User Manual
05/2017. Rev.1.2
EO-SG930

Table of Contents
English (UK)
Français
Deutsch
Italiano
Español
Magyar
Polski
Română
Български
Hrvatski
Srpski
Português
Latviešu
Lietuvių kalba
Eesti
Nederlands
Svenska
Norsk
Suomi
Dansk
Ελληνικά
Slovenščina
Slovenčina
Čeština
Türkçe


Русский
Українська
Қазақ тілі
English (USA)
Español (Castellano)
简体中文
繁體中文(台灣)
Français (Canada)
Português (Brasil)
한국어

3
Getting started
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Images may differ in appearance from the actual product. Content is subject to change
without prior notice.
•
Before using the Bluetooth speaker, make sure it is compatible with your device.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
English (UK)
1

Getting started
4
Maintaining water resistance
Your device supports water-resistance. Follow these tips carefully to maintain the water-
resistance of your device. Failure to do so may result in damage to your device.
•
Do not immerse the device in water deeper than 1 m or keep it submerged for more than
30 minutes.
•
Do not expose the device to water moving with force.
•
If the device is exposed to clean water, dry it thoroughly with a clean, soft cloth. If the
device is exposed to other liquids, such as salt water, ionised water, or alcoholic beverage,
rinse it with clean water and dry it thoroughly with a clean, soft cloth. If you do not follow
these instructions, the device’s performance and appearance may be affected.
•
If the device has been immersed in water or the microphone or speaker is wet,
sound may not be heard clearly during a call. Wipe the device with a dry cloth or dry it
thoroughly before using it.
•
Your device has been tested in a controlled environment and certified to be water-
resistant in specific situations (meets requirements of classification IPX7 as described
by the international standard IEC 60529-Degrees of Protection provided by Enclosures
[IP Code]; test conditions: 15-35 °C, 86-106 kPa, 1 metre, 30 minutes). Despite this
classification, it is still possible for your device to be damaged in certain situations.
English (UK)
2

Getting started
5
About the Level Box Slim
You can use this product as a Bluetooth speaker or as a battery pack for other devices.
Package contents
Check the product box for the following items:
•
Bluetooth Speaker
•
Quick start guide
•
Power sharing cable
•
USB cable
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
English (UK)
3

Getting started
6
Device layout
Speaker
Charger port
Microphone
Power button
Volume (-) button
Play/Bluetooth
pairing button
Indicator light
Volume (+) button
Stand
Battery indicator
light
Power sharing cable
(when charging the
other device)
USB cable (when
charging the
Bluetooth speaker)
Use the stand to support the device.
English (UK)
4

Getting started
7
Buttons
Button Function
Power button
•
Press and hold to turn the Bluetooth speaker on or off.
•
Press to check the remaining battery power.
•
Press to begin charging an external device when using the
Bluetooth speaker as a battery pack.
Volume (+) button
•
Press to increase the volume.
•
Press and hold to skip to the next song during music
playback.
Volume (-) button
•
Press to decrease the volume.
•
Press and hold to skip to the previous song during music
playback.
Play/Bluetooth pairing
button
•
Press and hold to enter Bluetooth pairing mode.
•
Press for approximately one second to launch S Voice when
the Bluetooth speaker is connected to another device via
Bluetooth.
•
Press to reconnect devices when the Bluetooth connection is
lost.
•
Press to pause or resume music during music playback.
•
Press to answer an incoming call.
•
Press and hold to reject an incoming call.
•
Press to end the current call.
English (UK)
5

Getting started
8
Indicator light
The indicator light alerts you to the Bluetooth speaker status.
Colour Status
Flashes blue three
times The Bluetooth speaker is powering on
Flashes red three times The Bluetooth speaker is powering off
Flashes red and blue The Bluetooth speaker is in Bluetooth pairing mode
Blue Bluetooth is connected
Red Bluetooth is not connected
Battery
Battery charging tips and precautions
•
You can charge the Bluetooth speaker using the charger (sold separately).
•
If the battery is completely discharged, the Bluetooth speaker cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for a few
minutes before turning on the Bluetooth speaker.
•
Using a power source other than the charger, such as a computer, may result in a slower
charging speed due to a lower electric current.
•
The Bluetooth speaker can be used while it is charging, but it may take longer to fully
charge the battery.
•
If the Bluetooth speaker receives an unstable power supply while charging, it may not
function. If this happens, unplug the charger from the Bluetooth speaker.
•
While charging, the Bluetooth speaker and the charger may heat up. This is normal and
should not affect the Bluetooth speaker lifespan or performance. If the battery gets
hotter than usual, the charger may stop charging.
English (UK)
6

Getting started
9
•
Charging the Bluetooth speaker while the charger port is wet may damage the speaker.
Dry the speaker thoroughly if it becomes wet.
•
If the Bluetooth speaker is not charging properly, take the Bluetooth speaker and the
charger to a Samsung Service Centre.
•
The charging time may vary depending on the charger specification.
Charging the battery
Charge the Bluetooth speaker before using it for the first time or when it has been unused for
extended periods.
Use only Samsung-approved chargers (5 V/2 A or higher). Unapproved chargers can
cause the battery to explode or damage the Bluetooth speaker.
1 Connect the Bluetooth speaker to a charger.
Connecting the charger improperly may cause serious damage to the Bluetooth
speaker. Any damage caused by misuse is not covered by the warranty.
If the charger port is wet, the four battery indicator lights will blink when you connect
the Bluetooth speaker to a charger.
2 After fully charging, disconnect the Bluetooth speaker from the charger.
•
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and be easily accessible while charging.
•
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
English (UK)
7

Getting started
10
Checking the remaining battery power
Press the Power button to check the remaining battery power.
Remaining battery power Battery indicator light status
70-100 % Four indicator lights on
40-70 % Three indicator lights on
20-40 % Two indicator lights on
10-20 % One indicator light on
0-10 % One indicator light blinking
Auto power saving mode
Save battery power by activating auto power saving mode.
Press and hold the Power button and the Volume (+) button simultaneously to activate auto
power saving mode. The Bluetooth speaker is automatically turned off when one hour has
passed since the media file playback paused.
To deactivate auto power saving mode, press and hold the Power button and the Volume (-)
button simultaneously.
When you turn on the Bluetooth speaker for the first time, it automatically enters auto
power saving mode.
English (UK)
8

11
Using the Bluetooth speaker
Turning the Bluetooth speaker on and off
Press and hold the Power button to turn the Bluetooth speaker on or off.
When you turn on the Bluetooth speaker for the first time, it enters Bluetooth pairing mode.
•
If your Bluetooth speaker is frozen and unresponsive, press and hold the Power
button more than eight seconds.
•
Follow all posted warnings and directions from authorised personnel in areas
where the use of wireless devices is restricted, such as aeroplanes and hospitals.
Connecting to another device
Notices for using Bluetooth
Bluetooth is a wireless technology standard that uses a 2.4 GHz frequency to connect to
various devices over short distances. It can connect and exchange data with other Bluetooth
enabled devices, such as mobile devices, computers, printers, and other digital home
appliances, without connecting via cables.
•
To avoid problems when connecting your Bluetooth speaker to another device, place the
devices close to each other.
•
Ensure that your Bluetooth speaker and the other Bluetooth device are within the
maximum Bluetooth range (10 m). The distance may vary depending on the environment
the devices are used in.
•
Ensure that there are no obstacles between the Bluetooth speaker and a connected
device, including human bodies, walls, corners, or fences.
•
Do not touch the Bluetooth antenna of a connected device.
English (UK)
9

Using the Bluetooth speaker
12
•
Bluetooth uses the same frequency as some industrial, scientific, medical, and low power
products and interference may occur when making connections near these types of
products.
•
Some devices, especially those that are not tested or approved by the Bluetooth SIG, may
be incompatible with your Bluetooth speaker.
•
Do not use the Bluetooth feature for illegal purposes (for example, pirating copies of files
or illegally tapping communications for commercial purposes).
Connecting device via Bluetooth
Pair the Bluetooth speaker with an available Bluetooth device. Once the devices are paired,
the Bluetooth speaker will automatically connect to the mobile device whenever you turn on
the Bluetooth speaker.
1 Bluetooth speaker Press and hold the Play/Bluetooth pairing button for more than
three seconds to enter Bluetooth pairing mode.
The indicator light will flash red and blue.
When you turn on the Bluetooth speaker for the first time, it enters Bluetooth pairing
mode.
2 Other device Activate the Bluetooth feature and search for Bluetooth devices.
For more information, refer to the other device’s user manual.
3 Other device Tap
[Speaker] Level Box Slim (0000) from the list of available devices.
The indicator light will flash blue.
•
The PIN for the Bluetooth speaker is the four-digit number in parenthesis displayed
on the other device’s Bluetooth settings screen. The number differs depending on
the Bluetooth speaker.
•
If the Bluetooth connection fails or the other device cannot locate the Bluetooth
speaker, remove the device’s information from the other device’s list. Then, try to
connect again.
•
The Bluetooth connection range and sound quality may vary depending on the
connected devices.
English (UK)
10

Using the Bluetooth speaker
13
Disconnecting or reconnecting devices
Press and hold the Play/Bluetooth pairing button for more than three seconds. The current
connection will end.
You can also end the connection by deactivating the Bluetooth feature on the connected
device.
If the Bluetooth connection ends due to the distance between the devices, bring the devices
closer together within a certain period of time. The devices will automatically reconnect.
•
You can also end the connection by turning off the Bluetooth speaker or
deactivating the Bluetooth feature on the connected device. When you turn on
the Bluetooth speaker again and the devices are in range, or activate the Bluetooth
feature on the connected device, the devices will automatically reconnect.
•
If the Bluetooth connection ends because of a device malfunction, use the
Bluetooth menu on the disconnected device to reconnect the devices.
•
Noise may occur if the Bluetooth connection is disconnected improperly.
Connecting to other devices
After ending the connection between the Bluetooth speaker and the currently connected
device, you can connect the Bluetooth speaker to another device.
1 Press and hold the Play/Bluetooth pairing button for more than three seconds.
The Bluetooth speaker will end the current Bluetooth connection and enter Bluetooth
pairing mode.
2 Connect the Bluetooth speaker to another device.
English (UK)
11

Using the Bluetooth speaker
14
Connecting additional devices
The Bluetooth speaker can connect to a maximum of two Bluetooth-enabled devices at the
same time. When you connect the Bluetooth speaker to two devices, the last device you
connect is recognised as the primary device. The other device is recognised as the secondary
device.
1 Connect the Bluetooth speaker and a device via Bluetooth. Refer to Connecting device
via Bluetooth for more information.
2 Press and hold the Play/Bluetooth pairing button for approximately three seconds to
enter Bluetooth pairing mode.
The indicator light will flash red and blue and the first device will be disconnected.
3 Follow the same connection procedure used for connecting the first device to connect
the Bluetooth speaker to second device.
4 Tap
[Speaker] Level Box Slim (0000) from the first device’s list to reconnect the
Bluetooth speaker to the first device.
This feature may not be supported on some devices.
Listening to music
Listen to music played on the connected device.
Press the Play/Bluetooth pairing button to play music.
Pausing or resuming playback
Press the Play/Bluetooth pairing button to pause or resume music playback.
Adjusting the volume
Press the Volume (+) button or Volume (-) button to adjust the volume.
English (UK)
12

Using the Bluetooth speaker
15
Skipping to other songs
Press and hold the Volume (+) button to skip to the next song during music playback.
Press and hold the Volume (-) button to skip to the previous song during music playback.
Using call features
When the Bluetooth speaker is connected to a mobile device, you can answer and control
calls from the connected mobile device.
Answering or rejecting a call
Press the Play/Bluetooth pairing button to answer a call.
Press and hold the Play/Bluetooth pairing button to reject an incoming call.
Adjusting the volume
Press the Volume (+) button or Volume (-) button to adjust the volume during a call.
Answering a second call
When a second call comes in during a call, the Bluetooth speaker will emit a beep.
Press and hold the Play/Bluetooth pairing button to reject an incoming second call during a
call.
Press the Play/Bluetooth pairing button to place a call on hold and answer a second call.
Press the Play/Bluetooth pairing button to switch between two calls.
Ending a call
Press the Play/Bluetooth pairing button to end a call.
Press and hold the Play/Bluetooth pairing button to end a current call and answer the held
call.
English (UK)
13

Using the Bluetooth speaker
16
Using the Samsung Level
On the connected device, download the Samsung Level app from Play Store or Galaxy Apps.
With the
Samsung Level app, you can check the remaining battery power and adjust the
volume. You can also set the Bluetooth speaker to notify you via voice notification when you
have notifications on the connected device.
Also, on the connected mobile device, launch the
Samsung Level app to share audio with
another Bluetooth speaker. If you activate the sound separation feature with the
Samsung
Level
app, you can also use two speakers to separate the left and right speaker into different
channels. Refer to Using the dual sound feature for more information.
For more information, refer to the help menu of the
Samsung Level .
The Samsung Level app is compatible with Samsung mobile devices running
Android 4.2.2 or higher. Some features may differ or may not work on your Bluetooth
speaker depending on the connected device or the operating system.
English (UK)
14

Using the Bluetooth speaker
17
Using the dual sound feature
This Bluetooth speaker supports the Dual Sound feature. You can connect two Bluetooth
speakers to share the same audio. You can also use two speakers to separate the left and right
speaker into different channels.
Ensure that the Bluetooth speaker that you want to share audio with is turned on.
•
Your Bluetooth speaker must be connected to a mobile device. If your Bluetooth
speaker is not connected to a mobile device, or is connected to more than two
mobile devices, you cannot activate the Dual Sound feature.
•
If the distance between your Bluetooth speaker and the connected devices is too
great, there is an obstacle obstructs the signal, or the Wi-Fi signal is strong, the
audio quality may be poor.
•
If you restart your Bluetooth speaker while using the Dual Sound feature, it will
try to reactivate the Dual Sound feature automatically. However, if your other
Bluetooth speaker is connected to another mobile device, the Dual Sound feature
will not reactivate automatically.
•
If your other Bluetooth speaker is turned off while using the Dual Sound feature,
the connection between the two Bluetooth speakers will end. When you turn it on
again, it will automatically reconnect to the mobile device that it was connected to
before activating the Dual Sound feature.
•
While sharing audio, the voice notification feature will be disabled.
•
Visit www.samsung.com to view the product specifications for the other Bluetooth
speaker to confirm that it supports the Dual Sound feature.
1 Other Bluetooth speaker Press and hold the Play/Bluetooth pairing button and
Volume (-) button simultaneously for approximately one second.
2 Bluetooth speaker Press and hold the Play/Bluetooth pairing button and Volume (+)
button simultaneously for approximately one second.
The audio will be shared.
Press and hold the Volume (+) and Volume (-) button on Bluetooth speaker simultaneously for
approximately one second to stop sharing audio.
English (UK)
15

Using the Bluetooth speaker
18
Using as a battery pack
Use the Bluetooth speaker as a battery pack while connecting to another device via the
power sharing cable.
1 Bluetooth speaker Insert the power sharing cable into the charger port.
2 Charged device Insert the other end of the power sharing cable into the multipurpose
jack.
3 Bluetooth speaker Press the Power button to start charging the battery.
4 After fully charging, disconnect the power sharing cable from the Bluetooth speaker and
other device for charging.
•
You can use the Bluetooth speaker while charging the other device. However, if the
battery power is low, some features may be limited.
•
The actual capacity (Wh) is measured based on the battery’s output current and
voltage. It may differ from the capacity (Wh) indicated on the device, depending
on the output power condition, the connected device’s circuit configuration, and
the operation environment.
English (UK)
16

19
Appendix
Troubleshooting
Before contacting a Samsung Service Centre, please attempt the following solutions.
Your Bluetooth speaker does not turn on
When the battery is completely discharged, your Bluetooth speaker will not turn on. Charge
the battery completely before turning on the Bluetooth speaker.
Your Bluetooth speaker freezes
If the Bluetooth speaker freezes or hangs, try to resolve it by turning off the Bluetooth speaker
and then turning it on again.
If the Bluetooth speaker is still unresponsive, end the Bluetooth connection and reconnect
it. To do this, press the Play/Bluetooth pairing button for approximately three seconds. When
the Bluetooth speaker enters Bluetooth pairing mode, connect the devices again, and then
check the operation of the Bluetooth speaker.
If the problem is still not resolved, contact a Samsung Service Centre.
The battery does not charge properly (For Samsung-approved USB
cables and chargers)
•
Ensure that the USB cable or the charger is connected properly.
•
Check whether your speaker has enough battery power before using it as a battery pack.
If the tips above do not solve the problem, contact a Samsung Service Centre.
English (UK)
17

Appendix
20
Another Bluetooth device cannot locate your Bluetooth speaker
•
Ensure that your Bluetooth speaker is in Bluetooth pairing mode.
•
Restart your Bluetooth speaker and search for the Bluetooth speaker again.
•
Ensure that your Bluetooth speaker and the other Bluetooth device are within the
maximum Bluetooth range (10 m).
If the tips above do not solve the problem, contact a Samsung Service Centre.
Your Bluetooth speaker cannot connect to another Bluetooth device
•
Ensure that your Bluetooth speaker and the other Bluetooth device are within the
maximum Bluetooth range (10 m).
•
On the device you want to connect with, disconnect all paired devices and try to connect
again.
Bluetooth connection is often disconnected
•
If there are obstacles between the devices, the operating distance may be reduced.
•
Ensure that your Bluetooth speaker and the other Bluetooth device are within the
maximum Bluetooth range (10 m).
•
When using the Bluetooth speaker with other Bluetooth devices, the connection may
be affected by electromagnetic waves. Use the Bluetooth speaker in environments with
fewer wireless devices present.
The Bluetooth speaker works differently as described in the manual
Available functions may differ depending on the connected device.
The battery depletes faster than when first purchased
•
When you expose the Bluetooth speaker or the battery to very cold or very hot
temperatures, the useful charge may be reduced.
•
The battery is consumable and the useful charge will get shorter over time.
English (UK)
18
