Samsung RS27FDBTNSR User manual

English
Refrigerator
user manual
imagine the possibilities
Thank you for purchasing a Samsung product.
To receive more complete service or accessory parts,
please register your product at or contact
www.samsung.com/register
1-800-SAMSUNG (726-7864)
Built-in
This manual is made with 100% recycled paper.
DA68-02935A-02.indb 1 13. 8. 28. �� 9:10

02_ safety information
SAFETY INFORMATION
• Before operating the
appliance, please read this
manual thoroughly and retain
it at a safe place near the
appliance for your future
reference.
• Use this appliance only for
its intended purpose as
described in this instruction
manual.
This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction
concerning the use of the
appliance by a person
responsible for their safety.
• Warnings and Important
Safety Instructions in this
manual do not cover all
possible conditions and
situations that may occur.
It is your responsibility to use
common sense, caution,
and care when installing,
maintaining, and operating
your appliance.
• Because the following
operating instructions
cover various models, the
characteristics of your
refrigerator may differ slightly
from those described in this
manual. All warnings may be
applicable.
If you have any questions
or concerns, contact your
nearest service center or find
help and information on line
at www.samsung.com.
safety information
DA68-02935A-02.indb 2 13. 8. 28. �� 9:10

safety information _03
Important safety symbols
and precautions:
WARNING
Hazards or unsafe practices
that may result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices
that may result in minor
personal injury or property
damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions
explicitly.
Unplug the power plug
from the wall socket.
Make sure the machine
is grounded to prevent
electric shock.
Call the service center for
help.
Note
These warning signs are
here to prevent injury to you
and others.
Please follow them carefully.
After reading this section,
keep it in a safe place for
future reference.
WARNING
CRITICAL
TRANSPORTATION AND
SITE WARNINGS
• When transporting and
installing the appliance,
care should be taken to
ensure that no parts of
the refrigerant circuit are
damaged.
• R-600a or R-134a is used as
a refrigerant.
Check the compressor label
on the rear of the appliance
or the rating label inside the
refrigerator to see which
refrigerant is used in your
refrigerator.
DA68-02935A-02.indb 3 13. 8. 28. �� 9:10

04_ safety information
WARNING
CRITICAL INSTALLATION
WARNINGS
• Do not install this
appliance near a heater
or flammable material.
• Do not spray flammable gas
near the refrigerator.
- There is a risk of explosion or
fire.
• Do not install this appliance
in a humid, oily or dusty
location, or in a location
exposed to direct sunlight or
water (rain drops).
- Exposure can cause
insulation to deteriorate.
Deteriorated insulation on
electrical parts may cause
electric shock or fire.
• Do not place this refrigerator
in direct sunlight or expose to
the heat from stoves, room
heaters, or other appliances.
• Do not plug several
appliances into the same
multiple power board.
The refrigerator should
always be plugged into its
own individual electrical
outlet which has a voltage
rating that matches the
voltage on the rating plate.
- This provides the best
performance and also
prevents overloading house
wiring circuits, which could
cause a fire hazard from
overheated wires.
• If the wall socket is loose, do
not insert the power plug.
- There is a risk of electric
shock or fire.
• Do not use a cord that
shows cracks or abrasion
damage along its length or at
either end.
• Do not bend the power cord
excessively or place heavy
articles on it.
• Do not use aerosols near the
refrigerator.
- Aerosols used near the
refrigerator may cause an
explosion or fire.
• Do not install this appliance
in a location where gas may
leak.
- This may result in an electric
shock or fire.
• We strongly
recommend you use
a qualified technician
or service company to
install or service the
refrigerator.
DA68-02935A-02.indb 4 13. 8. 28. �� 9:10

safety information _05
- Failing to do so may result
in an electric shock, fire,
explosion, problems with the
product, or injury.
• This refrigerator must be
properly installed and located
in accordance with the
manual before it is used.
• Connect the power plug in
the proper position with the
cord hanging down.
- If you connect the power
plug upside down, the wire
can get cut off and a cause
fire or an electric shock.
• Make sure that the power
plug is not squashed or
damaged by the back of the
refrigerator.
• When moving the refrigerator,
be careful not to roll over or
damage the power cord.
- This constitutes a fire hazard.
• The appliance must be
positioned so that the plug is
accessible after installation.
• The refrigerator must be
safely grounded.
- Always make sure that
you have grounded the
refrigerator before attempting
to investigate or repair any
part of the appliance. Power
leakages can cause severe
electric shock.
• Never use gas pipes,
telephone lines, or other
potential lightning attractors
as an electrical ground.
- Improper use of the
grounding plug can result
in a risk of electric shock.
If it is necessary to use an
extension cord, use only a
3-wire extension cord that
has a 3-blade grounding plug
and a 3-slot receptacle that
will accept the plug on the
appliance.
The marked rating of the
extension cord should be
AC115-120V, 10A, or
more.
If a grounding adapter
is used, make sure the
receptacle box is fully
grounded.
• Plug the power plug into the
wall socket firmly.
Do not use a damaged
power plug, damaged power
cord, or loose wall socket.
- This may result in an electric
shock or fire.
• Do not modify the
refrigerator. Unauthorized
modifications can cause
DA68-02935A-02.indb 5 13. 8. 28. �� 9:10

06_ safety information
safety problems.
To reverse an unauthorized
modification, we will charge
the full cost of parts and
labor.
• If the power cord is
damaged, have it
replaced immediately by
the manufacturer or its
service agent.
• The fuse on the refrigerator
must be changed by a
qualified technician or service
company.
- Failing to do so may result in
an electric shock or personal
injury.
• Never stare directly at the UV
LED lamp for long periods of
time.
- This may result in eye strain
due to the ultraviolet rays.
CAUTION
INSTALLATION CAUTIONS
• Allow sufficient space
around the refrigerator
and install it on a flat
surface.
- If your refrigerator is not level,
the internal cooling system
may not work correctly.
• Keep the ventilation space in
the appliance enclosure or
mounting structure clear of
obstructions.
• Allow the appliance to stand
for 2 hours after installation.
• We strongly recommend you
use a qualified technician or
service company to install
the refrigerator.
- Failing to do so may result
in an electric shock, fire,
explosion, problems with the
product, or injury.
• Do not stand on top of the
appliance or place objects
(such as laundry, lighted
candles, lighted cigarettes,
dishes, chemicals, metal
objects, etc.) on the
appliance.
- This may result in an electric
shock, fire, problems with the
product, or injury.
DA68-02935A-02.indb 6 13. 8. 28. �� 9:10

safety information _07
WARNING
CRITICAL USAGE
WARNINGS
• Do not insert the power
plug with wet hands.
- This may result in an electric
shock.
• Do not store articles on the
top of the appliance.
- When you open or close the
door, the articles may fall and
cause personal injury and/or
material damage.
• Do not put items filled with
water on the refrigerator.
- If spilled, there is a risk of fire
or electric shock.
• Do not let children hang on
the door. Serious injury can
occur.
• Do not leave the doors of
the refrigerator open while
the refrigerator is unattended
and do not let children enter
the refrigerator.
• Do not allow babies or
children go inside the drawer.
- It can cause death from
suffocation by entrapment or
personal injury.
• Do not sit on the Freezer
door.
- The door may be broken and
cause a personal injury.
• If you removed the divider
from the drawer to clean it
or to perform some other
action, you must reinstall
the drawer divider using the
provided screws afterwards
to prevent children from
becoming entrapped.
• Children should be
supervised to ensure that
they do not play with the
appliance.
- Keep fingers out of “pinch
point” areas.
Clearances between the
doors and cabinet are
necessarily small.
Be careful when you open
the doors when children are
in the area.
• Never put fingers or other
objects into the dispenser
hole, ice chute, or ice maker
bucket.
- It may cause personal injury
or material damage.
• Do not insert hands, feet
or metal objects (such
as knives, etc.) into the
bottom or the back of the
refrigerator.
- This may result in an electric
shock or injury.
DA68-02935A-02.indb 7 13. 8. 28. �� 9:10

08_ safety information
- Any sharp edges may cause
personal injury
• Do not store volatile or
flammable substances such
as benzene, thinner, alcohol,
ether, or LP gas in the
refrigerator.
- The storage of any of such
products may cause an
explosion.
• Do not store low
temperature-sensitive
pharmaceutical products,
scientific materials, or other
low temperature-sensitive
products in the refrigerator.
- Products that require
strict temperature controls
must not be stored in the
refrigerator.
• Do not place or use electrical
appliances inside the
refrigerator, unless they are of
a type recommended by the
manufacturer.
• Do not use a hair dryer to dry
the inside of the refrigerator.
Do not place a lighted candle
in the refrigerator to remove
bad odors.
- This may result in an electric
shock or fire.
• Do not touch the inside walls
of the freezer or products
stored in the freezer with wet
hands.
- This may cause frostbite.
• Do not use mechanical
devices or any other means
to accelerate the defrosting
process, other than those
recommended by the
manufacturer.
• Do not damage the
refrigerant circuit.
• This product is intended
only for the storage
of food in a domestic
environment.
• Bottles should be stored
tightly together so that they
do not fall out.
• If you detect a gas leak,
avoid any naked flames or
potential sources of ignition
and air the room in which
the appliance is standing for
several minutes.
• In the event of a gas leak
(such as propane gas, LP
gas, etc.), ventilate the room
immediately without touching
the power plug.
Do not touch the appliance
or power cord.
- Do not use a ventilating fan.
- A spark may result in an
DA68-02935A-02.indb 8 13. 8. 28. �� 9:10

safety information _09
explosion or fire.
• Use only the LED Lamps
provided by the manufacturer
or a Samsung service center.
• Children should be
supervised to ensure that
they do not play with and/or
climb into the appliance.
• Do not attempt to
repair, disassemble, or
modify the appliance
yourself.
• Do not use any fuse (such as
cooper, steel wire, etc.) other
than the standard fuse.
• If your appliance needs to
be repaired or reinstalled,
contact your nearest service
center.
- Failing to do so may result
in an electric shock, fire,
problems with the product,
or injury.
• If the appliance
generates a strange
noise, a burning smell,
or smoke, unplug the
power plug immediately
and contact your
nearest service center.
- Failing to do so may result in
an electric or fire hazards.
• If you experience difficulty
when changing the light,
contact service agent.
• If the products is equipped
with an LED Lamp, do not
disassemble the Lamp Cover
and LED Lamp yourself.
- Please contact the nearest
Samsung service center.
• If any foreign substance
such as water or dust enters
the mechanical or electrical
sections of the refrigerator
while you are cleaning it,
unplug the power plug
and contact your nearest
Samsung service center.
- There is a risk of fire.
DA68-02935A-02.indb 9 13. 8. 28. �� 9:10

10_ safety information
CAUTION
USAGE CAUTIONS
• To get the best
performance from the
product:
- Do not place food too close
to the vents at the rear of the
appliance. This can obstruct
free air circulation in the
refrigerator compartment.
- Wrap the food up properly or
place it in airtight containers
before putting it into the
refrigerator.
- Do not put food you have
just put into the freezer near
already frozen food.
• Do not place carbonated
or fizzy drinks in the freezer
compartment.
Do not put bottles or glass
containers in the freezer.
- When the contents freeze,
the glass may break and
cause personal injury and
property damage.
• Do not change or modify
the functionality of the
refrigerator.
- Changes or modifications
may result in a personal injury
and/or property damage.
Any changes or modifications
performed by a 3rd party on
this completed appliance are
not covered under Samsung
warranty service. Samsung
is not responsible for any
safety problems, injuries, or
damage resulting from 3rd
party modifications.
• Do not block air holes.
- If the air holes are blocked,
especially with a plastic bag,
the refrigerator can be over
cooled. If this cooling period
lasts too long, the water filter
may break and cause water
leakage.
• Please observe maximum
storage times and expiration
dates of frozen goods.
• If you won’t be using the
refrigerator for a very long
period of time, (3 weeks or
more) empty the refrigerator,
unplug it, close the water
valve, wipe excess moisture
from the inside walls, and
leave the doors open to
prevent odors and mold.
• Fill the water tank and ice
cube tray with potable water
only.
- Do not fill the tank with tea or
a sports drink.
This may damage the
DA68-02935A-02.indb 10 13. 8. 28. �� 9:10

safety information _11
refrigerator.
• Use only the ice-maker
provided with the refrigerator.
• The water supply to this
refrigerator must be installed/
connected by a suitably
qualified person and
connected to a potable water
supply only.
• To operate the ice-maker
properly, water pressure of
138~862kPa (1.4~8.8 kgf/
m³) is required.
• Do not spray volatile material
such as insecticide onto the
surface of the appliance.
- As well as being harmful to
humans, it may also result
in an electric shock, fire or
problems with the product.
• Do not apply strong shock
or excessive force onto the
surface of glass.
- Broken glass may result
in a personal injury and/or
property damage.
CAUTION
CLEANING AND
MAINTENANCE
CAUTIONS
• Before cleaning
or performing
maintenance, unplug
the appliance from the
wall socket.
- Failing to do so may result in
an electric shock or fire.
• Do not spray water directly
on the inside or outside the
refrigerator.
- There is a risk of fire or
electric shock.
• Do not use or place any
substances sensitive
to temperature such
as inflammable sprays,
inflammable objects, dry ice,
medicine, or chemicals near
the refrigerator.
Do not keep volatile or
inflammable objects or
substances (benzene,
thinner, propane gas, etc.) in
the refrigerator.
- This refrigerator is for storing
food only.
- This may result in a fire or an
explosion.
• Do not spray cleaning
DA68-02935A-02.indb 11 13. 8. 28. �� 9:10

12_ safety information
products directly on the
display.
- Printed letters on the display
may come off.
• Remove any foreign matter
or dust from the power plug
pins using a dry cloth.
Do not use a wet or damp
cloth when cleaning the plug.
- Otherwise there is a risk of
fire or electric shock.
• Never put fingers or objects
such as knives, etc. into the
dispenser hole or ice chute.
- This may cause personal
injury or material damage.
• Unplug the refrigerator
before cleaning
and performing
maintenance.
WARNING
STATE OF CALIFORNIA
PROPOSITION 65
WARNINGS:
• The California Safe Drinking
Water and Toxic Enforcement
Act requires the Governor
of California to publish a list
of substances known to the
State of California to cause
cancer, birth defects, or
other reproductive harm, and
requires businesses to warn
of potential exposure to such
substances.
This product contains a
chemical known to the State
of California to cause cancer,
birth defects, or other
reproductive harm.
This appliance can cause
low-level exposure to
some of the substances
listed, including benzene,
formaldehyde, and carbon
monoxide.
DA68-02935A-02.indb 12 13. 8. 28. �� 9:10

safety information _13
WARNING
CRITICAL DISPOSAL
WARNINGS
• DANGER : Risk of child
entrapment. Before you
throw away your old
refrigerator or freezer:
- Take off the doors and door
latch.
- Leave the shelves in place
so that children cannot easily
climb inside.
- Children trapped inside
a refrigerator can hurt
themselves or suffocate to
death.
• Please dispose of the
packaging material from this
product in an environmentally
friendly manner.
• Ensure that none of the
pipes on the back of the
appliance are damaged prior
to disposal.
• R-600a or R-134a is used as
a refrigerant.
Check the compressor
label on the front top of the
appliance or the rating label
inside the refrigerator to see
which refrigerant is used for
your refrigerator.
When this product contains
flammable gas (Refrigerant
R-600a), contact your local
authorities regarding the safe
disposal of this product.
Cyclopentane is used as an
insulation blowing gas.
Consequently, the insulation
material in the refrigerator
requires special disposal
procedures.
Please contact your local
authorities in regard to the
environmentally safe disposal
of this product.
Ensure that none of the
pipes on the back of the
appliances are damaged
prior to disposal.
• When disposing of this
product or other refrigerators,
remove the door/door seals
and door latch so that small
children or animals cannot
become trapped inside.
Leave the shelves in place so
that children may not easily
climb inside. Children should
be supervised to ensure that
they do not play with the old
refrigerator.
- Children trapped inside
a refrigerator can hurt
themselves or suffocate to
death.
DA68-02935A-02.indb 13 13. 8. 28. �� 9:10

14_ safety information
• Please dispose of the
packaging material for this
product in an environmentally
friendly manner.
• Keep all packaging materials
well out of the reach of
children, as packaging
materials can be dangerous
to children.
- If a child places a bag over
his or her head, the child
could suffocate.
ADDITIONAL TIPS
FOR PROPER USAGE
• In the event of a power
failure, call the local office of
your electric company and
ask how long it is going to
last.
- Most power failures that are
corrected within an hour
or two will not affect your
refrigerator temperatures.
However, you should
minimize the number of door
openings while the power is
off.
- Should the power failure last
more than 24 hours, remove
all frozen food.
• If keys are provided with the
refrigerator, the keys should
be kept out of the reach of
children and not be in the
vicinity of the appliance.
• The appliance might not
operate consistently (frozen
contents can thaw or
temperatures can become
too warm in the frozen food
compartment) when sited for
an extended period of time in
a location where ambient air
temperatures are constantly
below the temperatures
for which the appliance is
designed.
• Do not store food which
spoils easily at low
temperature, such as
bananas and melons.
• Your appliance is frost free,
which means there is no
need to manually defrost
your appliance. This will be
carried out automatically.
• Temperature rise during
defrosting complies with ISO
requirements.
However, if you want to
prevent an undue rise in the
temperature of the frozen
food while the appliance
defrosts, wrap the frozen
food in several layers of
newspaper.
DA68-02935A-02.indb 14 13. 8. 28. �� 9:10

safety information _15
• Any increase in the
temperature of frozen food
during defrosting can shorten
its storage life.
• Do not re-freeze frozen foods
that have thawed completely.
Saving Energy Tips
- Install the appliance in a
cool, dry room with adequate
ventilation.
Ensure that it is not exposed
to direct sunlight and never
put it near a direct source of
heat (a radiator, for example).
- Never block any vents or
grilles on the appliance.
- Allow warm food to cool
down before placing it in the
appliance.
- Put frozen food in the
refrigerator to thaw.
You can then use the low
temperatures of the frozen
products to cool food in the
refrigerator.
- Do not keep the door of
the appliance open for too
long when putting food in or
taking food out.
The shorter the time the door
is open, the less frost build-
up you’ll have in the freezer.
- Provide sufficient clearance
to the right, left, back, and
top when installing for air
circulation.
This will help reduce power
consumption and keep your
energy bills lower.
DA68-02935A-02.indb 15 13. 8. 28. �� 9:10

16_ safety information
1. Regulatory Notice
1.1 FCC Notice
FCC CAUTION:
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Contains Transmitter Module FCC ID: A3LDNURS11
This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received including interference that cause undesired
operation.
For product available in the USA/Canada market, only channel 1~11 can be operated.
Selection of other channels is not possible.
FCC STATEMENT:
This equipment has been tested and found to comply within the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a different circuit from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator
and your body. This device and its antenna(s) must not be co-located or operation in conjunction with any
other antenna or transmitter.
SAVE THESE INSTRUCTIONS
CAUTION
DA68-02935A-02.indb 16 13. 8. 28. �� 9:10

safety information _17
1. Regulatory Notice
1.2 IC Notice
Contains Transmitter Module IC: 649E-DNURS11
The term “IC” before the radio certification number only signifies that Industry Canada technical
specifications were met. Operation is subject to the following two conditions : (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.
For product available in the USA/Canada market, only channel 1~11 can be operated.
Selection of other channels is not possible.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm between the
radiator & your body. This device and its antenna(s) must not be co-located or operation in conjunction
with any other antenna or transmitter.
SAVE THESE INSTRUCTIONS
contents
SETTING UP YOUR SIDE-BY-SIDE REFRIGERATOR …………………………… 18
OPERATING THE SAMSUNG SIDE-BY-SIDE REFRIGERATOR………………… 23
TROUBLESHOOTING……………………………………………………………… 100
DA68-02935A-02.indb 17 13. 8. 28. �� 9:10

18_ setting up
INSTALLATION REQUIREMENTS
The installation location you choose must meet the
requirements listed in this section.
Selecting an installation place
• Check the refrigerator’s dimensions in the table
below before you begin to install it and confirm
it can clear all the doors on its way to the
installation location.
- If the refrigerator cannot clear the doors, you
cannot install it.
Front and side dimensions
(inches)
Model A B C D E
RS27FDBTNSR/*
47.6
(1209mm)
28.3
(720mm)
82
(2083mm)
92.1
(2340mm)
85.9
(2182mm)
Door 90º Open Door 130º Open
Dimensions with doors open
(inches)
Model A B C D E F
RS27FDBTNSR/*
44.5
(1129mm)
52.5
(1333mm)
40.6
(1032mm)
14.4
(365mm)
20.1
(510mm)
46.3
(1176mm)
• Allow sufficient space on
the right, left, back, and
top for air circulation.
- If there is not enough
space, you cannot install
the refrigerator.
Location of
Electrical
Receptacle
Water Supply
Opening (20x20)
Enclosure dimensions
(inches)
Model A B C
RS27FDBTNSR/*
48
(1219mm)
27.6
(701mm)
83.5 Min,
84.3 Max
(2121mm Min,
2141mm Max)
• Confirm that the floor is flat.
- If the refrigerator is installed on
an uneven floor, it will cause
vibration and noise.
• Confirm that the floor can
support the weight of the
refrigerator and the food inside
(1102.3lb (500kg) total).
• Confirm that the refrigerator will
be within reach of a grounded
wall outlet.
• If the refrigerator is a dispenser
model, confirm that it will be
within easy reach of a water
supply and that the humidity in
the location is low.
- The refrigerator needs easy
access to a water supply for the
water and ice dispensers.
Setting up your side-by-side
refrigerator
DA68-02935A-02.indb 18 13. 8. 28. �� 9:10

setting up _19
01 SETTING UP
• Avoid a location that is very
hot or extremely cold.
- Confirm that the location
has ambient temperatures
between 41ºF and 110ºF.
(5ºC and 43ºC)
- If you install the refrigerator in a location with
extremely cold or hot ambient temperatures, it
could malfunction, causing its cooling capacity
to decrease and its power consumption to
increase.
Ground the product
The refrigerator must be properly grounded to
prevent any power leakages or electric shocks.
To ground the refrigerator, plug it in to a grounded,
three blade wall outlet.
If the outlet in the installation location cannot
accept a three blade, grounded plug, have a
qualified electrician replace the current outlet with a
three blade grounded outlet.
Improper use of the grounding plug can result in
a risk of electric shock. If it is necessary to use
an extension cord, use only a 3-wire extension
cord that has a 3-blade grounding plug and a
3-slot receptacle that will accept the plug on the
refrigerator.
The marked rating of the extension cord should be
AC115-120V, 10A, or more.
If a you use a grounding adapter, make sure the
receptacle box is fully grounded.
Caution: Never use gas pipes, telephone lines, or
other potential lightning attractors as an electrical
ground.
REFRIGERATOR PARTS
Display (Touch Screen) : Displays time, refrigerator
temperatures, built in apps, etc.
Unit grill
Freezer door
Water/ice supplier (dispenser) : Supplies cold water purified by
the purification filter or supplies ice made by the ice-maker.
Water purification filter
Handle Fridge door
Power switch : Switches the refrigerator on or off.
Ice storage : Makes
and stores ice.
Ice outlet (Ice
discharge port)
DA68-02935A-02.indb 19 13. 8. 28. �� 9:10

20_ setting up
ALIGNING THE HEIGHTS OF THE
REFRIGERATOR DOORS
If the Fridge door is lower than the Freezer door,
adjust the door height by turning the door height
adjustment bolt at the bottom of the Fridge door.
Height difference
• Turning it counter clockwise increases the
height of the door and turning it clockwise
decreases the height of the door.
• Loosen the screw (1), turn the adjusting bolt
(2) with a spanner to align the door height to
the Freezer door and then fix it by fastening the
screw (1).
(1) Screw
(2) Adjusting bolt
• After adjusting the height, be sure to install the
protective rubber inserts as shown in the figure
to protect your feet from injury.
If you increase the height of the Fridge
door by too much, the switch may be
damaged or the door may not close
properly.
CAUTION
INSTALLING THE WATER
DISPENSER LINE
A water dispenser with a filter is one of the helpful
features on your new refrigerator.
To help promote better health, the water filter
removes unwanted particles from your water.
However, it does not sterilize or destroy
microorganisms.
You may need to purchase a water purifying
system to do that.
The water line also connects to the ice maker.
For the ice maker to operate properly, water
pressure of 20-125psi (138 ~ 862kPa) is required.
If the refrigerator is installed in an area with low
water pressure (below 20 psi), you can install a
booster pump to compensate for the low pressure.
After you have connected the water line, make
sure the water storage tank inside the refrigerator
is properly filled.
To do this, press the water dispenser lever until the
water runs from the water outlet.
Water line installation kits are available at
extra cost from your dealer.
We recommend using a water line
installation kit that contains copper tubing
and ¼” compression nut.
Connecting to the water supply line
1. First, shut off the main water
supply.
2. Locate the nearest cold water drinking line and
install the pipe clamp and shut off valve.
Pipe clamp
Cold water line
Shut off valve
DA68-02935A-02.indb 20 13. 8. 28. �� 9:10
