Samsung AC071TN4PKC User manual

Airconditioner
Installationmanual
AC***TN4PKC
• Thank you forpurchasing this Samsung airconditioner.
• Before operating this unit, please read this manual carefullyand retain it forfuture reference.

2English
Contents
SafetyInformation 3
SafetyInformation 3
InstallationProcedure 5
Installation Procedure 5
Step1 Checking and preparing accessories 5
Step 2 Choosing the installation location 5
Step 3 Optional: Insulating the bodyof the indoorunit 8
Step 4 Installing the indoorunit 8
Step 5 Purging inert gas from the indoorunit 10
Step 6 Cutting and flaringthe pipes 10
Step 7 Connecting the assemblypipes to the refrigerant pipes 11
Step 8 Performing the gas leak test 12
Step 9 Insulating the refrigerant pipes 12
Step10 Installing the drain hose and drain pipe 13
Step11 Performing the drainage test 15
Step12 Connecting the powerand communication cables 15
Step13 Optional: Extending the powercable 17
Step14 Setting the indoorunit addresses and the installation options 18
Appendix 36
Troubleshooting 36

3
English
SafetyInformation
WARNING
• Hazards orunsafe practicesthat may result in severe
personal injuryordeath.
CAUTION
• Hazards orunsafe practicesthat may result in minor
personal injuryorpropertydamage.
• Carefully followthe precautions listed belowbecause
theyare essential to guaranteethe safety of the
equipment.
WARNING
• Always disconnect the airconditionerfrom the power
supplybefore servicing it oraccessing its internal
components.
• Verifythat installation and testing operations are
performed byqualified personnel.
• Verifythat the airconditioneris not installed in an
easilyaccessible area.
Generalinformation
WARNING
• Carefully read the content of this manual before installing
the airconditionerand store the manual in a safe place in
orderto be ableto use it as reference afterinstallation.
• Formaximum safety, installers should always carefullyread
the followingwarnings.
• Store the operation and installation manual in a safe
location and rememberto hand it overto the newownerif
the airconditioneris sold ortransferred.
• This manual explains howto install an indoorunitwith a
split systemwith two SAMSUNG units. The use of other
types of unitswith different control systems maydamage
the units and invalidate thewarranty. The manufacturer
shall not be responsible fordamages arising from the use of
non compliant units.
• The manufacturershall not be responsible fordamage
originating from unauthorized changes orthe improper
connection of electric and requirements set forth in the
“Operating limits” table, included in the manual, shall
immediatelyinvalidate the warranty.
• The airconditionershould be used onlyforthe applications
forwhich it has been designed: the indoorunit is not
suitable to be installed in areas used forlaundry.
• Do not use the units if damaged. If problems occur, switch
the unit off and disconnect it from the powersupply.
• In orderto prevent electric shocks,fires orinjuries, always
stop the unit, disablethe protection switch and contact
SAMSUNG’s technical support if the unit produces smoke, if
the powercable is hot ordamaged orif the unit isvery noisy.
• Always rememberto inspect the unit, electric connections,
refrigerant tubes and protections regularly. These
operations should be performed byqualified personnel only.
• The unit contains moving parts,which should always be
kept out of the reach of children.
• Do not attemptto repair, move, alterorreinstall the unit. If
performed byunauthorized personnel, these operations may
cause electric shocks orfires.
• Donotplacecontainerswithliquidsorotherobjects ontheunit.
• All the materials usedforthe manufacture and packaging of
the airconditionerare recyclable.
• The packing material and exhaust batteries of the remote
controller(optional) must be disposed of in accordancewith
current laws.
• Theairconditionercontainsa refrigerantthat hastobedisposed
ofas specialwaste.Attheendofitslifecycle,theairconditioner
mustbe disposedofinauthorisedcentresorreturnedtothe
retailersothatitcanbe disposedofcorrectlyand safely.
• Wearprotective equipment (such as safetygloves,
goggles, and headgear) during installation and
maintenanceworks. Installation/repairtechnicians maybe
injured if protective equipment is not properly equipped.
Installingtheunit
WARNING
IMPORTANT:When installingthe unit,alwaysrememberto
connectfirsttherefrigeranttubes,thentheelectricallines.
• Always disassemble the electric lines before the refrigerant
tubes.
• Upon receipt, inspect the product toverifythat it has not been
damaged during transport. If the product appears damaged,
DO NOTINSTALL it and immediately report the damage to the
carrierorretailer(if the installerorthe authorized technician
has collectedthe material from the retailer.)
SafetyInformation

4
SafetyInformation
English
SafetyInformation
• Aftercompleting the installation, always carryout a
functional test and provide the instructions on howto
operatethe airconditionerto the user.
• Do not use the airconditionerin environments with
hazardous substances orclose to equipment that release
freeflames to avoid the occurrence of fires, explosions or
injuries.
• Do not install the product in a place where thermohygrostat
is needed (such as serverroom, machineryroom, computer
room, etc.) Those places do not provide guaranteed
operation condition ofthe product therefore performance
can be poorin these places.
• Do not install the product in a ship ora vehicle (such as a
campervan). Salt,vibration orotherenvironmental factor
maycause the product malfunction, electric shock orfire.
• Ourunits should be installed in compliancewith the spaces
shown in the installation manual,to ensure accessibility
from both sides and allowrepairs ormaintenance
operations to be carried out. The unit’s components should
be accessible and easyto disassemblewithout endangering
people and objects.
Forthis reason,when provisions of the installation manual
are not compliedwith, the cost required to access and repair
the units (in SAFETY CONDITIONS, as set out in prevailing
regulations)with harnesses, ladders, scaffolding orany
otherelevation systemwill NOTbe considered part of the
warrantyand will be chargedto the end customer.
Powersupplyline,fuseorcircuit
breaker
WARNING
• Always make sure that the powersupplyis compliant with
current safetystandards. Always install the airconditionerin
compliancewith current local safetystandards.
• Always verify that a suitable grounding connection is
available.
• Verifythat the voltage and frequency of the powersupply
complywith the specifications and that the installed power
is sufficient to ensure the operation of anyotherdomestic
appliance connected tothe same electric lines.
• Alwaysverifythat the cut-off and protection switches are
suitablydimensioned.
• Verifythat the airconditioneris connected tothe power
supplyin accordance with the instructions provided in the
wiring diagram included in the manual.
• Alwaysverifythat electric connections (cable entry, section
of leads, protections…) are compliant withthe electric
specifications andwith the instructions provided in the
wiring scheme.Alwaysverifythat all connections comply
with the standards applicable tothe installation of air
conditioners.
• Devices disconnected from the powersupply should be
completely disconnected in the condition of overvoltage
category.
• Be sure notto perform powercable modification, extension
wiring, and multiplewire connection.
– It maycause electric shock orfire due to poorconnection,
poorinsulation, orcurrent limit override.
– When extensionwiring is required due to powerline
damage, referto "Step13 Optional: Extendingthepower
cable" in the installation manual.
CAUTION
Makesurethatyou earththe cables.
• Do not connect the earthwire to the gas pipe,waterpipe,
lighting rod ortelephonewire. If earthing is not complete,
electric shock orfire mayoccur.
Installthe circuitbreaker.
• If the circuit breakeris not installed, electric shock orfire
mayoccur.
Makesurethat thecondensedwaterdrippingfromthe
drainhose runsoutproperlyand safely.
Install thepowercableand communication cable of
the indoorand outdoorunit at least1m awayfrom the
electricappliance.
Install theindoorunit awayfromlighting apparatus
usingthe ballast.
• If you use the wireless remote control, reception errormay
occurdue to the ballast of the lighting apparatus.
SafetyInformation

5
English
InstallationProcedure
InstallationProcedure
Step1 Checkingandpreparing
accessories
The following accessories are supplied with the indoor
unit.
Insulationpipe(3ea) Cable-tie(6 ea)
Drainhose (1ea) Installationmanual(1ea)
Clamp(1ea) Usermanual (1 ea)
Installationtemplate(1 ea) Dimensiongauge(1 ea)
Step2 Choosingtheinstallation
location
Installationlocationrequirements
• There must be no obstacles nearthe airinlet and
outlet.
• Install the indoorunit on a ceiling that can support its
weight.
• Maintain sufficient clearance around the indoorunit.
• Before installing the indoorunit, be sure tocheck
whetherthe chosen location iswell-drained.
• The indoorunit must be installed such that it is beyond
public access and is not touchable byusers.
• Rigidwallwithoutvibration.
• Where it is not exposed to direct sunshine.
• Wherethe airfiltercan be removed and cleaned easily.
Do notinstallthe airconditionerin following
places.
• Placewhere there is mineral oil orarsenic acid. Resin
parts flame and the accessories may drop orwater
mayleak. The capacityof the heat exchangermay
reduce orthe airconditionermaybe out of order.
• The placewhere corrosive gas such as sulphuric acid
gas generatesfrom thevent pipe orairoutlet.
• The copperpipe orconnection pipe maycorrode and
refrigerant may leak.
• The placewhere there is a machine that generates
electromagneticwaves. The airconditionermaynot
operate normally due to control system.
• The placewhere there is a dangerof existing
combustible gas, carbonfibre orflammable dust.
• The placewhere thinnerorgasoline is handled. Gas
mayleak and it maycause fire.

6
InstallationProcedure
English
InstallationProcedure
Indoorunitdimensions
(Unit: mm)
Category Square panel Circularpanel
Front
1000
Ceiling opening dimension
960 (950 - 960)
Ceiling opening dimension
960 (950 - 960)
358
116
1050
883
Large+,
Large
385 404 Refrigerant
pipe
Wire insert hole
Drain hose
connector
128
166
66
181
190
317
357
94
100
153
162 289
138
Small
385
66166
128
181
190
233
404 Refrigerant
pipe
Drain hose
connector
Wire insert hole
94 138
100
153
162 205
Common
646
646
942
80
787
H1
ø100
²ߣøɇθ˝ʪࡥøɇθ˝ʪࡤߣߪߢࡥƊɇࡤߣߧߢ
²ߤøɇθ˝ʪࡥøɇθ˝ʪࡤߣߧߤࡥƊɇࡤߣߤߤ
H2
Square panel Circularpanel

7
English
InstallationProcedure
Model AC071TN4PKC AC100TN4PKC AC120TN4PKC AC140TN4PKC
Netdimension(W×D×H) mm
947x947x 281 947x947x 365 947x947x365 947x947x 365
Liquidpipeconnection mm 6.35 9.52 9.52 9.52
Gaspipeconnection mm 15.88 15.88 15.88 15.88
Drainhose connection mm Outerdiameter: 32, innerdiameter: 25
• The circularpanel is bydefault available in exposed
installation.
• Make inspection holes onthe ceiling foreasier
installation and maintenance, as shown in the
following table. (The size of an inspection hole must be
at least 450 mm x 450 mm.)
• A suspended ceiling structure can substitute forthe
inspection holes.
Category
Inspectionhole
Recessedinstallation Exposed
installation
Integrated suspended
Squarepanel 1 ea -
Circularpanel 2 ea
• Forthe recessed installation ofthe circularpanel
(Unit: mm)
1050
883
ø1010 to1020
Ceiling opening diameter
ø1010 to1020
Inspection hole
Indoorunit
display
Refrigerant
pipe
Inspection hole
Connection part of the
drain hose
NOTE
• The clearance between the panel and the inspection
hole is15 to 20 mm on a side.
Spacingrequirements
A
A
A
A
A :1500 mm ormore
Indoorunit
'C'
2500 mm ormore
Obstruction
10 mm
20 mm
1500 mm or
more
(Unit: mm)
Model AC071TN4PKC AC100TN4PKC AC120TN4PKC AC140TN4PKC
C261 345 345 345

8
InstallationProcedure
English
InstallationProcedure
CAUTION
• The indoorunit must be installed according to the
specified distances in orderto permit accessibility
from each side, to guarantee correct operation,
maintenance, and repairof the unit.
The components of the indoorunit must be reachable
and removable undersafe conditions forpeople and
the unit.
• Do not holdthe dischargewhile carrying the indoor
unit to avoid the possibility of breakage.
• You must hold the hangerplate on the cornerand
carrythe indoorunit.
Step3 Optional:Insulatingthebody
oftheindoorunit
Ifyou install a cassette type indoorunit on the ceiling
when temperature is over27°C and humidity is over
80%,you must applyan extra10 mm thick polyethylene
insulation ora similartype of insulation tothe body of the
indoorunit.
Cut away the partwhere pipes are pulled outforthe
insulatingwork.
A
Insulate the end ofthe pipe and some curved area by
using separate insulator.
NOTE
• A: Reference forthe outercircumference of the unit
(When insulating the bodyof the indoorunit,
use A as the reference for its outercircumference.)
(Unit: mm)
Indoorunittypeand models Dimensions
360 cassette type <S>
(947 x 947 x 281) AC071TN4PKC 2610 x130
ߥߨߢʀɇϑϑʪϩϩʪϩцΧʪø
(947 x 947 x 365)
AC100TN4PKC
2610 x 215AC120TN4PKC
AC140TN4PKC
Step4 Installingtheindoorunit
When deciding on the location of the airconditionerthe
following restrictions must be taken into account.
1 Determinethe positions of the pipe and the drain hose
hole as shown inthe pattern sheet, and drill the hole
with an innerdiameterof14 mm.
NOTE
• Since the diagram is made of paper, it mayshrink
orstretch slightlydue to temperature orhumidity.
Forthis reason, before drilling the holes, be sure
to maintain the correct dimensions between the
markings.

9
English
InstallationProcedure
2 Performthe following steps to install inspection holes
in accordance with the panel type.
a Forthe recessed installation ofthe square panel.
• Install an inspection hole to the direction of
connection parts of the refrigerant pipe and the
drain hose. (1 point)
Refrigerant pipe
Inspection hole Indoorunit
display
b Forrecessed installation ofthe circularpanel
• Install inspection holes to both directions ofthe
connection part of the refrigerant pipe and the
drain hose and of the indoorunit display.
(2 points)
Refrigerant pipe
Inspection hole
Indoorunit display
Inspection hole
3 Insert bolt anchors, use existing ceiling supports or
construct a suitable support as shown in figure.
Concrete
Insert
Suspension bolt (M10) - eld supply
Hole in anchor
Hole in plug
4 Install the suspension bolts, depending on the ceiling
type.
Ceiling support
CAUTION
• Make sure that the ceiling is strong enough to support
theweight of the indoorunit. Before hanging the unit,
test the strength of each attached suspension bolt.
• If the length ofthe suspension bolt is more than1.5 m,
you are required to preventvibration.
5 Screweight pairs of nuts and washers to the
suspension bolts, making space forhanging the indoor
unit.
CAUTION
• You must install all of the suspension rods.
• It is important to leave sufficient space in thefalse
ceiling to allowaccess formaintenance orrepairs to
the drainage pipe connection,the refrigerant pipe
connection, orto remove the unit if necessary.
6 Hang the indoorunit to the suspension bolts between
two nuts. Cut a pad stopperand place it on the
suspension bolts to hold thewashers. Removethe
stopperand screwthe nuts tofix the unit.
1
2
2

10
InstallationProcedure
English
InstallationProcedure
7 Adjust the unitto the appropriate position, taking into
account the installation area forthe front panel.
• Place the pattern sheet onthe indoorunit.
• Adjust the space between the ceiling and the
indoorunit by using a dimension gauge.
• Fix the indoorunit securelyafteradjusting the level
of the unit byusing a leveller.
• Removethe pattern sheet and install the front
panel.
Indoorunit
Ceiling
Gauge of
dimensions Forthe recessed installation ofthe
square panel:11.5 mm
Forthe recessed installation ofthe
circularpanel: 41.5 mm
Step5Purginginertgasfromthe
indoorunit
The indoorunit comes with nitrogen gas (inert gas)
charged atthe factory. Therefore, all inert gas must be
purged before connecting the assembly piping.
Unscrewthe pinch pipe atthe end of eachrefrigerant
pipe.
Insulator Gas side
Liquid side
NOTE
• To prevent dirt orforeign objects from getting into the
pipes during installation, do not remove the pinch pipe
completely untilyou are readyto connect the piping.
Step6 Cuttingandflaringthepipes
1 Make sure that you havethe required tools available:
pipe cutter, reamer, flaring tool, and pipe holder.
2 Ifyou wishto shorten the pipes, cut themwith a pipe
cutter, ensuring that the cut edge remains at a 90°
angle to the side of the pipe. Referto the illustrations
belowforexamples of edges cut correctlyand
incorrectly.
Pipe cutter
Pipe Oblique Rough Burr
3 To prevent anygas from leaking out, remove all burrs
at the cut edge of the pipe, using a reamer.
4 Slide a flare nut on to the pipe and modifythe flare.
D
Flare
A
90° ± 2°
45° ± 2°
Pipe
L
R 0.4to 0.8 mm
Flare
D
OuterDiameter(D) Depth (A) Flaredimension (L)
Ø 6.35 mm 1.3 mm 8.7 to 9.1 mm
Ø 9.52 mm 1.8 mm 12.8 to13.2 mm
Ø12.70 mm 2.0 mm 16.2 to16.6 mm
Ø15.88 mm 2.2 mm 19.3 to19.7 mm
Ø19.05 mm 2.2 mm 23.6 to 24.0 mm

11
English
InstallationProcedure
5 Check that the flaring is correct, referring to the
illustrations belowforexamples of incorrect flaring.
Correct Inclined Damaged
Surface Uneven Thickness
Cracked
Step7 Connectingtheassembly
pipestotherefrigerantpipes
Therearetworefrigerant pipesof different diameters:
• A smallerone forthe liquid refrigerant.
• A largerone forthe gas refrigerant. The inside of
copperpipe must be clean and has no dust.
1 Removethe pinch pipe on the pipes and connect the
assemblypipes to each pipe, tightening the nuts, first
manuallyand thenwith a torquewrench, a spanner
applying the following torque.
Spanner Torque
wrench
Flare nut
Union
3
3
2
1
Outerdiameter(mm) Torque(N•m)
Ø 6.35 14 to18
Ø 9.52 34 to 42
Ø12.70 49to 61
Ø15.88 68 to 82
Ø19.05 100to120
(1 N•m=10 kgf•cm)
NOTE
• If the pipes must be shortened, see Step6 Cutting
andflaring thepipes on page 10.
2 Be sureto use an insulatorthick enough to coverthe
refrigerant tube to protect the condensate wateron
the outside of the pipe falling onto thefloorand to
improve the efficiencyof the unit.
3 Cut off anyexcessfoam insulation.
4 Make sure that there are no cracks orwaves on the
bent area.
5 Itwould be necessaryto double the insulation
thickness (10 mm ormore) to prevent condensation
even onthe insulatorwhen if the installed area is
warm and humid.
CAUTION
• Connectthe indoorand outdoorunits using pipeswith
flared connections (not supplied). Forthe lines, use
insulated, unwelded, degreased and deoxidized copper
pipe (Cu DHP type to ISO1337 orUNI EN12735-1),
suitable foroperating pressures of at least 4.2 MPa
and fora burst pressure of at least 20.7 MPa. Copper
pipe forhydro-sanitaryapplications is completely
unsuitable.
• Forsizing and limits (height difference, line length,
max. bends, refrigerant charge, etc.) seethe outdoor
unit installation manual.
• All refrigerant connection must be accessible, in order
to permit eitherunit maintenance orremoving it
completely.
• If the pipes require brazing, make sure that oxygen
free nitrogen (OFN) isflowing throughthe system.
• Nitrogen blowing pressure range is 0.02to 0.05 MPa.

12
InstallationProcedure
English
InstallationProcedure
Step8 Performingthegasleaktest
To identify potential gas leaks on the indoorunit, inspect
the connection area of each refrigerant pipe using a leak
detectorforR-410A.
Before recreating thevacuum and recirculating the
refrigerant gas, pressurize thewhole systemwith
nitrogen (using a cylinderwith a pressure reducer) at
a pressure above 4 MPa in orderto immediatelydetect
leaks on the refrigerant fittings.
Madevacuum for15 minutes and pressurizing system
with nitrogen.
Insulator Gas side
Liquid side
Step9 Insulatingtherefrigerantpipes
Onceyou have checked that there are no leaks in the
system, you can insulate the piping and hose.
1 To avoid condensation problems, place Acrylonitrile
Butadien Rubberseparatelyaround each refrigerant pipe.
No gap
NBR
NOTE
• Always make the seam of pipes face upwards.
2 Wind insulating tape around the pipes and drain hose
avoiding compressing the insulation too much.
Indoorunit
Insulation coverpipe
Be sure to overlap the insulation.
Insulation pipe
CAUTION
• Be sure to wrap insulationtightlywithout any gaps.
3 Finishwrapping insulating tape aroundthe rest of the
pipes leading to the outdoorunit.
4 The pipes and electrical cables connecting the indoor
unitwith the outdoorunit must be fixed to thewall
with suitable ducts.
CAUTION
• Make sure that all refrigerant connection must be
accessibleforeasy maintenance and detachment.
• Install the insulation not to getwiderand use the
adhesives on the connection part of it to prevent
moisture from entering.
• Wind the refrigerant pipewith insulation tape if it is
exposed to outside sunlight.
• Install the refrigerant pipe respecting that the
insulation does not get thinneron the bent part or
hangerof pipe.
• Add the additional insulation ifthe insulation plate
gets thinner.
Hanger
Refrigerant pipe insulation
Additional insulation
a
a x 3
5 Selectthe insulation of the refrigerant pipe.
• Insulate the gas side and liquid side pipe, noting
the insulation thickness that must differaccording
to the pipe size.
• Standard: Less than an indoortemperature
of 30°C,with humidityat 85%. If installing in
a high humidityenvironment, use one grade
thickerinsulatorby referring to the table below.
If installing in an unfavourable environment, use
thickerone.
• The heat-resistance temperature of the insulator
must be morethan120°C.

13
English
InstallationProcedure
Pipe Pipesize
(mm)
Insulationtype(heating/cooling)
Remarks
Standard
(Lessthan30°C,85%) Highhumidity (Over30°C, 85 %)
EPDM,NBR(mm)
Liquid
pipe Ø 6.35 to Ø9.52 9t 9t
The internal
temperature is
higherthan120 °C.
Ø12.7 to Ø19.05 13t 13t
Gas pipe
Ø 6.35 13t 19t
Ø 9.52
19t 25t
Ø12.70
Ø15.88
Ø19.05
• When installing insulation in the places and
conditions below, use the same insulation that is
used forhigh humidity conditions.
<Geologicalcondition>
High humiditylocations such as shorelines, hot
springs, lake orriversides, and ridges (when part of
the building is covered byearth and sand)
<Operationpurposecondition>
Restaurant ceiling, sauna, swimming pool etc.
<Buildingconstructioncondition>
Ceilings frequently exposed to moisture and cooling
are not covered. Forexample, pipes installed at a
corridorof a dormitoryand studio ornearan exit that
opens and closes frequently.
Places (where the pipes are installed) that are highly
humid due to a lack ofventilation.
Step10 Installingthedrainhoseand
drainpipe
1 Push the supplied drain hose as faras possible over
the drain socket.
2 Tighten the metal clamp as shown in the picture.
3 Wrapthe supplied large sealing pad overthe metal
clamp and drain hose to insulate and fix itwith clamps.
4 Insulate the complete drain piping inside the building
(field supply).
If the drain hose cannot be sufficientlyset on a slope,
fit the hosewith drain raising piping (field supply).
5 Push the drain hose upto insulation when connecting
the drain hose to drain socket.
Large seailng pad
Drain socket
Metal clamp Drain hose
Drain pipe
Be sure to bondthe drain
hose and the main pipe.
PVC Tube Joint
Ǥťߤߧ࣑ĮUࡤߥߤࡥÃUࡤߤߧ࣒
Drain pipe
Drain hose

14
InstallationProcedure
English
InstallationProcedure
CAUTION
Check that the indoorunit is levelwith the ceiling by
using the leveller.
• Install airventilation to drain condensation smoothly.
Airventilation
Ceiling
• If it is necessaryto increase the height ofthe drain
pipe, install the drain pipe straight within 300 mm
fromthe drain hose port. If it is raised higherthan
550 mm, there maybe waterleaks.
Band joint
Drain hose
Ceiling
20 mm ormore
300 mm orless
550 mm orless
• Do not give the hose an upward gradient beyond the
connection port. Thiswill cause waterto flow backwards
when the unit is stopped, resulting in waterleaks.
Undergradient
Ceiling
• Do not applyforce to the piping on the unit sidewhen
connecting the drain hose. The hose should not be
allowed to hang loose from its connection tothe unit.
Fasten the hose to awall, frame orothersupport as
close to the unit as possible.
Support pieces 1 to1.5 m
1/100 ormore
Ceiling
• Install horizontally.
Be horizontal
Indoorunit
Flexible hose
• Max. allowable axis gap.
Indoorunit
Max. 20 mm
• Max. allowable bending angle.
Indoorunit
Max. 30°
NOTE
• If a concentrated drain pipe is installed, referto the
figure below.
Full thread bolt hanger
Main airvent
(must be installed)
Centralized horizontal drain pipe
(more than1/100 slope)
Main drain pipe
200 mm
ormore
300 to
550 mm
1000 to1500 mm

15
English
InstallationProcedure
Step11 Performingthedrainagetest
1 Do a leaktest at the connection part of the flexible
hose and the drain pipe:
a Connect a general hose to the connection part of
the flexible hose of the indoorunit, and pourin
somewater.
Waterleakage
check part
Flexible hose
Hose
b Afterpouring some water, reassemblethe rubber
cap on the connection part of a flexible hose of
the indoorunit and firmlytighten itwith a band to
prevent leakage.
c Check the leak test at the part where the adhesive
forthe flexible hose and the drain pipe is used.
CAUTION
• The leak test must be performed forat least 24 hours.
2 Check the condensed waterdrainage:
a Pourabout 2 liters ofwaterinto the indoorunit
drain pan as shown inthe picture.
b When the electric cable connection is completed
• Turn on the indoorunit and outdoorunit.
• Operate inthe Cool mode.
CAUTION
• Onlyin the Cool mode,you can check the correct
operation of the drain pump.
When the electric cable connection has not been
completed
• Remove the control box coverof the indoorunit.
• Connectthe powersupply(220V, 60 Hz) to the L
and N terminals.
• Reassemble the control box coverand turn on the
indoorunit.
CAUTION
• When the float switch is not detected due to
insufficientwateron the drain pan, the drain
pumpwill not work.
• If the powersupply is directlyconnected tothe L
and N terminals, communication errormessage
might appear.
• Aftercompleting the drainage check, turn the unit
off and disconnect the powersupply.
• Reassemble the control box cover.
c Checkwhetherthe drain pumpworks correctly.
d Checkwhetherthe drainage is performing
correctlyat the end of the drain pipe.
e Check forleakage at the drain pipe and drain pipe
connection part.
f When leakage occurs, check whetherthe indoor
unit is level and check the drain hose connection
part, drainpipe connection part and drain pump
connection.
g When the drainage check is completed and
the condensedwaterremains on the drain pan,
remove thewater.
Step12 Connectingthepowerand
communicationcables
CAUTION
• Always rememberto connect the refrigerant pipes
before performing the electric connections.
When disconnecting the system, always disconnect
the electric cables before disconnecting the
refrigerant pipes.

16
InstallationProcedure
English
InstallationProcedure
CAUTION
• Always rememberto connect the airconditionerto
the grounding system before performing the electric
connections. Use a crimp ring terminal at the end of
eachwire.
The indoorunit is powered through the outdoorunit by
means of a H07 RN-F connection cable (ora more power
model), with insulation in synthetic rubberand a jacket
in polychloroprene (neoprene), in accordance withthe
requirements specified in the standard EN 60335-2-40.
1 Removethe screwon the electrical component box
and remove the coverplate.
2 Route the connection cordthrough the side of the
indoorunit and connect the cable to the terminals
referto the figure below.
3 Route the otherend of the cable to the outdoorunit
throughthe ceiling & the hole on thewall.
4 Reassemble the electrical component box cover,
carefullytightening the screw.
1phase
Indoorunit
Outdoorunit
Indoorpower Main powercable Communication cable
Indoorpowersupply
Powersupply Max/Min(V) Indoorpowercable
220 to 240V, 60 Hz ±10% ߢ࢏ߩߧࠌࡥߥиθʪϑ
Communicationcable
0.75 mm², 2wires
9.8 7.5
19.0
13.8
12.6 9.0
(Unit: mm)
ACpower:M4screw Communication:M3.5 screw
Tighteningtorque(kgf•cm)
M3.5 8.0to12.0
M4 12.0to18.0
• 1 N·m =10 kgf·cm
• Powersupplycords of parts of appliances foroutdoor
use shall not be lighterthan polychloroprene sheathed
flexible cord. (Code designation IEC:60245 IEC 57 /
CENELEC: H05RN-F orIEC:60245 IEC 66 / CENELEC:
H07RN-F)
• Since it has the external powersupply, referto the
outdoorunit installation manual forMAIN POWER.
CAUTION
• When installing the indoorunit in a computerroom or
a serverroom, use the double shielded communication
ʀɇɵʪ࣑ϩɇΧʪɇЇЇࢩΧͱцʪϑϩʪθɵθɇʒʀͱΧΧʪθ࣒ͱ˙
FROHH2R type.

17
English
InstallationProcedure
Step13 Optional:Extendingthe
powercable
1 Prepare the following tools.
Tools Spec Shape
Crimping pliers MH-14
Connection sleeve
(mm) 20xØ6.5 (HxOD)
Insulationtape Width19
mm
Contraction tube
(mm) 70xØ8.0 (LxOD)
2 As shown in thefigure, peel off the shieldsfrom the
rubberand wire of the powercable.
• Peel off 20 mm of cable shields fromthe pre-
installed tube.
Powercable (Unit: mm)
20 20 20
60
120
180
180
120
60
20 20 20
Pre-installed
tube forthe
powercable
CAUTION
• Forinformation about the powercable
specifications forindoorand outdoorunits, referto
the installation manual.
• Afterpeeling off cable wires from the pre-installed
tube, insert a contractiontube.
3 Insert both sides of corewire ofthe powercable into
the connection sleeve.
• Method1: Push the core wire into the sleevefrom
both sides.
• Method2: Twist thewire cores togetherand push it
into the sleeve.
Method1
Connection sleeve Connection sleeve
Method2
CAUTION
• If cablewires are connectedwithout using
connecting sleeves, theircontact area becomes
reduced, orcorrosion develops on the outersurfaces
of thewires (copperwires) overa long time. This may
cause an increase of resistance (reduction of passing
current) and consequently mayresult in a fire.
4 Usingacrimpingtool, compressthetwopoints andflipit
overandcompressanothertwopointsinthesamelocation.
• The compression dimension should be 8.0.
Compression
dimension
• Aftercompressing it, pull both sides of thewire to
make sure it is firmlypressed.
Method1 Method2
5 mm
Compress it 4 times. Compress it 4 times.
5 mm

18
InstallationProcedure
English
InstallationProcedure
5 Wrapitwiththeinsulationtapetwiceormoreandposition
yourcontractiontube inthemiddleoftheinsulationtape.
Method1 Method2
40 mm
Insulationtape Insulation tape
35 mm
6 Apply heat to the contraction tube to contract it.
Method1
Contraction tube Contraction tube
Method2
7 Aftertube contractionwork is completed,wrap itwith
the insulation tape to finish.
Three ormore layers of insulation are required.
Method1 IInsulationtape IInsulation tape Method2
CAUTION
• Make sure that the connection parts are not exposed
to outside.
• Be sure to use insulation tape and a contraction tube
made of approved reinforced insulating materials
that havethe same level ofwithstand voltage with
the powercable. (Complywith the local regulations on
extensions.)
WARNING
• In case of extending the electricwire, please DO NOT
use a round-shaped Pressing socket.
– Incompletewire connections can cause electric
shock ora fire.
Step14 Settingtheindoorunit
addressesandtheinstallationoptions
If the indoorunit requires a high level controller, you must
set the indoorunit address. Butyou must always set the
installation options, and set them byusing the remote control.
You cannot set both of the indoorunit address andthe
installation options in a batch: set both of them respectively.
Commonstepsforsettingtheaddressesand options
AR-KH00E/AR-KH03Eremotecontrol(for360 cassette only)
Temperature
button
Timerbutton
Wheel
Mode button
Settingthe
optionvalues
Enteringthe
modeforsetting
theoptions
NOTE
• The remote control displaymayvarydepending on the
model.
1 Enterthe mode forsetting the options:
a Remove the batteries from the remote control.
b While holding down the (Temp) and
(Timer) buttons simultaneously, insert the
batteries intothe remote control.
c Make sure that you are enteredto the mode for
setting the options:

19
English
InstallationProcedure
2 Set the option values.
CAUTION
• Thetotal numberofavailable optionsare 24: SEG1toSEG24.
• Because SEG1, SEG7, SEG13, and SEG19 are the page
options used bythe previous remote control models,
the modes to setvalues forthese options are skipped
automatically.
• Set a 2-digitvalue foreach option pairin the following
ͱθʒʪθࡤƊkߤɇʒƊkߥƊkߦɇʒƊkߧƊkߨɇʒ
ƊkߪƊk߫ɇʒƊkߣߢƊkߣߣɇʒƊkߣߤƊkߣߦ
ɇʒƊkߣߧƊkߣߨɇʒƊkߣߩƊkߣߪɇʒƊkߤߢ
ƊkߤߣɇʒƊkߤߤƊkߤߥɇʒƊkߤߦ
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0XXXXX
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1XXXXX
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
2XXXXX
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
3XXXXX
On(SEG1toSEG12) Off(SEG13to SEG24)
Steps Remotecontroldisplay
1 Set the SEG2 and SEG3 values:
a Set the SEG2value by rotating theWheel
counterclockwise until the value youwant to set
appears on the remote control display. SEG2
b Set the SEG3value by rotating theWheel clockwise
until thevalueyou want to set appears on the remote
control display.
SEG3
Whenyou rotatethe Wheel,values appearin the following order:
2 Press the (Mode) button. Cool and On appearon the remote control display.
3 Set the SEG4 and SEG5 values:
a Set the SEG4value by rotating theWheel
counterclockwise until the value youwant to set
appears on the remote control display. SEG4
b Set the SEG5value by rotating theWheel clockwise
until thevalueyou want to set appears on the remote
control display.
SEG5
Whenyou rotatethe Wheel,values appearin the following order:

20
InstallationProcedure
English
InstallationProcedure
Steps Remotecontroldisplay
4 Press the (Mode) button. Dry and On appearon the remote control display.
5 Set the SEG6 and SEG8 values:
a Set the SEG6value by rotating the Wheel
counterclockwise until the value youwant to set
appears on the remote control display. SEG6
b Set the SEG8value by rotating theWheel clockwise
until thevalueyou want to set appears on the remote
control display.
SEG8
Whenyou rotatethe Wheel,values appearin the following order:
6 Press the (Mode) button. Fan and On appearon the remote control display.
7 Set the SEG9 and SEG10 values:
a Set the SEG9value by rotating the Wheel
counterclockwise until the value youwant to set
appears on the remote control display. SEG9
b Set the SEG10 value byrotating theWheel clockwise
until thevalueyou want to set appears on the remote
control display.
SEG10
Whenyou rotatethe Wheel,values appearin the following order:
8 Press the (Mode) button. Heat and On appearon the remote control display.
9 Set the SEG11 and SEG12 values:
a Set the SEG11 value byrotating theWheel
counterclockwise until thevalueyou want to set
appears on the remote control display. SEG11
