Samsung CS21K5 User manual

COLOUR
TELEVISION
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ENG
REMOTE CONTROL
ON-SCREEN MENUS
ENJOY GAME (depending on the model)
TELETEXT FUNCTION (depending on the model)

2
ENG
Safety Instructions
The following illustrations represent the precautions to be taken when using and moving your television.
5¡
10%
HH
35¡ 75%
THIS DEVICE IS NOT FOR USE IN INDUSTRIAL ENVIRONMENTS
Caution
CAUTION: TO PREVENT ELECTRICAL SHOCK, DO
NOT REMOVE REAR COVER, NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Do NOT expose the television to
extreme temperature conditions or
to extreme humidity conditions.
Do NOT expose the television to
direct sunlight.
Do NOT expose the television to
any liquids.
If the television is broken, do not
try to repair it yourself. Contact
qualified service personnel.
During a storm conditions
(especially when there is lightning)
unplug the television from the
mains socket and aerial.
If the remote control is not used for
a long period of time, remove the
batteries and store it in a cool, dry
place.
WARNING: TO PREVENT DAMAGE WHICH MAY
RESULT IN FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
The lightning flash and arrow
head within the triangle is a
warning sign alerting you of
“dangerous voltage” inside the
product.
The exclamation point within the
triangle is a warning sign alerting
you of important instructions
accompanying the product.
➢Please use a soft and dry cloth (not containing volatile matter) when you clean the TV.
☛The main voltage is indicated on the
rear of the TV set and the frequency is
50 or 60Hz.

3
ENG
Contents
◆PREPARING YOUR TELEVISION
■Safety Instructions ................................................................................................ 2
■Caution ................................................................................................................. 2
■Control Panels ...................................................................................................... 4
■Connection Panels ............................................................................................... 5
■Viewing Picture From External Sources ............................................................... 7
■Infrared Remote Control (All Functions Except Teletext) ..................................... 8
■Infrared Remote Control (Teletext Functions) ...................................................... 9
■Inserting the Batteries in the Remote Control....................................................... 10
■Connecting the Aerial (or Cable Television Network)........................................... 10
■Switching Your Television On and Off.................................................................. 11
■Placing Your Television in Standby mode ............................................................ 11
■Plug & Play Feature.............................................................................................. 12
■Viewing the Demonstration................................................................................... 13
■Choosing Your Language..................................................................................... 13
◆SETTING UP THE CHANNELS
■Storing the Channels Automatically...................................................................... 14
■Selecting a Channel Numbered Ten or Over ....................................................... 14
■Storing the Channels Manually............................................................................. 15
■Skipping Unwanted Channels .............................................................................. 16
■Fine tuning Channel Reception ............................................................................ 17
■Sorting the Stored Channels ................................................................................ 18
◆USING THE TELEVISION
■Changing the Picture Standard ............................................................................ 19
■Adjusting the Picture Settings .............................................................................. 20
■Setting the Digital Noise Reduction ..................................................................... 21
■Setting the Blue Screen ....................................................................................... 21
■Selecting the Picture Format ................................................................................ 22
■Changing the Sound Standard ............................................................................. 22
■Adjusting the Sound Settings (depending on the model) ..................................... 23
■Extra Sound Settings
(Auto Volume/Melody/Pseudo Stereo/Turbo Sound) ........................................... 24
■Selecting the Sound Mode (depending on the model) ......................................... 25
■Adjusting the Volume............................................................................................ 26
■Switching the Sound Off Temporarily ................................................................... 26
■Setting the Sleep Timer (depending on the model) .............................................. 27
■Setting and Displaying the Current Time (depending on the model).................... 28
■Switching the Television On and Off Automatically (depending on the model) .... 29
■Activating the Child Lock ...................................................................................... 30
■Enjoying Games (depending on the model) ......................................................... 31
◆USING THE TELETEXT FUNCTION (depending on the model)
■Teletext Decoder .................................................................................................. 32
■Displaying Teletext Information ............................................................................ 32
■Selecting a Specific Teletext Page....................................................................... 33
■Using FLOF to Select a Teletext Page ................................................................. 34
■Storing Teletext Pages ......................................................................................... 34
◆INFORMATION ON CONNECTIONS AND RECOMMENDATIONS FOR USE
■Automatic Degaussing to Remove Color Patches................................................ 35
■Troubleshooting: Before Contacting Service Personnel....................................... 35
☛➢
Symbols
Press Important Note

4
ENG
Control Panels
➢The actual configuration on your TV may be different, depending on
your model.
ŒINPUT SOURCE SELECTION
´MENU DISPLAY
ˇVOLUME ADJUSTMENT
¨CHANNEL SELECTION
ˆSTANDBY INDICATOR
ØREMOTE CONTROL SENSOR
∏POWER ON/OFF
➣Using the Buttons on the Panel
If the remote control no longer works or you have lost it, you can use controls on the panel of the TV to:
◆Switch on the TV when it is in Standby mode and select channels ( ▼CH ▲)
◆Access the main menu ( MENU )
◆Adjust the volume ( - VOL + )
◆Switch among Video input modes ( TV/VIDEO )

5
ENG
Connection Panels
➢The actual configuration on your TV may be different, depending on
your model.
ŒAUDIO/VIDEO INPUT
´HEADPHONE CONNECTOR
Side of the TV Front of the TV
ŒConnecting External A/V Devices (INPUT)
The RCA (VIDEO + AUDIO-L and R) connectors are used for equipment such as camcorders, video disc
players and some video game devices.
➣◆When both the side (or front) and rear connectors are connected to external equipment, the side
(or front) AV has the priority.
◆When using the mono equipment such as camcorders, video disc players and some video game
devices, connect to the “AUDIO-L” input connector.
´Connecting Headphones
- You can connect a set of headphones to your television if you wish to watch a television programme without
disturbing the other people in the room.
- Prolonged use of headphones at a high volume may damage your hearing.
☛Whenever you connect an audio or video system to your
television, ensure that all elements are switched off.
Refer to the documentation supplied with your equipment for
detailed connection instructions and associated safety
precautions.

ENG
6
Connection Panels (continued)
➢The actual configuration on your TV may be different, depending on
your model.
INPUT 1
MONITOR
-OUT
INPUT 2
VIDEO
(MONO)
L-AUDIO-R
INPUT 1
MONITOR
-OUT
INPUT 2
VIDEO
(MONO)
L-AUDIO-R
RGB
2
1
Ϋ Connecting External A/V Devices (INPUT/OUTPUT)
The connectors (RCA or SCART) are used for equipment such as video disc players, video game devices,
camcorder and VCR.
ˇConnecting DVD
The RCA (Y + Pb + Pr + AUDIO-L and R) connectors are used for a DVD.
➣When using the mono equipment such as camcorders, video disc players and some video game
devices, connect to the “AUDIO-L”input connector.
Rear of the TV

7
ENG
Viewing Pictures From External Sources
Once you have connected up your various audio and video systems,
you can view the different sources by selecting the appropriate input.
1Check that all the necessary connections have been made.
2Switch the television on and if necessary, press the VIDEO
button one or more times until the required input is displayed.
➢Depending on the source selected, the pictures may appear
automatically.
➢To watch television programmes again, press the TV
button and select the number of the channel required.

8
ENG
Infrared Remote Control (All Functions Except Teletext)
➣ Operation of remote control may be affected by bright artificial light near to the TV set.
POWER
SOUND MENU DISPLAY
ONE/TWO-DIGIT CHANNEL
SELECTION
TURBO SOUND ON/OFF
TEMPORARY SOUND SWITCH-
OFF
VOLUME DECREASE
PREVIOUS CHANNEL
DIRECT CHANNEL SELECTION
TUNER/CABLE NETWORK
SELECTION
EXTERNAL INPUT SELECTION
ON-SCREEN DISPLAY
AUTOMATIC SWITCH-OFF
PICTURE SIZE
NEXT CHANNEL
VOLUME INCREASE
PICTURE STANDARD
SOUND STANDARD
SOUND MODE SELECTION
MENU DISPLAY
➣Buttons and markings are subject to change.
GAME DISPLAY
(OPTION)

9
ENG
Infrared Remote Control (Teletext Functions)
1
1
?
TELETEXT HOLD
FASTEXT TOPIC SELECTION
TELETEXT NEXT PAGE
TELETEXT PREVIOUS PAGE
TELETEXT DISPLAY/MIX
LIST/FLOF MODE SELECTION
TELETEXT REVEAL
TELETEXT STORE
PICTURE SIZE
TELETEXT SUB-PAGE
PROGRAMME SELECTION
BY NAME
➣Buttons and markings are subject to change.

10
ENG
You must insert or replace the batteries in the remote control when
you :
◆Purchase the television.
◆Find that the remote control is no longer operating
correctly.
1Remove the cover of the remote control by pressing the symbol
( ) and pulling the cover in the direction of the arrow.
2Insert batteries, taking care to respect the polarities:
◆+on the battery with +on the remote control
◆ - on the battery with - on the remote control
3Replace the cover by pushing it in the direction of the arrow.
PRESS
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
Plug the aerial or cable network input cable to the 75Ωcoaxial socket
on the rear of the television.
Inserting the Batteries in the Remote Control
Connecting the Aerial (or Cable Television Network)
75Ω
Cable
Television
Network
Rear of TV

11
ENG
The mains lead is attached to the rear of the television.
1Plug the mains lead into an appropriate socket.
➢The main voltage is indicated on the rear of the TV set and
the frequency is 50 or 60Hz.
2Press the “”(ON/OFF) button on the front of the television.
Result: The Standby indicator lights up on the front panel.
3Press the POWER button on the remote control to switch the
television on.
Result: The programme that you were watching last is re-
selected automatically.
4To switch your television off, press the “”(ON/OFF) button
again on the front of the television.
Placing Your Television in Standby mode
Your television can be placed in Standby mode, in order to reduce:
◆Power consumption
◆Wear of the cathode ray tube
The Standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
The television is placed automatically in Standby mode when you
turn it on.
1Press the POWER button on the remote control.
Result: The screen is turned off and the Standby indicator on
the front of the television lights up.
2To switch the screen back on, simply press the POWER button
again on the remote control.
➣Do not leave your television in standby mode for long
periods of time (when you are away on holiday, for example).
In this case, you should switch it off completely.
Switching Your Television On and Off

12
ENG
Plug & Play Feature
Plug & Play
Auto Store Exit
Ant. Input Check
Exit
P 1
471 MHz 48 %
When the television is initially powered ON, three basic customer
settings proceed automatically and subsequently: setting the
language, channel and clock.
1If the television is in Standby mode, press the POWER button
on the remote control.
Result: The message “Plug & Play”is displayed. It flickers for a
little while and then the “Language”menu is automatically
displayed.
2Press the ▲or ▼button to select required language. Press the
MENU button to enter the language, and then the message “Ant.
Input Check”is displayed.
➣If any language is not selected on the “Language”menu, the
“Language”menu will be displayed about 30 seconds later.
3Make sure that the antenna is connected to the TV. And then press
the +or –button to store the channels (refer to “Storing the
Channels Automatically”on page 14).
Result: The horizontal bar is displayed, and then channels are
stored in an order which reflects their positions in the
frequency range.
4When searching and storing is complete, the “Time”menu is
displayed.
5Press the +or –button to move to the hour or minute. Set the hour
or minute by pressing the ▲or ▼button (refer to “Setting and
Displaying the Current Time”on page 28).
6When you have finished, press the MENU button.
Result: The message “ENJOY YOUR WATCHING”is displayed,
and then the channel which has been stored will be
activated.
7If you want to reset this feature...
1Press the MENU button.
2Press the ▲or ▼button to select the “Function”, and then
press the +or –button.
3Select the “Plug & Play”by pressing the ▲or ▼button, and
then press the +or –button.
Result: The message “Plug & Play”is displayed.
Move Exit
Time
Clock 11 : 35
Enjoy Your Watching...
Select Enter Exit
Language : English
Time
Plug & Play
Blue Screen : Off
Child Lock
Demonstration
Function
ENJOY YOUR WATCHING
Time
Clock - - : - - AM

13
ENG
Viewing the Demonstration
To become familiar with the various menus provided by your
television, you can view the inbuilt demonstration.
1Press the MENU button.
2Press the ▲or ▼button to select the “Function”and press the +or
–button.
3Press the ▲or ▼button to select the “Demonstration”and press
the +or –button.
Result: Each of the menu options is displayed in turn.
4When you wish to exit from the demonstration, press the TV
button.
Select Enter Exit
Language : English
Time
Plug & Play
Blue Screen : Off
Child Lock
Demonstration
Function
Choosing Your Language
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU button.
2Press the ▲or ▼button to select the “Function”and press the +or
–button.
Result: The “Language”is selected.
3Press the +or –button again.
Result: The languages available are listed.
4Select a particular language by pressing the ▲or ▼button
repeatedly.
5When you have finished, press the TV button or, press the
MENU button repeatedly to return to normal viewing.
Select Adjust Exit
Language : English
Time
Plug & Play
Blue Screen : Off
Child Lock
Demonstration
Function

14
ENG
Exit
P 1
471 MHz 48 %
Storing the Channels Automatically
Select Enter Exit
Mode Custom
Adjust
Digital NR : Off
Select Enter Exit
Auto Store
Manual Store
Add/Erase
Fine Tune
Sort
Channel
Select Adjust Exit
Sort
From : P 1
To : P--
Store : ?
Channel
Selecting a Channel Numbered Ten or Over
When using the numeric buttons to select a channel stored at
programme position ten or higher, follow the instructions below.
1Press the -/-- button.
Result: The “
-- ”symbol is displayed.
2Enter the two-digit channel number.
Example: To select channel 42, press 4, followed by 2.
You can scan the frequency ranges available on your television and
in your country and store all the channels found automatically.
The channels are stored in the order in which they appear in the
frequency bands. It is possible that the automatically allocated
numbers may not correspond to those by which you wish to
identify the channels. If this is the case, refer to “Sorting the Stored
Channels” on page 18.
1Press the MENU button.
2Press the ▲or ▼button to select the “Channel”.
3Press the +or –button to select the “Auto Store”.
4Press the +or –button again.
Result: The horizontal bar is displayed, and then channels are
stored in an order which reflects their positions in the
frequency range. Finally, the search will end automatically.
5When searching and storing is complete, the “Sort”menu is
displayed.
To... Then...
Sort the stored channels Go to Step 4of the “Sorting
into the desired numerical order the Stored Channels”
procedure on page 18.
Exit the channel store function Press the MENU button
without sorting the channels repeatedly until the menus
disappear.
➣If sound does not work regularly after storing channels, select
the sound system which best corresponds in “Manual Store”
menu (refer to the opposite page).

15
ENG
When storing channels manually, you can choose:
◆Whether or not to store each of the channels found.
◆The number by which you wish to identify each stored
channel.
1Press the MENU button.
2Press the ▲or ▼button to select the “Channel”and press the +or
–button.
3Press the ▲or ▼button to select the “Manual Store”and press the
+or –button.
Result: The “Manual Store”menu is displayed with the “Color
System”selected.
4Press the +or –button repeatedly until the color is of the best
quality.
Result: The “Color System”is changed (depending on the
model).
AUTO ↔ PAL ↔ SECAM ↔ NTSC4.43 ↔ NTSC3.58
➣NTSC4.43 is a “trick”playback mode used
by special VCR’s to play PAL-recorded
videos in NTSC mode.
5Press the ▲or ▼button to select the “Sound System”and press
the +or –button repeatedly until the sound is of the best quality.
Result: The “Sound System”is changed (depending on the
model).
B/G ↔ I↔ D/K ↔ M
➣If sound does not work regularly after storing
channels, select the sound system which best
corresponds.
6To start the search, select the “Search”and then press the +or –
button.
Result: The tuner scans the frequency range until the first
channel or the channel that you selected is received on
your screen.
7To assign a programme number to the channel, select the
“Prog.No.”. Press the +or –button until you find the correct
number.
8To store the channel and associated programme number, select
the “Store”and press the +or –button.
Result: “OK”is displayed.
9Repeat Steps 6to 8for each channel to be stored.
10 When you have finished manual storage, press the TV button
or, press the MENU button repeatedly to return to normal viewing
Storing the Channels Manually
Select Adjust Exit
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Channel
Select Adjust Exit
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Channel
➞
➞
Select Enter Exit
Auto Store
Manual Store
Add/Erase
Fine Tune
Sort
Channel
Select Adjust Exit
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Channel
➞
➞
Select Adjust Exit
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Channel
Select Adjust Exit
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : OK
Channel
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : OK

You can exclude the channels of your choice from the channel scan
operation. When you scan through the stored channels, those you
have chosen to skip are not displayed.
All channels that you do not specifically choose to skip are
displayed during scanning.
1Press the MENU button.
2Press the ▲ or ▼ button to select the “Channel”and press the +or
–button.
3Press the ▲ or ▼ button to select the “Add/Erase”and press the +
or –button.
Result: The “Add/Erase”menu is displayed.
4Press the ▲ or ▼button to select the required channel.
5To add or erase the desired channel by pressing the +or –button.
6When you have finished adding and erasing channels, press the
TV button or, press the MENU button repeatedly to return to
normal viewing
16
ENG
Select Adjust Exit
Add/Erase
P 1 : Erased
P 2 : Added
P 3 : Added
P 4 : Added
Channel
Select Enter Exit
Auto Store
Manual Store
Add/Erase
Fine Tune
Sort
Channel
Select Adjust Exit
Add/Erase
P 1 : Added
P 2 : Added
P 3 : Added
P 4 : Added
Channel
Skipping Unwanted Channels

17
ENG
If the reception is clear, you do not have to fine-tune the channel,
as this is done automatically during the search and store operation.
If however the signal is weak or distorted, you may have to fine-
tune the channel manually.
1Press the MENU button.
2Press the ▲ or ▼ button to select the “Channel”and press the +or
–button.
3Press the ▲ or ▼ button to select the “Fine Tune”and press the +
or –button.
Result: The “Fine Tune”menu is displayed with the “Tune”
selected.
4To... Press the...
obtain a sharp and ◆+or –button.
clear picture and Result: The horizontal bar’s
good sound quality cursor moves to the left
or right.
memorise adjusted ◆▲ or ▼button to select the “Store”.
picture or sound ◆+or –button.
Result: “OK”is displayed.
erase adjusted ◆▲ or ▼button to select the “Erase”.
picture or sound ◆+or –button.
Result: “OK”is displayed.
5When you have finished, press the TV button or, press the
MENU button repeatedly to return to normal viewing.
Fine tuning Channel Reception
Select Adjust Exit
Fine Tune
Tune : -/+
Store : OK
Erase : ?
Channel
Fine Tune +1
Select Enter Exit
Auto Store
Manual Store
Add/Erase
Fine Tune
Sort
Channel
Select Adjust Exit
Fine Tune
Tune : -/+
Store : ?
Erase : ?
Channel
Select Adjust Exit
Fine Tune
Tune : -/+
Store : ?
Erase : OK
Channel

You can exchange the numbers of two channels, in order to:
◆Modify the numeric order in which the channels have
been automatically stored.
◆Give easily remembered numbers to the channels that
you watch most often.
1Press the MENU button.
2Press the ▲ or ▼ button to select the “Channel”and press the +or
–button.
3Press the ▲ or ▼ button to select the “Sort”and press the +or –
button.
Result: The “Sort”menu is displayed with the “From”selected.
4Press the +or –button until the channel number that you wish to
change is displayed.
Result: The selected channel’s picture is displayed.
5Press the ▲ or ▼ button to select the “To”.
6Press the +or –button until the new number by which you wish to
identify the channel is displayed.
Result: The selected channel is exchanged with the one
previously stored to the chosen number.
Example: If you select “P 1”for the “From”and “P 3”for the “To”:
◆Channel 1 becomes channel 3.
◆Channel 3 becomes channel 1.
7To... Press the...
Confirm the exchange ◆▲ or ▼button to select the “Store”.
of channel numbers ◆+or –button.
Result: “OK”is displayed.
➣You can exchange other
channel numbers by selecting
“From”and returning to step 4.
8When you have finished sorting channels, press the TV button
or, press the MENU button repeatedly to return to normal viewing
18
ENG
Select Adjust Exit
Sort
From : P 1
To : P 3
Store : ?
Channel
Select Adjust Exit
Sort
From : P 3
To : P 1
Store : OK
Channel
Select Enter Exit
Auto Store
Manual Store
Add/Erase
Fine Tune
Sort
Channel
Select Adjust Exit
Sort
From : P 1
To : P--
Store : ?
Channel
Sorting the Stored Channels

19
ENG
You can select the type of picture which best corresponds to your
viewing requirements. The following picture effects are available in
the order given:
◆Custom, Standard, Sports, Natural, Mild.
1Press the MENU button.
Result: The “Picture”menu is displayed.
2Press the +or –button.
Result: The “Mode”menu is selected.
3Select to satisfy your preference by pressing the +or –button.
4When you have been finished, press the TV button or, press the
MENU button repeatedly to return to normal viewing.
➣You can select the required picture effect by simply
pressing the “P.STD”(Picture standard) button on the
remote control.
Changing the Picture Standard
Select Adjust Exit
Mode Custom
Adjust
Digital NR : Off

20
ENG
Adjusting the Picture Settings
Your television has several settings which allow you to control picture
quality:
◆Color Tone, Contrast, Brightness, Sharpness, Color,
Tint (NTSC only)
1Press the MENU button.
Result: The “Picture”menu is displayed.
2Press the +or –button.
3Press the ▲ or ▼ button to select the “Adjust”, and then press the +
or –button.
Result: When select the “Mode”to “Custom”, the “Adjust”menu is
displayed.
4To adjust the... Press the...
◆Color Tone ◆+or –button.
Result: You select the required option
(Normal, Warm1, Warm2,
Cool1, Cool2).
◆Contrast ◆+or –button.
◆Brightness Result: The horizontal bar is displayed.
◆Sharpness
◆Color
◆Tint (NTSC only)
➣The “Sharpness”and “Tint”are not available in DVD
mode.
5When you are satisfied with the settings, press the TV button or,
press the MENU button repeatedly to return to normal viewing.
➣The television has an “automatic degaussing”system that is
activated if magnetic interference is present. To degauss the
television screen, switch power off by pressing the “”
(ON/OFF) button on the front panel (refer to “Automatic
Degaussing to Remove Color Patches”on page 35).
➣If you make any changes to the “Adjust”settings, the picture
standard is automatically switched to “Custom”.
Select Enter Exit
Mode Custom
Adjust
Digital NR : Off
Select Adjust Exit
Adjust
Color Tone : Normal
Contrast 100
Brightness 50
Sharpness 50
Color 50
Contrast 91
Select Adjust Exit
Adjust
Color Tone : Normal
Contrast 100
Brightness 50
Sharpness 50
Color 50
Contrast 100
