Samsung PS-37S4H User manual

PDP-TELEVISION
(PLASMA DISPLAY PANEL)
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
This device is a Class B digital apparatus.
ON-SCREEN MENUS
PICTURE INPICTURE (PIP)
COLOUR WEAKNESS ENHANCEMENT MODE
MYCOLOUR CONTROL
TELETEXT (OPTION)
SRS TRUSURROUNDXT
DIGITAL NATURAL IMAGE ENGINE
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 1

Precautions When Using the Still Image
English - 2
The still image may cause permanent damage to the TV screen.
• Digital Ready TV: When you select
the regular screen (4:3) mode to
watch an SD-grade digital
broadcast (and the set-top box
output is 480p).
Although digital broadcasting must be in
the wide screen (16:9) HD format,
broadcasters sometimes show programs
made originally in the regular screen
format (4:3) by converting the signals into
digital form, in which case the left and
right side edges of the screen are
cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the left, right and
the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave traces.
• Digital Ready TV: When you select
the wide screen (16:9) mode to
watch an SD-grade digital
broadcast (and the set-top box
output is 1080i).
• Digital Ready TV: When the
TV receives HD-grade signals
(and the set-top box output is 1080i).
When you watch a digital HD-grade
broadcast on a regular (4:3) TV with the
screen size "16:9" or "Panorama" selected,
you will be able to watch the program but
the top and bottom edges of the screen will
be cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the top, bottom
and the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave traces.
BN68-00745A-00Eng_0813 8/18/04 1:30 PM Page 2

Precautions When Using the Still Image (continued)
English - 3
• Integrated Digital TV
(Wide-screen): When the TV
receives SD-grade (regular)
broadcasting signals (receives
480p regular signals).
• Digital Ready TV (wide-screen):
digital TV: When the TV receives
SD-grade (regular) broadcasting
signals (with a set-top box).
• When you watch an analogue
(regular) broadcast on a
wide-screen TV (with the 4:3
screen mode selected).
Although digital broadcasting must be in
the wide screen (16:9) HD format,
broadcasters sometimes show programs
made originally in the regular screen
format (4:3) by converting the signals into
digital form, in which case the left and
right side edges of the screen are
cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the left, right and
the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave traces.
• When you watch a DVD, CD or a video
in wide screen (21:9) format on a wide-
screen (16:9) TV.
• When you connect a computer or a
game console to the TV and select the
4:3 screen mode.
If you connect a DVD player, computer or
a game console to the wide-screen TV
and watch a movie or play a game in
regular (4:3) or wide (21:9) screen mode,
the left and right side edges, or the top
and bottom edges of the screen will be
cropped.
Do not leave the screen in pause mode
for extended periods of time as you may
experience the same problem with
products by other manufacturers.
Note : If the borders at the left, right and
the center of the screen remain
fixed for an extended period of time,
the amounts of light transmission
will also remain varied and as a
result the borders may leave
traces.
BN68-00745A-00Eng_0813 8/18/04 1:30 PM Page 3

User Instructions
◆Screen Image retention
Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the
plasma monitor panel for more than 2 hours as it can cause screen image retention. This image
retention is also known as “screen burn”. To avoid such image retention, reduce the degree of
brightness and contrast of the screen when displaying a still image.
◆Height
The PDP can normally operate only under 2000m in height. It might abnormally function at a place
over 2000m in height and do not install and operate there.
◆Heat on the top of the PDP TV
The top side of the product may be hot after long periods of use as heat dissipates from the panel
through the vent hole in the upper part of the product.
This is normal and does not indicate any defect or operation failure of the product.
However, children should be prevented from touching the upper part of the product.
◆The product is making a ‘cracking’ noise.
A ‘cracking’ noise may occur when the product contracts or expands due to a change of surrounding
environment such as temperature or humidity. This is normal and not a defect of the unit.
◆Cell Defects
The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which require
sophisticated technology to produce. However, there may be few bright or dark pixels on the screen.
These pixels will have no impact on the performance of the product.
◆Avoid operating the TV at temperatures below 5°C(41°F)
◆Warranty
-Warranty does not cover any damage caused by image retention.
-Burn-in is not covered by the warranty.
English - 4
BN68-00745A-00Eng_0813 8/18/04 1:30 PM Page 4

DNIeTM (Digital Natural Image engine)
This feature bring you more detailed image with 3D noise
reduction, detail enhancement, contrast enhancement and
white enhancement. New image compensation algorithm gives
brighter, clearer, much detailed image to you. DNIeTM
technology will fit every signals into your eyes.
Checking Parts
Owner’s Instructions
Remote Control/
AAA Batteries
Power Cord
S-VIDEO Cable
PC Cable
DVI Cable
Antenna Cable
PC Audio Cable
Component Cables
(RCA)
Sold Separately
English - 5
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 5

Contents
◆FOREWORD
■Precautions When Using the Still Image ....................................................... 2
■User Instructions............................................................................................ 4
◆CONNECTING AND PREPARING YOUR DISPLAY
■Your New Plasma Display Panel................................................................... 8
■Infrared Remote Control ................................................................................ 10
■Inserting the Batteries in the Remote Control................................................ 11
■Assembling the Stand-Base .......................................................................... 11
■Installing the Display on the Wall Attachment Panel ..................................... 12
■Connecting to an Aerial or Cable Television Network ................................... 14
■Connecting a Satellite Receiver or Decoder.................................................. 14
■Switching On and Off..................................................................................... 15
■Placing in Standby Mode............................................................................... 15
■Becoming Familiar with the Remote Control ................................................. 16
■Setting Up Your Remote Control ................................................................... 17
■Plug & Play Feature....................................................................................... 18
■Choosing Your Language.............................................................................. 19
◆SETTING THE CHANNELS
■Storing Channels Automatically..................................................................... 20
■Storing Channels Manually............................................................................ 21
■Skipping Unwanted Channels ....................................................................... 23
■Sorting the Stored Channels ......................................................................... 24
■Assigning Names to Channels ...................................................................... 25
■Using the LNA (Low Noise Amplifier) Feature............................................... 26
■Activating the Child Lock ............................................................................... 27
■Displaying Information ................................................................................... 28
◆USING YOUR DISPLAY
■Changing the Picture Standard ..................................................................... 28
■Adjusting the Picture Settings........................................................................ 29
■Adjusting the Picture Settings (PC or DVI Mode) .......................................... 30
■Setting the Picture (PC Mode)....................................................................... 31
■Using the Fine Tune ...................................................................................... 33
■Viewing the Channel Scan Picture ................................................................ 34
■Freezing the Current Picture ......................................................................... 34
■Selecting the Picture Size.............................................................................. 35
■Selecting the Film Mode ................................................................................ 36
■DNIeTM (Digital Natural Image engine) ............................................... 36
■Setting the My Colour Control (Easy Control) ............................................... 37
■Setting the My Colour Control (Detail Control) .............................................. 38
■Setting the Blue Screen................................................................................. 39
■Setting the Melody Sound ............................................................................. 40
English - 6
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 6

Contents (continued)
◆USING YOUR DISPLAY (continued)
■Using the Colour Weakness Enhancement Feature ..................................... 41
■Viewing the Picture In Picture (PIP) .............................................................. 42
■Using the Digital NR (Noise Reduction) Feature ........................................... 45
■Protecting the Screen Burning....................................................................... 46
■Changing the Sound Standard ...................................................................... 47
■Adjusting the Sound Settings ........................................................................ 48
■Adjusting the Volume Automatically .............................................................. 49
■Setting the TruSurround XT........................................................................... 50
■Selecting the Internal mute............................................................................ 51
■Selecting the Sound Mode (depending on the model) .................................. 52
■Setting the Sleep Timer ................................................................................. 53
■Setting and Displaying the Current Time....................................................... 54
■Switching the Television On and Off Automatically ....................................... 55
■Viewing an External Signal Source ............................................................... 56
◆USING THE TELETEXT FEATURE
■Teletext Feature ............................................................................................ 57
■Displaying the Teletext Information ............................................................... 58
■Selecting Display Options.............................................................................. 59
■Selecting a Teletext Page.............................................................................. 60
◆ADDITIONAL INFORMATION AND CONNECTIONS
■Connecting to the External Devices .............................................................. 61
■Connecting to the S-Video Input.................................................................... 62
■Connecting to the DVI Input .......................................................................... 63
■Connecting to the PC Input ........................................................................... 63
■Connecting to the Component Input.............................................................. 64
■Connecting and Using the Home Theater System ........................................ 65
■Setting up Your PC Software (Windows only) ............................................... 66
■Input Mode (PC/DVI) ..................................................................................... 67
■Pin Configurations ......................................................................................... 68
◆RECOMMENDATIONS FOR USE
■Troubleshooting: Before Contacting Service Personnel................................ 69
■Programming the Remote Control for Other Components ............................ 70
☛➢
Press Important Note
Symbols
English - 7
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 7

Your New Plasma Display Panel
Front Panel
➢
The actual configuration on your PDP may be different,
depending on your model.
SOURCE
External input selection.
MENU
Menu display.
- VOL +
Volume adjustment.
Also used to select or adjust items on the
on-screen menu.
CH
Channel selection. Auto power On.
Also used to move up or down in the on-screen
menu.
Confirm your choice (Store or Enter).
a
I /
Press to turn the PDP on and off.
Power Indicator
-Power Off: Blue
-Power On: Off
b
Speaker
a c
b
Remote Control Signal Receiver
Aim the remote control towards this spot on
the PDP.
c
Touch button
Touch the printed names
of each button using your
finger to operate it.
English - 8
BN68-00745A-00Eng_0813 8/18/04 1:31 PM Page 8

Your New Plasma Display Panel (continued)
➢
The actual configuration on your PDP may be different,
depending on your model.
Rear Panel
➢For further details about connection, refer to pages 61~65.
a) DVI INPUT (DVI-D / L-AUDIO-R)
Connect to the digital video and audio output jack
of a device with DVI output.
b) MONITOR OUT (VIDEO / L-AUDIO-R)
Outputs for external devices.
c) PC INPUT (RGB IN / AUDIO)
Connect to the video and audio output jack on
your PC.
d) ONLY FOR SERVICE
Connector for service only.
e) S-VIDEO / L-AUDIO-R (AV2)
Video and audio inputs for external devices with
an S-Video output, such as a camcorder or VCR.
f) VIDEO / L-AUDIO-R (AV1, AV2)
Video and audio inputs for external devices, such
as a camcorder or VCR.
g) COMPONENT1, COMPONENT2
Video (Y/Pb/Pr) and audio (L-AUDIO-R) inputs for
Component.
h) ANT IN VHF/UHF (75Ω)
75ΩCoaxial connector for Aerial/Cable Network.
i) POWER IN
Connect the supplied power cord.
English - 9
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 9

Infrared Remote Control
➢The performance of the remote control may be affected by bright light.
PICTURE EFFECT SELECTION
PICTURE SIZE/
TELETEXT SIZE SELECTION
MENU DISPLAY/
TELETEXT INDEX
DNIe ON/DEMO/OFF
MOVE TO THE REQUIRED
MENU OPTION/
ADJUST AN OPTION VALUE
RESPECTIVELY
TURNS THE PDP ON AND OFF
FASTEXT TOPIC SELECTION
INFORMATION DISPLAY/
TELETEXT REVEAL
TV MODE SELECTION
EXIT TELETEXT
(DEPENDING ON THE MODEL)
DIRECT CHANNEL SELECTION
EXTERNAL INPUT SELECTION/
TELETEXT PAGE HOLD
AUTOMATIC SWITCH-OFF/
TELETEXT SUB-PAGE
CONFIRM YOUR CHOICE
(STORE OR ENTER)
NEXT CHANNEL/
TELETEXT NEXT PAGE
SOUND MODE SELECTION
IF YOUR REMOTE CONTROL IS NOT
FUNCTIONING PROPERLY, TAKE
OUT THE BATTERIES AND PRESS
THE RESET BUTTON FOR ABOUT
2~3 SECONDS. RE-INSERT THE
BATTERIES AND TRY USING THE
REMOTE CONTROL AGAIN.
TruSurround XT
MODE SELECTION
PREVIOUS CHANNEL/
TELETEXT PREVIOUS PAGE
PIP FUNCTIONS:
-PIP ACTIVATING OR DEACTIVATING
(PIP ON)
-SWAPPING THE MAIN AND THE SUB
PICTURE (SWAP)
-LOCATION SELECTION (POSITION)
-SOURCE SELECTION (SOURCE)
-SIZE SELECTION (SIZE)
-SCAN
-SELECTING THE CHANNEL OF SUB
PICTURE (P )
MAKE THE REMOTE CONTROL WORKS
FOR TV, VCR, CATV, DVD PLAYER, AND
STB
SOUND EFFECT SELECTION
TELETEXT CANCEL
VOLUME INCREASE
TEMPORARY SOUND SWITCH-OFF
VOLUME DECREASE
TELETEXT DISPLAY/
MIX BOTH TELETEXT INFORMATION
AND THE NORMAL BROADCAST
PICTURE STILL
WHEN YOU PRESS A BUTTON , ‘
’
APPEARS ALONG WITH SELECTED MODE
(TV, VCR, CATV, DVD, OR STB) AND
REMAINING BATTERIES ON LCD
VCR/DVD FUNCTIONS:
-REWIND (REW)
-STOP
-PLAY/PAUSE
-FAST FORWARD (FF)
REMOTE CONTROL SETUP
English - 10
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 10

You must insert or replace the batteries in the remote control when
you:
◆Purchase the PDP
◆Find that the remote control is no longer operating
correctly
1Remove the cover on the rear of the remote control by pressing
the symbol ( ) downwards and then pulling firmly to remove it.
2Insert two R03, UM4, “AAA” 1.5V or equivalent batteries taking
care to respect the polarities:
◆ - on the battery against - on the remote control
◆ + on the battery against + on the remote control
3Replace the cover by aligning it with the base of the remote
control and pressing it back into place.
Do not mix battery types, i.e. alkaline and manganese.
Inserting the Batteries in the Remote Control
Assembling the Stand-Base
1Assemble the PDP with the stand and firmly secure the PDP using
4 screws provided.
➢◆
Two or more people should carry the PDP. Never lay the
PDP on the floor because of possible damage to the screen.
Always store the PDP upright.
English - 11
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 11

Installing the Display on the Wall Attachment Panel
Wall Mount Bracket
Mounting Kits (Sold Separately)
4 EA 4 EA
Plastic Hanger Screws
Installation Notes
◆ Do not install the PDP on any place other than vertical walls.
◆ To protect the performance of the PDP and prevent troubles, avoid the followings:
- Do not install next to smoke and fire detectors.
- Do not install in an area subjected to vibration or high voltage.
- Do not install near or around any heating apparatus.
◆ Use only recommended parts and components.
English - 12
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 12

Installing the Display on the Wall Attachment Panel (continued)
➢The exterior of the PDP may be different than the picture.
(Assembly and installation of the plastic hanger is the same.)
1Remove the screws from the back of the PDP.
2Use the screws and assemble the plastic hanger.
3Tighten the screws of the plastic hanger to the back side of the PDP.
4Put the 4 pegs on the PDP in the grooves of the wall mount bracket and pull down on the PDP (!) to
secure it to the wall mount bracket (@). Tighten the screws as shown (#) so that the PDP cannot be
separated from wall mount bracket.
PDP panel
Wall attachment panel bracket Wall
☛◆Please ask the installers to install the wall mount bracket.
◆Please be sure to check if the plastic hanger is
completely secured on both the left and right side after
hanging the PDP on the wall mount bracket.
◆Please avoid catching your fingers while installing and
adjusting the angle.
◆Please tightly secure the wall mount bracket to the wall
to avoid injury from a falling PDP.
English - 13
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 13

In order to watch television programmes broadcast via a satellite
network, you must connect a satellite receiver to the rear of the
PDP. Also, in order to descramble a coded transmission signal, you
must connect a decoder to the rear of the PDP.
Using a Coaxial cable
Connect a coaxial cable to the:
◆Receiver (or Decoder) output socket.
◆Television aerial input socket.
➢If you wish to connect both a satellite receiver (or decoder)
and a VCR, you should connect the:
◆Receiver (or Decoder) to the VCR
◆VCR to the PDP
Otherwise, connect the receiver (or decoder) directly to the
PDP.
Connecting a Satellite Receiver or Decoder
Rear of the PDP
Satellite Receiver/
Decoder
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
1In the first three cases, connect the aerial or network input cable to
the ANT IN jack on the rear of the PDP.
2If you are using an indoor aerial, you may need to turn it when
tuning your PDP until you obtain a picture that is both sharp and
clear.
For further details, refer to:
◆“Storing Channels Automatically” on page 20
◆“Storing Channels Manually” on page 21
➢When installing or re-installing your PDP, be sure to use the
supplied coaxial antenna cable. If you connect using a different
coaxial cable, there is risk of noise or interference to the screen
image. (You must not use another general purpose cable.
Use the 3M/5M/7M cable supplied by Samsung.)
Connecting to an Aerial or Cable Television Network
Rear of the PDP
Cable Television
Network
or
or
English - 14
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 14

The mains lead is attached to the rear of your PDP.
1Plug the mains lead into an appropriate socket.
Result:The standby indicator on the front of the PDP lights up.
➢
The main voltage is indicated on the rear of the PDP and
the frequency is 50 or 60Hz.
2Press the “ I / ” button on the front of the PDP (or POWER ()
button on the remote control) to switch the PDP on.
Result:The programme that you were watching last is
re-selected automatically.
➢
If you have not yet stored any channels, No clear picture
appears. Refer to “Storing Channels Automatically” on page
20 or “Storing Channels Manually” on page 21.
3To switch your PDP off, press the “ I / ”button again.
Your PDP can be placed in standby mode, in order to reduce the
Power consumption.
The standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
1Press the POWER ()button on the remote control.
Result:The screen is turned off and the standby indicator on
the front of the PDP lights.
2To switch the PDP back on, simply press the POWER ()button
again or a numeric button.
➢
You can also switch on by pressing the Por button.
Switching On and Off
Placing in Standby Mode
TV
TV
Front of the PDP
English - 15
BN68-00745A-00Eng_0813 8/18/04 1:31 PM Page 15

Becoming Familiar with the Remote Control
The remote control is used mainly to:
◆Change channels and adjust the volume
◆Display the on-screen menu system
The following table presents the most frequently used buttons and
their functions.
Button Viewing Function Menu Function
Used to display the next -
stored channel.
Used to display the
-
previous stored channel.
to Used to display the corresponding channels.
➢For double digit channels, the second digit must be
pushed immediately after the first. Failure to do this will
result in a single digit channel being displayed.
SLEEP Used to select a preset time interval (off - 30 - 60 - 90 - 120 -
150 - 180).
Used to increase the -
volume.
Used to decrease the
-
volume.
MUTE Used to switch the sound off temporarily.
➢To turn the sound back on, press this button again, or
press the or button.
MENU Used to display the Used to return to the previous
on-screen menu system. menu or normal viewing.
- Used to:
◆Display a submenu
containing selections for
the current menu option
◆Increase/decrease a
menu option value
- Used to confirm your choice.
EXIT/TV - Used to exit from the menu
system and return to normal
viewing directly.
English - 16
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 16

This PDP’s remote control can operate VCR, Cable box, DVD, or
Set-Top Box, in addition to controlling the PDP.
➢The remote control is not compatible with the TV
manufactured by another company.
1Turn off your VCR, Cable box, DVD or Set-Top Box.
2Press the SELECT button.
Mode is changed whenever SELECT button is pressed.
3Press the POWER ()button on the remote control.
The component you select should turn on. If it turns on,
your remote control is now set correctly.
4Once your remote control is set up, press the SELECT button any
time you want to use the remote control to operate your VCR,
Cable box, DVD or Set-Top Box.
➢
When your remote control is in the VCR, CATV, DVD or
STB mode, the volume buttons still control your television’s
volume.
Setting Up Your Remote Control
➢To program the cable receiver controls:
◆Press the SELECT button to select CATV.
◆Point the remote control at the cable receiver and press
the SET button. Then press the company code number(s)
for the component in page 70.
Ex) If the component is manufactured by Oak, press 026.
➢To program the VCR controls:
◆Press the SELECT button to select VCR
◆Point the remote control at the VCR and press the SET
button. Then press the company code number(s) for the
component in page 71.
➢To program the DVD controls:
◆Press the SELECT button to select DVD
◆Point the remote control at the DVD and press the SET
button. Then press the company code number(s) for the
component in page 70.
VCR
English - 17
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 17

When the television is initially powered ON, several basic customer
settings proceed automatically and subsequently. The following
settings are available.
1If the television is in standby mode, press the POWER ()button
on the remote control.
Result:The message Plug & Play is displayed, then the
Language menu is automatically displayed a few
seconds later.
2Select the appropriate language by pressing the …or †button.
3Press the ENTER ()button to confirm your choice.
Result:The message Antenna Input Check is displayed.
4Make sure that the antenna is connected to the TV, then press
the ENTER ()button.
Result:The Area menu is displayed.
5Select your Area by pressing the …or †button.
6Press the ENTER ()button to confirm your choice.
Result:The Auto Store menu is displayed.
7To start the search, press the ENTER ()button.
Result:The search will end automatically. Channels are sorted
and stored in an order which reflects their position in
the frequency range (with lowest first and highest last).
When it has finished, the Clock Set menu is displayed.
➢To stop the search before it has finished or return to normal
viewing, press the MENU ()button.
➢Press the ENTER ()button to set the clock.
8Press the œor √button to move to the hour or minute.
Set the hour or minute by pressing the …or †button.
9When it has finished, the message Enjoy Your Watching is
displayed, then the channel which has been stored will be
activated.
Plug & Play Feature
Language
Move Enter
Asia/W.Europe
CIS/E.Europe
China
Hong Kong/UK
Australia
NZL/Indonesia
South Africa
▼ More
Area
Antenna Input Check
Plug & Play
Enter
Enjoy Your Watching
Press ENTER to start Plug & Play
Start
Plug & Play
Enter Exit
Press ENTER to start channel memory
40 MHz
0%
Start
Auto Store
Enter Stop
Channel store in process
57 MHz
1%
Auto Store
Enter Stop
Clock
Adjust Move Stop
Hour Min am/pm
07 05 am
Stop
Move Enter
English - 18
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 18

If you want to reset this feature...
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Setup.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the …or †button to select Miscellaneous.
Press the ENTER ()button.
Result:The options available in the Miscellaneous group are
displayed.
5Press the …or †button to select Plug & Play.
Press the ENTER ()button.
Result:The message Plug & Play is displayed.
6For further details on how to set, refer to the opposite page.
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Setup.
Result:The options available in the Setup group are displayed.
3Press the ENTER ()button.
4Press the …or †button to select Language.
Press the ENTER ()button.
Result:The available languages are listed.
5Select the appropriate language by pressing the …or †button.
6Press the ENTER ()button to confirm your choice.
7When you are satisfied with your choice, press the EXIT/TV ()
button to return to normal viewing.
Plug & Play Feature (continued)
Choosing Your Language
Time √√
Language : English √√
Digital NR : On √√
Miscellaneous √√
PC Setup √√
Colour Weakness :Off √√
Burn Protection √√
Setup
Move Enter Return
Melody : On √√
Plug & Play √√
Blue Screen : Off √√
Miscellaneous
Move Enter Return
TV
TV
Time √√
Language : English √√
Digital NR : On √√
Miscellaneous √√
PC Setup √√
Colour Weakness :Off √√
Burn Protection √√
Setup
Move Enter Return
TV
Time
Language : English
Digital NR : On √√
Miscellaneous √√
PC Setup
Colour Weakness :Off √√
Burn Protection
Setup
Move Enter Return
TV
English - 19
BN68-00745A-00Eng_0805 8/10/04 6:53 PM Page 19

You can scan for the frequency ranges available to you, (availability
depends on your country). Automatically allocated programme
numbers may not correspond to actual or desired programme
numbers. However you can sort numbers manually and clear any
channels you do not wish to watch.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:
The options available in the Channel group are displayed .
3Press the ENTER ()button.
4Press the …or †button to select Area.
Press the ENTER ()button.
Result:The countries available are listed.
5Select your country (or area) by pressing the …or †button.
6Press the ENTER ()button to confirm your choice.
7Press the …or †button to select Auto Store.
Press the ENTER ()button.
Result:The Auto Store menu is displayed.
8Press the ENTER ()button to start the search.
Result:The search will end automatically. Channels are sorted
and stored in an order which reflects their position in
the frequency range, (with lowest first and highest last).
When it has finished, the Channel Sort menu is
displayed.
➢To stop the search before it has finished, press the
MENU ()button.
➢When the channels have been stored, you can:
◆Sort them in the order required (see page 24)
◆Clear a channel (see page 23)
◆Fine-tune channel reception if necessary (see page 33)
◆Assign a name to the stored channels (see page 25)
◆Activate/deactivate the Digital Noise Reduction feature
(see page 45)
9Select the channel that you wish to move by pressing the …or †
button. Press the ENTER ()button.
10 Select the number of the programme to which the channel is to
be moved by pressing the …or †button.
Press the ENTER ()button.
Result:The channel is moved to its new position and
all other channels are shifted accordingly.
11 Repeat Steps 8to 9until you have moved all the channels to
the required programme numbers.
Storing Channels Automatically
Area : Asia/W.Europe √√
Auto Store √√
Manual Store √√
Edit √√
Fine Tune √√
Ch. Scan √√
Channel
Move Enter Return
TV
Area :
Auto Store
Manual Store
Edit
Fine Tune
Ch. Scan
Channel
Move Enter Return
TV
Asia/W.Europe
CIS/E.Europe
China
Hong Kong/UK
Australia
NZL/Indonesia
†
Area : Asia/W.Europe
√√
Auto Store √√
Manual Store √√
Edit √√
Fine Tune √√
Ch. Scan √√
Channel
Move Enter Return
TV
Channel store in process
57 MHz
1%
Stop
Auto Store
Enter Return
Sort
TV
2
-----
✽
3
-----
✽
4
-----
✽
5
-----
✽
6
-----
✽
Prog.
Move Enter Return
English - 20
BN68-00745A-00Eng_0813 8/18/04 1:31 PM Page 20
