SCC‐3100AQuickSet‐upGuide1May2009
SCC‐3100A
QuickSet‐upGuide


TheSCC‐3100AQuickset‐upguidedescribeshowtoconnecttobothanSPDspeeddome
andSVRdigitalrecorderforbothbasicandmultipleoperations.
Theequipmentusedinthisexampleincludes:
SCC‐3100A(FW2.5.2)&Junctionbox
SVR‐1680(FW1.2.2)
SPD‐3750(Ver1.08)
Baudrate9600



SCC‐3100AQuickSet‐upGuide1May2009
1. BasicOperation
a. HardwareConnections


























b. MenuSet‐up
MODELGO TOMENU SET PICTURE
SPD-3750
SW1(default)  CAM ID(address) : 1 

SW2(default) 
Pin No.  Purpose
Samsung Techwin Protocol (set DIP 1,2,3,4,
as OFF) Baud Rate : 9600 (set DIP 5,6 as
OFF) RS-485 (DIP 7 as OFF) 
*refer to manual for more information 
1~4  Protocol
5~6  Baud Rate Settings
7 
RS-485/422 Settings
8  Response Mode Settings
9  Backup Mode Settings 1
10~11  Termination Settings
12  Backup Mode settings 2


SCC‐3100AQuickSet‐upGuide1May2009


SVR-1680

Communication →
Remote 
Remote Keyboard ID : 1 

Communication→
Remote →Serial
→COM2 
(Device)SCC-3100
(Interface)RS 485 
(Baudrate)9600 
Communication→
Remote →Serial
→
COM4 
(Device)Samsung SPD-
(Interface)RS 485 
(Baudrate)9600


Communication→
Remote →Serial
→PTZ →CH1
(PTZ port)COM4 RS 485
Camera ID : 1

SCC-3100A

SET UP
→2(DVR) →
1(DVR MODEL
SETUP)
DVR →1 →
ENTER
PRESET 1(set as S-DVR)

SET UP →
3(CONTROLLER)
→2(SERIAL) →
1(S1)
Serial port 1 : 9600, 8(data bit), 1(stop
bit), None(parity bit)



SCC‐3100AQuickSet‐upGuide1May2009
2. MultipleOperation
a. HardwareConnections



























SCC‐3100AQuickSet‐upGuide1May2009



MODELGO TOMENU SET PICTURE
SVR-1680
PTZ 1
Menu →
Communication→
Remote
PTZ →CH 1
>> →camera ID →1

PTZ N
Menu →
Communication→
Remote
PTZ →CH N
>> →camera ID →N
DVR 1
Menu →
Communication→
Remote
Remote Keyboard ID : 1

DVR 2
Menu →
Communication→
Remote
Remote Keyboard ID : 2





SCC‐3100AQuickSet‐upGuide1May2009

3.
ControllerOperation
* If you operate more than 2 cameras, you have to select the camera (PTZ) through
controller (SCC-3100) after selecting DVR.

MODELMENU SET (In controller) PICTURE
DVR
Selection DVR 1 : DVR →1 →enter

DVR 2 : DVR →2 →enter
PTZ
Selection 
PTZ 1 : DVR →1 →camera →enter

PTZ N : DVR →2 →camera →enter
Termination
of Devices
DIP Switch

DIP10  DIP11 COM2 COM4 RS485  RS422
Termination
OFF  OFF  OFF  OFF 

ON  ON  ON  ON 
*In case of connecting more than 2 devices, you have to set the DIP switch of the last Device
as terminated. (Termination ON)
