Samsung LN26B360C5D User manual

LCD-TV
Chassis : N64C
Model : LN26B360C5D
LN32B360C5D
SERVICEManual
TFT-LCD TV Contents
LN32B360C5D
Refer to the service manual in the GSPN (see the rear cover) for the more information.
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. Wiring Diagram

Contents
1. Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-2. Servicing Precautions..................................................................................................... 1-2
1-3. Electrostatically Sensitive Devices (ESD) Precautions .................................................. 1-2
1-4. Installation Precautions .................................................................................................. 1-3
2. Product specications............................................................................................ 2-1
2-1. Feature & Specications................................................................................................. 2-1
2-2. Specication Comparison to Old Models........................................................................ 2-5
2-3. Accessories .................................................................................................................... 2-6
3. Disassembly and Reassembly ............................................................................... 3-1
3-1. Disassembly and Reassembly ....................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting .............................................................................................................. 4-1
4-2. Alignments and Adjustments ........................................................................................ 4-25
4-3. Factory Mode Adjustments ........................................................................................... 4-26
4-4. White Balance - Calibration .......................................................................................... 4-37
4-5. White Ratio (Balance) Adjustment................................................................................ 4-39
4-6. Servicing Information.................................................................................................... 4-40
5. Exploded View & Part List ...................................................................................... 5-1
5-1. LN26B360C5D Exploded View....................................................................................... 5-1
5-2. LN32B360C5D Exploded View....................................................................................... 5-3
5-3. LN26B360C5D Parts List ............................................................................................... 5-5
5-4. LN32B360C5D Parts List ............................................................................................. 5-20
6. Wiring Diagram........................................................................................................ 6-1
6-1. Wiring Diagram............................................................................................................... 6-1
6-2. Connector Functions ...................................................................................................... 6-4
6-3. Cables ............................................................................................................................ 6-4

GSPN (Global Service Partner Network)
Area Web Site
North America http://service.samsungportal.com
Latin America http://latin.samsungportal.com
CIS http://cis.samsungportal.com
Europe http://europe.samsungportal.com
China http://china.samsungportal.com
Asia http://asia.samsungportal.com
Mideast & Africa http://mea.samsungportal.com
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2009 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea
P/N: BN82-00552A-00

3-1
3. Disassembly and Reassembly
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LCD TV.
WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
Cautions: 1. Disconnect the LCD TV from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
Description Picture Description Screws
1. Place monitor face down on cushioned table.
Remove 4 screws from the stand.
Remove stand.
2. Remove the 11 screws of rear-cover.
Remove the 3 screws of rear-cover.
32”

3-2
3. Disassembly and Reassembly
Description Picture Description Screws
3. Lift up the rear-cover.
4. Remove the left and right speaker.
5. Remove the 4 screws of main board and
5 screws of IP board.
6. Remove the 8 screws of bottom
bracket stand link.

3-3
3. Disassembly and Reassembly
Description Picture Description Screws
7. Lift up the bottom and bracket stand link.
8. Lift up the panel.
Reassembly procedures are in the reverse order of disassembly procedures.※

5-1
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LN26B360C5D Exploded View
T0003 T0175
M0215
M0146M0146
M0115
M0174
M0014
M0013
M0027
T0531
M0254

5-2
5. Exploded View & Part List
5-1-1. LN26B360C5D Parts List
Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark
T0003 BN96-10017A ASSY COVER P-FRONT;LB450 26,PC+ABS,V0,BK 1 S.A
M0215 BN07-00638A LCD-PANEL;T260XW02 VS 1 S.A
T0175 BN96-06822H ASSY SPEAKER P;16ohm,4pin,5W,R:150 / L:3 1 S.A
M0115 BN61-04772A BRACKET-STAND LINK;B450 26inch,SECC 1 S.N.A
M0254 BN61-05013A HOLDER-SIDE AV;PS,V0,BK500,DUMMY 1 S.N.A
M0146 BN61-05177A BRACKET-PANEL SIDE;26inch,SECC,T1.2 2 S.N.A
M0146 BN61-05176A BRACKET-PANEL TOP;26inch,SECC,T1.2 2 S.N.A
M0174 BN44-00259A IP BOARD-IP;PSIV840C01A,H26HD_9SS,0.12mA 1 S.A
M0014 BN94-02679D ASSY PCB MAIN;LN32B360C5DXZA 1 S.A
M0013 BN96-10024A ASSY COVER P-REAR;LB450 26,UO,HIPS,V0,BK 1 S.A
M0027 BN96-06463F ASSY STAND P-BASE;22,26L450,ABS+PMMA,HB, 1 S.A

5-3
5. Exploded View & Part List
5-2. LN32B360C5D Exploded View
T0003
T0175
M0215
M0146
M0174
M0014
T0531
M0115
M0254
M0013
M0027

5-4
5. Exploded View & Part List
5-2-1. LN32B360C5D Parts List
Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark
T0003 BN96-10019A ASSY COVER P-FRONT;LB450 32,PC+ABS,V0,BK 1 S.A
M0215 BN07-00657A LCD-PANEL;V315B5-L01 1 S.A
T0175 BN96-09463A ASSY SPEAKER P;8ohm,4pin,10W,R:200 / L:4 1 S.A
M0115 BN61-04820A BRACKET-STAND LINK;B650-32,SECC,T1.2 1 S.N.A
M0254 BN61-05013A HOLDER-SIDE AV;PS,V0,BK500,DUMMY 1 S.N.A
M0146 BN61-04980A BRACKET-PANEL TOP;B550-3 32,SECC,T1.2 2 S.N.A
M0174 BN44-00260B IP BOARD;K02P133.00,H32HD_9AP,0.12mA,12. 1 S.A
M0014 BN94-02679D ASSY PCB MAIN;LN32B360C5DXZA 1 S.A
M0013 BN96-10026A ASSY COVER P-REAR;LB450 32,UO,HIPS,V0,BK 1 S.A
M0027 BN96-06464A ASSY STAND P-BASE;32L450,,ABS+PMMA,HB,BK 1 S.A

5-5
5. Exploded View & Part List
5-3. LN32B350F1D Exploded View
T0003
T0175
M0215
M0146
M0174
M0014
M0115
M0013
M0027
T0920
M0107

5-6
5. Exploded View & Part List
5-3-1. LN32B350F1D Parts List
Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark
T0003 BN96-10890A ASSY COVER P-FRONT;32,LB350,UO,PC,15%,V0 1 S.A
M0215 BN07-00639A LCD-PANEL;T315XW02 VV 1 S.A
T0175 BN96-04769C ASSY SPEAKER P;16ohm,4pin,5W,L350 26, 32 1 S.A
M0115 BN61-04820A BRACKET-STAND LINK;B650-32,SECC,T1.2 1 S.N.A
M0146 BN61-04409A BRACKET-PANEL SIDE;L450 26INCH,SECC,T1.2 2 S.N.A
M0174 BN44-00289B IP BOARD;PSIV121C01B,HV32HD_9SS,3mA,11.5 1 S.A
M0107 BN61-05314A BRACKET-PCB;LB650 32,SECC,T1.2 2 S.N.A
T0920 BN61-05320A GUIDE-STAND;LB650 32,ABS V0,BK500 1 S.A
M0014 BN96-11781A ASSY PCB P-MAIN;BN94-02887B,LN32B350F1DX 1 S.A
M0013 BN96-10915A ASSY COVER P-REAR;32,LB350,UO,HIPS,V0,(N 1 S.A
M0027 BN96-10911A ASSY STAND P-BASE;32,LB350,PMMA+ABS,HB,B 1 S.A

5-7
5. Exploded View & Part List
5-4. LN26B360C5D Parts List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
LN26B360C5DXZA LN26B360C5D,N64C/26AC5-G3F,26,LCD-TV,UNI
0.1 M0216 BN90-01510A ASSY STAND;22L450,UO,,, 1 S.N.A
..2 M0027 BN96-06463F ASSY STAND P-BASE;22,26L450,ABS+PMMA,HB, 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
...3 B/SBOTTOM BN61-02954A BRACKET-STAND BOTTOM;23,26 BORDEAUX PLUS 1 S.N.A
...3 T0920 BN61-03680C GUIDE-STAND;22,26L450,ABS,V0(NT),BLK 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
...3 T0004 BN63-03122A COVER-STAND BASE;23,26R81,ABS+PMMA,-,-,- 1 S.N.A
...3 M0126 BN73-00052C RUBBER-FOOT;LCD TV,CR RUBBER,T2.0 DIA19, 4 S.N.A
...3 ADH BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.001 S.N.A
0.1 M0001 BN90-02022A ASSY COVER FRONT;LB450 26 1 S.N.A
..2 T0175 BN96-06822H ASSY SPEAKER P;16ohm,4pin,5W,R:150 / L:3 1 S.A
..2 T0003 BN96-10017A ASSY COVER P-FRONT;LB450 26,PC+ABS,V0,BK 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 AA60-00091K SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.35, 1 S.N.A
...3 M0279 AA63-01637A FELT;50P9,FELT,0.5,10,80 1 S.N.A
...3 T0069 BN60-00048A SPACER-FELT;50Q9,FELT,620L,BLK,0.35T,10W 2 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.559 S.N.A
...3 M0112 BN63-04168Q COVER-FRONT;LB450 26,UO,PC+ABS,V0,BK25,S 1 S.N.A
...3 T0059 BN64-00379A INDICATOR LED;ROME-II,23,PC,CLEAR 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,VIOLET,DIFFUSER( 1 S.N.A
...3 T0022 BN64-00755A KNOB-CONTROL;32L450,ABS,V0,BK07 1 S.N.A
...3 BN64-00987A DECORATION-BOTTOM;26,LB450,PC CLEAR 1 S.N.A
...3 M0145 BN96-07269A ASSY BOARD P-FUNCTION;LN40A450C1D,CT5000 1 S.A
...3 BN96-09686A ASSY HOLDER P-SIDE,L;LB450 26,HIPS,V0,BK 1 S.N.A
....4 BN61-03261B BOSS-TAPE;Tulip,ACRYL,T1.1,W20mm,GRAY,TA 0.8 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.001 S.N.A
....4 BN61-04969A HOLDER-BOSS BOTTOM;26,LB450,PS,V0, BK500 1 S.N.A
...3 T0714 BN96-10362A ASSY BOARD P-IR;LE26B530,1299-01201-00,8 1 S.A
...3 ADH BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.001 S.N.A
0.1 M0002 BN90-02030A ASSY COVER REAR;LB450 26,UO 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 9 S.N.A
..2 M0013 BN96-10024A ASSY COVER P-REAR;LB450 26,UO,HIPS,V0,BK 1 S.A
...3 T0101 BN61-04929A BRACKET-WALL;26B450,SECC,T1.2 4 S.N.A
...3 M0006 BN63-05241A COVER-REAR;26,LB450(UO),PS, V0,BK500 1 S.N.A
...3 T0071 BN64-01047A INLAY-TERMINAL;B350,PS SHEET,T0.5,NT 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
0.1 M0112 BN91-03767A ASSY SHIELD;LN26B360C5DXZA 1 S.N.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 4 S.N.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.N.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 6 S.N.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 4 S.N.A

5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M2893 BN39-01099A LEAD CONNECTOR;Amber,UL1007#26,UL/CSA,30 1 S.A
..2 M0174 BN44-00259A IP BOARD-IP;PSIV840C01A,H26HD_9SS,0.12mA 1 S.A
..2 M0115 BN61-04772A BRACKET-STAND LINK;B450 26inch,SECC 1 S.N.A
..2 M0254 BN61-05013A HOLDER-SIDE AV;PS,V0,BK500,DUMMY 1 S.N.A
..2 M0146 BN61-05176A BRACKET-PANEL TOP;26inch,SECC,T1.2 2 S.N.A
..2 M0146 BN61-05177A BRACKET-PANEL SIDE;26inch,SECC,T1.2 2 S.N.A
..2 BN61-05281A HOLDER-CLAMP;LCD,NYLON 66,WHT 2 S.N.A
..2 M0230 BN96-07766J ASSY CABLE P-FFC;CORAL,FFC CABLE,385mm,3 1 S.A
0.1 M0017 BN91-03769D ASSY CHASSIS;LN32B360C5DXZA 1 S.N.A
..2 M0014 BN94-02679D ASSY PCB MAIN;LN32B360C5DXZA 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.025 S.N.A
...3 CN804 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 FCN101 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 S.N.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 S.A
...3 CN807 3722-002516 JACK-USB;4P/1C,AU30U,BLK,STRAIGHT,A TYPE 1 S.A
...3 CIS3 BN40-00138A TUNER;TDAU4-K01A,TDAU4-K01A,VSB(NTSC/ATS 1 S.A
...3 BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-03226D ASSY SMD;LN32B360C5DXZA 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45um,96.5Sn/ 0.039 S.N.A
....4 D707 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D708 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D709 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D710 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D711 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D810 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D812 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D813 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D815 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D816 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D818 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D823 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D601 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D901 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D902 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D905 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D906 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D907 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A

5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 D903 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D950 0403-000766 DIODE-ZENER;VLZ3V3A,3.16-3.38V,500mW,SOD 1 S.N.A
....4 D801 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D803 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D712 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D713 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D716 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D717 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D718 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D719 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D817 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D819 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D820 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D821 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D824 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D826 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 1 S.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 1 S.A
....4 D830 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 1 S.A
....4 D804 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 D805 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 D808 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 D809 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 D904 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 Q102 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q105 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q106 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q301_PWM 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q302 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q303 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q701 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q804 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q901 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q950 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC701 1006-001266 IC-LINE TRANSCEIVER;SP3232EEY,TSSOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001406 IC-EEPROM;AT24C512BN-SH25-T,512Kbit,64Kx 1 S.A
....4 IC202 1105-001931 IC-DDR2 SDRAM;K4T51163Q,DDR2-800,512Mbit 1 S.N.A
....4 T0124 1201-002797 IC-POWER AMP;NTP-3200,QFN,56P,8x8mm,DUAL 1 S.A
....4 T0085 1201-002849 IC-AUDIO AMP;DRV603,TSSOP,14P,5x4.4mm,DU 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-002835 IC-POSI.FIXED REG.;KIA7805AF,DPAK,3P,6.6 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC304 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC902 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A

5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 IC104 1203-005188 IC-DC/DC CONVERTER;AOZ1021AIL,SOP,8P,4.9 1 S.A
....4 IC602 1203-005559 IC-BACKLIGHT DRIVER;MP3302DJ,TSOT23,5P,2 1 S.A
....4 IC603 1204-002818 IC-DEMODULATOR;S5H1411,-,100P,14x14mm,PL 1 S.A
....4 IC201 1204-002980 IC-DECODER;SEMS13-LF,FBGA,377P,21x21mm,P 1 S.A
....4 IC805 1205-003479 IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6 1 S.A
....4 D701 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D702 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D703 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D704 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D705 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D706 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D714 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D715 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D720 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D825 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D827 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D831 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D832 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 VT401 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 VT801 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 VT803 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 VT804 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 VT805 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 VT806 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 R715 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R950 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R116 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R118 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R123 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R124 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R315_PWM 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R432 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R434 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R904 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R906 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R910 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R911 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R407 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R417 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R418 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R419 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R425 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R426 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R427 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R707 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R708 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R719 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R720 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R730 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R841 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R109 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A

5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 R358_WF 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R601 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R609 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R610 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R613 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R615 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R718 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R801 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R803 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R846 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R951 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R302 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R306 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R307 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R309 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R311 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R329 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R357 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R358 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R831 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R121 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R126 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R303 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R310_PWM 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R325 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R326 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R619 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R620 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R717 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R811 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R821 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R833 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R905 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R908 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R920 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R921 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R922 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R923 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R930 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R122 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R125 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R301 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R304_PWM 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R305_HD 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R308 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R312 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R313_JEIDA 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R327 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R333 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R334 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A

5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 R342 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R703 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R704 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R724 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R725 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R728 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R729 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R812 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R822 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R832 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R834 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R835 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R843 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R844 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R848 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R849 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R850 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R852 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R902 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R903 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R907 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R953 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R705 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R706 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R726 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R734 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R851 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R853 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R107 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R825 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R827 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R828 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R830 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R709 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R710 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R608 2007-000159 R-CHIP;56Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R602 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R607 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R320 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 1 S.N.A
....4 R605 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 1 S.N.A
....4 R119 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R356_JEIDA 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R712 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R880_CEC 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R881_CEC 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R316 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R317 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R321 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R322 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R323 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R357_WF 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A

5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 R702 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R810 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R813 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R814 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R820 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R823 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R824 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R838 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R842 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R952 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R410 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R411 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R413 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R414 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R415 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R416 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R420 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R421 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R617 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R621 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R502 2007-000640 R-CHIP;270ohm,1%,1/10W,TP,1608 1 S.A
....4 R612 2007-000669 R-CHIP;2Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R916 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R917 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R918 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R919 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R611 2007-000755 R-CHIP;330Kohm,1%,1/10W,TP,1608 1 S.A
....4 R108 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R412 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R606 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R901 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R912 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R913 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R614 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R618 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R625 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R131 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R909 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R616 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R837 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R845 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R129 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R113 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R114 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R115 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R130 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R503 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R604 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R203 2007-007307 R-CHIP;150ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R201 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R202 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A

5-14
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 R204 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R205 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R424 2007-007319 R-CHIP;390ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R603 2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R127 2007-007549 R-CHIP;4.99Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R501 2007-007721 R-CHIP;560ohm,1%,1/10W,TP,1608 1 S.A
....4 R716 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R723 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R727 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R836 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R839 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R840 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R854 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R855 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R856 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R128 2007-008593 R-CHIP;750ohm,1%,1/16W,TP,1005 1 S.A
....4 R111 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 S.N.A
....4 R319 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R328 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R345 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R433 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R622 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R623 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R347 2011-000515 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 1 S.N.A
....4 R401 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R402 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R403 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R404 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R336 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 R337 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 R338 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 R335 2011-001011 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 C904 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C916 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C805 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C810 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C816 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C818 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C912 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C306 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C606 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C714 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C715 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C716 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C102 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C201 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C217 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C302 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C405 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C903 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C909 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
