Samsung RS25J50 User manual

Refrigerator
User manual
RS25J50*
Free Standing Appliance
DA68-02981M (EN)-150612.indd 1 2015. 6. 12.  9:16

2 English
Contents
Contents
Contents
Safety information 3
Important safety symbols and precautions 4
Critical installation warnings 5
Installation cautions 8
Critical usage warnings 9
Usage cautions 13
Cleaning cautions 16
Critical disposal warnings 17
Additional tips for proper usage 18
Setting up 21
Getting ready to install the refrigerator 21
Setting up the refrigerator 24
Removing the refrigerator doors 26
Leveling the refrigerator 31
Making minor adjustments between doors 32
Installing the water dispenser line 33
Completing the set up 37
Operating 38
Checking the control panel 38
Using the control panel 40
Using the ice and cold water dispenser 43
Storing food 45
Removing the freezer/fridge accessories 47
Cleaning the refrigerator 48
Changing the water lter 50
Troubleshooting 53
DA68-02981M (EN)-150612.indd 2 2015. 6. 12. �� 9:16

English 3
Safety information
Safety information
•Before operating the appliance, please read this manual thoroughly and
retain it at a safe place near the appliance for your future reference.
•Use this appliance only for its intended purpose as described in this
instruction manual.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
•Warnings and Important Safety Instructions in this manual do not cover
all possible conditions and situations that may occur.
It is your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your appliance.
•Because these following operating instructions cover various models,
the characteristics of your refrigerator may differ slightly from those
described in this manual and not all warning signs may be applicable.
If you have any questions or concerns, contact your nearest service center
or nd help and information online at www.samsung.com.
DA68-02981M (EN)-150612.indd 3 2015. 6. 12. �� 9:16

4 English
Safety information
Safety information
Important safety symbols and precautions
WARNING
Hazards or unsafe practices that may result in severe personal injury or
death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
NOTE
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the contact center for help.
These warning signs are here to prevent injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe place for future reference.
CE Notice
This product has been determined to be in compliance with the Low
Voltage Directive (2006/95/EC), the Electromagnetic Compatibility
Directive (2004/108/EC), RoHS Directive (2011/65/EU), Commission
Delegated Regulation (EU) No 1060/2010 and the Eco-Design
Directive(2009/125/EC) implemented by Regulation (EC) No 643/2009 of
the European Union. (For products sold in European Countries only)
DA68-02981M (EN)-150612.indd 4 2015. 6. 12. �� 9:16

English 5
Safety information
Critical installation warnings
WARNING
•Do not install the refrigerator in a damp location or place where it
may come in contact with water.
- Deteriorated insulation on electrical parts may cause an electric shock or
re.
•Do not place this refrigerator in direct sunlight or expose it to the heat
from stoves, room heaters, or other appliances.
•Do not plug several appliances into the same multiple power strip.
The refrigerator should always be plugged into its own individual
electrical outlet which has a voltage rating that matches the voltage listed
on the refrigerator’s rating plate.
- This provides the best performance and also prevents overloading of
house wiring circuits, which could cause a re hazard from overheated
wires.
•If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of re.
•Do not use a power cord that has cracks or abrasion damage along its
length or at either end.
•Do not bend the power cord excessively or place heavy objects on it.
•Do not twist or tie the power cord.
•Do not hook the power cord over a metal object, place a heavy object on
the power cord, insert the power cord between objects, or push the power
cord into the space behind the appliance.
•When moving the refrigerator, be careful not to roll over or damage the
power cord.
- This may result in an electric shock or re.
•Never unplug your refrigerator by pulling on the power cord.
Always grip the plug rmly and pull straight out from the outlet.
- Damage to the cord may cause a short-circuit, re, and/or electric shock.
•Do not use aerosols near the refrigerator.
- Using aerosols near the refrigerator may cause an explosion or re.
DA68-02981M (EN)-150612.indd 5 2015. 6. 12. �� 9:16

6 English
Safety information
Safety information
•Do not install this appliance near a heater or inammable material.
•Do not install this appliance in a humid, oily, or dusty location , or in a
location exposed to direct sunlight or water (rain, etc.).
•Do not install this appliance in a location where gas may leak.
- This may result in an electric shock or re.
•This refrigerator must be properly located and installed in
accordance with the instructions in this manual before you use
it.
•Connect the power plug in the proper position with the cord hanging
down.
- If you connect the power plug upside down, the wire can get cut off and
cause a re or electric shock.
•When moving the refrigerator, be careful not to roll over or damage the
power cord.
- This constitutes a re hazard.
•Make sure that the power plug is not crushed or damaged by the back of
the refrigerator.
•Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts the packing
materials on his or her head.
•The appliance must be positioned so that the plug is accessible after
installation.
- Failing to do so may result in an electric shock or re due to electric
leakage.
•You need to remove all the protective plastic lm before you initially plug
the product in.
DA68-02981M (EN)-150612.indd 6 2015. 6. 12. �� 9:16

English 7
Safety information
•The refrigerator must be safely grounded.
- Always make sure that you have grounded the refrigerator before
attempting to investigate or repair any part of the appliance.
Power leakages can cause severe electric shock.
•Plug the power plug into the wall socket rmly.
Do not use a damaged power plug, damaged power cord, or loose wall
socket.
- This may result in an electric shock or re.
•If the power cord is damaged, have it replaced immediately by the
manufacturer or one of its service agents.
DA68-02981M (EN)-150612.indd 7 2015. 6. 12. �� 9:16

8 English
Safety information
Safety information
Installation cautions
CAUTION
•Allow sufcient space around the refrigerator and install it on a at
surface.
- If your refrigerator is not level, the internal cooling system may not work
correctly.
- Keep the ventilation space in the appliance enclosure or mounting
structure clear of obstructions.
•Allow the appliance to stand for 2 hours after installation.
•We strongly recommend you have a qualied technician or service
company install the refrigerator.
- Failing to do so may result in an electric shock, re, explosion, problems
with the product, or injury.
DA68-02981M (EN)-150612.indd 8 2015. 6. 12. �� 9:16

English 9
Safety information
Critical usage warnings
WARNING
•Do not insert the power plug into a wall socket with wet hands.
•Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall and cause personal
injury and/or material damage.
•Do not insert hands, feet or metal objects (such as knives, etc.) into the
bottom or the back of the refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury
•Do not put a container lled with water on the refrigerator.
- If spilled, there is a risk of re or electric shock.
•Children should be supervised to ensure that they do not play with the
appliance.
- Keep fingers out of “pinch point” areas.
Clearances between the doors and cabinet are necessarily small.
- Be careful when you open the doors if children are in the area.
•Do not let children hang on the door.
A serious injury may occur.
•Do not let children go inside the refrigerator.
They could become trapped.
•Do not insert your hands into the bottom area under the appliance.
- Any sharp edges may cause personal injury.
•Do not let children step on a drawer cover.
- The drawer may break and cause them to slip.
•Do not overll the refrigerator with food.
- When you open the door, an item may fall out and cause personal injury
or material damage.
•Do not touch the inside walls of the freezer or products stored in the
freezer with wet hands.
- This may cause frostbite.
DA68-02981M (EN)-150612.indd 9 2015. 6. 12. �� 9:16

10 English
Safety information
Safety information
•Never put ngers or other objects into the water dispenser hole, ice
chute, or ice maker bucket.
- It may cause personal injury or material damage.
•Do not use or place any substances sensitive to temperature such as
inammable sprays, inammable objects, dry ice, medicine, or chemicals
near or inside of the refrigerator.
•Do not keep volatile or inammable objects or substances (benzene,
thinner, propane gas, alcohol, ether, LP gas, and other such products) in
the refrigerator.
- This refrigerator is for storing food only.
- This may result in re or explosion.
•Do not store pharmaceutical products, scientic materials, or temperature
sensitive products in the refrigerator.
- Products that require strict temperature controls must not be stored in the
refrigerator.
•Do not place or use an electrical appliance inside the refrigerator, unless it
is of a type recommended by the manufacturer.
•Do not stand on top of the appliance or place objects (such as laundry,
lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.)
on the appliance.
This may result in an electric shock, re, problems with the product, or
injury.
Do not put a container lled with water on the appliance.
- If spilled, there is a risk of re or electric shock.
•Do not use mechanical devices or any other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
•Do not damage the refrigerant circuit.
•Do not spray volatile material such as insecticide onto the surface of the
appliance.
- As well as being harmful to humans, it may also result in an electric
shock, re, or problems with the product.
•Never stare directly at the UV LED lamp for long periods of time.
- This may result in eye strain due to the ultraviolet rays.
DA68-02981M (EN)-150612.indd 10 2015. 6. 12. �� 9:16

English 11
Safety information
•Do not attempt to repair, disassemble, or modify the appliance
yourself.
•Do not use any fuse (such as cooper, steel wire, etc.) other than a standard
fuse.
•If your appliance needs to be repaired or reinstalled, contact your nearest
service center.
- Failing to do so may result in an electric shock, re, problems with the
product, or injury.
•If the interior or exterior LED lamp has gone out, please contact your
nearest service center.
•Children should be supervised to ensure that they do not play
with the appliance.
- Keep ngers out of “pinch point” areas. : Clearances between the doors
and cabinet are necessarily small.
Be careful when you open the doors if children are in the area.
•Do not let children hang on the door. A serious injury may occur.
•Do not let children go inside the refrigerator. They could become trapped.
•Bottles should be stored tightly together so that they do not fall out.
•This product is intended only for the storage of food in a domestic
environment.
•If a gas leak is detected, avoid any naked ames or potential sources of
ignition, and air the room in which the appliance is standing for several
minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or re.
•Use only the LED Lamps provided by the manufacturer or its service
agents.
DA68-02981M (EN)-150612.indd 11 2015. 6. 12. �� 9:16

12 English
Safety information
Safety information
•If the refrigerator emits a burning smell or smoke, unplug the
refrigerator immediately and contact your Samsung Electronics
service center.
•If you experience difculty changing a non-LED light, contact a Samsung
service center.
•If the product is equipped with LED Lamps, do not disassemble the Lamp
Covers and LED Lamps yourself.
- Please contact your service agents.
•If dust or water enters the refrigerator, unplug the refrigerator and
contact your Samsung Electronics service center.
- There is a risk of re.
DA68-02981M (EN)-150612.indd 12 2015. 6. 12. �� 9:16

English 13
Safety information
Usage cautions
CAUTION
•Do not re-freeze frozen foods that have thawed completely.
Do not place carbonated or zzy drinks in the freezer compartment.
Do not put bottles or glass containers in the freezer.
- When the contents freeze, the glass may break and cause personal injury.
•Use only the ice maker provided with the refrigerator.
•Have the refrigerator’s water supply installed by a suitably qualied
person and connected only to a potable water supply.
To operate the ice maker properly, water pressure of 20 ~ 125 psi (138 ~
862 kPa) is required.
If you will be away from home for a long period of time (on vacation, for
example) and won’t be using the water or ice dispensers, close the water
valve.
- Otherwise, water leakage may occur.
•If you won’t be using the refrigerator for a very long period of time,
(3 weeks or more) empty the refrigerator, unplug it, close the water valve,
wipe excess moisture from the inside walls, and leave the doors open to
prevent odors and mold.
DA68-02981M (EN)-150612.indd 13 2015. 6. 12. �� 9:16

14 English
Safety information
Safety information
•Service Warranty and Modication.
•Any changes or modications performed by a 3rd party on this
nished appliance are not covered under Samsung warranty service,
nor is Samsung responsible for safety issues that result from 3rd party
modications.
•Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic bag, the refrigerator
can be over cooled.
If this cooling period lasts too long, the water lter may break and cause
water leakage.
•If the refrigerator is disconnected from the power supply, you should wait
for at least ve minutes before plugging it back in.
•If you have a long vacation planned or do not intend to use the
refrigerator for a long period of time, (3 weeks or more) empty the
refrigerator, pull out the power plug, close the water valve, wipe excess
moisture from the inside walls, and leave the doors open to prevent odors
and mold.
- Letting the refrigerator run long periods of time without using it can
cause the insulation to deteriorate and may cause a re.
•To get the best performance from the product:
- Do not place food too close to the vents at the rear of the appliance as it
can obstruct free air circulation in the refrigerator compartment.
- Wrap food up properly or place it in airtight containers before putting it
into the refrigerator.
- Do not place glass bottles or carbonated beverages into the freezer.
They can freeze and break.
Broken beverage containers can cause injury.
- Please observe maximum storage times and expiration dates of frozen
goods.
DA68-02981M (EN)-150612.indd 14 2015. 6. 12. �� 9:16

English 15
Safety information
- There is no need to disconnect the refrigerator from the power supply if
you will be away for less than three weeks.
However, if you will be away for more than three weeks, remove all the
food, unplug the refrigerator, close the water valve, wipe excess moisture
from the inside walls, and leave the doors open to prevent odors and
mold.
•Fill the water tank and ice cube trays with potable water only (tap water,
mineral water, or puried water).
- Do not ll the tank with tea or a Sports drink.
This may damage the refrigerator.
•Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or property damage.
•If the product is ooded, make sure to contact your nearest service
center.
- There is a risk of electric shock or re.
DA68-02981M (EN)-150612.indd 15 2015. 6. 12. �� 9:16

16 English
Safety information
Safety information
Cleaning cautions
CAUTION
•Do not spray water directly on the inside or outside the refrigerator.
- There is a risk of re or electric shock.
•Do not use a hair dryer to dry the inside of the refrigerator.
•Do not place a lighted candle in the refrigerator to remove bad odors.
- This may result in an electric shock or re.
•Use a clean, dry cloth to remove any foreign matter or dust from the
power plug blades.
Do not use a wet or damp cloth when cleaning the plug.
- Otherwise, there is a risk of re or electric shock.
•Before cleaning or performing maintenance, unplug the appliance
from the wall socket.
- Failing to do so may result in an electric shock or re.
DA68-02981M (EN)-150612.indd 16 2015. 6. 12. �� 9:16

English 17
Safety information
Critical disposal warnings
WARNING
•DANGER : Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
- Take off the doors and door latch.
- Leave the shelves in place so that children cannot easily climb inside.
- Children trapped inside a refrigerator can hurt themselves or suffocate to
death.
•Please dispose of the packaging material from this product in an
environmentally friendly manner.
•Ensure that none of the pipes on the back of the appliance are damaged
prior to disposal.
•R-600a or R-134a is used as a refrigerant.
Check the compressor label on the rear of the appliance or the rating label
inside the fridge to see which refrigerant is used for your refrigerator.
If this product contains ammable gas (Refrigerant R-600a), contact your
local authority in regard to safe disposal of this product.
•When disposing of this refrigerator, remove the door/door seals and door
latch so that small children or animals cannot become trapped inside.
Children should be supervised to ensure that they do not play with the
appliance.
If trapped inside, the child may get hurt or suffocate to death.
•Cyclopentane is used in the insulation.
The gases in the insulation material require a special disposal procedure.
Please contact your local authorities in regard to the environmentally safe
disposal of this product.
•Keep all packaging materials well out of the reach of children, as
packaging materials can be dangerous to children.
- If a child places a bag over his or her head, the child could suffocate.
DA68-02981M (EN)-150612.indd 17 2015. 6. 12. �� 9:16

18 English
Safety information
Safety information
Additional tips for proper usage
NOTE
•In the event of a power failure, call the local ofce of your Electricity
Company and ask how long it is going to last.
- Most power failures that are corrected within an hour or two will not
affect your refrigerator temperatures. However, you should minimize the
number of door openings while the power is off.
- Should the power failure last more than 24 hours, remove all frozen food.
•If keys are provided with the refrigerator, the keys should be kept out of
the reach of children and not be in the vicinity of the appliance.
•The appliance might not operate consistently (frozen contents can thaw
or temperatures can become too warm in the frozen food compartment)
when sited for an extended period of time in a location where ambient
air temperatures are constantly below the temperatures for which the
appliance is designed.
•Do not store food which goes bad easily at low temperature, such as
bananas and melons.
•Your appliance is frost free, which means there is no need to manually
defrost your appliance.
This will be carried out automatically.
•Temperature rise during defrosting complies with ISO requirements.
But If you want to prevent an undue rise in the temperature of frozen
food while the appliance defrosts, wrap the frozen food in several layers
of newspaper.
•Any increase in the temperature of frozen food during defrosting can
shorten its storage life.
•Do not re-freeze frozen foods that have thawed completely.
•The temperature of two star section (sections) or compartment
(compartments) which have two star symbol ( ) is slightly higher than
other freezer compartment (compartments).
The two star section (sections) or compartment (compartments) is (are)
based on the instruction and/or the condition as delivered.
DA68-02981M (EN)-150612.indd 18 2015. 6. 12. �� 9:16

English 19
Safety information
Saving energy tips
- Install the appliance in a cool, dry room with adequate ventilation.
Ensure that it is not exposed to direct sunlight and never put it near a
direct source of heat (radiator, for example).
- Never block any vents or grilles on the appliance.
- Allow warm food to cool down before placing it in the appliance.
- Put frozen food in the refrigerator to thaw.
You can then use the low temperatures of the frozen products to cool
food in the refrigerator.
- Do not keep the door of the appliance open for too long when putting
food in or taking food out.
The shorter time for which the door is open, the less ice will form in the
freezer.
- Clean the rear of the refrigerator regularly.
Dust increases energy consumption.
- Do not set temperature colder than necessary.
- Ensure sufcient air exhaust at the refrigerator base and at the back wall
of the refrigerator.
Do not cover air vent openings.
- Allow clearance to the right, left, top when installing.
This will help reduce power consumption and keep your energy bills
lower.
- For the most efcient use of energy, please keep the all inner ttings such
as baskets, drawers, shelves on the position supplied by manufacturer.
DA68-02981M (EN)-150612.indd 19 2015. 6. 12. �� 9:16

20 English
Safety information
Safety information
This appliance is intended to be used in household and similar applications
such as
- staff kitchen areas in shops, ofces and other working environments;
- farm houses and by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
DA68-02981M (EN)-150612.indd 20 2015. 6. 12. �� 9:16
