Samsung HW-H430 User manual

Wireless Audio - Soundbar
Imagine the possibilities
Thank you for purchasing this Samsung product.
To receive a more complete service, please register your product at
www.samsung.com/register
User manual
HW-H430

2
features
TV SoundConnect
TV SoundConnect lets you listen to audio from your TV on your Soundbar via a Bluetooth connection and lets you control the
sound.
3D SOUND
The 3D SOUND feature adds depth and spaciousness to your listening experience.
Wireless Subwoofer
Samsung’s wireless module does away with cables running between the main unit and the subwoofer.
Instead, the subwoofer connects to a compact wireless module that communicates with the main unit.
Special Sound mode
You can select from 5 different sound modes - MUSIC, VOICE, SPORTS, CINEMA, and STANDARD (Original Sound) - depending
on the type of content you want to enjoy.
Multi-function Remote Control
You can use the supplied remote control to control various operations with the simple press of a button.
Active Speaker System
This unit features an Active Speaker System that provides high sound quality in a single slim unit.
This unit does not require any satellite loudspeakers or speaker cabling, which are normally associated with conventional surround
sound systems.
USB Host support
You can connect and play music files from external USB storage devices such as MP3 players,
USB flash memory, etc. using the Soundbar's USB HOST function.
Bluetooth Function
You can connect a Bluetooth device to the Soundbar and enjoy music with high quality stereo sound, all without wires!
LICENSE
2.0 Channel
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
2.0 Channel
Manufactured under license under U.S. Patent No.s: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents
issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0 Channel is a
trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.
- To send inquiries and requests regarding open sources, contact Samsung via Email ([e-mail]).

3
ENG
safety information
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
•
This apparatus shall always be connected to a AC outlet with a protective grounding connection.
•
To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains
plug shall be readily operable.
CAUTION
• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the
apparatus.
• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power
plug must be easily and readily accessible at all times.
●Figures and illustrations in this User Manual are provided for reference only and may differ from actual
product appearance.
●An administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect with the product (i.e. where the user
manual has not been read).
(b) you bring the unit to a repair centre and there is no defect with the product (i.e. where the user manual
has not been read).
●You will be informed of the administration fee amount before a technician visits.

4
precautions
Ensure that the AC power supply in your house complies with the power requirements listed on the identification
sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with
enough space around it for ventilation 7~10 cm. Make sure the ventilation slots are not covered. Do not place the
unit on amplifiers or other equipment which may become hot. This unit is designed for continuous use. To fully
turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend to leave it unused for a
long period of time.
99.1mm 99.1mm
68.6
mm
99.1mm
During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
Protect the product from moisture (i.e. vases), and
excess heat (e.g. a fireplace) or equipment creating
strong magnetic or electric fields. Disconnect
the power cable from the AC supply if the unit
malfunctions. Your product is not intended for
industrial use. It is for personal use only.
CondenSoundbarion may occur if your product has
been stored in cold temperatures. If transporting the
unit during the winter, wait approximately 2 hours until
the unit has reached room temperature before using.
Do not expose the unit to direct sunlight or other heat
sources.
This could lead to overheating and cause the unit to
malfunction.
The batteries used with this product contain chemicals
that are harmful to the environment.
Do not dispose of batteries in the general household
trash.
Do not dispose of batteries in a fire.
Do not short circuit, disassemble, or overheat the
batteries.
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.

5
ENG
contents
FEATURES
2
2 Features
2 License
SAFETY INFORMATION
3
3 Safety warnings
4 Precautions
GETTING STARTED
6
6 Before reading the user’s manual
6 What’s included
DESCRIPTIONS
7
7 Front/Rear panel
REMOTE CONTROL
8
8 Remote control buttons and functions
CONNECTIONS
10
10 Installing the wall mount
11 Connecting the wireless subwoofer
12 Attaching the toroidal ferrite core to the
power cord of the subwoofer
12 Looping the power cable around the toroidal
core
13 Connecting an external device using audio
(analog) cable or optical (digital) cable
TROUBLESHOOTING
19
19 Troubleshooting
APPENDIX
20
20 Specifications
FUNCTIONS
14
14 Input mode
14 Bluetooth
16 Soundconnect
17 USB
18 Software upgrade

6
BEFORE READING THE USER’S MANUAL
Note the following terms before reading the user manual.
Icons used in this manual
Icon Term Definition
Caution
Indicates a situation where a function does not operate or settings may be
canceled.
Note
Indicates tips or instructions on the page that help you operate a function.
Safety Instructions and Troubleshooting
1) Be sure to familiarize yourself with the Safety Instructions before using this product. (See page 3)
2) If a problem occurs, check Troubleshooting. (See page 19)
Copyright
©2014 Samsung Electronics Co.,Ltd.
All rights reserved; no part or whole of this user’s manual may be reproduced or copied without the prior
written permission of Samsung Electronics Co.,Ltd.
getting started
WHAT’S INCLUDED
Check for the supplied accessories shown below.
Remote Control / Lithium Battery (3V
: CR2032)
Bracket-Wall Mount User Manual
(For Subwoofer power cable 1EA)
AUX Cable USB Cable Toroidal ferrite core
▪The appearance of the accessories may differ slightly from the illustrations above.
▪Use the dedicated USB cable to connect external USB devices to the unit.

7
ENG ●DESCRIPTIONS
descriptions
FRONT/REAR PANEL
▪When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.
▪When disconnecting the power cable from the wall outlet, pull the plug. Do not pull the cable.
▪Do not connect this unit or other components to an AC outlet until all connections between components are
complete.
REMOTE
CONTROL
SENSOR
The remote control can operate
Soundbars made by
SAMSUNG only.
DISPLAY Displays the current mode.
POWER
BUTTON Turns the Soundbar on and off.
FUNCTION
BUTTON
Selects the D.IN, AUX, BT, TV,
USB input.
- While the unit is powered,
pressing the button for more
than 3 seconds sets the button
to act as MUTE button. To
cancel MUTE button setup,
press button for more than 3
seconds again.
5VOLUME
( +/- )Controls the volume level.
6USB PORT Connect USB devices such as
MP3 players.
7OPTICAL IN Connect to the digital (optical)
output of an external device.
8AUX IN Connect to the Analog output
of an external device.
9
POWER
SUPPLY
CABLE
Plug the power supply cable
into the AC wall outlet.
9
1 2
5v 500mA
3
4
5
OPTICAL IN AUX IN
8
7
6

8
REMOTE CONTROL
REMOTE CONTROL BUTTONS AND FUNCTIONS
EQUALIZER WOOFER
Press to select Treble or Bass. Then, use the [,]button to adjust the
Treble or Bass volume from -3 to +3.
You can control the subwoofer volume. Press the [,]button to
increase or decrease the subwoofer volume. You can set it from SW -6 to
SW +6.
DIMMER
DIMMER : Press the DIMMER button to control the brightness of the
display.
Auto Power Link : Press and hold the DIMMER button for more than
3 seconds to turn the Auto Power Link function on or off.
(Auto Power Link : Default OFF)
* Auto Power Link
Synchronizes the Soundbar to a connected Optical source via the
Optical jack so it turns on automatically when you turn on your TV.
REPEAT
Press to set the REPEAT function during music playing from a USB
device.
REPEAT OFF : Cancels Repeat Playback.
REPEAT FILE : Repeatedly play a track.
REPEAT ALL : Repeatedly play all tracks.
REPEAT RANDOM : Plays tracks in random order. (A track that has
already been played may be played again.)
MUTE
You can turn the volume down to 0 with the push of a button.
Press again to restore the sound to the previous volume level.
SOURCE
Press to select a source connected to the Soundbar.
Skip Forward
If there is more than one file on the device you are playing, and you press
the ]button, the next file is selected.
AUDIO SYNC
If the Soundbar is connected to a digital TV and the video appears out of
sync with the audio, press the AUDIO SYNC buttons to sync the audio
with the video. Use the [,]buttons to set the audio delay between 0
ms and 300 ms. In USB mode, TV mode, and BT mode, the Audio Sync
function may not work.
▪Soundbar is a Samsung proprietary name.
▪Operate the TV using the TV's remote control.

9
ENG ●CONNECTIONS
Bluetooth POWER
Press the Bluetooth POWER button on the remote control to turn the
Bluetooth POWER on function on and off.
See pages 16 and 17 for details.
3D SOUND (3D Sound Plus)
Press the 3D SOUND button on the remote control to add depth and
spaciousness to the sound.
Press the 3D SOUND button on the remote control.
Each time the button is pressed, the selection changes as follows :
3D SOUND PLUS OFF
 3D SOUND PLUS MUSIC 
3D SOUND PLUS MOVIE
VOLUME
Adjusts the volume level of the unit.
POWER
Turns the Soundbar on and off.
SOUND EFFECT
You can select from 5 different sound modes - MUSIC, VOICE,
SPORTS, CINEMA, and STANDARD - depending on the type of
sources you want to enjoy.
Press the SOUND EFFECT button on the remote control.
Select the STANDARD mode if you want to enjoy the original sound.
Press the SOUND EFFECT button for more than 5 seconds to turn on or
off Smart Volume.
* Smart Volume
This will regulate and stabilize the volume level against a drastic
volume change caused by a channel change or scene transition.
Play/Pause
Press the +# button to pause playing the file temporarily.
Press the +# button again to play the selected file.
Skip Back
If there is more than one file on the device you are playing, and you press
the [button, the previous file is selected.
+Installing the Batteries in the Remote Control
1. Use a suitable coin to turn
the remote control's battery
cover counterclockwise to
remove it as shown in the
figure above.
2. Insert a 3V lithium battery. Keep the
positive (+) pole facing up when
inserting the battery. Put the battery
cover on and align the '' marks
side by side as shown in the figure
above.
3. Use a suitable coin to turn the
remote control battery cover
clockwise as far as it will go to
fix it in place.

10
connections
INSTALLING THE WALL MOUNT
You can use the wall mount bracket to mount this unit on a wall.
connections
Installation Precautions
• Install on a vertical wall only.
• For the installation, avoid a location with high temperature or humidity, or a wall that cannot sustain the
weight of the set.
• Check the strength of the wall. If the wall is not strong enough to support the unit, reinforce the wall or
install the unit on different wall that can support the unit's weight.
• Purchase and use the fixing screws or mollys appropriate for the kind of wall you have (plaster board, iron
board, wood, etc.). If possible, fix the support screws into wall studs.
• Connect cables from the unit to external devices before you install it on the wall.
• Make sure the unit is turned off and unplugged before you install it. Otherwise, it may cause an electric shock.
▪Do not hang onto the installed unit and avoid any impact to the unit.
▪Secure the unit firmly to the wall so that it does not fall off. If the unit falls off, it may cause an
injury or damage the product.
▪When the unit is installed on a wall, please make sure that children do not pull any of the
connecting cables, as it may cause it to fall.
▪For the optimal performance of a wall mount installation, install the speaker system at least 5 cm
below the TV.
1
21
5 cm or more
1. Place the wall mount bracket on a wall surface and then
secure it with two screws (not supplied).
If you are hanging the unit below a TV, be sure to install the
wall mount bracket so that the arrow ( ) is placed in the
center of the TV.
Also make sure the unit is at least 5 cm below the TV.
2. Fit the unit into the corresponding slots of the wall mount
bracket. For secure installation, make sure the mounting
studs slide firmly down into the bottom of the slots.
3. The installation is complete.
