Samsung RT23 User manual

REFRIGERATOR
OWNER’S INSTRUCTIONS
Before operating the unit, please read this manual thoroughly, and
retain for future refefence.
DA99-00555E REV (0.1)
Size 207/140 mm

MAIN FEATURES
Large Freezer Storage Area
- Stores large quantities of food in the freezer.
Jumbo Storage Guard
- Holds large bottles securely.
Adjustable Storage Guards
Position them for your convenience and according
to the height of your food containers.
-
Bio-Fresh Zone (Select model)
Keeps vegetables fresh for longer periods.
-
Sliding Drawer (Select model)
- Extra storage space for vegetables and fruits.
ICooling
- Advanced air circulation for faster surround cooling.
Super Freeze Zone (Select model)
Freezes stored items quickly.
-
Twist Ice-Tray (Select model)
Spring mechanism for automatic release of ice cubes.
-
BASIC PREPARATION
Read Instructions.
Please read all safety and operating instructions before
operating this appliance.
Retain Instructions.
Please keep this Owner's Manual for future reference.
Heed Warnings.
All warnigns, Cautions and Notes on this refrigerator are
important; please pay attention to them.
Follow Instructions.
For best results, follow all instructions given in this manual.
Model and Serial Numbers.
Include both the model number and the serial number when
corresponding with your Dealer concerning this product.
Contents
MAIN FEATURES ................................
CONTENTS .........................................
BASIC PREPARATION ........................
- Getting Started ...................................
INSTALLATION ....................................
CAUTIONS WHILE USING .................
PARTS ..................................................
REPLACING THE LAMP ......................
STORING FOOD .................................
HOW TO USE ......................................
- Temperature control ...........................
- Ice cube maker ..................................
- Chiller Compartment .........................
- Vegetable bin .....................................
LEVELING THE APPLIANCE ..............
REMOVING ACCESSORIES ...............
BEFORE CALLING SERVICE ..............
1
1
1
2
2
3,4
5,6
7
8
9
9
10
11
11
12
13,14
15,16
Date of Purchase :
Model No. :
Serial No. :
11

Before plugging in for the first time, allow the
refrigerator to stabilize for at least one hour.
Allow the freezer compartment to cool for 2 to 3
hours before storing food.
22
22
11
11
Avoid locations affected by draughts
or dampness.
For optimum operation, normal room
temperature is recommended. Avoid
locations in direct sunlight, near heaters,
radiators, stoves or ovens.
33
33
Allow a 100mm space between the refrigeratgor and the wall.
If your refrigerator is going into a receased area, allow at
least 300mm clearance above the refrigerator.
44
44
For personal safety, properly ground this appliance.
Do not ground this refrigerator with a telephone line,
gas pipe, etc.
22
Getting Started
INSTALLATION
above 300mm
above 100mm above 100mm

11
11
Do not allow water to splash onto
the refrigerator.
Water impairs the insulation of
electric parts and may cause an
electrical shock or a fire hazard.
-
-
Do not use flammable sprays such
as lacquer and paint near the
refrigerator.
Heat from the refrigeration unit may
ignite flammable aerosols.
22
22
-
-
Do not allow unattended children to play in
or around refrigerators and other large
appliances. The child may get hurt or they
could damage the appliance.
Do not allow children to hand on to the
refrigerator door.
33
33
-
-
3
CAUTIONS WHILE USING

For optimum operation, do not leave the door open
for any longer than necessary.
Leaving the door open allows warmer air to enter
the refrigerator and causes the refrigeration unit to
use more energy to maintain the temperature.
-
-
Do not store volatile chemicals such as
ether and benzene in the refrigerator.
The fumes, besides damaging food, can
build up and cause an explosion.
-
-
Do not use the refrigerator if it is not operating
correctly or has been damaged. Disconnect it from
the power supply and call your local service center.
If the power cord is damaged, avoid a hazard by
replacing it through the manufacturer or its service
agent or a similarly qualified person
-
-
Always be careful of not banging your head on the
bracket lock while storing or taking out food.
-
Frequent opening of door can cause excessive
frost in the unit that will reduce the cooling
momentarily, this is a general phenomenon
especially in coastal or high humidity area. It is
not a malfunction. Opening of door should be avoided
while defrosting.
Avoid keeping freezer door open for long time to prevent
frost accumulation.
-
44
44
55
55
66
66
77
77
88
88
4
-

Twist Ice Cube Tray (Select model)
Ice Storage Bin (Select model)
Freezer Compartment Temperature
Control
Guard FRE upp (Select model)
Super-Freeze Zone
(Select model)
Wire Shelf (Economy only)
Chiller Compartment (Select model)
Refrigerator Compartment Temperature
Control
i-Cooling
Refrigerator Shelf (Plastic or Steel)
Lamp
Adjustable Storage Guard
Dairy Guard (Select model)
Jumbo Guard
Bottle Storage Guard
Bio-Fresh Zone (Select model)
Sliding Drawer (Select model)
55
PARTS (TYPE - I)
It is recommended to store fruits & vegetables in Bio-fresh Zone/Case vegetable.

66
Twist Ice Cube Tray (Select model)
Ice Storage Bin (Select model)
Freezer Compartment Temperature
Control
Super-Freeze Zone (Select model)
Freezer shelf
Chiller Compartment (Select model)
Refrigerator Compartment
Temperature Control
i-Cooling
Refrigerator Shelf (Plastic or Steel)
Lamp
Adjustable Storage Guard
Dairy Guard (Select model)
Jumbo Guard
Bottle Storage Guard
Bio-Fresh Zone (Select model)
Sliding Drawer (Select model)
Bottle Guide (Select model)
PARTS (TYPE - II)
It is recommended to store fruits & vegetables in Bio-fresh Zone/Case vegetable.

-
-
11
11
22
22
77
Press upper tab of the lamp cover
with some tool such as driver and
pull it out.
Turn the existing lamp bulb and replace it with a new one.
Replace the lamp cover by aligning the cover at the top ( ) and carefully pressing
it into place ( )
1
2
REPLACING THE LAMP

Store food in small portions (Optional)
Seal food in containers with lids, in plastic wrap or
in plastic bags to prevent drying and the mingling
of odors.
Allow hot food and drinks to cool to
room temperature before placing them in
the refrigerator or freezer.
Allow sufficient space between stuff
to help the circulation of cool air.
Place liquid at the front of the refrigerator
to avoid freezing.
Wash dry fruits and vegetables
before placing them in the
refrigerator.
88
STORING FOOD

Temperature control
COLDEST
Freezer Temperature control
Turn the Temperature Control to "COLDEST" if you;
have a lot of food to store (refrigerator or freezer)
want to make ice (freezer)
require fast freezing (freezer)
-
-
-
Refrigerator Temperature control
Turn the Temperature Control to the midway point
between "COLDEST" and "COLD" for normal
refrigerating or freezing mode.
Turn the Temperature Control to "COLD" if you
want to store only a small amount of food in the
refrigerator or freezer.
When the air surrounding the refrigerator is below 5°C, turn the
Temperature Control to "COLD" to avoid freezing.
Apart from above mentioned Knob setting settings if you desire to
increase or reduce the cooling, turn the Knob clockwise or
anticlockwise beyond the marked positions respectively.
NOTE
-
-
99
HOW TO USE
NORMAL
COLD
Refrigerator
Freezer
Freezer Refrigerator
Freezer Refrigerator

Ice Cube Maker (Premium Type)
Fill the ice cube tray with water taking
care not to overfill.
1
11
Slide the tray onto the ice cube shelf.
2
22
When ice is formed, remove the ice cubes
from the ice cube tray by twisting the ice tray
knobs. Make sure the ice storage bin is beneath
the ice cube tray (see diagram below).
3
33
Ice Cube Maker (Economy Type)
1010
Knobs of ice tray
Water level
Ice trays are recommended to make Ice faster.

Chiller Compartment (Premium only)
This compartment helps preserve the taste of food and
prolongs its freshness by freezing the surface of the food
only. Use the chiller for storing cheese, meat, snacks, fish
or any food to be used soon.
Bio-Fresh Zone (Premium only)
This compartment maintains the moisture and
freshness of vegetables. It maintains necessary
humidity and protects the vegetables from
direct draughts of cold air which prevents drying.
To increase humidity, set the humidity control to high.
To decrease humidity, set it to low.
The vegetable bin is not suitable for storing tropical fruits such as bananas, pineapples, etc.
CAUTION
1111
HUMIDITY CONTROL HUMIDITY CONTROL

When the refrigerator leans to the left,
turn the left front foot counterclockwise.
When the refrigerator leans to the right,
turn the right front foot counterclockwise.
1212
LEVELING THE APPLIANCE
To compensate for any floor unevenness, adjust
the height of the appliance by turning the
adjustable feet clockwise or counterclockwise.
The adjustable feet are at the front along the
lower edge of the refrigerator chassis.

Freezer Shelf (Premium model)
Pull the shelf forward and slide
it out.
-
Refrigerator Shelf
Pull the shelf forward until it
meets the stopper.
Tilt the front of the shelf up and
pull it out.
-
-
Bio-Fresh Zone Bin and Cover (Premium only)
Pull the vegetable bin forward
and take it out of the refrigerator.
Lift the cover up and pull it out
of the refrigerator.
-
-
1313
REMOVING ACCESSORIES

Chiller Compartment
Pull the chiller compartment towards
you until it meets the stopper.
Tilt the front upward and pull
the compartment out.
-
-
Adjustable Storage Guard
Lift the guard up and slide it out (These
storage guards are adjustable and may be
positioned to best fit your needs.)
Bottle Storage Guards
Lift the guard up and slide it out (This
bottle storage guard is not adjustable;
it fits in only one position.)
Dairy Guard (Premium only)
Lift the guard up and slide it out.
(This bottle storage guard is not adjustable;
it fits in only one position.)
When the cover is away from the guard.
1.
2.
3.
Stick the left boss of the cover into the
hole as shown.
Lift the cover up at the end.
Push the right boss of the cover into the
hole.
1414

1515
BEFORE CALLING SERVICE
ProblemProblem Probable causeProbable cause SolutionSolution
Power plug not connected properly Connect the power plug properly
Input electricity supply voltage
Low/High
Use stabilizer for rated voltage
Stabilizer not working
1. Refrigerator
not working
2. Excess
Cooling
Low
Cooling
Temperature control knob set
towards COLDEST cooling
position
Rotate the Temperature control knob towards
COLD cooling position
No clearance from sides Keep refrigerator away from wall for better performance
Stuff stored in front of air holes
Don't Store hot food till it comes to room
temperature
Avoid door opening for long time
Hot food stored inside
Frequent open/close of door and
door open for long time
Temperature control knob set
towards COLD cooling
position
Rotate the Temperature control knob towards
COLDEST cooling Position
3.
Connect the power plug directly to wall socket.
If refrigerator works, call an electrician to fix the
stabilizer problem
Though the refrigerator will work in high/low voltage, it is recommended to use stabilizer.
NOTE
Maintain gap between stuff & air holes
220
ON
OFF

1616
6. Frost inside Door not closed properly Check the door to be closed fully, There should be
no gap
Leave food & liquid to cool before placing them in the
refrigerator
7. Slow ice
formation
Incorrect setting of Temperature
control knob
Rotate the freezer Temp control knob towards
COLDEST cooling position
ProblemProblem Probable causeProbable cause SolutionSolution
4. Noise Legs of Refrigerator not leveled
properly
Refrigerator installed too close
to wall
Objects behind or under the
refrigerator
Noise like water flowing
Install refrigerator in a flat/ stable surface & adjust the
front legs
Maintain proper gap from the walls
Remove the objects from behind or under the
refrigerator
This sound is generated by the flow of the
refrigerant & not a malfunction
5. Smell Food spoiled inside the
refrigerator
Improper covering of food
Clean the spoiled food & properly dry the
spoiled area
Store the food in sealed containers or wrap
properly
NOTE
2.
1.
All specifications in this manual are subject to change without prior notice.
Sides of a refrigerator may get hot. This is not a malfunction.
Pots/Bowl used for Ice making Use Ice tray for Ice making
Hot stuff kept inside

ELECTRONICS
