Keith McMillen Instruments K-Board Pro 4 Specification sheet

Get Started
2.
Open SOftware...
Your K-Board Pro 4 is a class compliant USB MIDI device,
which means it will work with any MIDI-capable software
running on Mac OS, iOS, Windows, or Android.
Most software will begin working immediately with your
K-Board. If not, please consult your software’s documen-
tation as there may be specific instructions for configuring
a new MIDI device.
3.
play...
Your K-Board Pro 4 works just like a normal keyboard
(with some exciting extras). Have fun making music with
your new instrument!
1.
pluG In...
Use the provided Micro-USB cable to connect your
K-Board to computers or tablets. Simply plug the micro
end into the K-Board’s USB port, and the other end into a
USB port on the desired device.
Some tablets may require additional connectors/adapt-
ers in order to function properly. Please ensure these are
properly configured if you are experiencing connection
issues.
KMI Music Inc warrants this product against defects in materials and
workmanship for one year from the date of purchase. During this war-
ranty period, this product will be replaced without charge. This warran-
ty does not cover any damage due to acts of nature, accidents, misuse,
abuse or negligence. Replacement as provided under this warranty is
the exclusive remedy of the consumer. KMI Music inc shall not be li-
able for any incidental or consequential damages for breach of any
expressed or implied warranty on this product, except to the extent
prohibited by applicable law. Any implied warranty or merchantability
or fitness for a particular purchase on this product is limited to the du-
ration of the warranty.
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
to
a
tablet
to
a
computer

featureS
Z-a xIS
y-ax IS
x -ax IS
SlId erS
Mpe c OMpat Ibl e
VelOcIt y
Download software and user manual at:
www.keithmcmillen.com/kbp4/downloads
Access the web editor at:
https://files.keithmcmillen.com/products/k-board-pro-4/editor
Get technical support at:
https://files.keithmcmillen.com/support
The K-Board Pro
4 can send both
The K-Board Pro 4 can detect where
your finger is along the Z-axis (pressure)
of each key. This sends Channel Pressure
by default.
The K-Board Pro 4 can detect where
your finger is along the Y-axis of
each key (up and down). This sends
CC74 (timbre) by default.
The K-Board Pro 4 can detect
where your finger is along the
X-axis of each key (left and right).
This controls Pitch by default (re-
turn mode is on by default, consult
the full documentation for more
info).
The K-Board Pro 4 has four touch sensitive sliders.
These can be assigned to MIDI CC’s, but can also
control aspects of the hardware. By default they will
control global pitch bend, octave select, key pitch
bend range, and send CC1, respectively.
The K-Board Pro 4 is fully MPE compatible out of the
box. You can take advantage of the 5 dimensions of
control to send pitch and expression data per key
with any software or hardware that supports the MPE
specification.
strike and release velocity, giving all the nuance you
expect from a keyboard controller.
