7150 Washer and Dryer Product Guide 1
Product Guide
Samsung proprietary and condential
7150 Series Laundry
WA54CG7150 – Washer
DVE54CG7150 – Electric Dryer
DVG54CG7150 – Gas Dryer
Available in Brushed Navy and White

Samsung proprietary and condential
7150 Washer and Dryer Product Guide 2
Table of Contents
Product Overview
Product Overview 4
Carousel Image Order 5
Product Messaging
Features and Benets 8
Lifestyle Images 14
Product Specs
Related Products 17
Spec Sheet 18
Energy Guide 19
User Manual and Warranty 20
Feature Icons 22
WA54CG7150 - Top Load Washer
Product Overview
Product Overview 24
Carousel Image Order 25
Product Messaging
Features and Benets 28
Product Specs
Related Products and Accessories 33
Spec Sheets 34
User Manual and Warranty 35
Feature Icons 37
Price Tag Guidance 38
DVE54CG7150 - Electric Dryer
DVG54CG7150 - Gas Dryer

Samsung proprietary and condential
7150 Washer and Dryer Product Guide 3
Product
Overview
Samsung proprietary and condential
WA54CG7150AD
WA54CG7150AW
5.4 cu. ft. Smart Top Load Washer with Pet Care Solution
and Super Speed Wash

Samsung proprietary and condential
7150 Washer and Dryer Product Guide 4
| 7150 Washer
Washer: Overview | Messaging | Specs | Icons
Product Overview
Product Description
Samsung's 5.4 cu. ft. Extra-Large Capacity Smart Top Load Washing Machine is equipped with Pet Care
Solution, which removes 6X more pet hair1 with Pet Care Wash Cycle that loosens hair to be trapped by dual
pet hair lters. With Super Speed Wash, powerfully clean a full load of laundry in just 28 minutes without
sacricing cleaning performance.2
• Pet Care Solution – Remove 6X more pet hair1
• Super Speed Wash – Thoroughly wash a full load in just 28 minutes2
• Wi-Fi Connectivity with SmartThings – Remotely start, schedule and receive end of cycle alerts to your smartphone3
• Active WaterJet – Easily pretreat with a built-in water faucet
1 WA7150C using the Pet Care Wash cycle and Pet Hair Filter compared to WA7700A using Normal cycle.
2 Based on using Super Speed on a Normal Cycle with an 8lb load.
3Requires wireless network, Samsung account and SmartThings App. The Samsung SmartThings App supports Android OS 4.0 (ICS) or later which is optimized for Samsung smartphones (Galaxy S and
Galaxy Note series). This app also supports iOS 7 or later for iPhone models. SmartThings App available in App Store and Play Store.
Product Title
5.4 cu. ft. Smart Top Load Washer with Pet Care Solution and Super Speed Wash
Available Colors
White
Model Number: WA54CG7150AW
UPC: 887276760377
Easy Ads Links
Brushed Navy Washer:https://dam.gettyimages.com/p/z0c3461/digital-appliances?o=AND&q=WA54CG7150AD
White Washer:https://dam.gettyimages.com/p/z0c3461/digital-appliances?o=AND&q=WA54CG7150AW
Brushed Navy
Model Number: WA54CG7150AD
UPC: 887276760360
