Samsung HT-D350 User manual

Digital Home
Entertainment System
user manual
Imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
HT-D350
HT-D355
HT-D350_D355-TK_ENG-1228.indd Sec1:1HT-D350_D355-TK_ENG-1228.indd Sec1:1 2011-12-29  10:57:562011-12-29  10:57:56

2English
Safety Information
Safety Warnings
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
CAUTION : TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
This symbol indicates important
instructions accompanying the
product.
WARNING
To reduce the risk of fire or electric shock, do
not expose this appliance to rain or moisture.
CAUTION
Apparatus shall not be exposed to dripping or splashing
and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
The Mains plug is used as a disconnect device and shall
stay readily operable at any time.
This apparatus shall always be connected to an AC outlet
with a protective grounding connection.
To disconnect the apparatus from the mains, the plug
must be pulled out from the mains socket, therefore the
mains plug shall be readily operable.
•
•
•
•
•
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1
CLASS 1 LASER PRODUCT
This Compact Disc player is classified as a CLASS
1 LASER product.
Use of controls, adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED, AVOID EXPOSURE TO BEAM.
•
HT-D350_D355-TK_ENG-1228.indd 2HT-D350_D355-TK_ENG-1228.indd 2 2011-12-29  10:58:182011-12-29  10:58:18

English 3
Accessories
Check for the supplied accessories below.
㪈㪉㪊
㪋㪌㪍
㪎㪏
㪇
㪐
FUNCTION
TVSOURCE
DSP/ EQ
ABCD
S/WLEVEL
REPEAT USBREC DIMMER
TUNER
MEMORY
MO/ST
DISC
MENU
TITLE
INFO GIGA
VOL
TVCH V
TUNINGV
DVDRECEIVER
SELECT
SAMSUNG
TV
MUTE
POWER
PL
TOOLS
Video Cable FM Antenna
User manual Remote Control/Batteries (AAA size)
Precautions
Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product.
Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (7.5~10cm).
Do not place the product on amplifiers or other equipment which may become hot.
Make sure the ventilation slots are not covered.
Do not stack anything on top of the product.
Before moving the product, ensure the Disc Insert Hole is empty.
In order to disconnect the product completely from the power supply, remove the AC plug from the wall outlet, especially when left
unused for a long period of time.
During thunderstorms, disconnect the AC plug from the wall outlet. Voltage peaks due to lightning could damage the
product.
Do not expose the product to direct sunlight or other heat sources. This could lead to overheating and malfunction of the
product.
Protect the product from moisture, and excess heat or equipment creating strong magnetic or electric fields (i.e.
speakers.).
Disconnect the power cable from the AC supply if the product malfunctions.
Your product is not intended for industrial use. Use of this product is for personal use only.
Condensation may occur if your product or disc has been stored in cold temperatures. If transporting the product during
the winter, wait approximately 2 hours until the product has reached room temperature before using.
The batteries used with this product contain chemicals that are harmful to the environment.
Do not dispose of batteries in the general household trash.
•
•
•
•
•
•
•
•
•
•
•
•
•
HT-D350_D355-TK_ENG-1228.indd 3HT-D350_D355-TK_ENG-1228.indd 3 2011-12-29  10:58:182011-12-29  10:58:18

4English
Cautions on Handling and Storing Discs
Small scratches on the disc may reduce sound and
picture quality or cause skipping.
Be especially careful not to scratch discs when
handling them.
Holding discs
Do not touch the playback side of the disc.
Hold the disc by the edges so that
fingerprints will not get on the surface.
Do not stick paper or tape on the disc.
Disc Storage
Do not keep in direct sunlight
Keep in a cool ventilated area
Keep in a clean Protection jacket.
Store vertically.
NOTE
Do not allow the discs to become contaminated with dirt.
Do not load cracked or scratched discs.
Handling and Storing Discs
If you get fingerprints or dirt on the disc, clean it with a
mild detergent diluted in water and wipe with a soft cloth.
When cleaning, wipe gently from the inside to the
outside of the disc
NOTE
Condensation may form if warm air comes into contact
with cold parts inside the product. When condensation
forms inside the product, it may not operate correctly. If
this occurs, remove the disc and let the product stand
for 1 or 2 hours with the power on.
•
•
•
•
•
•
✎


•
✎

Licence
Dolby, Pro Logic, and the double-D symbol are
registered trademarks of Dolby Laboratories.
ABOUT DIVX VIDEO: DivX® is a digital video format
created by DivX, Inc. This is an official DivX Certified®
device that plays DivX video. Visit www.divx.com for
more information and software tools to convert your files
into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified®
device must be registered in order to play purchased
DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your
device setup menu. Go to vod.divx.com for more
information on how to complete your registration.
DivX Certified® to play DivX® video, including premium
content
DivX®, DivX Certified® and associated logos are
trademarks of DivX, Inc. and are used under licence.
Covered by one or more of the following U.S. patents :
7,295,673; 7,460,668; 7,515,710; 7,519,274
HDMI, the HDMI Logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other
countries.
This item incorporates copy protection technology that
is protected by U.S. patents and other intellectual
property rights of Rovi Corporation. Reverse engineering
and disassembly are prohibited.
Copyright
© 2011 Samsung Electronics Co., Ltd. All rights reserved.
Copy Protection
Many DVD discs are encoded with copy protection.
Because of this, you should only connect your product
directly to your TV, not to a VCR. Connecting to a VCR
results in a distorted picture from copy-protected DVD
discs.
•
•
•
•
•
Safety Information
HT-D350_D355-TK_ENG-1228.indd 4HT-D350_D355-TK_ENG-1228.indd 4 2011-12-29  10:58:182011-12-29  10:58:18

English 5
Contents
ENGLISH
SAFETY INFORMATION
2 Safety Warnings
3 Precautions
3 Accessories
4 Cautions on Handling and Storing Discs
4 Licence
4 Copyright
4 Copy Protection
GETTING STARTED
6 Icons that will be used in manual
6 Disc Types and Characteristics
9 Description
9 Front Panel
9 Rear Panel
10 Remote control
CONNECTIONS
11 Connecting the Speakers
14 Connecting the Video Out to your TV
16 Connecting the FM Antenna
17 Connecting Audio from External Components
SETUP
18 Before Starting (Initial Settings)
18 Setting the Setup menu
19 Display
19 TV Aspect
19 BD Wise
19 Resolution
19 HDMI Format
19 Video Out Signal
19 Audio
19 Speaker Setting
21 DRC (Dynamic Range Compression)
21 AUDIO SYNC
21 HDMI AUDIO
21 System
21 Initial Settings
21 DivX(R) Registration
21 Language
22 Security
22 Parental Rating
22 Change Password
22 Support
22 Product Information
BASIC FUNCTIONS
22 Disc Playback
23 Audio CD(CD-DA)/MP3/WMA Playback
23 JPEG File Playback
24 Using the Playback Function
27 Sound Mode
28 Listening to Radio
ADVANCED FUNCTIONS
29 USB Function
29 USB Recording
OTHER INFORMATION
30 Troubleshooting
31 Language code list
32 Specifications
Figures and illustrations in this User Manual are
provided for reference only and may differ from actual
product appearance.
An administration fee may be charged if either
an engineer is called out at your request and there
is no defect in the product
(i.e. where you have failed to read this user manual)
you bring the unit to a repair centre and there is no
defect in the product
(i.e. where you have failed to read this user
manual).
The amount of such administration charge will be
advised to you before any work or home visit is
carried out.
•
•
a.
b.
•
HT-D350_D355-TK_ENG-1228.indd 5HT-D350_D355-TK_ENG-1228.indd 5 2011-12-29  10:58:192011-12-29  10:58:19

6English
Getting Started
Icons that will be used in manual
Make sure to check the following terms before
reading the user manual.
Icon Term Definition
d
DVD
This involves a function
available with DVD-Video or
DVD±R/±RW discs that
have been recorded and
finalised in Video Mode.
B
CD
This involves a function
available with a data CD
(CD DA, CD-R/-RW).
A
MP3
This involves a function
available with CD-R/-RW
discs.
G
JPEG
This involves a function
available with CD-R/-RW
discs.
D
DivX
This involves a function
available with MPEG4 discs.
(DVD±R/±RW, CD-R/-RW)
!
CAUTION
This involves a case where a
function does not operate or
settings may be cancelled.
✎NOTE
This involves tips or instructions
on the page that help each
function operate.
Shortcut
Key
This function provides direct and
easy access pressing the button
on the remote control.
Region Code
The product and the discs are coded by region. These
regional codes must match in order for the disc to play. If the
codes do not match, the disc will not play.
A DVD Video labeled
ALL
will also play on this system.
Disc Types and Characteristics
Disc types that can be played
Disc Types &
Mark (Logo)
Recorded
Signals Characteristics
DVD-VIDEO
VIDEO
DVD video
DVD-R/DVD-RW IN DVD video
FORMAT
DVD+R/DVD+RW IN DVD
video FORMAT
AUDIO-CD
AUDIO AUDIO CD
DivX
AUDIO
+
VIDEO
AUDIO CD
CD-R/CD-RW in AUDIO CD
FORMAT
DATA CD
CD-R/CD-RW in DATA CD
FORMAT that contains the
following kinds of files and
conforms to ISO 9660 LEVEL
1/LEVEL 2, OR JOLIET
(EXTENDED FORMAT)
-MP3 files
-JPEG Image files
-MPEG 4 VIDEO files
DATA DVD
DVD-ROM/DVD-R/DVD-RW
DVD+R/DVD+RW IN DATA
DV FORMAT that contains
the following kinds of files
and conforms to
UDF(*Universal Disk Format)
-MP3 files
-JPEG Image files
-MPEG 4 VIDEO files
USB Device
USB Device that contains the
following kinds of files.
-MP3 FILE OR WMA/WMV
fi l e s
-JPEG Image files
-MPEG 4 Video files
HT-D350_D355-TK_ENG-1228.indd 6HT-D350_D355-TK_ENG-1228.indd 6 2011-12-29  10:58:192011-12-29  10:58:19

English 7
01 Getting Started
Do not use the following type of discs!
LD, CD-G, CD-I, CD-ROM, DVD-ROM and
DVD-RAM discs cannot be played on this product.
If such discs are played, a <WRONG DISC
FORMAT> message appears on the TV screen.
DVD discs purchased abroad may not play on this
product.
If such discs are played, a <Wrong Region. Please
check Disc.> message appears on the TV screen.
Disc Types And Disc Format
This product does not support Secure (DRM) Media files.
CD-R Discs
Some CD-R discs may not be playable depending on
the disc recording device (CD-Recorder or PC) and the
condition of the disc.
Use a 650MB/74 minute CD-R disc.
Do not use CD-R discs over 700MB/80 minutes as
they may not be played back.
Some CD-RW (Rewritable) media, may not be playable.
Only CD-Rs that are properly "closed" can be fully
played. If the session is closed but the disc is left open,
you may not be able to fully play the disc.
CD-R MP3 Discs
MP3 file names should contain no blank spaces
or special characters (. / = +).
Use discs recorded with a compression/
decompression data rate greater than 128Kbps.
If the disc is not closed, it will take longer to begin
playback and not all of the recorded files may be played.
For files encoded in Variable Bit Rate (VBR)
format, i.e. files encoded in both low bit rate and
high bit rate (e.g., 32Kbps ~ 320Kbps), the
sound may skip during playback.
A maximum of 500 tracks can be played per CD.
A maximum of 300 folders can be played per CD.
CD-R JPEG Discs
A maximum of 999 images can be stored on a folder.
When playing a Kodak/Fuji Picture CD, only the JPEG
files in the picture folder can be played.
Picture discs other than Kodak/Fuji Picture CDs may
take longer to start playing or may not play at all.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DVD±R/±RW, CD-R/RW Discs
Software updates for incompatible formats are not
supported.
(Example : QPEL, GMC, resolutions higher than
800 x 600 pixels, etc.)
If a DVD-R/-RW disc has not been recorded
properly in DVD Video format, it will not be
playable.
DivX (Digital internet video express)
DivX® is a video file format developed by DivX, Inc and is
based on MPEG4 compression technology to provide
audio and video data over the Internet in real-time.
MPEG4 is used for video encoding and MP3 for audio
encoding, enabling to watch a movie at near DVD-quality
video and audio.
Supported Formats (DivX)
This product only supports the following media formats.If both
video and audio formats are not supported, the user may
experience problems such as broken images or no sound.
Supported Video Formats
Format Supported Versions
AVI DivX3.11~DivX5.1
WMV V1/V2/V3/V7
Supported Audio Formats
Format Bit Rate Sampling
Frequency
MP3 80~320kbps 44.1khz
WMA 56~128kbps
AC3 128~384kbps 44.1/48khz
Aspect Ratio : Although the default DivX resolution is
640x480 pixels, this product supports up to
720x480 pixels. TV screen resolutions higher than
800 will not be supported.
When you play a disc whose sampling frequency is
higher than 48khz or 320kbps, you may experience
shaking on the screen during playback.
Sections with a high frame rate might not be played
while playing a DivX file.
Since this product only provides encoding formats
authorized by DivX Networks, Inc., a DivX file
created by the user might not play.
•
•
•
•
•
•
HT-D350_D355-TK_ENG-1228.indd 7HT-D350_D355-TK_ENG-1228.indd 7 2011-12-29  10:58:192011-12-29  10:58:19

8English
Getting Started
Notes on USB connection
Supported devices: USB storage media, MP3
player, digital camera
If a folder or file name is longer than 10
characters, it may not properly display or
operate.
A subtitle file bigger than 300KB may not be
properly displayed.
A certain USB/digital camera device, USB card
reader is not supported.
FAT16 and FAT32 file systems are supported.
Photo (JPEG), music (MP3, WMA) and video file
should have their names in Korean or English.
Otherwise, the file may not played.
Connect directly to the product's USB port.
Connecting through another cable may raise
problems with USB compatibility.
Inserting more than one memory device to a
multi-card reader may not operate properly.
PTP protocol for digital camera is not supported.
Do not disconnect USB device during a
"Reading" process.
Bigger the image resolution, the longer the delay
to displaying.
DRM applied MP3/WMA or video files
downloaded from a commercial site are not
played back.
External HDD device is not supported.
The maximum current supported by the USB
port for an external device is 500 mA (at 5V DC).
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
Supported file formats
Format Still
Picture Music Movie
File name
JPG MP3 WMA WMV DivX
File
extension
JPG
.JPEG .MP3 .WMA .WMV .AVI
Bit rate
–80~320
kbps
56~128
kbps
4Mbps 4Mbps
Version
–– V8 V1,V2,
V3,V7
DivX3.11~
DivX5.1
Pixel
640x480 –– 720x480
Sampling
Frequency
– 44.1kHz 44.1kHz 44.1KHz~ 48KHz
14)
HT-D350_D355-TK_ENG-1228.indd 8HT-D350_D355-TK_ENG-1228.indd 8 2011-12-29  10:58:192011-12-29  10:58:19

English 9
01 Getting Started
Description
Front Panel
Rear Panel
SURROUND SURROUND
SUBWOOFER
CENTER FRONTFRONT
SPEAKERS OUT
SPEAKER IMPEDANCE : 3
FM ANT
VIDEO OUT
AUX IN
COMPONENT OUT
HDMI OUT
DIGITAL
AUDIO IN
ONLY
FOR SERVICE
1 2
1
SPEAKER OUTPUT
CONNECTORS
2
ONLY FOR SERVICE
3
EXTERNAL DIGITAL OPTICAL IN
JACK (DIGITAL AUDIO IN)
4
HDMI OUT JACK
5
COMPONENT VIDEO OUTPUT
JACKS
6
FM ANTENNA JACK
7
VIDEO OUT JACK
8
AUX IN JACKS
3 54 6
8 7
5V 500mA
1 2 86 7 94 53
1
DISC TRAY
2
DISPLAY
3
USB PORT
4
OPEN/CLOSE BUTTON ( )
5
FUNCTION BUTTON ( )
6
STOP BUTTON ( )
7
PLAY/PAUSE BUTTON ( )
8
VOLUME CONTROL BUTTON
( , )
9
POWER BUTTON ( )
10
REMOTE CONTROL SENSOR
10
HT-D350_D355-TK_ENG-1228.indd 9HT-D350_D355-TK_ENG-1228.indd 9 2011-12-29  10:58:192011-12-29  10:58:19

10 English
Getting Started
Remote control
Tour of the Remote Control
Installing batteries in the Remote Control
NOTE
Place batteries in the remote control so they match the
polarity : (+) to (+) and (–) to (–).
Always replace both batteries at the same time.
Do not expose the batteries to heat or flame.
The remote control can be used up to approximately 7
meters in a straight line.
The remote control will work on a Samsung TV.
✎





* Battery size: AAA
㪈㪉㪊
㪋㪌㪍
㪎㪏
㪇
㪐
FUNCTION
TV SOURCE
DSP / EQ
ABCD
S/W LEVEL
REPEAT USB REC DIMMER
TUNER
MEMORY
MO/ST
DISC
MENU
TITLE
INFO GIGA
VOL
TV CH V
TUNING V
DVD RECEIVER
SELECT
SAMSUNG
TV
MUTE
POWER
PL
TOOLS
Turn the product on and off.
Allow access to common functions
of the product such as the Photo
List.
A. TITLE button : Press to check
the title menu.
B. DISC MENU button : Press to
check the disc menu.
Press numeric button to operate options.
or
1. PLII button : Select the desired Dolby
Pro Logic II audio mode, P.Bass or MP3
enhancement function.
2. DSP/EQ button : Select the desired
DSP/EQ audio mode.
3. SW/ LEVEL button : Used to adjust the
level of the subwoofer.
4. REPEAT button : Allows you to repeat a
title, chapter, track or disc.
Adjust the volume up/down.
Press to skip forwards /Change channels up.
Press to select TV.
Exit the menu.
Return to the previous menu.
To open and close the disc tray.
Press to select TV's video mode.
or
This is mode selection button.
Press to pause a disc.
Press numeric button to operate options.
or
5. USB REC button : Used to start USB
recording.
6. DIMMER button : Adjust the
brightness of Display.
7. INFO button :Display current disc(file)
status.
8.GIGA button : Used to turn on/off
GIGA Sound function.
Cut off the sound temporarily.
C. MO/ST button : Press to listen
in Mono/Stereo in the FM mode.
D. TUNER MEMORY button :
Press to preset FM stations.
Press this to move to the home
menu.
Press to stop/play a disc.
Press to skip backwards.
/Change channels down.
Select on-screen menu items and
change menu value.
Used to change the audio/subtitle
language, angle etc.
Press to select the DVD RECEIVER
mode.
Press to search backwards or
forwards.
HT-D350_D355-TK_ENG-1228.indd 10HT-D350_D355-TK_ENG-1228.indd 10 2011-12-29  10:58:202011-12-29  10:58:20

English 11
02 Connections
This section involves various methods of connecting the product to other external components.
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
Connecting the Speakers
Front Speakers ei
Place these speakers in front of your listening position, facing inwards (about 45°)
toward you. Place the speakers so that their tweeters will be at the same height
as your ear. Align the front face of the front speakers with the front face of the
center speaker or place them slightly in front of the center speakers.
Center Speaker f
It is best to install it at the same height as the front speakers. You can also install it
directly over or under the TV.
Surround Speakershj
Place these speakers to the side of your listening position. If there isn't enough
room, place these speakers so they face each other. Place them about 60 to
90cm above your ear, facing slightly downward.
*
Unlike the front and center speakers, the surround speakers are used to
handle mainly sound effects and sound will not come from them all the time.
Subwoofer g
The position of the subwoofer is not so critical. Place it anywhere you like.
Position of the product
Place it on a stand or cabinet shelf, or under the
TV stand.
Selecting the Listening Position
The listening position should be located about 2.5
to 3 times the distance of the TV's screen size
away from the TV.
Example : For 32" TV's 2~2.4m
For 55" TV's 3.5~4m
SW
CAUTION
Do not let children play with or near the speakers. They could get hurt if the speaker falls.
When connecting the speaker wires to the speakers, make sure that the polarity (+/–) is correct.
Keep the subwoofer out of the reach of children so as to prevent them from inserting their hands or alien
substances into the duct (hole) of the subwoofer.
Do not hang the subwoofer on the wall through the duct (hole).
NOTE
If you place a speaker near your TV set, screen colour may be distorted because of the magnetic field
generated by the speaker. If this occurs, place the speaker away from your TV set.
!




✎

Connections
HT-D350_D355-TK_ENG-1228.indd 11HT-D350_D355-TK_ENG-1228.indd 11 2011-12-29  10:58:212011-12-29  10:58:21

12 English
Connections
Speaker Components
SPEAKER CABLE
FRONT
(L) (R)
SUBWOOFER
SURROUND
(L) (R)
CENTER
HT-D350
Speaker Components Assembled Speakers
HT-D355

FRONT
SURROUND
(L) (R) STAND
STAND BASE
(L) (R)
SCREW (5×15): 4EA
SCREW (4×20): 16EA
SUBWOOFER
CENTER SPEAKER
FRONT/SURROUND
SPEAKER
SUBWOOFER
CENTER
Installing the Speakers on the Tallboy Stand
* HT-D355 only - Front/Surround Speakers
Turn the Stand Base upside-down and connect it to
the Stand.
Insert small screws (4*20, For connecting Stand & Stand
Base) clockwise into the four holes marked using a
screwdriver as shown in the illustration.
CAUTION : When you use a torque screwdriver, be
careful not to put excessive force. Otherwise, it runs
idle or can be damaged. (torque screwdriver- below
15 kg.f.cm)
1.
2.
!
1 2
Stand
Stand
Base
HT-D355
SPEAKER CABLE
HT-D350_D355-TK_ENG-1228.indd 12HT-D350_D355-TK_ENG-1228.indd 12 2011-12-29  10:58:212011-12-29  10:58:21

English 13
02 Connections
Connecting The Speakers
Press down the terminal tab on the back of the speaker.
Insert the black wire into the black terminal (–) and the red wire into the red
terminal (+), and then release the tab.
Connect the connecting plugs to the back of the product by matching the
colours of the speaker plugs to the speaker jacks.
1.
2.
3.
Black Red
Connecting the wall mount
Connect the speaker cord with the colour
tube to (+), and the speaker cord without the
colour tube to (–).
Prepare screws (not supplied) that are suitable
for the hole on the back of each speaker.
See the illustrations below.
Fasten the screws to the wall, then hang the
speaker on the wall.
1.
2.
3.
Colour tube
Front left speaker (L) : White
Front right speaker (R) : Red
Center speaker : Green
Surround left speaker (L) : Blue
Surround right speaker (R) : Gray
5 mm
10 mm
Hold on the back of the speaker
30 mm
4 mm
8 to 10 mm
Depth of fastened screw
Connect the upper Speaker to the assembled Stand.
Insert another large screw (5*15, For connecting Speaker
& Stand) clockwise into the hole on the rear of the
speaker using a
screwdriver.
This is the appearance after the speaker is installed.
Follow this steps to install other speaker.
3.
4.
5.
5
4
3
Stand
Speaker
HT-D350_D355-TK_ENG-1228.indd 13HT-D350_D355-TK_ENG-1228.indd 13 2011-12-29  10:58:322011-12-29  10:58:32

14 English
Connections
Connecting the Video Out to your TV
Choose one of the three methods for connecting to a TV.
METHOD 1 : HDMI
Connect an HDMI cable (not supplied) from the HDMI OUT jack on the back of the product to the HDMI IN
jack on your TV.
METHOD 2 : Component Video
If your television is equipped with Component Video inputs, connect a Component video cable(not supplied)
from the COMPONENT OUT (PR, PBand Y) jacks on the back of the product to the Component Video Input
jacks on your TV.
METHOD 3 : Composite Video
Connect the supplied Video cable from the VIDEO OUT jack on the back of the product to the VIDEO IN jack
on your TV.
NOTE
Resolutions available for the HDMI output are 480p(576p), 720p,1080i/1080p. See page 19 for the resolution
setting.
This product operates in Interlace scan mode 480i(576i) for component/composite output.
After making the video connection, set the Video input source on your TV to match the corresponding Video
output mode on your product.
Turn this product on first before you set the video input source on your TV. See your TV owner's manual for
more information on how to select the TV's Video Input source.
CAUTION
Do not connect the unit through a VCR. Video signals fed through VCRs may be affected by copyright
protection systems and the picture will be distorted on the television.
✎



!

FM ANT
VIDEO OUT
AUX IN
COMPONENT OUT
HDMI OUT
DIGITAL
AUDIO IN
FM
ANT
AUX
IN
D
IGITA
L
AUDIO I
N
METHOD 3 (supplied)
Green
BlueRed
METHOD 1
METHOD 2
HT-D350_D355-TK_ENG-1228.indd 14HT-D350_D355-TK_ENG-1228.indd 14 2011-12-29  10:58:342011-12-29  10:58:34

English 15
02 Connections
HDMI FUNCTION
HDMI Auto Detection Function
The product's video output will automatically change to HDMI mode when connecting an HDMI cable while power is on.
HDMI (High Definition Multimedia Interface)
HDMI is an interface that enables the digital transmission of video and audio data with just a single
connector. Using HDMI, the product transmits a digital video and audio signal and displays a vivid picture
on a TV having an HDMI input jack.
HDMI connection description
- HDMI outputs only a pure digital signal to the TV.
- If your TV does not support HDCP (High-bandwidth Digital Content Protection), random noise appears
on the screen.
What is the HDCP?
HDCP (High-band width Digital Content Protection) is a system for protecting DVD content outputted via
HDMI from being copied. It provides a secure digital link between a video source (PC, DVD. etc) and a
display device (TV, projector. etc). Content is encrypted at the source device to prevent unauthorized
copies from being made.
Using Anynet+(HDMI-CEC)
Anynet+ is a function that enables you to control other Samsung Devices with your Samsung TV's remote
control. Anynet + can be used by connecting this product to a SAMSUNG TV using a HDMI Cable. This is
only available with SAMSUNG TV's that support Anynet+.
Connect the product to a Samsung TV with an HDMI cable. (See page 14)
Set the Anynet+ function on your TV. (See the TV instruction manual for more information.)
NOTE
The Anynet+ function supports some buttons of the remote control.
This function is not available if an HDMI cable does not support CEC.
Depending on your TV, certain HDMI output resolutions may not work.
Please refer to the user’s manual of your TV.
Please check the
logo (If your TV has an logo, then it supports Anynet+ function.)
•
•
•
•
•
1.
2.
✎




HT-D350_D355-TK_ENG-1228.indd 15HT-D350_D355-TK_ENG-1228.indd 15 2011-12-29  10:58:352011-12-29  10:58:35

16 English
Connections
Connecting the FM Antenna
Connect the FM antenna supplied to the FM Antenna jack.
Slowly move the antenna wire around until you find a location where reception is good, then fasten it to a
wall or other rigid surface.
NOTE
This product does not receive AM broadcasts.
1.
2.
✎

FM ANT
VIDEO OUT
AUX IN
COMPONENT OUT
HDMI OUT
T
AL
O
IN
V
IDE
O
OUT
AU
X IN
C
OMPONENT OUT
H
DMI OU
T
T
AL
O
IN
FM Antenna (supplied)
HT-D350_D355-TK_ENG-1228.indd 16HT-D350_D355-TK_ENG-1228.indd 16 2011-12-29  10:58:352011-12-29  10:58:35

English 17
02 Connections
Connecting Audio from External Components
SURROUND SURROUND
SUBWOOFER
CENTER FRONTFRONT
SPEAKERS OUT
SPEAKER IMPEDANCE : 3
FM ANT
VIDEO OUT
AUX IN
COMPONENT OUT
HDMI OUT
DIGITAL
AUDIO IN
ONLY
FOR SERVICE
SPEAKERS OUT
SPEAKER IMPEDANCE : 3
FM ANT
VIDEO OUT
COMPONENT OUT
HDMI OUT
ONLY
FOR SERVICE
Optical Cable
(not supplied)
Audio Cable (not supplied)
If the external analogue
component has only one Audio
Out, connect either left or right.
Set-Top Box VCR
AUX
OPTICAL
WhiteRed
AUX : Connecting an External Analogue Component
Analogue signal components such as a VCR.
Connect AUX IN (Audio) on the back of the product to the Audio Out of the external Analogue
component.
Be sure to match the colours of the connecting jacks.
Press the FUNCTION button to select AUX input.
The mode switches as follows :
DVD/CD ➞ D.IN ➞AUX ➞USB ➞FM
NOTE
You can connect the Video Output jack of your VCR to the TV, and connect the Audio Output jacks of the
VCR to this product.
OPTICAL : Connecting an External Digital Component
Digital signal components such as a Cable Box/Satellite receiver (Set-Top Box).
Connect the DIGITAL AUDIO IN (OPTICAL) on the back of the product to the Digital Output of the
external digital component.
Press the FUNCTION button to select D.IN.
The mode switches as follows :
DVD/CD ➞ D.IN ➞AUX ➞USB ➞FM
1.
•
2.
•
✎

1.
2.
•
HT-D350_D355-TK_ENG-1228.indd 17HT-D350_D355-TK_ENG-1228.indd 17 2011-12-29  10:58:362011-12-29  10:58:36

18 English
Setup
Before Starting (Initial Settings)
Press the POWER button when it is plugged in
TV for the first time.
Initial Settings screen will be displayed.
Move Select Return
Initial settings I On-Screen Language
Select a language for the on-screen displays.
English
한국어
Nederlands
Français
Deutsch
Italiano
Press the ▲▼ buttons to select the desired
language, then press the ENTER button.
Press the ENTER button to select Start button.
Press the ▲▼ buttons to select desired TV Aspect,
then press the ENTER button.
NOTE
If you have not selected a preferred language in
the initial settings, you will see a language
selection window next time you turn on the
product.
Your language selection will apply to all menus:
On-Screen Menu, Disc Menu, Audio, Subtitle.
If you want to move to the previous screen, press
the RETURN button.
Once you select a menu language, you can
change it by pressing the STOP () button on the
remote control for more than 5 seconds with no
disc inserted.
When the Initial Settings screen does not appear,
refer to the Initial Settings. (see page 21)
1.
2.
3.
4.
✎





Setting the Setup menu
The access step may differ depending on the selected
menu. The GUI (Graphical User Interface) in this
manual may differ, depending on the firmware version.
TUNING V
TOOLS
1
2
3
4
1
MENU BUTTON : Display the home menu.
2
ENTER / DIRECTION BUTTON
Move the cursor and select an item.
Select the currently selected item.
Confirm the setting.
3
RETURN BUTTON : Return to the previous
setup menu.
4
EXIT BUTTON : Exit the setup menu.
Function DVD/CD
Settings
Press the POWER button.
Press the
◄► buttons to select Settings, then
press the ENTER button.
Press the
 buttons to select the desired
menu, then press the ENTER button.
Press the
 buttons to select the desired sub-
menu, then press the ENTER button.
Press the
 buttons to select the desired
item, then press the ENTER button.
Press the EXIT button to exit the setup menu.
1.
2.
3.
4.
5.
6.
HT-D350_D355-TK_ENG-1228.indd 18HT-D350_D355-TK_ENG-1228.indd 18 2011-12-29  10:58:382011-12-29  10:58:38

English 19
03 Setup
Display
You can configure various display options such as
the TV Aspect, Resolution, etc.
TV Aspect
Depending on the type of television you have, you
may want to adjust the screen setting.
4:3 Pan-Scan •
Select when you want to see the 16:9
video supplied by the DVD without the
black bars on top and bottom, even
though you have a TV with a 4:3 ratio
screen(extreme left and right portion of
the movie picture will be cut off).
4:3 Letter Box •
Select when you want to see the total
16:9 ratio screen DVD supplies, even
though you have a TV with a 4:3 ratio
screen. Black bars will appear at the
top and bottom of the screen.
16:9 Wide •
You can view the full 16:9 picture on
your widescreen TV.
NOTE
When using HDMI, the screen is automatically converted to the
16:9 Wide mode and TV Aspect is deactivated.
If a DVD is in the 4:3 ratio, you cannot view it in the wide screen.
Since DVD discs are recorded in various image formats, they will
look different depending on the software, the type of TV, and the
TV aspect ratio setting.
BD Wise
(Samsung products only)
BD Wise is Samsung's latest inter-connectivity
feature. When you connect Samsung products with
BD-Wise to each other via HDMI, the optimum
resolution will be set automatically.
On : The original resolution of the DVD disc will
be output to the TV direct.
Off : The output resolution will be fixed
according to the Resolution previously set,
regardless of the resolution of the disc.
✎




•
•
NOTE
This will optimize the picture quality according
to the content (In the DVD disc, etc) that you
want to play and the product or your BD Wise-
compliant Samsung TV.
If you want to change the resolution in BD Wise
mode, you must set BD mode to Off in advance.
BD Wise will be disabled if the product is
connected to a device that does not support
BD Wise.
Resolution
Sets the output resolution of the HDMI video signal. The
number in 576p, 720p, 1080i and 1080p indicates the
number of lines of video.
The i and p indicate interlace and progressive scan,
respectively.
480p(576p) : Outputs 480 lines of progressive video.
720p : Outputs 720 lines of progressive video.
1080i : Outputs 1080 lines of interlaced video.
1080p : Outputs 1080 lines of progressive video.
BD Wise : Automatically sets the optimal resolution when
connected via HDMI to a TV with the BD Wise feature. (The
BD Wise menu item appears only if BD Wise is set to On.)
NOTE
If Component or Composite is connected, the
resolution supports only 480i(576i).
1080P may not appear depending on TV.
HDMI Format
You can optimize the colour setting from the HDMI
output. Select a connected device Type.
Monitor : Select if connected to a Monitor via HDMI.
TV : Select if connected to a TV via HDMI.
Video Out Signal
Different countries apply different TV standard.
You can select from NTSC or PAL.
NTSC : You can select the NTSC video format
PAL : You can select the PAL video format
Audio
Speaker Setting
Speaker Size
You can set the Speaker Size of the Center and Surround
Speakers, as well as Test Tone in this mode.
✎



•
•
•
•
•
✎


•
•
•
•
HT-D350_D355-TK_ENG-1228.indd 19HT-D350_D355-TK_ENG-1228.indd 19 2011-12-29  10:58:382011-12-29  10:58:38

20 English
Setup
Settings
Move Select Return
Speaker Setting
Speaker Size ►
Sound Edit
Delay Time
Test Tone : Off
Select Return
For the Front, the mode is set to Small.
For the Subwoofer, the mode is set to Present.
For the Center and Surround, you can switch the
mode to Small or None.
- Small : Select this when using the speakers.
- None : Select this when no speaker is
connected.
NOTE
The speaker mode may vary depending on the
Dolby Pro Logic and Stereo settings.
Sound Edit
You can adjust the balance and level for each speaker.
Settings
m Move " Select ' Return
Sound Edit
< Change " Select ' Return
dB
dB
dB
dB
dB
dB
dB
Front Bal.
Surround Bal.
Center Level
Surround Level
SW Level
R
R
L
L
Press the ▲▼ buttons to select and adjust the
desired speaker.
Press the ◄► buttons to adjust the settings.
Adjusting Front/Surround Bal.
You can select between 0 and -6.
The volume decreases as you move closer to –6.
Adjusting Center/Surround/Subwoofer Level
The volume level can be adjusted in steps from
+6dB to –6dB.
The sound gets louder as you move closer to +6dB
and quieter as you get closer to -6dB.
•
•
•
✎





Delay Time
If the speakers cannot be placed at equal distances from
the listening position, you can adjust the delay time of the
audio signals from the Center and Surround speakers.
You can also set the Test Tone in this mode.
Setting up the Speaker Delay Time
When 5.1CH Surround Sound is played, you can
enjoy the best sound if the distance between you
and each speaker is the same.
Since the sounds arrive at the listening position at
different times depending on the placement of
speakers, you can adjust this difference by adding a
delay effect to the Center and Surround Speakers.
Settings
m Move " Select ' Return
< Change " Select ' Return
Delay Time
Front
Center : 00ms
Surround : 10ms
Subwoofer
Test Tone : Off
Test Tone
Settings
m Move " Select ' Return
Speaker Setting
Speaker Size
Sound Edit
Delay Time
Test Tone : On ►
" Select ' Return
Use the Test Tone feature to check the speaker
connections.
Press the
◄► buttons to select On.
The test tone will be sent to Front Left ➞Center
➞Front Right ➞Surround Right ➞Surround
Left ➞Subwoofer in order.
To stop the test tone, press the ENTER button.
•
•
HT-D350_D355-TK_ENG-1228.indd 20HT-D350_D355-TK_ENG-1228.indd 20 2011-12-29  10:58:412011-12-29  10:58:41
