Samsung NV51K7770SS/AA User manual

Built-In Electric Wall Oven
User manual
NV51K7770S*
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 1 8/24/2016 12:30:22 PM

2 English
Regulatory Notice
FCC STATEMENT:
This equipment has been tested and found to comply within
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and
receiver
• Connecting the equipment to an outlet that is on a different
• circuit than the radio or TV
• Consulting the dealer or an experienced radio/TV technician
for help.
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is
Subject to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only
channels 1~11 are available. You cannot select any other
channels.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 2 8/24/2016 12:30:22 PM

English 3
Regulatory Notice
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated so there is at least
8 inches (20 cm) between the radiator and your body. This
device and its antenna(s) must not be co-located or operated in
conjunction with any other antenna or transmitter.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated so there is at least 8 inches
(20 cm) between the radiator and your body. This device and
its antenna(s) must not be co-located or operated in conjunction
with any other antenna or transmitter.
2. IC Notice
The term “IC” before the radio certication number only
signies that Industry Canada technical specications were
met. Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only
channels 1~11 are available. You cannot select any other
channels.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 3 8/24/2016 12:30:22 PM

4 English
Contents
ContentsContents
Important safety instructions 5
Introducing your new oven 18
Overview 18
What’s included with your oven 18
Before you begin 19
Energy saving tips 19
Water reservoir 19
Operating the oven 20
Control panel 20
Display 21
Setting the temperature 21
Control Lockout 22
Kitchen Timer 23
Timed cooking 24
Delay Start 25
Using the Temp probe 26
Twin cooking mode temperature setting ranges 27
Oven functions 28
Using the healthy cook feature 34
Using the gourmet cook feature 36
Using the smart control feature 37
Using the oven racks 38
Using the gliding rack 40
Using the divider 41
Using the clean feature 41
Settings 48
Using the Sabbath feature 50
Maintaining your appliance 51
Care and cleaning of the oven 51
Removing the oven doors 53
Replacing the oven doors 54
Changing the oven light 55
Troubleshooting 56
Troubleshooting 56
Information codes 59
Warranty (U.S.A) 60
Warranty (CANADA) 61
Open Source Announcement 63
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 4 8/24/2016 12:30:23 PM

English 5
Important safety instructions
SAVE THESE INSTRUCTIONS
CAUTION
To reduce the risk of re, explosion, electric shock, or personal
injury when using your oven, follow these basic safety
precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric
shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and
others. Please follow them explicitly.
After reading this section, keep it in a safe place for future
reference.
Important safety instructions
Read and follow all instructions before using your oven to
prevent the risk of re, electric shock, personal injury, or
damage when using the oven. This guide does not cover all
possible conditions that may occur. Always contact your service
agent or the manufacturer about problems that you do not
understand.
WHAT YOU NEED TO KNOW ABOUT SAFETY
INSTRUCTIONS
Warnings and important safety instructions in this manual do
not cover all possible conditions and situations that may occur.
It is your responsibility to use common sense, caution, and care
when installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 5 8/24/2016 12:30:23 PM

6 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
Always disconnect the power to the appliance before
servicing by removing the fuse or switching off the circuit
breaker.
• Do not enter the oven.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the room.
• Do not use water on grease res. Turn off the oven to avoid
spreading the ames. Smother the re or ames by closing
the door or use a dry chemical, baking soda, or foam-type
extinguisher.
• Avoid scratching or striking the glass doors and the control
panel. Doing so may lead to glass breakage. Do not cook on
a product with broken glass. Shock, re, or cuts may occur.
STATE OF CALIFORNIA PROPOSITION 65 WARNING
US ONLY
WARNING : This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm.
FOR YOUR SAFETY
When using electrical appliances, you should follow basic
safety precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as
described in this Owner’s Manual.
• Potentially hot surfaces include the oven vent opening,
surfaces near the opening, and crevices around the oven
door.
Proper Installation - Be sure your appliance is properly
installed and grounded by a qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual.
All other servicing should be referred to a qualied
technician.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 6 8/24/2016 12:30:23 PM

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use only dry potholders. Placing moist or damp
potholders on hot surfaces may result in burns from
steam. Do not let the potholder touch hot heating
elements. Do not use a towel or other bulky cloth
instead of a potholder.
• Teach children not to play with the controls or any
other part of the oven.
• For your safety, do not use high-pressure water
cleaners or steam jet cleaners to clean any part of the
oven.
• If the power cord is damaged, it must be replaced
by the manufacturer, its service agent, or similarly
qualied persons to avoid creating a hazard.
• The appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• If there is a re in the oven during self-cleaning, turn
the oven off and wait for the re to go out. Do not
force the door open. The introduction of fresh air at
self-cleaning temperatures may lead to a burst of ame
from the oven. Failure to follow these instructions may
result in severe burns.
• If the oven is heavily soiled with oil, self-clean the oven
before using the oven again. Leaving the oil in place
creates a risk of re.
• Wipe up heavy soil on the oven bottom with a paper
tower or rag before self-cleaning. Self-cleaning the
oven when there is heavy soil on the oven bottom
requires longer cleaning cycles and produces more
smoke.
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure
all packing materials are removed from the appliance
before operating it. Keep plastics, clothes, and paper
away from parts of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or
hanging garments while using the appliance.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 7 8/24/2016 12:30:23 PM

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
WARNING
• Ensure that the appliance is switched off before replacing
the lamp to avoid the possibility of electric shock.
CHILD SAFETY
WARNING
• This appliance is not intended for use by young children
or inrm persons without the adequate supervision of a
responsible adult.
• Young children should be supervised to ensure that they do
not play with the appliance.
• Keep children away from the door when opening or closing
it as they may bump themselves on the door or catch their
ngers in the door.
• During self-cleaning, the surfaces may get hotter than usual.
Keep small children away from the oven when it is in the
self-cleaning mode.
WARNING
Accessible parts may become hot during use. To avoid burns,
young children should be kept away.
ELECTRICAL SAFETY
• Use only the factory installed exible power cord to
connect to the power supply. Do not use a 3rd party
power supply cord kit.
• The appliance should be serviced only by qualied
service personnel. Repairs carried out by unqualied
individuals may cause injury or a serious malfunction.
If your appliance is in need of repair, contact a Samsung
authorized service center. Failure to follow these
instructions may result in damage and void the warranty.
• Flush - mounted appliances may be operated only after
they have been installed in cabinets and workplaces
that conform to the relevant standards. This ensures
that the appliances are installed in compliance with the
appropriate safety standards.
• If your appliance malfunctions or if fractures, cracks, or
splits appear:
• Switch off the oven.
• Unplug the oven from the AC wall outlet.
• Contact your local Samsung service center.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 8 8/24/2016 12:30:23 PM

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use care when opening the door. Let hot air or steam
escape before you remove food from or put food into the
oven.
• Protective liners. Do not use aluminum foil to line the oven
bottoms, except as suggested in this manual. Improper
installation of these liners may result in a risk of electric
shock or re.
• Keep oven vent ducts unobstructed. The oven vent is
located above the right rear surface unit. This area could
become hot during oven use. Never block this vent or place
plastic or heat-sensitive items on it.
• Placement of oven racks. Always place oven racks in the
desired location while the oven is cool. If the rack must be
moved while the oven is hot, use potholders. Do not let the
potholders come in contact with the hot heating element in
the oven.
• Do not allow aluminum foil or a meat probe to contact
the heating elements.
OVEN
• DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR
SURFACES OF THE OVEN. Heating elements may be hot
even though they are dark in color. Interior surfaces of
an oven become hot enough to cause burns. During and
after use, do not touch or let clothing or other ammable
materials contact the heating elements or interior
surfaces of the oven until they have had sufcient time
to cool. Other surfaces of the appliance may become hot
enough to cause burns. Among these surfaces are oven
vent openings and surfaces near these openings, the
oven door, and the window of the oven door.
• Do not heat unopened food containers. The build-up of
pressure may cause the container to burst and result in
injury.
• Do not use the oven to dry newspapers. If overheated,
newspapers can catch re.
• Do not use the oven for a storage area. Items stored in an
oven can ignite.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 9 8/24/2016 12:30:23 PM

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
SELFCLEANING OVENS
Do not clean the door gasket. The door gasket is essential
for a good seal. Care should be taken not to rub, damage,
or move the gasket.
• Never keep pet birds in the kitchen. Birds are
extremely sensitive to the fumes released during an
oven self-clean cycle. Fumes may be harmful or fatal to
birds. Move birds to a well-ventilated room.
• Clean only the parts listed in this manual in the self-
clean cycle. Before self-cleaning the oven, remove the
divider, rack, utensils, and any food.
• Before operating the self-clean cycle, wipe grease and
food soils from the oven. Excessive amounts of grease
may ignite, leading to smoke damage to your home.
• Do not use any commercial oven cleaner or oven liner
protective coating of any kind in or on the outside of
the oven.
• Remove the nickel oven shelves from the oven before
you begin the self-cleaning cycle or they may discolor.
• During use, the appliance becomes hot.
Care should be taken to avoid touching heating
elements inside the oven.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass. They can scratch
the surface which may result in the glass shattering.
CAUTION
Do not attempt to operate the oven during a power failure.
If the power fails, always turn the oven off. If the oven is
not turned off and the power returns, the oven may begin to
operate again. Food left unattended could catch re or spoil.
NV51K7770S_AA_DG68-00857A-01_EN+MES+CFR.indb 10 8/24/2016 12:30:23 PM
