction tube to contract it.
Method1 Contractiontube Contractiontube Method2
7 Aftertube contractionwork is completed,wrap itwith
the insulation tape to finish.
Three ormore layers of insulation are required.
Method1 IInsulation tape IInsulationtape Method2
CAUTION
• Make sure that the connection parts are not exposed
to outside.
• Be sure to use insulation tape and a contraction tube
made of approved reinforced insulating materials
that havethe same level ofwithstandvoltagewith
the powercable. (Complywith the local regulations on
extensions.)
WARNING
• In case of extending the electricwire, please DO NOT
use a round-shaped Pressing socket.
– Incompletewire connections can cause electric
shock ora fire.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGX` YWYWTXYTW`GGG㝘㤸GXXa[`a[X

20
InstallationProcedure
English
InstallationProcedure
Step5 Connectingtherefrigerant
pipe
Items Maximumallowablelength[m]
Applicableoutdoor
unitmodels AC018TXQREH AC024TXQREH
AC036TXQREH AC048TXQREH AC060TXQRGH
Mainpipe(L1) 30 50 75
Max.height
differencebetween
outdoorandindoor
units(h1) 20 30 30
ߢ
øࠔ
˵ࠔ
indoor
outdoor
• Tempergrade and minimum thickness ofthe
refrigerant pipe
Outerdiameter
[mm] Minimumthickness [mm] Tempergrade
ø 6.35 0.7
C1220T-O
ø 9.52 0.7
ø12.70 0.8
ø15.88 1.0
ø15.88 0.8 C1220T-1/2H
OR
C1220T-H
ø19.05 0.9
ø 22.23 0.9
CAUTION
• Be sureto use C1220T-1/2H (Semi-hard) pipe formore
ϩ˵ɇŝߢߪࢋߡߦࢋÃ˙цͱЇЇϑʪAߢߣߣߡƟࣗĮ࣍Ɗͱ˙ϩ࣎ΧΧʪ˙ͱθ
ŝߢߪࢋߡߦࡡϩ˵ʪΧΧʪɇцɵʪɵθͱʪࡡи˵ʀ˵ʀɇθʪϑЇϩ
in an injury.
Makeatleast one round:
Itwillreducenoiseandvibration
Afterconnectiong
thepipes,block
thepart .
(A)Heat radiation holes
Donot blockthe holes.
• The appearance ofthe unit maybe different from the
diagram depending on the model.
CAUTION
Pipe outlet
• Cut the pipe outletto the exact pipe size. In addition,
remove foreign substances and burres aroudthe
outlet.
• ťʪθ˙ͱθʀЇϩϩ˝иϩ˵ͱцɇʀЇϩϩʪθ࣍ʪуࢋΧΧʪθ࣎ɇʒ
nevertapwith a hammernearthe pipe outlet.
Otherwise, it maycause product damage such as
warping of the cabinet.
• Afterconnecting the pipeswith Pipe outlet, plug the
space aroundthe pipes.
• Afterconnecting the pipes, proceed exactlyas directed
in the guide to prevent interference with the internal
parts.
• Tighten the nuts to the specified torques. If
overtightened,the nuts could be broken so refrigerant
mayleak.
• Protect orenclose refrigerant tubing to avoid
mechanical damage.
• Afterinstalling pipes, block the unused knock hole
to prevent small animal from entering. However, the
radiant heat hole(A) should be able to intake air.
ki]_TW`ZZ`hTWYptwhjG⴬⢰㫴G㐘㞬ὤG㢨㬅䏬䑀䇘㏘䇸pxluUGGGYW YWYWTXYTW`GGG㝘㤸GXXa[`a[X
