Samsung S19C350NW User manual

User Manual
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
S19C350NW
S22C350B
S22C350H
S23C340H
S23C350B
S23C350H
S24C340HL
S24C350BL
S24C350HL
S24C350H
S27C350H
BN46-00312A-09

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
10 Copyright
10 Icons used in this manual
11 Cleaning
12 Securing the Installation Space
12 Precautions for storage
13 Safety Precautions
13 Symbols for safety precautions
14 Electricity and Safety
15 Installation and Safety
17 Operation
21 Correct posture to use the product
PREPARATIONS 22 Checking the Contents
22 Removing the Packaging
23 Checking the Components
24 Parts (S19C350NW)
24 Frontal Button
25 Direct Key guide
26 Function Key Guide
28 Parts
(S22C350B / S23C350B / S24C350BL /
S22C350H / S23C340H / S23C350H /
S24C340HL / S24C350H / S24C350HL /
S27C350H)
28 Frontal Button
30 Direct Key guide
31 Function Key Guide
33 Reverse Side (S19C350NW)
34 Reverse Side (S22C350B / S23C350B /
S24C350BL)
35 Reverse Side (S22C350H / S23C340H /
S23C350H / S24C340HL / S24C350H /
S24C350HL / S27C350H)

Table Of Contents
Table Of Contents 3
36 Installation
36 Attaching the Stand
37 Removing the Stand
38 Adjusting the Product Tilt
39 Anti-theft Lock
CONNECTING AND USING
A SOURCE DEVICE
40 Before Connecting
40 Pre-connection Checkpoints
41 Connecting and Using a PC
41 Connection Using the D-SUB Cable (Analog
Type)
42 Connection Using the DVI Cable (S22C350B /
S23C350B / S23C350BL)
42 Connection Using an DVI-HDMI Cable
(S22C350B / S23C350B / S23C350BL)
43 Connection Using an HDMI Cable (S22C350H /
S23C340H / S23C350H / S24C340HL /
S24C350H / S24C350HL / S27C350H)
43 Connection Using an HDMI-DVI Cable
(S22C350H / S23C340H / S23C350H /
S24C340HL / S24C350H / S24C350HL /
S27C350H)
44 Connecting to Headphones
(S22C350H / S23C340H / S23C350H /
S24C340HL / S24C350H / S24C350HL /
S27C350H)
44 Connecting the Power
45 Tidying Up the Connected Cables
46 Changing the sound settings on Windows
47 Driver Installation
48 Setting Optimum Resolution
49 Changing the Resolution Using a PC
SCREEN SETUP
(S19C350NW)
53 Brightness
53 Configuring Brightness
54 Contrast
54 Configuring Contrast

Table Of Contents
Table Of Contents 4
55 Sharpness
55 Configuring Sharpness
56 SAMSUNG MAGIC Bright
56 Configuring SAMSUNG MAGIC Bright
57 SAMSUNG MAGIC Angle
57 Configuring SAMSUNG MAGIC Angle
58 SAMSUNG MAGIC Upscale
58 Configuring SAMSUNG MAGIC Upscale
59 Image Size
59 Changing the Image Size
60 H-Position & V-Position
60 Configuring H-Position & V-Position
61 Coarse
61 Adjusting Coarse
62 Fine
62 Adjusting Fine
SCREEN SETUP
(S22C350B / S23C350B /
S24C350BL)
63 Brightness
63 Configuring Brightness
64 Contrast
64 Configuring Contrast
65 Sharpness
65 Configuring Sharpness
66 SAMSUNG MAGIC Bright
66 Configuring SAMSUNG MAGIC Bright
67 SAMSUNG MAGIC Angle
67 Configuring SAMSUNG MAGIC Angle
68 SAMSUNG MAGIC Upscale
68 Configuring SAMSUNG MAGIC Upscale

Table Of Contents
Table Of Contents 5
69 Image Size
69 Changing the Image Size
71 H-Position & V-Position
71 Configuring H-Position & V-Position
72 Coarse
72 Adjusting Coarse
73 Fine
73 Adjusting Fine
SCREEN SETUP
(S22C350H / S23C340H /
S23C350H / S24C340HL /
S24C350H / S24C350HL /
S27C350H)
74 Brightness
74 Configuring Brightness
75 Contrast
75 Configuring Contrast
76 Sharpness
76 Configuring Sharpness
77 SAMSUNG MAGIC Bright
77 Configuring SAMSUNG MAGIC Bright
79 SAMSUNG MAGIC Angle
79 Configuring SAMSUNG MAGIC Angle
80 SAMSUNG MAGIC Upscale
80 Configuring SAMSUNG MAGIC Upscale
81 Image Size
81 Changing the Image Size
83 HDMI Black Level
83 Configuring the HDMI Black Level Settings
84 H-Position & V-Position
84 Configuring H-Position & V-Position
85 Coarse
85 Adjusting Coarse

Table Of Contents
Table Of Contents 6
86 Fine
86 Adjusting Fine
CONFIGURING TINT 87 Red
87 Configuring Red
88 Green
88 Configuring Green
89 Blue
89 Configuring Blue
90 Color Tone
90 Configuring the Color Tone Settings
91 Gamma
91 Configuring Gamma
COORDINATING OSD 92 Language
92 Changing the Language
93 Menu H-Position & Menu V-Position
93 Configuring Menu H-Position & Menu V-
Position
94 Display Time
94 Configuring Display Time
95 Transparency
95 Changing Transparency
SETUP AND RESET
(S19C350NW)
96 Reset
96 Initializing Settings (Reset)
97 Eco Saving
97 Configuring Eco Saving
98 Off Timer
98 Configuring Off Timer

Table Of Contents
Table Of Contents 7
99 Turn Off After
99 Configuring Turn Off After
100 Key Repeat Time
100 Configuring Key Repeat Time
101 Power LED On
101 Configuring Power LED On
SETUP AND RESET
(S22C350B / S23C350B /
S24C350BL)
102 Reset
102 Initializing Settings (Reset)
103 Eco Saving
103 Configuring Eco Saving
104 Off Timer
104 Configuring Off Timer
105 Turn Off After
105 Configuring Turn Off After
106 PC/AV Mode
106 Configuring PC/AV Mode
107 Key Repeat Time
107 Configuring Key Repeat Time
108 Source Detection
108 Configuring Source Detection
109 Power LED On
109 Configuring Power LED On
SETUP AND RESET
(S22C350H / S23C340H /
S23C350H / S24C340HL /
S24C350H / S24C350HL /
S27C350H)
110 Reset
110 Initializing Settings (Reset)
111 Eco Saving
111 Configuring Eco Saving
112 Off Timer
112 Configuring Off Timer

Table Of Contents
Table Of Contents 8
113 Turn Off After
113 Configuring Turn Off After
114 PC/AV Mode
114 Configuring PC/AV Mode
115 Key Repeat Time
115 Configuring Key Repeat Time
116 Source Detection
116 Configuring Source Detection
117 Power LED On
117 Configuring Power LED On
INFORMATION MENU AND
OTHERS
118 INFORMATION
118 Displaying INFORMATION
119 Configuring Brightness and Contrast in
the Initial Screen
120 Configuring Volume in the Initial Screen
INSTALLING THE
SOFTWARE
121 MagicTune
121 What is "MagicTune"?
121 Installing the Software
122 Removing the Software
123 MultiScreen
123 Installing the Software
124 Removing the Software
TROUBLESHOOTING
GUIDE
125 Requirements Before Contacting
Samsung Customer Service Center
125 Testing the Product
125 Checking the Resolution and Frequency
125 Check the following.
128 Q & A

Table Of Contents
Table Of Contents 9
SPECIFICATIONS 130 General (S19C350NW)
132 General (S22C350B / S23C350B /
S24C350BL)
134 General (S22C350H / S23C340H)
136 General (S23C350H / S24C340HL)
138 General (S24C350HL / S24C350H /
S27C350H)
140 PowerSaver
142 Standard Signal Mode Table
APPENDIX 145 Contact SAMSUNG WORLD WIDE
151 Responsibility for the Pay Service (Cost
to Customers)
151 Not a product defect
151 A Product damage caused by customer's fault
151 Others
153 Correct Disposal
153 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
154 Terminology
INDEX

10
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
2013 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Icons used in this manual
An administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual)
(b) you bring the unit to a repair centre and there is no defect in the product
(i.e. where you have failed to read this user manual).
The amount of such administration charge will be advised to you before any work or home visit
is carried out.
The following images are for reference only. Real-life situations may
differ from what is shown in the images.
©

11
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1. Power off the monitor and computer.
2. Disconnect the power cord from the monitor.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the monitor with a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the monitor.
5. Connect the power cord to the product after cleaning the product.
6. Power on the monitor and computer.
!
!

12
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire
and damage the product. Be sure to allow the amount of space as shown below or greater when
installing the product.
The exterior may differ depending on the product.
Precautions for storage
Be sure to contact Samsung Customer Service Center (page 145) if the inside of the monitor needs
cleaning. (service fee will be charged).
3.93 inches(10 cm)
3.93
inches
(10 cm)
3.93
inches
(10 cm)
3.93 inches
(10 cm)
3.93 inches
(10 cm)

13
Before Using the Product
Before Using the Product
Safety Precautions
Symbols for safety precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

14
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
An electric shock or fire may result.
Do not plug many products into the same power socket.
Otherwise, the socket may overheat and cause a fire.
Do not touch the power plug with wet hands.
Otherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
An unstable connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices
only).
An electric shock or injury may result.
Do not bend or pull the power cord with force. Do not weigh the power cord
down with a heavy object.
A damaged power cord may cause an electric shock or fire.
Do not place the power cord or product near heat sources.
An electric shock or fire may result.
Remove foreign substances such as dust around the plug pins and power socket
with a dry cloth.
Otherwise, a fire may result.
!
!
!

15
Before Using the Product
Before Using the Product
Caution
Installation and Safety
Warning
Do not unplug the power cord when the product is in use.
The product may become damaged by an electric shock.
Do not use the power cord for products other than authorized products supplied
by Samsung.
An electric shock or fire may result.
Keep the power socket where the power cord is connected unobstructed.
If any problem occurs in the product, unplug the power cable to completely
cut the power to the product.
Power to the product cannot be completely cut off with the power button.
Hold the plug when disconnecting the power cord from the power socket.
An electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
Otherwise, a fire may result.
Avoid installing the product in a narrow space with bad ventilation, such as a
bookshelf or wall closet.
Otherwise, a fire may result due to an increased internal temperature.
Keep the plastic packaging bag for the product in a place that cannot be reached
by children.
Children may suffocate.
!
!
!
!

16
Before Using the Product
Before Using the Product
Caution
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.).
The product may fall and break or cause a personal injury.
Using the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
An electric shock or fire may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
Otherwise, the product lifespan may be reduced, or a fire may result.
Do not install the product within the reach of young children.
The product may fall and injure children.
Edible oil, such as soybean oil, can damage or deform the product. Do not install
the product in a kitchen or near a kitchen counter.
Take care not to drop the product when moving it.
Otherwise, product failure or personal injury may result.
Do not set down the product on its front.
The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
The product may fall and break or cause a personal injury.
Install the product only on cabinets or shelves of the right size.
!
!

17
Before Using the Product
Before Using the Product
Operation
Warning
Put down the product carefully.
The product may fall and break or cause a personal injury.
Installing the product in an unusual place (a place exposed to a lot of fine
particles, chemical substances or extreme temperatures, or an airport or train
station where the product should operate continuously for an extended period of
time) may seriously affect its performance.
Be sure to consult Samsung Customer Service Center (page 145) before
installation if you want to install the product at such a place.
High voltage runs through the product. Do not attempt to disassemble, repair, or
modify the product on your own.
An electric shock or fire may result.
Contact Samsung Customer Service Center (page 145) for repair.
Before moving the product, turn off the power switch and disconnect the power
cable and all other connected cables.
Otherwise, the power cord may be damaged and a fire or electric shock may
result.
If the product generates a strange noise, a burning smell, or smoke, remove the
power cord immediately and contact Samsung Customer Service Center (page
145).
An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
The product may fall, and your child may become injured or seriously
harmed.
If the product falls or the exterior is damaged, power off the product, remove the
power cord, and contact Samsung Customer Service Center (page 145).
Otherwise, an electric shock or fire may result.
Do not put a heavy object, toy, or sweets on top of the product.
The product or heavy objects may fall as children try to reach for the toy or
sweets resulting in a serious injury.
!
SAMSUNG
!
!
!

18
Before Using the Product
Before Using the Product
During a lightning or thunderstorm, power off the product and remove the power
cable.
An electric shock or fire may result.
Do not drop objects on the product or apply impact.
An electric shock or fire may result.
Do not move the product by pulling the power cord or any cable.
Otherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
Sparks can cause an explosion or fire.
Do not lift or move the product by the power cord or any cable.
Otherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
Do not use or keep combustible spray or an inflammable substance near the
product.
An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
Otherwise, a fire may result from an increased internal temperature.
Do not insert a metallic object (a chopstick, coin, hair pin, etc.) or inflammable
object (paper, match, etc.) into the vent or ports of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 145).
Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 145).
Product failure, an electric shock or fire may result.
!
!
!
GAS
!
100

19
Before Using the Product
Before Using the Product
Caution
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
If you are not going to use the product for an extended period of time,
activate power-saving mode or a moving-picture screen saver.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
Otherwise, a fire may result from accumulated dust, overheating, an electric
shock, or electric leakage.
Use the product at the recommended resolution and frequency.
Your eyesight may deteriorate.
Do not put DC power adapters together.
Otherwise, a fire may result.
Remove the plastic bag from the DC power adapter before you use it.
Otherwise, a fire may result.
Do not let water enter the DC power device or get the device wet.
An electric shock or fire may result.
Avoid using the product outdoors where it can be exposed to rain or snow.
Be careful not to get the DC power adapter wet when you wash the floor.
Do not put the DC power adapter near to any heating apparatus.
Otherwise, a fire may result.
Keep the DC power adapter in a well-ventilated area.
Looking at the screen too close for an extended period of time can deteriorate
your eyesight.
!
!
-_-
!
!
!
!

20
Before Using the Product
Before Using the Product
Do not hold the monitor upside-down or move it by holding the stand.
The product may fall and break or cause a personal injury.
Do not use humidifiers or stoves around the product.
An electric shock or fire may result.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
Eye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended
period of time as it will become hot.
Store the small accessories used with the product out of reach of children.
Exercise caution when adjusting the product angle or stand height.
Otherwise, children's fingers or hands may become stuck and injured.
Tilting the product excessively may cause it to fall and result in personal
injury.
Do not place heavy objects on the product.
Product failure or personal injure may result.
When using headphones or earphones, do not turn the volume too high.
Having the sound too loud may damage your hearing.
!
!
!
