Samsung AM NJD Series User manual

Console Type Series
Floor : AMNJD
Air Conditioner
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DB68-03877A-12

2
Features of your new air conditioner
Slim & Smart Design
Extremely slim and compact design will allow this air conditioner to fit in any kind of interior space.
Ionizer function
Ionizer function generates hydrogen(H) and oxygen(O2) to attack undesirable air contaminants such as bacteria,
pollen, and odor. It makes you breathe better as if you were staying around waterfalls, ocean surf, rivers and
mountains.
2Way air outlet
There are two separate air outlets for cooling and heating. Having warmer air coming out from the bottom part of the
air outlet will spread the warm air evenly throughout the room. Stay cooler and warmer in every corner of your room.
Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but can also be an efficient
heating method in the winter with the advanced“Heat Pump” system. This technology is up to 300% more efficient
than electrical heating, so you can further reduce its running cost. Now, meet year-round needs with one air
conditioner.

3
ENGLISH
Contents
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Viewing your air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using the remote controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Basic operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting the On/Off timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Using the Purity function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Selecting an indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Cleaning and maintaining the air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Instruction for packing and unpacking the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.

4
Safety precautions
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the extensive
features and functions of your new appliance.
Because the following operating instructions cover various models,
the characteristics of your air conditioner may differ slightly from those
described in this manual. If you have any questions, call your nearest
contact center or find help and information online at www.samsung.com.
Important safety symbols and precautions:
WARNING Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor
personal injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric
shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION WARNING
Use the power line with the power specifications of the product or
higher and use the power line for this appliance only. In addition, do
not use an extension line.
XExtending the power line may result in electric shock or fire.
XDo not use an electric transformer. It may result in electric shock or fire.
XIf the voltage/frequency/rated current condition is different, it may
cause fire.
The installation of this appliance must be performed by a qualified
technician or service company.
XFailing to do so may result in electric shock, fire, explosion, problems
with the product, or injury.

5
ENGLISH
FOR INSTALLATION WARNING
Install a switch and circuit breaker dedicated to the air conditioner.
XFailing to do so may result in electric shock or fire.
Fix the outdoor unit firmly so that the electric part of the outdoor
unit is not exposed.
XFailing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inflammable material.
Do not install this appliance in a humid, oily or dusty location, in a
location exposed to direct sunlight and water (rain drops). Do not
install this appliance in a location where gas may leak.
XThis may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high
external wall where it could fall.
XIf the outdoor unit falls, it may result in injury, death or property
damage.
This appliance must be properly grounded. Do not ground the
appliance to a gas pipe, plastic water pipe, or telephone line.
XFailure to do so may result in electric shock, fire, an explosion, or other
problems with the product.
XNever plug the power cord into a socket that is not grounded correctly
and make sure that it is in accordance with local and national codes.

6
Safety precautions
FOR INSTALLATION CAUTION
Install your appliance on a level and hard floor that can support its
weight.
XFailing to do so may result in abnormal vibrations, noise, or problems
with the product.
Install the draining hose properly so that water is drained correctly.
XFailing to do so may result in water overflowing and property damage.
When installing the outdoor unit, make sure to connect the draining
hose so that draining is performed correctly.
XThe water generated during the heating operation by the outdoor unit
may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death
or property damage.
FOR POWER SUPPLY WARNING
When the circuit breaker is damaged, contact your nearest service
center.
Do not pull or excessively bend the power line. Do not twist or tie
the power line. Do not hook the power line over a metal object,
place a heavy object on the power line, insert the power line
between objects, or push the power line into the space behind the
appliance.
XThis may result in electric shock or fire.
FOR POWER SUPPLY CAUTION
When not using the air conditioner for a long period of time or
during a thunder/lightning storm, cut the power at the circuit
breaker.
XFailing to do so may result in electric shock or fire.

7
ENGLISH
FOR USING WARNING
If the appliance is flooded, please contact your nearest service
center.
XFailing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or
smoke, unplug the power plug immediately and contact your
nearest service center.
XFailing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.),
ventilate immediately without touching the power line.
Do not touch the appliance or power line.
XDo not use a ventilating fan.
XA spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service
center.
XFailing to do so may result in problems with the product, water leakage,
electric shock, or fire.
XA delivery service for the product is not provided. If you reinstall the
product in another location, additional construction expenses and an
installation fee will be charged.
XEspecially, when you wish to install the product in an unusual location
such as in an industrial area or near the seaside where it is exposed to
the salt in the air, please contact your nearest service center.
Do not touch the circuit breaker with wet hands.
XThis may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
XThis may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to
climb onto the machine.
XThis may result in children seriously injuring themselves.

8
Safety precautions
FOR USING WARNING
Do not turn the air conditioner off with the circuit breaker while it is
operating.
XTurning the air conditioner off and then on again with the circuit
breaker may cause a spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials
well out of the reach of children, as packaging materials can be
dangerous to children.
XIf a child places a bag over its head, it may result in suffocation.
Do not insert your fingers or foreign substances into the outlet
when the air conditioner is operating or the front panel is closing.
XTake special care that children do not injure themselves by inserting
their fingers into the product.
Do not touch the front panel with your hands or fingers during the
heating operation.
XThis may result in electric shock or burns.
Do not insert your fingers or foreign substances into the air inlet/
outlet of the air conditioner.
XTake special care that children do not injure themselves by inserting
their fingers into the product.
Do not use this air conditioner for long periods of time in badly
ventilated locations or near infirm people.
XSince this may be dangerous due to a lack of oxygen, open a window at
least once an hour.
If any foreign substance such as water has entered the appliance,
cut the power by unplugging the power plug and turning the circuit
breaker off and then contact your nearest service center.
XFailing to do so may result in electric shock or fire.

9
ENGLISH
FOR USING WARNING
Do not attempt to repair, disassemble, or modify the appliance
yourself.
XDo not use any fuse (such as cooper, steel wire, etc.)other than the
standard fuse.
XFailing to do so may result in electric shock, fire, problems with the
product, or injury.
FOR USING CAUTION
Do not place objects or devices under the indoor unit.
XWater dripping from the indoor unit may result in fire or property
damage.
Check that the installation frame of the outdoor unit is not broken at
least once a year.
XFailing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and
current is measured according to ISO standard for energy efficiency.
Do not stand on top of the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal
objects, etc.) on the appliance.
XThis may result in electric shock, fire, problems with the product, or
injury.
Do not operate the appliance with wet hands.
XThis may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of
the appliance.
XAs well as being harmful to humans, it may also result in electric shock,
fire or problems with the product.
Do not drink the water from the air conditioner.
XThe water may be harmful to humans.

10
Safety precautions
FOR USING CAUTION
Do not apply a strong impact to the remote controller and do not
disassemble the remote controller.
Do not touch the pipes connected with the product.
XThis may result in burns or injury.
Do not use this air conditioner to preserve precision equipment,
food, animals, plants or cosmetics, or for any other unusual
purposes.
XThis may result in property damage.
Avoid directly exposing humans, animals or plants from the air flow
from the air conditioner for long periods of time.
XThis may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.

11
ENGLISH
FOR CLEANING WARNING
Do not clean the appliance by spraying water directly onto it. Do not
use benzene, thinner or alcohol to clean the appliance.
XThis may result in discoloration, deformation, damage, electric shock or
fire.
Before cleaning or performing maintenance, unplug the air
conditioner from the wall socket and wait until the fan stops.
XFailing to do so may result in electric shock or fire.
FOR CLEANING CAUTION
Take care when cleaning the surface of the heat exchanger of the
outdoor unit since it has sharp edges.
XTo avoid cutting your fingers, wear thick cotton gloves when cleaning it.
Do not clean the inside of the air conditioner by yourself.
XFor cleaning inside the appliance, contact your nearest service center.
XWhen cleaning the internal filter, refer to the descriptions in the
‘Cleaning and maintaining the air conditioner’section.
XFailure to do may result in damage, electric shock or fire.

12
Viewing your air conditioner before use
Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay
cool or warm with optimal efficiency.
Please read the user manual to get started and to make the best use of the air conditioner.
Checking the indoor unit
Carefully unpack your air conditioner, and check the unit to make sure it is not damaged.
Main parts
Air intake
Mode indicator and Control
button
Air outlet
(Cooling/Heating)
Air outlet
(Heating)
Blade pin lever
Blade pin lever
NOTE Your air conditioner may slightly look different from illustration shown above depending on your model.
Mode indicator and Control button
Ionizer indicator
Fan mode indicator
Timer indicator
Remote control sensor
Power indicator
Power button
Deice indicator

13
ENGLISH
Removing the front panel
Grab the top portion of the front panel and pull the front cover towards yourself. Unhook the safety string and lift up
the front panel.
Auto Off
Viewing the power button and parts under the panel
You may locate the Power button among with the mode indicators. When the front panel is open, you may locate the
temperature sensor and the Air flow switch. Temperature sensor is located on the top left side of the air conditioner
just above the anti-allergy/deodorizing filter slot and the Air flow switch is located on the top right corner of the air
conditioner.
You can turn on the air conditioner in Auto mode by pressing the Power button.
When you set the Air flow switch on Auto, it will open the bottom air outlet in Cool, Heat and Fan modes. However, in
Silence mode, the bottom air outlet will be closed. Also, in Cool mode, the bottom air outlet will be closed within an
hour. When you set the Air flow switch on Off, the bottom air outlet will be closed.
The room temperature sensor measures indoor room temperature.
Auto Off
Auto Off
Air flow switch
Power button
Room temperature sensor

14
Using the remote controller
• Point the remote controller towards the remote controller receiver of the indoor unit.
• When you press the button on the remote controller correctly, you will hear beep sound from the indoor unit and a
transmit indicator( ) appears on the remote controller display.
Remote controller buttons
Mode
Selects operation mode.
Air flow direction (Left and right)
Adjusts the air flow direction left and right.
Power
Turns the air conditioner on or off.
Temperature
Adjusts the temperature.
Options
Selects options during operation.
Direction
Moves to select and set an
option.
Fan speed
Adjusts the fan speed.
Air flow direction (Up and down)
Adusts the air flow direction up and down
(Not applicable to Duct type models).
SET
Selects or cancels an option.
Settings
Selects settings.
Timer
Sets timer option.
• In case you wish to cancel the options or settings that you have just set, press the Options or Settings
button again, then the most recently selected item will blink and you may simply cancel it by pressing
the SET button while selected item is blinking.
NOTE

15
ENGLISH
Remote controller display
Operation mode Remote controller
transmission
Low battery
Fan speed
Air flow direction
Settings
Set temperature or on/
off set time with the timer
function
On/Off timer
Options
• When turning off and turning on the remote controller, the Timer, Options and Settings set before
turning off the remote controller are cancelled. However, the fan direction does not change.
NOTE
Battery changing time
When the battery is exhausted, ( ) will be displayed on the remote controller display. When the icon appears, change
the batteries.
The remote controller requires two 1.5V AAA type batteries.
Storing the remote controller
When you do not use the remote controller for a long time, remove the batteries from the remote
controller and store it in the remote controller holder.

16
Using the remote controller
Inserting the batteries
1. Open the battery cover of the remote controller.
Press the ( ) part gently and lift it up in the arrow direction.
2. Insert the batteries.
Check and match the (+)and (-) signs accordingly.
3. Close the battery cover.
Match the cover and bottom part of the remote controller and press it until you hear
click sound.
CAUTION Make sure that water is not allowed to enter the remote controller.
• There is a possibility that the air conditioner will not operate by remote controller near strong light such
as a fluorescent lamp or neon sign. In this case, use the remote controller in front of the remote controller
receiver of the indoor unit.
• If other electrical products are operated by the remote controller, call your nearest service center.
• Filter reset : When the filter reset indicator is turned on the indoor unit display, clean the filter and press
the Settings <, > or Settings (Filter Reset) blinking SET button.
• Beep off : To silence the beep sound, press the Settings <, > or Settings (Beep) blinking SET
button. If you press the Settings <, > or Settings (Beep) blinking SET button again,
the beep sound will ring again.
NOTE
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be
disposed of with other household waste at the end of their working life. Where marked, the chemical symbols
Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC
Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health
or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of
waste and recycle them through your local, free battery return system.

17
ENGLISH
Basic operation
Basic operation is an operation mode that can be selected by pressing the Mode button.
Auto
In Auto mode, the air conditioner will automatically adjust the temperature and fan speed to maintain your fresh
environment.
• When the indoor temperature is too high, the powerful cool breeze is generated and when the indoor room
becomes cool enough, the soft breeze is generated.
Cool
Cool mode is frequently used and you can freely control the temperature, fan speed, and air flow direction in Cool
mode.
• When you select the Heat mode while the Cool mode is on, the Cool mode is cancelled.
Dry
The air conditioner in Dry mode acts like a dehumidifier by removing moisture from the indoor air. The Dry mode will
provide you with fresh air even on a rainy day.
Fan
Fan mode provides you with a breeze just like a fan to make fresh environment for you.
Heat
In Heat mode, you can warm your room even in the fall and winter.
• The fan may not commence immediately to avoid generating a cold breeze.
• During the Heat mode, defrost operation may be performed to remove the frost formed on the outdoor unit.
(When the frost is removed by the defrost operation in Heat mode, steam is generated from the outdoor unit.)
• If you stop operating the air conditioner after heating operation, the fan will operate for some time to cool the
indoor unit.
• When you select the Cool mode while the Heat mode is on, the Heat mode is cancelled.
• When the outdoor temperature is low and humidity is high during the heat mode, the outdoor unit's
heating capacity may decrease due to the frost formed on the outdoor heat exchanger. The defrost
operation removes the frost formed on the heat exchanger of the outdoor unit for 5 ~ 12 minutes.
During the defrost operation, the indoor unit does not generate breeze in order to prevent cold breeze
blowing out.
 The interval between the defrost operation can decrease depending on the amount of the frost formed on the
outdoor unit.
 The interval between defrost operation can also decrease by humidity level with rain or snow.
NOTE

18
Using the remote controller
Turning the air conditioner on
Press the button to operate the air conditioner.
Selecting the operation mode
Press the button to select an operation mode.
Adjusting the temperature
Press the button to adjust the temperature.
Auto Temperature can be adjusted by 1 °C(1 °F) within the range of 18 °C(65 °F)~30 °C(86 °F).
Cool Temperature can be adjusted by 1 °C(1 °F) within the range of 18 °C(65 °F)~30 °C(86 °F).
Dry Temperature can be adjusted by 1 °C(1 °F) within the range of 18 °C(65 °F)~30 °C(86 °F).
Fan Temperature cannot be adjusted.
Heat Temperature can be adjusted by 1 °C(1 °F) within the range of 16 °C(61 °F) ~30 °C(86 °F).
Selecting the fan speed
Press the button to adjust the fan speed.
Auto (Auto)
Cool (Auto), (Low), (Med), (High)
Dry (Auto)
Fan (Low), (Med), (High)
Heat (Auto), (Low), (Med), (High)

19
ENGLISH
Selecting air flow direction
This function allows you to shift the air flow direction up and down or left and right.
Press the or button to move the air flow direction up and down or left and right while the air
conditioner is turned on.
Remote controller display
f When the blade reaches the desired position, press the or button one
more time to set the air flow direction. The up/down and left/right tilting of the
blade will stop.
 Duct type model cannot adjust air flow direction up and down.
 button not available on RAC.

20
Setting the On/Off timer
You can set the air conditioner to be turned on or off automatically at desired time.
Setting the On timer
When the air conditioner is turned off.
Remote controller display
1. Press the Timer button to select (On).
-(On) indicator will keep blinking and you can set the time.
2. Press the <or >button to set the time.
-You can set the time in half hour unit from 30minutes (0.5 on the display)
~ 3hours and hour unit from 3 ~ 24hours.
-Time can be set from minimum 30 minutes to maximum 24hours.
3. Press the SET button to complete the On timer setting.
-(On) indicator and the set time of the timer will be displayed on the
remote controller display.
-On timer setting will be cancelled if you don't press the SET button within
10seconds after setting the time. Therefore, check for the (On) indicator
on the remote controller display.
Cancel f Press the Timer button select (On) press the <or >button
set the timer to press the SET button.
Additional options available in On timer
Select the mode from (Auto) (Cool) (Dry) (Fan) and (Heat).
You can adjust the temperature after timer setting is completed.
Temperature adjustment is only available in Auto/Cool/Dry/Heat mode. In Fan mode, temperature
cannot be adjusted.
• When On timer setting is completed, the set status will be displayed for 3 seconds, and then only (On)
indicator will remain on the remote controller display thereafter.
NOTE
