Samsung EVNX200ZBSBUS User manual

This user manual includes detailed usage instructions for your camera.
Please read this manual thoroughly.
ENG
User Manual

1
Copyright information
PlanetFirst represents Samsung Electronics' commitment
to the sustainable development and social responsibility
through eco-driven business and management activities.
• Microsoft Windows and the Windows logo are registered trademarks
of the Microsoft Corporation.
• Mac is a registered trademark of the Apple Corporation.
• HDMI, the HDMI logo, and the term
“High Definition Multimedia Interface” are
trademarks or registered trademarks of HDMI
Licensing LLC.
• Trademarks and trade names used in this manual are the property of
their respective owners.
• Camera specifications or contents of this manual may be changed
without prior notice due to upgrade of camera functions.
• You are not allowed to reuse or distribute any part of this manual
without prior permission.
• For Open Source License information, refer to the
“OpenSourceInfo.pdf” in the provided CD-ROM.

2
Health and safety information
Prevent damage to subjects’ eyesight.
Do not use the flash in close proximity (closer than 1 m/3 ft) to people
or animals. If you use the flash too close to your subject’s eyes, this can
cause temporary or permanent eyesight damage.
Keep your camera away from small children and pets.
Keep your camera and all accessories out of the reach of small
children and animals. Small parts may cause choking or serious injury
if swallowed. Moving parts and accessories may present physical
dangers as well.
Do not expose the camera to direct sunlight or high
temperatures for an extended period of time.
Prolonged exposure to sunlight or extreme temperatures can cause
permanent damage to your camera’s internal components.
Avoid covering the camera with blankets or clothes.
The camera may overheat, which may distort the camera or cause a
fire.
If liquid or foreign objects enter your camera, immediately
disconnect all power sources, such as the battery, and
then contact a Samsung service center.
Always comply with the following precautions and usage tips to avoid
dangerous situations and ensure peak performance of your camera.
Warning—situations that could cause injury to
yourself or others
Do not disassemble or attempt to repair your camera.
This may result in electric shock or damage to the camera.
Do not use your camera near flammable or explosive
gases and liquids.
This may cause a fire or explosion.
Do not insert flammable materials into the camera or store
these materials near the camera.
This may cause a fire or electric shock.
Do not handle your camera with wet hands.
This may result in electric shock.

3
Health and safety information
Caution—situations that could cause damage to your
camera or other equipment
Remove the batteries from your camera when storing it for
an extended period of time.
Installed batteries may leak or corrode over time and cause serious
damage to your camera.
Use only authentic, manufacturer-recommended, Lithium-
ion replacement batteries. Do not damage or heat the
battery.
Inauthentic, damaged, or heated batteries may cause a fire or personal
injury.
Use only Samsung-approved batteries, chargers, cables
and accessories.
• Using unauthorized batteries, chargers, cables or accessories can
cause batteries to explode, damage your camera, or cause injury.
• Samsung is not responsible for damage or injuries caused by
unapproved batteries, chargers, cables or accessories.
Use the battery only for its intended purpose.
Misusing the battery may cause a fire or electric shock.
Do not touch the flash while it fires.
The flash is very hot when fired and may burn your skin.
Do not use a damaged power supply cord, plug, or loose
outlet when you charge batteries.
This may cause a fire or electric shock.
Do not force the camera’s parts or apply pressure to the
camera.
This may cause your camera to malfunction.
Exercise caution when you connect cables and install
batteries and memory cards.
If you force the connectors, improperly connect cables, or improperly
install batteries and memory cards, you can damage ports, connectors,
and accessories.
Keep cards with magnetic strips away from the camera
case.
Information stored on the card may be damaged or erased.
Never use a damaged battery, or memory card.
This may result in electric shock or camera malfunction or cause a fire.

4
Health and safety information
Check that the camera is operating properly before use.
The manufacturer takes no responsibility for any loss of files or damage
that may result from camera malfunction or improper use.
You must plug the small end of the USB cable into your
camera.
If the cable is reversed, it may damage your files. The manufacturer is
not responsible for any loss of data.
Protect your camera’s lens.
Do not expose the lens to direct sunlight, as this may discolor the image
sensor or cause it to malfunction.
If the camera overheats, remove the battery and allow it to
cool down.
• Prolonged usage of the camera may overheat the battery and raise
the internal temperature of the camera. If the camera stops operating,
remove the battery and allow it to cool down.
• High internal temperatures may result in noise in your photos. This is
normal and does not affect your camera’s overall performance.

5
Indications used in this manual
Shooting mode indications
Shooting mode Indication
Smart Auto
t
Program
P
Aperture Priority
A
Shutter Priority
S
Manual
M
Lens Priority
i
Magic
N
Panorama
p
Scene
s
Movie
v
Icons used in this manual
Icon Function
Additional information
Safety warnings and precautions
[ ]
Camera buttons. For example, [Shutter] represents the
shutter button.
( )
Page number of related information
►
The order of options or menus you must select to
perform a step; for example: Select 1►Quality
(represents select 1, and then Quality).
The number next to the icon may vary depending on
the shooting mode. That is, some options may be
located under 2or 3.
*
Annotation

6
Contents
Chapter 1
My Camera
Getting started ............................................................................ 25
Unpacking..................................................................................... 25
Camera layout ............................................................................. 26
Display icons ............................................................................... 29
In Shooting mode.......................................................................... 29
Capturing photos ............................................................................ 29
Recording videos ............................................................................ 30
In Playback mode.......................................................................... 31
Viewing photos ............................................................................... 31
Playing videos ................................................................................. 31
Lenses.......................................................................................... 32
Lens layout.................................................................................... 32
Locking or unlocking the lens.......................................................... 33
Lens markings............................................................................... 35
Accessories ................................................................................. 36
External flash layout....................................................................... 36
Connecting the flash...................................................................... 37
GPS module layout (optional)......................................................... 39
Attaching the GPS module ............................................................ 39
Tips
Concepts in Photography
Shooting postures....................................................................... 11
Holding the camera.......................................................................... 11
Standing photography...................................................................... 11
Crouching photography ................................................................... 12
Aperture ....................................................................................... 12
Aperture value and the depth of field................................................ 13
Shutter speed.............................................................................. 14
ISO sensitivity.............................................................................. 15
How the aperture setting, shutter speed, and ISO sensitivity
control exposure ......................................................................... 16
Correlation between focal length, angle, and perspective....... 17
Depth of field ............................................................................... 18
What controls out-of-focus effects? ................................................. 18
DOF preview .................................................................................... 20
Composition ................................................................................ 20
Rule of Thirds.................................................................................. 20
Photos with two subjects ................................................................. 21
Flash............................................................................................. 22
Flash guide number.......................................................................... 22
Bounce Photography ....................................................................... 23

7
Contents
Shooting modes .......................................................................... 41
tSmart Auto mode............................................................ 41
PProgram mode........................................................................... 42
Program Shift.................................................................................. 42
AAperture Priority mode .............................................................. 43
SShutter Priority mode ................................................................. 43
MManual mode............................................................................ 44
Framing mode................................................................................. 44
Using bulb....................................................................................... 44
iLens Priority mode ................................................................... 45
Using the Emode ................................................................ 45
Using i-Function in PASM modes ................................................. 46
Using i-Zoom .................................................................................. 47
NMagic mode ......................................................................... 48
pPanorama mode..................................................................... 48
sScene mode ..................................................................... 49
vMovie mode............................................................................ 51
Available functions by shooting mode............................................ 52
Chapter 2
Shooting Functions
Size .............................................................................................. 54
Photo size options......................................................................... 54
Video size options ......................................................................... 55
Quality.......................................................................................... 56
Photo quality options..................................................................... 56
Video quality options ..................................................................... 56
ISO sensitivity.............................................................................. 57
White Balance (light source)....................................................... 58
White Balance options................................................................... 58
Customizing preset options............................................................. 59
Picture Wizard (photo styles)...................................................... 61
AF mode ...................................................................................... 62
Single AF....................................................................................... 62
Continuous AF............................................................................... 63
Manual focus................................................................................. 63
AF area......................................................................................... 64
Selection AF .................................................................................. 64
Multi AF......................................................................................... 65
Face detection AF ......................................................................... 65
Self-portrait AF .............................................................................. 66
MF assist ..................................................................................... 67
Optical Image Stabilization (OIS)................................................ 68
OIS options ................................................................................... 68

8
Contents
Drive (shooting method) ............................................................. 69
Single ............................................................................................ 69
Continuous.................................................................................... 69
Burst ............................................................................................. 70
Timer............................................................................................. 70
Auto Exposure Bracketing (AE Bracket)......................................... 71
White Balance Bracketing (WB Bracket) ........................................ 71
Picture Wizard Bracketing (P Wiz Bracket)..................................... 72
Bracketing setting.......................................................................... 72
Flash............................................................................................. 73
Flash options................................................................................. 73
Correcting the red-eye effect ......................................................... 74
Adjusting the flash intensity............................................................ 74
Metering....................................................................................... 75
Multi .............................................................................................. 75
Center-weighted............................................................................ 76
Spot .............................................................................................. 76
Measuring the exposure value of the focus area ............................ 77
Smart Range................................................................................ 78
Color space ................................................................................. 79
Exposure compensation/lock..................................................... 80
Exposure compensation ................................................................ 80
Exposure lock................................................................................ 80
Video functions............................................................................ 81
Movie AE mode............................................................................. 81
Multi Motion .................................................................................. 81
Fader............................................................................................. 82
Voice ............................................................................................. 82
Chapter 3
Playback/Editing
Searching and managing files .................................................... 84
Viewing photos.............................................................................. 84
Viewing image thumbnails ............................................................. 84
Viewing files by category in Smart Album....................................... 85
Viewing files as a folder.................................................................. 85
Protecting files............................................................................... 85
Deleting files .................................................................................. 86
Deleting a single file......................................................................... 86
Deleting multiple files....................................................................... 86
Deleting all files................................................................................ 86
Viewing photos............................................................................ 87
Enlarging a photo .......................................................................... 87
Viewing a slide show ..................................................................... 87
Auto rotating.................................................................................. 88
Playing videos ............................................................................. 89
Trimming a video during playback.................................................. 89
Capturing an image during playback ............................................. 90
Editing photos ............................................................................. 91
Options ......................................................................................... 91

9
Contents
Chapter 4
Camera settings menu
User settings .............................................................................. 94
ISO customizing ............................................................................ 94
ISO step.......................................................................................... 94
Auto ISO range ............................................................................... 94
Noise reduction ............................................................................. 94
DMF .............................................................................................. 94
AF Priority...................................................................................... 94
Distortion Correct .......................................................................... 95
iFn Customizing............................................................................. 95
User display................................................................................... 96
Key mapping ................................................................................. 97
Grid Line........................................................................................ 97
AF lamp......................................................................................... 97
Setting 1....................................................................................... 98
Setting 2..................................................................................... 100
Setting 3..................................................................................... 101
GPS ............................................................................................ 102
Chapter 5
Connecting to external devices
Viewing files on a TV or HDTV .................................................. 104
Viewing files on a TV.................................................................... 104
Viewing files on an HDTV............................................................. 105
Viewing files on a 3D TV ............................................................. 106
Printing photos.......................................................................... 107
Printing photos with a PictBridge photo printer............................ 107
Configuring print settings .............................................................. 108
Creating a print order (DPOF)....................................................... 108
DPOF options ............................................................................... 109
Transferring files to your computer .......................................... 110
Transferring files to your Windows computer ............................... 110
Connecting the camera as a removable disk ................................. 110
Disconnecting the camera (for Windows XP) ................................. 111
Transferring files to your Mac computer ....................................... 111
Using programs on a PC........................................................... 112
Installing software........................................................................ 112
Programs contained on the CD..................................................... 112
Using Intelli-studio ....................................................................... 113
Requirements................................................................................ 113
Using the Intelli-studio Interface..................................................... 114
Transferring files using Intelli-studio................................................ 115
Using Samsung RAW Converter.................................................. 116
Requirements for Windows ........................................................... 116
Requirements for Mac................................................................... 116
Using the Samsung RAW Converter Interface ............................... 117
Editing RAW format files................................................................ 117

10
Contents
Before contacting a service center .......................................... 129
Camera specifications .............................................................. 132
Lens specifications ................................................................... 136
Glossary..................................................................................... 139
Optional accessories ................................................................ 144
Index .......................................................................................... 145
FCC notice................................................................................. 148
Chapter 6
Appendix
Error messages ......................................................................... 120
Maintaining the camera ............................................................ 121
Cleaning the camera.................................................................... 121
Camera lens and display ............................................................... 121
Image sensor ................................................................................ 121
Camera body ................................................................................ 121
Using or storing the camera......................................................... 122
Inappropriate places to use or store the camera............................ 122
Using on beaches or shores.......................................................... 122
Storing for extended period of time ............................................... 122
Using the camera with caution in humid environments .................. 123
Other cautions .............................................................................. 123
About memory card..................................................................... 124
Supported memory card ............................................................... 124
Memory card capacity................................................................... 124
Cautions when using memory cards ............................................. 126
About the battery......................................................................... 126
Battery specifications .................................................................... 126
Battery life..................................................................................... 128
Low battery message.................................................................... 128
Notes about using the battery ....................................................... 128
Notes about charging the battery .................................................. 128

11
Concepts in Photography
Standing photography
Compose your shot; stand up straight with your feet shoulder-length
apart, and keep your elbows pointed down.
Shooting postures
A correct posture for stabilizing the camera is necessary for taking a
good photo. Even if you hold a camera correctly, the wrong posture
can cause the camera to shake. Stand up straight and remain still to
maintain a steady base for your camera. When shooting with a low
shutter speed, hold your breath to minimize body movement.
Holding the camera
Hold the camera with your right hand and place you right index finger
on the shutter button. Place your left hand under the lens for support.

12
Concepts in Photography
Crouching photography
Compose your shot, crouch with one knee touching the ground, and
keep a straight posture.
Aperture
The aperture, a hole that controls the amount of light that enters the
camera, is one of the three factors that determine the exposure. The
aperture housing contains thin, metal plates that open and close to let
light through the aperture and into the camera. The size of the aperture
is closely related to the brightness of a photo: the larger the aperture,
the brighter the photo; the smaller the aperture, the darker the photo.
Aperture sizes
Minimum aperture Medium aperture Maximum aperture
Darker photo
(aperture opened slightly)
Brighter photo
(aperture opened wide)

13
Concepts in Photography
The size of the aperture is represented by a value known as an
“F-number.” The f-number represents the focal length divided by the
diameter of the lens. For example, if a lens with a 50 mm focal length
has an f-number of F2, the diameter of the aperture is 25 mm.
(50 mm/25 mm=F2) The smaller the f-number, the greater the size of
the aperture.
The opening in the aperture is described as the Exposure Value (EV).
Increasing the Exposure Value (+1 EV) means the amount of light
doubles. Decreasing the Exposure Value (-1 EV) means the amount of
light halves. You can also use the exposure compensation feature to
fine-tune the amount of light by subdividing exposure values into 1/2,
1/3 EV, and so on.
+1 EV
F1.4 F2 F2.8 F4 F5.6 F8
-1 EV
Exposure Value Steps
Aperture value and the depth of field
You can blur or sharpen the background of a photo by controlling the
aperture. It is closely related to the depth of field (DOF), which can be
expressed as small or large.
A photo with a large DOF A photo with a small DOF
The aperture housing contains several blades. These blades move together
and control the amount of light passing through the center of the aperture.
The number of blades also affects the shape of light when shooting night
scenes. If an aperture has an even number of blades, light divides into an
equal number of sections. If the number of blades is odd, the number of
sections is double the number of blades.
For example, an aperture with 8 blades divides light into 8 sections and an
aperture with 7 blades into 14 sections.
7 blades 8 blades

14
Concepts in Photography
Shutter speed
Shutter speed refers to the amount of time it takes to open and close
the shutter, and it is an important factor in the brightness of a photo, as it
controls the amount of light which passes through the aperture before it
reaches the image sensor.
Usually, the shutter speed is manually adjustable. The measurement
of the shutter speed is known as the “Exposure Value” (EV), which is
marked in intervals of 1 s, 1/2 s, 1/4 s, 1/8 s, 1/15 s, 1/1000 s, 1/2000 s,
and so on.
Exposure
+1 EV
-1 EV
1 s 1/2 s 1/4 s 1/8 s 1/15 s 1/30 s
Shutter Speed
Therefore, the faster the shutter speed, the less light will be let in.
Likewise, the slower the shutter speed, the more light will be let in.
As the photos below illustrate, a slow shutter speed allows more time
to let light in, so the photo becomes brighter. On the other hand, a fast
shutter speed allows less time to let light in and the photo becomes
darker and more easily freezes subjects in motion.
0.8 s 0.004 s

15
Concepts in Photography
ISO sensitivity
The exposure of an image is determined by the sensitivity of the
camera. This sensitivity is based on international film standards, known
as ISO standards. On digital cameras, this sensitivity rating is used
to represent the sensitivity of the digital mechanism that captures the
image.
ISO sensitivity doubles as the number doubles. For example, an ISO
200 setting is capable of capturing images at twice the speed of an ISO
100 setting. However, higher ISO settings can result in “noise”—small
specks, spots, and other phenomena in a photo that give the shot
a noisy or dirty appearance. As a general rule, it is best to use a low
ISO setting to prevent noise in your photos, unless you are shooting in
darkened environments or at night.
Changes in the quality and brightness according to ISO sensitivity
Because a low ISO sensitivity means the camera will be less sensitive
to light, you need more light to have an optimal exposure. When using
a low ISO sensitivity, open the aperture more or reduce the shutter
speed to allow more light to enter the camera. For example, on a sunny
day when light is abundant, a low ISO sensitivity does not require a low
shutter speed. However, in a dark place or at night, a low ISO sensitivity
and a fast shutter speed will result in a blurry photo.
A photo captured with a tripod and
high sensitivity
A blurred photo with a low ISO sensitivity

16
Concepts in Photography
How the aperture setting, shutter speed,
and ISO sensitivity control exposure
The aperture setting, shutter speed, and ISO sensitivity are closely
interconnected in photography. The aperture setting controls the
opening that regulates the light that enters the camera, while the shutter
speed determines the length of time that light is allowed to enter.
ISO sensitivity determines the speed at which the film reacts to light.
Together, these three aspects are described as the triangle of exposure.
A change in shutter speed, aperture value, or ISO sensitivity can be
offset by adjustments to the others to maintain the amount of light.
The results, however, change according to the settings. For example,
shutter speed is useful in expressing movement, aperture can control
the depth of field, and ISO sensitivity can control the graininess of a
photo.
Settings Results
Aperture
Wide aperture
= more light
Narrow aperture
= less light
Wide = small depth of field
Narrow = large depth of field
Settings Results
Shutter speed
Fast speed
= less light
Slow speed
= more light
Fast = still
Slow = blurry
ISO sensitivity
High sensitivity
= more sensitive to light
Low sensitivity
= less sensitive to light
High = more grainy
Low = less grainy

17
Concepts in Photography
Correlation between focal length, angle,
and perspective
Focal length, which is measured in millimeters, is the distance between
the middle of the lens to its focal point. It affects the angle and
perspective of captured images. A short focal length translates into a
wide angle, which allows you to capture a wide shot. A long focal length
translates into a narrow angle, which allows you to capture telephoto
shots.
Short focal length
wide shot
wide angle
wide-angle lens
Long focal length
telephoto shot
narrow angle
telephoto lens
Look at these photos below and compare the changes.
20 mm angle 50 mm angle 200 mm angle
Normally, a lens with a wide angle is suitable for shooting landscapes and
a lens with a narrow angle is recommended for shooting sports events or
portraits.

18
Concepts in Photography
Depth of field
Portraits or still-life photos mostly acclaimed by people are the ones on
which the background is out of focus so the subject looks pronounced.
Depending on the focused areas, a photo can be blurred or sharpened.
This is called ‘a low DOF’ or ‘a high DOF’.
The depth of field is the focused area around the subject. Therefore,
a small DOF signifies that the focused area is narrow and a large DOF
means the focused area is wide.
A photo with a small DOF, which stresses the subject and makes the
rest of it blurred, can be obtained by using a telescope lens or selecting
a low aperture value. Conversely, a photo with a large DOF which
shows all the elements on the photo sharply focused can be achieved
by using a wide angle lens or selecting a high aperture value.
Small Depth of Field Large Depth of Field
What controls out-of-focus effects?
DOF depends on aperture value
The wider the aperture is (namely the lower the aperture value), the
lower the DOF becomes. Under the condition where the other values
including shutter speed and ISO sensitivity are equal, a low aperture
value leads to a photo with a low DOF.
50 mm F5.7 50 mm F22

19
Concepts in Photography
DOF depends on focal length
The longer the focal length is, the lower the DOF gets. A telescope lens
with a longer focal length than a telescope lens with a short focal length
is better to capture a photo of a low DOF.
A photo captured with a 20 mm
telescope lens
A photo captured with a 100 mm
telescope lens
DOF depends on the distance between the subject and
the camera
The shorter the distance between the subject and the camera is, the
lower the DOF gets. Therefore, taking a photo close to a subject can
result in a photo of low DOF.
A photo captured with a 100 mm telescope lens
A photo captured close to the subject
