Samsung 6 series User manual

Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.
Country Customer Care Centre Web Site
AUSTRALIA 1300 362 603 www.samsung.com/au
CHINA 800-810-5858
400-810-5858
010-6475 1880
www.samsung.com/cn
HONG KONG:3698 - 4698 www.samsung.com/hk
INDIA 3030 8282
1-800-3000-8282
1800 110011
www.samsung.com/in
INDONESIA 0800-112-8888 www.samsung.com/id
JAPAN 0120-327-527 www.samsung.com/jp
MALAYSIA 1800-88-9999 www.samsung.com/my
NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com/nz
PHILIPPINES 1-800-10-SAMSUNG(726-7864)
1-800-3-SAMSUNG(726-7864)
02-5805777
www.samsung.com/ph
SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com/sg
THAILAND 1800-29-3232
02-689-3232
www.samsung.com/th
TAIWAN 0800-329-999 www.samsung.com/tw
VIETNAM 1 800 588 889 www.samsung.com/vn
SOUTH AFRICA 0860-SAMSUNG(726-7864 ) www.samsung.com/za
U.A.E 800-SAMSUNG (726-7864)
8000-4726
www.samsung.com/ae
LCD TV
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/hk
Model Serial No.
BN68-01564E-00
BN68-01564E.indb 1 2009-03-12 �� 8:00:06

License
Without producing harmful VOC (Volatile Organic Compounds), Samsung’s Eco-friendly “Crystal Design”
expresses colour gradation thanks to our dual injection technology.
TruSurround HD, SRS and symbol are trademarks of SRS Labs, Inc. TruSurround HD technology is
incorporated under license from SRS Labs, Inc.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
DivX Certied products using Home Theatre Test Kit v3.0 or later: Plays DivX® video, including premium
content.
Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen
Do not display still image and partially still on the LCD panel for more than 2 hours as it can cause screen image retention.
This image retention is also known as “screen burn”. To avoid such image retention, reduce the degree of brightness and
contrast of the screen when displaying a still image.
Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the
left, right and centre of the screen caused by the difference of light emission on the screen. Playing a DVD or
a game console may cause a similar effect to the screen. Damages caused by the above effect are not
covered by the Warranty.
Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images. To
prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
© 2009 Samsung Electronics Co., Ltd. All rights reserved.
❑
❑
●
●
●
BN68-01564E.indb 1 2009-03-12 �� 8:00:06

CONNECTING AND PREPARING YOUR TV
Viewing the Control Panel ................................................................. 2
Accessories ....................................................................................... 3
Viewing the Connection Panel........................................................... 4
Remote Control ................................................................................. 6
Installing Batteries in the Remote Control ......................................... 7
OPERATION
Viewing the menus ............................................................................ 7
Plug & Play Feature........................................................................... 8
CHANNEL CONTROL
Conguring the Channel Menu.......................................................... 8
Managing Channels..........................................................................11
PICTURE CONTROL
Conguring the Picture Menu .......................................................... 13
Viewing Picture-in-Picture................................................................ 16
Using Your TV as a Computer (PC) Display.................................... 16
Setting up the TV with your PC........................................................ 17
SOUND CONTROL
Conguring the Sound Menu........................................................... 18
Selecting the Sound Mode .............................................................. 19
SETUP
Conguring the Setup Menu............................................................ 20
Network Connection and setup ....................................................... 23
INPUT / SUPPORT
Conguring the Input Menu ............................................................. 28
Conguring the Support Menu......................................................... 28
MEDIA PLAY (USB & DLNA)
Connecting a USB Device ............................................................... 30
Media Play Function ........................................................................ 31
Sorting the Photo List ...................................................................... 32
Photo List Option Menu ................................................................... 33
Viewing a Photo or Slide Show........................................................ 34
Slide Show Option Menu ................................................................. 35
Sorting the Music List ...................................................................... 36
Music List Option Menu ................................................................... 36
Playing a Music ............................................................................... 37
Music Play option Menu .................................................................. 38
Sorting the Movie List ...................................................................... 38
Movie List Option Menu................................................................... 39
Playing a Movie File ........................................................................ 40
Movie Play Option Menu ................................................................. 41
Using the Setup Menu ..................................................................... 42
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
MEDIA PLAY-DLNA
Setting the DLNA Network............................................................... 43
Installing the DLNA Application........................................................ 43
Using the DLNA Application............................................................. 44
Using the DLNA Function ................................................................ 47
ANYNET+
Connecting Anynet+Devices........................................................... 48
Setting Up Anynet+.......................................................................... 49
Switching between Anynet+Devices............................................... 49
Recording ........................................................................................ 50
Listening through a Receiver (Home theatre).................................. 50
Troubleshooting for Anynet+............................................................ 51
CONTENT LIBRARY
Using the Content Library................................................................ 52
Using the TV Memory Contents....................................................... 52
Using the Content Management...................................................... 53
INTERNET@TV
Getting Started with Internet@TV.................................................... 54
Setting up Internet@TV ................................................................... 54
Using the Internet@TV service........................................................ 55
RECOMMENDATIONS
Installing the Stand .......................................................................... 56
Disconnecting the Stand.................................................................. 57
Installing the Wall Mount Kit ............................................................ 57
Assembling the Cables.................................................................... 57
Anti-Theft Kensington Lock (depending on model) ......................... 57
Securing the TV to the Wall ............................................................. 58
Troubleshooting: Before Contacting Service Personnel .................. 59
Specications .................................................................................. 60
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
CONTENTS
N O T
Symbol
Note One-Touch
Button TOOL Button
English - 1
BN68-01564E.indb 1 2009-03-12 �� 8:00:06

English - 2
CONNECTING AND PREPARING YOUR TV
Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
Product design and specications may be changed without notice in order to enhance product performance.
Viewing the Control Panel
The product colour and shape may vary depending on the model.
The front panel buttons can be activated by touching them with your nger.
1 REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
2 SOURCE E
Toggles between all the available input sources. In the on-screen menu, use this button as you would use the ENTER E
button on the remote control.
3 MENU
Press to see an on-screen menu of your TV’s features.
4 y
Press to increase or decrease the volume.
In the on-screen menu, use the y buttons as you would use the ◄ and ► buttons on the remote control.
5 z
Press to change channels. In the on-screen menu, use the z buttons as you would use the ▼ and ▲ buttons on the
remote control.
6 POWER INDICATOR
Blinks and turns off when the power is on and lights up in stand-by mode.
7 P(POWER)
Press to turn the TV on and off.
8 SPEAKERS
N
¦
N
N
8 8
8 8
6 54 37 21
654321 7
BN68-01564E.indb 2 2009-03-12 �� 8:00:07
VOL

English - 3
Accessories
Remote Control & Batteries
(AAA x 2) Power Cord Stand Screw (M4 X L16) Cover-Bottom
Programme CD Cleaning Cloth Holder-Wire Cable
(depending on the model)
User Manual ● Warranty card ● Safety Guide ● Registration Cards ●
Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer.
Warranty card / Safety Guide / Registration Cards (Not available in all locations)
The items colour and shape may vary depending on the model.
¦
N
N
N
BN68-01564E.indb 3 2009-03-12 �� 8:00:07

English - 4
Viewing the Connection Panel
The product colour and shape may vary depending on the model.
Whenever you connect an external device to your TV, make sure that power on the unit is turned off.
When connecting an external device, match the colour of the connection terminal to the cable.
1 AV IN 1 [VIDEO] / [R-AUDIO-L]
Connect RCA cable to an appropriate external A/V device such as VCR, DVD or Camcorder.
Connect RCA audio cables to [R-AUDIO-L] on your set and the other ends to corresponding audio out connectors on the
A/V device.
2 HDMI IN 1, HDMI IN 2, HDMI IN 3(DVI), HDMI IN 4
Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players)
No additional Audio connection is needed for an HDMI to HDMI connection.
When using an HDMI / DVI cable connection, you must use the HDMI IN 3(DVI) jack.
What is HDMI?
‘High Denition Multimedia interface’ allows the transmission of high denition digital video data and multiple channels of
digital audio.
The HDMI / DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied).
The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital
Copy Protection) coding feature installed, and supports multi - channel digital audio.
The TV may not output sound and pictures may be displayed with abnormal colour when DVD / Blu-ray player / Cable
Boxes / Satellite receivers supporting HDMI versions older than 1.3 are connected. When connecting an older HDMI
cable and there is no sound, connect the HDMI cable to the HDMI IN 3(DVI) jack and the audio cables to the DVI AUDIO
IN jacks on the back of the TV. If this happens, contact the company that provided the DVD / Blu-ray player / Cable Box /
Satellite receiver to conrm the HDMI version, then request a rmware update. HDMI cables that are not 1.3 may cause
annoying icker or no screen display.
Supported modes for HDMI / DVI and Component.
480i 480p 576i 576p 720p 1080i 1080p
HDMI / DVI 50Hz X X O O O O O
HDMI / DVI 60Hz O O O X O O O
Component O O O O O O O
3 DVI AUDIO IN
DVI audio outputs for external devices.
4 PC IN [PC] / [AUDIO]
Connect to the video and audio output jack on your PC.
5 ANT 1 IN/ ANT 2 IN
Connects to an Air or cable TV system.
There are two kinds of antennas: Air and Cable.
6 LAN
Connect a LAN cable to this port to connect to the Network.
¦
N
N
N
–
–
–
–
–
N
N
N
–
–
–
–
–
7
21 3 2 64
890!@
#
$
$
2
5
(AIR) (CABLE)
ANT 1 IN ANT 2 IN
[TV Side Panel]
[TV Rear Panel]
Power Input
BN68-01564E.indb 4 2009-03-12 �� 8:00:08

English - 5
7 KENSINGTON LOCK (depending on the model)
The Kensington Lock (optional) is a device used to physically x the system when used in a public place.
If you want to use a locking device, contact the dealer where you purchased the TV.
The location of the Kensington Lock may be different depending on its model.
8 H (HEADPHONE)
Headphone may be connected to the headphone output on your set. While the head phone is connected, the sound from
the built-in speakers will be disabled.
Using the sound function is restricted when connecting headphones to the TV.
Prolonged use of headphones at a high volume may damage your hearing.
You will not hear sound from the speakers when you connect headphones to the TV.
The headphone volume and TV volume are adjusted separately.
9 AUDIO OUT [R-AUDIO-L]
Connect RCA audio cables to AUDIO OUT [R-AUDIO-L] on the rear of your set and the other ends to corresponding
audio in connectors on the Amplier or DVD Home Theatre.
0 DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component.
When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL) jack: Decrease the volume of the TV
and adjust the volume level with the system’s volume control.
5.1CH audio is possible when the TV is connected to an external device supporting 5.1CH.
! SERVICE
Connector for service only.
@ COMPONENT IN 1, 2
Connect component video cables (optional) to component connector (PR, PB, Y) on the rear of your set and the other ends
to corresponding component video out connectors on the DVD.
If you wish to connect both the Set-Top Box and DVD, you should connect the Set-Top Box to the DVD and connect the
DVD to component connector (PR, PB, Y) on your set.
The PR, PBand Y connectors on your component devices DVD are sometimes labeled Y, B-Y and R-Y or Y, Cb and Cr.
Connect RCA audio cables (optional) to [R-AUDIO-L] on the rear of your set and the other ends to corresponding audio
out connectors on the DVD.
# AV IN 2 [VIDEO] / [R-AUDIO-L]
Connect RCA cable to an appropriate external A/V device such as VCR, DVD or Camcorder.
Connect RCA audio cables to [R-AUDIO-L] on your set and the other ends to corresponding audio out connectors on the
A/V device.
$ USB1(HDD) / USB2
Connector for software upgrades and Media Play, etc.
You can connect to Samsung’s network wirelessly using the ‘Samsung Wireless LAN Adapter’ (Sold separately).
For USB HDD, use the USB1 (HDD) port.
–
–
–
–
N
N
N
N
–
–
N
N
–
–
–
–
–
–
–
–
–
N
BN68-01564E.indb 5 2009-03-12 �� 8:00:08

English - 6
Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.
The performance of the remote control may be affected by bright light.
The product colour and shape may vary depending on the model.
1 POWER: Turns the TV on and
off.
2 TV: Selects the TV mode directly.
3 NUMERIC BUTTONS: Press to
change the channel.
4 E : Performs the same function
as the ENTER E key of the
directional keys. When switching
channels with the numeric
buttons, and you press the
channel number and then the
ENTER E key, the channel is
immediately switched.
5 Y : Press to increase or
decrease the volume.
6 SOURCE: Press to display
and select the available video
sources.
7 CH LIST: Used to display
Channel Lists on the screen.
8 TOOLS: Use to quickly select
frequently used functions.
9 INTERNET@: Press to use
various internet services to
view useful information and
entertaining content. Internet@
TV may not be available in
certain territories.
0 COLOURS BUTTONS: Use
these buttons in the Channel
list, Internet@TV, Media play
menu, etc.
! TTX/MIX: TEXT function in
MHEG.
@ INFO: Press to display
information on the TV screen.
# Use these buttons in the DMA,
Media Play (USB & DLNA) and
Anynet+. ( ∏ : This remote can
be used to control recording on
Samsung recorders with the
Anynet+ feature)
$ ON/OFF @ : Pressing the
ON/OFF @ light button toggles
between on and off. When the
remote control is on, and a key
is pressed on the remote control,
the remote control buttons will
be lit for a moment. (Using the
remote control with the ON/OFF
@ light button set to On will
reduce the battery usage time.)
% PRE-CH: Enables you to return
to the previous channel you were
watching.
^ MUTE: Press to temporarily cut
off the sound.
& P < / P > : Press to change
channels.
* MENU: Displays the main
on-screen menu
( FAV.CH: Press to switch to your
Favourite channels.
) RETURN: Returns to the
previous menu
a  UP▲/DOWN▼/LEFT◄/
RIGHT►/ENTER E : Use to
select on-screen menu items and
change menu values.
b EXIT: Press to exit the menu.
c CONTENT: This function enables
you to view the Content Library.
(see page 52)
d MEDIA.P: Allows you to play
music les, pictures, and movies.
e SUBT.: Digital subtitle display
f GUIDE: This is used to activate
the EPG icon function in
the MHEG (Multimedia and
Hypermedia Information Coding
Experts Group).
¦
N
N
N
1
2
3
4
5
6
7
8
9
0
!
@
#
$
%
^
&
)
a
b
c
d
e
f
*
(
BN68-01564E.indb 6 2009-03-12 �� 8:00:08

English - 7
Installing Batteries in the Remote Control
1. Lift the cover at the back of the remote control upward as shown in the gure.
2. Install two AAA size batteries.
Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside the
compartment.
3. Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t be using the
remote control for a long time.
If the remote control doesn’t work, check the following:
Is the TV power on?
Are the plus and minus ends of the batteries reversed?
Are the batteries drained?
Is there a power outage or is the power cord unplugged?
Is there a special uorescent light or neon sign nearby?
OPERATION
Viewing the menus
Before using the TV, follow the steps below to learn how to navigate the menu in order to select and adjust different functions.
Operation of the OSD (On Screen Display)
The access steps may differ depending on the selected menu.
1. Press the MENU button.
2. The main menu appears on the screen. The menu’s left side has icons : Picture, Sound,
Channel, Setup, Input, Application, Support.
3. Press the ▲ or ▼ button to select one of the icons.
4. Then press the ENTER E button to access the icon’s sub-menu.
5. Press the ▲ or ▼ button to select the icon’s submenu.
6. Press the ◄ or ► button to decrease or increase the value of a particular item. The
adjustment OSD may differ depending on the selected menu.
7. Press the ENTER E button to complete the conguration. Press the EXIT button to exit.
¦
N
N
N
–
–
–
–
–
¦
❑
MENU Button
Display the main on-screen menu.
ENTER E / DIRECTION Button
Move the cursor and select an
item. Select the currently selected
item. Confirm the setting.
RETURN Button
Return to the previous menu.
EXIT
Exit the on-screen menu.
Mode :Standard ▶
Backlight :7
Contrast :95
Brightness :45
Sharpness :50
Colour :50
Tint(G/R) :G50/R50
AdvancedSettings
Mode :Standard
Backlight :7 ▶
Contrast :95
Brightness :45
Sharpness :50
Colour :50
Tint(G/R) :G50/R50
AdvancedSettings
PictureOptions
7
U Move L Adjust E Enter R Return
▲
Backlight
▼
Help icon
BN68-01564E.indb 7 2009-03-12 �� 8:00:08

English - 8
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and subsequently.
1. Press the POWER button on the remote control. The message Select the OSD
Language.is displayed. Press the ENTER E button. Select the appropriate
language by pressing the ▲ or ▼ button. Press the ENTER E button to conrm
your choice.
2. Press the ◄ or ► button to select Store Demo or Home Use, then press the
ENTER E button.
We recommend setting the TV to Home Use mode for the best picture in
your home environment.
Store Demo mode is only intended for use in retail environments.
If the unit is accidentally set to Store Demo mode and you want to return to Home Use (Standard): Press the Volume
button on the TV. When the volume OSD is displayed, press and hold the MENU button on the TV for 5 seconds.
3. Press the ▲ or ▼ button to select Air,Cable or Auto, then press the ENTER E button.
Air: Air antenna signal.
Cable: Cable antenna signal.
Auto:Air and Cable antenna signals.
4. Press the ▲ or ▼ button to select the channel source to memorize. Press the ENTER E button to select Start.
Digital & Analogue: Digital and Analogue channels.
Digital: Digital channels.
Analogue: Analogue channels.
The channel search will start and end automatically.
Press the ENTER E button at any time to interrupt the memorization process.
After all the available channels are stored, the message Set the Clock Mode. is displayed.
5. Press the ENTER E button. Press the ▲ or ▼ button to select Auto, then Press the ENTER E button.
If you select Manual, Set current date and time is displayed.
If you have received a digital signal, the time will be set automatically. If not, select Manual to set the clock.
6. The description for the connection method providing the best HD screen quality is displayed. Check the description and press
the ENTER E button.
7. Press the ◄ or ► button to select See Product Guide or Watch TV, then the ENTER E button.
See Product Guide: You are moved to the Product Guide where you can view the introduction to the main functions of
your new HDTV.
Watch TV: You can watch the set broadcasting channel.
If you want to reset this feature...
1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTER E button.
2. Press the ENTER E button again to select Plug & Play.
The Plug & Play feature is only available in the TV mode.
●
●
●
●
●
●
●
●
CHANNEL CONTROL
ConguringtheChannelMenu
Antenna
Your TV can memorize both Air and Cable channels.
If the antenna is connected to ANT 1 IN (AIR), select “Air” and if it is connected to ANT 2 IN
(CABLE), select “Cable”.
If both ANT 1 IN (AIR) and ANT 2 IN (CABLE) are connected, select the antenna input you
want.
If the antenna input is not selected properly, noise may appear on the screen.
¦
❑
N
N
N
Plug & Play
Language :
中文
English
Enter
Move
Select the OSD Language.
Antenna  :Air ►
Auto Store
Manual Store
Full Guide
Mini Guide
Default Guide : Full Guide
Guide Type : Guide
Channel List
Channel
BN68-01564E.indb 8 2009-03-12 �� 8:00:09
3.
Enter your 4 digit PIN number. The default PIN number of a new TV set is "0-0-0-0".
NIf you want to change PIN number, use the Change PIN function.
N
N
N
N
N
N
N
N
N

English - 9
Auto Store
You can scan for the frequency ranges available to you (and availability depends on your country).
Automatically allocated programme numbers may not correspond to actual or desired programme numbers.
If a channel is locked using the Child Lock function, the PIN input window appears.
Air/Cable/Auto
Air: “Air” antenna signal.
Cable: “Cable” antenna signal.
Auto: “Air” and “Cable” antenna signals.
If the antenna is connected to ANT 1 IN (AIR), select “Air” and if it isconnected to ANT 2 IN (CABLE), select “Cable”.
If both ANT 1 IN (AIR) and ANT 2 IN (CABLE) are connected, select “Auto”.
Antenna source to memorize
Digital & Analogue / Digital / Analogue
Digital & Analogue: Digital and Analogue channels.
Digital: Digital channels.
Analogue: Analogue channels.
Scans for all channels with active broadcast stations and stores them in the TV’s memory.
If you want to stop Auto Store, press the
ENTER button.
The Stop Auto Store? message will be displayed.
Select Yes by pressing the ◄ or ► button, then press the
ENTER button.
Manual Store
Scans for a channel manually and stores it in the TV’s memory.
If a channel is locked using the Child Lock function, the PIN input window appears.
Digital Channel
Manual store for digital channels.
Channel: Set the Channel number using the ▲, ▼ or number (0~9) buttons.
Frequency: Set the frequency using the number buttons.
Bandwidth: Set the bandwidth using the ▲, ▼ or number (0~9) buttons.
When it has finished, channels are updated in the channel list.
Analogue Channel
Manual store for analogue channel.
Programme (Programme number to be assigned to a channel): Sets the programme number using the ▲, ▼ or number (0~9)
buttons.
Colour System → Auto / PAL / SECAM / NTSC4.43 / NTSC3.58: Sets the colour system value using the ▲ or ▼ button.
Sound System → M / BG / DK / I / L: Sets the sound system value using the ▲ or ▼ button.
Channel (When you know the number of the channel to be stored): Press the ▲ or ▼ button to select C (Air channel) or S
(Cable channel). Press the ► button, then press the ▲, ▼ or number (0~9) buttons to select the required number.
You can also select the channel number directly by pressing the number (0~9) buttons.
If there is abnormal sound or no sound, reselect the sound standard required.
Search (When you do not know the channel numbers): Press the ▲ or ▼ button to start the search. The tuner scans the
frequency range until the first channel or the channel that you selected is received on the screen.
Store (When you store the channel and associated programme number): Set to OK by pressing the ENTER button.
Channel mode”:…
P (Programme mode): When completing tuning, the broadcasting stations in your area have been assigned to position
numbers from P00 to P99. You can select a channel by entering the position number in this mode.
C (Air channel mode): You can select a channel by entering the assigned number to each air broadcasting station in this
mode.
S (Cable channel mode): You can select a channel by entering the assigned number for each cable channel in this mode.
Full Guide / Mini Guide
This function may not be supported depending on your country.
The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme entries may appear blank or out
of date as a result of the information broadcast on a given channel. The display will dynamically update as soon as new information
becomes available.
You can also display the guide menu simply by pressing the GUIDE button. (To configure the Default Guide, refer to the
descriptions.)
Full Guide
Displays the programme information as time ordered One hour segments. Two hours of programme information is displayed which
may be scrolled forwards or backwards in time.
Mini Guide
The information of each programme is displayed by each line on the current channel Mini Guide screen from the current
programme onwards according to the programme starting time order.

●
●
●

●
●
●

●
●
●

●
●
●
●
●
●
–
–
–


BN68-01564E.indb 9 2009-03-12 �� 8:00:09
❑
❑
❑
N
N
N
N
N
N
N
N
N
N
O
E
E
E

English - 10
Default Guide→Full Guide / Mini Guide
This function may not be supported depending on your country.
You can decide whether to display either the Mini Guide or the Full Guide when the GUIDE button on the remote control is
pressed.
GuideType→Guide/Auto
You can decide whether to display either the built-in Guide or the downloaded Guide when the GUIDE button on the remote control
is pressed
Guide:Set the built-in guide to be displayed when the GUIDE button on the remote control is pressed.
Auto:Set the TV to select the proper Guide automatically when the GUIDE button on the remote control is pressed.
Channel List
For the detailed procedures on using the Channel List, refer to the Managing Channels instructions.
You can select these options by simply pressing the CH LIST button on the remote control.
Channel Mode
When press the P </>button, Channels will be switched within the selected channel list.
Fine Tune
If the reception is clear, you do not have to ne tune the channel, as this is done automatically during the search and store
operation. If the signal is weak or distorted, you may have to ne tune the channel manually.
Fine tuned channels that have been saved are marked with an asterisk “*” on the right-hand side of the channel number in the
channel banner.
To reset the ne-tuning, select Reset by pressing the ▲ or ▼ button and then press the ENTER E button.
Only Analogue TV channels can be ne tuned.
LNA(LowNoiseAmplier)
If the TV is operating in a weak-signal area, the LNA function can improve the reception (a low-noise preamplier boosts the
incoming signal).
While viewing an Analogue channel, this function can work.
Using the Full / Mini Guide
Full Guide
DTV Cable 900 f tn Tue, 1 Jun 2:10 am
Freshmen On Campus
2:00 am - 2:30 am
No Detailed Information
Today 2:00 pm - 3:00 pm 3:00 pm - 4:00 pm
Mint Extra
Loaded
Fresh 40 with Dynamite MC
The Distillery
Smash Hits! Sunday
900 f tn
901 ITV Play
902 Kerrang!
903 Kiss
903 oneword
903 Smash Hits!
▼
Street Hypn..
Kisstory
No Information
No Information
No Information
Freshmen O..
Watch
Information

■

Mini Guide
■ +24 Hours■ Exit
Mini Guide DTV Cable 900 f tn
Street Hypnosis
Booze Britain
2:00 am
2:30 am
5:00 am
▼
Freshmen On Campus
Watch
Information

■Full Guide

■Next Page
■ Exit
To... Then...
Watch a programme in the EPG list Select a programme by pressing the ▲, ▼, ◄, ► button.
Exit the guide Press the blue button
If the next programme is selected, it is scheduled with the clock icon displayed. If the ENTER E button is pressed again, press
the ◄, ► button to select Cancel Schedules, the scheduling is canceled with the clock icon gone.
View programme information Select a programme of your choice by pressing the ▲, ▼, ◄, ► button.
Then press the INFO button when the programme of your choice is
highlighted.
The programme title is on the upper part of the screen center.
Please click on INFO button for the detailed information. Channel Number, Running Time, Status Bar, Parental Level, Video
Quality Information (HD / SD), Sound Modes, Subtitle, languages of Subtitle and brief summary of the highlighted programme are
included on the detailed information. “▼” will appears if the summary is long.
Toggle between the Mini Guide or Full Guide Press the red button repeatedly.
In Full Guide
Scrolls backwards quickly (24 hours).
Scrolls forwards quickly (24 hours).
Press the green button repeatedly.
Press the yellow button repeatedly.
In Mini Guide
Display previous page quickly.
Display next page quickly.
Press the green button.
Press the yellow button.
❑
N
❑
N
N
❑
O
❑
❑
N
N
N
❑
N
BN68-01564E.indb 10 2009-03-12 �� 8:00:09
Page
Page

English - 11
Managing Channels
Using this menu, you can add / delete or set favourite channels and so on.
All Channels
Shows all currently available channels.
Added Channels
Shows all added channels.
Favourites
Shows all favourite channels.
To select the favourites channels you have set up, press the FAV.CH button on the remote control.
Programmed
Shows all current reserved programmes.
Select a channel in the All Channels, Added Channels or Favourites screen by pressing the ▲ / ▼ buttons, and pressing
the ENTER E button. Then you can watch the selected channel.
Using the Colour buttons with the Channel List
Red (Antenna): Toggle between your “Air” and “Cable” Antenna.
Green (Zoom): Enlarges or shrinks a channel number.
Yellow (Select): Selects multiple channel lists. You can perform the Add / Delete, Add to Favourite / Delete from
Favourite or Lock / Unlock function for multiple channels at the same time. Select the required channels by pressing the
yellow button, and then press the TOOLS button to set all the selected channels at the same time.
TOOLS (Tools): Displays the Delete (or Add), Add to Favourite (or Delete from Favourite), Lock (or Unlock), Timer
Viewing, Edit Channel Name, Edit Channel Number, Sort, Select All, Deselect All or Auto Store menu. (The Options
menus may differ depending on the situation.)
Channel Status Display Icons
A
An Analogue channel.
c
A channel selected by pressing the yellow button.
*
A channel set as a Favourite.
(
A programme currently being broadcast.
\
A locked channel.
)
A reserved programme
Channel List Option Menu (in All Channels / Added Channels / Favourites)
Press the TOOLS button to use the option menu.
Option menu items may differ depending on the channel status.
Add / Delete
You can delete or add a channel to display the channels you want.
All deleted channels will be shown on All Channels menu.
A gray-coloured channel indicates the channel has been deleted.
The Add menu only appears for deleted channels.
You can also delete a channel to the Added Channels or Favourites menu in the same
manner.
Add to Favourite / Delete from Favourite
You can set channels you watch frequently as favourites.
The ♥ symbol will be displayed and the channel will be set as a favourite.
All favourite channels will be shown on Favourite menu.
Press the TOOLS button to display the Tools menu. You can also set the Add to Favourite by selecting Tools → Add to
Favourite.
Lock / Unlock
You can lock a channel so that the channel cannot be selected and viewed. This function is available only when the Child Lock is
set to On. (see page 21)
The PIN number input screen appears. Enter your 4 digit PIN number.
The default PIN number of a new TV set is 0-0-0-0. You can change the PIN, by selecting Change PIN from the menu.
The \ symbol will be displayed and the channel will be locked.
¦



O

N
N
–
–
–
–
N
N
N

N
N
N
N

N
N
T

N
N
N
A
2 C71
A
3 C6
A 4 C76
A
5 C77
A
6 S12
A
7 C21
A
8 C23
A
9 C27
A
10 C34
A
11 C38
Added Channels
Air Antenna Zoom Select Page T Tools
A
2 C71
A
3 C6
A 4 C76
A
5 C77
A
6 S12
A
7 C21
A
8 C23
A
9 C27
A
10 C34
A
11 C38
All Channels
Air Antenna Zoom Select Page T Tools
Delete
Add to Favourite
Lock
Timer Viewing
Edit Channel Name
Sort
▼
BN68-01564E.indb 11 2009-03-12 �� 8:00:09

English - 12
Timer Viewing
If you reserve a programme you want to watch, the channel is automatically switched to the reserved channel in the Channel List;
even when you are watching another channel. To reserve a programme, set the current time rst. (See page 20.)
Only memorized channels can be reserved.
You can set the channel, day, month, year, hour and minute directly by pressing the number buttons on the remote control.
Reserved programmes will be shown on Programmed menu.
Digital Programme Guide and Viewing Reservation
When a digital channel is selected, and you press the ► button, the Programme Guide for the channel appears. You can
reserve a programme according to the procedures described above.
Edit Channel Name (analogue channels only)
Channels can labeled so that their call letters appear whenever the channel is selected.
The names of digital broadcasting channels are automatically assigned and cannot be renamed.
Edit Channel Number (digital channels only)
You can also edit the channel number by pressing the number buttons on the remote control.
Sort (analogue channels only)
This operation allows you to change the programme numbers of the stored channels. This operation may be necessary after using
the auto store.
Select All / Deselect All
Select All: You can select all the channels in the channel list.
Deselect All: You can deselect all the selected channels by pressing the TOOLS button.
You can perform the add / delete, add to Favourite / delete from Favourite, or lock / unlock function for multiple channels at
the same time. Select the required channels by pressing the yellow button , and then press the TOOLS button to set all the
selected channels at the same time.
The c mark appears to the left of the selected channels.
You can select Deselect All only when there is at least a selected channel.
Auto Store
For further details on setting up options, refer to page 9.
If a channel is locked using the Child Lock function, the PIN input window appears.
Channel List Option Menu (in Programmed)
You can view, modify or delete a reservation.
Press the TOOLS button to use the option menu.
Change Info
Select to change a viewing reservation.
Cancel Schedules
Select to cancel a viewing reservation.
Information
Select to view a viewing reservation. (You can also change the reservation information.)
Select All
Select all reserved programmes.

N
N
N
N

N

N


●
●
●
N
N

N
N
N




1 / 1 / 2009
01:59 pm 5 )
2 / 1 / 2009
06:59 pm 2 ) The Equalizer
08:59 pm 2 ) McMillan & Wife
07:59 am 2 ) M.Spillane’s mike
Programmed
Air Zoom Select T Tools E Information
Change Info
Cancel Schedules
Information
Select All
BN68-01564E.indb 12 2009-03-12 �� 8:00:09

English - 13
PICTURE CONTROL
ConguringthePictureMenu
Mode
You can select the type of picture which best corresponds to your viewing requirements.
Dynamic
Selects the picture for increased denition in a bright room.
Standard
Selects the picture for the optimum display in a normal environment.
Natural
Selects the picture for optimum and eye-comfortable display.
Movie
Selects the picture for viewing movies in a dark room.
Backlight / Contrast / Brightness / Sharpness / Colour / Tint(G/R)
Your television has several setting options that allow you to control the picture quality.
Backlight: Adjusts the brightness of LCD back light.
Contrast: Adjusts the contrast level of the picture.
Brightness: Adjusts the brightness level of the picture
Sharpness: Adjusts the edge denition of the picture.
Colour: Adjusts colour saturation of the picture.
Tint(G/R): Adjusts the colour tint of the picture.
Select a picture mode to be adjusted rst. The adjusted values are saved for each picture mode.
When you make changes to Backlight, Contrast, Brightness, Sharpness, Colour or Tint(G/R), the OSD will be adjusted
accordingly.
In analogue TV, AV1, AV2 modes of the PAL system, you cannot use the Tint(G/R) Function.
In PC mode, you can only make changes to Backlight, Contrast and Brightness.
Settings can be adjusted and stored for each external device you have connected to an input of the TV.
The energy consumed during use can be signicantly reduced if the brightness level of the picture is lowered, which will
reduce the overall running cost.
Advanced Settings
Samsung’s new TVs allow you to make even more precise picture settings than previous
models.
Advanced Settings is available in Standard or Movie mode.
In PC mode, you can only make changes to Dynamic Contrast, Gamma and White
Balance from among the Advanced Settings items.
BlackTone→Off/Dark/Darker/Darkest
You can select the black level on the screen to adjust the screen depth.
DynamicContrast→Off/Low/Medium/High
You can adjust the screen contrast so that the optimal contrast is provided.
Gamma
You can adjust the Primary Colour (Red, Green, Blue) Intensity.
Colour Space
Colour Space is a colour matrix composed of red, green and blue colours. Select your favourite Colour Space to experience the
most natural colour.
Auto: Auto Colour Space automatically adjusts to the most natural colour tone based on programme sources.
Native: Native Colour Space offers deep and rich colour tone.
Custom: Adjusts the colour range to suit your preference.
Customizing the Colour Space
Colour→Red/Green/Blue/Yellow/Cyan/Magenta
Adjusts the Colour range to suit your preference. Colour is available when Colour Space is set to Custom.
Red / Green / Blue: In Colour, you can adjust the RGB values for the selected colour.
Reset: Resets the colour space to the default values.
¦
❑




❑
●
●
●
●
●
●
N
N
N
N
N
N
❑
N
N




●
●
●
N
–
–
–
–
Mode  :Standard  ►
Backlight : 7
Contrast : 95
Brightness : 45
Sharpness : 50
Colour : 50
Tint (G/R) : G50/R50
Advanced Settings
Colour : 50
Tint (G/R) : G50/R50
AdvancedSettings  ►
Picture Options
Picture Reset
BN68-01564E.indb 13 2009-03-12 �� 8:00:10

English - 14
White Balance
You can adjust the colour temperature for more natural picture colours.
R-Offset / G-Offset / B-Offset / R-Gain / G-Gain / B-Gain: Changing the adjustment value will refresh the adjusted screen.
Reset: The previously adjusted white balance will be reset to the factory defaults.
Flesh Tone
You can emphasize the pink ‘esh tone’ in the picture.
Changing the adjustment value will refresh the adjusted screen.
EdgeEnhancement→Off/On
You can emphasize object boundaries in the picture.
xvYCC→Off/On
Setting the xvYCC mode to on increases detail and colour space when watching movies from an external device (ie. DVD player)
connected to the HDMI (YCbCr 4:4:4 and YCbCr 4:2:2) or Component IN jacks.
xvYCC is available when the picture mode is set to Movie, and the external input is set to HDMI or Component mode.
Picture Options
In PC mode, you can only make changes to the Colour Tone and Size from among the items in Picture Options.
ColourTone→Cool/Normal/Warm1/Warm2/Warm3
You can select the most comfortable colour tone to your eyes.
Settings can be adjusted and stored for each external device you have connected to an input of the TV.
Warm1, Warm2 or Warm3 is only activated when the picture mode is Movie.
Size
You can select the picture size which best corresponds to your viewing requirements.
Press the TOOLS button to display the Tools menu. You can also set the size by selecting Tools → Picture Size.
Auto Wide: Automatically adjusts the picture size to the 16:9 aspect ratio.
This function may not be supported depending on your country.
16:9: Adjusts the picture size to 16:9 appropriate for DVDs or wide broadcasting.
Wide Zoom: Magnify the size of the picture more than 4:3.
Zoom: Magnies the 16:9 wide picture (in the vertical direction) to t the screen size.
4:3: This is the default setting for a video movie or normal broadcasting.
Screen Fit: Use the function to see the full image without any cutoff when HDMI (720p / 1080i / 1080p) or Component (1080i
/ 1080p) signals are input.
Depending on the input source, the picture size options may vary.
The items available may differ depending on the selected mode.
In PC Mode, only 16:9 and 4:3 mode can be adjusted.
Settings can be adjusted and stored for each external device you have connected to an input of the TV.
Temporary image retention may occur when viewing a static image on the set for more than two hours.
Wide Zoom: Press the ► button to Select Position, then press the ENTER E button. Press the ▲ or ▼ button to move the
screen up / down. Then press the ENTER E button.
Zoom: Press the ► button to Select Position, then press the ENTER E button. Press the ▲ or ▼ button to move the picture
up and down. Then press the ENTER E button. Press the ► button to Select Size, then press the ENTER E button. Press
ENTER E button.
After selecting Screen Fit in HDMI (1080i / 1080p) or Component (1080i / 1080p) mode: Select Position by pressing the ◄ or
► button. Use the ▲, ▼, ◄ or ► button to move the picture.
Reset: Press the ◄ or ► button to select Reset, then press the ENTER E button. You can initialize the setting.
If you use the Screen Fit function with HDMI 720p input, 1 line will be cut at the top, bottom, left and right as in the overscan
function.
ScreenMode→16:9/WideZoom/Zoom/4:3
This function may not be supported depending on your country.
When setting the picture size to Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS
(Wide Screen Service) image or nothing.
16:9: Sets the picture to 16:9 wide mode.
Wide Zoom: Magnify the size of the picture more than 4:3.
Zoom: Magnify the size of the picture vertically on screen.
4:3: Sets the picture to 4:3 normal mode.
This function is available in Auto Wide mode.
This function is not available in PC, Component or HDMI mode.

●
●





●
●
●
●
●
●

●
●
●
●
BN68-01564E.indb 14 2009-03-12 �� 8:00:10
N
N
N
N
N
N
N
N
N
N
N
N
N
the ▲ or ▼ button to magnify or reduce the picture size in the vertical direction. Then press the
N
N
N
N
N
❑

English - 15
DigitalNR→Off/Low/Medium/High/Auto
If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static
and ghosting that may appear on the screen.
When the signal is weak, select one of the other options until the best picture is displayed.
HDMIBlackLevel→Normal/Low
You can directly select the black level on the screen to adjust the screen depth.
This function is active only when the external input connects to HDMI (RGB signals).
FilmMode→Off/Auto1/Auto2
The TV can be set to automatically sense and process lm signals from all sources and adjust the picture for optimum quality.
Film Mode is supported in TV, AV, COMPONENT(480i / 1080i) and HDMI(480i / 1080i).
100HzMotionPlus→Off/Clear/Standard/Smooth/Custom/Demo
Removes drag from fast scenes with a lot of movement to provide a clearer picture.
This function is not available in PC mode.
If you enable 100Hz Motion Plus, noise may appear on the screen. If this occurs, set 100Hz Motion Plus to off or select one
of the other options.
Off: Switches 100Hz Motion Plus off.
Clear: Sets 100Hz Motion Plus to clear. Provides a clear picture for fast moving scenes.
Standard: Sets 100Hz Motion Plus to standard.
Smooth: Sets 100Hz Motion Plus to smooth. Provides a smooth picture for fast moving scenes.
Custom: Adjusts the blur and judder reduction level to suit your preference.
Blur Reduction: Adjusts the blur reduction level in video sources.
Judder Reduction: Adjusts the judder reduction level in video sources with lm signals.
Reset: Reset the custom settings.
Demo: Displays the difference between 100Hz Motion Plus on and off modes.
BlueOnlyMode→Off/On
This function is for AV device measurement experts. This function displays the blue signal only by removing the red and green
signals from the video signal so as to provide a Blue Filter effect that is used to adjust the Colour and Tint of video equipment such
as DVD players, Home Theatres, etc. Using this function, you can adjust the Colour and Tint to preferred values appropriate to
the signal level of each video device using the Red / Green / Blue / Cyan / Magenta / Yellow Colour Bar Patterns, without using an
additional Blue Filter.
Blue Only Mode is available when the picture mode is set to Movie or Standard.
PictureReset→ResetPictureMode/Cancel
Resets all picture settings to the default values.
Reset Picture Mode: Current picture values return to default settings.

N

N

N

N
●
●
●
●
●
–
–
–
●

N
❑
N
BN68-01564E.indb 15 2009-03-12 �� 8:00:10

English - 16
Viewing Picture-in-Picture
You can display a sub picture within the main picture of set programme or video input. In this
way, you can watch the picture of set programme or video input from any connected equipment
while watching the main picture.
Press the TOOLS button to display the Tools menu. You can also congure PIP related
settings by selecting Tools→PIP.
You may notice that the picture in the PIP window becomes slightly unnatural when you
use the main screen to view a game or karaoke.
PIP
Main picture Sub picture
Component 1, 2
HDMI 1, HDMI2, HDMI3/DVI, HDMI 4
PC
TV
PIP→Off/On
You can activate or deactivate the PIP function.
Size→ Õ / à / À / Œ
You can select a size of the sub-picture.
Position→ – / à / œ / —
You can select a position of the sub-picture.
In Double ( Œ , À ) mode, Position cannot be selected.
Air/ Cable
Selects either Air or Cable as the input source for the sub-screen.
Channel
You can select the channel for the sub-screen.
SoundSelect→Main/Sub
You can listen to the sound of the sub (PIP) picture.
Press the TOOLS button to display the Tools menu. You can also set the sound of the sub picture by selecting Tools→PIP→
Sound Select.
Main: Used to listen to the sound of the main picture.
Sub: Used to listen to the sound of the sub picture.
Using Your TV as a Computer (PC) Display
Setting Up Your PC Software (Based on Windows XP)
The Windows display-settings for a typical computer are shown below. The actual screens on your PC will probably be different,
depending upon your particular version of Windows and your particular video card. However, even if your actual screens look
different, the same basic set-up information will apply in almost all cases. (If not, contact
your computer manufacturer or Samsung Dealer.)
1. First, click on ‘Control Panel’ on the Windows start menu.
2. When the control panel window appears, click on ‘Display’ and a display dialogbox will
appear.
3. Navigate to the ‘Settings’ tab on the display dialog-box.
The correct size setting (resolution): Optimum-1920 X 1080 pixels
If a vertical-frequency option exists on your display settings dialog box, the correct
value is ‘60’ or ‘60 Hz’. Otherwise, just click ‘OK’ and exit the dialog box.
¦
T
N
❑



N



●
●
¦
●
●
Melody : Medium
Energy Saving : Off
PIP     ►
Setup
PIP
PIP : On ►
Size : Õ
Position : Ã
Air/Cable : Air
Channel : Air 6
U Move E Enter R Return
BN68-01564E.indb 16 2009-03-12 �� 8:00:10

English - 17
Display Modes
Both screen position and size will vary depending on the type of PC monitor and its resolution. The resolutions in the table are
recommended.
D-Sub and HDMI/DVI Input
Mode Resolution Horizontal Frequency
(KHz)
Vertical Frequency
(Hz)
Pixel Clock Frequency
(MHz)
Sync Polarity
(H / V)
IBM 640 x 350 31.469 70.086 25.175 +/-
720 x 400 31.469 70.087 28.322 -/+
MAC 640 x 480 35.000 66.667 30.240 -/-
832 x 624 49.726 74.551 57.284 -/-
1152 x 870 68.681 75.062 100.000 -/-
VESA CVT
720 x 576 35.910 59.950 32.750 -/+
1152 x 864 53.783 59.959 81.750 -/+
1280 x 720 44.772 59.855 74.500 -/+
1280 x 960 75.231 74.857 130.000 -/+
1280 x 720 56.456 74.777 95.750 -/+
VESA DMT
640 x 480 31.469 59.940 25.175 -/-
640 x 480 37.861 72.809 31.500 -/-
640 x 480 37.500 75.000 31.500 -/-
800 x 600 37.879 60.317 40.000 +/+
800 x 600 48.077 72.188 50.000 +/+
800 x 600 46.875 75.000 49.500 +/+
1024 x 768 48.363 60.004 65.000 -/-
1024 x 768 56.476 70.069 75.000 -/-
1024 x 768 60.023 75.029 78.750 +/+
1152 x 864 67.500 75.000 108.000 +/+
1280 x 1024 63.981 60.020 108.000 +/+
1280 x 1024 79.976 75.025 135.000 +/+
1280 x 800 49.702 59.810 83.500 -/+
1280 x 800 62.795 74.934 106.500 -/+
1280 x 960 60.000 60.000 108.000 +/+
1360 x 768 47.712 60.015 85.500 +/+
1440 x 900 55.935 59.887 106.500 -/+
1440 x 900 70.635 74.984 136.750 -/+
1680 x 1050 65.290 59.954 146.250 -/+
VESA GTF 1280 x 720 52.500 70.000 89.040 -/+
1280 x 1024 74.620 70.000 128.943 -/-
1920 x 1080p 67.500 60.000 148.500 +/+
When using an HDMI / DVI cable connection, you must use the HDMI IN 3(DVI) jack.
The interlace mode is not supported.
The set might operate abnormally if a non-standard video format is selected.
Separate and Composite modes are supported. SOG is not supported.
Too long or low quality VGA cable can cause picture noise at high resolution modes (1920x1080 or 1600x1200).
Setting up the TV with your PC
Preset: Press the SOURCE button to select PC mode.
Auto Adjustment
Auto Adjustment allows the PC screen of set to self-adjust to the incoming PC video signal.
The values of ne, coarse and position are adjusted automatically.
Press the TOOLS button to display the Tools menu. You can also set the Auto Adjustment
by selecting Tools→AutoAdjustment.
This function does not work in DVI-HDMI mode.
Screen
Coarse / Fine
The purpose of picture quality adjustment is to remove or reduce picture noise. If the noise is not removed by Fine-tuning alone,
then adjust the frequency as best as possible (Coarse) and Fine-tune again. After the noise has been reduced, readjust the picture
so that it is aligned on the center of screen.
PC Position
Adjust the PC’s screen positioning if it does not t the TV screen. Press the ▲ or ▼ button to adjusting the Vertical-Position. Press
the ◄ or ► button to adjust the Horizontal-Position.
Image Reset
You can replace all image settings with the factory default values.

N
N
N
N
N
¦
N
❑
T
N
❑



Brightness : 45
Sharpness : 50
AutoAdjustment   ►
Screen
Advanced Settings
Picture Options
Picture Reset
BN68-01564E.indb 17 2009-03-12 �� 8:00:10

English - 18
SOUND CONTROL
ConguringtheSoundMenu
Mode→Standard/Music/Movie/ClearVoice/Custom
You can select a sound mode to suit your personal preferences.
Press the TOOLS button to display the Tools menu. You can also congure the sound
mode by selecting Tools→SoundMode.
Equalizer
The sound settings can be adjusted to suit your personal preferences.
Mode
You can select a sound mode to suit your personal preferences.
Balance
Controls the balance between the right and left speakers.
100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth Adjustment)
To adjust the level of different bandwidth frequencies
Reset
Resets the equalizer settings to the default values.
SRSTruSurroundHD→Off/On
SRS TruSurround HD is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two
speakers. TruSurround delivers a compelling, virtual surround sound experience through any two-speaker playback system,
including internal television speakers. It is fully compatible with all multichannel formats.
Press the TOOLS button to display the Tools menu. You can also set the SRS TruSurround HD by selecting Tools→SRSTS
HD.
Audio Language (digital channels only)
You can change the default value for audio languages. Displays the language information for the incoming stream.
While viewing a digital channel, this function can be selected.
You can only select the language among the actual languages being broadcast.
AudioFormat→MPEG/DolbyDigital/Advanced(digitalchannelsonly)
When sound is emitted from both the main speaker and the audio receiver, a sound echo may occur due to the decoding speed
difference between the main speaker and the audio receiver. In this case, use the TV Speaker function.
While viewing a digital channel, this function can be selected.
The Audio Format appears according to the broadcasting signal.
AutoVolume→Off/On
Each broadcasting station has its own signal conditions, and so it is not easy to adjust the volume every time the channel is
changed. This feature lets you automatically adjust the volume of the desired channel by lowering the sound output when the
modulation signal is high or by raising the sound output when the modulation signal is low.
¦
❑
T
❑




❑
T
❑
N
N
❑
N
N
❑
Mode   :Custom ►
Equalizer
SRS TruSurround HD : Off
Audio Language : ----
Audio Format : ----
Auto Volume : Off
Speaker Select : TV Speaker
Sound Select Main
Sound
BN68-01564E.indb 18 2009-03-12 �� 8:00:10
