Samsung UN TU7000F Series User manual

UHD TV
SERVICEManual
UHD TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
Project : UTU7000K
Chassis : UWL00
Model : UN58TU7000F
UN65TU7000F
UN70TU7000F
UN75TU7000F
UN**TU7000F

Contents
1. Precautions ............................................................................................................................1-1
1-1. Safety Precautions ............................................................................................................................ 1-1
1-1-1. Warnings .................................................................................................................................. 1-1
1-1-2. Servicing the LED TV............................................................................................................. 1-1
1-1-3. Fire and Shock Hazard .......................................................................................................... 1-1
1-1-4. Product Safety Notices.........................................................................................................1-2
1-2. Servicing Precautions.......................................................................................................................1-3
1-2-1. General Servicing Precautions............................................................................................1-3
1-3. Static Electricity Precautions ..........................................................................................................1-4
1-4. Installation Precautions...................................................................................................................1-5
2. Product Specications .........................................................................................................2-1
2-1. Product Information..........................................................................................................................2-1
2-2. Specications.................................................................................................................................... 2-2
2-3. Other Information ............................................................................................................................ 2-3
2-4. Accessories.........................................................................................................................................2-7
2-5. Key Features & Operation .............................................................................................................. 2-8
2-5-1. 2020’ About This TV ............................................................................................................. 2-8
2-5-2. New 2020’ Device Care ....................................................................................................... 2-9
2-6. Viewing the Functions................................................................................................................... 2-10
2-6-1. Find a variety of content with one remote (US)............................................................ 2-10
2-6-2. Spend time watching, not searching (US)..................................................................... 2-10
2-6-3. Fits with your home ecosystem........................................................................................ 2-11
2-6-4. Works wth Amazon Alexa.................................................................................................. 2-11
2-6-5. Control your TV with the Google Assistant ....................................................................2-12
2-6-6. Works with AirPlay 2 ..........................................................................................................2-12
2-7. The Remote Control.........................................................................................................................2-13
2-7-1. About the Buttons on the Remote Control .....................................................................2-13
2-7-2. Installing batteries into the remote control ..................................................................2-14
2-8. Using the TV Controller..................................................................................................................2-14
2-9. Rear Connect ....................................................................................................................................2-15
3. Disassembly and Reassemble ............................................................................................ 3-1
3-1. TV Disassembly ..................................................................................................................................3-1
4. Troubleshooting................................................................................................................... 4-1
4-1. Function Control Operation Test ....................................................................................................4-1
4-1-1. FUNCTION/IR Control Test...................................................................................................4-1
4-1-2. FUNCTION/IR Control Test of Function/Wi-Fi /BT Module .......................................... 4-2
4-2. Power.................................................................................................................................................. 4-3
4-2-1. SMPS Standby....................................................................................................................... 4-5

4-3. Video Troubleshooting.................................................................................................................... 4-9
4-3-1. Customer Picture Test ......................................................................................................... 4-9
4-3-2. Video Circuit Layout.......................................................................................................... 4-10
4-3-3. Combined MAIN/T-CON Models .....................................................................................4-11
4-4. AUDIO Troubleshooting................................................................................................................ 4-14
4-5. Network Troubleshooting ............................................................................................................ 4-15
4-5-1. Checking the Internet connection status...................................................................... 4-15
4-5-2. Using the Wi Analyzer App .............................................................................................4-17
4-5-3. Wired LAN Operation Test (TV to Router) ..................................................................... 4-18
4-5-4. Know Before Wireless Internet Connection ................................................................. 4-19
4-6. Smart Hub .......................................................................................................................................4-20
4-6-1. Smart Hub Connection Test .............................................................................................4-20
4-7. BlueTooth/WiFi Module................................................................................................................. 4-22
4-8. Factory Mode .................................................................................................................................. 4-24
4-9. Replacing Main Board ...................................................................................................................4-30
4-10. Detail Factory Option .................................................................................................................. 4-35
4-11. Factory Data................................................................................................................................... 4-39
4-12. AV Control Tabe............................................................................................................................. 4-52
4-13. Updating the TV’s Software........................................................................................................4-59
4-13-1. Updating to the latest TV software...............................................................................4-60
5. Wiring Diagram .................................................................................................................... 5-1
5-1. Wiring Diagram ..................................................................................................................................5-1
5-2. Connector........................................................................................................................................... 5-3
5-2-1. Main Board............................................................................................................................. 5-3
5-2-2. SMPS Board ...........................................................................................................................5-7
5-3. Cables ............................................................................................................................................... 5-10

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
GSPN (GLOBAL SERVICE PARTNER NETWORK)
© 2020 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea
Area Web Site
Europe, MENA, CIS, Africa https://gspn1.samsungcsportal.com
E.Asia, W.Asia, China, Japan https://gspn2.samsungcsportal.com
N.America, S.America https://gspn3.samsungcsportal.com

1. Precautions
1-1. Safety Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
Forcontinued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
1. When servicing the LED TV, Disconnect the AC line cord from the AC outlet.
2. It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of
this meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitorto the user, perform the following safety checks:
1. Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the
chassis and other metal parts in the monitor.
2. Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and
compartment covers orshields, isolation resistorcapacitornetworks, mechanical insulators, etc.
3. Leakage Current Hot Check:
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL EXPOSED
METAL SURFACES
2-WIRE CORD
ALSO TESTWITH PLUG
REVERSED (USING AC
ADAPTER PLUG AS
REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current testeror a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current forAppliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
4. With the unit completely reassembled, plug the AC line cord directly into a120VAC outlet. With the unit’s AC switch
rst in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit,
etc.) and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from
visual inspection. The protection they give may not be obtained by replacing them with components rated for higher
voltage, wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists.
A substitute replacement that does not have the same safety characteristics as the recommended replacement part
might create shock, re and/or other hazards. Product safety is under review continuously and new instructions are
issued whenever appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
1. Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before attempting
to: (a) remove orreinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect a test
component in parallel with an electrolytic capacitor.
2. Some components are raised above the printed circuit board forsafety. An insulation tube ortape is sometimes used.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such
elements to theiroriginal position.
3. Afterservicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that
the area around the serviced part has not been damaged.
4. Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input
terminals and earphone jacks).
5. Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greaterthan 1 megohm.
6. Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductorcomponents orassemblies, drain the electrostatic charge from your
body by touching a known earth ground. Alternatively, weara discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
2. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent
accumulation of an electrostatic charge.
3. Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.
4. Use only a grounded-tip soldering iron to solder or desolderESDs.
5. Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate
electrical charges sufcient to damage ESDs.
6. Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs
are packaged with leads that are electrically shorted togetherby conductive foam, aluminum foil or other conductive
materials.
7. Immediately before removing the protective material from the leads of a replacement ESD, touch the protective
material to the chassis orcircuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
8. Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

1. Forsafety reasons, more than a people are required forcarrying the product.
2. Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.
3. Do not place the product in areas with poor ventilation such as a bookshelf orcloset. The increased internal
temperature may cause re.
4. Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed
to moisture. Otherwise, it may cause a re or electric shock.
5. Make sure to turn the poweroff and unplug the power cord from the outlet before repositioning the product. Also check
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
6. Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the
antenna falling over may cause re or electric shock.
7. When installing the product, leave enough space (0.4m) between the product and the wall forventilation purposes.
A rise in temperature within the product may cause re.
8. If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an
explosion (for example, with some lithium batteries), the following applies:
CAUTION
• Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according
to the instructions.
• Do not dispose of batteries in a re.
• Do not short circuit, disassemble or overheat the batteries.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type.
• Do not be exposed to excessive heat such as sunshine, re or the like.
1-5
1. Precautions
1-4. Installation Precautions

2-1
2. Product specications
2. Product Specications
2-1. Product Information
Model UN**TU7000F
Front View
W
* W : Width H : High D : Depth
H
D
Detail View
Color Front : TITAN GRAY / Stand : TITAN GRAY / Deco : CARBON SILVER

2-2
2. Product specications
2-2. Specications
Model Name UN58TU7000 UN65TU7000
Display Resolution 3840 x 2160 3840 x 2160
Screen Size
Diagonal
Measured Diagonally
58˝ Class
57.5 inches
65˝ Class
64.5 inches
Sound (Output) 20 W 20 W
Dimensions (W x H x D)
Body
With Stand
50.8 x 29.5 x 2.4 inches
(1291.0 x 748.6 x 59.9 mm)
50.8 x 32.3 x 9.8 inches
(1291.0 x 819.4 x 249.7 mm)
57.1 x 32.7 x 2.4 inches
(1449.4 x 830.3 x 59.9 mm)
57.1 x 35.6 x 11.2 inches
(1449.4 x 905.2 x 283.5 mm)
Weight
Without Stand
With Stand
33.5 lbs (15.2 kg)
34.0 lbs (15.4 kg)
45.4 lbs (20.6 kg)
46.1 lbs (20.9 kg)
Model Name UN70TU7000 UN75TU7000
Display Resolution 3840 x 2160 3840 x 2160
Screen Size
Diagonal
Measured Diagonally
70˝ Class
69.5 inches
75˝ Class
74.5 inches
Sound (Output) 20 W 20 W
Dimensions (W x H x D)
Body
With Stand
61.9 x 34.4 x 2.4 inches
(1572.4 x 874.5 x 59.9 mm)
61.9 x 37.8 x 13.4 inches
(1572.4 x 959.0 x 339.9 mm)
65.9 x 37.7 x 2.4 inches
(1673.2 x 958.2 x 59.9 mm)
65.9 x 41.1 x 13.4 inches
(1673.2 x 1043.0 x 339.9 mm)
Weight
Without Stand
With Stand
53.4 lbs (24.2 kg)
54.5 lbs (24.7 kg)
67.0 lbs (30.4 kg)
67.9 lbs (30.8 kg)

2-3
2. Product specications
2-3. Other Information
NOTE
Design and specications are subject to change without prior notice.
Item UN**TU7000FXZA
General
Information
Product LED
Series 7
Country UNITED STATES
Display Screen Size 58" 65" 70" 75"
Diagonal Screen Size 5 7. 5 " 64.5" 69.5" 74.5"
Resolution 3,840 x 2,160
Ultra Black N/A
Screen Curvature N/A
Video Picture Engine Crystal Processor 4K
Motion Rate MR120 MR120 MR120 MR120
HDR (High Dynamic Range) HDR
Compatible with HDR 10+ Yes
HLG (Hybrid Log Gamma) Yes
Contrast Mega Contrast
Viewing Angle N/A
Color PurColor
Dual LED N/A
Micro Dimming N/A
Local Dimming N/A
Auto Depth Enhancer N/A
Contrast Enhancer Yes
Auto Motion Plus Yes
Film Mode Yes
Natural Mode Support Yes
Audio Dolby Digital Plus Yes
Dolby 5.1 Decoder N/A
Object Tracking Sound N/A
Q-Symphony N/A
Dialog Enhancement Yes
Audio Pre-selection Descriptor N/A
Hole Array Speaker N/A
Sound Output (RMS) 20W
Speaker Type 2CH
Woofer N/A

2-4
2. Product specications
Item UN**TU7000FXZA
Audio Multiroom Link Yes
Blutooth Audio Yes
Smart Service Samsung SMART TV Smart
Operating System Tizen™
Bixby N/A
Far-Field Voice Interaction N/A
Multi Voice Assistant N/A
Works with Google Assistant Yes
Works With Alexa Yes
TV Plus Yes
Web Browser Yes
SmartThings App Support Yes
SmartThings N/A
Samsung Health N/A
Universal Guide Yes (US Only)
Gallery Yes
Convergence TV to Mobile - Mirroring N/A
Mobile to TV - Mirroring, DLNA Yes
NFC on TV N/A
Tap View Yes
Digital Butler N/A
Multi-View N/A
Sound Wall N/A
Personal Screen N/A
Remote Access Yes
Camera Support N/A
360 Video Player N/A
360 Camera Support N/A
Bluetooth Low Energy Yes
WiFi Direct Yes
TV Sound to Mobile Yes
Sound Mirroring Yes
Tuner/
Broadcasting
Digital Broadcasting ATSC/ClearQAM
Analog Tuner Yes
Connectivity HDMI 2
USB 1
Component In (Y/Pb/Pr) N/A
Composite In (AV) N/A

2-5
2. Product specications
Item UN**TU7000FXZA
Connectivity Ethernet (LAN) Yes
Audio Out (Mini Jack) N/A
Digital Audio Out (Optical) 1
RF In (Terrestrial / Cable input / Satellite
input) 1/1(Common Use for Terrestrial)/0
Ex-Link ( RS-232C ) N/A
HDMI A / Return Ch. Support Yes
eARC Yes
HDMI Quick Switch Yes
WiFi Yes (WiFi5)
Bluetooth Yes (BT4.2)
Anynet+ (HDMI-CEC) Yes
Design Design New Bezel-less
Bezel Type 3 Bezel-less
Slim Type Slim look
Front Color TITAN GRAY
Light Effect (Deco) N/A
Stand Type QUAD POD
Stand Color TITAN GRAY
Additional
Feature
Adaptive Picture N/A
Active Voice Amplier N/A
Adaptive Sound Adaptive Sound
AI Streaming N/A
AI Upscale N/A
Auto Rotation N/A
Art Mode (The Frame) N/A
Ambient Mode N/A
Brightness/Color Detection Brightness Detection
Portrait Mode N/A
Accessibillity - Voice Guide US English
Accessibility - Learn TV Remote / Learn
Menu Screen US English
Accessibility - Others Enlarge / High Contrast / Multi-output Audio / Caption
Moving / Separate Closed Caption
Ultra Clean View N/A
Digital Clean View Yes
Auto Channel Search Yes
Auto Power Off Yes
Caption (Subtitle) Yes

2-6
2. Product specications
Item UN**TU7000FXZA
Additional
Feature
Connect Share™ (HDD) Yes
ConnectShare™ (USB 2.0) Yes
EPG Yes
Extended PVR N/A
Game Mode Yes (Auto Game Mode)
Freesync N/A
G-SYNC N/A
OSD Language English, Spanish, French
BT HID Built-in Yes
USB HID Support Yes
V-Chip Yes
IPv6 Support Yes
MBR Support Yes
Eco Feature Eco Sensor Yes
Power Power Supply AC110-120V 50/60Hz
Power Consumption (Max) 165 W 190 W 225 W 230 W
Power Consumption (Stand-by) 0.5 W
Power Consumption (Typical) 70 W 73 W 94 W 94 W

2-7
2. Product specications
2-4. Accessories
NOTE
• The items’ colors and shapes may vary depending on the model.
• Cables not included in the package contents can be purchased separately.
• The part code for some accessories may differ depending on your region.
• The provided accessories may vary depending on the model.
Power CableHolder-Cable Samsung Smart Remote /
Batteries (AAA x 2)
User Manual /
Regulatory Guide
55″
1
1 2 3
3
32
1 2
58″
-
75″
43″
-
50″
43″ 50″
Product Code. No Product Code. No
• Remote Control BN59-01315J
• Power Cable
3903-001117
(58" / 65" / 70")
3903-001132
(75")
• Batteries (AAA x 2) 4301-000103
• User Manual BN68-10302A
• Warranty Card (BN68-10628A) / Regulatory Guide (BN68-09371A)
(Not available in some locations)

2-8
2. Product specications
2-5. Key Features & Operation
2-5-1. 2020’ About This TV
Contact Samsung TV Info – “About This TV”
£ Settings £ Support £ About This TV
MN : "Model Number"
PD : "Purchase Date"
SN : "Serial Number"
FW : "Firmware"
FC : "Firmcode"
MI : "Model ID"
LS : "Local Set"
DI : "DUID"
MA : "Wired MAC Address"
VS : "Version"
SC 10001_Z_Z_Z
QR CODE
(Scanned & processed by email)
Important 2019/2020 TV Info:
1. Model Code
2. Serial Number
3. TV Key Device
4. Software Version
5. Status Code
6. Sub-Micom Version
7. E-Manual Version
8. Wired Mac Address: If Missing replace Main Board
9. Wireless MAC Address: Veries WiFi Operation
10. Bluetooth Address: Veries Bluetooth operation
11. Smart Control Bluetooth Mac Address
12. Smart Control Battery Status
13. Ambient Mode Operation (Q Series TVs)
14. Smart Hub Information

2-9
2. Product specications
2-5-2. New 2020’ Device Care
£ Settings £ Support £ Device Care
Manage Storage Self Diagnosis Request Support

2-10
2. Product specications
2-6. Viewing the Functions
2-6-1. Find a variety of content with one remote (US)
Smart Hub & One Remote Function (Availability of the feature may vary by region. Check before use.)
All you need is one remote to discover tons of different kinds of content. From controlling your set-top box to game
console, apps, and even live TV.
• Actual remote control may differ from image shown.
• Service may not be launched at the same time as Samsung TV, and the availability may vary by region.
2-6-2. Spend time watching, not searching (US)
Universal Guide (Availability of the feature may vary by region. Check before use.)
A curated list of content from broadcast and streaming channels, personalized to you. Now, it's easy to get to your favorite
content easily, without having to open an app.
• Content services may vary by regions and are subject to change without notications.

2-11
2. Product specications
2-6-3. Fits with your home ecosystem
Works with
Make life more connected. Samsung TV works seamlessly with Amazon Alexa, Google Assistant and AirPlay 2.
• Some features and functions provided by connected devices may not be supported or limited to use.
2-6-4. Works wth Amazon Alexa
Amazon Alexa
New Samsung TV works with Alexa so your life just got simpler. It’s easy to connect your Alexa-enabled devices. With
Samsung TV's compatibility, have Alexa turn on your TV, change channels, control volume, and more.
• Amazon, Alexa, and all related logos are trademarks of Amazon.com, Inc. or its afliates.
• This service may not be available at the time of purchase of this product and the availability may vary by region.
