Samsung RH29 Series User manual

user manual
100 %,I
Recycled Paper /
_J
This manual is made with 100 %recycled paper.
the possibilities
Thank you for purchasing this Samsung product
Free Standing Appliance

Cont nt,s
SAFETY INFORMATION ........................................................................ 2
SETTING UP YOUR SIDE-BY-SIDE REFRIGERATOR ................................. 11
OPERATING THE SAMSUNG SIDE-BY-SIDE REFRIGERATOR ..................... 22
TROUBLESHOOTING ........................................................................... 41
C
SAFETY INFORMATION
Before using your new Samsung Side-By-Side
Refrigerator, please read this manual thoroughly to
ensure that you know how to operate the features
and functions that your new appliance offers safely
and efficiently.
This appliance is not intended for use by persons
(including children) with reduced physical,
sensory, or mental capabilities, or those who lack
experience and knowledge, unless they have been
given supervision or instruction concerning the use
of the appliance by a person responsible for their
safety.
Because the following instructions cover various
models, the characteristics of your refrigerator may
differ slightly from the refrigerator described in this
manual.
If you have any question, contact us at
1-800-SAMSUNG or find help and information
online at www.samsung.com.
Important safety symbols and
precautions:
/iX WARNING
Hazards or unsafe practices that may result in
severe personal injury or death.
Z_ CAUTION
Hazards or unsafe practices that may result in
minor personal injury or property damage.
Do NOT attempt.
Do NOT disassemble.
_ Do NOT touch.
Follow directions carefully.
Unplug the power plug from the wall
socket.
Make sure the refrigerator is grounded to
3revent electric shock.
Call the contact center for help.
Note.
These warning symbols are here to prevent
injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe
place for future reference.
Engl sh - 2

,,_ WARNING
CRITICAL INSTALLATION
WARNINGS
• Do not install the refrigerator in a damp
location or place where it may come in
contact with water.
Deteriorated insulation on electrical parts may
cause an electric shock or fire.
• Do not place this refrigerator in direct sunlight
or expose it to the heat from stoves, room
heaters, or other appliances.
• Do not plug several appliances into the same
multiple power strip.
The refrigerator should always be plugged into
its own individual electrical outlet which has a
voltage rating that matches the voltage listed
on the refrigerator's rating plate.
This provides the best performance and
also prevents overloading of house wiring
circuits, which could cause a fire hazard from
overheated wires.
• Ifthe wall socket is loose, do not insert the
power plug.
There is a risk of electric shock of fire.
• Do not use a power cord that has cracks or
abrasion damage along its length or at either
end.
• Do not bend the power cord excessively or
place heavy objects on it.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal
object, place a heavy object on the power
cord, insert the power cord between objects, or
push the power cord into the space behind the
appliance.
• When moving the refrigerator, be careful not to
roll over or damage the power cord.
This may result in an electric shock or fire.
• Never unplug your refrigerator by pulling on the
power cord.
Always grip the plug firmly and pull straight out
from the outlet.
Damage to the cord may cause a short-circuit,
fire, and/or electric shock.
• Do not use aerosols near the refrigerator.
Using aerosols near the refrigerator may cause
an explosion or fire.
• Do not install this appliance near a heater or
inflammable material.
• Do not install this appliance in a humid, oily,
or dusty location, or in a location exposed to
direct sunlight or water (rain, etc.).
• Do not install this appliance in a location where
gas may leak.
This may result in an electric shock or fire.
• This refrigerator must be properly
located and installed in accordance
with the instructions in this manual
before you use it.
• Connect the power plug in the proper position
with the cord hanging down.
Ifyou connect the power plug upside down, the
wire can get cut off and cause a fire or electric
shock.
• When moving the refrigerator, be careful not to
roll over or damage the power cord.
This constitutes a fire hazard.
• Make sure that the power plug is not crushed
or damaged by the back of the refrigerator.
• Keep the packing materials out of reach of
children.
There is a risk of death from suffocation if a
child puts the packing materials on his or her
head.
• The appliance must be positioned so that the
plug is accessible after installation.
Failing to do so may result in an electric shock
or fire due to electric leakage.
• You need to remove all the protective plastic
film before you initially plug the product in.
• The refrigerator must be safely
grounded.
Always make sure that you have grounded the
refrigerator before attempting to investigate or
repair any part of the appliance.
Power leakages can cause severe electric
shock.
Never use gas pipes, telephone lines, or other
potential lightning attractors as an electrical
ground.
Improper use of the grounding plug can result
in a risk of electric shock.
If it is necessary to use an extension cord, use
only a 3-wire extension cord that has a 3-blade
grounding plug and a 3-slot receptacle that will
accept the plug on the appliance.
The marked rating of the extension cord should
beAC 115-120 V, 10A, or more.
If a grounding adapter is used, make sure the
Engl sh - 3

receptacleboxisfullygrounded.
Plugthepowerplugintothewallsocketfirmly.
Donotuseadamagedpowerplug,damaged
powercord,orloosewallsocket.
Thismayresultinanelectricshockorfire.
Ifthepowercordisdamaged,
haveitreplacedimmediatelybythe
manufactureroroneofitsservice
agents.
z_ CAUTION
INSTALLATION CAUTIONS
• Allow sufficient space around the
refrigerator and install it on a flat
surface.
Ifyour refrigerator is not level, the internal
cooling system may not work correctly.
Keep the ventilation space in the appliance
enclosure or mounting structure clear of
obstructions.
• Allow the appliance to stand for 2 hours after
installation.
• We strongly recommend you have a qualified
technician or service company install the
refrigerator.
Failing to do so may result in an electric shock,
fire, explosion, problems with the product, or
injury.
When installing the refrigerator, make sure both
legs contact the floor for secure installation.
Legs are located at the bottom back of each
door.
Insert a flathead screwdriver and turn it in the
direction of the arrow until it is level.
Always balance the load on each door.
Overload on any one door may fell the
refrigerator, causing physical injury.
_WARNING
CRITICAL USAGE WARNINGS
• Do not insert the power plug into a wall
socket with wet hands.
• Do not store articles on the top of the
appliance.
When you open or close the door, the articles
may fall and cause personal injury and/or
material damage.
• Do not insert hands, feet or metal objects (such
as knives, etc.) into the bottom or the back of
the refrigerator.
This may result in an electric shock or injury.
Any sharp edges may cause a personal injury
• Do not put a container filled with water on the
refrigerator.
If spilled, there is a risk of fire or electric shock.
• Children should be supervised to ensure that
they do not play with the appliance.
Keep fingers out of "pinch point" areas.
Clearances between the doors and cabinet are
necessarily small. Be careful when you open
the doors if children are in the area.
• Do not let children hang on the door.
A serious injury may occur.
• Do not let children go inside the refrigerator.
They could become trapped.
• Do not insert your hands into the bottom area
under the appliance.
Any sharp edges may cause personal injury.
• Do not let children step on a drawer cover.
The drawer may break and cause them to slip.
• Do not overfill the refrigerator with food.
When you open the door, an item may fall out
and cause personal injury or material damage.
• Do not touch the inside walls of the freezer or
products stored in the freezer with wet hands.
This may cause frostbite.
• Never put fingers or other objects into the water
dispenser hole, ice chute, or ice maker bucket.
It may cause personal injury or material
damage.
• Do not use or place any substances sensitive
Engl sh - 4

totemperaturesuchasinflammablesprays,
inflammableobjects,dryice,medicine,or
chemicalsnearorinsidetherefrigerator.
• Donotkeepvolatileorinflammableobjects
orsubstances(benzene,thinner,propane
gas,alcohol,ether,LPgas,andothersuch
products)intherefrigerator.
Thisrefrigeratorisforstoringfoodonly.
Thismayresultinfireorexplosion.
• Donotstorepharmaceuticalproducts,scientific
materials,ortemperaturesensitiveproductsin
therefrigerator.
Productsthatrequirestricttemperature
controlsmustnotbestoredintherefrigerator.
• Donotplaceoruseanelectricalappliance
insidetherefrigerator,unlessitisofatype
recommendedbythemanufacturer.
• Donotstandontopoftheapplianceorplace
objects(suchaslaundry,lightedcandles,
lightedcigarettes,dishes,chemicals,metal
objects,etc.)ontheappliance.
Thismayresultinanelectricshock,fire,
problemswiththeproduct,orinjury.
• Donotputacontainerfilledwithwateronthe
appliance.
Ifspilled,thereisariskoffireorelectricshock.
• Donotusemechanicaldevicesoranyother
meanstoacceleratethedefrostingprocess,
otherthanthoserecommendedbythe
manufacturer.
• Donotdamagetherefrigerantcircuit.
• Donotsprayvolatilematerialsuchas
insecticideontothesurfaceoftheappliance.
Aswellasbeingharmfultohumans,itmayalso
resultinanelectricshock,fire,orproblemswith
theproduct.
• NeverstaredirectlyattheUVLEDlampforlong
periodsoftime.
Thismayresultineyestrainduetothe
ultravioletrays.
• Donotattempttorepair,disassemble,
ormodifytheapplianceyourself.
Donotuseanyfuse(suchascooper,steelwire,
etc.)otherthanastandardfuse.
Ifyourapplianceneedstoberepairedor
reinstalled,contactyournearestservicecenter.
Failingtodosomayresultinanelectricshock,
fire,problemswiththeproduct,orinjury.
IftheinteriororexteriorLEDlamphasgone
out,pleasecontactyournearestservicecenter.
[_ • Childrenshouldbesupervisedto
ensurethattheydonotplaywiththe
appliance.
Keepfingersoutof"pinchpoint"areas.:
Clearancesbetweenthedoorsandcabinetare
necessarilysmall.
Becarefulwhenyouopenthedoorsifchildren
areinthearea.
• Donotletchildrenhangonthedoor.
Aseriousinjurymayoccur.
• Donotletchildrengoinsidetherefrigerator.
Theycouldbecometrapped.
• Bottlesshouldbestoredtightlytogethersothat
theydonotfallout.
• Thisproductisintendedonlyforthestorageof
foodinadomesticenvironment.
• Ifagasleakisdetected,avoidanynaked
flamesorpotentialsourcesofignition,andair
theroominwhichtheapplianceisstandingfor
severalminutes.
Donottouchtheapplianceorpowercord.
Donotuseaventilatingfan.
Asparkmayresultinexplosionorfire.
• UseonlytheLEDLampsprovidedbythe
manufactureroritsserviceagents.
• Iftherefrigeratoremitsaburningsmell
orsmoke,unplugtherefrigerator
immediatelyandcontactyour
SamsungElectronicsservicecenter.
• Ifyouexperiencedifficultychanginganon-LED
light,contactaSamsungservicecenter.
• IftheproductisequippedwithLEDLamps,do
notdisassembletheLampCoversandLED
Lampsyourself.
Pleasecontactyourserviceagents.
• Ifdustorwaterenterstherefrigerator,unplug
therefrigeratorandcontactyourSamsung
Electronicsservicecenter.
Thereisariskoffire.
Englsh-5

,,_ CAUTION
USAGE CAUTIONS
• Do not re-freeze frozen foods that have
thawed completely.
Do not place carbonated or fizzy drinks
in the freezer compartment.
Do not put bottles or glass containers
in the freezer.
When the contents freeze, the glass may break
and cause personal injury.
• Use only the ice maker provided with the
refrigerator.
• Have the refrigerator's water supply installed by
a suitably qualified person and connected only
to a potable water supply.
To operate the ice maker properly, water
pressure of 20 - 125 psi (138 - 862 kPa) is
required.
Ifyou will be away from home for a long period
of time (on vacation, for example) and won't
be using the water or ice dispensers, close the
water valve.
Otherwise, water leakage may occur.
• Ifyou won't be using the refrigerator for a very
long period of time, (3 weeks or more) empty
the refrigerator, unplug it, close the water valve,
wipe excess moisture from the inside walls,
and leave the doors open to prevent odors and
mold.
• Service Warranty and Modification.
• Any changes or modifications
performed by a 3rd party on this
finished appliance are not covered
under Samsung warranty service, nor is
Samsung responsible for safety issues
that result from 3rd party modifications.
• Do not block the air vents inside the refrigerator.
Ifthe air vents are blocked, especially with a
plastic bag, the refrigerator can be over cooled.
Ifthis cooling period lasts too long, the water
filter may break and cause water leakage.
• Ifthe refrigerator is disconnected from the
power supply, you should wait for at least five
minutes before plugging it back in.
• Ifyou have a long vacation planned or do not
intend to use the refrigerator for a long period of
time, (3 weeks or more) empty the refrigerator,
pull out the power plug, close the water valve,
wipe excess moisture from the inside walls,
and leave the doors open to prevent odors and
mold.
Letting the refrigerator run long periods of time
without using it can cause the insulation to
deteriorate and may cause a fire.
• To get the best performance from the product:
Do not place food too close to the vents at the
rear of the appliance as it can obstruct free air
circulation in the refrigerator compartment.
Wrap food up properly or place it in airtight
containers before putting it into the refrigerator.
Do not place glass bottles or carbonated
beverages into the freezer.
They can freeze and break.
Broken beverage containers can cause injury.
Please observe maximum storage times and
expiration dates of frozen goods.
There is no need to disconnect the refrigerator
from the power supply if you will be away for
less than three weeks.
However, if you will be away for more than
three weeks, remove all the food, unplug the
refrigerator, close the water valve, wipe excess
moisture from the inside walls, and leave the
doors open to prevent odors and mold.
• Fillthe water tank and ice cube trays with
potable water only (tap water, mineral water, or
purified water).
Do not fill the tank with tea or a Sports drink.
This may damage the refrigerator.
• Do not strike or apply excessive force to any
glass surface.
Broken glass may result in a personal injury
and/or property damage.
• If the product is flooded, make sure to
contact your nearest service center.
There is a risk of electric shock or fire.
Engl sh - 6

,,_ CAUTION
CLEANING CAUTIONS
Q
o
o
+ Do not spray water directly on the
inside or outside the refrigerator
There is a risk of fire or electric shock.
Do not use a hair dryer to dry the inside of the
refrigerator
Do not place a lighted candle in the refrigerator
to remove bad odors.
This may result in an electric shock or fire.
[_ + Use a clean, dry cloth to remove any
foreign matter or dust from the power
plug blades.
Do not use a wet or damp cloth when
cleaning the plug.
Otherwise, there is a risk of fire or electric
shock.
+ Before cleaning or performing
maintenance, unplug the appliance
from the wall socket.
Failing to do so may result in an electric shock
or fire.
WARNING
+ This product contains chemicals known to
the State of California to cause cancer and
reproductive toxicity.
z._ WARNING
CRITICAL DISPOSAL WARNINGS
+ DANGER : Risk of child entrapment.
Before you throw away your old
refrigerator or freezer:
Take off the doors and door latch.
Leave the shelves in place so that children
cannot easily climb inside.
Children trapped inside a refrigerator can hurt
themselves or suffocate to death.
+ Please dispose of the packaging material from
this product in an environmentally friendly
manner
+ Ensure that none of the pipes on the back of
the appliance are damaged prior to disposal.
+ R-600a or R-134a is used as a refrigerant.
Check the compressor label on the rear of
the appliance or the rating label inside the
fridge to see which refrigerant is used for your
refrigerator.
Ifthis product contains flammable gas
(Refrigerant R-600a), contact your local
authority in regard to safe disposal of this
product.
+ When disposing of this refrigerator, remove the
door/door seals and door latch so that small
children or animals cannot become trapped
inside.
Children should be supervised to ensure that
they do not play with the appliance.
Iftrapped inside, the child may get hurt or
suffocate to death.
+ Cyclopentane is used in the insulation.
The gases in the insulation material require a
special disposal procedure.
Please contact your local authorities in regard
to the environmentally safe disposal of this
product.
+ Keep all packaging materials well out of the
reach of children, as packaging materials can
be dangerous to children.
If a child places a bag over his or her head, the
child could suffocate.
Engl sh +7

I'_ ADDITIONAL TIPS FOR
PROPER USAGE
• Inthe event of a power failure, call the local
office of your Electricity Company and ask how
long it is going to last.
Most power failures that are corrected in an
hour or two will not affect your refrigerator
temperatures. However, you should minimize
the number of door openings while the power
is off.
Should the power failure last more than 24
hours, remove and discard all frozen food.
• If a key is provided with refrigerator, the keys
should be kept out of the reach of children and
not be kept in the vicinity of the appliance.
• The appliance might not operate consistently
(frozen contents can thaw or temperatures
can become too warm in the frozen food
compartment) when sited for an extended
period of time in a location where ambient
air temperatures are constantly below the
temperatures for which the appliance is
designed.
• Do not store food which goes bad easily at low
temperature, such as bananas and melons.
,, Your appliance is frost free, which means there
is no need to manually defrost your appliance.
This will be carried out automatically.
• Temperature rise during defrosting complies
with ISO requirements.
But Ifyou want to prevent an undue rise in the
temperature of frozen food while the appliance
defrosts, wrap the frozen food in several layers
of newspaper.
• Any increase in the temperature of frozen food
during defrosting can shorten its storage life.
• Do not re-freeze frozen foods that have thawed
completely.
Saving Energy Tips
Install the appliance in a cool, dry room with
adequate ventilation.
Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat (a
radiator, for example).
Never block any vents or grilles on the
appliance.
Allow warm food to cool down before placing it
in the appliance.
Put frozen food in the refrigerator to thaw.
You can then use the low temperatures of the
frozen products to cool food in the refrigerator.
Do not keep the door of the appliance open for
too long when putting food in or taking food
out.
The shorter the time the door is open, the less
frost build-up you'll have in the freezer.
Provide sufficient clearance to the right, left,
back, and top for air circulation when installing
the refrigerator. This will help reduce power
consumption and keep your energy bills lower.
Engl sh - 8

1. Regulatory Notice
1.1 FCC Notice
/_X FCC CAUTION:
CAUTION
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
Contains Transmitter Module FCC ID: A3LSWL-B70F
This device complies with Part 15 of FCC Rules. Operation is Subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received including interference that cause undesired
operation.
For products available in the US and Canadian markets, only channels 1+11 are available.
You cannot select other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. Ifthis equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
+ Reorient or relocate the receiving antenna
+ Increase the separation between the equipment and receiver
+ Connect the equipment to an outlet that is on a different circuit than the receiver.
+ Consult the dealer or an experienced radio/TV technician for help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated so there is at least 8 inches (20 cm) between the
radiator and your body. This device and it's antennas must not be co-located or operated in conjunction
with any other antenna or transmitter except in accordance with FCC multi-transmitter product
procedures.
SAVE THESE INSTRUCTIONS
Eng+sh - 9

1. Regulatory Notice
1.2 IC Notice
Contains Transmitter Module IO: 649E - SWLB70F
The term "10" before the radio certification number only signifies that Industry Canada technical
specifications were met. Operation is subject to the following two conditions : (1) this device may not
cause interference, and (2)this device must accept any interference, including interference that may
cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-O03.
Cet appareil numerique de la classe Best conforme a la norme NMB-O03 du Canada.
For products available in the US and Canadian markets, only channels 1-11 are available.
You cannot select other channels.
IC RADiATiON EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated so there is at least 8 inches (20 cm)
between the radiator and your body. This device and it's antennas must not be co-located or operated
in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter
product procedures.
SAVE THESE iNSTRUCTiONS
Engl sh - 10

/©UF
GETTING READY TO INSTALL
THE REFRIGERATOR
Congratulations on the purchase of your Samsung
Side-By-Side Refrigerator.
We hope you will enjoy the many state-of-the-art
features and efficiencies that this new appliance
has to offer.
Selecting the best location for the
refrigerator
• Select a location with easy access to a water
supply.
• Select a location without direct exposure to
sunlight.
• Select a location with level (or nearly level)
flooring.
• Select a location with enough space for the
refrigerator doors to open easily.
See the diagram above, right.
• Select a location that allows sufficient space to
the right,left, back, and top for air circulation.
See the diagram below.
• Select a location that allows you to move the
refrigerator easily if it needs maintenance or
service.
sdo by sdo
E E
E
67 7/8" (1725 mm)
B:_- ....
-4, .........
C -.+ i
- t
- i+
Model RH29* RH22*
Depth "A" 85 1/8" (893 mm) 28 2/8" (718 mm)
Width "B" 35 7/8" (912 ram) 35 7/8" (912 ram)
Height "C" 68 1/2" (1742 mm) 68 1/2" (1742 ram)
Overall Height "D" 69 6/8" (1774 mm) 69 6/8" (1774 mm)
Depth "E" 35 2/8" (896 ram) 28 1/4" (721 ram)
, llow clearance to the right, left, back
and top when installing.
This will help reduce power consumption
and keep your energy bills lower.
• Do not install the refrigerator in locations where
the temperature is over 109 °F (43 °C) or below
41 °F (5 °C).
Eng+sh - 11

When moving your refrigerator
To prevent floor damage, be sure the front levelling
legs are in the up position (above the floor),
Refer to 'Levelling the refrigerator' in this manual
(page 16).
Leg Screw Driver
Flooring
For proper installation, you must place this
refrigerator on a level, hard surface that is the
same height as the rest of the floor.
This surface should be strong enough to support a
fully loaded refrigerator.
To protect the finish of the flooring, cut a large
section of the cardboard carton and place it under
the refrigerator where you are working.
When moving the refrigerator, you need to pull and
push it straight forwards or back.
Do not wiggle it from side to side,
Required Tools (Not provided)
Philips Flat-bladescrew Socket wrench
screwdriver(+) driver (-) (13/32")(10 ram)
Allenwrench
(3/16")(5 mm)
REMOVING THE REFRIGERATOR
DOORS
If your entrance won't allow the refrigerator to pass
easily through it, you can remove the doors,
To remove the doors, follow the steps below,
If you do not need to remove the doors, go to
"Leveling the Refrigerator" on page 16,
1. SEPARATE THE WATER SUPPLY LINES
FROM THE FRIDGE
1, Pull the two water lines (which are in the Fixer)
out to the front.
Engl sh --12

2.Removethetwowaterlines(Whiteforwater
andtheotherforice)bypressingthecoupler
(1)andpullingthewaterline(2)away.
CAU_TION °f the water lines _ _
_toh.
/K CAUTION
When reconnecting the supply hoses, make sure
the same colored hoses are inserted with each
other.
2. DETACH THE HINGE COVER
1. Disconnect the power cord, and remove 3
cover screws using a Phillips screwdriver ( 1 ).
Then open the refrigerator door and pull the
hooks on the sides to loosen the cover ( 2 ).
Lift up the cover towards you to detach it
(3).
Detach the hinge cover with the door open and
then close the door once the hinge cover has
been detached.
(1)
(2)
{3)
3. DISASSEMBLE THE FREEZER DOORS
1. Remove the hinge cover and then disconnect
the electrical wire connector.
2. Flip the clamp (A up in direction 1 and then
pull it off in direction 2.
3. Remove the hinge ( B ).
4. Lift up the door and detach it from the
refrigerator.
Engl sh --13

/K CAUTION
o
o
Be careful not to damage the electrical wires
when assembling or disassembling the doors,
Make sure the doors do not fall over and
become damaged while they are detached
from the refrigerator,
4. DISASSEMBLE THE COLD
COMPARTMENT SHOW CASE DOOR
1, Disassemble the housing connector,
2, Disassemble the three fastening screws on the
top hinge of the show case,
3, Remove the show case
door,
5. DISASSEMBLE THE REFRIGERATOR
DOORS
1, Push the fixer hinge up, and pull it forward to
remove it,
2, Disassemble the top hinge from the front of the
door,
3, Remove the entire door,
CAUTION
Fix the wire on the Hinge Hook to prevent the
damage on the wire when reassembling,
j,¢
Engl sh --14

RE-ATTACHING THE DOORS
To re-attach the doors, follow the steps below,
1. RE-ATTACH THE FREEZER DOOR
Z_ CAUTION
+ Be sure to re-attach the Freezer Door before
reattaching the Fridge Door.
+ Before re-attaching, make sure that all the wire
connectors at the bottom of the Freezer Door
are connected.
How to Re-Attach the Freezer Door
1, Attach the doors to the hinges at the bottom of
the refrigerator.
2, Insert the hinge ( B ) into the hinge slot on the
refrigerator, and then press down over the
hinge hole on the door.
Insert the clamp ( A ) in the direction of arrow
( 1 ) and then lower it in the direction of arrow
( 2 ) to lock it in place.
d}
®
Hook up the electrical wire connector.
Z_ CAUTION
The display may not function properly if you
neglect to connect the electrical wires while
assembling the door.
2. RE-ATTACH THE REFRIGERATOR
DOOR
To re-attach the REFRIGERATOR door, assemble
the parts in reverse order.
Engl sh --15

3. RE-ATTACH THE COLD
COMPARTMENT SHOW CASE DOOR
To re-attach the COLD COMPARTMENT SHOW
CASE DOOR, assemble the parts in reverse order.
4. RE-ATTACH THE HINGE COVER
1. Open the refrigerator doors.
2. Attach the hinge cover to the top of the
refrigerator.
Secure the cover in place with the three screws
you removed earlier using a Phillips screwdriver.
i-i
5. RE-ATTACH THE WATER SUPPLY
MNER
1. The Water Line must be fully Inserted to the
center of the transparent coupler to prevent
water leakage from the dispenser.
2. Insert the 2 clips in the install pack and check
that each clip holds the line firmly.
Center of Transparent coupler
Clip A (1/4")
(6.35 ram)
z_ CAUTION
Keep the clips out of the reach of children and
make sure that children do not play with them or
put them into their mouths.
LEVELING THE REFRIGERATOR
AND ADJUSTING THE HEIGHT
AND GAP OF THE DOORS
How to level the refrigerator
Ifthe front of the appliance is slightly higher than
the rear, the door can be opened and closed more
easily.
Setting up the refrigerator on an uneven surface
will cause the refrigerator to lean.
If the freezer side is lower:
Insert a flathead screwdriver into the height
leveler located at the bottom back of the freezer
door and turn it in the direction of the arrow
until it is level.
If the refrigerator side is lower:
Insert a flathead screwdriver into the height
leveler located at the bottom back of the
refrigerator door and turn in the direction of the
arrow until it is level.
Engl sh - 16

oRaise the front of the refrigerator so that
the doors close by themselves.
Adjusting the levelers so that the back
of the refrigerator is much higher than
the front of the refrigerator can make it
difficult to open the doors,
Ifthe back of the refrigerator is not level, put an
appropriately sized thin piece of wood or tile
where the refrigerator leg you want to raise will
be set, and then secure it in place using tape.
Slide the refrigerator into its spot, with the back
leg you want to raise on the tile or wood.
Then, adjust the level of the front legs.
When pushing the refrigerator in, be careful not
to damage the floor,
HOW TO ADJUST THE DOOR
HEIGHT
If one door is lower than the other:
• The refrigerator door height can be adjusted
using the adjustment nuts located at the
bottom of each door,
Raising the door too high can cause the door to
interfere with the hinge cover when it is opened
or closed,
1. Open the door that needs to be adjusted and
loosen the clamping nut ( A ) at the bottom of
the door by turning it clockwise (_ ) using
the spanner included in the product package,
(Raise the lower of the two doors first,)
2. Adjust the height of the door by turning the
adjustment nut ( B ) counterclockwise ( _ )
with a spanner.
(Turn it counterclockwise ( _ ) to increase
the height of the door and clockwise ( _ ) to
decrease it.)
Open the door and adjust it from the inside,
3. Once the doors are level, turn the clamping nut
( A ) counterclockwise (_ ) to tighten it.
®Adjusting the level when the refrigerator
is empty can result in the refrigerator
becoming uneven again once items have
been placed inside,
Ifthis occurs, adjust the level again,
iiiiiiiiiiiiiiii
iiiiiiiiiiiiiiii
iiiiiiiiiiiiiiii
Engl sh --17

HOW TO ADJUST THE GAP
BETWEEN THE DOORS
If the gap between the refrigerator door and the
freezer door is uneven:
• Use the gap adjustor located at the top of the
refrigerator door (right side).
• Excessive force can cause the adjustor bolt to
break.
1. Remove the refrigerator
door's hinge cover.
Detach the hinge cover with
the door open and then close
the door once the hinge
cover has been detached.
2. Adjust the gap using a 4 mm Allen wrench (not
included).
3. Rotate the bolt clockwise (_ ) to widen
the gap. Rotate it counterclockwise ( _ ) to
narrow the gap.
Adjust until the gap between the refrigerator
door and the freezer door appears even.
Z[_ CAUTION
When arranging the cables, take caution not to
tear or peel off the cable coating,
HOW TO ADJUST THE GAP
BETWEEN THE REFRIGERATOR
DOOR AND THE REFRIGERATOR
BODY
If the gap between the refrigerator door and the
refrigerator is uneven :
• Use the adjustors located at the top edge of
the refrigerator, inside each door.
1. Open the door where the gap with the
refrigerator is narrower and then turn the
adjustor counterclockwise (_ ) until the gap
is even.
2. Once the gap between the door and the
refrigerator has been adjusted, turn the adjustor
nut clockwise ( _ ) to lock the adjustor in
place.
Engl sh --18

iNSTALLiNG THE WATER
DISPENSER LiNE
A water dispenser is one of the helpful features on
your new Samsung Refrigerator.
To help promote better health, the Samsung water
filter removes unwanted particles from your water.
However, it does not sterilize or destroy
microorganisms.
You may need to purchase a water purifying
system to do that.
The water line also connects to the ice maker.
For the ice maker to operate properly, water
pressure of 20 -125 psi (138 -862 kPa) is
required.
If the refrigerator is installed in an area with low
water pressure (below 20 psi), you can install a
booster pump to compensate for the low pressure.
After you have connected the water line, make
sure the water storage tank inside the refrigerator
is properly filled.
To do this, press the water dispenser lever until
water runs from the water dispenser.
®Water line installation kits are available at
extra cost from your dealer.
We recommend using a water supply kit
that contains copper tubing.
The Samsung refrigerator warranty does
not cover water line installation.
We strongly recommend you have a
plumber or authorized installer install the
water line.
Connecting to the water supply line
1. First, shut off the main water supply line and
turn the ice-maker off.
The refrigerator should NOT be plugged in
at this point.
2. Locate the nearest cold water drinking water
line.
3. Install the pipe clamp and shut off valve.
4. Connect the water line installation kit to the
shut off valve.
Water line installation kit
Engl sh - 19

Connecting the water supply line to the
refrigerator
There are several items that you need to purchase
to complete this connection.
You may find these items sold as a kit at your local
hardware store.
Use Copper Tubing Use Plastic Tubing
® ¼" copper tubing ® ¼" plastic tubing
® ¼" compression nut _ Molded end (Bulb)
(1pc) ® ¼" compression nut
® Ferrule (2pc) (1pc)
Refrigerator
_ Plastic Tubing
I (Supplied)
Compression Nut ....._ [_
{1/4") (Assembled) _ Compression
_ Fitting (Assembled)
Ferrule _ _-- Bulb
(Not supplied) .,_ - + ,_ _ nutC°mpressi°n(B)(1/4")
(Not supplied)
Copper tubing or Plastic tubing (B)
(Not supplied) (Not supplied)
Connect the household water line to the
assembled compression fitting.
Ifyou are using copper tubing, slip the
compression nut ( B ) (not supplied) and
ferrule (not supplied) on the copper tubing (not
supplied) as shown.
Ifyou are using plastic tubing ( B ), insert the
molded end (Bulb) of the plastic tubing ( B ) into
the compression fitting.
Z_ CAUTION
Do not use plastic tubing ( B ) without the molded
end (Bulb).
2. Tighten the compression nut ( B ) onto the
compression fitting.
Do not over-tighten the compression nut ( B ).
3. Turn the water on and check for any leaks
inside the refrigerator, around the water filter,
and in any connection areas.
Ifyou find water drops or leaks, turn off the
main water supply.
Ifthe leaks are in the connection areas, check
the connections and, if necessary, tighten.
Ifthere are leaks in the refrigerator, check
the water filter and confirm it is in the locked
position.
Turn on the water supply and check for leaks
again.
4. Plug in the refrigerator.
5. Flush 3 gallons of water through the filter before
drinking or using the water from the refrigerator.
(Flush approximately 6 minutes.)
This will clean the water supply system and
remove air from the lines.
To flush, press the Water button, and then press
a large glass or cup against the water dispenser
lever. Fill the glass, empty it into the kitchen sink
after it is filled, and then repeat.
[_ dditional flushing may be required in
some households.
6. Open the refrigerator door and make sure there
are no water leaks coming from the water filter.
+ fter you turn on the refrigerator, let the
ice maker make ice for 1 to 2 days.
Over that period of time, throw out the
first 1 or 2 buckets of ice the ice maker
makes to ensure all impurities have been
removed from the water line.
+ Only connect the water line to a drinkable water
source.
+ Ifyou have to repair or disassemble the water
line, cut off 1/4" of the plastic tubing to make
sure you get a snug, leak-free connection.
+ You can test the water line quickly using a
paper cup.
Under normal conditions, the water dispenser
can fill a 5.75 oz. (170 cc) cup in about 10
seconds.
Eng+sh- 20
