Samsung PL81 User manual

User Manual
Basic Operation
PL80/PL81
ENG / TUR

32 32
Contents
Get answers to common questions …3
Health and safety information ……… 4
Camera layout ………………………… 6
Setting up your camera ……………… 8
Unpacking …………………………………8
Inserting the battery and memory card …9
Removing the battery and memory card… 9
Charging the battery …………………… 10
Turning on your camera………………… 10
Selecting options …………………… 11
Capturing photos or videos ……… 12
Transferring files to a PC
(Windows) …………………………… 15
Specifications ……………………… 18
Copyright information
Microsoft Windows and the Windows logo are registered•
trademarks of the Microsoft Corporation.
•Cameraspecicationsorcontentsofthismanualmaybe
changed without prior notice due to upgrade of camera
functions.
•ForOpenSourceLicenseinformation,refertothe
“OpenSourceInfo.pdf”intheprovidedCD-ROM.

32 32
English
Get answers to common questions
You can easily solve most problems by setting shooting options.
TherearemoredetailsabouthowtosetshootingoptionsintheCDversionoftheusermanual.
The subject's
eyes appear red.
This is caused by a reflection from the camera flash.
Settheashoptionto• Red–eye or Red–eye Fix.
Ifthephotohasalreadybeentaken,select• Red–eye Fix in the edit menu.
Photos have
dust
spots.
Dustparticlesoatingintheairmaybecapturedinphotoswhenusingtheash.
Turn off the flash or avoid taking photos in a dusty place.•
SetISOspeedoptions.•
Photos are
blurred.
This may be caused by taking photos in low light conditions or holding the camera
incorrectly.
Press [• Shutter] halfway down to make sure the subject is focused.
Photos are
blurred when
shooting at night.
Asthecameratriestoletinmorelight,theshutterspeedslows.
Thiscanmakeitdifculttosteadythecameraandmayresultincamerashake.
Turn on the flash.•
Select• Night in the mode.
SetISOspeedoptions.•
Use a tripod to prevent your camera from shaking.•

54
54
Health and safety information
Comply with the following precautions to avoid dangerous
or illegal situations while operating the camera and keep
this manual handy for future reference.
Warnings
Do not use your camera near flammable or explosive
gases and liquids
Donotuseyourcameranearfuels,combustibles,or
ammablechemicals.Donotstoreorcarryammable
liquids,gases,orexplosivematerialsinthesame
compartment as the camera or its accessories.
Keep your camera away from small children and pets
Keep your camera and all accessories out of the reach
ofsmallchildrenandanimals.Smallpartsmaycause
choking or serious injury if swallowed. Moving parts and
accessories may present physical dangers as well.
Prevent damage to subjects’ eyesight
Donotusetheashincloseproximity(closerthan1m/3
ft) to people or animals. Using the flash too close to
your subject’s eyes can cause temporary or permanent
damage.
Handle and dispose of batteries and chargers
with care
UseonlySamsung-approvedbatteriesandchargers.•
Incompatible batteries and chargers can cause serious
injuries or damage to your camera.
Neverdisposeofbatteriesinare.Followalllocal•
regulations when disposing of used batteries.
Never place batteries or cameras on or in heating•
devices,suchasmicrowaveovens,stoves,or
radiators.Batteriesmayexplodewhenoverheated.

54
54
English
Protect batteries, chargers, and memory cards from
damage
Avoidexposingbatteriesormemorycardstoverycold•
orveryhottemperatures(below0°C/32°Forabove
40°C/104°F).Extremetemperaturescanreducethe
charging capacity of your batteries and can cause
memory cards to malfunction.
Prevent batteries from making contact with metal•
objects,asthiscancreateaconnectionbetweenthe+
and – terminals of your battery and lead to temporary
or permanent battery damage.
Prevent memory cards from making contact with•
liquids,dirt,orforeignsubstances.Ifdirty,wipethe
memory card clean with a soft cloth before inserting in
your camera.
Use only Samsung-approved accessories
Using incompatible accessories may damage your
camera,causeinjury,orvoidyourwarranty.
Protect your camera’s lens
Protectyourlensfromngerprintsandscratches.Clean
yourlenswithasoft,clean,debris-freelenscloth.
Cautions
Handle and store your camera carefully and sensibly
Donotallowyourcameratogetwet—liquidscan•
causeseriousdamage.Donothandleyourcamera
with wet hands. Water damage to your camera can
void your manufacturer’s warranty.
Avoidusingorstoringyourcameraindusty,dirty,•
humid,orpoorly-ventilatedareastopreventdamage
to moving parts and internal components.
Protectyourcamerafromimpact,roughhandling,and•
excessivevibrationtoavoidseriousdamage.
Exercisecautionwhenconnectingcablesoradapters•
andinstallingbatteriesandmemorycards.Forcing
theconnectors,improperlyconnectingcables,or
improperly installing batteries and memory cards can
damageports,connectors,andaccessories.
Donotinsertforeignobjectsintoanyofyourcamera’s•
compartments,slots,oraccesspoints.Thistypeof
damage may not be covered by your warranty.

76
76
Camera layout
Battery chamber cover
Memory card slot
Tripod mount Battery holder
Battery chamber
Shutter button
AF-assist light/timer lamp
USB / AV / DC terminal
Flash
Microphone
Smart button
POWER button
Lens / Lens cover
Speaker
Zoom Lever

76
76
English
Display
MODE button
Fn / Delete button
Navigation button/OK button
Playback button
MENU button
Status lamp

98
98
Setting up your camera
Unpacking
Camera ACadapter/
USBcable
Rechargeable battery Strap
SoftwareCD-ROM
(Usermanualincluded)
QuickStartManual
Optional accessories
Memory cards
Camera case
A/Vcable
Battery charger

98
98
English
Inserting the battery and memory card Removing the battery and memory card
Note
The internal memory can be used as a temporary storage
device when the memory card is not inserted.
Push the lock up to
release the battery.
Push gently until the card
disengages from the
camera and then pull it
out of the slot.
▼ Removing the battery
▼ Removing the memroy card
Withthegold-coloured
2
contacts facing up
1
4
WiththeSamsunglogo
3
facing up

1110
1110
Press [POWER].
Setting up your camera
Turning on your cameraCharging the battery
Beforeusingthecameraforthersttime,you
must charge the battery.
Press [▪P] to turn on the camera
in Playback mode.
Press and hold [▪P] to mute
camera sounds.
Indicator light
Red▪: Charging
Green▪:Fullycharged

1110
1110
English
You can select options by pressing [m] and using the
navigationbuttons([D],[M],[F],[t]).
Note
You can also access shooting options by pressing [f] but
some options are not available.
InShootingmode,press[
1
m].
Use the navigation buttons to scroll to an option
2
or menu.
Photo size
Back Move
Tomoveleftorright,press[▪F] or [t].
Tomoveupordown,press[▪D] or [M].
Press [
3
o]toconrmthehighlightedoptionor
menu.
Going back to the previous menu
Press [m] again to go back to the previous menu.
Note
Press [Shutter]toreturntoShootingmode.
E.g. Selecting a white balance option in the
P mode
Press [
1
]toselect( ).
Press [
2
m].
Press [
3
D] or [M] to scroll to Shooting and
then press [t] or [o].
Press [
4
D] or [M] to scroll to White Balance
and then press [t] or [o].
Press [
5
F] or [t] to scroll to a white balance
option.
Press [
6
o].
Selecting options

1312
1312
Press [
3
Shutter] halfway down to focus
automatically.
A green frame means the subject in focus.▪
Press [
4
Shutter] all the way down to take the
photo.
Taking a photo
Press [
1
]toselect( ).
(Press[ ],[ ]toselect( ).)
Align your subject in the frame.
2
Capturing photos or videos

1312
1312
English
Note
Number of photos by resolution (for1GBSD)
Resolution Super fine Fine Normal
4000x3000 168 238 362
3984x2656 195 267 407
3968x2232 229 305 477
3264x2448 244 326 514
2592x1944 362 489 699
2048x1536 543 674 752
1024x768 978 1,086 1,222
These figures are measured under Samsung’s standard
conditions and may vary depending on shooting conditions
and camera settings.
Viewing photos
Press [
1
P].
Ifthecameraisoff,itwillturnon.▪
Press [
2
F] or [t]toscrollthroughles.
Pressandholdtoviewlesquickly.▪
Capturing photos or videos

1514
1514
Viewing videos
Press [
1
P].
Press [
2
o].
Play Capture
Use the following buttons to control playback.
3
[F]Scanbackward
[o]Pause or resume playback
[t]Scanforward
[Zoom] left or right Adjust the volume level
Recording a video
Press [
1
]toselect( ).
(Press[ ]toselect( ).)
Align your subject in the frame.
2
Press [
3
Shutter].
Press [▪o] to pause or resume.
Press [
4
Shutter] again to stop the recording.
Capturing photos or videos

1514
1514
English
Transferring files to a PC (Windows)
InserttheinstallationCDinaCD-ROMdrive
1
and follow the onscreen instructions.
Note
Click Samsung Digital Camera Manual to read the user
manual.
The CD contains the following programs
Samsung Master Editphotosandvideos
Adobe Reader Viewtheusermanual
ConnectthecameratothePCwiththeUSB
2
cable.
Caution
You must plug the end of the cable with the indicator
light(▲)intoyourcamera.Ifthecableisreversed,itmay
damageyourles.Themanufacturerisnotresponsiblefor
any loss of data.

1716
1716
OnyourPC,select
2
My Computer →
Removable Disk →DCIM →100PHOTO.
Turn on the camera.
1
The PC recognises the camera automatically.▪
Note
Ifthecamerafailstoconnect,apop-upwindowwillappear.
SelectComputer.
Transferring files to a PC (Windows)

1716
1716
English
Selectthelesyouwantanddragorsavethem
3
to the PC.
To disconnect safely (for Windows XP)
ThewaytodisconnecttheUSBcableforWindowsVista
/7issimilar.
Click
Click

1918
1918
Specifications
sensor
Type 1/2.3"(Approx.7.81mm)CCD
Pixels
Effectivepixels:approx.12.2mega-pixels,
Totalpixels:approx.12.4mega-pixels
Lens
Focal length
Samsunglensf=5.1-25.5mm
(35mmlmequivalent:28.2-141mm)
F-stop range F3.4(W)-F5.9(T)
Display 2.7"(6.86cm)230K,TFTLCD
Focusing
Type TTLautofocus(MultiAF,CenterAF,
TrackingAF)
Range
Wide Tele
Normal 80cm-innity
Macro 10cm-80cm -
Auto
Macro 10cm-innity 100cm-innity
Shutter speed
SmartAuto:1/8-1/2,000sec.•
Program:1-1/2,000sec.•
Night:8-1/2,000sec.•
Fireworks:2sec.•
Storage
Internalmemory:approx.86MB•
Externalmemory(Optional):•
SDcard(upto4GBguaranteed),
SDHCcard(upto8GBguaranteed)
Internal memory capacity may not match
these specifications.
Interface
Digital output Connector:USB2.0
Audio output Mono(Internalspeaker),
Stereo(Microphone)
Video output A/V:NTSC,PAL(selectable)•
DC power
input
connector
4.2V
Rechargeable
battery BP70A
Dimensions (W x H x D) 96.8×57.5×20.2(18.9)mm
(excludingprotrusions)
Weight 120.3g
(withoutbatteryandmemorycard)
Operating temperature 0-40°C
Operating humidity 5-85%

1918
1918
English
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(ApplicableintheEuropeanUnionandother
Europeancountrieswithseparatecollection
systems)
Thismarkingontheproduct,accessoriesorliterature
indicates that the product and its electronic accessories
(e.g.charger,headset,USBcable)shouldnotbe
disposed of with other household waste at the end
of their working life. To prevent possible harm to the
environment or human health from uncontrolled waste
disposal,pleaseseparatetheseitemsfromothertypes
of waste and recycle them responsibly to promote the
sustainablereuseofmaterialresources.Household
users should contact either the retailer where they
purchasedthisproduct,ortheirlocalgovernmentofce,
for details of where and how they can take these items
for environmentally safe recycling. Business users should
contact their supplier and check the terms and conditions
of the purchase contract. This product and its electronic
accessoriesshouldnotbemixedwithothercommercial
wastes for disposal.
Correct disposal of batteries in this product
(ApplicableintheEuropeanUnionandother
Europeancountrieswithseparatebattery
return systems)
Thismarkingonthebattery,manualorpackaging
indicates that the batteries in this product should not be
disposed of with other household waste at the end of
theirworkinglife.Wheremarked,thechemicalsymbols
Hg,CdorPbindicatethatthebatterycontainsmercury,
cadmiumorleadabovethereferencelevelsinEC
Directive2006/66.Ifbatteriesarenotproperlydisposed
of,thesesubstancescancauseharmtohumanhealthor
the environment.
To protect natural resources and to promote material
reuse,pleaseseparatebatteriesfromothertypesof
wasteandrecyclethemthroughyourlocal,freebattery
return system.
Samsung Eco-mark
ItisSamsung’sownsymbolmarkisusedtoeffectively
communicateSamsung’senvironmentalfriendlyproduct
activities to the consumers. The mark represents
Samsung’scontinuouseffortondevelopmentof
environmental conscious products.

TR-3TR-2TR-3TR-2
İçindekiler
Genel soruların yanıtları …………… 3
Sağlık ve Güvenlik Bilgileri ………… 4
Kamera yerleşimi …………………… 6
Kameranızı ayarlama ………………… 8
Paketi açma ………………………………8
Pili ve hafıza kartını takma ………………9
Pili ve hafıza kartını çıkarma ……………9
Pili şarj etme …………………………… 10
Kameranızı açma ……………………… 10
Seçenekleri belirleme …………… 11
Fotoğraf veya video çekme ……… 12
Dosyaları bilgisayara aktarma
(Windows) ………………………… 15
Teknik Özellikler …………………… 18
Telif hakkı bilgileri
Microsoft Windows ve Windows logosu, Microsoft •
Corporation'ın tescilli ticari markalarıdır.
• Kameranın teknik özellikleri veya bu kılavuzun içeriği
kamera işlevlerinin yükseltilmesi nedeniyle önceden
haber verilmeden değiştirilebilir.
• Bu kılavuzda yer alan tüm marka ve ürün adları, ilgili
firmalarının kayıtlı ticari markalarıdır.
