English - 1
SETTING UP YOUR TV
Viewing the Control Panel ................................................................. 2
Accessories ....................................................................................... 3
Viewing the Connection Panel........................................................... 4
Viewing the Remote Control.............................................................. 7
Mini Remote Control.......................................................................... 8
Installing Batteries in the Remote Control ......................................... 8
Viewing the menus ............................................................................ 9
Placing Your Television in Standby Mode.......................................... 9
Plug & Play Feature......................................................................... 10
CHANNEL
Channel Menu ..................................................................................11
Managing Channels ........................................................................ 14
Conguring the Picture Menu .......................................................... 16
Viewing Picture-in-Picture................................................................ 20
Using Your TV as a Computer (PC) Display.................................... 21
Setting up the TV with your PC........................................................ 22
SOUND
Conguring the Sound Menu........................................................... 23
Selecting the Sound Mode .............................................................. 24
SETUP
Conguring the Setup Menu............................................................ 25
Setting the Time............................................................................... 27
Network Connection ........................................................................ 29
Setting the Network ......................................................................... 32
INPUT / SUPPORT
Input Menu....................................................................................... 35
Support Menu .................................................................................. 35
MEDIA PLAY (USB & DLNA)
Connecting a USB Device ............................................................... 38
Media Play Function ........................................................................ 39
Sorting the Photo List ...................................................................... 40
Photo List Option Menu ................................................................... 41
Viewing a Photo or Slide Show........................................................ 42
Slide Show Option Menu ................................................................. 43
Sorting the Music List ...................................................................... 44
Music List Option Menu ................................................................... 45
Playing Music .................................................................................. 46
Music Play option Menu .................................................................. 47
Sorting the Movie List ...................................................................... 47
Movie List Option Menu................................................................... 48
Playing a Movie File ........................................................................ 48
Movie Play Option Menu ................................................................. 50
Using the Setup Menu ..................................................................... 51
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
MEDIA PLAY-DLNA
Setting the DLNA Network............................................................... 52
Installing the DLNA Application........................................................ 53
Using the DLNA Application............................................................. 54
Using the DLNA Function ................................................................ 56
ANYNET+
Connecting Anynet+Devices........................................................... 57
Setting Up Anynet+.......................................................................... 58
Switching between Anynet+Devices............................................... 58
Recording ........................................................................................ 59
Listening through a Receiver (Home Theatre)................................. 59
Troubleshooting for Anynet+............................................................ 60
CONTENT LIBRARY
Using the Content Library................................................................ 61
Using the Contents .......................................................................... 62
Using the Content Management...................................................... 63
HOME NETWORK CENTRE
Home Network Centre ..................................................................... 64
Setting Up the Home Network Centre ............................................. 65
Using the Message Function ........................................................... 66
Using the Media Function................................................................ 67
RECOMMENDATIONS
Teletext Feature............................................................................... 68
Installing the Stand .......................................................................... 69
Disconnecting the Stand.................................................................. 70
Installing the Wall Mount Kit ............................................................ 70
Anti-Theft Kensington Lock ............................................................. 70
Preparing before installing Wall-Mount............................................ 70
Assembling the Cables.................................................................... 71
Securing the Installation Space ....................................................... 72
Securing the TV to the Wall ............................................................. 72
Troubleshooting: Before Contacting Service Personnel.................. 73
Specications .................................................................................. 74
GNU GENERAL PUBLIC LICENSE
END OF TERMS AND CONDITIONS
GNU Lesser General Public License (LGPL)
END OF TERMS AND CONDITIONS
LICENSE ISSUES
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
CONTENTS
English
Symbol
N O T
Note One-Touch Button TOOL Button Press
❑
BN68-01985P-00Eng.indb 1 2009-04-10 �� 5:01:16

English - 2
SETTING UP YOUR TV
Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
Product design and specifications may be changed without notice in order to enhance product performance.
Viewing the Control Panel
The product colour and shape may vary depending on the model.
The front panel buttons can be activated by touching it with your finger.
1REMOTE CONTROL SENSOR: Aim the remote control towards this spot on the TV.
2 P (POWER): Press to turn the TV on and off.
3 z : Press to change channels. In the on-screen menu, use the
z
buttons as you would use the ▼ and ▲
buttons on the remote control.
4 Y : Press to increase or decrease the volume. In the on-screen menu, use the Y buttons as you would use the
◄ and ► buttons on the remote control.
5MENU: Press to see an on-screen menu of your TV’s features.
6SOURCE E : Toggles between all the available input sources. In the on-screen menu, use this button as you use the
ENTER E button on the remote control.
7SPEAKERS
N
¦
N
N
7
6 5 4 3
1 2
7
BN68-01985P-00Eng.indb 2 2009-04-10 �� 5:01:16

English - 3
Accessories
Remote Control &
Batteries (AAA x 2) Programme CD Cover-Bottom Cleaning Cloth
(M4 X L10) (M4 X L12)
Warranty Card / Safety Guide (Not
available in all locations) Stand Screw X 5 Stand Screw X 4
(Applicable to 32inch
models only)
Mini Remote Control &
Batteries (3V)
Holder-Wire Cable
(Depending on the model) Component Cable Holder-Ring (4ea) Holder-Wire (3ea)
Holder-Wire Stand AV Cable SCART Cable Owner’s Instructions
Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer.
The items colour and shape may vary depending on the model.
¦
N
N
BN68-01985P-00Eng.indb 3 2009-04-10 �� 5:01:18

English - 4
Viewing the Connection Panel
The product colour and shape may vary depending on the model.
1KENSINGTON LOCK
The Kensington Lock (optional) is a device used to physically fix the system when used in a public place. If you want to use a
locking device, contact the dealer where you purchased the TV.
The location of the Kensington Lock may be different depending on its model.
2LAN
Connect a LAN cable to this port to connect to the Network.
3ANT IN
Connects to an antenna or cable TV system.
¦
N
N
2
13 4 65
9
0
!
0
@
#
7
8
[TV Rear Panel]
Power Input
BN68-01985P-00Eng.indb 4 2009-04-10 �� 5:01:19

English - 5
4EXT (RGB)
Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players.
When connecting, use the appropriate connector.
In EXT Mode, DTV Out supports MPEG SD Video and Audio only.
Input/Output Specification
Connector Input Output
Video Audio (L / R) RGB Video + Audio (L / R)
EXT O O O Only TV or DTV output is available.
5AV IN [VIDEO] / [L-AUDIO-R]
Video and audio inputs for external devices, such as a camcorder or VCR.
When connecting, use the appropriate connector.
6COMPONENT IN
Connects Component video / audio.
When connecting, use the appropriate connector.
7PC IN
Connects to the video output jacks on your PC.
If your PC supports an HDMI connection, you can connect this to the HDMI IN 1(DVI), 2, 3 or 4terminal.
If your PC supports a DVI connection, you can connect this to the HDMI IN 1(DVI) / PC/DVI AUDIO IN terminal.
8PC/DVI AUDIO IN
Connect to the audio output jack on your PC.
DVI audio outputs for external devices.
9HDMI IN 1(DVI), 2, 3, 4
Connects to the HDMI jack of a device with an HDMI output.
No sound connection is needed for an HDMI to HDMI connection.
Use an HDMI cable which is smaller than 14mm.
What is HDMI?
HDMI(High-Definition Multimedia Interface), is an interface that enables the transmission of digital audio and video signals
using a single cable.
The difference between HDMI and DVI is that the HDMI device is smaller than DVI’s one.
The TV may not output sound and pictures may be displayed with abnormal colour when DVD / Blu-ray player / Cable
Box / Satellite receiver (Set-Top Box) supporting HDMI versions older than 1.3 are connected. When connecting an older
HDMI cable and there is no sound, connect the HDMI cable to the HDMI IN 1(DVI) jack and the audio cables to the PC/
DVI AUDIO IN jacks on the back of the TV. If this happens, contact the company that provided the DVD / Blu-ray player /
Cable Box / Satellite receiver (Set-Top Box) to confirm the HDMI version, then request an upgrade.
Use the HDMI IN 1(DVI) jack for DVI connection to an external device. Use a DVI to HDMI cable or DVI-HDMI adapter
(DVI to HDMI) for video connection and the PC/DVI AUDIO IN jacks for audio. When using an HDMI / DVI cable
connection, you must use the HDMI IN 1(DVI) jack.
HDMI cables that are not 1.3 may cause annoying flicker or no screen display.
0USB1(HDD) / USB2
Connector for software upgrades and Media Play, etc.
You can connect to Samsung’s network wirelessly using the ‘Samsung Wireless LAN Adapter’ (Sold separately).
For USB HDD, use the USB1 (HDD) port.
!DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component such as a Home theatre receiver.
When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL) jack: Decrease the volume of the TV
and adjust the volume level with the system’s volume control.
5.1CH audio is possible when the TV is connected to an external device supporting 5.1CH.
When the receiver (home theatre) is set to On, you can hear sound output from the TV’s Optical jack. When the TV is
displaying a DTV(air) signal, the TV will send out 5.1 channel sound to the Home theatre receiver. When the source is a
digital component such as a DVD / Blu-ray player / Cable Box / Satellite receiver (Set-Top Box) and is connected to the
TV via HDMI, only 2 channel sound will be heard from the Home Theatre receiver. If you want to hear 5.1 channel audio,
connect the digital audio out jack on DVD / Blu-ray player / Cable Box / Satellite receiver (Set-Top Box) directly to an
Amplifier or Home Theatre, not the TV.
N
N

N
N
N
N
N
N
N


N
N
N
N
N
N
N
BN68-01985P-00Eng.indb 5 2009-04-10 �� 5:01:19

English - 6
@COMMON INTERFACE Slot
Insert CI (Common Interface) card into the slot.
When not inserting ‘CI CARD’ in some channels, ‘Scrambled Signal’ is displayed on the screen.
The pairing information containing a telephone number, CI CARD ID, Host ID and other information will be displayed in
about 2~3 minutes. If an error message is displayed, please contact your service provider.
When the channel information configuration has finished, the message ‘Updating Completed’ is displayed, indicating that
the channel list is now updated.
You must obtain a CI CARD from a local cable service provider. Remove the CI CARD by carefully pulling it out with your
hands since dropping the CI CARD may cause damage to it.
Insert the CI-Card in the direction marked on it.
The place of the COMMON INTERFACE Slot may be different depending on its model.
CAM is not supported in some countries and regions, check with your authorized dealer.
The CI+ function is only applicable to UE********P model.
If you have some problems, please contact to service provider.
#EX-LINK
Connector for service only.



N
N
N
N
N
BN68-01985P-00Eng.indb 6 2009-04-10 �� 5:01:19

English - 7
Viewing the Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.
The performance of the remote control may be affected by bright light.
The product colour and shape may vary depending on the model.
1 POWER : Turns the TV on and
off.
2 TV : Selects the TV mode
directly.
3 NUMERIC BUTTONS : Press to
change the channel.
4 E :Performs the same function
as the ENTER E button of
the directional buttons. When
switching channels with the
numeric buttons, and you press
the channel number and then the
ENTER E button, the channel is
immediately switched.
5 CH LIST : Used to display
Channel Lists on the screen.
6 TOOLS : Use to quickly select
frequently used functions.
7 INTERNET@ : Press to use
various internet services to
view useful information and
entertaining content.
8 COLOUR BUTTONS : Use these
buttons in the Channel list,
Media Play menu, etc.
9 Y : Press to increase or
decrease the volume.
0 MUTE M : Press to temporarily
cut off the sound.
@ INFO : Press to display
information on the TV screen.
# Use these buttons in the Media
Play and Anynet+modes. ( ∏ :
This remote can be used to
control recording on Samsung
recorders with the Anynet+
feature)
$ ON/OFF @ : Pressing the
ON/OFF @ light button toggles
between on and off. When the
remote control is on, and a button
is pressed on the remote control,
the remote control buttons will
be lit for a moment. (Using the
remote control with the ON/OFF
@ light button set to On will
reduce the battery usage time.)
% PRE-CH : Enables you to return
to the previous channel you were
watching.
^ MENU : Displays the main on-
screen menu.
& FAV.CH : Used to display
Favourites Channel Lists on the
screen.
* RETURN : Returns to the
previous menu
(  UP▲/DOWN▼/LEFT◄/
RIGHT►/ENTER E : Use to
select on-screen menu items and
change menu values.
) EXIT : Press to exit the menu.
a SOURCE : Press to display
and select the available video
sources.
b > P < : Press to change
channels.
c CONTENT : This function
enables you to view the Content
Library.
d MEDIA.P : Allows you to play
music files, pictures, and movies.
e SUBT. : Digital subtitle display
f GUIDE : Electronic Programme
Guide (EPG) display
Teletext Functions
2 : : Exit from the Teletext
display
5 8 : Teletext store
6 4 : Teletext size selection
8 Fastext topic selection
0 0 : Teletext mode selection
(LIST / FLOF)
! / : Alternately select
Teletext, Double, or Mix.
@ 5 : Teletext reveal
% 1 : Teletext sub page
^ 6 : Teletext index
* 9 : Teletext hold
) 7 : Teletext cancel
b 2 : Teletext next page
3 : Teletext previous page
¦
N
N
N
2
1
3
4
5
0
6
7
8
9
!
@
#
$
%
^
&
*
)
b
c
d
e
f
a
(
BN68-01985P-00Eng.indb 7 2009-04-10 �� 5:01:20

English - 8
Mini Remote Control
The Mini Remote Control is a simplified remote control that consists of the
power, channel and volume buttons only.
1Television Standby button
2 < : Next channel / > : Previous channel
3+ : Volume increase / –: Volume decrease
4IrDA transmitter
Use the Mini Remote Control so that this part faces the TV.
Installing Batteries in the Remote Control
Normal Remote Control
1. Lift the cover at the back of the remote control upward as shown in the
figure.
2. Install two AAA size batteries.
Make sure to match the ‘+’ and ‘–’ ends of the batteries with the
diagram inside the compartment.
3. Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t
be using the remote control for a long time. (Assuming typical TV
usage, the batteries should last for about one year.)
Mini Remote Control
1. Turn the battery cover counterclockwise to unlock it and then separate the battery cover.
2. Insert the corresponding 3V Lithium battery.
3. Place the battery cover into the remote control aligning it with the grooves
and then turn the battery cover clockwise to lock the cover.
If the remote control doesn’t work, check the following:
Is the TV power on?
Are the plus and minus ends of the batteries reversed?
Are the batteries drained?
Is there a power outage or is the power cord unplugged?
Is there a special fluorescent light or neon sign nearby? RATI
¦
N
¦
N
N
N





1
4
2
3
2
3
OPEN
CLOSE
BN68-01985P-00Eng.indb 8 2009-04-10 �� 5:01:20

English - 9
Viewing the menus
Before using the TV, follow the steps below to learn how to navigate the menu in order to select and adjust different functions.
Operation the OSD (On Screen Display)
The access step may differ depending on the selected menu.
1. Press the MENU button.
2. The main menu appears on the screen. The menu’s left side has icons : Picture, Sound,
Channel, Setup, Input, Application, Support.
3. Press the ▲ or ▼ button to select one of the icons.
4. Then press the ENTER E button to access the icon’s sub-menu.
5. Press the ▲ or ▼ button to select the icon’s submenu.
6. Press the ◄ or ► button to decrease or increase the value of a particular item. The
adjustment OSD may differ depending on the selected menu.
7. Press the ENTER E button to complete the configuration. Press the EXIT button to exit.
Placing Your Television in Standby Mode
Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when you
wish to interrupt viewing temporarily (during a meal, for example).
1. Press the POWER P button on the remote control.
The screen is turned off and a standby indicator appears on your set.
2. To switch your set back on, simply press the POWER P button again.
Do not leave your set in standby mode for long periods of time (when you are away on holiday, for example). It is best to
unplug the set from the mains and aerial.
¦
❑
¦
N
N
MENU Button
Display the main on-screen menu.
ENTER E / DIRECTION Button
Move the cursor and select an
item. Select the currently selected
item. Confirm the setting.
RETURN Button
Return to the previous menu.
EXIT
Exit the on-screen menu.
Mode :Standard ▶
Backlight :7
Contrast :95
Brightness :45
Sharpness :50
Colour :50
Tint(G/R) :G50/R50
AdvancedSettings
Mode :Standard
Backlight :7 ▶
Contrast :95
Brightness :45
Sharpness :50
Colour :50
Tint(G/R) :G50/R50
AdvancedSettings
PictureOptions
7
U Move L Adjust E Enter R Return
▲
Backlight
▼
Help icon
BN68-01985P-00Eng.indb 9 2009-04-10 �� 5:01:20

English - 10
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and subsequently.
1. Press the POWER button on the remote control.
You can also use the POWER P button on the TV.
The message Select the OSD Language. is displayed.
2. Press the ENTER E button. Select the appropriate language by pressing the ▲ or ▼
button. Press the ENTER E button to confirm your choice.
3. Press the ◄ or ► button to select Store Demo or Home Use, then the ENTER E button.
We recommend setting the TV to Home Use mode for the best picture in your home
environment.
Store Demo mode is only intended for use in retail environments.
If the unit is accidentally set to Store Demo mode and you want to return to Home
Use (Standard): Press the volume button on the TV. When the volume OSD is displayed, press and hold the MENU
button on the TV for 5 seconds.
4. Press the ENTER E button. Select the appropriate country by pressing the ▲ or ▼ button. Press the ENTER E button to
confirm your choice.
5. Press the ▲ or ▼ button to select Air or Cable, then press the ENTER E button.
Air: Air antenna signal.
Cable: Cable antenna signal.
6. Press the ▲ or ▼ button to select the channel source to memorize. Press the ENTER E button to select Start.
When setting the antenna source to Cable, a step appears allowing you to set a value for the digital channel search. For
more information, refer to Channel→AutoStore.
Digital & Analogue: Digital and Analogue channels.
Digital: Digital channels.
Analogue: Analogue channels.
The channel search will start and end automatically.
Press the ENTER E button at any time to interrupt the memorization process.
After all the available channels are stored, the message Set the Clock Mode. is displayed.
7. Press the ENTER E button. Press the ▲ or ▼ button to select Auto, then Press the ENTER E button.
If you select Manual, Set current date and time is displayed.
If you have received a digital signal, the time will be set automatically. If not, select Manual to set the clock.
8. The description for the connection method providing the best HD screen quality is displayed. Check the description and press
the ENTER E button.
9. Press the ◄ or ► button to select See Product Guide or Watch TV. Press the ENTER E button.
See Product Guide: You are moved to the Product Guide where you can view the introduction to the main functions of
your new HDTV.
Watch TV: You can watch the memorized channels.
If you want to reset this feature...
1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup,
then press the ENTER E button.
2. Press the ENTER E button again to select Plug & Play.
3. Enter your 4 digit PIN number. The default PIN number of a new TV set is ‘0-0-0-0’.
If you want to change PIN number, use the Change PIN function.
The Plug & Play feature is only available in the TV mode.
¦
N
N
N
N
N
N
N
N
N
N
N
N
N
N


N
N
Plug&Play  ▶
Language :English
Time
GameMode :Off
BDWise :On
NetworkType :Cable
NetworkSetup
ChildLock :On
Setup
SelecttheOSDLanguage.
MenuLanguage :English  ▶
E Enter
Plug&Play
BN68-01985P-00Eng.indb 10 2009-04-10 �� 5:01:21

English - 11
CHANNEL
Channel Menu
Country
Analogue Channel
You can change the country for analogue channels.
Digital Channel
You can change the country for digital channels.
The PIN number input screen appears. Enter your 4 digit PIN number.
Auto Store
You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated
programme numbers may not correspond to actual or desired programme numbers.
If a channel is locked using the Child Lock function, the PIN input window appears.
Air / Cable
Antenna source to memorize
Digital & Analogue: Digital and Analogue channels.
Digital: Digital channels.
Analogue: Analogue channels.
When selecting Cable→Digital&Analogue or Cable→Digital:
Provide a value to scan for cable channels.
SearchMode→Full/Network/Quick
Quick
Network ID: Displays the network identification code.
Frequency: Displays the frequency for the channel. (Differs in each country)
Modulation: Displays available modulation values.
Symbol Rate: Displays available symbol rates.
Scans for all channels with active broadcast stations and stores them in the TV’s memory.
If you want to stop Auto Store, press the ENTER E button.
The Stop Auto Store? message will be displayed.
Select Yes by pressing the ◄ or ► button, then press the ENTER E button.
Manual Store
Scans for a channel manually and stores it in the TV’s memory.
If a channel is locked using the Child Lock function, the PIN input window appears.
Digital Channel
Manual store for digital channels.
Digital Channel is only available in DTV mode.
Channel: Set the Channel number using the ▲, ▼ or number (0~9) buttons.
Frequency: Set the frequency using the number buttons.
Bandwidth: Set the bandwidth using the ▲, ▼ or number (0~9) buttons.
When it has finished, channels are updated in the channel list.
Analogue Channel
Manual store for analogue channel.
Programme (Programme number to be assigned to a channel): Sets the programme number using the ▲, ▼ or number (0~9)
buttons.
ColourSystem→Auto/PAL/SECAM/NTSC4.43: Sets the colour system value using the ▲ or ▼ button.
SoundSystem→BG/DK/I/L: Sets the sound system value using the ▲ or ▼ button.
¦
❑
■
■
N
❑
N
■
●
●
●
●
N




N
N
❑
N
N
■
N
●
●
●
N
■
●
●
●
Country  ▶
AutoStore
ManualStore
CableSearchOption
FullGuide
MiniGuide
DefaultGuide :FullGuide
ChannelList
Channel
BN68-01985P-00Eng.indb 11 2009-04-10 �� 5:01:21

English - 12
Channel (When you know the number of the channel to be stored): Press the ▲ or ▼ button to select C(Air channel) or S
(Cable channel). Press the ► button, then press the ▲, ▼ or number (0~9) buttons to select the required number.
You can also select the channel number directly by pressing the number (0~9) buttons.
If there is abnormal sound or no sound, reselect the sound standard required.
Search (When you do not know the channel numbers): Press the ▲ or ▼ button to start the search. The tuner scans the
frequency range until the first channel or the channel that you selected is received on the screen.
Store (When you store the channel and associated programme number): Set to OK by pressing the ENTER E button.
Channel mode
P (Programme mode): When completing tuning, the broadcasting stations in your area have been assigned to position
numbers from P00 to P99. You can select a channel by entering the position number in this mode.
C (Air channel mode): You can select a channel by entering the assigned number to each air broadcasting station in this
mode.
S (Cable channel mode): You can select a channel by entering the assigned number for each cable channel in this mode.
Cable Search Option (depending on the country)
Sets additional search options such as the frequency and symbol rate for cable network searches.
Freq.Start (Frequency Start): Set the start frequency (Differs in each country)
Freq.Stop (Frequency Stop): Set the stop frequency (Differs in each country)
Modulation: Displays available modulation values.
Symbol Rate: Displays available symbol rates.
Full Guide / Mini Guide
The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme entries may appear blank or out
of date as a result of the information broadcast on a given channel. The display will dynamically update as soon as new information
becomes available.
You can also display the guide menu simply by pressing the GUIDE button. (To configure the Default Guide, refer to the
descriptions.)
Full Guide
Displays the programme information as time ordered One hour segments. Two hours of programme information is displayed which
may be scrolled forwards or backwards in time.
Mini Guide
The information of each programme is displayed by each line on the current channel Mini Guide screen from the current
programme onwards according to the programme starting time order.
DefaultGuide→MiniGuide/FullGuide
You can decide whether to display either the Mini Guide or the Full Guide when the GUIDE button on the remote control is
pressed.
Channel List
For detailed procedures on using the Channel List, refer to the Managing Channels instructions.
You can select these options by simply pressing the CH LIST button on the remote control.
Channel Mode
When press the P > / < button, Channels will be switched within the selected channel list.
Added Ch.
Channels will be switched within the memorized channel list.
Favourite Ch.
Channels will be switched within the favourite channel list.
●
N
N
N
●
N



❑
●
●
●
●
❑
O
■
■
❑
❑
O
❑
■
■
BN68-01985P-00Eng.indb 12 2009-04-10 �� 5:01:21

English - 13
Fine Tune
If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store
operation. If the signal is weak or distorted, you may have to fine tune the channel manually.
Fine tuned channels that have been saved are marked with an asterisk “*” on the right-hand side of the channel number in the
channel banner.
To reset the fine-tuning, select Reset by pressing the ▲ or ▼ button and then press the ENTER E button.
Only Analogue TV channels can be fine tuned.
Using the Full / Mini Guide
To... Then...
Watch a programme in the EPG list Select a programme by pressing the ▲, ▼, ◄, ► button.
Exit the guide Press the blue button
If the next programme is selected, it is scheduled with the clock icon displayed. If the ENTER E button is pressed again, press
the ◄, ► button to select Cancel Schedules, the scheduling is cancelled with the clock icon gone.
View programme information Select a programme of your choice by pressing the ▲, ▼, ◄, ► button.
Then press the INFO button when the programme of your choice is
highlighted.
The programme title is on the upper part of the screen centre.
Please click on INFO button for the detailed information. Channel Number, Running Time, Status Bar, Parental Level, Video
Quality Information (HD / SD), Sound Modes, Subtitle or Teletext, languages of Subtitle or Teletext and brief summary of the
highlighted programme are included on the detailed information. “...” will be appeared if the summary is long.
Toggle between the Mini Guide and Full Guide Press the Red button repeatedly.
In Full Guide
Scrolls backwards quickly (24 hours).
Scrolls forwards quickly (24 hours).
Press the Green button repeatedly.
Press the Yellow button repeatedly.
In Mini Guide
Display previous page quickly.
Display next page quickly.
Press the Green button.
Press the Yellow button.
❑
N
N
N
FullGuide
E Watch Information  Page MiniGuide +24Hours Exit
DTVCable900ftn2:10Tue1Jun
FreshmenOnCampus
2:00-2:30
NoDetailedInformation
Today 2:00-3:00 3:00-4:00
MintExtra
Loaded
40withDynamiteMC
TheDistillery
SmashHits!Sunday
900ftn
901ITVPlay
902Kerrang!
903Kiss
904oneword
905Hits
▼
StreetHypn..
Kisstory
NoInformation
NoInformation
NoInformation
FreshmenO..
900
E Watch Information  Page FullGuide Exit
MiniGuide DTVCable900ftn
StreetHypnosis
BoozeBritain
2:00
2:30
5:00
FreshmenOnCampus
▼
BN68-01985P-00Eng.indb 13 2009-04-10 �� 5:01:21

English - 14
Managing Channels
Using this menu, you can add / delete or set favourites channels and use the programme guide
for digital broadcasts.
All Channels
Shows all currently available channels.
Added Channels
Shows all added channels.
Favourites
Shows all favourite channels.
To select the favourites channels you have set up, press the FAV.CH button on the remote control.
Programmed
Shows all current reserved programmes.
Select a channel in the All Channels, Added Channels or Favourites screen by pressing the ▲ / ▼ buttons, and pressing
the ENTER E button. Then you can watch the selected channel.
Using the Colour buttons with the Channel List
Red (Channel Type): Toggle between your TV, Radio, Data / Other and All.
Green (Zoom): Enlarges or shrinks a channel number.
Yellow (Select): Selects multiple channel lists. You can perform the add/delete or add to favourites/delete from favourites
function for multiple channels at the same time. Select the required channels and press the Yellow button to set all the
selected channels at the same time. The c mark appears to the left of the selected channels.
TOOLS (Tools): Displays the Delete (or Add), Add to Favourite (or Delete from Favourite), Lock (or Unlock), Timer
Viewing, Edit Channel Name, Edit Channel Number, Sort, Select All (or Deselect All), Auto Store menu. (The
Options menus may differ depending on the situation.)
Channel Status Display Icons
A : An Analogue channel.
c : A channel selected by pressing the Yellow button.
* : A channel set as a Favourite.
( : A programme currently being broadcast.
\ : A locked channel.
) : A reserved programme
Channel List Option Menu (in All Channels / Added Channels / Favourites)
Press the TOOLS button to use the option menu.
Option menu items may differ depending on the channel status.
Add / Delete
You can delete or add a channel to display the channels you want.
All deleted channels will be shown on All Channels menu.
A gray-coloured channel indicates the channel has been deleted.
The Add menu only appears for deleted channels.
You can also delete a channel to the Added Channels or Favourites menu in the same
manner.
Add to Favourite / Delete from Favourite
You can set channels you watch frequently as favourites.
Press the TOOLS button to display the Tools menu. You can also set the add to (or delete from) Favourite by selecting Tools
→AddtoFavourite (or Delete from Favourite).
The “ * ” symbol will be displayed and the channel will be set as a favourite.
All favourite channels will be shown on Favourites menu.
Lock / Unlock
You can lock a channel so that the channel cannot be selected and viewed.
This function is available only when the Child Lock is set to On.
The PIN number input screen appears. Enter your 4 digit PIN number.
The default PIN number of a new TV set is ‘0-0-0-0’. You can change the PIN, by selecting Change PIN from the menu.
The ‘ \ ’ symbol will be displayed and the channel will be locked.
¦
■
■
■
O
■
N
N




N






N
N
■
N
N
N
N
■
T
N
N
■
N
N
N
N
AllChannels
824UKTVGold
825UKTVstyle
A 1C--
A
2C--
A
3C--
A
4C--
A
5C--
A
6C--
A
7C--
A
8C--
All ChannelType Zoom Select T Tools
Delete
AddtoFavourite
Lock
TimerViewing
EditChannelName
Sort

AddedChannels
824UKTVGold
825UKTVstyle
A 1C--
A
2C--
A
3C--
A
4C--
A
5C--
A
6C--
A
7C--
A
8C--
All ChannelType Zoom Select T Tools
BN68-01985P-00Eng.indb 14 2009-04-10 �� 5:01:22

English - 15
Timer Viewing
If you reserve a programme you want to watch, the channel is automatically switched to the reserved channel in the Channel List;
even when you are watching another channel. To reserve a programme, set the current time first.
Only memorized channels can be reserved.
You can set the channel, day, month, year, hour and minute directly by pressing the number buttons on the remote control.
Reserving a programme will be shown in the Programmed menu.
Digital Programme Guide and Viewing Reservation
When a digital channel is selected, and you press the ► button, the Programme Guide for the channel appears. You can
reserve a programme according to the procedures described above.
Edit Channel Name (analogue channels only)
Channels can be labelled so that their call letters appear whenever the channel is selected.
The names of digital broadcasting channels are automatically assigned and cannot be renamed.
Edit Channel Number (digital channels only)
You can also edit the channel number by pressing the number buttons on the remote control.
Sort (analogue channels only)
This operation allows you to change the programme numbers of the stored channels. This operation may be necessary after using
the auto store.
Select All / Deselect All
Select All: You can select all the channels in the channel list.
Deselect All: You can deselect all the selected channels.
You can only select Deselect All when there is a selected channel.
Auto Store
For detailed procedures on setting up options, refer to the ‘Channel Menu’ instructions.
If a channel is locked using the Child Lock function, the PIN input window appears.
Channel List Option Menu (in Programmed)
You can view, modify or delete a reservation.
Press the TOOLS button to use the option menu.
Change Info
Select to change a viewing reservation.
Cancel Schedules
Select to cancel a viewing reservation.
Information
Select to view a viewing reservation.
(You can also change the reservation information.)
Select All
Select all reserved programmes.
■
N
N
N
N
■
N
■
■
■
●
●
N
■
N
N
N
■
■
■
■
Programmed
1/1/2009
13:595TV1 ) 
18:592TV3 ) TheEqualizer
20:592TV3 ) McMillan&Wife
21:592TV3 ) M.Spillane’smike
All Zoom Select T Tools E Information
ChangeInfo
CancelSchedules
Information
SelectAll

BN68-01985P-00Eng.indb 15 2009-04-10 �� 5:01:22

English - 16
Configuring the Picture Menu
Mode
You can select the type of picture which best corresponds to your viewing requirements.
Press the TOOLS button to display the Tools menu. You can also set the picture mode by
selecting Tools→PictureMode.
Dynamic
Selects the picture for increased definition in a bright room.
Standard
Selects the picture for the optimum display in a normal environment.
Natural
Selects the picture for an optimum and eye-comfortable display.
This function is not available in PC mode.
Movie
Selects the picture for viewing movies in a dark room.
Backlight / Contrast / Brightness / Sharpness / Colour / Tint(G/R)
Your television has several setting options that allow you to control the picture quality.
Backlight: Adjusts the brightness of LED back light.
Contrast: Adjusts the contrast level of the picture.
Brightness: Adjusts the brightness level of the picture
Sharpness: Adjusts the edge definition of the picture.
Colour: Adjusts colour saturation of the picture.
Tint(G/R): Adjusts the colour tint of the picture.
In analogue TV, Ext., AV modes of the PAL system, you cannot use the Tint(G/R) Function.
When you make changes to Backlight, Contrast, Brightness, Sharpness, Colour or Tint(G/R) the OSD will be adjusted
accordingly.
In PC mode, you can only make changes to Backlight, Contrast and Brightness.
Settings can be adjusted and stored for each external device you have connected to an input of the TV.
The energy consumed during use can be signicantly reduced if the brightness level of the picture is lowered, which will
reduce the overall running cost.
¦
❑
T
■
■
■
N
■
❑
●
●
●
●
●
●
N
N
N
N
N
Mode :Standard ▶
Backlight :7
Contrast :95
Brightness :45
Sharpness :50
Colour :50
Tint(G/R) :G50/R50
AdvancedSettings
7
U Move L Adjust E Enter R Return
▲
Backlight
▼
BN68-01985P-00Eng.indb 16 2009-04-10 �� 5:01:22

English - 17
Advanced Settings
Samsung’s new TVs allow you to make even more precise picture settings than previous
models.
Advanced Settings is available in Standard or Movie mode.
In PC mode, you can only make changes to Dynamic Contrast, Gamma and White
Balance from among the Advanced Settings items.
BlackTone→Off/Dark/Darker/Darkest
You can select the black level on the screen to adjust the screen depth.
DynamicContrast→Off/Low/Medium/High
You can adjust the screen contrast so that the optimal contrast is provided.
Gamma
You can adjust the primary colour (red, green, blue) intensity.
Colour Space
Colour space is a colour matrix composed of red, green and blue colours. Select your favourites colour space to experience the
most natural colour.
Auto: Auto Colour Space automatically adjusts to the most natural colour tone based on programme sources.
Native: Native Colour Space offers deep and rich colour tone.
Custom: Adjusts the colour range to suit your preference.
Changing the adjustment value will refresh the adjusted screen.
Settings can be adjusted and stored for each external device you have connected to an input of the TV. For example, if
you have a DVD player connected to HDMI 1 and it is currently selected, settings and adjustments will be saved for the
DVD player.
Colour: Red, Green, Blue, Yellow, Cyan or Magenta
Colour is available when Colour Space is set to Custom.
In Colour, you can adjust the RGB values for the selected colour.
To reset the adjusted RGB value, select Reset.
Red: Adjusts the red saturation level of the selected colour.
Green: Adjusts the green saturation level of the selected colour.
Blue: Adjusts the blue saturation level of the selected colour.
Reset: Resets the colour space to the default values.
White Balance
You can adjust the colour temperature for more natural picture colours.
R-Offset: Adjusts the red colour darkness.
G-Offset: Adjusts the green colour darkness.
B-Offset: Adjusts the blue colour darkness.
R-Gain: Adjusts the red colour brightness.
G-Gain: Adjusts the green colour brightness.
B-Gain: Adjusts the blue colour brightness.
Reset: The previously adjusted white balance will be reset to the factory defaults.
Flesh Tone
You can emphasize the pink ‘flesh tone’ in the picture.
Changing the adjustment value will refresh the adjusted screen.
EdgeEnhancement→Off/On
You can emphasize object boundaries in the picture.
xvYCC→Off/On
Setting the xvYCC mode to on increases detail and colour space when watching movies from an external device (ie. DVD player)
connected to the HDMI or Component IN jacks.
xvYCC is available when the picture mode is set to Movie, and the external input is set to HDMI or Component mode.
This function may not be supported depending on your external device.
❑
N
N
■
■
■
■
●
●
●
N
N

N
N
N




■
●
●
●
●
●
●
●
■
N
■
■
N
N
BlackTone :Off  ▶
DynamicContrast :Medium
Gamma :0
ColourSpace :Native
WhiteBalance
FleshTone :0
EdgeEnhancement :On
U Move E Enter R Return
AdvancedSettings
BN68-01985P-00Eng.indb 17 2009-04-10 �� 5:01:22

English - 18
Picture Options
In PC mode, you can only make changes to the Colour Tone and Size from among the
items in Picture Options.
ColourTone→Cool/Normal/Warm1/Warm2/Warm3
Warm1, Warm2 or Warm3 is only activated when the picture mode is Movie.
Settings can be adjusted and stored for each external device you have connected to an
input of the TV.
Size
Occasionally, you may want to change the size of the image on your screen. Your TV comes
with several screen size options, each designed to work best with specific types of video input. Your cable box/satellite receiver
may have its own set of screen sizes as well. In general, though, you should view the TV in 16:9 mode as much as possible.
Press the TOOLS button to display the Tools menu. You can also set the size by selecting Tools→PictureSize.
Auto Wide: Automatically adjusts the picture size to the 16:9 aspect ratio.
16:9: Adjusts the picture size to 16:9 appropriate for DVDs or wide broadcasting.
Wide Zoom: Magnify the size of the picture more than 4:3.
Zoom: Magnifies the 16:9 wide picture (in the vertical direction) to fit the screen size.
4:3: This is the default setting for a video movie or normal broadcasting.
Screen Fit: Use the function to see the full image without any cut-off when HDMI (720p / 1080i / 1080p) or Component (1080i
/ 1080p) signals are input.
Depending on the input source, the picture size options may vary.
The items available may differ depending on the selected mode.
In PC Mode, only 16:9 and 4:3 mode can be adjusted.
Settings can be adjusted and stored for each external device you have connected to an input of the TV.
Temporary image retention may occur when viewing a static image on the set for more than two hours.
Wide Zoom: Press the ► button to Select Position, then press the ENTER E button. Press the ▲ or ▼ button to move the
picture up / down. Then press the ENTER E button.
Zoom: Press the ► button to Select Position, then press the ENTER E button. Press the ▲ or ▼ button to move the picture
up and down. Then press the ENTER E button. Press the ► button to Select Size, then press the ENTER E button. Press
the ▲ or ▼ button to magnify or reduce the picture size in the vertical direction. Then press the ENTER E button.
After selecting Screen Fit in HDMI (1080i / 1080p) or Component (1080i / 1080p) mode: Select Position by pressing the ◄
or ► button. Use the ▲, ▼, ◄ or ► button to move the picture.
Reset: Press the ◄ or ► button to select Reset, then press the ENTER E button. You can initialize the setting.
If you use the Screen Fit function with HDMI 720p input, 1 line will be cut at the top, bottom, left and right as in the Overscan
function.
When Double ( À , Œ ) mode has been set in PIP, the Picture Size cannot be set.
ScreenMode→16:9/WideZoom/Zoom/4:3
When setting the picture size to Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS
(Wide Screen Service) image or nothing. Each individual European country requires different picture size so this function is
intended for users to select it.
16:9: Sets the picture to 16:9 wide mode.
Wide Zoom: Magnify the size of the picture more than 4:3.
Zoom: Magnify the size of the picture vertically on screen.
4:3: Sets the picture to 4:3 normal mode.
This function is available in Auto Wide mode.
This function is not available in PC, Component or HDMI mode.
DigitalNR→Off/Low/Medium/High/Auto
If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static
and ghosting that may appear on the screen.
When the signal is weak, select one of the other options until the best picture is displayed.
HDMIBlackLevel→Normal/Low
You can select the black level on the screen to adjust the screen depth.
This function is active only when an external device is connected to the TV via HDMI (RGB signals).
❑
N
■
N
N
■
T
●
●
●
●
●
●
N
N
N
N
N
N
N
N

N
N
■
●
●
●
●
N
N
■
N
■
N
ColourTone :Normal  ▶
Size :AutoWide
ScreenMode :16:9
DigitalNR :Auto
HDMIBlackLevel :Normal
FilmMode :Off
100HzMotionPlus :Standard
 ▼
U Move E Enter R Return
PictureOptions
