Samsung ADN BDEH Series User manual

DVM HYDRO UNIT_IM_E_03469A(1).indd 56 2012-11-21 오후 2:32:32

EN ES FR IT PT DE
DB68-03469A(1)
ADN✴✴✴BDEH✴ Series
Air Conditioner
installation manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/register
DVM HYDRO UNIT_IM_E_03469A(1).indd 57 2012-11-21 오후 2:32:32

2
Safety precautions
Before installing an air conditioner, please read this manual thoroughly to ensure that you know how to safely and efficiently
install a new appliance.
❋ This product uses R-410A refrigerant.
- When using R-410A, moisture or foreign substances may affect the capacity and reliability of the product. Safety
precautions must be taken when installing the refrigerant pipe.
- The designed maximum pressure of the system is 4.1MPa. Select appropriate material and thickness according to the
regulations.
- R-410A is a quasi-azeotrope of two refrigerants. Make sure to charge with liquid phase when filling refrigerant. (If you
charge vapor refrigerant, it may affect the capacity and reliability of the product as a result of a change in the blend of
the refrigerant.)
❋ You must connect the outdoor unit for R-410A refrigerant. When outdoor unit for R-22 refrigerant is connected, product
cannot operate normally.)
❋ This product uses plate type heat exchanger, and extra concern must be taken regarding on selecting the installation
location since it requires water pipe installation.
❋ For product protection, closed type water circuit system must be adopted for water pipe system.
Before the installation, read the‘Severe warning signs’and the‘Caution signs’thoroughly.
Manufacturer is not responsible for accidents due to incorrect installation. (User will be responsible for any service charges
that may occur.)
Manufacturer is not responsible for any product problems that may occur due to incorrect water pipe installation.
Maintain the water temperature and the amount of water flow within operational range. Manufacturer is not responsible if
the heat exchanger freezes and ruptures due to incorrect installation.
This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC), and the Electromagnetic
Compatibility Directive (2004/108/EC) of the European Union.
WARNING Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.
Contents
Safetyprecautions......................................................................................................... 2
Preparing the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
BaseconstructionandinstallationoftheDVMHydrounit .................................................................. 7
Refrigerantpipeinstallation ............................................................................................... 9
Performingleaktestandinsulation .......................................................................................13
Waterpipeinstallation....................................................................................................15
Connectingpowerandcommunicationcable.............................................................................20
Connectingexternalcontact..............................................................................................28
Settinganindoorunitaddressandinstallationoption.....................................................................42
Productmaintenance.....................................................................................................49
Failurediagnosis..........................................................................................................50
Errorcode ................................................................................................................51
Using the PCB Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Completingtheinstallation ...............................................................................................54
Explainingfunctionstotheuser........................................................................................... 54
DVM HYDRO UNIT_IM_E_03469A(1).indd 2 2012-11-21 오후 2:32:18

3
ENGLISH
SEVERE WARNING SIGNS
Installation must be requested to a qualified installer.
fIf the user installs a product improperly on their own, it may cause refrigerant leakage and lead to electric shock or fire in
worst case scenario.
Install the unit in a place where it is strong enough to hold the product weight.
fWhen installed in place where it is not strong enough to withhold the product weight, the unit could fall and cause injury.
Do not put any product or object under the DVM Hydro unit.
fWater from the DVM Hydro unit may fall and cause fire or loss of property.
Electric work must be done by qualified persons, complying the national wiring regulations and installed according to
the instruction stated in the installation manual with leased circuit.
fCapacity shortage on the leased circuit and improper installation may cause electric shock or fire.
Use specified wires to connect the DVM Hydro unit and outdoor unit, and make sure the wire is firmly fixed.
fImproper connection may cause fire.
Neatly arrange the wires in the electrical parts to make sure that electrical cover is closed securely without any gap.
fIf the cover is not properly closed, heat may generate on the electrical terminal and cause electric shock or fire.
Make sure to use the provided or specified parts with the specified tools for installation.
fFailing to do so may cause product failure, refrigerant leakage, fire or electric shock.
In any case of refrigerant leakage, make sure to ventilate.
fIf the refrigerant gas comes in contact with fire, harmful gas will be generated.
fMake sure that the refrigerant gas does not leak after completing the installation. If the refrigerant gas of the indoor unit
leaks and comes into contact with the fan heater, space heater or stove, harmful gas will be generated.
Make sure to perform grounding work.
fDo not connect the ground wire to a gas pipe, water pipe, lightning rod or telephone grounding. Improper grounding
could cause electric shock.
Do not install the product in a place where it is or might be exposed to inflammable gas leakage.
fWhen the gas leaks and gets accumulated around the product, it may cause fire.
Installation work must be done according to the instruction in this installation manual.
fImproper installation may cause water leakage, electric shock or fire.
When inserting the power plug, make sure to insert it fully and check that power plug and a consent does not have any
dusts, blockage or loosened part.
fIf there are dusts, blockage or loosened part on a power plug or consent, it can cause electric shock or fire. Also, replace
the consent if it is loosened.
When installation is in progress, check the following before operating the product.
fMake sure pipes are properly connected without any leakage.
fWhen there is leakage on the connected part, air may get in and cause abnormally high pressure state which may lead to
pipe explosion and personal injury.
Do not assemble the power cord on your own, use two cables together to extend the cable length or connect the power
to a multi consent connected with other products.
fBad connection, isolation and over voltage may cause fire or electric shock.
Cut-off the main power supply before electrical installation of DVM Hydro unit.
fPotential risk or electric shock.
You may need to install an ELB (earth leakage breaker) depending on the installation location.
fNot installing an ELB (earth leakage breaker) may cause electric shock.
Supply power to the product during winter time since the product will operate in protection mode itself when the
temperature decrease below 0°C.
fIf you cut-off the power, protection mode cannot be operated and may cause damage to the product.
fDVM Hydro unit is designed to be installed indoor. Make sure to install it in a place where there is no risk of surrounding
temperature from dropping below zero.
DVM HYDRO UNIT_IM_E_03469A(1).indd 3 2012-11-21 오후 2:32:18

4
Safety precautions
CAUTION SIGNS
Read the installation manual thoroughly before installing the product.
Make sure to transport the product with its packages on. In case if you must remove the packaging, use soft materials
to carry the product to prevent any damages on the product.
Perform the drainage/piping work securely according to the installation manual.
fIf not, water could drop from the unit and household goods could get wet and damaged.
Wear thick gloves during the installation process.
fIf not, personal injury may occur due to the air conditioner parts.
If the DVM Hydro unit is installed in a small area, beware of oxygen deficiency in the area that may caused by
refrigerant leakage.
Do not install or operate DVM Hydro unit in following places:
fPlace where surrounding air contains mineral oil or where oil vapor occurs; or cooking area where vapor or water
particles occur by spraying. (When particles of oil sticks to the heat exchanger following incidents may occur; it may
cause performance decrease or cause condensation water to scatter. Also, if oil particles sticks to the plastic parts, it may
cause damage or deformation of those part which may lead to product malfunction or refrigerant leakage.)
fPlace where corrosive gas, such as sulphurous gas, exists. (When installing the product in these places, contact an
installation specialty store since the copper pipe and brazing part will need additional corrosion proof or anti-rust
additive to prevent corrosion.
fPlace where product is exposed to flammable gases, carbon fiber, flammable powder/dust or place where volatile
flammable gases such as thinner or gasoline is frequently used. (Gases near DVM Hydro unit may ignite.)
fPlace where electromagnetic waves are emitted (Control devices may not work.)
fPlace with high level of basicity within the air such as near ocean; place with high voltage fluctuation such as factory; and
within the car or ship.
fPlace where special spray is frequently used.
fPlace where fine powder is used (such as bakery)
fDo not use the product to store precision instrument, food, plants or animals, cosmetic goods, art works or any other
special purpose. (There is risk of property loss.)
fPlace where noise or vibration may occur.
After completing the installation, run the trial operation. If no error occurs, explain to the customer how to use and
clean the air conditioner according to the user’s manual. In addition give the installation manual and the user’s manual
to the customer.
Before the installation, check if the product is in good shape.
fDo not install the product with the damage which occurred during shipment.
All of the materials used to manufacture product and packages are eco-friendly and they are recyclable.
Refrigerant used in this product must be added or disposed in an appropriate way by qualified personnel.
fAt the end of the life cycle, take it to a proper recycling or disposal center or return it to the dealer so that it can be
disposed correctly.
DVM HYDRO UNIT_IM_E_03469A(1).indd 4 2012-11-21 오후 2:32:18

5
ENGLISH
Preparing the installation
Tools required for installation
General tools
①Vacuum pump ②Torque wrench ③Pipe cutter ④Reamer ⑤Pipe bender
⑥Spirit level ⑦Screw driver ⑧Spanner ⑨Drill ⑩L wrench
⑪Measuring tape
Tools for operation
①Thermometer ②Resistance meter ③Electroscope
Accessories (supplied)
Before the installation, make sure to check if following accessories are included inside the DVM Hydro unit.
Installation manual Drain plug Drain cap
Additional accessory (not included)
Additional accessory needs to be purchased separately and installed to operate DVM Hydro unit.
(Model name of the wire remote controller : MWR-WW00)
Wired remote controller
fRecommended specification of the strainer
Model name Work pressure Work temperature Water pipe
connection part Mesh Size Material (Strainer/Mesh)
ADN160BDEH✴
ADN320BDEH✴1.0 MPa -5~45°C PT 1 (25A) 50 Mesh AISI316/SUS304
ADN500BDEH✴PT 1-1/4 (32A)
DVM HYDRO UNIT_IM_E_03469A(1).indd 5 2012-11-21 오후 2:32:19

6
Preparing the installation
Selecting installation location
fChoose a place with ventilation duct or opening to cool down the heat generated from the product and maintain the
surrounding temperature within 5~40°C and the humidity below 80%.
fChoose a place where structure can bear the weight and vibration of the DVM Hydro unit.
fChoose a flat place that rainwater does not settle or leak.
fChoose a well ventilated place with sufficient space for repair and other services.
fChoose a place where you can easily connect the refrigerant pipes between the DVM Hydro unit and outdoor unit within
allowable distance.
fDo not install this product in a place where it may corrode.
fInstall the power cable and communication cable of the DVM Hydro unit and outdoor unit at least 1m away from the
electric appliance such asTV. (In some cases, there may be problem even if there's more than 1m gap from the electric
appliances.)
Space requirement
fWhen installing the product, make sure to secure minimum distance with obstacles as shown below.
fWhen you install one product on top of the other one, secure at least 600mm of space on the water pipe side.
<When installing one product on top of the other one>
(Unit: mm)
Service
space
(Front)
100330600
400518300
Service
space
(Side)
Installation
space for
pipe
Product
100
400
600
100100100
200
626 626
Service space
H beam
• If the outdoor unit is needed to installed closed to the walls unavoidably, prevent the vibration generated from
the product to the walls with cushioning materials etc.
CAUTION
DVM HYDRO UNIT_IM_E_03469A(1).indd 6 2012-11-21 오후 2:32:19

7
ENGLISH
BaseconstructionandinstallationoftheDVMHydrounit
• If this product is installed in residential area, apply anti-vibration product to prevent the vibration from
transferring to the building.
WARNING
fManufacturer is not responsible for the damage occurred by not following the installation standards.
1. Considering the vibration and weight of the DVM Hydro unit, strength of the base ground must be strong enough to
prevent noise and the top part of the base ground has to be flat.
2. Base ground should be 1.5 times larger than the bottom of the Hydro unit.
3. It is necessary to add wire mesh or steel bar during concrete construction for the base ground to prevent damages or
cracks.
4. Place the DVM Hydro unit on the base construction and completely fix it with the bolt, nut and washer. (The bearing force
has to be over 3.5kN)
5. Fix the DVM Hydro unit firmly with 4 foundation bolts.
6. When concrete construction for DVM Hydro unit installation is completed, install an anti-vibration pad(t=20mm or
more) or an anti-vibration frame(vibration transmissibility=5% and below) to prevent vibration of the outdoor unit from
transferring to the base ground.
7. When constructing base ground, DVM Hydro unit must be supported within the range of following dimensions.
Base ground construction
Drain hole 200mm or more
Outdoor unit installation
333
365
340
518
(Unit: mm)
DVM Hydro unit
Anchor bolt
Nut, Spring
washer
H beam or anti-
vibration frame
Anti-vibration pad
A+10~20mm or more
A
20mm
Over 50mm
DVM HYDRO UNIT_IM_E_03469A(1).indd 7 2012-11-21 오후 2:32:19

8
Base construction and installation of the DVM Hydro
unit
Anchor specification
b
c
a
m
Size Diameter of
drill bit (a) Anchor length (b) Sleeve length (c) Insert depth Fastening torque
M10 14 mm 75 mm 40 mm 50 mm 30 N·m
Dimension of the DVM Hydro unit
340
33316
599
365
626
27
45 45205
60
100
Communication cable
Liquid pipe
Gas pipe
External contact
Water outlet pipe
Water inlet pipe
Power cable
518
73.5 65 90
Unit: mm
Model name of DVM Hydro unit ADN160BDEH✴ADN320BDEH✴ADN500BDEH✴
Refrigerant
side
Liquid side
connection part 3/8”(ø9.52) 3/8”(ø9.52) 1/2”(ø12.7)
Gas side connection
part 5/8”(ø15.88) 7/8”(ø22.23) 1-1/8”(ø28.58)
Water side connection part PT 1 (25A) PT 1 (25A) PT 1-1/4 (32A)
DVM HYDRO UNIT_IM_E_03469A(1).indd 8 2012-11-21 오후 2:32:19

9
ENGLISH
Refrigerant pipe installation
Refrigerant pipe work
fUse exclusive tools and accessories for R-410A to respond to pressure of the R-410A and prevent foreign substances from
entering into the pipes.
fThe length of refrigerant pipe should be as short as possible and the height difference between the DVM Hydro unit and
outdoor unit should be minimized.
fPiping work must be done within allowable piping length, height difference, and the allowable length after branching.
fThe pressure of the R-410A is high. Use only certified refrigerant pipe and follow the installation method.
fUse clean refrigerant pipe and there shouldn’t be any harmful ion, oxide, dust, iron content or moisture inside pipe.
fPipe work must be done aside from the product.
fAfter completing the pipe installation, calculate the additional amount of refrigerant according to method of each indoor
units and make sure to use R-410A refrigerant when charging. (Color of the R-410A refrigerant container is painted in
pink.)
Model name of DVM Hydro unit ADN160BDEH✴ADN320BDEH✴ADN500BDEH✴
Amount of additional refrigerant 0.3kg 0.7kg 1.2kg
fDo not use Flux when welding the refrigerant pipes.
Tools used for refrigerant pipe installation
Product using R-410A refrigerant requires exclusive tools. Check the conventional tools for compatibility before installation.
Tool Work Compatibility with conventional tool
Pipe cutter
Refrigerant pipe work
Pipe cutting Compatible
Flaring tool Pipe flaring
Refrigerating machine
oil
Apply refrigerant oil on
flared part
Use exclusive ether oil, ester oil, alkali benzene
oil or mixture of these oils
Torque wrench Connect flare nut with
pipe
Compatible
Pipe bender Pipe bending
Nitrogen gas Air tightness test Inhibition of oxidation
Welder Pipe welding
Manifold gauge Air tightness test ~
additional refrigerant
charging
Vacuuming, charging and
checking operation
Need exclusive one to prevent mixture of R-22
refrigerant oil use and also the measurement is
not available due to the high pressure.
Refrigerant charging
hose
Need exclusive one due to the refrigerant
leakage or inflow of impurities.
Vacuum pump Vacuum drying
Compatible (Use products which contains the check valve to prevent the oil
from flowing backward into the outdoor unit.)
Use the one that can be vacuumed up to 100.7 kPa (5 Torr).
Scale for refrigerant
charging Compatible
Gas leak detector Gas leak test Need exclusive one
(Ones used for R-134a is compatible)
Flare nut Must use the flare nut equipped with the product.
Refrigerant leakage may occur when the conventional flare nut for R-22 is used.
DVM HYDRO UNIT_IM_E_03469A(1).indd 9 2012-11-21 오후 2:32:19

10
Refrigerant pipe installation
Selecting refrigerant pipe
fInstall the refrigerant pipe according to main pipe size for each capacities of DVM Hydro unit.
Model name of DVM Hydro unit ADN160BDEH✴ADN320BDEH✴ADN500BDEH✴
Refrigerant
side
Liquid side 3/8”(ø9.52) 3/8”(ø9.52) 1/2”(ø12.7)
Gas side 5/8”(ø15.88) 7/8”(ø22.23) 1-1/8”(ø28.58)
Keeping refrigerant pipe
fTo prevent foreign materials or water from entering the pipe, storing method and sealing method (especially during
installation) is very important. Apply correct sealing method depending on the environment.
fBe especially careful when you penetrate the pipe through the hole in a wall or when the end of the pipe is exposed to
outdoor during installation.
fUse the flare nut supplied with the product. If other flare nuts are used, it can cause refrigerant leakage.
Exposure place Exposure time Sealing type
Outdoor Longer than one month Pipe pinch
Shorter than one month Taping
Indoor - Taping
Pinching the refrigerant pipe
fCompress the end of the refrigerant pipe and weld the compressed part.
Refrigerant pipe Welding part
Taping the refrigerant pipe
fSeal the end of the refrigerant pipe with a PVC vinyl tape.
End of the pipe
Refrigerant pipe
PVC tape
Squeeze flat Stick the squeezed part to the pipe
Finish up by wrapping around the
pipe again
DVM HYDRO UNIT_IM_E_03469A(1).indd 10 2012-11-21 오후 2:32:19

11
ENGLISH
Refrigerant pipe welding and safety information
Important information for refrigerant pipe work
fMake sure there is no moisture inside the pipe.
fMake sure there are no foreign substances and impurities in the pipe.
fMake sure there is no leakage.
fMake sure to follow the instruction when welding or storing the pipe.
Nitrogen flushing welding
fWhen welding the refrigerant pipes, flush them with nitrogen gas as shown in the picture.
fIf you do not perform nitrogen flushing when welding the pipes, oxide may form inside the pipe and can cause damage
to the important parts such as compressor and valves etc.
fAdjust the flow rate of the nitrogen flushing with a pressure regulator to maintain 0.05m3/h or less.
fWhen welding the pipes on the connection port, cover the valve with wet cloth before welding (to protect the parts
within the valve)
Welding part
Nitrogen Copper pipe (ø6.25 mm)
Stop valve
Taping
High pressure hose
Nitrogen
Wet cloth
Gas side (Welded)
Flowmeter
ø6.35
Pressure regulator
Direction of the pipe when welding
fDirection of the pipe should be headed downward or in a sideways when welding.
fAvoid welding the pipe with pipe direction heading upward.
Downward Side Upward
DVM HYDRO UNIT_IM_E_03469A(1).indd 11 2012-11-21 오후 2:32:20

12
Refrigerant pipe installation
Refrigerant pipe work on DVM Hydro unit
Wet cloth
Gas pipe
Liquid pipe
• Caution for welding the pipe to a DVM Hydro unit
- When welding the pipe to the product, the unit may get damaged by the heat and flame from welding. Use a
flame proofing cloth to protect the unit from a brazing fire or flame.
- Wrap the pipe with a wet cloth and weld it as shown in the illustration. Also, water dripping from the wet cloth
may interrupt the welding so make sure the water does not drip from the wet cloth.
- Make sure that connected pipes of DVM Hydro unit and the outdoor unit does not interrupt each other or make
contact with the product. (Vibration may cause damage to the pipes.)
- When removing the sealed pipe on the bottom side of the service valve, cut it with a pipe cutter first and then
start the welding.When the sealed pipe is welded without cutting, you may get injured by the refrigerant
within the pipe.
CAUTION
1. Remove the copper cap of the refrigerant pipe and eliminate the sludge or foreign substances on the welded part and
then weld the connecting pipe on each port.
- Since nitrogen gas is sealed within the pipe, you must discharge the nitrogen gas from the liquid pipe.Then remove the
copper cap and check for existence of the nitrogen gas.
- Check the pressure of the nitrogen gas before welding. If the nitrogen gas is not being purged, product is not normal so
do not install it.
Gas side
Copper cap
Liquid side
2. Cover the refrigerant pipe well with an insulator.
- It prevents the water, on the outer surface of the pipe, from dripping and increase the efficiency of the DVM Hydro unit.
3. Cut off the leftover insulator.
4. Check for cracks on the bent part of the pipes.
5. When the DVM Hydro unit is installed in a hot and humid place, water may form on the outer surface of the insulator so it
would be necessary to double the insulation thickness (10mm or more).
DVM HYDRO UNIT_IM_E_03469A(1).indd 12 2012-11-21 오후 2:32:20

13
ENGLISH
Performing leak test and insulation
Before completing the installation (insulating hose and pipes), you must check for gas leakage and when there is no leakage,
you may insulate the pipes and hoses.
Leak test
Use a gas detector to check the connection part of the pipes for gas leakage.
Gas side
Liquid side
Insulation
Selecting the insulator of refrigerant pipe
fInsulate the gas pipe and liquid pipe by referring to the thickness of insulator for each pipe size.
fThe standard temperature and humidity condition is 30°C with humidity below 85%. If the condition is in high humidity, use
one grade thicker.
Pipe Pipe size (mm)
Thickness of the insulator [Cooling, Heating (mm)]
RemarksStandard [30°C, 85%] High humidity
[30°C, 85% or more]
EPDM, NBR
Liquid pipe Ø6.35~Ø9.52 9 9 Heat resisting
temperature should be
over 120°C
Ø12.70~Ø19.05 13 13
Gas pipe Ø6.35 13 19
Ø9.52 ~ Ø28.58 19 25
1. To avoid condensation problems, wrap each pipes with heat-resisting
polyethylene foam.
- Make sure that the opening part of the insulation to face up.
No gap
Insulator
Heat-resisting
polyethylene foam
2. Wrap the refrigerant pipes and drain pipes with insulator. Insulator
Install the insulation to be
overlapped
DVM Hydro
unit
Fix securely without any gap.
DVM HYDRO UNIT_IM_E_03469A(1).indd 13 2012-11-21 오후 2:32:20

14
Installing the drain pipe
Installing the drain pipe
fUse a spirit level to make sure that product is horizontally leveled.
fChoose one of the 2 drain holes on the bottom of the product and insert the provided drain plug, then connect the drain
pipe.
fFrom the 2 drain holes, block the unused hole with the provided rubber plug.
fInstall the drain pipe at the rear side of the unit to get a sufficient space for repairs and service on the front side.
fDo not install a trap on the pipe and install the drain pipe horizontally with a slope of 1/50 or more to prevent water from
flowing backwards.
fFor smooth drainage, install an air vent that is open to air.
fInsulate the drain pipe and drain plug with insulation over 10mm.
fInstall self-regulating heat cable on the drain pipe to prevent it from being frozen.
fInstall the safety equipment for a heating appliance.
More than
1/50 slope
Open to air
Drain plug
When concentrated drainage is installed
fInstall a concentrated drain pipes with an air vent that is open to air.
Open to air
More than 1/50 slope
Drain plug
Checking the water leakage
Prepare about 2 liters of water and pour water into the drain pan of the DVM Hydro unit as shown in the illustration.
DVM HYDRO UNIT_IM_E_03469A(1).indd 14 2012-11-21 오후 2:32:20

15
ENGLISH
Water pipe installation
1. You do not need to equip extra expansion tank when there's open type expansion tank on top part of the existing
thermal storage tank. However, if you do not have expansion tank, you will need to construct closed type pipe system
and equip expansion tank.
2. Water pipe installation system
1) Install the water pipe as shown in the below illustration. All the parts, other than DVM Hydro unit, must follow on site
installation specification.
<Water pipe connection part>
DVM Hydro unit
Water
pipe
Insulator
Over 80 mm
Finishing tape
fInstalling hot water supply
①
⑥
②⑧
⑪⑪
⑧
⑩
⑦⑫
③
⑨
Makeup water
On site
installation Ball valve
(Used as
cleaning hole)
Overflow pipe
Drain pipe
Water out
Water in
Hot
water
tank
Cleaning device
Top part slope ≥ 1/200
Hydro unit
Heat
exchanger
on water
side ④⑤
Mechanical room
①Water pipe joint (union, flange) ⑤Flexible joint ⑨Expansion tank
②Thermometer ⑥Drain (within the product) ⑩Temperature sensor for hot water tank
③Manometer ⑦Pump ⑪Drain valve
④Ball valve ⑧Air vent ⑫Strainer
DVM HYDRO UNIT_IM_E_03469A(1).indd 15 2012-11-21 오후 2:32:20

16
Water pipe installation
fInstalling under floor heating
①
⑥
②⑧
⑪⑪
⑧
⑩
⑦⑫
③
⑨
Makeup water
On site
installation Ball valve
(Used as
cleaning hole)
Overflow pipe
Drain pipe
Water out
Water in
Under floor
heating coil
Hot
water
tank
Cleaning device
Top part slope ≥ 1/200
Hydro unit
Heat
exchanger
on water
side ④⑤
Mechanical room
①Water pipe joint (union, flange) ⑤Flexible joint ⑨Expansion tank
②Thermometer ⑥Drain (within the product) ⑩Temperature sensor for thermal storage tank
③Manometer ⑦Pump ⑪Drain valve
④Ball valve ⑧Air vent ⑫Strainer
fOn site installation specification
Model name
Strainer Flow meter Thermometer Manometer Air vent Pump Ball valve Drain valve
ADN160BDEH✴
#50 PT 1
0~50ℓ/min
0~100°C 0~1MPa
0.6 m3/h
(Condition:
0.15 MPa)
48ℓ/min
PT 1 15 A
ADN320BDEH✴0~100ℓ/min
92ℓ/min
(Refer to
pressure
drop graph)
ADN500BDEH✴#50
PT 1-1/4 0~150ℓ/min 0~100°C 0~1MPa
0.6 m3/h
(Condition:
0.15 MPa)
150ℓ/min
(Refer to
pressure
drop graph)
PT 1-1/4 15 A
2) Water pipe socket must be connected with a less tightening torque value stated in the below table. If you apply more
torque, it may cause damage to the product.
Diameterofwaterpipe (Outerdiameter,mm) Tightening torque (N•m)
ø10~20 25
ø21~30 50
ø31~50 100
ø51~80 220
ø81~115 600
❋ 1N•m=10kgf•cm
3) Use certified parts for water pipe system and the water pressure of the water pipe system connected to outdoor unit
must remain under 1.0 MPa. Use copper or stainless pipe water pipe.
DVM HYDRO UNIT_IM_E_03469A(1).indd 16 2012-11-21 오후 2:32:20

17
ENGLISH
4) Water pipes must be equipped with valves and other instrumentations as shown in the diagram. Strainer and
flow switch must be installed within 1~2m from the entrance pipe of the DVM Hydro unit.
- When strainer is not installed, sand, dust or rust debris may cause product breakage.
5) Water inlet pipe is located at the bottom part of the heat exchanger and the water outlet pipe is at the top part of the
heat exchanger.
6) DVM Hydro unit must be installed indoor at room temperature and the water inlet and outlet must be insulated
with the heat exchanger as shown in the diagram.
7) Damp-proof, cold reserving and insulation work must be done thoroughly to prevent condensation from
forming on the surface of the product and drain pipes of indoor/outdoor units. When the necessary work is
not done thoroughly, you will waste energy caused by thermal loss and may get property damage during cold
seasons when water pipe freezes and bursts. This product will keep the circulation pump to operation in certain
interval, even when the power is off, in order to prevent pipe rupture. Therefore, you must check if the power
(220~240V) is being supplied.
8) If you stop the product for long time or in night time, water pipe circuit may freeze naturally when the
temperature around the DVM Hydro unit is under 0°C. When water pipe circuit freezes, it will cause damage to
the plate type heat exchanger and therefore preventive measure must be taken according to the situation.
- Drain remaining water in the water pipe
- Install self-regulating heat cable on the water pipes
- If the product is installed in a place where surround temperature drops below 0°C, use anti-freeze accordingly for
freezing point depression.
9) Install number of auto air discharge valve at a point where air may remain within the pipe (such as vertical water
pipe). If the air within the pipe is not discharged, it may cause performance decrease or corrosion on the product or
pipes.
10) Following is the operation range of water.
Section
Standard condition Recommended operation range
Inlet water
temperature
(°C)
Amount of water (ℓ/min) Amount of water (ℓ/min) Inlet water
temperature (°C)
ADN160BDEH✴ADN320BDEH✴ADN500BDEH✴ADN160BDEH✴ADN320BDEH✴ADN500BDEH✴
Recommended
range
Cooling 23 48 92 150 24~48 46~92 75~150 15~25
Heating 30 30~45
fWhen the amount of cooling water is out of the operation range, stop the DVM Hydro unit and take care of the cause
before re-start the operation.
fTemperature of discharged water is very high so be careful not to come in contact with the body. Also, cover the external
water pipe with appropriate insulator for insulation and preventing burns.
11) Water scale may occur on the plate type heat exchanger depending on the water quality and the type of plate heat
exchanger so regular chemical cleaning is necessary. When installing water pipes, install a heat source water shut-off
valve and also install the flushing pipe with a ball valves (for chemical cleaning) on the pipe installed between the
shut-off valve and the outdoor unit.
12) Before trial operation, connect the cleaning pipes installed on inlet and outlet as shown in above illustration.Then,
take appropriate measures (such as blind flange etc) to stop the circulation water from entering the outdoor unit
plate type heat exchanger, and use circulating pump to remove foreign substance within the water pipes and clean
the strainer. If you do not clean the strainer, foreign substances may accumulates on plate type heat exchanger and
may break the heat exchanger or cause problem to it.
13) Make sure that water quality within the water pipe meets the standard of cooling water quality for refrigerating and
air conditioning equipment.
- Heat source water containing high level of foreign substances can cause water heat exchanger and pipe corrosion or
creation of water scale. (Use the appropriate heat source water according to the below table)
- If the make-up water is provide from any other source than local water supply, make sure to check the quality of water.
- Strainer (which needs to be purchased separately) must be installed to the‘Water IN’pipes of the water pipe. If sand,
dust or rust debris enters to water system, it may cause corrosion on metallic materials or blockage of the water heat
exchanger and damage the heat exchanger.
- If the existing thermal storage tank or pipes are used, foreign substances may block the plate type heat exchanger of
the DVM Hydro unit so, water quality and foreign substances must be managed.
DVM HYDRO UNIT_IM_E_03469A(1).indd 17 2012-11-21 오후 2:32:20

18
Water pipe installation
Section Item
Closed circuit system Effects Recommended
number for water
quality inspection
Heat source
water Make-up water Corrosion Scale
Standard
value
pH[25 ˚C] 7.0 ~ 8.0 7.0 ~ 8.0 O O Twice a month
Electric conductivity [25 ˚C](mS/m) 30 and below 30 and below O O
Chloride ion (mg Cl-/L) 50 and below 50 and below O
Once a month
Sulfate ion (mg S042-/L) 50 and below 50 and below O
M alkali level [pH 4.8](mg CaCo3/L) 50 and below 50 and below O
Total hardness (mg CaCo3/L) 70 and below 70 and below O
Calcium hardness (mg CaCo3/L) 50 and below 50 and below O
Ionized silica (mg SiO2/L) 30 and below 30 and below O
Reference
Iron (mg Fe/L) 1.0 and below 0.3 and below O O
Once a month
Copper (mg Cu/L) 1.0 and below 1.0 and below O
Sulfate ion(mg S2/L) Not to be
detected
Not to be
detected O
Ammonium ion (mg NH4+/L) 0.3 and below 0.1 and below O
Residual chlorine (mg Cl/L) 0.25 and below 0.3 and below O
Free carbon dioxide (mg CO2/L) 0.4 and below 0.4 and below O
Stability index - - O O
• Circle (O) marks in the chart show the factor relevant to corrosion or water scale.
• When the water temperature is over 40˚C, steels without protective coating may corrode when expose to water.
Applying corrosion prevention material or degassing can be effective measure to prevent corrosion.
• For the cooling water and the make-up water, used under closed circuit water system with closed circuit cooling
tower, should satisfy the standard shown in above table.
• Supplied water or make-up water should be tap water, industrial water or groundwater. Purified water,
neutralized water and softened water should not be supplied.
• 15 items in the above table is a typical factor for corrosion and/or water scale.
• When water pipe circuit freezes, it will cause breakage on the plate type heat exchanger. Therefore appropriate
preventive measure must be taken according to the situation.
- Drain remaining water in the water pipe
- Constantly operate the water pump to circulate the water within the water pipe
- Install a self-regulating heat cable on the water pipe
• Open the valve of the water pipe connected to the outdoor unit after flushing (cleaning foreign substances in
water pipe) is completed.
• Check that air is vented from the water pipe and circulation amount is secured before opening the service valve
on the refrigerant side of the outdoor unit.
• When circulating water stops during outdoor nit operation, it may cause breakage on plate type heat exchanger.
NOTE
DVM HYDRO UNIT_IM_E_03469A(1).indd 18 2012-11-21 오후 2:32:20

19
ENGLISH
Pressure drop graphs
fADN160BDEH✴
Pressure drop from heat
exchanger (kPa)
    







Amount of water (ℓ/min)
fADN320BDEH✴
Pressure drop from heat
exchanger (kPa)
    










Amount of water (ℓ/min)
fADN500BDEH✴
Pressure drop from heat
exchanger (kPa)
    








Amount of water (ℓ/min)
DVM HYDRO UNIT_IM_E_03469A(1).indd 19 2012-11-21 오후 2:32:20
