Samsung SP50L7HX User manual

DLP TV
SP50L7HX
SP56L7HX
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
PICTURE INPICTURE (PIP)
COLOUR WEAKNESS ENHANCEMENT MODE
MYCOLOUR CONTROL
SRS TruSurroundXT
DIGITAL NATURAL IMAGE ENGINE
This device is a Class B digital apparatus.
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 1

1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 2

English - 3
Contents
◆CONNECTING AND PREPARING YOUR TELEVISION
■Control Panel of Your Television ................................................................... 5
■Connection Panel of Your Television ............................................................ 6
■Connecting to an Aerial or Cable Television Network ................................... 8
■Connecting a Satellite Receiver or Decoder.................................................. 8
■Infrared Remote Control ................................................................................ 9
■Inserting the Batteries in the Remote Control................................................ 10
■Switching Your Television On and Off........................................................... 11
■Placing Your Television in Standby Mode..................................................... 11
■Becoming Familiar with the Remote Control ................................................. 12
■Plug & Play Feature....................................................................................... 13
■Choosing Your Language.............................................................................. 14
◆USING YOUR TELEVISION
■Storing Channels Automatically..................................................................... 15
■Storing Channels Manually............................................................................ 16
■Skipping Unwanted Channels ....................................................................... 18
■Sorting the Stored Channels ......................................................................... 19
■Activating the Child Lock ............................................................................... 20
■Assigning Names to Channels ...................................................................... 21
■Fine Tuning Channel Reception.................................................................... 22
■Using the LNA (Low Noise Amplifier) Feature............................................... 23
■Viewing the Channel Scan Picture ................................................................ 23
■Displaying Information ................................................................................... 24
■Freezing the Current Picture ......................................................................... 24
■Changing the Picture Standard ..................................................................... 25
■Adjusting the Picture Settings........................................................................ 26
■Selecting the Picture Size.............................................................................. 27
■Using the Digital NR (Noise Reduction) Feature ........................................... 28
■DNIeTM (Digital Natural Image engine) ............................................... 28
■Setting the My Colour Control - (Easy Control) ............................................. 29
■Setting the My Colour Control - (Detail Control) ............................................ 30
☛➢
Press Important Note
Symbols
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 3

English - 4
Contents (continued)
◆USING YOUR TELEVISION (continued)
■Setting the Film Mode.................................................................................... 31
■Viewing the Picture In Picture (PIP) .............................................................. 32
■Changing the Sound Standard ...................................................................... 34
■Adjusting the Sound Settings ........................................................................ 35
■Setting the SRS TSXT................................................................................... 35
■Adjusting the Volume Automatically .............................................................. 36
■Enjoying the Sound of External Speakers..................................................... 37
■Selecting the Sound Mode (depending on the model) .................................. 38
■Setting and Displaying the Current Time....................................................... 39
■Setting the Sleep Timer ................................................................................. 40
■Switching the Television On and Off Automatically ....................................... 41
■Setting the Blue Screen................................................................................. 42
■Setting the Melody Sound ............................................................................. 42
■Using the Colour Weakness Enhancement Feature ..................................... 43
■Setting the Picture in PC Mode ..................................................................... 44
■Viewing an External Signal Source ............................................................... 45
■Assigning Names to External Sources .......................................................... 46
◆USING THE TELETEXT FEATURE
■Teletext Feature ............................................................................................ 47
■Displaying the Teletext Information ............................................................... 48
■Selecting Display Options.............................................................................. 48
■Selecting a Teletext Page.............................................................................. 49
◆ADDITIONAL INFORMATION AND CONNECTIONS
■Connecting to the External Input/Output ....................................................... 50
■Connecting to the Audio Output .................................................................... 51
■Connecting to the S-Video Input.................................................................... 51
■Connecting to the Digital Input ...................................................................... 52
■Connecting to the Component Input.............................................................. 53
■Connecting to the PC Input ........................................................................... 53
■Setting up Your PC Software (Windows only) ............................................... 54
■PC/HDMI(DVI) Input Mode ............................................................................ 55
■Redirecting an Input to the External Output .................................................. 56
◆RECOMMENDATIONS FOR USE
■Setting Up Your Remote Control ................................................................... 57
■Programming the Remote Control for Other Components ............................ 58
■Replacing the Lamp....................................................................................... 60
■Troubleshooting: Before Contacting Service Personnel................................ 61
■Technical Specifications ................................................................................ 62
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 4

English - 5
Control Panel of Your Television
➢
The actual configuration on your TV may be different, depending on
your model.
Auto timer on has been set.
(Timer indicator)
Press to switch between viewing
TV programs and signals from
connected components.
Press to change channels and
to move between items on
the on-screen menu.
Press to activate (or change)
a particular item.
Aim the remote control
towards this spot on the TV.
Press to see the on-screen
menu.
Press to decrease or increase
the volume and to select
items when using the on-
screen menu.
Standby state.
(Standby indicator; Red)
Press and hold the POWER
button for a few seconds to
turn the TV on or off.
➢Touching the control panel using your finger will light up Blue LEDs for all buttons. At this
moment, locate the desired button and touch it to operate.
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 5

English - 6
Connection Panel of Your Television
➢
The actual configuration on your TV may be different, depending on
your model.
➢It takes about 30 seconds for the TV to warm up, so normal brightness may not appear
immediately.
➢The TV has a fan to keep the inside lamp from overheating. You’ll occasionally hear it working.
The Information window appears as
illustrated above while the TV is turning on.
(Refer to the TV set’s display for animation
details). When successfully turned on, an
animated “Smile” figure appears and then
fades out slowly.
When these indicators appear, there is a
possible problem with the TV.
Lamp or other component
may be defective. Please
contact a certified
technician.
Check if the ventilation hole
on the rear of the set is
blocked, because if the inner
temperature is too high, the
power will shut off.
A cooling fan inside the set is
not operating normally.
The TV’s rear cover is not
properly shut.
Appears while the TV is
turning off.
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 6

English - 7
Connection Panel of Your Television (continued)
➢
The actual configuration on your TV may be different, depending on
your model.
ŒANT IN
Coaxial connector for aerial or cable
network.
´S-Video Input
Connect to S-Video output jacks of an
S-VHS VCR or DVD player.
ˇAudio/Video Input
Connect to the audio/video output jacks of
VCRs, DVD players and similar devices.
¨COMPONENT Input
Connect to the audio and video outputs of
DVD or DTV Set-Top Box.
480i/480p/576i/576p/720p/1080i Y, PBand
PRvideo signal outputs are available.
ˆAudio Output
Connect to the external audio amplifier.
ØSCART Input/Output
Inputs or outputs for external devices, such
as VCR, DVD, video game device or video
disc players.
∏PC Input
Connect to the PC audio/video outputs.
”DVI Audio Input
Connect to the audio output jacks for device
with DVI output.
’HDMI/DVI Input
Connect to the digital device with HDMI or
DVI output.
˝SERVICE Jack
It is for repairs and software upgrades.
Switch the TV on and off
Press the power switch toward “ I ”
(ON) to turn the TV on.
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 7

English - 8
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
1In the first three cases, connect the aerial or network input cable to
the ANT IN jack on the rear of the television.
2If you are using an indoor aerial, you may need to turn it when
tuning your television until you obtain a picture that is both sharp
and clear.
For further details, refer to:
◆“Storing Channels Automatically” on page 15.
◆“Storing Channels Manually” on page 16.
Connecting to an Aerial or Cable Television Network
Rear of the TV
Cable Television
Network
or
Connecting a Satellite Receiver or Decoder
In order to watch television programmes broadcast via
a satellite network, you must connect a satellite receiver
to the rear of TV. Also, in order to descramble a coded
transmission signal, you must connect a decoder
to the rear of TV.
◆Using a RCA cable
Connect the receiver (or decoder) RCA cable to one of the
RCA connectors on the rear of the television.
◆Using a coaxial cable
Connect a coaxial cable to the:
- Receiver (or Decoder) output socket.
- Television aerial input socket.
➢If you wish to connect both a satellite receiver (or decoder)
and a VCR, you should connect the:
◆Receiver (or Decoder) to the VCR
◆VCR to the television
Otherwise, connect the receiver (or decoder) directly to
the television.
Rear of the TV
Satellite Receiver/
Decoder
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 8

English - 9
Infrared Remote Control
➢The performance of the remote control may be affected by bright light.
POWER ON/OFF
DIRECT CHANNEL SELECTION
VOLUME INCREASE
TEMPORARY SOUND SWITCH-OFF
MENU DISPLAY/
TELETEXT INDEX
MOVE TO THE REQUIRED MENU
OPTION/
ADJUST AN OPTION VALUE
RESPECTIVELY
STILL THE MAIN PICTURE
➢In the PIP mode, the main and
sub pictures are stilled
at the same time.
PICTURE EFFECT SELECTION
EXTERNAL INPUT SELECTION/
TELETEXT HOLD
SWITCH REPEATEDLY BETWEEN THE
LAST TWO CHANNELS DISPLAYED
PICTURE SIZE
EXIT FROM ANY DISPLAY
PREVIOUS CHANNEL/
TELETEXT PREVIOUS PAGE
CONFIRM YOUR CHOICE
(STORE OR ENTER)
DISPLAY INFORMATION/
TELETEXT REVEAL
SRS TruSurround XT MODE SELECTION
ONE OR TWO-DIGIT CHANNEL
SELECTION
TUNER/CABLE NETWORK
SELECTION
SOUND EFFECT SELECTION
MAKE THE REMOTE CONTROL WORKS
FOR TV, VCR, CABLE-BOX (CATV),
DVD PLAYER, OR SET-TOP BOX (STB)
SOUND MODE SELECTION
VOLUME DECREASE
NEXT CHANNEL/
TELETEXT NEXT PAGE
CURRENT TIME DISPLAY/
TELETEXT SUBPAGE
TELETEXT DISPLAY/
MIX BOTH TELETEXT INFORMATION
AND THE NORMAL BROADCAST
DNIe ON/DEMO/OFF/
TELETEXT SIZE SELECTION
AUTOMATIC SWITCH-OFF/
TELETEXT CANCEL
SET THE MBR CODE OF REMOTE
CONTROL FOR THE PRODUCTS
EXCEPT SAMSUNG PRODUCT
(OPTION)
IF YOUR REMOTE CONTROL IS
NOT FUNCTIONING PROPERLY,
TAKE OUT THE BATTERIES AND
PRESS THE RESET BUTTON FOR
ABOUT 2~3 SECONDS. RE-
INSERT THE BATTERIES AND
TRY USING THE REMOTE
CONTROL AGAIN.
FASTEXT TOPIC SELECTION
WHEN YOU PRESS A BUTTON , ‘
’
APPEARS ALONG WITH SELECTED MODE
(TV, VCR, CATV, DVD OR STB) AND
REMAINING BATTERIES ON LCD
PIP FUNCTIONS;
-PIP ACTIVATING OR DEACTIVATING
(PIP ON)
-SWAPPING THE MAIN AND THE SUB
PICTURE (SWAP)
-SELECTING THE CHANNEL OF SUB
PICTURE (P
^
/
∨
)
VCR/DVD FUNCTIONS;
-REWIND (REW)
- STOP
-PLAY/PAUSE
-FAST FORWARD (FF)
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 9

English - 10
You must insert or replace the batteries in the remote control when
you:
◆Purchase the television
◆Find that the remote control is no longer operating
correctly
1Remove the cover on the rear of the remote control by pressing
the symbol ( ) downwards and then pulling firmly to remove it.
2Insert two R03, UM4, “AAA” 1.5V or equivalent batteries taking
care to respect the polarities:
◆ - on the battery against - on the remote control
◆ + on the battery against + on the remote control
3Replace the cover by aligning it with the base of the remote
control and pressing it back into place.
Do not mix battery types, i.e. alkaline and manganese.
Inserting the Batteries in the Remote Control
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 10

English - 11
Your television can be placed in Standby mode, in order to reduce
the power consumption.
The Standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
1Press the POWER ()button on the remote control.
Result:The screen is turned off and the Standby indicator on
the front of the television lights.
2To turn the screen back on, simply press the POWER ()button
again.
➢You can also switch on by pressing the P/,TV or numeric
button.
☛Do not leave your television in Standby mode for long
periods of time (when you are away on holiday, for
example). Turn your television off by pressing the power
switch on the back of the set. It is best to unplug the set
from the mains and aerial.
Placing Your Television in Standby Mode
The mains lead is attached to the rear of your television.
1Plug the mains lead into an appropriate socket.
➢The main voltage is indicated on the rear of the television
and the frequency is 50 or 60Hz.
2Press the power switch on the rear of the television toward “ON”
(I).
3Press the POWER ()button on the remote control or the front of
the television.
Result:The programme that you were watching last is re-
selected automatically.
➢If you have not yet stored any channels, No clear picture
appears. Refer to “Storing Channels Automatically” on page
15 or “Storing Channels Manually” on page 16.
4To switch your television off, press the power switch toward “OFF”
(O).
Switching Your Television On and Off
TV
TV
Standby indicator
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 11

English - 12
Becoming Familiar with the Remote Control
The remote control is used mainly to:
◆Change channels and adjust the volume
◆Display the on-screen menu system
The following table presents the most frequently used buttons and
their functions.
Button Viewing Function Menu Function
Used to display the next -
stored channel.
Used to display the
-
previous stored channel.
to Used to display the corresponding channels.
➢For double digit channels, the second digit must be
pushed immediately after the first. Failure to do this will
result in a single digit channel being displayed.
Used to select a channel numbered ten or over.
Press this button, and the “
-- ” symbol is displayed.
Enter the two-digit channel number.
Used to switch repeatedly between the last two channels
displayed.
To quickly switch between two channels that are far apart,
tune to one channel, then use the numeric buttons to select
second channel. Then, use the PRE-CH button to quickly
alternate between them.
Used to increase the -
volume.
Used to decrease the
-
volume.
Used to switch the sound off temporarily.
➢To turn the sound back on, press this button again, or
press the or button.
Used to display the Used to return to the previous
on-screen menu system. menu or normal viewing.
- Used to:
◆Display a submenu
containing selections for
the current menu option
◆Increase/decrease a
menu option value
- Used to confirm your choice.
- Used to exit from the menu
system and return to normal
viewing directly.
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 12

English - 13
When the television is initially powered ON, several basic customer
settings proceed automatically and subsequently. The following
settings are available.
1If the television is in Standby mode, press the POWER ()button
on the remote control.
2To start the Plug & Play, select the Start and press the ENTER
button.
Result:The available languages are listed.
3Select the appropriate language by pressing the …or † button.
Press the ENTER button to confirm your choice.
Result:The message Check antenna input is displayed.
4Make sure that the antenna is connected to the TV, and then
press the ENTER button.
Result:The available areas are listed.
5Select the appropriate area by pressing the …or † button.
Press the ENTER button to confirm your choice.
Result:The Auto Store menu is displayed.
6Press the ENTER button to start the search
Result:The search will end automatically. Channels are sorted
and stored in an order which reflects their position in
the frequency range (with lowest first and highest last).
➢To stop the search before it has finished or return to normal
viewing, press the EXIT or ENTER button.
7When the channels have been stored, the Clock Set menu is
displayed. Press the ENTER button to set the current time.
Press the œor √button to move to the hour or minute.
Set these by pressing the …or †button.
Press the ENTER button to confirm your choice.
8When it has finished, the message Enjoy your watching is
displayed, and then the channel which has been stored will be
activated.
Plug & Play Feature
Plug & Play
Start
Start Plug & Play
Language
Plug & Play
Move Enter Skip
Area
Austria
Belgium
Croatia
Denmark
Finland
France
Germany
Plug & Play
Move Enter Skip
Enter Return
Plug & Play
OK
Check antenna input.
Enter Skip
Plug & Play
Start
Auto Store
Enter Skip
Plug & Play
Stop
Auto Store
175 MHz
18%
Enter Skip
Plug & Play
Clock Set : - - : - -
Enter Skip
Enjoy your watching.
OK
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 13

English - 14
Setup
Move Enter Return
Plug & Play
Language : English
Time
Blue Screen : Off
Melody : On
Colour Weakness : Off
PC
AV Setup
TV
If you want to reset this feature...
1Press the MENU button.
Result:The main menu is displayed.
2Press the …or †button to select Setup.
Result:The options available in the Setup group are displayed.
3Press the ENTER button.
Result:The Plug & Play is selected.
4Press the ENTER button again.
5To start the Plug & Play, select the Start and press the ENTER
button.
6For further details on how to set, refer to the previous page.
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU button.
Result:The main menu is displayed.
2Press the …or †button to select Setup.
Result:The options available in the Setup group are displayed.
3Press the ENTER button.
4Press the …or †button to select Language.
Press the ENTER button.
Result:The available languages are listed.
5Select the appropriate language by pressing the …or †button.
6Press the ENTER button to confirm your choice.
Plug & Play Feature (continued)
Choosing Your Language
Setup
Move Enter Return
Plug & Play √√
Language : English √√
Time √√
Blue Screen : Off √√
Melody : On √√
Colour Weakness : Off √√
PC √√
AV Setup √√
TV
Setup
Move Enter Return
Plug & Play √√
Language : English √√
Time √√
Blue Screen : Off √√
Melody : On √√
Colour Weakness : Off √√
PC √√
AV Setup √√
TV
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 14

English - 15
You can scan for the frequency ranges available to you (and
availability depends on your country). Automatically allocated
programme numbers may not correspond to actual or desired
programme numbers. However you can sort numbers manually and
clear any channels you do not wish to watch.
1Press the MENU button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The options available in the Channel group are
displayed.
3Press the ENTER button.
Result:The Auto Store is selected.
4Press the ENTER button again.
Result:The Area is selected.
5Press the ENTER button once again.
Result:The available areas are listed.
6Select the appropriate area by pressing the …or †button.
Press the ENTER button to confirm your choice
7Press the …or †button to select Search.
Press the ENTER button.
8To start the search, select the Start and press the ENTER
button.
Result:The search will end automatically. Channels are sorted
and stored in an order which reflects their position in
the frequency range (with lowest first and highest last).
The programme originally selected is then displayed.
➢To stop the search before it has finished or return to normal
viewing, press the EXIT or ENTER button.
9When the channels have been stored, you can:
◆Sort them in the order required (see page 19)
◆Clear a channel (see page 18)
◆Assign a name to the stored channels (see page 21)
◆Fine-tune channel reception if necessary (see page 22)
◆Activate/deactivate the LNA (Low Noise Amplifier) feature
(see page 23)
◆Activate/deactivate the Digital NR (Noise Reduction)
feature (see page 28)
Storing Channels Automatically
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Child Lock √√
Name √√
Fine Tune √√
††More
TV
Auto Store
Area : Asia/W.Europe
Search √√
TV
Austria
Belgium
Croatia
Denmark
Finland
France
Germany
Iceland
Ireland
†
Auto Store
Area : Austria √√
Search √√
TV
Move Enter Return
Move Enter Return
Move Enter Return
Search
Start
Press ENTER to start.
Enter Return
Search
OK
Auto Store is incomplete.
No channel is memorized.
Enter Return
Search
Stop
Auto Store in progress.
175 MHz
18%
Enter Return
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 15

English - 16
You can store the television channels, including those received via
cable networks.
When storing channels manually, you can choose:
◆Whether or not to store each of the channels found
◆The programme number of each stored channel which
you wish to identify
1Press the MENU button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The options available in the Channel group are
displayed.
3Press the ENTER button.
4Press the …or †button to select Manual Store.
Press the ENTER button.
Result:The option available in the Manual Store group are
displayed with Prog. is selected.
5To assign a programme number to a channel, find the correct
number by pressing the …or † button.
6If necessary, select the broadcasting standard required. Press the
œor √button to select Colour System and press the …or †
button. The colour standards are displayed in the following order.
(depending on the model).
◆AUTO - PAL - SECAM
7Press the œor √button to select Sound System and press the …
or †button. The sound standards are displayed in the following
order. (depending on the model).
BG - DK - I - L
Storing Channels Manually
Manual Store
Prog. Colour System Sound System
1AUTO BG
Channel Search Store
C
--
887MHz ?
œœ√√
Move Adjust Return
Manual Store
Prog. Colour System Sound System
1AUTO BG
Channel Search Store
C
--
887MHz ?
œœ√√
Move Adjust Return
Manual Store
Prog. Colour System Sound System
1AUTO BG
Channel Search Store
C
--
887MHz ?
œœ√√
Move Adjust Return
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Child Lock √√
Name √√
Fine Tune √√
††More
TV
Move Enter Return
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 16

English - 17
8If you know the number of the channel to be stored, see the
following steps.
◆ Press the œor √button to select Channel.
◆ Press the …or †button to select C(Air channel) or S(Cable
channel).
◆ Press the √button.
◆ Press the numeric buttons (0~9), …or †button to select
indicate the required number.
➢If there is no sound or abnormal sound, reselect the sound
standard required.
9If you do not know the channel numbers, select the Search by
pressing the œor √button. Press the …or †button to start the
search.
Result:The tuner scans the frequency range until the first
channel or the channel that you selected is received
on your screen.
10 To store the channel and associated programme number, select
the Store by pressing the œor √ button.
Press the ENTER button.
Result:The OK is displayed.
11 Repeat Steps 8to 10 for each channel to be stored.
☛Channel mode
◆P(Programme mode): When completing tuning, the
broadcasting stations in your area have been assigned to
position numbers from P00 to P99. You can select a channel
by entering the position number in this mode.
◆C(Real channel mode): You can select a channel by
entering the assigned number to each air broadcasting station
in this mode.
◆S(Cable channel mode): You can select a channel by
entering the assigned number for each cable channel in this
mode.
Storing Channels Manually (continued)
Manual Store
Prog. Colour System Sound System
1AUTO BG
Channel Search Store
C
--
887MHz ?
œœ√√
Move Adjust Return
Manual Store
Prog. Colour System Sound System
1AUTO BG
Channel Search Store
C02 887MHz ?
œœ√√
Move Adjust Return
Manual Store
Prog. Colour System Sound System
1AUTO BG
Channel Search Store
C02 887MHz OK
œœ√√
Move Select Return
Manual Store
Prog. Colour System Sound System
1AUTO BG
Channel Search Store
C
--
887MHz ?
œœ√√
Move Adjust Return
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 17

English - 18
You can exclude the channels of your choice from the channel scan
operation. When you scan through the stored channels, those that
you have chosen to skip are thus not displayed. All channels that
you do not specifically choose to skip are displayed during
scanning.
1Press the MENU button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The options available in the Channel group are
displayed.
3Press the ENTER button.
4Press the …or †button to select Add/Delete.
Press the ENTER button.
Result:The Add/Delete menu is displayed with the current
channel automatically is selected.
5Press the …or †button to select the channel to be added or
deleted. Press the ENTER button.
6To add or delete the channel, select Added or Deleted by
pressing the …or †button.
7Press the ENTER button to confirm.
Skipping Unwanted Channels
Add/Delete
TV
1
----- *
Deleted
2
----- *
Deleted
3
----- *
Deleted
4
----- *
Deleted
5
----- *
Deleted
Prog. Ch.
Move Enter Return
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Child Lock √√
Name √√
Fine Tune √√
††More
TV
Move Enter Return
Add/Delete
TV
1
----- *
Deleted
2
----- *
Deleted
3
----- *
Added
4
----- *
Deleted
5
----- *
Deleted
Prog. Ch.
Adjust Enter Return
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 18

English - 19
This operation allows you to change the programme numbers of
stored channels. This operation may be necessary after using the
auto store. You can delete those channels you do not want to keep.
1Press the MENU button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The options available in the Channel group are
displayed.
3Press the ENTER button.
4Press the …or †button to select Sort. Press the ENTER button.
Result:The Sort menu is displayed.
5Select the channel that you wish to move by pressing the …or †
button. Press the ENTER button.
6Select the number of the programme to which the channel is to be
moved by pressing the …or †button. Press the ENTER button.
Result:The channel is moved to its new position and all other
channels are shifted accordingly.
7Repeat Steps 5to 6until you have moved all the channels to the
required programme numbers.
Sorting the Stored Channels
Sort
TV
1
-----
*
2
-----
*
3
-----
*
4
-----
*
5
-----
*
Prog. Ch.
Sort
TV
1
-----
*
-----
*
2
-----
*
3
-----
*
4
-----
*
5
-----
*
Prog. Ch.
Move Enter Return
Move Enter Return
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Child Lock √√
Name √√
Fine Tune √√
††More
TV
Move Enter Return
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 19

English - 20
This feature allows you to prevent unauthorized users, such as
children, from watching unsuitable programmes by muting out
video and audio. Child Lock cannot be released using front panel
buttons. Only remote control can release the Child Lock setting, so
keep the remote control away from children.
1Press the MENU button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The options available in the Channel group are
displayed.
3Press the ENTER button.
4Press the …or †button to select Child Lock.
Press the ENTER button.
Result:The Child Lock menu is displayed with the current
channel automatically is selected.
Blue Screen is displayed when the Child Lock is
activated.
5Press the …or †button to select the channel to be locked.
6Press the ENTER button. To lock the channel, select Locked by
pressing the …or † button (to unlock the channel, select
Unlocked).
7Press the ENTER button to confirm.
Activating the Child Lock
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
Child Lock √√
Name √√
Fine Tune √√
††More
TV
Move Enter Return
Child Lock
TV
1
----- *
Unlocked
2
----- *
Unlocked
3
----- *
Unlocked
4
----- *
Unlocked
5
----- *
Unlocked
Prog. Ch. Lock
Child Lock
TV
1
----- *
Unlocked
2
----- *
Unlocked
3
----- *
Locked
4
----- *
Unlocked
5
----- *
Unlocked
Prog. Ch. Lock
Move Enter Return
Adjust Enter Return
1_BP68-00389B-00Eng 7/29/04 1:42 PM Page 20
