Samsung NQ50H7935ES User manual

imagine the possibilities
Thank you for purchasing this Samsung product.
Combi Steam Built-in
Oven
user manual
NQ50H7935ES
This manual is made with 100 % recycled paper.
Please be advised that the Samsung warranty does NOT cover service calls
to explain product operation, correct improper installation, or perform normal
cleaning or maintenance.
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 1 2014-10-23  11:34:35

English - 2
contents
SAFETY INFORMATION
3
03 Safety information
BEFORE YOU BEGIN
15
15 Setting the clock
16 Setting the energy save mode
16 Switching off the beeper
17 Child safety lock
18 Filling the water tank
19 Setting the water hardness
OVEN USE
20
20 Types of heating
23 Using the steam mode
27 Using the combi steam mode
29 Using the reheat mode
30 Using oven mode
41 Using multi-level cook mode
43 Using the keep warm mode
44 Setting cook time
45 Setting end time
46 Setting delay start
47 Using the auto menu mode
48 Guide to auto menu setting
51 Using the auto defrost mode
53 Test dishes
DESCALING AND CLEANING
54
54 Descale mode
56 Using the steam clean feature
57 Cleaning
58 Changing the lamp
TROUBLESHOOTING AND
INFORMATION CODE
59
59 Troubleshooting
61 information codes
TECHNICAL DATA
62
62 Technical data
63 Product data sheet
OVEN FEATURES
12
12 Oven
13 Oven controls
14 Accessories
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 2 2014-10-23  11:34:35

English - 3
safety information
USING THIS INSTRUCTION BOOKLET
You have just purchased a SAMSUNG oven. Your Owner’s Instructions contain valuable information
on cooking with your oven:
• Safety precautions
• Suitable accessories and cookware
• Useful cooking tips
• Cooking tips
LEGEND FOR SYMBOLS AND ICONS
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
Warning; Fire hazard Warning; Hot surface
Warning; Electricity Warning; Explosive material
Do NOT attempt. Do NOT touch.
Do NOT disassemble. Follow directions explicitly.
Unplug the power plug from the wall
socket.
Make sure the machine is grounded to
prevent electric shock.
Call the service center for help. Note
Important
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE.
Make sure that these safety precautions are obeyed at all
times.
Before using the oven, confirm that the following
instructions are followed.
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 3 2014-10-23  11:34:36

English - 4
01 SAFETY INFORMATION
WARNING
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Appliance should allow to disconnection of the
appliance from the supply after installation.
The disconnection may be achieved by having the plug
accessible or by incorporating a switch in the fixed
wiring in accordance with the wiring rules.
During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside the
oven.
WARNING: Accessible parts may become hot during
use. Young children should be kept away.
A steam cleaner is not to be used.
WARNING: Ensure that the appliance is switched o
before replacing the lamp to avoid the possibility of
electric shock.
WARNING: The appliance and its accessible parts
become hot during use.
Care should be taken to avoid touching heating
elements.
Children less than 8 years of age shall be kept away
unless continuously supervised.
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 4 2014-10-23  11:34:36

English - 5
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
The temperature of accessible surfaces may be high
when the appliance is operating.
The door or the outer surface may get hot when the
appliance is operating.
Keep the appliance and its cord out of reach of
children less than 8 years.
Appliances are not intended to be operated by means
of an external timer or separate remote-control system.
Please put the bent up frame side to the
back, in order to support the restposition
when cooking big loads.
Do not use oven rack for microwave oven mode.
INSTALLATION INSTRUCTIONS
General
Technical Information
Electrical Supply: 230 V ~ 50 Hz
Dimensions (w×h×d)
Set size : W 595 x H 454.2 x D 570
Built in size : W 555 x H 445 x D 548.8
This appliance complies with EU regulations.
Disposal of Packaging and Appliance
Packaging is recyclable.
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 5 2014-10-23  11:34:36

English - 6
01 SAFETY INFORMATION
Packaging may consist of the following materials:
- cardboard;
- polyethylene film (PE);
- CFC-free polystyrene(PS rigid foam).
Please dispose of these materials in a responsible manner
in accordance with government regulations.
The authorities can provide information on how to dispose
of domestic appliances in a responsible manner.
Safety
This appliance should only be connected by a qualified
technician. The Oven is NOT designed for use in a
commercial cooking setting. It should be used exclusively
for cooking food in a home setting. The appliance is hot
during and after use.
Exercise caution when young children are present.
Electrical Connection
The house mains to which the appliance is connected
should comply with national and local regulations.
Appliance should allow to disconnection of the appliance
from the supply after installation. The disconnection
may be achieved by having the plug accessible or by
incorporating a switch in the fixed wiring in accordance
with the wiring rules.
Install in the Cabinet
Kitchen Cabinets in contact with the oven must be heat-
resistant up to 100 °C.
Samsung will take no responsibility for damage of cabinets
from the heat.
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 6 2014-10-23  11:34:36

English - 7
Fig1. Slide the oven partly into the recess. Lead the
connection cable to the power source.
Fig2. Slide the oven completely into the recess.
Fig3. Fasten the oven using the two screws (4 X 25 mm)
provoded.
Fig4. Make the electrical connection.
Check that the appliance works.
Fig1 Fig3
Fig2 Fig4
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 7 2014-10-23  11:34:49

English - 8
01 SAFETY INFORMATION
Building-in dimensions
Min. 550
Min. 564~568
341
555
200 cm²
454.2
Min. 50
200 cm²
Min. 446
Max. 450
Space for
power outlet
(30 ¢ Hole)
445
358
85
595 549
21
600
Be sure to hold the appliance with
2side handles and door handle
when unpacking the product.
Side
handle
Side
handle
Door handle
Built-under Dimensions
Min.
550
Min. 564
Max. 568
Min. 446
Max. 450 50
200 cm²
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 8 2014-10-23  11:34:50

English - 9
CLEANING YOUR OVEN
1.
Cleaning inside the cavity.
• Lift up both left and right shelves at
the front (1). Move them towards the
middle (2) and pull them out. Wipe any
leftovers from the ceiling or walls using
a neutral cloth dipped in detergent.
• When completed, install both shelves
back into the correct positions.
• Even solid, dicult stains or dry leftovers
can be removed by using the steam clean process.
2.
Cleaning the oven surface, control panel and window.
• The surface of the oven can be wiped with a wet dish
towel, followed by a dry cloth to remove the water
completely.
• Do not use force when cleaning the control panel as it
can be damaged while cleaning.
• Clean the transparent window with a neutral
detergent-dipped dish towel and then with a dry cloth
until no water remains.
3.
Cleaning the water tank and the tray.
• Wipe them with a sponge dipped in a neutral detergent
and then rinse them with water.
4. Cleaning the accessories.
• Wipe them with a neutral detergent and dry them
before inserting them back into the cooking cavity.
• Do not use force on the accessories when wiping
them with a scrubber, as this may damage the coated
surface.
21
NQ50H7935ES_ET_DG68-00471H-01_EN.indb 9 2014-10-23  11:34:50

English - 10
01 SAFETY INFORMATION
CHANGING THE LAMP
Replacing the rear oven lamp and cleaning the glass cap
1. Take o the cap by turning
counterclockwise.
2. Remove the metal ring and the sheet
ring and clean the glass cap.
3. If necessary, replace the bulb with a
25watt, 230 V, 300 °C heat - resistant oven light bulb.
4. Fit the metal and the sheet ring to the
glass cap.
5. Replace the glass cap.
WARNING
This appliance is intended only for domestic use.
This appliance must only be used for food preparation.
Open the cooking compartment door carefully. Hot steam will escape.
Never store combustible items in the cooking compartment.
Never trap cables of electrical appliances in the hot cooking compartment door. The cable
insulation could melt.
Never take accessories out of the appliance without using oven gloves.
Do not clean the appliance immediately after switching it o. The water in the evaporator dish
is still hot. Wait until the appliance has cooled down.
Incorrect repairs are dangerous. Repairs may only be carried out by one of our experienced
after-sales engineers. If the appliance is faulty, switch it o using the fuse in the fuse box or
disconnect the appliance at the mains. Contact the after-sales service.
Do not use the cooking compartment door as a shelf.
Do not store any food in the appliance. This can lead to corrosion.
Use only the accessories provided. They are specially designed for your appliance.
When steaming in the perforated steam dish, you can insert the baking tray underneath.
Dripping liquid is caught. (Steam function model only)
Ovenware must be heat and steam resistant.
Do not use ovenware that shows signs of rust. Even the smallest spots of rust can lead to
corrosion in the cooking compartment.
Metal
ring
Sheet
ring
Glass
cap
Sheet
ring
Bulb
