Samsung PN50B860Y2F User manual

Plasma TV
user manual
BN68-02271A-02
Contact SAMSUNG WORLD-WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
Comment contacter Samsung dans le monde
Si vous avez des suggestions ou des questions concernant les produits Samsung, veuillez contacter le Service
Consommateurs Samsung.
Country Customer Care Center Web Site Address
U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com/us Samsung Electronics America, Inc. 105 Challenger Road
Ridgefield Park, NJ 07660-0511
CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca
Samsung Electronics Canada Inc., Customer Service 55
Standish Court Mississauga, Ontario L5R 4B2 Canada
Samsung Electronique Canada Inc., Service à la Clientèle
55 Standish Court Mississauga, Ontario L5R 4B2
Canada
Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/register
Model Serial No.
imagine the possibilities
BN68-850_Eng.indb 1 2009-06-18 �� 3:54:57

Important Warranty Information Regarding Television Format Viewing
Wide screen format PDP Displays (16:9, the aspect ratio of the screen width to height) are primarily designed to view wide
screen format full-motion video. The images displayed on them should primarily be in the wide screen 16:9 ratio format,
or expanded to fill the screen if your model offers this feature and the images are constantly moving. Displaying stationary
graphics and images on screen, such as the dark side-bars on nonexpanded standard format television video and
programming, should be limited to no more than 5% of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock market reports, video game displays, station logos,
web sites or computer graphics and patterns, should be limited as described above for all televisions. Displaying stationary
images that exceed the above guidelines can cause uneven aging of PDP Displays that leave subtle, but permanent
burned-in ghost images in the PDP picture. To avoid this, vary the programming and images, and primarily display
full screen moving images, not stationary patterns or dark bars.
On PDP models that offer picture sizing features, use these controls to view different formats as a full screen picture.
Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a result of format
selection and use, as well as burned-in images, are not covered by your Samsung limited warranty.
© 2009 Samsung Electronics Co., Ltd. All rights reserved.
English - 2
BN68-850_Eng.indb 2 2009-06-18 �� 3:54:57

User Instructions
Screen Image retention
Do not display a still image (such as on a video game) on the plasma display panel for more than several minutes as it can cause
screen image retention. This image retention is also known as “screen burn”. To avoid such image retention, refer to page 27 of this
manual to reduce the degree of brightness and contrast of the screen when displaying a still image.
Altitude
The PDP can only operate normally at heights under 6500ft.
Heat on the top of the Plasma TV
The top side of the product may be hot after long periods of use as heat dissipates from the panel through the vent hole in the upper
part of the product.
This is normal and does not indicate any defect or operation failure of the product.
However, children should be prevented from touching the upper part of the product.
The product is making a ‘cracking’ noise.
A ‘cracking’ noise may occur when the product contracts or expands due to a change in the surrounding environment such as
temperature or humidity. This is normal and not a defect of the unit.
Cell Defects
The PDP uses a panel consisting of 2,360,000(HD-level) to 6,221,000(FHD-level) pixels which require sophisticated technology to
produce. However, there may be a few bright or dark pixels on the screen. These pixels will have no impact on the performance of the
product.
Avoid operating the TV at temperatures below 41°F (5°C)
A still image displayed too long may cause permanent damage to the PDP Panel.
Watching the Plasma TV in 4:3 format for a long period of time may leave traces of borders displayed on
the left, right and center of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause similar effects to the screen.
Damages caused by the above effect are not covered by the Warranty.
After-images on the Screen.
Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images for a long time.
Warranty
Warranty does not cover any damage caused by image retention.
Burn-in is not covered by the warranty.
English - 3
BN68-850_Eng.indb 3 2009-06-18 �� 3:54:58

Contents
Symbol N O T
Press Note One-Touch Button TOOLS
English
Connecting and Preparing Your TV
List of Features■..........................................................................5
Checking Parts■..........................................................................5
Viewing the Control Panel■.........................................................6
Viewing the Connection Panel■...................................................7
Remote Control■.........................................................................9
Connections
Connecting VHF and UHF Antennas■.......................................10
Connecting Cable TV■..............................................................10
Connecting a DVD / Blu-ray Player or Cable Box / Satellite■
receiver (Set-Top Box) via HDMI.............................................12
Connecting a DVD /Blu-ray Player or Cable Box / Satellite■
receiver (Set-Top Box) via DVI ................................................12
Connecting a DVD / Blu-ray Player or Cable Box / Satellite■
receiver (Set-Top Box) via Component cables ........................13
Connecting a Camcorder■........................................................13
Connecting a VCR■...................................................................14
Connecting a Digital Audio System■.........................................15
Connecting an Amplier / DVD Home Theater■........................15
Connecting a PC■.....................................................................16
Operation
Turning the TV On and Off■......................................................17
Changing Channels■.................................................................17
Adjusting the Volume■...............................................................17
Using the TOOLS Button■.........................................................18
Using the Remote Control Backlight Buttons■..........................18
Viewing the Display■.................................................................18
Viewing the Menus■..................................................................19
Plug & Play Feature■................................................................20
Channel Control
Storing Channels■....................................................................21
Managing Channels■................................................................22
Picture Control
Changing the Picture Settings■.................................................24
PC Display
Using Your TV as a Computer (PC) Display■............................28
Display Modes■.........................................................................28
Setting up the TV with your PC■...............................................29
Sound Control
Changing the Sound Settings■..................................................30
Function Description
Conguring the Setup Menu■....................................................31
Viewing the Picture in Picture (PIP)■.........................................35
Setting the Time■......................................................................36
Source List / Edit Name■...........................................................37
Support■....................................................................................38
Media Play
Connecting a USB Device■.......................................................40
Using the Media Play Function■................................................41
Using and Sorting Photo List■...................................................42
Viewing a Photo or Slide Show■..............................................43
Using and Sorting the Music List■.............................................45
Playing a Music■......................................................................46
Using and Sorting the Movie List■.............................................47
Playing a Movie File■...............................................................48
Picture / Music Settings Using Media Play■..............................50
Using the Setup Menu■.............................................................51
Media Play-DLNA
Setting the DLNA Network■.......................................................52
Installing the DLNA Application■...............................................52
Using the DLNA Application■....................................................54
Using the DLNA Function■........................................................57
Anynet+
Connecting Anynet■+Devices ..................................................58
Setting Up Anynet■+.................................................................60
Switching between Anynet■+Devices .......................................60
Recording■................................................................................61
Listening through a Receiver■...................................................62
Troubleshooting for Anynet■+...................................................62
Content Library
Activating the Content Library■.................................................63
Using the Content Library■........................................................64
Network
Network Connection■................................................................65
Network Setup■.........................................................................68
Internet@TV
Getting Started with Internet@TV■...........................................72
Editing Snippets in the Dock■...................................................74
Using the Prole Widget■..........................................................74
Using the Yahoo!® Widget Gallery■..........................................76
Using the Yahoo!® Weather Widget■........................................77
Using the Yahoo!® News Widget■............................................77
Using the Yahoo!® Flickr Widget■............................................. 78
Using the Yahoo!® Finance Widget■......................................... 79
Troubleshooting for internet@TV■........................................... 79
Help Website■...........................................................................80
Home Network Center
Home Network Center■.............................................................81
Setting Up the Home Network Center■.....................................82
Using the Message Function■...................................................83
Using the Media Function■........................................................84
Appendix
Troubleshooting■.......................................................................85
Assembling the Cables■............................................................86
Preparation before installing the Wall-Mount■...........................87
How to attach the Stand-Base■.................................................87
Securing the TV to the Wall■.....................................................88
Wall Mount Kit Specications (VESA)■.....................................89
Specications■..........................................................................90
Dimensions (PN50B850Y1F/PN50B860Y2F)■.........................91
Dimensions (PN58B850Y1F/PN58B860Y2F)■.........................92
English - 4
BN68-850_Eng.indb 4 2009-06-18 �� 3:54:59

Checking Parts
Please make sure the following items are included with your TV. If any items are missing, contact your dealer.
The items' color and shape may vary depending on the model.
N
Remote Control
(BN59-00851A) /
AAA Batteries
(4301-000103)
Owner’s Instructions /
Quick Setup Guide
(BN68-02135A)
Warranty Card /
Safety Guide Manual
(Not available in all
locations)
Cleaning Cloth
(BN63-01798B)
Program CD TV-Holder / Screw
(BN96-10788A)
(Refer to page 88)
Holder-Ring (4ea)
(BN61-05280A)
(Refer to page
87)
Cover-Bottom
(Refer to page 87)
(PN50B850Y1F/
PN50B860Y2F only)
Cover-Bottom & Screw
(Refer to page 87)
(PN58B850Y1F/
PN58B860Y2F only)
Holder-Wire Cable
(Refer to page 86)
Holder-Wire stand
(BN61-05491A)
(Refer to page 86)
Holder-Wire (3ea)
(BN61-05373A)
(Refer to page 86)
Screws (5ea)
(PN50B850Y1F/
PN50B860Y2F only)
Ferrite Core (7ea)
(3301-001305) Ferrite Core (3301-001201)
(PN58B850Y1F/
PN58B860Y2F only)
Ferrite CoreN
The ferrite cores are used to shield the cables
from interference.
When connecting a cable, open the ferrite
core and clip it around the cable near the plug.
List of Features
Adjustable picture settings that can be stored in the TV’s memory.•
Automatic timer to turn the TV on and off.•
A special sleep timer.•
V-Chip function.•
Excellent Digital Interface & Networking :•
With a built-in HD digital tuner, non-subscription HD broadcasts can be viewed with no Cable Box/Satellite receiver (Set-Top Box)
needed.
HDMI/DVI connection of your PC to this TV.•
Excellent Picture Quality•
SRS TruSurround HD provides a virtual surround system.•
Media Play• : Allows you to play music les, pictures, and movies saved on a USB or DLNA device.
Internet@TV•: You can use various internet services and view useful information and entertaining content.
Home Network Center• : Allows you to congure a mobile message server or a DLNA media render.
Connecting and Preparing Your TV
Power Cord (2ea)
Component
Cable (1ea) PC/DVI Audio Cable (1ea) HDMI Cable (4ea)
English - 5
BN68-850_Eng.indb 5 2009-06-18 �� 3:55:03

Viewing the Control Panel
The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
The product color and shape may vary depending on the model.
N
The front panel buttons can be activated by touching them with your nger.N
1 REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
2SOURCE
Toggles between all the available input sources
(TV, AV, Component, PC, HDMI1/DVI, HDMI2, HDMI3,
HDMI4, USB).
In the on-screen menu, use this button as you would use
N
the ENTER
E
button on the remote control.
3
MENU
Press to see an on-screen menu of your TV’s features.
4
– VOL +
Press to increase or decrease the volume. In the on-screen
menu, use the – VOL + buttons as you would use the
◄ and ► buttons on the remote control.
5
CH
Press to change channels. In the on-screen menu, use the
CH buttons as you would use the ▲ and ▼ buttons
on the remote control.
6
POWER INDICATOR
Blinks and turns off when the power is on and lights up in
stand-by mode.
7 (
POWER)
Press to turn the TV on and off.
8
SPEAKERS
English - 6
(PN50B860Y2F / PN58B860Y2F)
Light Effect
PN50B850Y1F / PN58B850Y1F
BN68-850_Eng.indb 6 2009-06-18 �� 3:55:04

Viewing the Connection Panel
Use the connection panel jacks to connect A/V components that will be connected continuously, such as Blu-ray/DVD players
or a VCR.
The product color and shape may vary depending on the model.
N
English - 7
TV Rear Panel
BN68-850_Eng.indb 7 2009-06-18 �� 3:55:05

For best HDMI connection to this product, be sure to useN
HDMI cables with a maximum thickness as below.
Below 40 inch model:•
Max 0.47inch (12mm)
40 inch and above model:•
Max 0.55inch (14mm)
1
POWER IN
Connects the supplied power cord.
2
EX-LINK
Used for service only.
3
USB 1 (HDD) / USB 2
Connect a USB mass storage device to view photo les
(JPEG) and play audio les (MP3) or movie les. You can
also use these jacks connect to SAMSUNG’s network
wirelessly.
The USB 1 (HDD) port is also used as the HDD. HDD
N
(Hard disk drive) is device which stores digitally encoded
data.
4
AUDIO OUT
Audio outputs to external devices.
5
DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component.
6
HDMI IN 1 (DVI), 2, 3, 4
Connect to the HDMI jack of a device with an HDMI output.
Use an HDMI cable which is smaller than 14mm.
N
What is HDMI?NHDMI(High-Definition Multimedia Interface), is an•
interface that enables the transmission of digital audio
and video signals using a single cable.
The difference between HDMI and DVI is that the•
HDMI device is smaller in size and has the HDCP
(High Bandwidth Digital Copy Protection) coding
feature installed.
We recommend that 14mm is proper for cable size.•
This is smaller than standard.
PC/DVI AUDIO IN
Connect to the DVI audio output jack of an external device.
7
PC IN / PC/DVI AUDIO IN
Connects to the video and audio output jacks on your PC.
If your PC supports an HDMI connection, you can
N
connect this to the HDMI IN 1, 2, 3, or 4 terminal.
If your PC supports a DVI connection, you can connect
N
this to the HDMI IN 2 / DVI AUDIO IN [R-AUDIO-L]
terminal.
8
COMPONENT IN / AV IN
Connects Component video / audio. The COMPONENT IN
jack is also used as the AV IN jack.
Connect the video cable to the
NCOMPONENT IN
[Y/VIDEO] jack and the audio cable to the COMPONENT
IN [R-AUDIO-L] jacks.
9
ANT IN
Uses a 75Ω Coaxial connector for an Air/Cable Network.
0
LAN
Connect a LAN cable to this port to connect to the Network.
English - 8
BN68-850_Eng.indb 8 2009-06-18 �� 3:55:05

Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.
The product color and shape may vary depending on the model.
N
The performance of the remote control may be affected by bright light.N
1
POWER
Turns the TV on and off.
2
TV
Selects the TV mode directly.
3
NUMERIC BUTTONS
Press to select a channel.
4
Press to select additional channels (digital
and analog) being broadcast by the same
station. For example, to select channel
“54-3”, press “54”, then press “ ” and “3”.
5
CH LIST
Use to display Channel Lists on the screen.
6
MENU
Displays the main on-screen menu.
7
TOOLS
Use to quickly select frequently used
functions.
8
UP▲/DOWN▼/LEFT◄/
RIGHT►/ENTER
Use to select on-screen menu items and
change menu values.
9
INTERNET@
This function enables you to view
Internet@TV.
0
COLOR BUTTONS
Use these buttons in the Channel list,
Media Play, and Internet@TV, etc.
!
SOURCE
Press to display and select the available
video sources.
@
VOL
Press to increase or decrease the volume.
#
MEDIA.P (Media play)
This function enables you to view and play
photo and music les from an external
device. (Refer to pages 42 (Photo), 45
(Music) and 47 (Movie))
$
INFO
Press to display information on the TV
screen.
%
MTS
Press to choose stereo, mono or Separate
Audio Program (SAP broadcast).
^
Use these buttons in the DMA, Media Play
and Anynet+ modes.
(: This remote can be used to control
recording on Samsung recorders with the
Anynet+ feature)
&
ON/OFF
Press to backlight the buttons on the remote.
This function is convenient for using at night
or when the room is dark. (Using the remote
control with the ON/OFF() light button set
to On will reduce the battery usage time.)
*
PRE-CH
Tunes to the previous channel.
(
FAV.CH
Press to switch to your favorite channels.
)
RETURN
Returns to the previous menu.
a
EXIT
Press to exit the menu.
b
CH
Press to change channels.
c
MMUTE
Press to temporarily cut off the sound.
d
P.SIZE
Picture size selection.
e
CONTENT
This function enables you to view Content
Library.
f
CC
Controls the caption decoder.
Installing Batteries in the Remote Control
❑
1. Lift the cover at the back of the remote control upward as shown in the gure.
2. Install two AAA size batteries.
Make sure to match the “+” and “–” ends of the batteries with the diagram inside the
N
compartment.
3. Close the cover as shown in the gure.
Remove the batteries and store them in a cool, dry place if you won’t be using the
N
remote control for a long time. (Assuming typical TV usage, the batteries should
last for about one year.)
Using the remote control with the
NON/OFF( ) light button set to On will reduce the
battery usage time.
If the remote control doesn’t work, check the following
N
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power outage or is the power cord unplugged?
5. Is there a special uorescent light or neon sign nearby?
English - 9
VOL CH
BN68-850_Eng.indb 9 2009-06-18 �� 3:55:06

Connecting VHF and UHF Antennas
If your antenna has a set of leads that look like this, see “Antennaswith300ΩFlatTwin
Leads” below.
If your antenna has one lead that looks like this, see “Antennaswith75ΩRoundLeads”.
If you have two antennas, see “Separate VHF and UHF Antennas”.
Antennaswith300ΩFlatTwinLeads
❑
Ifyouareusinganoff-airantenna(suchasaroofantennaorrabbitears)thathas300Ω
twin flat leads, follow the directions below.
1. Place the wires from the twin leads under the screws on a 300-75 Ω adapter (not supplied).
Use a screwdriver to tighten the screws.
2. Plug the adaptor into the ANT IN terminal on the back of the TV.
Antennaswith75ΩRoundLeads
❑
Plug the antenna lead into the ANT IN terminal on the back of the TV.
Separate VHF and UHF Antennas
❑
If you have two separate antennas for your TV (one VHF and one UHF), you must
combine the two antenna signals before connecting the antennas to the TV. This
procedure requires an optional combiner-adaptor (available at most electronics shops).
1. Connect both antenna leads to the combiner.
2. Plug the combiner into the ANT IN terminal on the bottom of the back panel.
Connecting Cable TV
To connect to a cable TV system, follow the instructions below.
Cable without a Cable Box
❑
Plug the incoming cable into the ANT IN terminal on the back of the TV.
Because this TV is cable-ready, you do not need a cable box to view unscrambled cable
N
channels.
Connecting to a Cable Box that Descrambles All Channels
❑
1. Find the cable that is connected to the ANT OUT terminal on your cable box.
This terminal might be labeled “ANT OUT”, “VHF OUT” or simply, “OUT”.
N
2. Connect the other end of this cable to the ANT IN terminal on the back of the TV.
Connections
Continued...
English - 10
ANT OUT
ANT IN
ANT IN
UHF
VHF
ANT IN
ANT IN
UHF
VHF
ANT IN
ANT IN
BN68-850_Eng.indb 10 2009-06-18 �� 3:55:07

Connecting to a Cable Box that Descrambles Some Channels
❑
If your cable box descrambles only some channels (such as premium channels), follow the instructions below. You
will need a two-way splitter, an RF (A/B) switch, and four lengths of Antenna cable. (These items are available at most
electronics stores.)
1. Find and disconnect the cable that is
connected to the ANT IN terminal on your
cable box.
This terminal might be labeled “ANT IN”,
N
“VHF IN” or simply, “IN”.
2. Connect this cable to a two-way splitter.
3. Connect an Antenna cable between the
OUTPUT terminal on the splitter and the IN
terminal on the cable box.
4. Connect an Antenna cable between the ANT
OUT terminal on the cable box and the B–IN
terminal on the RF(A/B) switch.
5. Connect another cable between the other
OUT terminal on the splitter and the A–IN
terminal on the RF (A/B) switch.
6. Connect the last Antenna cable between the
OUT terminal on the RF (A/B) switch and the
ANT IN terminal on the rear of the TV.
After you have made this connection, set the A/B switch to the “A” position for normal viewing. Set the A/B switch to the “B” position
to view scrambled channels. (When you set the A/B switch to “B”, you will need to tune your TV to the cable box’s output channel,
which is usually channel 3 or 4.)
English - 11
Splitter
Incoming
cable
RF (A/B)
Switch
Cable Box
ANT IN
Splitter
Incoming
cable
TV Rear
RF (A/B)
Switch
ANT IN
Splitter
Cable Box
Incoming
cable
Splitter
Incoming
cable
Splitter
Cable Box
RF (A/B)
Switch
Incoming
cable
IN CABLE OUT
IN CABLE OUT
IN CABLE OUT
IN CABLE OUT
A
B
A
B
A
B
BN68-850_Eng.indb 11 2009-06-18 �� 3:55:08

Connecting a DVD / Blu-ray Player or Cable Box / Satellite receiver
(Set-Top Box) via HDMI
This connection can only be made if there is an HDMI Output jack on the external device. This connection will provide the
highest quality picture.
1. Connect an HDMI Cable between the HDMI IN1 (DVI), 2, 3, or 4) jack on the TV and the HDMI jack on the DVD / Blu-ray Player or
Cable Box / Satellite receiver (Set-Top Box).
What is HDMI?
N
HDMI, or high-denition multimedia interface, is an interface that enables the transmission of digital audio and video signals •
using a single cable.
The difference between HDMI and DVI is that the HDMI device is smaller in size and has the HDCP (High Bandwidth Digital•
Copy Protection) coding feature installed.
Each DVD Player or Cable Box / Satellite receiver (Set-Top Box) has a different back panel conguration.
N
The TV may not output sound and pictures may be displayed with abnormal color when DVD / Blu-ray Player or Cable Box /N
Satellite receiver supporting HDMI versions older than 1.3 are connected. When connecting an older HDMI cable and there is no
sound, connect the HDMI cable to the HDMI IN 1 (DVI) jack and the audio cables to the PC/DVI AUDIO IN jacks on the back of
the TV. If this happens, contact the company that provided the DVD / Blu-ray Player or Cable Box / Satellite receiver to conrm the
HDMI version, then request an upgrade.
HDMI cables that are not 1.3 may cause annoying icker or no screen display.
N
Connecting a DVD /Blu-ray Player or Cable Box / Satellite receiver
(Set-Top Box) via DVI
This connection can only be made if there is a DVI Output jack on the external device.
1. Connect a HDMI/DVI Cable or DVI-HDMI Adapter between the HDMI IN 1 (DVI) jack on the TV and the DVI jack on the DVD /
Blu-ray Player or Cable Box/Satellite receiver (Set-Top Box).
2. Connect Audio Cables between the PC/DVI AUDIO IN jack on the TV and the DVD/Blu-ray Player or Cable Box / Satellite receiver.
Each DVD / Blu-ray Player or Cable Box / Satellite receiver (Set-Top Box) has a different back panel conguration.
N
When connecting a DVD Player or Cable Box / Satellite receiver (Set-Top Box), match the color of the connection terminal to the
N
cable.
When using an HDMI / DVI cable connection, you must use the
NHDMI IN 1 (DVI) jack.
English - 12
DVD/Blu-ray Player or Cable
Box / Satellite receiver
TV Rear Panel
HDMI Cable (Not supplied)1
DVD/Blu-ray Player or Cable Box /
Satellite receiver
TV Rear Panel
Audio Cable (Not supplied)
HDMI/DVI Cable (Not supplied)
1
2
BN68-850_Eng.indb 12 2009-06-18 �� 3:55:11

Connecting a DVD / Blu-ray Player or Cable Box / Satellite receiver
(Set-Top Box) via Component cables
The rear panel jacks on your TV make it easy to connect a DVD/Blu-ray Player or Cable Box / Satellite receiver (Set-Top Box) to
your TV.
1. Connect Component Cable between the COMPONENT IN [Y, PB, PR]jacks on the TV and the COMPONENT [Y, PB, PR] jacks on the
DVD / Blu-ray Player or Cable Box / Satellite receiver(Set-Top Box).
2. Connect Audio Cables between the COMPONENT IN [R-AUDIO-L] jacks on the TV and the AUDIO OUT jacks on the DVD / Blu-ray
Player or Cable Box / Satellite receiver (Set-Top Box).
Component video separates the video into Y (Luminance (brightness)),
NPB(Blue) and PR(Red) for enhanced video quality. Be sure
to match the component video and audio connections. For example, if connecting the video cable to COMPONENT IN, connect the
audio cable to COMPONENT IN also.
Each DVD / Blu-ray Player or Cable Box / Satellite receiver (Set-Top Box) has a different back panel conguration.
N
When connecting a DVD / Blu-ray Player or Cable Box / Satellite receiver (Set-Top Box), match the color of the connection terminalN
to the cable.
Connecting a Camcorder
The side and rear panel jacks on your TV make it easy to connect a camcorder to your TV.
Using an Video / Audio Cable
❑
1. Connect a Video Cable between the AV IN [VIDEO] jack on the TV and the VIDEO OUT jack on the camcorder.
2. Connect Audio Cables between the AV IN [L-AUDIO-R] jacks on the TV and the AUDIO OUT jacks on the Camcorder.
Each Camcorder has a different back panel conguration.
N
When connecting a Camcorder, match the color of the connection terminal to the cable.N
English - 13
DVD / Blu-ray Player or Cable Box
/ Satellite receiver
TV Rear Panel
Audio Cable (Not supplied)
Component Cable (Not supplied)
1
2
Camcorder
TV Rear Panel
Video Cable (Not supplied)
Audio Cable (Not supplied)
2
1
BN68-850_Eng.indb 13 2009-06-18 �� 3:55:12

Connecting a VCR
Video Connection
❑
These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the
instructions on pages 10~11). Skip step 1 if you have not yet connected to an antenna or a cable system.
1. Unplug the cable or antenna from the back of the TV.
2. Connect the cable or antenna to the ANT IN terminal on the back of the VCR.
3. Connect an Antenna Cable between the ANT OUT terminal on the VCR and the ANT IN terminal on the TV.
4. Connect a Video Cable between the AV IN [Y/VIDEO] jack on the TV and the VIDEO OUT jack on the VCR.
5. Connect Audio Cables between the AV IN [R-AUDIO-L] jacks on the TV and the AUDIO OUT jacks on the VCR
If you have a “mono” (non-stereo) VCR, use a Y-connector (not supplied) to connect to the right and left audio input jacks of the
N
TV. Alternatively, connect the cable to the “R” jack.
If your VCR is stereo, you must connect two cables.
Each VCR has a different back panel conguration.
N
When connecting a VCR, match the color of the connection terminal to the cable.N
When connecting to AV IN, the colorNof the AV IN [Y/VIDEO] jack (Green) does not match the color of the video cable (Yellow).
Using an HDMI Cable
❑
1. Connect an HDMI Cable between the HDMI IN (1 (DVI), 2, 3, or 4) jack on the TV and the HDMI jack on the camcorder.
Each Camcorder has a different back panel conguration.
N
English - 14
TV Rear Panel
Camcorder
HDMI Cable (Not supplied)1
VCR Rear Panel
TV Rear Panel
2
Audio Cable(Not supplied)
Video Cable(Not supplied)
Antenna cable(Not supplied)
3
4
5
BN68-850_Eng.indb 14 2009-06-18 �� 3:55:12

Connecting a Digital Audio System
The rear panel jacks on your TV make it easy to connect a Digital Audio System(Home theater/Receiver) to your TV.
1. Connect an Optical Cable between the DIGITAL AUDIO OUT (OPTICAL) jacks on the TV and the Digital Audio Input (OPTICAL)
jacks on the Digital Audio System.
When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL) jack : Decrease the volume of the TV, and
adjust the volume level with the system’s volume control.
5.1CH audio is possible when the TV is connected to an external device supporting 5.1CH.
N
Each Digital Audio System has a different back panel conguration.N
When the receiver (home theater) is set to On, you can hear sound output from the TV’s Optical jack. When the TV is displaying aN
DTV(air) signal, the TV will send out 5.1 channel sound to the Home theater receiver. When the source is a digital component such
as a DVD and is connected to the TV via HDMI, only 2 channel sound will be heard from the Home Theater receiver.
If you want to hear 5.1 channel audio, connect the DIGITAL AUDIO OUT (OPTICAL) jack on the DVD / Blu-ray player or Cable/
Satellite Box directly to an Amplier or Home Theater, not the TV.
Connecting an Amplifier / DVD Home Theater
1. Connect Audio Cables between the AUDIO OUT jacks on the TV and AUDIO IN [L-AUDIO-R] jacks on the Amplier/DVD Home
Theater.
When an audio amplier is connected to the AUDIO OUT jacks terminals : Decrease the volume of the TV, and adjust the volume
level with the Amplier’s volume control.
Each Amplier / DVD Home Theater has a differe
Nnt back panel conguration.
When connecting an Amplier / DVD Home Theater, match the color of the connection terminal to the cable.
N
English - 15
Digital Audio System
TV Rear Panel
Optical Cable (Not supplied)
Amplifier / DVD Home Theater
TV Rear Panel
Audio Cable (Not supplied)
BN68-850_Eng.indb 15 2009-06-18 �� 3:55:14

Connecting a PC
Using a D-Sub Cable
❑
1. Connect a D-Sub Cable between PC IN jack on the TV and the PC output jack on your computer.
2. Connect a PC Audio Cable between the PC/DVI AUDIO IN jack on the TV and the Audio Out jack of the sound card on your
computer.
Using an HDMI/DVI Cable
❑
1. Connect an HDMI/DVI cable between the HDMI IN 1 (DVI) jack on the TV and the PC output jack on your computer.
2. Connect a 3.5 mm Stereo plug to 2RC
A cable between the PC/DVI AUDIO IN jack on the TV and the Audio Out jack of the sound
card on your computer.
Each PC has a different back panel coNnguration.
When connecting a PC, match the color of the connection terminal to the cable.
N
When using an HDMI/DVI cable connection, you must use the HDMI IN 1 (DVI) terminal.N
English - 16
TV Rear Panel
PC
3.5 mm Stereo plug to 2 RCA Cable (Not supplied)
HDMI/DVI Cable (Not supplied)
1
2
PC
TV Rear Panel
PC Audio Cable (Not supplied)
D-Sub Cable (Not supplied)
1
2
BN68-850_Eng.indb 16 2009-06-18 �� 3:55:15

Turning the TV On and Off
Press the POWER button on the remote control. You can also use the POWER button
on the TV.
It may take a while for your TV to power on.
N
Changing Channels
Using the Channel Buttons
❑
Press the CH or CH button to change channels.
When you press the
NCH or CH button, the TV changes channels in
sequence. You will see all the channels that the TV has memorized. (The TV must
have memorized at least three channels). You will not see channels that were either
erased or not memorized. See page 21 to memorize channels.
Using the Number Buttons
❑
Press the number buttons to go directly to a channel. For example, to select channel “27”,
press “2”, then “7”.
For quick channel change, press the number buttons, then press the
NENTERE
button.
Using the “
❑” Button
The “ ” button is used to select stations that broadcast a digital signal.
For example, for Channel "7-1", press "7", then " ”, then "1".
For quick channel change, press the number buttons, then press the
NENTERE
button.
Using the PRE-CH Button to select the Previous Channel
❑
Use the number buttons to quickly tune to any channel. Press the PRE-CH button. The
TV will switch to the last channel viewed.
To quickly switch between two channels that are far apart, tune to one channel, then
N
use the number button to select the second channel. Then use the PRE-CH button to
quickly alternate between them.
Adjusting the Volume
Using the Volume Buttons
❑
Press the VOL or VOL button to increase or decrease the volume.
Using the Mute Button
❑
At any time, you can cut off the sound using the MMUTE button.
1. Press MMUTE button and the sound cuts off.
will displayed on the screen.
2. To turn mute off, press the MMUTE button again, or simply press the VOL or
VOL button.
Operation
English - 17
VOL CH
VOL CH
VOL CH
VOL CH
VOL CH
VOL CH
VOL CH
BN68-850_Eng.indb 17 2009-06-18 �� 3:55:16

Using the TOOLS Button
You can use the TOOLS button to select your frequently used functions quickly and easily. The Tools menu changes
depending on which external input mode you are viewing.
1. Press the TOOLS button. The Tools menu will appear.
2. Press the ▲/▼ button to select a menu, then press the ENTER
E
button.
3. Press the ▲/▼/◄/►/ENTER
E
buttons to display, change, or use the selected items.
For a more detailed description of each function, refer to the corresponding page.
Anynet+ (HDMI-CEC), see page 60•
Picture Mode, see page 24•
Sound Mode, see page 30•
Sleep Timer, see page 36•
SRS TS HD, see page 30•
Add to Favorite (or Delete from Favorite), see page 22•
Switch to Cable (or Air), see page 21•
PIP, see page 35•
Auto Adjustment, see page 29•
Viewing the Display
The display identifies the current channel and the status of certain audio-video settings.
1. Press the INFO button on the remote control. The TV will display the channel, the type of
sound, and the status of certain picture and sound settings.
Press the
OINFO button once more or wait approximately 10 seconds and it disappears
automatically.
Using the Remote Control Backlight Buttons
Use this feature in dark surroundings and when you are unable to see the remote control buttons clearly.
1. Press the ON/OFF() light button
When
NON, the button backlight is turned on for a moment.
Pressing a remote control button when the remote control is on turns the button backlight on for a moment.
N
If you touch or move the remote control and the motion is detected by the sensor of the remote control, the button backlight will
be turned on for a moment.
The button backlight will not be turned on when the remote control is turned off.
N
English - 18
VOL CH
VOL CH
TV #1 Fri, Dec 19 2:05 am
M. Spillane’s Mike Hammer
Bonocrunch
DTV Air
13-1
Dolby Digital
1080i 16:9 English
1:55 am - 2:55 am
Next Program 2:55 am - 3:55 am
Prison Break
Tools
Anynet+ (HDMI-CEC)
Picture Mode : Standard
Sound Mode : Custom
Sleep Timer : Off
SRS TS HD : Off
Add to Favorite
Switch to Cable
U Move E Enter e Exit
BN68-850_Eng.indb 18 2009-06-18 �� 3:55:17

Viewing the Menus
Before using the TV, follow the steps below to learn how to navigate the menu in order to select and adjust different functions.
1. Press the MENU button.
The main menu is displayed on the screen. Its left side has the following icons: Picture, Sound, Channel , Setup, Input,
Application, Support.
2. Press the ▲ or ▼ button to select one of the icons.
Press the ◄ or ► button to access the icon’s sub-menu.
3. Press the ▲ or ▼ button to move to items in the menu.
Press the ENTEREbutton to enter items in the menu.
4. Press the ▲/▼/◄/► button to change the selected items.
Press the RETURN button to return to the previous menu.
5. Press the EXIT button to exit from the menu.
Using the remote control buttons
Button Operations Button Operations
MENU Display the main on-screen menu. ▲/▼/◄/► Move the cursor and select an item.
RETURN Return to the previous menu.
ENTEREChoose the currently selected item.
Confirm the setting.
EXIT Exit the on-screen menu.
Example: Setting the TV’s Brightness in the Picture Menu
❑
Adjusting the Brightness to 80
1. Press the MENU button to display the menu.
2. Press the ENTEREbutton to select Picture.
3. Press the ▲ or ▼ button to select Brightness.
4. Press the ENTEREbutton.
5. Press the ◄ or ► button until the Brightness changes to 80.
6. Press the ENTEREbutton.
Press the
NEXIT button to exit from the menu.
English - 19
Mode : Standard
Cell Light : 4
Contrast : 95
Brightness : 45
Sharpness : 50
Color : 50
Tint (G/R) : G50/R50
Advanced Settings
Mode : Standard
►
Cell Light :4
Contrast : 95
Brightness : 45
Sharpness : 50
Color : 50
Tint (G/R) : G50/R50
Advanced Settings
Cell Light :4
Contrast : 95
Brightness : 45
►
Sharpness : 50
Color : 50
Tint (G/R) : G50/R50
Advanced Settings
Picture Options
Picture Reset

Brightness
80

Brightness

45
Enter Return
Adjust
Move
Enter Return
Adjust
Move
BN68-850_Eng.indb 19 2009-06-18 �� 3:55:18

Plug & Play Feature
The first time you turn on your new TV, choose your basic settings for language, input source and channels, and time of day
using the plug & play feature. The TV will store these settings in memory. Storing the channels in memory will allow you to
scan the stored channels rather than have to enter their digits each time you want to change channels.
The Screen Saver is activated if there is no remote control key input for longer than 1 minute while Plug & Play is running.
N
The Screen Saver is activated if there is no operating signal for longer than 15 minutes.N
1. Press the POWER button on the remote control.
Select Language of the OSD menu is automatically displayed. Select the appropriate
language by pressing the ▲ or ▼ button. Press the ENTERE button to conrm your
choice.
2. Press the ◄ or ► button to select Store Demo or Home Use, then press the
ENTEREbutton.
We recommend setting the TV to
NHome Use mode for the best picture in your home
environment.
Store Demo
Nmode is only intended for use in retail environments.
If the unit is accidentally set to
NStore Demo mode and you want to return to Home
Use (Standard): Press the Volume button on the TV. When the volume OSD is
displayed, press and hold the MENU button on the TV for 5 seconds.
3. Press the ▲ or ▼ button to select the Antenna source to memorize. Press the
ENTEREbutton to select Start.
Air•: Air antenna signal.
Cable•: Cable antenna signal.
Auto•: Air and Cable antenna signals.
In
NCable mode, you can select the correct signal source among STD, HRC, and
IRC by pressing the ▲, ▼, ◄ or ► button, then press the ENTEREbutton. If
you have Digital cable, select the cable system signal source for both Analog and
Digital. Contact your local cable company to identify the type of cable system that
exists in your particular area.
4. The TV will begin memorizing all of the available channels.
To stop the search before it has nished, press the
NENTEREbutton with Stop
selected.
After all the available channels are stored, it starts to remove scrambled channels. The Auto program menu then reappears.
N
Press the ENTEREbutton when channel memorization is complete.
5. The message Set the Clock Mode. is displayed. Press the ENTEREbutton.
Press the ▲ or ▼ button to select Auto, then Press the ENTEREbutton. The message Set to daylight saving time. is displayed.
If you select Manual, Set current date and time is displayed. For detailed descriptions about the Manual, refer to page 36.
6. Press the ▲ or ▼ button to select Off, On, or Auto, then press the ENTEREbutton.
The image to select time zone in which you live is automatically displayed.
7. Press the ▲ or ▼ button to Select the time zone, then press the ENTEREbutton.
If you have received a digital signal, the time will be set automatically. If not, see page 36 to set the clock.
8. The brief instruction on How to get the best performance from your new HDTV is displayed.
Press the ENTEREbutton.
You can change to the previous or next page by pressing the ◄ or ► button.
N
You can access theNHD Connection Guide in the Support menu.
9. The message Enjoy your TV. is displayed.
If you want to view the TV immediately, select the
NWatch TV.
If you want to view the
NSee Product Guide, press the ENTEREbutton.
If you want to reset this feature...
1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup,
then press the ENTEREbutton.
2. Press the ENTEREbutton again to select Plug & Play. For further details on setting up
options, press the ENTEREbutton again.
The
NPlug & Play feature is only available in the TV mode.
Setup
Plug & Play ►
Language : English
Time
Game Mode : Off
BD Wise : On
Network Type : Cable
Network Setup
V-Chip
English - 20
Skip
U Move Enter
Plug & Play
Select Language of the OSD.
Language :
U Move E Enter
English
Español
Français
Select the Antenna source to memorize.
Air
Cable
Auto
Start
Start
Start
U Move E Enter Skip
Plug & Play
Auto Program in Progress.
DTV Air : 0 Air : 0
DTV Cable : 0 Cable : 0 Air 13
Stop
Plug & Play
E Enter Skip
0%
BN68-850_Eng.indb 20 2009-06-18 �� 3:55:18
