Samsung DW60H6050 Series Assembly instructions

DISHWASHER
REPAIR Guide
DISHWASHER
DW6*M****BB
DW6*M****IB
* For End User.
DW6*M****F* DW6*M****U* DW6*M****S*
Basic Model : DW60H6050 Series
DW60H5050 Series
Model Name : DW60M6050 Series
DW60M6040 Series
Model Code : DW60M6050FS DW60M6050FW
DW60M6052FS DW60M6052FW
DW60M6050US DW60M6050UW
DW60M6051US DW60M6051UW
DW6BM6051US DW60M6050SS
DW60M6031SS DW60M6050BB
DW60M6051BB DW60M6031BB
DW60M6070IB DW60M6040FS
DW60M6040FW DW60M6040US
DW60M6040UW DW60M6042US
DW60M6044US DW60M6040SS
DW6KM6041SS DW60M6040BB
DW6KM6041BB DW60M5050FS
DW60M5050FW DW60M5050BB
DW6KM5031BB DW60M5070IB

IMPORTANT SAFETY NOTICE
Following the repair by a non-authorized service provider self-repair or
non-professional repair of the product Samsung is not liable for any
damage to the product any injury or any other product safety issue caused
by any attempt to repair the product which does not carefully follow these
repair and maintenance instructions. Any damage to the product caused by
an attempt to repair the product by any person other than a Samsung
certified service provider will not be covered by the warranty.
All rights reserved.
This service guide may not be reproduced in whole or
as a part in any form whatsoever without the written permission of
the SAMSUNG ELECTRONICS Company.
WARNING
Note
1. You can check where to buy replacement parts at http://www.samsung.com/support/
2. Visit the part purchase site and enter the model code of your product to check the parts
available for purchase. The model code is labelled on the edge of the tub. When you open the
dishwasher’s door, you can check the model code and version on the barcode label at the left
side of the tub.
3. For replacement parts make sure the part name matches that of the illustration in this
manual.
- User-serviceable parts are limited to door hinge and seals other seals spray arms drain
lters interior racks and plastic peripherals such as baskets and lids.
Caution
1. The part name listed on the site may differ from that in this manual. Please make sure you
choose the right part name.
2. Be sure to wear safety gloves while making repairs.
3. Must working more than 2 people to handling heavy weight.

Disassembly and Reassembly _ 3
1. TOOLS FOR REMOVAL AND REASSEMBLY
Tool image
No. Tool Type Remarks
①Adjustable Wrench
②Open-end Wrench 1-7/16”
③Vice Pliers
④Others
(screwdriver, nipper, long nose pliers) Common tools for servicing Screwdriver – Phillip, Flat, Torx T15
⑤Ear clamping tool In reassembling of the clamp-bend(ear clamp) using our
SVC part, this tool is needed.
Preparation for parts replacement
1. Take out the residual water inside the product. (Drain the water by operating the drain pump)
2. Close the water supply valve.
3. Turn off the power & disconnect power cable.
You must turn off the circuit breaker connected to the product.
4. Pull out the unit from the sink and lay it on the oor.
Be careful of the drain hose when pulling out the unit.
5. For materials and repair information related to self-repair, refer to the web site : www.samsung.com/support

4 _ Disassembly and Reassembly
2. STANDARD DISASSEMBLY DRAWINGS
2-1. PRECAUTION
Caution
Before servicing,
- Make sure to remove all items include baskets inside dishwasher.
- Drain the water in the dishwasher and disconnect the power supply.
- Lock the water faucet that connected with inlet hose.
- Uninstall the dishwasher from the furniture cabinet except simple work.
- Disconnect the Inlet & Drain hoses from the duct, if the hoses are too short to pull the dishwasher out of the furniture
cabinet enough.
- Make sure to remove any remaining water in the Sump and hoses by rag or vacuum.
→ There is a risk of water spill on the oor.

Disassembly and Reassembly _ 5
2-2. CAP CASE BRAKE / GASKET BRAKE
- Cap Case Brake : DD81-01387A / SVC-AIR BREAKER NUT
- Gasket Brake : DD81-01388A / SVC-SEAL RING
Part Figure Description
CAP CASE
BRAKE / GASKET
BRAKE
A
B
[DISASSEMBLY]
1. Remove 3 screws that connect left SIDE PANEL to
front side of dishwasher.
- Type A: DD81-02693A / 2 pcs
- Type B: DD81-02694A / 1 pc
Warning
Be sure to remove the power plug before servicing.
NOTE :
In case of Free Standing models, there’re no
screws of type B.
C
B
2
1
2. Remove 3 screws at the back side of dishwasher.
- Type C: DD81-02692A / 1 pc
- Type B: DD81-02694A / 2 pcs
NOTE :
In case of Free Standing models, take off the
COVER TOP by removing 2 screws of type A.
After removing screws, pull the COVER TOP
backward rst, and take it off upward.
Guide Tub Top
3. Remove 1 screw at the left side of GUIDE TUB
TOP.
- Screw: DD81-02694A / 1 pc

6 _ Disassembly and Reassembly
Part Figure Description
CAP CASE
BRAKE / GASKET
BRAKE
4. Take off the left SIDE PANEL.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
5. Take off the CAP CASE BRAKE by rotating to
counter-clockwise direction with long-nose pliers.
Caution
It can be broken easily when you use iron part of
the pliers. Take off the cap using handle part to
prevent damage.
Cap Case brake Gasket brake
6. Remove the GASKET BRAKE from the CASE
BRAKE assembly.
[ASSEMBLY]
1. Put the GASKET BRAKE on the CASE BRAKE,
and fasten the CAP CASE BRAKE by rotating to
clockwise direction with long-nose pliers.
Caution
It can be broken easily when you use iron part of
the pliers. Take off the cap using handle part to
prevent damage.
Caution
Pay attention to assemble the seal correctly.
It can cause the water leakage when it’s
misassembled.
2. Assemble the left SIDE PANEL with the screws.
Caution
Fasten the screws that was assembled to origin
location. Don’t assemble to other locations.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.

Disassembly and Reassembly _ 7
2-3. DOOR HINGE
- Door Hinge : DD82-01505A, DD82-01506A / SVC ASSY-DOOR LINK R, L (except DW60M****IB)
Part Figure Description
DOOR HINGE
(except
DW6*M****IB)
B
A
[DISASSEMBLY]
* PREPARATION: Remove SIDE PANEL Left &
Right refer to the section of ‘CAP CASE BRAKE /
GASKET BRAKE’.
1. Remove 8 screws xing the ASSY CONTROL
PANEL with Torx® T15 screwdriver.
- Type A: DD81-01371A / 2 pcs
- Type B: DD81-02466A / 6 pcs
Warning
Be sure to remove the power plug before servicing.
Caution
The screws can fall into the SUMP after
disassembly. Keep the screws to other place to
reassemble the DOOR.
DW6*M****F*/DW6*M****U*/DW6*M****SS
DW6*M****BB/DW60M****IB
2. Remove wire connector of Sub PBA.
NOTE :
In case of DW6*M5*** models, remove the Door
switch assembly also.
C
3. Remove 6 screws to take off DOOR OUTER with
Torx® T15 screwdriver.
- Type C: DD81-01370A / 6 pcs
Warning
Be sure to remove the power plug before servicing.
Caution
Be careful to avoid injury when the DOOR is closed
after remove DOOR OUTER.
Caution
The screws can fall into the SUMP after
disassembly. Keep the screws to other place to
reassemble the DOOR.

8 _ Disassembly and Reassembly
Part Figure Description
DOOR HINGE
(except
DW6*M****IB)
Hook Hook
4. Remove 2 terminals that connected to
DETERGENT DISPENSER, and 1 ground wire that
connected to BRACKET DOOR FRAME.
Warning
Be sure to remove the power plug before servicing.
Caution
Pay attention to hook of terminals.
5. Remove HOLDER ROPE DOOR from the DOOR
HINGE left & right with the DOOR closed.
Caution
Pay attention to DOOR drop after remove the rope.
It can cause injury.

Disassembly and Reassembly _ 9
Part Figure Description
DOOR HINGE
(except
DW6*M****IB)
GUIDE HINGE 6. Push both ribs of GUIDE HINGE to pull out the DOOR.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge of broken parts.
About 15˚
DOOR INNER assembly
7. Do same work at the opposite side, and pull out the
DOOR INNER assembly to the direction of about 15˚.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
8. Remove 2 screws to take off BRACKET DOOR
FRAME from the DOOR INNER.
- Screws: DD81-02728A / 2 pcs
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
9. Remove 2 screw at each side to take off DOOR
HINGE from the DOOR INNER.
- Screws: DD81-02764A / 4 pcs
10. Take off the GUIDE HINGE from the DOOR
HINGE.
NOTE :
DOOR HINGE and GUIDE HINGE will serviced to
assembly only.

10 _ Disassembly and Reassembly
Part Figure Description
DOOR HINGE
(except
DW6*M****IB)
[ASSEMBLY]
1. Assemble the DOOR HINGE assembly and
BRACKET DOOR FRAME with machine screws.
- Screws for DOOR HINGE assembly:
DD81-02764A / 4 pcs
- Screws for BRACKET DOOR FRAME:
DD81-02728A / 2 pcs
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
About 15˚
2. Put the DOOR INNER assembly into the holder of
TUB to lock the hook of DOOR HINGE.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
3. Put the HOLDER ROPE DOOR on the both side of
DOOR HINGE with the DOOR closed.
4. Connect 2 terminals of DETERGENT DISPENSER,
and 1 ground wire.
Caution
Make sure the Wire harness are not getting stuck in
other parts.

Disassembly and Reassembly _ 11
Part Figure Description
DOOR HINGE
(except
DW6*M****IB)
DW6*M****F*/DW6*M****U*/DW6*M****SS
DW6*M****BB/DW60M****IB
5. Connect the wire harness to Sub PBA.
Caution
Make sure the Wire harness are not getting stuck in
other parts.
NOTE :
Incase of DW6*M5*** models, place the DOOR
SWITCH assembly on the CONTROL PANEL also.
B
A
6. Fix 8 screws to assemble the ASSY CONTROL
PANEL with Torx® T15 screwdriver.
- Type A: DD81-01371A / 2 pcs
- Type B: DD81-02466A / 6 pcs
1
2
7. Assemble the holes of DOOR OUTER to hooks of
CONTROL PANEL.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
Holes of DOOR OUTER Hooks of CONTROL PANEL
C
8. Fasten 6 screws to x the DOOR OUTER.
NOTE :
Use the Torx® T15 screw driver.
- Type C: DD81-01370A / 6 pcs

12 _ Disassembly and Reassembly
- Door Inner : DD82-01494B / SVC ASSY-INNER DOOR (DW60M6070IB)
DD82-01619B / SVC ASSY-INNER DOOR (DW60M5070IB)
- Door Hinge : DD82-01773A, DD82-01774A / SVC ASSY-DOOR LINK L, R (DW60M****IB)
Part Figure Description
DOOR INNER /
DOOR HINGE
(DW60M****IB)
[DISASSEMBLY]
* PREPARATION: Disassemble DOOR OUTER,
CONTROL PANEL, WIRE HARNESS and SIDE
PANEL
1. Open the door about 45˚.
Warning
Be sure to remove the power plug before servicing.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
2. Insert pin or thin stick to x the door spring.
Caution
Make sure to use strong pin enough to endure the
spring force.

Disassembly and Reassembly _ 13
Part Figure Description
DOOR INNER /
DOOR HINGE
(DW60M****IB)
3. Remove the 2 screws(at each side / Total 4 pcs)
xing DOOR INNER.
Caution
Be careful not to dent the DOOR INNER during
disassembly.
4. Remove the stopper carefully.
Caution
Do not this work without safety gloves. It can cause
injury from sharp edge.

14 _ Disassembly and Reassembly
Part Figure Description
DOOR INNER /
DOOR HINGE
(DW60M****IB)
Door Hinge left Door Hinge right
5. Remove the stopper carefully.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
Warning
Be careful not to pop out the spring while
disassembly. It can cause serious injury.
NOTE :
DOOR HINGE will be serviced with DOOR INNER
together by DOOR INNER assembly(SVC ASSY-
INNER DOOR).
[ASSEMBLY]
1. Pull the spring enough, and insert pin or thin stick
to x the door spring.
Caution
Make sure to use strong pin enough to endure the
spring force.
Warning
Be careful not to pop out the spring. It can cause
serious injury.

Disassembly and Reassembly _ 15
Part Figure Description
DOOR INNER /
DOOR HINGE
(DW60M****IB)
2. Hang the DOOR HINGE to the hole of the spring.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
3. Assemble the stopper carefully.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
4. Fasten the 2 screws(at each side / Total 4 pcs) to
x DOOR INNER.
Warning
Be careful not to dent the DOOR INNER during
assembly.

16 _ Disassembly and Reassembly
Part Figure Description
DOOR INNER /
DOOR HINGE
(DW60M****IB)
5. Remove pin
NOTE :
After servicing DOOR INNER assembly, assemble
WIRE HARNESS, DOOR OUTER, CONTROL
PANEL and SIDE PANEL.

Disassembly and Reassembly _ 17
2-4. HOLDER HINGE
- Holder Hinge : DD81-01367A / SVC-GUIDE DOOR LINK
Part Figure Description
HOLDER HINGE
[DISASSEMBLY]
* PREPARATION: Disassemble SIDE PANEL left &
right.
1. Remove HOLDER ROPE DOOR from the DOOR
HINGE left & right with the DOOR closed.
Warning
Be sure to remove the power plug before servicing.
Caution
Pay attention to DOOR drop after remove the rope.
It can cause injury.
2. Remove HOLDER HINGE from the DOOR HINGE.
Caution
Be careful to avoid injury from the DOOR drop
without HOLDER ROPE DOOR.
NOTE :
Rotate the HOLDER HINGE to release from hook.
[ASSEMBLY]
* Reassembly is the reverse order of disassembly.

18 _ Disassembly and Reassembly
2-5. SEAL TUB PACKING
- Seal Tub Packing : DD81-01381A / SVC-GASKET TUB
Part Figure Description
SEAL TUB
PACKING
Seal tub packing
Bracket seal tub
[DISASSEMBLY]
1. Pull out the old seal from the BRACKET SEAL
TUB.
Warning
Be sure to remove the power plug before servicing.
Warning
Be careful to touch the BRACKET SEALTUB after
removed the seal.
It can cause injury from sharp edge.
Insert to Bracket
seal Tub
Seal tip
Seal tip faces to
inside
[ASSEMBLY]
1. Put some water on new SEAL TUB PACKING to
assemble it easily. Fold the SEAL TUB PACKING in
half with the tip of the seal facing inward.
Caution
Pay attention to the direction of seal. If it is
assembled in reverse, it may cause leakage of
steam or water.
Center
About 20 cm
2. Assemble the SEALTUB PACKING to center of the
BRACKET SEALTUB. Press seal about 20 cm (red
dotted line) on both sides based on the center line.

Disassembly and Reassembly _ 19
Part Figure Description
SEAL TUB
PACKING
About 3~4 cm
3. Put Seal in the left & right side of the bottom.
NOTE :
The folded seal is about 3~4 cm long.
4. Press the seal from the top corner toward remaining
side.
Caution
Pay attention to assemble not to deform the seal
tip at the corner. If the gap is opened, it may cause
steam leakage.

20 _ Disassembly and Reassembly
2-6. ROTOR LOWER / ASSY DUCT NOZZLE
- Rotor Lower : DD81-01847A / SVC-NOZZLE LOWER
- Assy Duct Nozzle : DD82-01501A / SVC ASSY-DUCT NOZZLE (DW6*M6***)
DD82-01646A / SVC ASSY-DUCT NOZZLE (DW6*M5***)
Part Figure Description
ROTOR LOWER
/ ASSY DUCT
NOZZLE
Rotor lower
[DISASSEMBLY]
1. Open the dishwasher's door, and remove the
ROTOR LOWER.
2. Turn the COARSE FILTER counter-clockwise to
unlock the lter assembly.
3. Remove 2 screws to take off ASSY DUCT NOZZLE.
- Screws: DD81-02718A / 2 pcs
Duct Nozzle assembly
(DW6*M6***)
Duct Nozzle assembly
(DW6*M5***)
4. Release the hooks from tub holders.
Warning
Do not this work without safety gloves. It can cause
injury from sharp edge.
Caution
Make sure to reassemble to correct location.
There’re risks of leakage or poor performance
when it’s misassembled.
NOTE :
There's no Top rotor for DW6*M5*** models.
