Samsung SM-R210 User manual

www.samsung.com
User Manual
SM-R210
English. 06/2017. Rev.1.0

2
Table of Contents
Basics
3 About the Gear 360
4 Read me first
5 Package contents
6 Device layout
8 Indicator light
9 Camera status screen
11 Memory card
14 Battery
17 Attaching the strap to the Gear 360
18 Turning the Gear 360 on and off
19 Connecting the Gear 360 to a mobile
device
Using the Gear 360
23 Using the Gear 360’s menus
24 Recording videos and taking photos
with the Gear 360 solely
25 Connecting to a mobile device
remotely
26 Recording videos or taking photos
36 Live broadcast
37 Configuring camera settings
39 Viewing videos or images
46 Using the computer program
47 Transferring files to a computer
47 Configuring the settings
49 Updating the software
Appendix
50 Troubleshooting
52 Removing the battery

3
Basics
About the Gear 360
The Gear 360 camera captures 360-degree videos and photos of you and your surroundings
in one shot. The two fisheye lenses capture lively photos and videos.
When you connect the Gear 360 to your mobile device via Bluetooth or Wi-Fi, you can capture
videos and photos remotely from your mobile device. You can also view, edit, and share
videos and photos.
If you connect the Gear 360 to a Gear VR, you can view your Gear 360 videos more realistically.

Basics
4
Read me first
Please read this manual before using this device to ensure safe and proper use.
•
Images may differ in appearance from the actual product. Content is subject to change
without prior notice.
•
Before using the Gear 360 make sure they are compatible with your device.
•
This product includes certain free/open source software. To see the instructions for
viewing the open source licence, go to the Samsung website (opensource.samsung.com).
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information

Basics
5
Package contents
Check the product box for the following items:
•
Gear 360
•
USB Cable (USB Type-C)
•
Strap
•
Pouch
•
Quick start guide
•
The items supplied with the Gear 360 and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this Gear 360 and may not be compatible
with other devices.
•
You can only use a computer which is compatible with the USB cable provided.
Visit www.samsung.com to see a list of compatible computers.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the Gear 360 before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
•
Always store the Gear 360 in its pouch. If its lenses are scratched, image quality
may decrease.

Basics
6
Device layout
Strap hole
OK key
Front camera
Front camera status
light
Menu key
Indicator light
Camera status screen
Power key
Microphone
Speaker
Rear camera
Rear camera status
light
Memory card tray
Multipurpose jack
(USB Type-C)

Basics
7
Tripod socket
Keys
Key Function
Power
•
Press and hold to turn the Gear 360 on or off.
•
Press to return to the previous screen on the camera status
screen.
Menu
•
Press repeatedly to move to the menu you want.
•
Press and hold to access connection modes.
OK
•
Press to record a video or take a photo, or select the option
you want.

Basics
8
Indicator light
The indicator light informs you of your Gear 360’s status.
Indicator light
Colour Status
Flashes blue three times
•
Power on
•
Formatting a memory card or successfully resetting the
Gear 360
Flashes red three times
•
Power off
Flashes red
•
Battery power is low (lower than 10 %)
•
Overheating
Red
•
The battery is charging.
Green
•
The battery is fully charged.
Red
→
Green
→
Blue
•
Waiting for the mobile device to connect
Blue
•
Connected to the mobile device
Flashes blue
•
Transferring videos or photos
•
Updating software

Basics
9
Camera status screen
Access menus, such as camera modes and connection modes, and view the Gear 360’s status
via messages and indicator icons on the camera status screen.
Camera status screen
Indicator icons
Indicator icons appear on the camera status screen. You can check the Gear 360’s status on
the camera status screen.
Current shooting mode
Available video
recording time /
Available number of
photos you can take
Mobile device
connection status
Battery power /
Charging status

Basics
10
Icon Meaning
Battery power level
Battery charging status
•
: Charging
•
: Overheating
•
: Charger connected improperly
/ Connected to a mobile device
Waiting for the mobile device to connect
Not connected to a mobile device
Recording mode
Recording a video
Photo shooting mode
Time lapse mode
Take several photos at set intervals and save them as one video.
Time lapse shooting interval
Recording a time lapse video
Video looping mode
Record a video continuously by deleting a set period of the previously
recorded content and saving the new content.
Video looping recording time
Landscape HDR mode
Automatically take three photos, combine them, and then calibrate the
colours.
Live broadcast mode
Broadcasting a live video
Memory card is full
No memory card / Memory card error
Connected to a computer with a USB cable
USB connection error

Basics
11
Memory card
Installing a memory card
A memory card must be inserted to record videos or take photos. Depending on the memory
card manufacturer and type, some memory cards may not be compatible with your Gear 360.
•
Some memory cards may not be fully compatible with the Gear 360. Using an
incompatible card may damage the Gear 360 or the memory card, or corrupt the
data stored in it.
•
If you use a slow writing memory card, the recording of your video can be
interrupted because the card cannot process data at the rate the video is being
shot. If this occurs, replace the card with a faster memory card or reduce the video
resolution.
•
Use caution to insert the memory card right-side up.
•
Memory cards are sold separately.
•
If you insert or remove a memory card while the Gear 360 is turned on, the power
will turn off.
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When a memory card is not inserted, Check SD Card is displayed on the camera
status screen.

Basics
12
1 Pull out the memory card tray gently from the memory card tray slot.
Memory card tray
Be careful not to damage your fingernails when you remove the memory card tray.
2 Gently press the memory card into the memory card tray with the gold-coloured
contacts properly aligned with the Gear 360’s contacts.
3 Insert the memory card tray back into the memory card tray slot.
Memory card
Memory card tray slot

Basics
13
Removing the memory card
1 Pull out the memory card tray gently from the memory card tray slot.
2 Remove the memory card.
3 Insert the memory card tray back into the memory card tray slot.
Formatting the memory card
A memory card formatted on a computer may not be compatible with the Gear 360. Format
the memory card on the Gear 360 or on the mobile device.
Before formatting the memory card, remember to make backup copies of all
important data stored in the memory card. The manufacturer’s warranty does not
cover loss of data resulting from user actions.
Formatting on the Gear 360
1 Press the Menu key until
Settings appears on the camera status screen, and then press
the OK key to select it.
2 Press the Menu key until
Format appears on the camera status screen, and then press the
OK key to select it.
3 Press the Menu key until
Yes appears on the camera status screen, and then press the OK
key to select it.
A confirmation message will appear on the camera status screen when the formatting is
finished.

Basics
14
Formatting on the mobile device
1 On the mobile device, tap the
Samsung Gear 360 app or the Gear 360 app
→
Settings .
2 Tap
Reset and format
→
Format Gear 360 SD card .
A confirmation message will appear on the camera status screen when the formatting is
finished.
If you want to format a memory card on the mobile device, you must connect the
Gear 360 to the mobile device. Refer to Connecting the Gear 360 to a mobile device
for more information.
Battery
Charging the battery
Charge the battery before using the Gear 360 for the first time or when it has been unused for
extended periods.
Use only Samsung-approved chargers. Unapproved chargers can cause the battery to
explode or damage the Gear 360.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•
Chargers are sold separately.
•
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.

Basics
15
1 Plug the small end of the charger into the multipurpose jack of the Gear 360, and plug
the large end of the charger into an electric socket.
Multipurpose jack
(USB Type-C)
2 After fully charging, disconnect the Gear 360 from the charger. First unplug the charger
from the Gear 360, and then unplug it from the electric socket.

Basics
16
Battery charging tips and precautions
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the device cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few minutes
before turning on the device.
•
Using a power source other than the charger, such as a computer, may result in a slower
charging speed due to a lower electric current.
•
The device can be used while it is charging, but it may take longer to fully charge the
battery.
•
While charging, the Gear 360 and the charger may heat up. This is normal and should not
affect the Gear 360’s lifespan or performance. If the temperature rises above a certain
level, battery charging will be stopped.
•
You cannot charge the Gear 360 while recording a video, using the time lapse feature, or
using the viewfinder remotely on the connected mobile device.
•
To save the battery power, activate the auto shut-off feature.
•
When you do not use the auto shut-off feature, the battery will be charged only when the
Gear 360 is turned off.
•
If the Gear 360 is not charging properly, take the Gear 360 and the charger to a Samsung
Service Centre.

Basics
17
Attaching the strap to the Gear 360
You can conveniently carry the Gear 360 by attaching the strap to the Gear 360. Insert the
strap into the strap hole, and then pull the loop.
1
2
You can also use the strap’s rubber ring to fix the Gear 360 to record videos or take photos.

Basics
18
Turning the Gear 360 on and off
Press and hold the Power key to turn on the Gear 360.
To turn off the Gear 360, press and hold the Power key.
•
The Gear 360 turns off if it is not used for a specified period. By using the Auto
power off after
option, you can set the length of time the Gear 360 waits before it
turns off. Refer to Configuring the settings for more information.
•
Follow all posted warnings and directions from authorised personnel in areas, such
as aeroplanes and hospitals.
Restarting the Gear 360
If your Gear 360 is frozen and unresponsive, press and hold the Power key for more than
7 seconds to restart it.

Basics
19
Connecting the Gear 360 to a mobile device
Installing the app on a mobile device
To connect your Gear 360 and mobile device, install the Samsung Gear 360 app or the Gear
360 app on the mobile device.
Download the Samsung Gear 360 (New) app from
Galaxy Apps or Play Store .
For iOS devices, download the Samsung Gear 360 app from
App Store .
Depending on your mobile device, it may not be compatible with the Gear 360 or
may not support some features. Visit www.samsung.com to see a list of compatible
mobile devices.
Connecting to a mobile device
To control the Gear 360 from your mobile device, the Gear 360 must be paired with the
mobile device. After the Gear 360 has paired with the mobile device, the Gear 360 will try to
connect to the mobile device every time you turn on the Gear 360.
For Android devices, you can capture videos and photos and view them on your mobile
device via Wi-Fi Direct after connecting for the first time.
Connection methods may vary depending on your mobile device and software
version. To connect with an iOS device, connect the Gear 360 with the mobile device
in the Wi-Fi settings, launch the Gear 360 app, and then complete the connection.
Gear 360
1 Turn on the Gear 360.
2 Press and hold the Menu key.

Basics
20
3 When
Connect to Android appears on the camera status screen, press the OK key.
For iOS devices, press the Menu key again, and when
Connect to iOS appears on the
camera status screen, press the OK key.
If you connect the Gear 360 to your iOS mobile device via Wi-Fi, iOS mobile device
pairing mode (Wi-Fi) will be activated automatically from next time without having
to press the Menu key. Also, Connect to iOS appears on the camera status screen first
when you press and hold the Menu key.
Mobile device
4 Launch the
Samsung Gear 360 app on the mobile device.
For iOS devices, launch the
Gear 360 app.
5 Tap
CONNECT TO GEAR 360 .
6 Follow the on-screen instructions to complete the connection.
When your Gear 360 and mobile device are connected, the Bluetooth or Wi-Fi icon will
appear on the camera status screen.
